Weed Eater SB180BV Owner’s Manual

(_ Trademark

Operator's Manual

Manual del Operador

Manuel de L'utilisateur

IMPORTANT MANUAL - Do not throw away
MANUAL IMPORTANTE - No Io descarte

MANUEL IMPORTANT - A Conserver

/

SB180BV

/

warnings and safety instructions. Failure to do so can

WARNING Read the operator's manual and follow all
result in serious injury, Always wear eye protection.

ADVERTENClA Lea el manual del operador y siga todas
las advertencias e instrucciones de seguridad. El no
hacerlo puede resultar en lesiones graves.

AVERTISSEMENT Ure le manuel de rutilisateur et bien
respecter tousles avertissements et toutes les instructions

de securit& Tout defaut de le faire pourrait entraTner des
blessures graves.

Electrolux Home Products, Augusta, GA 30907
WCI Outdoor Products, IRc. 530087854 7/28/00

/

='1_

oWARNINL.i: Failure to follow all

Safety Rules and Precautions can result in
serious injury.

KNOW YOUR UNIT

• Read your Operator's Manual carefully
until you completely understand and can

follow all warnings and safety instructions

before operating the unit.

• Restrict your unit to users who understand
and will follow all warnings and safety in-

structions in this manual.

PLAN AHEAD

• Always wear eye protection when operat-
ing, servicing, or performing maintenance

on your unit. Wearing eye protection will
help to prevent rocks or debris from being
blown or ricocheting into eyes and face

which can result in blindness and/or seri-

ous injury. Eye protection should meet the
requirements of ANSI Z87.1.

• Always wear foot protection. Do not go
barefoot or wear sandals.

• Always wear respirator or face mask when

working with unit in dusty environments.

• Secure hair above shoulder length. Se=
cure or remove jewelry, loose clothing, or
clothing with loosely hanging straps, ties,

tassels, etc, They can be caught in moving

parts.

• Do not operate the unit when you are tired,
ill, upset, or if you are under the influence of
alcohol, drugs, or medication.

• Keep children, bystanders, and animals
away from work area a minimum of 30 feet
(10 m) when starting or operating unit. Do
not point the blower nozzle in the direction
of people or pets.

• Inspect the area before starting the unit.
Remove all debris and hard objects such
as rocks, glass, wire, etc. that can rico-
chet, be thrown, or otherwise cause injury
or damage during operation.

HANDLE FUEL WITH CAUTION, IT
IS HIGHLY FLAMMABLE

• Eliminate all sources of sparks or flame
(including smoking, open flames, or work

that can cause sparks) in the areas where
fuel is mixed, poured, or stored.

• Mix and pour fuel in an outdoor area; store

fuel in a cool, dry, well ventilated place; and

use an approved, marked container for all

fuel purposes.

• Do not smoke while handling fuel or while
operating the unit.

• Make sure the unit is properly assembled
and in good operating condition.

• Do not fill fuel tank while engine is running.

• Avoid spilling fuel or oil. Wipe up fuel spills
before starting engine.

• Move at least 10 feet 3 meters away from

fuel and fueling site before start ng engine.

• Always store gasoline in a container ap-
proved for flammable liquids.

OPERATE YOUR UNIT SAFELY

WARNING: Stop the engine before

opening the vacuum inlet door. The engine

must be stopped and the impeller blades no
longer turning to avoid serious injury from the

rotating blades.

• Inspect unit before each use for worn,
loose, missing, or damaged parts. Do not

use until unit is in proper working order.

• Keep outside surfaces free of oil and fuel.

• Never start or run engine inside a closed
room or building. Breathing exhaust fumes

can kill.

• To avoid static electricity shock, do not

wear rubber gloves or any other insulated
gloves while operating the unit.

• Do not set unit on any surface excel3t a

clean, hard area while engine is running,

Debris such as gravel, sand, dust, grass,

etc. could be picked up by the air intake
and thrown out through discharge open-

ing, damaging unit, property, or causing

serious injury to bystanders or operator.

• Avoid dangerous environments. Do not
use in unventilated areas or where explo-

sive vapors or carbon monoxide build up
could be present.

• DO not overreach or use from unstable

surfaces such as ladders, trees, steep
slopes, rooftops, etc. Keep firm footing

and balance at all times.

• Never place objects inside the blower

tubes; always direct the blowing debris
away from people, animals, glass, and

solid objects such as trees, automobiles,
walls, etc, The force of air can cause

rocks, dirt, or sticks to be thrown or to rico-

chet which can hurt people or animals,

break glass, or cause other damage,

• Never run unit without the proper equip-
ment attached. When using your unit as a
blower, always install blower tubes. When
using your unit as avacuum, always install

vacuum tubes and vacuum bag assembly.

Make sure vacuum bag assembly is com-
pletely zipped.

• Check air intake opening, blower tubes,

vacuum tubes, and elbow tube frequently,
always with the engine stopped and the
spark plug disconnected, Keep vents and
discharge tubes free of debris which can
accumulate and restrict proper air flow.

• Never place any object in the air intake

opening as this could restrict proper air
flow and cause damage to the unit

• Never use for spreading chemicals, fertil-
izers, or other substances which may con-

fain toxic materials.

• To avoid spreading fire, do not use near
leaf or brush fires, fireplaces, barbecue
pits, ashtrays, etc,

• Use only for jobs explained in this manual.

-2-

MAINTAIN YOUR UNIT PROPERLY

• Have all maintenance other than the rec-
ommended procedures described in the

Operator's Manual performed by your
Service Dealer.

• Disconnect spark plug before performing
maintenance except for carburetor adjust-

ments.

• Use only recommended WEED EATER
replacement parts; use of any other parts
may void your warranty and cause dam-

age to your unit.

• Empty the fuel tank before storing the unit.
Use up fuel left in carburetor by starting the
engine and letting it run until it stops.

• Do not use any accessory or attachment
other than those recommended by the

manufacturer for use with your unit.

• Do not store the unit or fuel in a closed area

where fuel vapors can reach sparks or an

open flame from water heaters, electric
motors or switches, furnaces, etc.

• Store in a dry area out of reach of children.

SPECIAL NOTICE: For users on U.S.

Forest Land and in some states, including

California(Public Resources Codes 4442
and 4443), Idaho, Maine, Minnesota, New
Jersey, Oregon, and Washington: Certain in-

ternal combustion engines operated on for-
est, brush, and/or grass covered land in the
above areas are required to be equipped
with a spark arrestor, maintained in effective

working order, or the engine must be con-
structed, equipped, and maintained for the

prevention of fire. Check with your state or
local authorities for regulations pertaining to
these requirements. Failure to follow these

requirements is a violation of the law. This
unit is not factory equipped with a spark ar-
restor; however, a spark arrestor is available

as an optional part. If a spark arrestor is re-
quired in your area, contact your Authorized
Service Dealer for the correct kit. The spark
arrestor, blower tubes, and nozzles must be

assembled to the unit to be in full compliance
with the regulations.

SPECIAL NOTICE: Exposure to vibra-
tions through prolonged use of gasoline

powered hand tools could cause blood ves-
sel or nerve damage in the fingers, hands,

and joints of people prone to circulation dis-
orders or abnormal swelling. Prolonged use

in cold weather has been linked to blood ves-
sel damage in otherwise healthy people. If

symptoms occur such as numbness, pain,
loss of strength, change in skin color or tex-

ture, or loss of feeling in the fingers, hands, or
joints, discontinue the use of this tool and
seek medical attention. An antivibrafion sys-

tem does not guarantee the avoidance of
these problems. Users who operate power

tools on a continual and regular basis must
monitor closely their physical condition and

the condition of this tool.

PREPARATION

_ib WARNING: Stop the engine and be

sure the impeller blades have stopped turn-

ing before opening the vacuum inlet door or
attempting to insert or remove the vacuum
tubes. The rotating blades can cause seri-
ous injury.

_kWARNING: If you receive your unit
assembled, check each step to insure your

unit is properly assembled. Follow all safety

information in the manual and on the unit.

BLOWER TUBE ASSEMBLY

• Assemble the blower tube and nozzle to

the unit (turn clockwise to tighten).

SHOULDER STRAP ASSEMBLY

(for blower use only)

• Pass the shoulder strap over your head

and onto your left shoulder.

• Snap the hook onto the retainer on the top

handle.

_ Retainer

VACUUM BAG ASSEMBLY

• Open the zipper on the vacuum bag and in-

sert the elbow tube.

• Push the end of the elbow tube with the

grooves through the small bag tube open-

ing. Make sure the bag tube opening is

flush against large raised rib on the tube.

• Close the zipper on the bag. Make sure the

zipper is closed completely and the zipper
seam is tucked toward inside of the bag.

Raised Rib_ _Bag Tube

Zippe[ [

f_ Opening

-3-

VACUUM TUBE ASSEMBLY

• Remove the blower tube from the engine.

• Insert a screwdriver into the latch area on
the vacuum inlet cover.

• Gently tilt the tip of the screwdriver forward
toward blower outlet while pulling up on the
vacuum inlet cover with your other hand.

• Hold the vacuum inlet cover open until up-

per vacuum tube is installed.

[ i k Latch Are

_M,_ utlet

I_ Cover_

• Assemble upper vacuum to unit; turn

clockwise to tighten.

• Align slanted end of lower vacuum tube as

shown. Push lower vacuum tube into up-
per vacuum tube.

• Insert the elbow tube into the blower outlet.

Make sure elbow tube is curved to the left.

• Turn tube counterclockwise to tighten.

Elbow Tube

The Left

Blower a

Vacuum

= Inlet

YOU MUST make sure the tubes are secure

before using the unit.

Eye

Slanted

Vacuum Inlet

• When converting back to the blower fea-
ture, make sure that the latch on the vacu-

um inlet cover is securely fastened.

SHOULDER STRAP ADJUSTMENT

(for vacuum bag)

• Hold the unit as shown below.

• Pass the shoulder strap over your head

and onto your left shoulder.

• Snap the hook onto the retainer on the top

handle.

• Extend your right arm toward the rear of
the vacuum bag.

• Adjust shoulder strap until the vacuum

bag/shoulder strap seam lies between

your thumb and index finger.

• Make sure air flows freely from the elbow
tube into bag. If bag is kinked, the unit will

not operate properly.

BLOWER VACUUM

OPERATING TIPS

• To reduce the risk of hearing loss associat-
ed with sound level(s), hearing protection

is required.

• To reduce the risk of injury associated with
contacting rotating parts, stop the engine

before installing or removing attachments.
Do not operate without guards in place.

• Operate power equipment only at reason-
able hours-not early in the morning or late at

night when people might be disturbed. Com-
ply with times listed in local ordinances. Usu-

al recommendations are 9:00 a.m. to 5:00

p.m., Monday through Saturday.

• To reduce noise levels, limit the number of

pieces of equipment used at any one time.

• To reduce noise levels, operate power

blowers at the lowest possible throttle

speed to do the job.

• Use rakes and brooms to loosen debris

before blowing.

• In dusty conditions, slightly dampen sur-
faces or use a mister attachment when
water is available.

• Conserve water by using power blowers

instead of hoses for many lawn and gar-

-4-

den applications, including areas such as
gutters, screens, patios, grills, porches,
and gardens.

• Watch out for children, pets, open win-
dows, or freshly washed cars. Blow debris
away safely,

• Usethe full blowernozzleextension sothe
air stream can work close to the ground.

• After using blowers and other equipment,
CLEAN UP! Dispose of debris in trash re-
ceptacles.

This engine is certified to operate on un-
leaded gasoline. Gasoline must be mixed
with a good quality 2-cycle air-cooled engine
oil designed to be mixed at a ratio of 40:1.

Poulan/Weed Eater brand oil is recom-

mended. (A 40:1 ratio is obtained by mixing

3.2 ounces of oil with 1 gallon of unleaded

_naSOline. When mixing fuel follow the

structions printed on the conta her. Always

read and follow safety rules under HANDLE

FUEL WITH CAUTION in the SAFETY
RULES section.

TO STOP THE ENGINE:

• The ON/STOP switch is used to stop the en-
gine. The switch stays in the ON position.

To stop engine, press and hold the switch

in the STOP position until the engine comes

to a complete stop.

BEFORE STARTING THE ENGINE:

• Fuel the engine. Move at least 10 feet (3
meters) away from the fueling site.

• Hold the unit in the starting position as
shown. Make sure the blower end is di-

rected away from people, animals, glass,
and solid objects.

STARTING POSITION

BLOWER VACUUM

oWARNIN£.i: When starting engine,

hold the unit as illustrated. Do not set unit on
any surface except a clean, hard area when

starting engine or while engine is running.

Debris such as gravel, sand, dust, grass,
etc. could be picked up by the air intake and
thrown out through the discharge opening,
damaging the unit or property, or causing se-
rious injury to bystanders or the operator.

Throttle
Trigger

iThrottle

Lock

(shown in HALF CHOKE position)

STARTING A COLD ENGINE OR A
WARM ENGINE AFTER RUNNING
OUT OF FUEL:

• Move choke to FULL CHOKE position.

• Activate the throttle iock as follows:

• squeeze and hold throttle trigger;

• press and hold throttle lock, then

• release the throttle trigger

• Pull starter rope handle sharply until en-
gine attempts to run, but NO MORE THAN6

PULLS

LISTEN: The engine may sound as if it is

trying to start before the 6th pull. This
sound may be hard to hear. If so, go to the

next step immediataiy.

• Move choke to HALF CHOKE position.

• Pull starter rope handle sharply until en-
gine runs, but no more than 6 pulls.

NOTE: If engine has not started after 6
pulls, repeat all of the above steps.

• Allow engine to run for 10 to 15 seconds,
then move choke to OFF CHOKE position.

• Squeeze and release the throttle trigger to

release the throttle lock.

NOTE: If engine dies with choke at OFF

CHOKE position, move the choke to the HALF
CHOKE position and pull the starter rope 5

more times. If engine does not start and op-

erate properly, refer to CARBURETOR AD-
JUSTMENTS.

• To stop engine, press and hold the switch

in the STOPposition until the engine comes

to a complete stop.

STARTING A WARM ENGINE:

• Move choke to HALF CHOKE position.

• Activate the throttle lock.

• Pull starter rope handle sharply until en-
gine runs, but no more than 6 pulls.

• Move choke to OFFCHOKEposition. Then,
squeeze and release the throttle trigger to

release the throttle lock.

NOTE: If engine does not run after 5 pulls, it
is probably flooded. Wait a few minutes and

repeat procedure with choke at OFF CHOKE.

• To stop engine, press and hold the switch

in the STOPposition until the engine comes

to a complete stop.

-5-
