1 Bluetooth buttonBluetooth button to launch Windows Ink Workspace, customizable in Windows pen settings.
2 Side-switchesTwo side-switches; Tip-side switch for power on/off; Both switches for changing protocol.
3 Pen NibExchangeable pen nib
Deutsch
1 Bluetooth-TasteBluetooth-Taste zum Starten des Windows Ink-Arbeitsbereichs, kann in den Windows-Stifteinstellungen
2 StifttastenZwei Stifttasten, untere Stifttaste zum Ein- und Ausschalten der Stromversorgung, beide Tasten zum
2
3 StiftspitzeAustauschbare Stiftspitze
3
angepasst werden.
Ändern des Protokolls.
English
Deutsch
Francais
1
1 Bouton BluetoothBouton Bluetooth pour démarrer l'Espace de travail Windows Ink,
2 Boutons latérauxDeux boutons latéraux ; Bouton latéral côté pointe pour mise sous tension / hors tension ;
3 Pointe de styletPointe de stylet remplaçable
Italiano
1 Pulsante BluetoothPulsante Bluetooth per lanciare Area Windows Ink, personalizzabile nelle impostazioni penna Windows.
2 Pulsanti lateraliDue pulsanti laterali; pulsante sul lato della punta per on/off; entrambi i pulsanti per cambiare il protocollo.
2
3 Punta della pennaPunta della penna intercambiabile
3
personnalisable dans les paramètres du stylet Windows.
Les deux boutons servent à changer de protocole.
Francais
Italiano
Espanol
1
1 Botón de BluetoothBotón de Bluetooth para abrir Área de trabajo de Windows Ink;
2 Botones lateralesDos botones laterales: el botón más cercano a la punta para el encendido/apagado;
Bluetooth 버튼Bluetooth 버튼을통해 Windows Ink Workspace를 시작하고, Windows 펜 설정에서 Bluetooth 버튼을 맞춤
2
사이드 스위치전원을 켜고 끄는 팁 사이드 스위치 두 개가 있으며, 두 가지 모두 프로토콜을 바꾸는 데 사용됩니다.
3
펜심교체용 펜심
3
personalizable en los ajustes del lápiz de Windows.
ambos botones para cambiar el protocolo.
설정할 수 있습니다.
Espanol
日本語
한국어
Get started with your Bamboo Ink Plus
English
1. Windows device update
Confirm your stylus driver is up to date.
Go to: www.wacom.com/inkplusgo
2.
To get started with your Bamboo Ink Plus
a. Connect your
stylus to your
computer or
USB charger
with the
included cable.
b. Turn on your
stylus by
pressing the
tip-side switch.
3h
3. Changing the protocol setting
Press 2 seconds
If the stylus does not work on your device,
press and hold both side-switches at the
same time for 2 seconds to change the
setting.
4.
Pair your Bamboo Ink Plus with your device
6 seconds
a. From the Windows Start menu, select
Settings > Devices > Bluetooth® and
other devices. Make sure Bluetooth is
“On”.
b. Hold the Bluetooth button for 6
seconds. The LED starts blinking.
c. Select “+ Add Bluetooth or other
devices”. From the list of devices, select
“Bamboo Ink Plus” and click on “Pair”.
5. Open Windows Ink apps
Depends on devices, setting may differ.
You can also change what the Bluetooth
button does in Settings > Devices > Pen &
Windows Ink.
Click Bluetooth button
to open Windows Ink
Workspace.
Double click to open
Screen Sketch.
Click and hold to open
Sticky Notes.
Bamboo nib kitLearn more about your stylus on
wacom.com
• To learn more about your stylus, go to:
From left to right:
firm, soft, blue
On certain devices the blue nib from the
nib kit can enhance your pen experience.
Please check for device compatibility.
Insert the pen nib into the holder, slide
to the side and gently pull up to remove
the nib. Insert the new nib and push with
finger tip.
www.wacom.com/inkplusgo
• Mobile solutions for your stylus: Bamboo
Paper app.
Erste Schritte mit dem Bamboo Ink Plus
1. Update des Windows-Geräts
Überprüfen Sie, ob der Treiber des
Eingabestifts aktuell ist.
Mehr dazu unter:
www.wacom.com/inkplusgo
2. Erste Schritte mit dem Bamboo Ink Plus
a. Verbinden Sie
den Eingabestift
über das
mitgelieferte
Kabel mit einem
Computer
oder USBLadeadapter.
b. Schalten Sie
den Eingabestift
ein, indem Sie die untere Taste drücken.
3 Std.
3. Ändern der Protokolleinstellung
Wenn der Eingabestift auf Ihrem Gerät
nicht funktioniert, halten Sie beide
Stifttasten 2 Sekunden lang gedrückt, um
die Einstellung zu ändern.
2 Sekunden lang drücken
Deutsch
4.
Koppeln des Bamboo Ink Plus mit einem Gerät
6 Sekunden
a. Wählen Sie im Windows-Startmenü
„Einstellungen“ > „Geräte“ > „Bluetoothund andere Geräte“. Stellen Sie sicher,
dass Bluetooth auf „Ein“ gestellt ist.
b. Halten Sie die Bluetooth-Taste 6
Sekunden lang gedrückt. Die LED
beginnt zu blinken.
c. Wählen Sie „Bluetooth- oder anderes
Gerät hinzufügen“. Wählen Sie in der
Geräteliste „Bamboo Ink Plus“ aus, und
klicken Sie auf „Koppeln“.
5. Öffnen der Windows Ink-Apps
Je nach Gerät können die Einstellungen
abweichen. Unter „Einstellungen“ > „Geräte“
> „Stift & Windows Ink“ können Sie die
Funktion der Bluetooth-Taste anpassen.
Drücken Sie einmal
die Bluetooth-Taste,
um den Windows InkArbeitsbereich zu öffnen.
Drücken Sie sie zweimal,
um „Bildschirmskizze“ zu
starten.
Halten Sie die
Taste gedrückt, um
„Kurznotizen“ zu öffnen.
Bamboo Stiftspitzen-SetErfahren Sie mehr über Ihren
Eingabestift auf wacom.com
Von links nach rechts:
fest, weich, blau
Auf bestimmten Geräten kann die blaue
Stiftspitze aus dem Stiftspitzen-Set Ihre
Stifterfahrungen verbessern. Überprüfen
Sie das Gerät auf Kompatibilität.
Setzen Sie die Stiftspitze in die Halterung,
schieben Sie den Stift zur Seite und ziehen
ihn vorsichtig nach oben, um die Spitze zu
entfernen. Setzen Sie die neue Spitze ein,
und drücken Sie sie mit der Fingerspitze
fest.
• Weitere Informationen zum Eingabestift
finden Sie unter:
www.wacom.com/inkplusgo
• Mobile Lösungen für Ihren Eingabestift:
Bamboo Paper-App.
Mise en route de votre Bamboo Ink Plus
1. Mise à jour de périphériques Windows
Confirmez que le pilote de votre stylet
est à jour. Rendez-vous sur :
www.wacom.com/inkplusgo
2.
Mise en route de votre Bamboo Ink Plus
a. Connectez
votre stylet à
votre ordinateur
ou à votre
chargeur USB à
l'aide du câble
livré.
b. Allumez votre
stylet en
appuyant sur le
bouton côté pointe.
3 h
3.
Changement des paramètres de protocole
Appuyez pendant 2 secondes
Si le stylet ne fonctionne pas sur votre
appareil, appuyez simultanément et sans
relâcher sur les deux boutons latéraux
pendant 2 secondes pour modifier les
paramètres.
Français
4. Couplez votre Bamboo Ink Plus avec
votre appareil
6 secondes
a. À partir du menu Démarrer de
Windows, choisissez aramètres >
Périphériques > Bluetooth® et autres
périphériques. Assurez-vous que le
Bluetooth est sur « Activé ».
b. Maintenez le bouton Bluetooth enfoncé
pendant 6 secondes. Le voyant LED
clignote.
c. Sélectionnez « + Ajouter Bluetooth ou
un autre périphérique ». Dans la liste des
périphériques, sélectionnez « Bamboo
Ink Plus » puis cliquez sur « Coupler ».
5. Ouvrez les applications Windows Ink
Les paramètres peuvent différer en
fonction des périphériques. Vous
pouvez aussi changer la fonction du
bouton Bluetooth dans Paramètres >
Périphériques > Stylet & Windows Ink.
Cliquez sur le bouton
Bluetooth pour ouvrir
l'Espace de travail
Windows Ink.
Double cliquez ensuite
pour ouvrir Croquis sur
capture d'écran.
Cliquez sans relâcher
pour ouvrir l'application
Pense-bête.
Kit de pointes Bamboo
De gauche à droite :
ferme, doux, bleu
Sur certains périphériques, la pointe de
stylet bleue du kit de pointes peut enrichir
votre expérience. Veuillez vérifier la
compatibilité de votre appareil.
Insérez le pointe du stylet dans le portestylet, faites-le coulisser sur le côté et
tirez doucement vers le haut pour retirer la
pointe. Insérez la nouvelle pointe et appuyez
dessus avec le bout de votre doigt.
En savoir plus sur votre stylet sur
wacom.com
• Pour plus d'informations sur votre stylet,
allez sur :
www.wacom.com/inkplusgo
• Solutions mobiles pour votre stylet :
Application Bamboo Paper
Introduzione all'uso di Bamboo Ink Plus
Italiano
1. Aggiornamento dispositivo Windows
Confermare che il driver della penna è
aggiornato.
Accedere a: www.wacom.com/inkplusgo
2. Introduzione all'uso di Bamboo Ink Plus
a. Collegare
la penna al
computer o
all’adattatore
di carica USB
con il cavo in
dotazione.
b. Accendere
la penna
premendo il
pulsante sul lato della punta.
3h
3.
Modificare l'impostazione del protocollo
Premere per 2 secondi
Se la penna non funziona sul dispositivo,
tenere premuti entrambi i pulsanti laterali
contemporaneamente per 2 secondi per
modificare l’impostazione.
4.
Associare Bamboo Ink Plus con il dispositivo
6 secondi
a. Dal menu Start di Windows, selezionare
Impostazioni > Dispositivi > Bluetooth®
e altri dispositivi. Verificare che l’opzione
Bluetooth sia impostata su “Attivato”.
b. Tenere premuto il pulsante Bluetooth per
6 secondi. Il LED inizia a lampeggiare.
c. Selezionare “+ Aggiungi dispositivo
Bluetooth o di altro tipo”. Dall'elenco dei
dispositivi, selezionare “Bamboo Ink Plus”
e fare clic su “Associa”.
5. Aprire le app Windows Ink
Le impostazioni potrebbero differire
a seconda del dispositivo. È inoltre
possibile cambiare le funzioni del pulsante
Bluetooth, selezionando Impostazioni >
Dispositivi > Penna & Windows Ink.
Fare clic sul pulsante
Bluetooth per aprire
Area Windows Ink.
Fare doppio clic per
aprire Note su schermo.
Tenere premuto per
aprire Memo.
Kit punte Bamboo
Da sinistra a destra:
pesante, leggera, blu
Su alcuni dispositivi la punta blu del kit
può migliorare l'esperienza d'uso della
penna. Verificare la compatibilità del
dispositivo.
Inserire la punta della penna nel supporto, far
scorrere di lato e tirare delicatamente verso
l'alto per rimuovere la punta. Inserire la nuova
punta e spingere con la punta del dito.
Ulteriori informazioni sulla penna
su wacom.com
• Per ulteriori informazioni sulla penna,
visitare il sito Web:
www.wacom.com/inkplusgo
• Soluzioni mobili per la penna:
App Bamboo Paper.
Primeros pasos con Bamboo Ink Plus
1. Actualización del dispositivo Windows
Compruebe si el controlador del lápiz
está actualizado.
Visite: www.wacom.com/inkplusgo
2. Introducción al uso de Bamboo Ink Plus
a. Conecte el lápiz
al ordenador o
al cargador USB
con el cable
incluido.
b. Pulse el botón
más cercano a
la punta para
encender el
lápiz.
3 h
3. Cambio de la configuración del protocolo
Pulse durante 2 segundos
Si el lápiz no funciona en su dispositivo,
mantenga pulsados los dos botones
laterales al mismo tiempo durante
2 segundos para cambiar la configuración.
Español
4.
Emparejamiento de Bamboo Ink Plus con su
dispositivo
6 segundos
a. Desde el menú Inicio de Windows, seleccione
Configuración > Dispositivos > Bluetooth®
y otros dispositivos. Asegúrese de que
Bluetooth esté «Activado».
b. Mantenga pulsado el botón de Bluetooth
durante 6 segundos. El led comienza a
parpadear.
c. Seleccione «+ Agregar Bluetooth u otro
dispositivo». En la lista de dispositivos,
seleccione «Bamboo Ink Plus» y haga clic en
«Emparejar».
5. Abra las aplicaciones de Windows Ink
Es posible que los ajustes varíen según
el dispositivo. También puede modificar
las funciones del botón de Bluetooth en
Configuración > Dispositivos > Lápiz y
Windows Ink.
Haga clic en el botón
de Bluetooth para abrir
Área de trabajo de
Windows Ink.
Haga doble clic para
abrir Anotación en
captura de pantalla.
Haga clic y mantenga
pulsado para abrir
Notas rápidas.
Kit de puntas Bamboo
De izquierda a derecha:
firme, suave y azul
En algunos dispositivos, la punta azul del
kit de puntas puede mejorar su experiencia
con el lápiz. Compruebe la compatibilidad
con el dispositivo.
Inserte la punta del lápiz en el soporte, ladee
el lápiz y tire de este suavemente hacia
arriba para retirar la punta. Inserte la nueva
punta y empújela con la punta del dedo.
Obtenga más información sobre
su lápiz en wacom.com
• Para obtener más información acerca de
su lápiz, consulte:
www.wacom.com/inkplusgo
• Soluciones móviles para su lápiz:
Aplicación Bamboo Paper
