WHEEL LOADER
he WL 50 offers high payloads to provide better
T
breakout force and lifting capacities. Its ergonomic
design enhances operator comfort and improves
productivity. Operating elements, including a multifunctional single lever control and an additional lever for
third control circuit, are conveniently arranged next to
the driver
features excellent visibility and an infinitely adjustable
steering column. The driver’s platform is side tilting for
easy access and serviceability. This unit features a
hydraulically operated centrally-articulated pendulum
steering system. The WL 50 provides a tight turning
radius for added maneuverability in small areas.
’s seat for easy operation. Driver’s cab
WL 50
www.wackerneuson.com
TECHNICAL DATA
L 50 WHEEL LOADER
W
Make/Type Deutz BF4M 2011
odel turbo-charged, liquid-cooled, 4-cylinder diesel engine
M
ENGINEPERFORMANCEDIMENSIONS
Max. engine output HP (kW) 75 (56)
Drive speed 2 speed mph (kph) 0 – 3.7 (0 – 6)
3
ucket capacity yd
B
Drive Hydrostatic all-wheel drive with
xles Outboard planetary axles - rigid
A
Brake Hydrostatic drive and hub brake with braking-
tandard tires 405/70-18 EM (earthmoving)
S
A- Overall length with standard bucket in (mm) 213 (5417)
A' Overall length without bucket in (mm) 179 (4545)
- Axle centre to bucket pivot-point in (mm) 41 (1030)
B
C- Wheelbase in (mm) 79 (2005)
D- Rear overhang in (mm) 57 (1445)
- Overhead loading height i
E
ax. height of bucket pivot point in (mm) 1
F- M
H- Max. dumping height in (mm) 101 (2569)
I- Scraping depth in (mm) 2 (50)
K- Reach at max dump height in (mm) 28 (723)
L- Height of cab in (mm) 103 (2602)
M- Total working height in (mm) 161 (4090)
N- Maximum dumping angle 38°
O- Reverse roll angle on ground 43°
P- Reverse roll angle at max. lift height 45°
Q- Inside turning radius in (mm) 61 (1546)
R- Total width, standard in (mm) 73 (1840)
T- Ground clearance in (mm) 15 (377)
V- Width across cab in (mm) 50 (1251)
W- Track width in (mm) 55 (1400)
Z- Maximum turning radius in (mm) 154 (3908)
Weight lbs (kg) 10,660 (4835)
3
m
(
)
automotive control
inching pedal, operating on all 4 wheels
n (mm) 122 (3094)
– 12.4 (0 – 20)
0
0.98 (0.75)
31 (3336)
YDRAULICS
H
ork pump Gear pump
W
low rate - working gpm (l/min) 17 (64)
F
Pressure psi (bar) 3046 (210)
LOADER
esign Z-bar lift frame
D
Hydraulic lifting capacity lb (kg) 9761 (4428)
reak-out force lb (kg) 7713 (3499)
B
traight tipping load (bucket) lb (kg) 6870 (3116)
S
Articulated tipping load (bucket) lb (kg) 5608 (2544)
traight tipping load (pallet) lb (kg) 5708 (2589)
S
r
A
ticulated tipping load (pallets) lb (kg) 4665 (2116)
STEERING
System Hydraulically operated centrally-
Oscillation angle ±12°
Articulation angle ±45°
iculated pendulum steering
art
Noise level
A
Noise level (L
W
) 101 dB(A)
www.wackerneuson.com
WL 50/Dec-2007/Layout Goes Studio/Printing Marek Group
