Wacker Neuson PDT 2A, PDT 3A, PDI 3A, PDT 2, PDT 3 Operator's Manual

0154614en 006
0309

Pump

PDT 2A
PDI 2A
PDT 3A

OPERATOR’S MANUAL

0154614EN

PDI 3A

PD 2A/3A Table of Contents

1. Foreword 5

2. Safety Information 6

2.1 Laws Pertaining to Spark Arresters ...................................................... 6

2.2 Operating Safety .................................................................................. 8

2.3 Operator Safety while using Internal Combustion Engines .................. 9

2.4 Service Safety ...................................................................................... 9

2.5 Label Locations .................................................................................. 10

2.6 Safety Labels ...................................................................................... 11

3. Technical Data 13

3.1 Engine ................................................................................................ 13

3.2 Pump .................................................................................................. 14

3.3 Sound Measurements ........................................................................ 15

3.4 Dimensions ......................................................................................... 16

4. Operation 18

4.1 Application .......................................................................................... 18

4.2 Recommended Fuel ........................................................................... 18

4.3 Transporting the Machine ................................................................... 19

4.4 Priming Pump ..................................................................................... 20

4.5 Before Starting ................................................................................... 20

4.6 To Start ............................................................................................... 21

4.7 To Stop ............................................................................................... 21

4.8 Operation ............................................................................................ 22

4.9 Accessories ........................................................................................ 22

4.10 Hoses and Clamps ............................................................................. 23

5. Maintenance 24

5.1 Periodic Maintenance Schedule ......................................................... 24

5.2 Changing Engine Oil .......................................................................... 25

5.3 Servicing Air Cleaner .......................................................................... 26

wc_bo0154614006enTOC.fm 3

Table of Contents PD 2A/3A

5.4 Spark Plug ...........................................................................................27

5.5 Gear Case ...........................................................................................28

5.6 Connecting Rod Bearing .....................................................................29

5.7 Cleaning Pump ....................................................................................29

5.8 Cleaning Sediment Cup ......................................................................30

5.9 Carburetor Adjustment ........................................................................30

5.10 Storage ................................................................................................31

5.11 Troubleshooting ...................................................................................32

5.12 Decomissioning ...................................................................................33

wc_bo0154614006enTOC.fm 4

WARNING

1 Foreword

Foreword

CALIFORNIA

Proposition 65 Warning:

Engine exhaust, some of its constituents, and certain vehicle
components, contain or emit chemicals known to the State of
California to cause cancer and birth defects or other reproductive
harm.

This manual provides information and procedures to safely operate
and maintain this Wacker model. For your own safety and protection
from injury, carefully read, understand and observe the safety
instructions described in this manual.

Keep this manual or a copy of it with the machine. If you lose this
manual or need an additional copy, please contact Wacker
Corporation. This machine is built with user safety in mind; however,
it can present hazards if improperly operated and serviced. Follow
operating instructions carefully! If you have questions about operating
or servicing this equipment, please contact Wacker Corporation.

The information contained in this manual was based on machines in
production at the time of publication. Wacker Corporation reserves the
right to change any portion of this information without notice.

All rights, especially copying and distribution rights, are reserved.

Copyright 2008 by Wacker Corporation.

No part of this publication may be reproduced in any form or by any
means, electronic or mechanical, including photocopying, without
express written permission from Wacker Corporation.

Any type of reproduction or distribution not authorized by Wacker
Corporation represents an infringement of valid copyrights and will be
prosecuted. We expressly reserve the right to make technical
modifications, even without due notice, which aim at improving our
machines or their safety standards.

wc_tx000001gb.fm 5

Safety Information PD 2A/3A

2. Safety Information

This manual contains DANGER, WARNING, CAUTION, NOTICE and
NOTE callouts which must be followed to reduce the possibility of
personal injury, damage to the equipment, or improper service.

This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.

DANGER indicates a hazardous situation which, if not avoided, will
result in death or serious injury.

DANGER

WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.

WARNING

CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.

CAUTION

NOTICE: Used without the safety alert symbol, NOTICE indicates a
hazardous situation which, if not avoided, could result in property
damage.

Note: Contains additional information important to a procedure.

2.1 Laws Pertaining to Spark Arresters

Notice: State Health Safety Codes and Public Resources Codes
specify that in certain locations spark arresters be used on internal
combustion engines that use hydrocarbon fuels. A spark arrester is a
device designed to prevent accidental discharge of sparks or flames
from the engine exhaust. Spark arresters are qualified and rated by
the United States Forest Service for this purpose.

wc_si000085gb.fm 6

PD 2A/3A Safety Information

In order to comply with local laws regarding spark arresters, consult
the engine distributor or the local Health and Safety Administrator.

wc_si000085gb.fm 7

Safety Information PD 2A/3A

2.2 Operating Safety

Internal combustion engines present special hazards during operation
and fueling. Read and follow the warning instructions in the engine
Owner’s Manual and the safety guidelines below. Failure to follow the

DANGER

2.2.1 NEVER allow anyone to operate this equipment without proper

2.2.2 NEVER touch the engine or muffler while the engine is on or

2.2.3 NEVER use accessories or attachments that are not recommended by

2.2.4 NEVER pump volatile, flammable or low flash point fluids. These fluids

2.2.5 NEVER pump corrosive chemicals or water containing toxic

warnings and safety standards could result in severe injury or death.

training. People operating this equipment must be familiar with the
risks and hazards associated with it.

immediately after it has been turned off. These areas get hot and may
cause burns.

Wacker. Damage to equipment and injury to the user may result.

could ignite or explode.

substances. These fluids could create serious health and
environmental hazards. Contact local authorities for assistance.

2.2.6 ALWAYS read, understand, and follow procedures in the Operator’s
Manual before attempting to operate the machine.

2.2.7 ALWAYS be sure operator is familiar with proper safety precautions
and operation techniques before using machine.

2.2.8 ALWAYS be sure the rammer will not tip over, roll, slide, or fall when
not being operated.

2.2.9 ALWAYS close fuel valve on engines equipped with one when
machine is not being operated.

2.2.10 ALWAYS store the machine properly when it is not being used. The
machine should be stored in a clean, dry location out of the reach of
children.

wc_si000085gb.fm 8

PD 2A/3A Safety Information

2.3 Operator Safety while using Internal Combustion Engines

A poorly maintained machine can become a safety hazard! In order
for the machine to operate safely and properly over a long period of
time, periodic maintenance and occasional repairs are necessary.

WARNING

2.3.1 DO NOT smoke while operating the machine.

2.3.2 DO NOT smoke when refueling the engine.

2.3.3 DO NOT refuel a hot or running engine.

2.3.4 DO NOT refuel the engine near an open flame.

2.3.5 DO NOT spill fuel when refueling the engine.

2.3.6 DO NOT run the engine near open flames.

2.3.7 ALWAYS refill the fuel tank in a well-ventilated area.

2.3.8 ALWAYS replace the fuel tank cap after refueling.

2.4 Service Safety

A poorly maintained machine can become a safety hazard! In order
for the machine to operate safely and properly over a long period of
time, periodic maintenance and occasional repairs are necessary.

WARNING

2.4.1 DO NOT attempt to clean or service the machine while it is running.
Rotating parts can cause severe injury.

2.4.2 DO NOT crank a flooded engine with the spark plug removed on
gasoline-powered engines. Fuel trapped in the cylinder will squirt out
the spark plug opening.

2.4.3 DO NOT test for spark on gasoline-powered engines if the engine is
flooded or the smell of gasoline is present. A stray spark could ignite
the fumes.

2.4.4 DO NOT use gasoline or other types of fuels or flammable solvents to
clean parts, especially in enclosed areas. Fumes from fuels and
solvents can become explosive.

2.4.5 ALWAYS operate the machine with all safety devices and guards in
place and in working order.

2.4.6 ALWAYS keep the area around the muffler free of debris such as
leaves, paper, cartons, etc. A hot muffler could ignite the debris and
start a fire.

2.4.7 ALWAYS replace worn or damaged components with spare parts
designed and recommended by Wacker Corporation.

2.4.8 ALWAYS disconnect the spark plug on machines equipped with
gasoline engines, before servicing, to avoid accidental start-up.

wc_si000085gb.fm 9

Safety Information PD 2A/3A

2.5 Label Locations

CAUTION

GREASE CONNECTING
ROD BEARING MONTHL

ENGRASE RODAMIENTO
DE LA BIELA
MENSUALMENTE

VORSICHT

PLEUELLAGER JEDEN

Y

MONAT SCHMIEREN

PRECAUTIONPRECAUCION

GRAISSER ROULEMENT
DE LA BIELLE TOUS
LES MOIS

30744

WARNING

DO NOT OPERATE WITHOUT SAFETY GUARDS.
READ AND UNDERSTAND INSTRUCTION BOOK.

WARNUNG

NICHT OHNE SCHUTZVORRICHTUNG
BETREIBEN. BEDIENUNGSANWEISUNG
GENAU DURCHLESEN.

ADVERTENCIA

NO OPERE SIN LOS DISPOSITIVOS
DE SEGURIDAD. LEA Y ENTIENDA
PRIMERO LAS INSTRUCCIONES.

AVERTISSEMENT

NE PAS OPERER SANS DEFLECTEUR
PROTECTIF. LIRE ET COMPRENDRE
LES INSTRUCTIONS DE SERVICE.

117431

wc_si000085gb.fm 10

PD 2A/3A Safety Information

2.6 Safety Labels

Wacker machines use international pictorial labels where needed.
These labels are described below:

Label Meaning

DANGER!
Engines emit carbon monoxide; operate only
in well-ventilated area. Read the Operator’s
Manual.
No sparks, flames, or burning objects near the
machine. Shut off the engine before refueling.

WARNING!
Hot surface!

CAUTION

GREASE CONNECTING
ROD BEARING MONTHL

ENGRASE RODAMIENTO
DE LA BIELA
MENSUALMENTE

WARNING

DO NOT OPERATE WITHOUT SAFETY GUARDS.
READ AND UNDERSTAND INSTRUCTION BOOK.

WARNUNG

NICHT OHNE SCHUTZVORRICHTUNG
BETREIBEN. BEDIENUNGSANWEISUNG
GENAU DURCHLESEN.

ADVERTENCIA

NO OPERE SIN LOS DISPOSITIVOS
DE SEGURIDAD. LEA Y ENTIENDA
PRIMERO LAS INSTRUCCIONES.

AVERTISSEMENT

NE PAS OPERER SANS DEFLECTEUR
PROTECTIF. LIRE ET COMPRENDRE
LES INSTRUCTIONS DE SERVICE.

VORSICHT

PLEUELLAGER JEDEN

Y

MONAT SCHMIEREN

PRECAUTIONPRECAUCION

GRAISSER ROULEMENT
DE LA BIELLE TOUS
LES MOIS

CAUTION!
Read and understand the supplied Operator’s
Manuals before operating this machine. Fail­ure to do so increases the risk of injury to your­self or others.

WARNING!
Pinch point! Do not operate without safety
guards. Read and understand the operator’s
manual.

117431

CAUTION!
Grease connecting rod bearing monthly.

30744

wc_si000085gb.fm 11

Safety Information PD 2A/3A

Label Meaning

CAUTION!
Lifting point.

Guaranteed sound power level in dB(A).

wc_si000085gb.fm 12

PD 2A/3A Technical Data

3. Technical Data

3.1 Engine

Item Number:

PDT/PDI 2A

0007610, 0007611
0007624, 0007625

0007614, 0007615,
0007616, 0007628,

0007629, 0009407

Engine

Engine Make Honda
Engine Model GX 120 K1 QX
Rated Power
Spark Plug
Electrode Gap
Engine speed
Air Cleaner
Engine Lubrication
Engine Oil Capacity
Fuel

kW (Hp)

type

mm (in.)

rpm

type

oil grade

ml (oz.)

type

3.0 (4.0)

(NGK) BPR 6ES, BOSCH WR 7DC

0.7 – 0.8 (0.028 – 0.031)
2700 ± 100

Dual element

SAE10W30 - service class SF, SE, SD, or SC

600 (20)

Regular unleaded gasoline

PDT/PDI 3A

Fuel Tank Capacity

wc_td000085gb.fm 13

l (qts.)

2.5 (2.6)

Technical Data PD 2A/3A

3.2 Pump

Item Number:

Weight
*Max. Suction Lift
Max. Discharge Head
Max. Total Head
Max. Discharge Pres-

sure
Max. Discharge Flow

Gear Case Lubrication

Suction / Discharge Dia.

kg (lbs.)

m (ft.)

m (ft.)

m (ft.)

kg/cm2
(psi)

m3h (gpm)

oil grade
ml (oz.)

mm (in.)

PDT/PDI 2A

0007610, 0007611
0007624, 0007625

PDT/PDI 3A

0007614, 0007615,
0007616, 0007628,

0007629, 0009407

Pump

52 (114) 63 (138)

7.5 (25) 7.5 (25)

7.5 (25) 7.5 (25)
15 (50) 15 (50)

0.76 (10.8) 0.76 (10.8)

11 (50) 20 (88)

SAE 30

1000 (32)

50 (2) 75 (3)

SAE 30

1000 (32)

Maximum Solid Size
Ambient air tempera-

ture limits
Pumped fluid tempera-

ture limits

* Based on pump operating at sea level. Maximum suction lift will be less at higher altitudes.

mm (in.)

°C (°F)

°C (°F)

30 (1.25) 45 (1.75)

-17 to 40

(0 to 105)

-17 to 65

(0 to 150)

-17 to 40

(0 to 105)

-17 to 65

(0 to 150)

wc_td000085gb.fm 14

PD 2A/3A Technical Data

3.3 Sound Measurements

The required sound specification, Paragraph 1.7.4.f of 89/392/EEC
Machinery Directive, is:

• the guaranteed sound power level (L

• the sound pressure level at operator’s location (L

) = 96 dB(A).

WA

) = 82 dB(A).

pA

These sound values were determined according to ISO 3744 for the
sound power level (LWA) and ISO 6081 for the sound pressure level
(LpA) at the operator’s location.

wc_td000085gb.fm 15

Technical Data PD 2A/3A

3.4 Dimensions

Item Revision

0007610

107- 635

PDT2A

108+ 635

0007611
PDT2A(I)

wc_td000085gb.fm 16

A

mm (in.)Bmm (in.)Cmm (in.)Xmm (in.)Ymm (in.)Zmm (in.)

(25)

(25)
635

(25)

1015

(40)

1015

(40)

1015

(40)

572

(22.5)

610
(24)

572

(22.5)

---

---

---

PD 2A/3A Technical Data

0007614
PDT3A

0007615
PDT3A(I)

0007616
PDT3A(WW)

0007624
PDI2A

0007625
PDI2A(I)

0007628
PDI3A

107- 750

(29.5)

108+ 760

(30)
750

(29.5)

750

(29.5)

1015

(40)

1015

(40)

1015

(40)

1015

(40)

610
(24)

635
(25)

610
(24)

610
(24)

---

---

---

---

107- - - - 445

(17.5)

108+ - - - 435

(17)

107- - - - 445

(17.5)

108+ - - - 435

(17)

107- - - - 445

(17)

1015

(40)

1015

(40)

1015

(40)

1015

(40)

1015

(40)

572

(22.5)

610
(24)

572

(22.5)

610
(24)

610
(24)

0007629
PDI3A(I)

0009407
PDI3A(WW)

108+ - - - 435

(17)

107- - - - 445

(17)

108+ - - - 435

(17)

102- - - - 445

(17)

103+ - - - 435

(17)

1015

(40)

1015

(40)

1015

(40)

1015

(40)

1015

(40)

635
(25)

610
(24)

635
(25)

610
(24)

635
(25)

wc_td000085gb.fm 17

Operation PD 2A/3A

4. Operation

4.1 Application

This pump is intended for removing clean water or water containing a
large amount of debris and suspended solids. The model PD 2A can
pump water containing solids up to 30 mm (1.25 in.) diameter. The
model PD 3A can pump water containing solids up to 45 mm (1.75 in.)
in diameter.

Diaphragm pumps are ideal for pumping mud, slurries and seepage.
Typical applications include dewatering of trenches, sewers, pipelines,
septic tanks, holding tanks, farm ponds, fields and excavations where
a large amount of solids may be present in the water.

4.2 Recommended Fuel

The engine requires regular grade unleaded gasoline. Use only fresh,
clean gasoline. Gasoline containing water or dirt will damage fuel
system. Consult engine owner’s manual for complete fuel
specifications.

wc_tx000228gb.fm 18

PD 2A/3A Operation

4.3 Transporting the Machine

Fire hazard. Spilled fuel can ignite and cause severe burns. Lift and
transport the machine in an upright position.

WARNING

When lifting and transporting this machine:

• Close the fuel valve.

• Lift and transport it in an upright position.

• Use the lifting hook (a) to lift the machine.

• Use lifting equipment capable of lifting at least 70 kg (150 lbs.).

• Use the lifting hook, rear tie-down bar (b), and the handle (c) to
secure the machine to the transport vehicle.

• Do not use the wheels or the axle as tie-down points.

c

b

wc_tx000228gb.fm 19

Operation PD 2A/3A

4.4 Priming Pump

See Graphic: wc_gr001064

Diaphragm pumps are self priming and seldom need to have water
added to them before starting. However, if the pump has not been
used for several weeks and the rubber valves inside it are dry, adding
water through the surge chamber (f) will help the valves seal and
shorten the amount of time required for the pump to prime.

B

A

4.5 Before Starting

See Graphic: wc_gr001064

4.5.1 Read safety instructions at the beginning of manual.

4.5.2 Place pump as near to water as possible, on a firm, flat, level surface.

4.5.3 Check that hoses are securely attached to pump. Suction hose (c)
must not have any air leaks. Check that all hose clamps (b) and
couplings (a) are tight. Check that cap on surge chamber (f) is tight.

=

>

=

>

?

>

@

w c _ g r 0 0 1 0 6 4

4.5.4 Check that discharge hose (e) is not blocked. Lay hose out as straight
as possible. Remove any twists or sharp bends from hose which may
block the flow of water.

Note: Operating the pump with any part of the discharge line
positioned higher than 7.5 m (25 ft.) above the pump can cause
backflow into the pump and damage pump components.

4.5.5 Make sure suction strainer (d) is clean and securely attached to end of
hose. The strainer is designed to protect the pump by preventing large
objects from being pulled into the pump.

Position strainer so it will remain under water as water level drops.

4.5.6 Check fuel level, engine oil level, and condition of air cleaner.

wc_tx000228gb.fm 20

PD 2A/3A Operation

4.6 To Start

See Graphic: wc_gr000014

4.6.1 Open fuel valve by moving lever to the right (a1).

Note: If engine is cold, move choke lever to close position (b1). If
engine is hot, set choke to open position (b2).

4.6.2 Turn engine switch to “ON” (e1).

4.6.3 Open throttle by moving it slightly to left (d1).

4.6.4 Pull starter rope (c).

Note: If the oil level in the engine is low, the engine will not start. If this
happens, add oil to engine. Some engines are equipped with an oil
alert light (f) that will come on while pulling the starter rope.

4.6.5 Open choke as engine warms (b2).

4.6.6 Open throttle fully to operate.

4.7 To Stop

See Graphic: wc_gr000014

4.7.1 Reduce engine RPM to idle by moving throttle completely to right (d2).

4.7.2 Turn engine switch to “OFF” (e2).

4.7.3 Close fuel valve by moving lever to the left (a2).

wc_tx000228gb.fm 21

Operation PD 2A/3A

4.8 Operation

Run engine at full speed while operating pump.
Pump should begin pumping water within a minute depending on

length of suction hose and height of pump above water. Longer hoses
will require more time.

If pump does not prime, check for loose fittings or air leak in suction
hose. Make sure strainer in water is not blocked.

DO NOT pump flammable fluids, fuels, corrosive chemicals or fluids
containing toxic substances. These fluids can create potentially

WARNING

4.9 Accessories

dangerous health and environmental hazards. Contact local
authorities for assistance.

WACKER offers a complete line of fittings, hoses, and clamps to
properly connect the pump to match various job conditions.

wc_tx000228gb.fm 22

PD 2A/3A Operation

4.10 Hoses and Clamps

See Graphic: wc_gr001065

Suction Hose

Suction hoses (a) must be rigid enough not to collapse when pump is
operating.

Discharge Hose

Discharge hoses (b) are usually thin-walled collapsible hoses. Rigid
hoses similar to those used as suction hoses may also be used as
discharge hoses.

Note: Suction and discharge hoses are available from WACKER.
Contact your nearest dealer for more information.

Suction Hose to Inlet Coupling

Two clamps (c) are recommended for connection of suction hoses to
inlet coupling.

Note: This connection is important. Even a small air leak on the
suction side of pump will prevent the pump from priming.

Other Hose Connections

For other hose connections, one T-bolt or worm-gear type clamp is
usually sufficient to hold hoses in place. In some cases, slight
variances in hose diameters may make it necessary to add more
clamps in order to maintain tight connections.

b

a

wc_gr001065

c

wc_tx000228gb.fm 23

Maintenance PD 2A/3A

5. Maintenance

5.1 Periodic Maintenance Schedule

The chart below lists basic machine and engine maintenance. Refer to
your engine Operator’s Manual for additional information on engine
maintenance.

Check fuel level.
Check engine oil level.
Inspect air filter. Replace as needed.
Check external hardware.
Change engine oil.
Check oil level in pump gear case.
Grease pump connecting rod bearing.
Clean sediment cup on engine fuel

system.
Check and clean spark plug.
Check and adjust valve clearance.

Daily

before

starting









After

first

20 hrs.



Every 2

weeks

or 25

hrs.





Every

100

hrs.





Every

300

hrs.



Change oil in pump gear case.

wc_tx000229gb.fm 24



PD 2A/3A Maintenance

5.2 Changing Engine Oil

See Graphic: wc_gr000022

5.2.1 Drain the oil while the engine is still warm.

5.2.2 Remove the oil filler plug (a) and the drain plug (b) to drain the oil.

Note: In the interests of environmental protection, place a plastic sheet
and a container under the machine to collect any liquid that drains off.
Dispose of this liquid in accordance with environmental protection
legislation.

5.2.3 Install the drain plug.

5.2.4 Fill the engine crankcase with the recommended oil up to the level of
the plug opening (c). See section Technical Data for oil quantity and
type.

5.2.5 Install the oil filler plug.

wc_tx000229gb.fm 25

wc_gr000022

Maintenance PD 2A/3A

5.3 Servicing Air Cleaner

See Graphic: wc_gr000025

The engine is equipped with a dual element air cleaner. Service air
cleaner frequently to prevent carburetor malfunction.

NOTICE: NEVER run engine without air cleaner. Severe engine
damage will occur.

NEVER use gasoline or other types of low flash point solvents for
cleaning the air cleaner. A fire or explosion could result.

WARNING

To service:

5.3.1 Remove air cleaner cover (a). Remove both elements and inspect
them for holes or tears. Replace damaged elements.

5.3.2 Wash foam element (b) in solution of mild detergent and warm water.
Rinse thoroughly in clean water. Allow element to dry thoroughly. Soak
element in clean engine oil and squeeze out excess oil.

5.3.3 Tap paper element (c) lightly to remove excess dirt. Replace paper
element if it appears heavily soiled.

wc_tx000229gb.fm 26

PD 2A/3A Maintenance

5.4 Spark Plug

See Graphic: wc_gr000028

Clean or replace the spark plug as needed to ensure proper operation.
Refer to your engine operator’s manual.

The muffler becomes very hot during operation and remains hot for a
while after stopping the engine. Do not touch the muffler while it is hot.

WARNING

Note: Refer to section Technical Data for the recommended spark

plug type and the electrode gap setting.

5.4.1 Remove the spark plug and inspect it.

5.4.2 Replace the spark plug if the insulator is cracked or chipped.

5.4.3 Clean the spark plug electrodes with a wire brush.

5.4.4 Set the electrode gap (a).

5.4.5 Tighten the spark plug securely.

NOTICE: A loose spark plug can become very hot and may cause
engine damage.

wc_tx000229gb.fm 27

Maintenance PD 2A/3A

5.5 Gear Case

See Graphic: wc_gr003450

Check the oil level in the gear case once a week or every 25 hours of
operation.

Remove oil level plug (h). Check that oil level is even with plug
opening. If oil level is low, add oil through the top fill plug opening (g).
Do not overfill.

Change oil in gear case once a year or every 300 hours of operation.
Drain oil through drain plug opening (f) at bottom of gear case. Add oil

through fill plug on top of gear case. See Technical Data for oil quantity
and type.

g g

h

f f

wc_gr003450

h

wc_tx000229gb.fm 28

PD 2A/3A Maintenance

5.6 Connecting Rod Bearing

See Graphic: wc_gr003451

Grease connecting rod bearing once a week or every 25 hours of
operation.

Use a hand operated grease gun. Add grease through grease fitting
located behind access hole (j) provided on front cover.

k

j

5.7 Cleaning Pump

See Graphic: wc_gr003451

When pumping heavy sludges or water containing large amounts of
dirt and solids, clean the pump often. If allowed to sit in the pump and
dry, these materials will harden and could damage the valves or
diaphragm inside the pump the next time it is used.

When cleaning pump:

5.7.1 Pump clean water through pump for a few minutes after each use to
flush dirt from inside pump and hoses.

5.7.2 Remove dirt from between engine cooling fins to prevent them from
clogging up. This will prevent engine from overheating.

5.7.3 Remove front cover (k) and clean dirt and grease build-up from
connecting rod and inside of front pump cover.

wc_gr003451

wc_tx000229gb.fm 29

Maintenance PD 2A/3A

5.8 Cleaning Sediment Cup

See Graphic: wc_gr000029

5.8.1 Turn the fuel valve off.

5.8.2 Remove the sediment cup (a) and the O-ring (b).

5.8.3 Wash both thoroughly in a nonflammable solvent. Dry and reinstall
them.

5.8.4 Turn the fuel valve on and check for leaks.

b

a

wc_gr000029

5.9 Carburetor Adjustment

See Graphic: wc_gr000032

5.9.1 Start the engine and allow it to warm up to operating temperature.

5.9.2 Set the pilot screw (a) two turns out. See Note.

5.9.3 With the engine idling, turn the pilot screw (a) in or out to the setting
that produces the highest rpm.

5.9.4 After the pilot screw is adjusted, turn the throttle stop screw (b) to
obtain the standard idle speed. See Technical Data.

Note: On some engines the pilot screw is fitted with a limiter cap (c)
to prevent excessive enrichment of the air-fuel mixture in order to
comply with emission regulations. The mixture is set at the factory and
no adjustment should be necessary. Do not attempt to remove the
limiter cap. The limiter cap cannot be removed without breaking the
pilot screw.

wc_gr000032

5.9.1

wc_tx000229gb.fm 30

PD 2A/3A Maintenance

5.10 Storage

If pump is being stored for more than 30 days:

NEVER open priming plug, discharge plug, or cover when pump is hot.

WARNING

5.10.1 Remove discharge plug from pump casing and drain out any water left
in the housing after pump has cooled.

5.10.2 Remove pump cover and clean inside of pump housing. Coat inside of
pump with a light film of oil to reduce corrosion. A spray can of oil works
well for this.

5.10.3 Tape up suction and discharge ports to prevent anything from falling
into pump.

5.10.4 Change engine oil and follow procedures described in engine manual
for engine storage.

5.10.5 Cover pump and engine and store in a clean, dry area.

wc_tx000229gb.fm 31

Maintenance PD 2A/3A

5.11 Troubleshooting

Problem / Symptom Reason / Remedy

Engine does not start. • Engine problem. See engine manufacturer’s service

manual for troubleshooting and repair.

• Engine oil level too low. Add oil to engine.

• Pump housing filled with dirt and debris. Disassem­ble and clean inside of pump.

• Pump gear case damaged. Inspect and repair.

Engine starts but pump does

not take in water.

• Pump is located too high above or too far away from
water. Locate pump closer to water.

• Air leak on suction side of pump. Check that hose
fittings and cap on surge chamber are tight and seal­ing properly.

• Suction hose damaged or collapsed. Repair or
replace hose.

• Strainer plugged. Clean or replace strainer.

• Dirt collecting inside pump and hoses, blocking flow.
Clean inside of pump and flush hoses.

• Engine running slow. Check engine speed and
adjust. See chapter Technical Data for engine
speed.

• Pump valves damaged or not seating properly.
Check for stones and gravel imbedded in valves.
Replace valves.

• Diaphragm loose or damaged. Inspect diaphragm
for damage. Replace and tighten.

Pump output low. • Pump located too high above or too far away from

wc_tx000229gb.fm 32

water. Locate pump closer to water.

• Suction strainer or intake line partially plugged.
Clean hose line and strainer.

• Discharge hose is kinked or end is blocked. Check
that hose lies straight and flows freely.

• Discharge hose too narrow. Use hose of equal
diameter or larger than suction hose.

PD 2A/3A Maintenance

5.12 Decomissioning

5.12.1 When this machine has reached the end of its useful life, practice
environment-friendly recycling.

• Do not dispose of the machine in normal garbage containers.

• Dispose of the machine in accordance with local environmental

recycling regulations.

• Take the machine to your local designated recycling location.

5.12.2

wc_tx000229gb.fm 33

EC DECLARATION OF CONFORMITY

CE-KONFORMITÄTSERKLÄRUNG

DECLARACIÓN DE CONFORMIDAD DE LA CE

DÉCLARATION DE CONFORMITÉ C.E.

WACKER NEUSON CORPORATION, N92 W15000 ANTHONY AVENUE, MENOMONEE FALLS, WISCONSIN USA

AUTHORIZED REPRESENTATIVE IN THE EUROPEAN UNION
BEVOLLMÄCHTIGTER VERTRETER FÜR DIE EUROPÄISCHE GEMEINSCHAFT
REPRESENTANTE AUTORIZADO EN LA UNIÓN EUROPEA
REPRÉSENTANT AGRÉÉ AUPRÈS DE L’UNION EUROPÉENNE

hereby certifies that the construction equipment specified hereunder / bescheinigt, daß das Baugerät / certifica que la máquina de
construcción / atteste que le matériel :

WACKER CONSTRUCTION EQUIPMENT AG
Preußenstraße 41
80809 München

1. Category / Art / Categoría / Catégorie

Water Pump Units

Wasserpumpen

Equipos de Bomba de Agua

Groupe Motopompe à Eau

2. Type - Typ - Tipo - Type

PDT 2A, PDT 3A, PDI 2A, PDI 3A, PDT 2, PDT 3

3. Item number of equipment / Artikelnummer / Número de referencia de la máquina / Numéro de référence du matériel :

0007610, 0007614, 0007624, 0007625, 0007628, 0007629, 0009407, 0009494, 0009495

4. Net installed power / absolute installierte Leistung / Potencia instalada neta / Puissance installée nette :

PDT 2A, PDT 3A, PDI 2A, PDI 3A 2,6 kW

PDT 2, PDT 3 3,2 kW

Has been sound tested per Directive 2000/14/EC / In Übereinstimmung mit Richtlinie 2000/14/EG bewertet worden ist / Ha sido
ensayado en conformidad con la norma 2000/14/CE / A été mis à l’épreuve conforme aux dispositions de la directive 2000/14/CEE :

Conformity Assessment Procedure /
Konformitätsbewertungsverfahren / Procedimiento
para ensayar conformidad / Procédé pour
l’épreuve de conformité

Annex V / Anhang V

Measured sound power level / Gemessener
Schallleistungspegel / Nivel de potencia
acústica determinado / Niveau de puissance
acoustique fixé

95 dB(A) 96 dB(A)

Guaranteed sound power level/ Garantierter
Schallleistungspegel / Nivel de potencia
acústica garantizado / Niveau de puissance
acoustique garanti

Anexo V / Annexe V

and has been produced in accordance with the following standards:
und in Übereinstimmung mit folgenden Richtlinien hergestellt worden ist:
y ha sido fabricado en conformidad con las siguientes normas:
et a été produit conforme aux dispositions des directives européennes ci-après :

2000/14/EC
2002/88/EC
89/336/EEC
98/37/EEC

30.07.08

Date / Datum / Fecha / Date

2008-CE-PD2_PD3_Q.fm

William Lahner Dan Domanski

Vice President of Engineering Manager, Product Engineering

WACKER NEUSON CORPORATION

Wacker Construction Equipment AG · Preußenstraße 41 · D-80809 München · Tel.: [phone] - 0 · Fax: +49 - (0)89-3 54 02-3 90
Wacker Corporation · P.O. Box 9007 · Menomonee Falls, WI 53052-9007 · Tel. : [phone] · Fax: [phone] · Tel. : [phone]
Wacker Asia Pacific Operations · Skyline Tower, Suite 2303, 23/F · 39 Wang Kwong Road, Kowloon Bay, Hong Kong · Tel. [phone] · Fax: [phone]
