V-Zug MWC-XSL60BL Operating Instructions
V-ZUG Ltd
Microwave
Miwell-Combi XSL
Operating instructions
Thank you for choosing to buy one of our products. Your appliance is made
to high standards and is easy to use. Nevertheless, please take the time to
read these operating instructions in order to familiarize yourself with the
appliance and get the best use out of it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance at the time these operating instructio ns went to p ress. The right to make
technical modifications for the purpose of the further development of the
appliance is reserved.
Validity
The model number corresponds to the first three digits on the identification
plate. These operating instructions apply to the model:
Type Model no. Size system
MWC-XSL/60 939 60-450
Variations depending on the model are noted in the text.
© V-ZUG Ltd, CH-6301 Zug, 2012
2
Contents
1 Safety precautions 5
1.1 Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 General safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Appliance-specific safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.5 Instructions for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.6 Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.7 Note on accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2 Appliance description 20
2.1 Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.2 Operating and display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.4 Ventilation fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3 Operating the appliance 26
3.1 Using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.2 Start protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.3 Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4 User settings 29
4.1 Childproof lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2 Time display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.3 Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.4 Acoustic signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.5 Temperature unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.6 Time format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.7 Factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5 Time functions 33
5.1 Setting and changing the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.2 Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.3 Operating time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.4 Delayed start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3
6 Operating modes 39
6.1 Hot air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.2 Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.3 Grill-forced convection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.4 Power&Favorit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.5 Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.6 CombiCrunch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.7 AutomaticPlus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.8 Combi mode hot air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.9 Combi mode grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.10 Combi mode grill-forced convection . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.11 Fast heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.12 Power&Favorit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.13 AutomaticPlus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.14 Combi mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7 Care and maintenance 50
7.1 Cleaning the exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.2 Cleaning the appliance door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.3 Cleaning the door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.4 Cleaning the cooking space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.5 Cleaning the accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.6 Replacing a defective light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8 Trouble-shooting 53
8.1 What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8.2 After a power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9 Accessories and spare parts 56
10 Technical data 57
11 Notes 58
12 Index 61
13 Repair service 63
4
1 Safety precautions
1.1 Symbols used
Denotes important safety precautions. Failure to observe said
precautions can result in injury or in damage to the appliance or
fittings!
Information and precautions that should be observed.
Information on disposal.
Information about the operating instructions.
➤ Indicates step-by-step instructions.
– Describes how the appliance reacts to the steps taken.
• Indicates a list.
5
1 Safety precautions
1.2 General safety precautions
• Read the operating instructions before using
the appliance for the first time!
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and/or knowledge, unless
they are supervised or have been given
instruction concerning use of the appliance by
a person responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• If the mains cable of this appliance is
damaged, it must be replaced by the
manufacturer or its Customer Services or a
similarly qualified person in order to avoid
hazard.
6
1 Safety precautions
1.3 Appliance-specific safety precautions
• READ THE IMPORTANT SAFETY
INSTRUCTIONS CAREFULLY AND RETAIN
FOR FUTURE USE.
• WARNING: Children should only use the
appliance in the combined operating mode
under adult supervision due to the
temperatures generated.
• WARNING: In the event that the appliance
door or door seal is damaged, the appliance
must not be used until it has been repaired by
a qualified competent person.
• WARNING: It is hazardous for anyone other
than a qualified competent person to carry out
any service or repair operation which involves
the removal of a cover which gives protection
against exposure to microwave energy.
7
1 Safety precautions
• WARNING: Liquids and other foods must not
be heated in sealed containers, as they are
liable to explode.
• The appliance is intended to be used in
household.
• Only use containers that are suitable for use
in microwave appliances.
• The appliance must be carefully monitored
when cooking foodstuffs in containers made
from plastic or paper, as they could ignite.
• The appliance is intended for heating food
and beverages.
Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth
and similar may lead to risk of injury, ignition
or fire.
• If smoke is detected, switch off the appliance
or pull out the mains plug, and keep the
appliance door closed to stifle any flames.
8
1 Safety precautions
• Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must
be taken when handling the vessel.
• The contents of feeding bottles and baby food
jars must be stirred or shaken and the
temperature must to be checked before
consumption, in order to avoid burns and
scalds.
• Eggs in their shell or whole hard-boiled eggs
should not be heated in microwave
appliances since they may explode, even after
microwave heating has ended.
• The appliance should be cleaned regularly
and any food residue should be removed.
• Failure to maintain the appliance in a clean
condition could lead to deterioration of the
surface that could adversely affect the life of
the appliance and possibly result in a
hazardous situation.
9
1 Safety precautions
• Do not use abrasive cleaning agents or sharp
metal scrapers for cleaning the glass of the
appliance door, as they can scratch the
surfaces. This can destroy the glass.
• Under no circumstances use a steam cleaner.
• Whe using the baking tray, the sloped side
must face the appliance door. This makes it
safer when pulling out the baking tray.
10
1 Safety precautions
1.4 Disclaimer
• Any repairs, modifications or manipulations to the appliance, especially
any live parts, may only be carried out by the manufacturer, its Customer
Services or similarly qualified persons. Repairs if carried out incorrectly
may cause serious injury, damage to the appliance and fittings, as well as
affect the functioning of the appliance. If the appliance is not working
properly or in case of a repair order, follow the instructions given in the
REPAIR SERVICE section. If necessary, please contact Customer Services.
• Make sure no water gets inside the appliance: Do not spray the appliance
with water. If water gets inside it can damage the appliance.
• Retain these operating instructions for future reference. If you sell or pass
the appliance on to a third party, please ensure these operating instructions accompany the appliance, together with the instructions on
installation.
• The appliance is designed for use in the home for preparing food. No
liability is assumed for any damage caused by improper or incorrect use.
11
1 Safety precautions
1.5 Instructions for use
• The appliance corresponds to recognised technology standards and the
relevant safety regulations. Proper use of the appliance is essential to avoid
damage and accidents. Please observe the precautions given in these
operating instructions.
• The appliance must be installed and connected up to the electricity supply
in accordance with the separate installation instructions. Have the
necessary work carried out by a qualified fitter/electrician.
• Before using the newly installed appliance for the first time, please observe
the precautions in
• If the appliance malfunctions, you must disconnect it from the power supply
immediately.
• You should not in any circumstances flambé or cook with a lot of fat in the
cooking space.
• You should not use the appliance as a room heater.
• You should never use the appliance to dry animals, fabrics or paper!
• You should ensure that the mains cables of other electrical appliances do
not get caught in the door of the appliance, the electrical cable insulation
could become damaged.
• You should ensure there are no foreign bodies or pets in the cooking
space before closing the appliance door.
• You should not store objects in the cooking space that could pose a
danger if the appliance were accidentally switched on. You should not
store food or any temperature-sensitive or inflammable materials, e.g.
cleaning agents, oven sprays, etc., in the cooking space.
• You should use original spare parts only.
USING FOR THE FIRST TIME.
12
1 Safety precautions
Caution: Danger of injury!
• Be careful that fingers do not get caught in the door hinges. Otherwise, if
the appliance door is moved, there is a risk of injury. Particular care should
be taken when children are around.
• An open appliance door poses danger of tripping or injury! Do not sit or
rest on the appliance door or use it as a storage surface.
Caution: Burns hazard!
• Accessible parts of the appliance can get hot when in use. Keep children
away!
• The appliance, the appliance door and especially the glass get very hot
when in use.
• Steam may escape from the cooking space when the appliance door is
opened. Do not put your hands into the cooking space if there is steam in
it!
• Overheated fat and oil can easily catch fire. Heating oil in the cooking
space to sear meat is dangerous and should not be done. Never try to
extinguish burning oil or fat with water (danger of explosion)! Extinguish the
flames using a fire blanket and keep all doors and windows closed.
• Do not pour spirits (e.g. brandy, whisky, schnapps, etc.) over hot food –
danger of explosion!
• Accessories get hot in the cooking space. Always wear protective gloves
or use oven cloths.
• If you notice smoke possibly coming from a fire in the appliance or inside
the cooking space, keep the appliance door closed and disconnect the
appliance from the mains supply.
• The appliance will remain hot for some time after it is switched off and cool
down only slowly to room temperature. Allow sufficient time for the
appliance to cool down before, for instance, cleaning it.
• Do not leave the appliance unsupervised when drying herbs, bread,
mushrooms, etc. If the foodstuff dries out too much, this can pose a fire
hazard.
13
1 Safety precautions
How to avoid damaging the appliance
• The construction of the appliance may not be changed in any way. Do not
apply force to or interfere with the appliance door or the control and safety
devices. The illumination may only be replaced by our Customer Services.
• Always keep the appliance clean. Clean the appliance door with mild
detergent.
• Take care not to damage the appliance door, the door frame and the door
hinges.
• Do not use abrasive cleaning agents or cleaning aids such as steel wool,
knives, glass scrapers, razor blades, etc. to clean the door glass.
Scratches on the door glass could cause a breakage.
• Close the appliance door carefully.
• When cleaning the appliance make sure no water can get into the inside
of the appliance. Use only a moderately damp cloth. Do not spray the
inside or outside of the appliance with water. Do not use a steam cleaner.
If water gets inside the appliance, it can cause damage.
1.6 Microwave
• Microwave energy is safe when used properly. When the appliance door is
opened, microwave operation is automatically interrupted. In the event of a
malfunction or damage to the appliance, especially to the appliance door,
do not use microwave operation. The appliance must be repaired by
qualified personnel.
• Ensure that nothing is trapped between the appliance door and the frame.
• Do not switch the microwave on until you have put the food in the cooking
space.
14
1 Safety precautions
Heating foods and liquids
• Do not leave your appliance unattended when heating or cooking food in
containers that are made of plastic, paper or other flammable materials.
The containers can melt or ignite.
• Do not heat beverages or food that contain alcohol. Ignition hazard and
danger of explosion!
• When heating liquids, place a teaspoon in the vessel to prevent delayed
boiling (or superboiling). With delayed boiling, boiling point is reached
without the typical steam bubbles forming. Disturbing an open vessel, even
slightly, can cause the liquid to shoot out – risk of scalding!
• Do not use vessels with a narrow spout.
• Stir liquids halfway through heating and when the time is up allow the
vessel to stand in the cooking space for a short time. Stir the contents once
more and then take the vessel out of the cooking space.
• Infant food in jars or bottles must be heated without the lid, top or teat.
Infant food must be stirred or shaken well after being heated. It is imperative to check the temperature of the food before giving it to the infant –
risk of scalding!
• Do not heat food in tightly sealed containers (tins, bottles, sealed foil, paper
or metal disposable packaging). Remove plastic packaging before
cooking or defrosting foods. Sealed containers can explode. Always open
the containers.
15
1 Safety precautions
• The cooking time depends on the quantity, nature and initial temperature
of the food, as well the dishes being used. Always start with the shorter
cooking time given to avoid overcooking the food. Otherwise, smaller
quantities or food with a low moisture content can dry out and possibly
ignite. If the food has not reached the right stage of cooking when the time
is up, then extend the cooking time.
• Prick food with a skin or peel such as potatoes, tomatoes, sausages, shell
food, etc. with a fork. Otherwise, the steam that is produced will be unable
to escape and may cause the food to explode.
• Do not cook eggs in the shell. Do not heat up boiled eggs. Eggs can
explode in the microwave. Crack the eggs open and then whisk them.
Pierce the yolks of fried eggs.
16
1 Safety precautions
1.7 Note on accessories
The accessories get very hot during use – burns hazard! Always
wear protective gloves or use oven cloths.
Turntable roller and glass turntable
• You should use the appliance at all times and exclusively with the turntable
roller and the glass turntable supplied.
• You should never place a vessel or container other than the glass turntable
directly on the turntable roller.
• You should allow the glass turntable to cool down first before cleaning it or
rinsing it with water.
• You should not cook food directly on the glass turntable.
• You should not place hot food or containers on the glass turntable when it
is cold.
• You should not place frozen food or containers on the glass turntable when
it is hot.
CombiCrunch plate
• You should use the CombiCrunch plate in the CombiCrunch and hot air
modes only.
• You should never use the CombiCrunch plate together with the wire rack
in the CombiCrunch mode.
• You should never use the CombiCrunch plate as a stand for other
cookware or containers.
High or low wire rack
• You should always place the wire rack in the centre of the glass turntable.
• When using the combi mode, do not put metal cookware on the wire rack.
Otherwise, arcing can occur which will damage your appliance.
• You should never use the wire rack with the Power&Favorit, microwave and
CombiCrunch operating modes. Otherwise, arcing can occur which will
damage your appliance.
17
1 Safety precautions
Food cover
• Use the food cover with the Power&Favorit and microwave modes only.
The food cover could otherwise melt.
Baking tray
• You should only use the baking tray in the hot air mode. Otherwise, arcing
can occur which will damage the appliance.
Cookware
• You should ensure that the cookware does not touch the sides of the
cooking space as it rotates.
Note also when using the microwave and combi modes:
• You should use only heat-resistant, microwave-proof dishes, such as glass,
ceramic, porcelain or temperature-resistant plastics. Microwaves can
penetrate these materials. Microwaves cannot or can only partially
penetrate metal cookware; food in this instance will remain cold. If you use
metal cookware, arcing could occur which will damage the appliance.
• You should only use cookware with a metal decor, e.g. a gold rim, or food
in aluminium containers if the manufacturer guarantees their microwave
compatibility. This also applies to products made from recycled paper.
• Do not use a meat thermometer. The features of meat thermometers can
cause arcing in the microwave mode, which will damage your appliance.
• Porcelain, ceramic and earthenware dishes with cavities – which can fill
with water – can crack. Follow the manufacturers’ instructions.
18
1 Safety precautions
1.8 Disposal
Packaging
Danger of suffocation! Packaging materials (e.g. plastic,
polystyrene) can be dangerous for children. Keep packaging
materials away from children.
All packaging material is marked and should be collected for
recycling and disposed of in an environmentally friendly way.
Disconnection
➤ Pull the plug out of the mains socket or have the appliance disconnected
from the mains supply by an electrician. Then cut off the mains cable.
➤ Disable the appliance after disconnecting it.
Appliance disposal
• The symbol on the identification plate warns that the appliance may
not be disposed of in normal household waste.
• The appliance must be disposed of in accordance with local regulations
on waste disposal. For more information on the handling, disposal and
recycling of the product, please contact the local authorities, the local
recycling facilities for household waste or the retailer from whom you
purchased the appliance.
19
2 Appliance description
2.1 Construction
1
9
2
8
72
2
3
4
5
6
1 Operating and display elements
2 Ventilation slots
3 Safety door catch
4 Appliance door
5 Microwave inlet
20
6
5
6 Level
7 Grill
8 Hot air fan
9 Identification plate
Loading...
