Oven
Hotair SL
Operating instructions
VZUG LTD
2
Dear V-ZUG Customer
Thank you for choosing to buy one of our products.
Your appliance is made to high standards and is easy to use. Nevertheless, please
take the time to read these operating instructions in order to familiarize yourself with
the appliance and get the best use out of it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance at the
time these operating instructions went to press. The right to make technical modifications for the purpose of the further development of the appliance is reserved.
Symbols used
A Indicates step-by-step instructions.
– Describes how the appliance reacts to the steps taken.
䡲 Indicates a list.
Validity
The model number corresponds to the first three digits on the identification plate. These
operating instructions apply to the following models:
Deviations depending on the model are noted in the text.
© V-ZUG LTD, CH-6301 Zug, 2006
Denotes important safety precautions. Failure to observe
said precautions can result in injury or damage to the appli
ance or fittings!
Denotes useful tips for the user.
Type Model no. Size system
BH-SL 704 55-381
BH-SL 705 60-381
3
Contents
Safety precautions 5
Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . 5
Correct use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Children in the home . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Appliance description 10
Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operating and display elements . . . . . . . . . . . . . . . . . . . 11
Using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . 13
General operating instructions . . . . . . . . . . . . . . . . . . . . . 13
User settings 14
Childproof lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Time display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Baking and roasting 17
Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Selecting an operating mode . . . . . . . . . . . . . . . . . . . . . 19
Checking / Changing the cooking space temperature . . . . . 20
Changing the operating mode . . . . . . . . . . . . . . . . . . . . 20
End of baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Optimal use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Clock functions 26
Setting and changing the time . . . . . . . . . . . . . . . . . . . . . 26
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Operating time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Delayed start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Tips on settings 32
… Contents
4
Care and maintenance 39
Cleaning the exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Cleaning the accessories . . . . . . . . . . . . . . . . . . . . . . . . 39
Cleaning the cooking space . . . . . . . . . . . . . . . . . . . . . . 40
Removing the appliance door . . . . . . . . . . . . . . . . . . . . . 41
Catalytic self-cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Troubleshooting 43
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
After a power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Tips and tricks 45
Note for testing institutes . . . . . . . . . . . . . . . . . . . . . . . . . 46
Accessories and spare parts 47
Disposal 48
Index 49
Repair service 51
Quick instructions 52
5
Safety precautions
In accordance with the requirements of IEC 60335-1:
䡲 This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless supervised or unless they have been given instruction concerning the use of the
appliance by a person responsible for their safety.
Before using for the first time
䡲 The appliance must be installed and connected up to the electricity supply in ac-
cordance with the separate installation instructions. The necessary work should be
done by a qualified fitter or electrician.
䡲 Dispose of the packaging material in accordance with local regulations.
䡲 Before using the newly installed appliance for the first time, please follow the tips
in the 'Using for the first time' section.
䡲 Make the desired user settings.
The appliance corresponds to recognised technology stand
ards and the relevant safety regulations. Proper use of the
appliance is however essential to avoid damage and acci
dents. Please therefore follow the precautions given in these
operating instructions.
… Safety precautions
6
Correct use
䡲 The appliance is designed for use in the home for preparing food. No liability is
assumed for any damage caused by improper or incorrect use.
䡲 Not to be used as a room heater or humidifier.
䡲 Any repairs, modifications or manipulations to the appliance, especially any elec-
trical parts, should only be carried out by the manufacturer, its Customer Services
or similarly qualified persons. Repairs if carried out incorrectly may cause serious
injury, damage to the appliance and fittings, as well as affect the functioning of
the appliance. If the appliance is not working properly or in case of a repair order,
follow the instructions given in the 'Repair service' section. Please contact Customer
Services if necessary.
䡲 Use original spare parts only.
䡲 Retain these operating instructions for future reference. If you sell or pass the appli-
ance on to a third party, please ensure these operating instructions accompany the
appliance, together with the instructions on installation. In this way, the new owner
can inform themselves about how to use the appliance correctly and read the pertinent safety precautions.
Children in the home
䡲 Packaging material (e.g. plastic, polystyrene) can be dangerous for children. Dan-
ger of suffocation! Please keep packaging material away from children.
䡲 The appliance is designed for use by adults who are familiar with these operating
instructions. Children are often unable to recognise the danger of electrical appliances. Ensure proper supervision and do not allow children to play with the appliance – there is a danger that children can hurt themselves.
䡲 Use the childproof locking facility.
… Safety precautions
7
Use
䡲 If the appliance is visibly damaged, do not use it. Contact our Customer Services.
䡲 If the appliance is not operating properly, disconnect it from the electricity supply
immediately.
䡲 Ensure the mains cables of other electrical appliances do not get caught in the door
of the appliance, as the electrical cable insulation could get damaged.
䡲 If the mains cable is damaged, it must be replaced by Customer Services.
䡲 Ensure there are no foreign bodies or pets in the cooking space before closing the
appliance door.
䡲 Objects that could pose a danger if the appliance were accidentally switched on
should not be stored in the cooking space. Do not store temperature-sensitive or
inflammable materials, e.g. cleaning agents, oven sprays, etc., in the cooking
space.
䡲 Keep the appliance door closed when grilling. The heat could damage the oper-
ating and display elements or the fitted units above.
… Safety precautions
8
Caution: Burn hazard!
䡲 The appliance gets very hot when in use.
䡲 Heat is produced during baking and roasting. The appliance door, especially the
glass, can get hot. Burn hazard – do not touch. Keep children away!
䡲 Overheated fat and oil can easily catch fire. Heating oil in the cooking space to
sear meat is dangerous and should not be done. Never try to extinguish burning
oil or fat with water – danger of explosion! Smother the flames with a damp cloth
and keep all doors and windows closed.
䡲 Do not pour spirits (e.g. brandy, whisky, schnapps, etc.) over hot food – danger
of explosion!
䡲 Accessories such as wire shelves and trays, etc. get hot in the cooking space.
Always wear protective gloves or use oven cloths.
䡲 Do not leave the appliance unsupervised when drying herbs, bread, mushrooms,
etc. If the foodstuff dries out too much, it can pose a fire hazard.
䡲 If you notice smoke from a possible fire coming from the appliance or from inside
the cooking space, keep the appliance door closed. Switch off the appliance or
disconnect it from the mains supply.
䡲 The appliance will remain hot for some time after it is switched off and cool down
only slowly to room temperature. Allow sufficient time for the appliance to cool
down before, for instance, cleaning it.
… Safety precautions
9
Caution: Danger of injury!
䡲 When using or cleaning the appliance be careful not to put fingers in the door
hinges, otherwise there is a risk of injury if the appliance door is moved.
Particular care should be taken when children are around.
䡲 Only leave the appliance door open in the at-rest position. An open appliance
door poses danger of tripping or injury! Do not sit or rest on the appliance door
or use it as a storage surface.
How to avoid damaging the appliance
䡲 Close the appliance door carefully.
䡲 Using knives or cutting wheels on the original baking tray will visibly damage the
surface.
䡲 To prevent corrosion, allow the cooking space to dry out thoroughly after use by
leaving the appliance door open in the at-rest position.
䡲 When cleaning the appliance make sure no water gets inside it. Use a moderately
damp cloth. Do not spray the inside or outside of the appliance with water. Do not
use a steam cleaner. If water gets inside the appliance, it can cause damage.
10
Appliance description
Construction
1 Operating and display elements
2 Door handle
3 Appliance door
1
2
3
… Appliance description
11
Operating and display elements
Buttons
Displays
Symbols
A Illumination E Timer
B Cooking space temperature F Operating time and switch-off time
C Operating mode G Off
D Adjusting knob
H Temperature I Time, duration and timer
J Cooking space temperature M Operating time
K Operating modes N Switch-off time
L Timer O Time
P Communications interface
C
P
K
J H I L M N O
A B C D E F G
… Appliance description
12
1 Appliance door 7 Cooking space temperature sensor
2 Door seal 8 Shelf levels
3 Illumination 9 Protective foil
4 Cooking space ventilation 10 Wire shelf
5 Grill 11 Original baking tray
6 Grill guard
2
1
3
5
4
8
(Level 4)
6
7
(Level 1)
9
10
11
(Level 2)
(Level 3)
… Appliance description
13
Using for the first time
Before operating the newly installed appliance for the first time the following steps
should be taken:
A Remove all packaging and transport materials from the cooking space.
A If the display on the right is flashing , turn the adjusting knob to set
the desired time.
– The display stops flashing after around 15 seconds and the time is set.
A Heat the empty appliance (i.e. without the wire shelf, baking tray, etc.) using the
operating mode at maximum temperature for approximately 1 hour. There is
likely to be some smoke and odour given off, we therefore recommend ventilating
the room well during this phase.
General operating instructions
The operating mode, cooking space temperature as well as the cooking time and various other functions can be selected by pressing the appropriate button once or more.
䡲 The symbol for the function selected illuminates or flashes.
䡲 The corresponding display flashes with a recommended value.
䡲 Turn the adjusting knob to change the recommended value.
䡲 Press the adjusting knob to start the appliance straightaway.
䡲 If the adjusting knob is not pressed, the appliance will start automatically within 15
seconds of the last setting change.
䡲 Additional settings or changes can be made at any time.
䡲 Press the button to switch off the appliance.
14
User settings
You can change the appliance settings to suit your own preferences. The procedure
is the same for all user settings.
The following diagram gives an overview of the possible user settings.
▪ off *
▪ on
▪ invisible
▪ visible *
* Factory setting
Childproof look
Time
A Depress button for 5 seconds.
… User settings
15
Childproof lock
The childproof lock is to prevent the appliance from being accidentally switched on.
Switching the childproof lock on / off
A With the appliance switched off, hold the button depressed for 5 seconds.
– appears in the display.
A Press the adjusting knob to confirm.
– appears in the display for childproof lock off.
A Press the adjusting knob to confirm.
– appears in the display.
A Turn the adjusting knob to change the display to for childproof
lock on.
A Press the adjusting knob to confirm.
A Press the button to exit.
– The user setting selected is activated.
Operation with childproof lock activated
If the or buttons are pressed when the childproof lock is activated:
– A double acoustic signal is emitted.
– Nothing happens when the buttons are pressed.
– appears in both displays.
A When the childproof lock is activated, press the button together with the
or button.
– The childproof lock is overridden. The appliance can now be used as normal.
– The childproof lock is automatically reactivated 10 minutes after the appliance
has been switched off.
The / / and buttons can be used irrespective of whether
the childproof lock is activated or not.
… User settings
16
Time display
Select between
䡲 (invisible)
䡲 (visible)
Switching the time display on / off
A With the appliance switched off, depress the button for 5 seconds.
– appears in the display.
A Press the adjusting knob to confirm.
– appears in the display.
A Turn the adjusting knob until appears in the display for time
display visible.
A Press the adjusting knob to confirm.
– flashes in the display.
A Turn the adjusting knob.
– appears in the display for time display invisible.
A Press the adjusting knob to confirm.
A Press the button to exit
– The user settings selected are activated.
If «invisible» is selected, the displays are not illuminated when the appliance
is off, minimizing electricity consumption. When the appliance is on the time
is displayed.
17
Baking and roasting
Operating modes
The operating modes available are described below.
Hot air
Hot air humid
A Press the button1×.
– Recommended cooking space
temperature: 180 °C
A heating element behind the back wall of the
cooking space heats up the air inside the cooking
space. A fan circulates the hot air evenly around
the cooking space. The food is warmed evenly
from all sides so that it is possible to bake on two
levels at the same time and thus save energy.
Suitable for cooking moist cakes and pastries,
such as flans, on two levels.
A Press the button 2×.
– Recommended cooking space
temperature: 180 °C
The steam produced during baking is largely
retained in the cooking space ensuring the food
retains its moisture.
Suitable for gratins, soufflés and yeast pastries.
… Baking and roasting
18
Grill
Grillforced convection
Keep appliance door closed when grilling.
A Press the button 3×.
– Recommended cooking space
temperature: 250 °C
The grill is suitable for grilling and gratinating
food.
Use the wire shelf for grilling food that is not too
thick and for putting tins on.
A Press the button 4×.
– Recommended cooking space
temperature: 200 °C
To avoid excessively dirtying the bottom of the
cooking space, put the food to be grilled in a
shallow, heatproof dish.
It is recommended that food be grilled on the wire
shelf at a cooking space temperature of between
150 °C and 190 °C. A baking tray lined with
aluminium foil placed at the lowest shelf level
serves as a drip tray.
Suitable for roasting chicken and meat as well as
for gratinating and browning.
… Baking and roasting
19
Selecting an operating mode
How to select an operating mode is explained by means of an example.
Assume you want to bake a cake in a 25 cm long cake tin. The 'Tips on settings' section gives:
The recommended cooking space temperature is given as a range to take account of
differences between recipes. For the first attempt, it is recommended the cooking
space temperature be set at the median value – in this example, 160 °C.
A Put the wire shelf in the cooking space at level 1.
A Press the button once or more to select the desired operating mode – in this
example hot air.
– The symbol illuminates.
–The symbol flashes.
– The recommended cooking space temperature flashes .
A Turn the adjusting knob to set the desired temperature – in this example
.
The recommended cooking space temperature can be changed as long as the
symbol and the temperature display are still flashing. If they have
already stopped flashing, press the button.
Burn hazard from heat produced during baking and
roasting! Please read the 'Safety precautions' section first.
Preheat Level
Time in
mins.
Cake, 25 cm 155–165 yes 1 50–60
If the cooking space temperature is not changed within the next 15 seconds,
the appliance switches on automatically.
C
C
… Baking and roasting
20
A Press the adjusting knob to start the appliance straightaway.
– As long as the cooking space temperature is under 30 °C, appears
in the temperature display.
– A single acoustic signal is emitted when the set cooking space temperature is
reached.
A Place the cake tin on the wire shelf.
Checking / Changing the cooking space temperature
The set cooking space temperature can be checked or changed during operation.
A Press the button.
– The symbol flashes for approximately 15 seconds.
– The set cooking space temperature flashes in the temperature
display.
A Turn the adjusting knob to change the cooking space temperature.
Changing the operating mode
The operating mode can be changed during operation.
A Press the button repeatedly until the desired operating mode appears.
– The set cooking space temperature remains unchanged.
The temperature display shows the temperature in the cooking space rising.
C
… Baking and roasting
21
End of baking
A After baking for approximately 50 minutes, check to see whether the cake is done.
Insert a wooden skewer in the centre of the cake and if it comes out clean the cake
is ready. Otherwise put the cake back and continue to bake.
A Take the cake out of the cooking space when it is done.
Switching off
A Press the button.
– The and symbols go out.
– As long as the cooking space temperature exceeds 80 °C, the temperature is
shown in the display.
A Leave the appliance door in the at-rest position, allowing the cooking space to
cool down.
When the symbols are no longer illuminated the appliance is off.
The cooling fan may continue to run for a certain length of time after the
appliance has been switched off.
C
… Baking and roasting
22
Optimal use
The recommended baking and roasting temperatures given in older recipe books are
likely to be too high and the recommended shelf levels in the cooking space not ideal.
The 'Tips on settings' section shows how to get the best use out of the appliance.
If in doubt, follow these tips. Note that the temperatures and times given in the tables
are based on typical methods of preparing food and thus are only indicative.
Cooking space temperature when using hot air
When baking or roasting with hot air, the cooking space temperature needs to be
around 20 °C lower than with top and bottom heat. Recipes often only give temperatures for baking or roasting with top and bottom heat. Compare them to the temperatures in the 'Tips on settings' section. If in doubt, select a lower temperature.
If the cake or roast is nice and brown on the outside but still doughy or raw
in the middle, it is usually a sign that the cooking space temperature is too
high.
… Baking and roasting
23
Baking with hot air
Place a suitable baking form (round tin, spring form tin, cake tin, etc.) on the wire shelf.
Push the original baking tray right to the back of the cooking space for optimum air
circulation.
Selecting the right level is particularly important when using hot air.
On one level
䡲 Place original baking tray or shallow
baking form on the wire shelf at level
1, or as recommended in the 'Tips on
settings' section.
䡲 Put deep baking forms, e.g. spring
form or gugelhopf (ring) tins, on the
wire shelf at level 1, or on the wire
shelf and then place directly on the
floor of the cooking space.
䡲 Put bulky food, e.g. a loaf of bread,
on the original baking tray at level 1.
On two levels
䡲 Put the original baking tray at level 1
and the wire shelf at level 4.
1
4
1
1
… Baking and roasting
24
Saving energy
䡲 Avoid opening the appliance door frequently.
䡲 Only switch the illumination on if needed.
䡲 Use the residual heat: for longer cooking times, i.e. over 30 minutes, switch
appliance off some 5 to10 minutes before the end of the cooking time.
Exceptions: soufflé, sponge, choux pastry and puff pastry.
Preheating
䡲 Do not preheat the cooking space unless recommended in the recipe or in 'Tips on
settings'.
䡲 Preheat briefly before grilling. See the cooking times given in 'Tips on settings'.
Minimize cleaning
䡲 To avoid food spills on the bottom of the cooking space, place protective foil in
the bottom of the appliance. The appliance comes with protective foil in the bottom. To order more original protective foil sheets, see the 'Accessories and spare
parts' section for the article number.
䡲 When grilling, to minimize cleaning, place the original baking tray – lined with
aluminium foil – at level 1.
… Baking and roasting
25
Using accessories
䡲 It is important to put the food that is to be cooked or baked at
the right level in the cooking space. See the 'Tips on settings'
section for which level to use.
䡲 The original baking tray serves as a baking form for flans and
biscuits, etc. and as a shelf, e.g. when baking with hot air on
two levels, and as a drip tray for use with the wire shelf.
䡲 Frozen food products, such as quiche or bread buns, that do
not fill the original baking tray shrink when they are cooked, especially if cooked at a high temperature. This is normal and unavoidable when using square baking trays. Taking the baking
tray out can also be more difficult. As it cools down, the baking
tray goes back to its original form. The wire shelf covered with
baking paper or a round baking tray placed on the wire shelf
can be used to cook such food on instead of the baking tray.
䡲 Using extremely hard knives or cutting wheels (ceramic, carb-
ide) to cut foodstuff on the original baking tray can damage the
surface.
䡲 The wire shelf can also be used for putting roasting tins and
baking forms, as well as meat and frozen pizza, etc, on.
䡲 The original baking tray is to be used the normal way round –
not upside down.
26
Clock functions
The appliance features the following clock functions:
䡲 Clock
䡲 Timer (the timer can be used at any time and independently of all other functions)
䡲 Operating time (time-controlled switch-off)
䡲 Delayed start (time-controlled switch-on and switch-off)
Setting and changing the time
A Depress the and buttons at the same time.
– The set time e.g. and the symbol flash.
A Turn the adjusting knob to set the time.
A Press the adjusting knob to confirm.
When the appliance is switched off, the display is dimmed between 22:00 and
6:00.
The clock cannot be altered if the delayed start function has been activated,
and in which case a double acoustic signal is emitted.
… Clock functions
27
Timer
The timer functions like an egg timer. It can be used at any time and independently of
all other functions.
Setting
A Press the button.
–The symbol flashes.
– apears in the right display.
A Turn the adjusting knob to set the timer duration.
The timer is set using the following intervals:
䡲 Up to 10 minutes in 10-second intervals, e.g. = 9 minutes and
50 seconds.
䡲 Over 10 minutes in 1-minute intervals, e.g. = 1 hour and
12 minutes.
The maximum timer duration that can be set is 9 hours and 59 minutes.
A Press the adjusting knob to start the timer.
– The symbol illuminates.
– The time remaining is displayed (provided no operating time has been
entered).
When the time is up:
– A sequence of 5 short acoustic signals is repeated for 1 minute.
–The symbol flashes.
A Press the adjusting knob to cancel the acoustic signal.
Checking and changing
A Press the button.
–The symbol flashes.
– The countdown to the time remaining flashes.
A Turn the adjusting knob to change the timer duration.
A Press the adjusting knob to confirm.
… Clock functions
28
Switching off before time
A Press the button.
– The symbol flashes.
– The countdown to the time remaining flashes.
A Turn the adjusting knob and turn the timer duration to .
A Press the adjusting knob to confirm.
Operating time
The operating time is the length of time that an operating mode is switched on. The
operating mode automatically switches off when the operating time is up.
Setting
A Preheat the cooking space if necessary.
A Place the food in the cooking space.
A Press the button.
– The symbol flashes.
– The symbol and the selected operating mode illuminate.
– flashes in the right display (10 minutes are pre-programmed).
A Turn the adjusting knob to set the desired operating time.
A Press the adjusting knob to start operation.
– The symbol for the selected operating mode illuminates.
– The and symbols illuminate.
– The current cooking space temperature is shown in the temperature display.
– The operating time remaining is shown in the right display.
Example: You select the operating mode and .
At 9:00 you set an operating time of 1 hour and 15 minutes.
The appliance will switch off at 10:15.
C
C
… Clock functions
29
Checking and changing
A Press the button.
A Turn the adjusting knob to change the operating time.
A Press the adjusting knob to confirm.
Switching off before time
A Press the button.
End of the operating time
– The selected operating mode automatically switches off when the operating time
is up.
– A long, intermittent acoustic signal is emitted for 1 minute.
– The symbol flashes.
– The current cooking space temperature is shown in the temperature display.
A Press the adjusting knob to cancel the acoustic signal.
… Clock functions
30
Delayed start
The delayed start function helps you if you want to have a dish ready for a certain time
but you cannot switch the appliance on or off yourself at just the right time. Set the
operating time as well as the switch-off time. The appliance will switch on – with a
delay – and off again automatically.
If you use the food probe, you will need to estimate the cooking time. You will find a
guide on times in the tips on settings. The appliance will automatically switch on with
a delay and off again when the food probe temperature set is reached. Note that,
depending on the estimated cooking time, this could occur somewhat earlier or later
than the set switch-off time.
Setting
A Place the food in the cooking space and select the operating mode and the cook-
ing space temperature.
A Press the button.
– The symbol flashes.
– The symbol and selected operating mode light up.
– flashes in the right display (10 minutes are pre-programmed).
A Turn the adjusting knob to set the desired operating time.
A Press the button again.
– The symbol flashes.
– The actual time and the set operating time flash in the right display.
A Turn the adjusting knob to set the desired switch-off time and thus the
delayed start.
Perishables should not be kept unrefrigerated too long.
The switch-off time can be extended to 23 hours and 59 minutes at the most.
C
… Clock functions
31
A Press the adjusting knob to confirm.
– The and symbols light up.
– Until it turns on automatically, the appliance remains switched off.
Checking and changing
With the delayed start, it is possible to check all the settings. Only the switch-off time
can be changed.
A Press the button 2×.
–The symbol flashes.
– The switch-off time flashes in the right display.
A Turn the adjusting knob to change the switch-off time.
A Press the adjusting knob to confirm.
Switching off before time
A Press the button.
At switchoff time
– The appliance automatically switches off when the switch-off time is reached.
– A long, intermittent acoustic signal is emitted for 1 minute.
– The symbol flashes.
– The current cooking space temperature is shown in the temperature display.
A Press the adjusting knob to cancel the acoustic signal.
Example: You select the operating mode and .
At 9:00 you set an operating time of 1 hour and 15 minutes and a switchoff time of 12:30.
The appliance will switch on at 11:15 and go off again at 12:30.
32
Tips on settings
Cakes
Preheat Level
Time in
mins.
Cake, 25 cm 155–165 yes
1
50–60
Whisked sponge cake, ø 24 cm 170–180 no 30–40
Roulade / Swiss roll 180–190
yes
8–10
Carrot cake 160–170
55–65
Gugelhopf (ring cake) 155–165
Fruit tart with short-crust pastry 170–180 40–50
Linzertorte, ø 24–26 cm
160–170
50–55
Gingerbread 55–65
Quark cheesecake, ø 24–26 cm 170–190 no 45–50
Apple strudel 180–190 yes 40–45
… Tips on settings
33
Savouries and biscuits
Flans and pizza
Preheat Level
Time in
mins.
Savouries 160–170
yes
1
or
1 + 4
15–20
Ham croissants 180–190 20–25
Yeast pastries 170–190 15–25
Eclairs 180–190 30–35
Macaroons 120 15–20
Mailänderli (butter biscuits),
jam biscuits
160–170 14–18
Chräbeli (aniseed biscuits) 130–140 20–30
Meringues 90 90–120
Preheat Level
Time in
mins.
Fruit flan 170–190
yes
1
or
1 + 4
40–50
Pizza (fresh) 220–230 20–30
Vegetable flan 180–200
40–50
Cheese flan 170–180
… Tips on settings
34
Bread and plaited bread
Gratins and soufflés
Preheat Level
Time in
mins.
Bread 190–210
5 mins.
1
45–50
Zopf (plaited bread) 170–180 35–45
Raisin bread, hazelnut wreath,
hazelnut plait
170–190 yes 35–40
Preheat Level
Time in
mins.
Gratins sweet / savoury 180–200
yes 1
45–50
Potato gratin (with raw
potatoes)
180–190 50–55
Soufflés sweet / savoury 175–180 35–45
… Tips on settings
35
Meat
Poultry and fish
Preheat Level
Time in
mins.
Veal shoulder, 5.5 cm thick
180–190
no
0
90–100
Pork shoulder, 6 cm thick yes 110–120
Leg of lamb, 9 cm thick 180 4 mins. 45–55
Meat loaf, 5 cm thick 180–200 no
1
70–75
Liver loaf 180
yes
40–50
Fillet encased in puff pastry 180–190 35–45
4 chops
260
6 mins. 4 15–18
4 sausages 4 mins. 3 14–16
For level 0, put the wire shelf in the original baking tray and place directly on
the floor of the cooking space.
Preheat Level
Time in
mins.
Chicken, 1–1.2 kg 180–190 no 0 60–80
2 whole trout 240 4 mins. 3 8–10
Fillet of fish, ca. 600 g 190–200 yes 1 15–20
For level 0, put the wire shelf in the original baking tray and place directly on
the floor of the cooking space.
… Tips on settings
36
Gratinating
Roasting at a low temperature
Cooking using a Römertopf (clay cooking pot)
Preheat Level
Time in
mins.
Toast
260
6 mins.
44–5
Toast Hawaii (ham and
pineapple toastie)
5 mins.
Vegetables 6 mins. 3 or 4 5–10
Preheat Level
Time in
hours
Fillet of beef, 5 cm thick 80–85
yes 1
2–2½
Roast beef, 5 cm thick 80–90
Loin of pork kidney end,
5 cm thick
90–100 2½–3½
Preheat Level
Time in
mins.
Whole chicken,1 kg 200
no 1
60–70
Roast, 1 kg
230
100–120
Meat loaf, ca. 800 g 60–70
… Tips on settings
37
Drying and desiccating
A Only use healthy, ripe fruit, fresh mushrooms and herbs.
A Place the washed and chopped fruit, mushrooms or herbs on baking paper on the
wire shelf or on the original baking tray and put in the cooking space at the ap-
propriate level.
A When drying or desiccating, use only the wire shelf and original baking tray at
the same time.
A Turn the food at regular intervals to ensure even drying.
Always keep your eye on foodstuffs when drying or desic
cating them – if they dry out too much, they can pose a fire
hazard!
Wedge a wooden spoon between the underside of the operating panel and
the top of the appliance door, leaving about a 2 cm gap open.
Preheat Level
Time in
hours
Apples, peeled and unpeeled, cut
into slices or rings
70
no
1
1 + 4
12–13
Mushrooms, cut into 2 mm thick
slices
50–60
4–5
Herbs 1–1½
… Tips on settings
38
Bottling
Bottling involves preserving food in glass jars.
A Only use undamaged jars.
A Fill and seal the jars in accordance with the manufacturer’s instructions.
A Put a maximum of five jars – ideally of the same size and each holding no more
than1 litre – in the original baking tray and place at level 2 in the cold cooking
space, as shown in the diagram. The jars should not touch one another.
A Set the operating mode to150 °C and heat for about 35–40 minutes until the
liquid in the jars starts to bubble.
A Set the cooking space temperature to 0 °C and allow the jars to sterilise for 40
minutes.
A Press the button, switching off the operating mode, and leave the appliance
door open in the at-rest position.
A Leave the jars in the cooking space to cool down completely. Finally, check that
the jars are sealed.
39
Care and maintenance
Cleaning the exterior
A Avoid cleaning the surface of the appliance with abrasive or caustic cleaning
agents, stainless steel cleaner, scouring pads, wire wool, etc., which can damage
the surface.
A Remove any food spills or excess cleaning solution as quickly as possible. Clean
the surface with a cloth dampened with tap water and then polish using a soft
cloth.
Cleaning the accessories
䡲 The wire shelf and shelf guides can be cleaned in the dishwasher.
䡲 The baking tray can be cleaned in the dishwasher. The non-stick effect, however,
will wear off with time.
… Care and maintenance
40
Cleaning the cooking space
A Avoid using abrasive cleaners such as scouring pads, steel wool, etc. as they can
damage the surface.
A Clean the appliance door with a soft cloth dampened with water. Finish off by pol-
ishing with a soft cloth.
䡲 Depending on the model, the cooking space may have an enamel coating (smooth
surface) and in which case it can be cleaned using standard oven cleaners. Please
follow the manufacturer’s instructions.
For ease of cleaning, various parts in the cooking space can be easily removed.
Removing the shelf guides
A Lift the shelf guides slightly at the front and remove
from the front holes.
A Push the shelf guides to the back and remove from
the back holes.
A Reassemble in the reverse order.
As the temperature sensor and the heating elements in the
cooking space can be easily damaged, care must be taken
not to bend them during cleaning.
… Care and maintenance
41
Removing the appliance door
A Open the appliance door as far
as it will go.
A Fold the clamps on the door
hinges 1 forward.
A Close the appliance door just
enough that it can be lifted out.
A To reassemble, push the hinges
into the holes from the front.
A Open the appliance door as far
as it will go and fold back the
clamps on the door hinges 1.
The following parts can also be removed
䡲 Door seal
A Pull the seal slightly out at the corners and unhook.
1
1
… Care and maintenance
42
Catalytic selfcleaning
Depending on the model, the cooking space may come supplied with a catalytic selfcleaning coating. The coating is matt and rough. During the catalytic cleaning process, food residues are burned off at temperatures of over 200 °C during normal use.
The cleaning process requires oxygen out of the air. A dirty catalytic coating should,
therefore, not be covered. Dried-up, baked-on food spills (e.g. burned-on gravy or
glaze) impair the cleaning effect and can be avoided, as follows:
A When grilling, place the original baking tray – lined with aluminium foil – at
level 1.
A Wipe away food spills as soon as possible when still in a liquid form.
A Place protective foil on the bottom of the cooking space.
For dried-up, baked-on food spills:
A Soften with a damp cloth and then wipe away.
A Use a plastic or wooden spatula to scrape off any dried-up, baked-on food spills.
Soften any stubborn rests with a damp cloth and then wipe away.
If the cooking space is heavily soiled, it is recommended that the empty cooking space
be heated for several hours at the maximum cooking space temperature using the
operating mode.
The life expectancy of the catalytic coating largely depends on the degree of soiling.
Do not scrub the cooking space or use oven sprays, cleaning
pastes or household detergents in it. The catalytic coating
may otherwise become discoloured and the selfcleaning
function may no longer work.
Only remove dried-up, baked-on food spills. Any remaining food residues will
eventually disappear after going through the baking and cleaning process a
number of times. In the case of a heavily soiled appliance or after being in
operation for several years, some stains may remain.
43
Troubleshooting
What to do if …
… the appliance is not working
… the illumination is not working
… when grilling, thick smoke is given off
Possible cause Solution
䡲 Fuse or circuit breaker for
electrical installations in the
home is defect.
䡲 Fuse or circuit breaker keeps
blowing.
䡲 No power.
A Change the fuse.
A Reset the circuit breaker.
A Call Customers Services.
A Check mains supply.
Possible cause Solution
䡲 The light bulb is defective. A Call Customer Services as a special kind of light
bulb is needed.
Possible cause Solution
䡲 The food is too near to the
heating elements.
䡲 The cooking space temper-
ature is too high.
A Check that the level being used is as recom-
mended in the 'Tips on settings'.
A Reduce the cooking space temperature.
… Trouble-shooting
44
… «F..» is flashing in the display
After a power failure
After a power failure flashes in the right display.
Setting the time
A Depress the and buttons at the same time.
A Turn the adjusting knob to set the time.
A Press the adjusting knob to confirm.
Possible cause Solution
䡲 Various situations can lead
to an «F» error message.
A Cancel the error message by pressing the
button.
A Switch the electricity supply off for about
1minute.
A Switch the electricity supply back on again.
A If the message appears again, note down the
error number and then switch the electricity
supply off.
A Call Customer Services.
䡲 The user settings remain unchanged.
䡲 If there is a power failure during soft roasting, it will be no longer possible
to continue running this operating mode.
45
Tips and tricks
The baking or roast looks good on the outside, but is still doughy
or raw in the middle
䡲 The baking or roasting time can be reduced only slightly by increasing the cooking
space temperature (cooked on the outside and raw on the inside). Lower the tem-
perature of the cooking space slightly and lengthen the cooking time
correspondingly.
Cake collapses
䡲 Check your settings with those given in the 'Tips on settings' section.
䡲 Reduce the cooking space temperature by 10 °C and possibly extend the baking
time.
䡲 Bake the finished cake mixture immediately. Follow the mixing times given in reci-
pes. With whisked sponge cakes, for example, beat the egg yolk mass and the
egg whites slightly longer.
䡲 Check the recipe: adding too much baking powder, for instance, can cause
problems.
Uneven browning
䡲 Uneven browning is to a certain degree normal. More even browning is generally
achieved at lower temperatures. If necessary, lower the temperature of the cooking
space slightly and extend the cooking time correspondingly.
䡲 When baking with hot air, check that the shelf levels used correspond to those re-
commended in the 'Tips on settings' section.
䡲 Do not push baking tins or bulky foodstuff right to the back of the cooking space.
… Tips and tricks
46
The baking has come out lighter on one tray than on the other
䡲 When baking on more than one tray at the same time, the baking produce is not
always ready simultaneously. Give the tray with the baking that is not so brown a
little longer.
Measuring the cooking space temperature using own thermometer
䡲 In accordance with an internationally accepted norm, the cooking space temper-
ature is measured when the appliance is empty. Taking own temperature measurements can be imprecise and not suitable for checking how exact the cooking
space temperature is.
Note for testing institutes
The stated measurements according to EN 50304 are to be tested in the hot air humid
operating mode.
47
Accessories and spare parts
Please give model no. and exact description when ordering parts.
Accessories
Spare parts
Original baking tray
Wire shelf
Protective foil for bottom of cooking space
(set of 5)
Door seal
48
Disposal
Packaging
䡲 All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are
marked accordingly and should, if possible, be collected for recycling and disposed of in an environmentally friendly way.
Disconnection
䡲 Disconnect the appliance from the mains. With a fixed appliance, this is to be car-
ried out by a qualified electrician!
Safety
䡲 Disable the appliance to prevent accidents caused by improper use, especially
through children playing.
䡲 Pull the plug out of the mains socket or have the appliance disconnected from the
mains by a qualified electrician. Then cut the mains cable.
Disposal
䡲 The old appliance should not be discarded as worthless rubbish. If disposed of
correctly, the raw materials can be recovered for recycling.
䡲 The symbol on the identification plate warns that the appliance may not be
disposed of in normal household waste.
䡲 The appliance must be disposed of in accordance with local regulations on waste
disposal.
For more information on the handling, disposal and recycling of the product,
please contact the local authorities, the local recycling facilities for household
waste or the retailer from whom you purchased the appliance.
49
Index
A
Accessories .............................. 47
Ordering ............................. 51
Using.................................. 25
Adjusting knob .......................... 11
Appliance description................. 10
Appliance door
Removing ............................ 41
B
Baking..................................... 17
Baking with hot air..................... 23
Before using for the first time .......... 5
Biscuits .................................... 33
Bottling .................................... 38
Bread...................................... 34
Browning
Uneven ............................... 45
Buttons..................................... 11
C
Cakes ..................................... 32
Care ....................................... 39
Childproof lock ......................... 15
Children in the home.................... 6
Cleaning
Accessories.......................... 39
Cooking space..................... 40
Exterior................................ 39
Clock ...................................... 26
Cooking
Using a Römertopf (clay cooking
pot) .................................... 36
Cooking space temperature......... 20
D
Delayed start............................. 30
Desiccating .............................. 37
Disconnection ........................... 48
Display elements........................ 11
Disposal................................... 48
Drying foodstuffs ........................ 37
E
End of baking time..................... 21
Error message ........................... 44
F
Fish ......................................... 35
Flans ....................................... 33
G
General operating instructions ...... 13
Gratinating............................... 36
Gratins .................................... 34
Grill ........................................ 18
Grill-forced convection ................ 18
H
Hot air..................................... 17
Baking ................................ 23
Levels.................................. 23
Hot air humid............................ 17
L
Levels
Hot air ................................ 23
M
Maintenance ............................ 39
Malfunction .............................. 51
Meat....................................... 35
… Index
50
N
Note for testing institutes ............. 46
O
Operating element .................... 11
Operating mode ....................... 17
Changing ........................... 20
Selecting............................. 19
Operating time
Operating mode .................. 28
Orders .................................... 51
P
Packaging ............................... 48
Pizza ...................................... 33
Plaited bread............................ 34
Poultry..................................... 35
Power failure ............................ 44
Preheating ............................... 24
Q
Queries................................... 51
Quick instructions ...................... 52
R
Repair service........................... 51
Roasting .................................. 17
Roasting at a low temperature ..... 36
Römertopf (clay cooking pot) ....... 36
Round tin ................................. 23
S
Safety ..................................... 48
Safety precautions
Before using for the first time ..... 5
Children in the home ............... 6
Correct use............................ 6
Use...................................... 7
Saving energy .......................... 24
Savouries................................. 33
Selecting
Operating mode................... 19
Self-cleaning............................. 42
Service agreements.................... 51
Service centre........................... 51
Soufflés ................................... 34
Spare parts .............................. 47
Ordering............................. 51
Switching off
Operating mode................... 21
Switch-off time .......................... 30
Symbols............................... 2, 11
T
Testing institutes......................... 46
Time
Display ............................... 16
Setting ................................ 26
Timer ...................................... 27
Tips and tricks........................... 45
Tips on settings ......................... 32
Trouble-shooting ........................ 43
U
Uneven browning...................... 45
User settings ............................. 14
Using for the first time............. 5, 13
51
Repair service
Whether you contact us for repairs or orders, please always state the serial number
(FN) and the name of the appliance. Enter these details below and also on the service
sticker which comes with the appliance. Stick it in a conspicuous place or in your address book.
You will also find the same details on the certificate of guarantee, the original sales
invoice and the identification plate of the appliance.
A Open the appliance door.
– The identification plate is on the left-side panel.
If the appliance is not working properly, contact your nearest V-ZUG LTD service centre
using freephone 0800 850 850 and stand in close proximity to the appliance.
Queries, orders, service agreements
For administrative or technical queries or problems, as well as for ordering spare parts
and accessories, please contact our head office in Zug on tel. 041 767 67 67.
As regards the maintenance of all our products, when the warranty expires you have
the option of taking out a service agreement. We will be happy to send you the necessary forms.
The 'Troubleshooting' section will help you to carry out small
repairs yourself, saving you the time and trouble of calling
out a service engineer and the cost that goes along with it.
FN
Appliance
Quick instructions
Please read the safety precautions in these operating instructions!
Setting the time
A Depress the and buttons at the same time.
A Turn the adjusting knob to the time.
A Press the adjusting knob to confirm.
Selecting the operating mode
A Press the button repeatedly until the desired operating mode appears.
A Turn the adjusting knob to set the cooking space temperature.
A Press the adjusting knob to start.
Switching off the appliance
A Press the button.
Setting the timer
A Press the button.
A Turn the adjusting knob to set the timer duration.
VZUG LTD
Industriestrasse 66, 6301 Zug
Tel. 041 767 67 67, Fax 041 767 61 61
vzug@vzug.ch, www.vzug.ch
Service Centre: Tel. 0800 850 850
J704.13-1
Loading...
