VTech T2447 User Manual
with Caller ID Digital Answering System
Cordless Phone System
USER’S MANUAL
t2447
caller ID / call waiting *
Digital answering system
with 3 mailboxs and
15 minutes record time.
90 name and number
caller ID memory
Important Safety Instructions
When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock and injury, including the
following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink,
or swimming pool).
5. Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for
ventilation. To protect it from overheating, these openings must not be blocked
by placing the product on the bed, sofa, rug, or other similar surface. This
product should never be placed near or over a radiator or heat register. This
product should not be placed in a built-in installation where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product
where the cord will be abused by persons walking on it.
9. Never push objects of any kind into this product through cabinet slots as they
may touch dangerous voltage points or short out parts that could result in a
risk of fire or electric shock. Never spill liquid of any kind on the product.
10. To reduce the risk of electric shock, do not disassemble this product, but take
it to an authorized service facility. Opening or removing cabinet parts other
than specified access doors may expose you to dangerous voltages or
other risks. Incorrect reassembling can cause electric shock when the appliance is subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk
of fire or electric shock.
12. Unplug this product from the wall outlet and refer servicing to an authorized
service facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating instructions, because improper adjustment of other controls may
result in damage and will often require extensive work by an autho-
rized technician to restore the product to normal operation.
E. If the product has been dropped and the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.
1
Important Safety Instructions
13. Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
15. Only put the Handset of your telephone next to your ear when it is in normal
talk mode.
2
Before You Begin
Enhanced 2.4GHz Technology - Dual Band transmission combines the best of
2.4GHz and 900MHz technologies, providing enhanced performance over standard cordless telephones.
3
Before You Begin
Parts Check List:
1. Base Unit
2. Handset
3. Base AC Power Adaptor
4. Telephone Line Cord
To purchase replacement battery packs, call VTech Communications, Inc. at
1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1800-267-7377.
5. Battery
6. Belt Clip
7. User’s Manual
8. Base Wall Mounting Bracket
Base UnitHandset
Belt Clip
Base Wall
Mounting Bracket
Battery
4
User’s Manual
Telephone Line Cord
The Handset Layout
1
2
3
4
5
6
7
8
1. Antenna
2. Earpiece
3. LCD
4. Left and Right Arrow Keys
5. Phone/Flash Key
6. Dialing Keys (0-9,*,#)
7. Chan/Delete Key
9
10
11
12
13
14
8. Microphone
9. Headset Jack
10. Sel Key
11. Off Key
12. Hold Key
13. Redial/Pause Key
14. Prog Key
5
The Base Unit Layout
1
2
3
4
5
6
13
PRIVACYOF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING
THIS PHONE.
NOTCAUSE HARMFUL INTERFERENCE; AND 2)THIS DEVICE MUST
ACCEPTANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
ISSUBJECT TO THE FOLLOWINGTWO CONDITIONS: 1)THIS DEVICE MAY
RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C, RJ11W
THISDEVICE COMPLIES WITH PART 15 OF THE FCC RULES.OPERATION
VTECH TELECOMMUNICATIONS LTD.
MANUFACTURED IN CHINA
COMPLIES WITH 47 CFR PART 68
REGISTRATION NO.:US: EW7W901B24280
HAC FCCID: EW780-5298-B00
7
8
9
10
11
12
MODEL:2447
14
1. Menu Key
2. Change Key
3. Time/Set Key
4. Memo/Rec Key
5. Page Key
6. In Use/Charging Light
7. On/Off Key
8. Volume -/+ Keys
9. Skip/Quick Key
10. Delete Key
11. Repeat/Slow Key
12. Play/Stop (Mailbox) Keys
13. DC Connector Jack
14. Telephone Line Jack
6
Installation
Before Y ou Install
1. Choose a location for the Base near an electrical outlet and a telephone
jack. This phone requires a modular telephone jack and a standard electri-
cal outlet (110V AC) not controlled by a wall switch.
2. Install the Handset battery. Use only VTech batteries.
a) Remove battery
compartment cover
by pressing on the
indentation and sliding downward.
b) Align the two holes in the plug with the
socket pins, then snap the plug into place.
c) Place the battery in the compartment with
the wires in the lower right corner. Angle
the top of the battery under the top claws
first, then snap the bottom of the battery
in. Place the wires under the guide, located
below the battery.
d) Replace battery compartment cover.
Getting Started
3. Plug the DC connectors to the Base. Plug the AC adaptors into an electrical
outlet. Connect the telephone line cord to the jack on the Base, and the other
end to a modular telephone jack, as illustrated on the next page.
4. Place the Handset in the Base. Charge the battery for 10-12 hours.
7
Installation
Table/Desk Installation
Connect the
power cord.
Getting Started
1. Check for Dial T one
After the battery is charged, pick up the Handset and press PHONE, you should
hear a dial tone.
Connect the telephone
line cord
MODEL:2447
VTECH TELECOMMUNICATIONS LTD.
MANUFACTURED IN CHINA
COMPLIES WITH 47 CFR PART 68
REGISTRATION NO.:US:EW7W901B24280
RINGEREQUIVALENCE: 0.1B USOCJACK: RJ11C, RJ11W
THISDEVICE COMPLIES WITH PART15 OF THE FCC RULES. OPERATION
ISSUBJECT TOTHE FOLLOWING TWO CONDITIONS: 1)THIS DEVICE MAY
NOTCAUSE HARMFUL INTERFERENCE; AND 2)THIS DEVICE MUST
ACCEPTANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
PRIVACYOF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING
THIS PHONE.
HAC FCC ID: EW780-5298-B00
2. Set Time and Date
If you subscribe to Caller ID service, the date and time will be set automatically with
the first incoming call. If you do not have Caller ID service, you can set the date
and time manually.
• Press PROG, and then press or until DATE/TIME is displayed. Press
SEL.
• The month is flashing. Press or until the screen displays the correct
month. Press SEL.
• The day is flashing. Press or until the screen displays the correct day.
Press SEL.
• The hour is flashing. Press or until the screen displays the correct hour.
Press SEL.
• The minute is flashing. Press or until the screen displays the correct
minute. Press SEL.
• AM or PM is flashing. Press or to choose AM or PM. Press SEL.
8
Installation
Wall Mounting
The Wall Mount bracket is designed for use on standard wall mount plates only.
1. Run the power and telephone line cords through the slots in the bracket,
connecting them to the jacks located on the underside of the Base.
2. Plug the AC adapter into an electrical outlet. If the battery has not been
previously charged, place the Handset in its Base, and allow it to charge for
12 hours.
3. Connect the telephone line cord to the wall jack.
4. Line up the tabs on the wall mount bracket with the slots on the bottom of the
Base Unit. Snap the bracket firmly in place.
5. Mount the Base on the wall. Position the Base Unit so the mounting studs
will fit into the holes on the wall mount bracket. Slide the Base Unit down on
the mounting studs until it locks into place.
Getting Started
9
Telephone Operation
Answer a Call
Press any key
except OFF.
Hold
Press to put a call
on hold. Press again
to release hold.
OR
Lift the Handset of
an extension.
Make a Call
Press PHONE, then dial
the number.
OR
Dial the number (use
to backspace and correct digits), then
press PHONE to call.
Flash/Call Waiting
If you have Call Waiting
service, you will hear a
Basic Operation
beep if someone calls
while you are on a call.
Press PHONE/FLASH to
put your current call on
hold and take the new
call. Press this button at
any time to switch between calls.
Channel
Switch to a clear channel while
on a call.
Delete
While Handset is idle, press and
hold to delete all records in Call
Log.
When viewing the Call Log, press
to delete the current record displayed.
Handset Volume
Adjust the volume while on a call.
A double beep will sound4when
you reach the maximum or minimum setting.
DIR
Press DIR when phone is not in
use to display phonebook entries. While entering letters,
press to advance cusor.
CID
Press CID when phone is not
in use to display caller ID information. When entering numbers or letters, press to delete
last character entered.
Select
Use SEL in conjunction with
PROG during Handset pro-
gramming.
End a Call
Press OFF
OR
Place Handset
in Base.
Exit
Programming
Cancel a page
Redial
Press PHONE, then press REDIAL/PAUSE to call the last num-
ber dialed (up to 32 digits).
OR
Press REDIAL/PAUSE, then
press PHONE to the call last number dialed.
Press REDIAL/PAUSE twice to
delete the last number dialed
record with Handset idle.
Pause
Press REDIAL/PAUSE to inset a
dialing pause when enter numbers.
Program
Enter programming mode with Handset idle (on hook).
10
Telephone Operation
Page
Press to page the Handset for up to 60
seconds. Press again, press OFF on
Handset or place Handset in Base to
cancel the page.
In Use/Charging
• Flashes in unison with the ring of an
incoming call.
• Flashes slowly when the Handset is in
use.
• Flashes rapidly when a call is on hold.
• Glows steadily when the Handset is
charging.
11
Basic Operation
Telephone Operation
Handset Ringer Style/Battery Save
You can select from four different Handset ringer styles, or turn the ringer off and
extend the battery life.
1. Make sure the Handset is off.
2. Press PROG.
3. Press until the screen displays RINGER:.
4. Press SEL. The current setting blinks, and you will hear a sample of the ring.
5. Press or to select RINGER:1, 2, 3, 4 or OFF. You will hear a sample of
each ring.
6. Press SEL to choose the displayed ringer setting.
Set Dial Mode
If you have touch tone service, the phone is ready to use as soon as the battery is
charged. If you have pulse (rotary) service, you'll need to change the dial mode.
1. Press PROG.
2. Press Until screen displays DIAL MODE & SETTING.
3. Press SEL. The current setting blinks.
DIAL MODEL: TONEDIAL MODEL: TONE
DIAL MODEL: TONE
DIAL MODEL: TONEDIAL MODEL: TONE
Default setting: Tone
4. Press
5. Press SEL.
Set Language
Basic Operation
1. Press PROG to begin prgramming.
2. Press or until LANGUAGE is displayed.
3. Press SEL. The current setting blinks.
4. Press to display ENGLISH, ESPANOL or FRENCH
5. Preess SEL to select displayed language and exit.
to display tone or pulse.
ENGLISHENGLISH
ENGLISH
ENGLISHENGLISH
Default setting: English
Temporary Tone Dialing
If you have pulse (rotary) service only, you can change from pulse to touch tone
dialing during a call by pressing *TONE. This is useful if you need to send touch
tone signals for access to telephone banking or long-distance services.
1. Dial the number.
2. Press *TONE. Buttons pressed after this send touch tone signals.
3. After you hang up, the phone automatically returns to pulse (rotary) service.
12
Telephone Operation
Display Screen Messages
Screen Displays: When:
** RINGING **** RINGING **
** RINGING **
** RINGING **** RINGING **
There is a call coming in.
CONNECTING...CONNECTING...
CONNECTING...
CONNECTING...CONNECTING...
PHONE ONPHONE ON
PHONE ON
PHONE ONPHONE ON
SCANNING...SCANNING...
SCANNING...
SCANNING...SCANNING...
** PAGING **** PAGING **
** PAGING **
** PAGING **** PAGING **
HOLDHOLD
HOLD
HOLDHOLD
BATTERY LOWBATTERY LOW
BATTERY LOW
BATTERY LOWBATTERY LOW
NO CONNECTNO CONNECT
NO CONNECT
NO CONNECTNO CONNECT
The Handset is waiting for a dial tone.
The Handset is in use.
The Handset is changing to another of the 30
channels available.
The Base is paging the Handset.
There is a call on hold.
The Battery needs to be recharged.
1. Displays and a sad tone sounds when the
Base power is off and PHONE is pressed.
2. Displays and a sad tone sounds when
Handset is out of range and an attempt to
dial is failed.
Basic Operation
13
Speed Dial
You can store up to 9 telephone numbers with names (up to 15 characters, 24 digits
each location) you dial frequently into the Speed dial memory locations you assign (1
though 9) in the Handset.
You can also store telephone numbers with names alphabetically in the directory. See
T elephone Directory for instructions.
NOTES:
1. The entries you store in Speed dial memory will be marked with 01 through
09 and also display in the directory.
2. Press OFF at any time to exit speed dial mode.
Store a Number/Name in Memory
1. Press PROG. Then press or until the screen displays SPEED DIAL.
2. Press SEL. The screen displays ENTER 1-9.
NOTE: When memory is full, the screen displays MEMORY FULL, an error tone
sounds, and you will not be able to store a new record until you delete a
stored record the speed dial memory or telephone directory.
3. Press the key (1 through 9) to assign the memory location for your entry. The
screen displays ENTER NAME.
NOTE: If the location is not empty, your new entry will be stored in place of the old
and will delete the former entry. Take caution to not save over entries you do not
wish to delete from memory.
4. Using the chart below, enter up to 15 characters for the name you’re storing.
to backspace and make corrections; use to add a space.
Use
Basic Operation
Presses
Dial Key 1 2 3 4 5 6
1: 1
2: A B C 2
3: D E F 3
4: G H I 4
5: J K L 5
6: M N O 6
7: P Q R S 7
8: T U V 8
9: W X Y Z 9
0: 0
* *
#: & ’ , - . #
5. When you finish entering the name, press SEL or PROG. The screen displays ENTER NUMBER.
6. Enter the telephone number. Use to backspace and make corrections.
Press REDIAL/PAUSE to enter a pause if necessary.
14
Loading...
