VTech t2340 User Manual

Table of Contents
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GETTING STARTED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Install Handset Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Table/Desk Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Charge the Handset Battery . . . . . . . . . . . . . . . . . . . . . . . 7
Set Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Check for Dial Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Set the Dial Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Set Handset Date and Time . . . . . . . . . . . . . . . . . . . . . . . 8
BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Telephone Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Handset Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Base Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Operating Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Temporary Tone Dialing . . . . . . . . . . . . . . . . . . . . . . . . . 11
Call Forward . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Display Screen Messages . . . . . . . . . . . . . . . . . . . . . . . . 12
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Store a Number/Name in Speed Dial . . . . . . . . . . . . . . . . . .13
Edit a Number/Name in Speed Dial . . . . . . . . . . . . . . . . . . .15
Delete a Number/Name in Speed Dial . . . . . . . . . . . . . . . . . .15
Dial a Speed Dial Number . . . . . . . . . . . . . . . . . . . . . . . . 15
Reassign Locations in Speed Dial . . . . . . . . . . . . . . . . . . . .15
Telephone Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Store a Number/Name in the Directory . . . . . . . . . . . . . . . . .16
Edit a Number/Name in the Directory . . . . . . . . . . . . . . . . . .17
Delete a Number/Name in the Directory . . . . . . . . . . . . . . . . .17
Dial a Number from the Directory . . . . . . . . . . . . . . . . . . . . 18
Move a Number/Name to the Memory . . . . . . . . . . . . . . . . . .18
Caller ID Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
About Call History (Caller ID) . . . . . . . . . . . . . . . . . . . . . .20
Review Call History . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Delete Records from Call History . . . . . . . . . . . . . . . . . . . .20
Dial a Displayed Number. . . . . . . . . . . . . . . . . . . . . . . . .21
Store a Displayed Number . . . . . . . . . . . . . . . . . . . . . . . .21
www.vtechphones.com TABLE OF CONTENTS
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Battery Care and Maintenance. . . . . . . . . . . . . . . . . . . . . .22
Replacing the Handset Battery. . . . . . . . . . . . . . . . . . . . . .22
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Warranty Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . .32
FCC, ACTA and IC Regulations . . . . . . . . . . . . . . . . . . . . . . . 32
The RBRC Seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Technical Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
1
NEED HELP?
This book has all the feature operation and troubleshooting you need to install
and operate your new VTech phone. Please take the time to review thoroughly
to ensure proper installation and the benet of this VTech innovative and feature
rich product. You can also visit our website at www.vtechphones.com for support,
shopping, and everything new at VTech.
In Canada, please visit www.vtechcanada.com
VTech toll free 1-800-595-9511 In Canada dial 1-800-267-7377
Before You Begin
Parts Check list
1. Handsets (2)
2. Base Unit
3. Charger Power Adaptor
4. Charger
5. Telephone Line Cord
6. Batteries (2)
7. AC Power Adaptor
8. User’s Manual
To purchase replacement batteries, visit us on the web at www.vtechphones.com or call VTech Communications, Inc. at 1-800-595-9511.
In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377.
HANDSET x 2
BASE UNIT
CHARGER
POWER ADAPTOR
CHARGER
Important!
Before using this telephone, you must read Important Safety
Instructions
page 32.
on
Getting Started
TELEPHONE LINE CORD
BATTERY x 2
AC POWER ADAPTOR
www.vtechphones.com
USER’S MANUAL
GETTING STARTED
3
• Use only the provided
“CLICK”
VTech battery, or equivalent.
Installation
Choose Location
For maximum performance of your cordless telephone system:
1. Choose a central location for your Base Unit.
2. Ins ta ll y o ur b a se un it a n d extension handsets away from electronic equipment, such as personal computers, television sets and microwave ovens.
3. In lo ca tions where there are mul tiple cor dless teleph one s, separate base units as much as possible.
4. Install your telephone equipment away fro m heat sources and sunlight.
5. Avoid excessive moisture, dust or extreme cold.
Install Handset Battery
a) Align the two holes in the plug with
the socket pins, then snap the plug into place.
b) Place the battery in the compartment with
the wires in the lower right corner. Angle the top of the battery under the top claws
rst, then snap the bottom of the pack in.
Place the wires under the guide, located below the battery.
c) Replace cover by sliding it up into
place.
d) Place the handset in its base when
not in use to ensure maximum daily performance.
a)
c)
GETTING STARTED
4
www.vtechphones.com
Installation
 
 
Table/Desk Installation
Getting Started
Connect the powe r cord. Afte r charging the battery for at least 16 hours, connect the telephone
line cord.
Standard electrical outlet
www.vtechphones.com
• Install the base unit away from electronic equipment such as personal computers, televisi on sets or microwave ovens. Av o id exc ess ive heat, cold, dust or moisture.
GETTING STARTED
5
Installation
Wall Mounting
Your phone base unit is designed to mount on a standard telephone wall plate. Wall mounting is optional.
1. Run the power and telephone cords through the slot, then connect them to the jacks located on the underside of the base.
2. Plug the AC adaptor into an electrical outlet. If the battery has not been previously charged, place the handset in the base, and allow it to charge at least 16 hours (or overnight). Connect the telephone line cord to the wall jack.
3. Mount the base on the wall. Position the base unit so the mounting studs will t into the holes on the wall mount bracket. Slide the base unit down on the mounting studs until it locks into place.
GETTING STARTED
6
www.vtechphones.com
Installation
Charge the Handset Battery
Place the handset in the base. CHARGING... will display. Be sure to charge the battery for at least 16 hours before using your phone.
Set Language
• Press PROG, then press or Press SELECT.
• The current setting blinks. Press Spanish).
• Press SELECT to save your selection.
Check for Dial Tone
After the batteries are charged, pick up the handset and press TALK; you should hear a dial tone. If you do not, try this phone in another phone jack
Set the Dial Mode
If you have touch tone service, the phone is ready to use as soon as the battery is charged. If you have pulse (rotary) service, you’ll need to change the dial mode.
• Press PROG.
• Press or
• Press SELECT. The current setting blinks.
• Press or
• Press SELECT to save.
until the screen displays DIAL MODE: and the current setting.
to select TONE or PULSE.
until LANGUAGE is displayed.
or
until the screen displays the correct language (English or
• If the phone will not be used for a long period of time, remove the battery to prevent possible leakage.
• If you have any trouble installing your phone, please refer to the
Troubleshooting
section near the end of this manual.
Getting Started
www.vtechphones.com
GETTING STARTED
7
• In the event of a power outage, or if your phone’s power cord is unplugged, the time setting will be lost.
GETTING STARTED
8
Installation
Set Handset Date and Time
If you subscribe to caller ID service, the date and time will be set automatically with the rst incoming call. If you do not have caller ID service, you can set the date and time manually:
• Press PROG, then press or
• The month is ashing. Press or
• The day is ashing. Press or
• The hour is ashing. Press or
• The minute is ashing. Press or
AM or PM is ashing. Press or
until DATE/TIME is displayed. Press SELECT.
until the screen displays the correct month. Press SELECT.
until the screen displays the correct day. Press SELECT.
until the screen displays the correct hour. Press SELECT.
until the screen displays the correct minute. Press SELECT.
to choose between AM or PM. Press SELECT
Handset Ringer Style/Battery Save
You can select from four different handset ringer styles, or turn the ringer off and extend the battery life.
• With the handset in idle (off) mode, press PROG.
• Press or
• Press SELECT. The current setting blinks, and you will hear a sample of the ring.
• Press or
• Press SELECT.
until the screen displays RINGER: and the current setting.
to select RINGER: 1, 2, 3, 4 or OFF. You will hear a sample of each ring tone.
If you subscribe to DSL service:
If you hear noise during conversations and/or your caller ID features aren’t functioning properly, install a
noise lter to the telephone line between the base unit
and the telephone line jack. Contact your DSL provider
to obtain a noise lter.
Telephone line cord
www.vtechphones.com
To single telephone jack (RJ11C)
Noise lter
(For xDSL users)
Telephone Operation
Handset Operation
1. Make a Call
Press before or after dialing number to place a call.
Flash/Call Waiting
2.
Press to begin a call, then dial a number. During a call, press to receive an incoming call, if call waiting is activated.
Chan
3.
While on a call, press
4. Delete
Press to delete one or all calls in the call log. See page 20 for complete instructions.
5. Answer a Call
Press any key (except
6. Handset Volume
Adjust the volume while on a call. A double beep will sound
when you reach the maximum or minimum setting.
CID
• When phone is not in use, press information.
• When phone is not in use, press directory entries.
7. Select
Press to conrm the highlighted option while in programming mode.
8. Off
During a call, press to hang up. While in programming mode, press to cancel an operation, back up, or exit.
9. Redial/Pause
10. Press to enter programming mode.
and DIR keys
Press to view redial memory. While entering numbers, press and hold to insert a dialing pause.
PROG
CHAN to switch to a clearer channel.
(any key)
OFF) to answer a call.
/CID to display caller ID
/DIR to display
1,2
5
3,4
www.vtechphones.com
6
7 8
10
9
BASIC OPERATION
Basic Operation
9
Telephone Operation
Base Operation
1. Locate Handset
• Press the LOCATE HANDSET key to page the handset.
• Press it second time to cancel a page.
• Th e base will ring the h andset for one minute before en ding the page automatically.
• The handset can also cancel the page by pressing the OFF key.
BASIC OPERATION
10
www.vtechphones.com
Telephone Operation
Operating Range
Th is cordle ss teleph on e o pe rates wit hin t he maximu m po wer a llowed by the Federa l Communications Commission (FCC). Even so, this handset and base can communicate over only a certain distance — which can vary with the locations of the base and handset, the weather, and the
construction of your home or ofce.
If you receive a call while you are out of range, the handset might not ring or if it does ring, the call might not connect when you press TALK. Move closer to the base, then press TALK to answer the call.
If you move out of range during a phone conversation, you might hear noise or interference. To improve reception, move closer to the base.
If you move out of range without pressing OFF, your phone will be left off the hook. To hang up properly,
walk back into range, periodically pressing OFF.
Temporary Tone Dialing
If you have pulse (rotary) service, you can change from pulse dialing to touch tone dialing during a call by pressing * TONE. This is useful if you need to send touch tone signals for access to telephone banking or long distance services.
1. Dial the number.
2. Press
3. After you hang up, the phone automatically returns to pulse service.
Call Forward
An external call can be forwarded from one handset (HS1) to the other handset (HS2).
1. While on a call, press TRANSFERRED. HS2 will ring and show: TRANSFERRED CALL.
2. Press any key except OFF on HS2 to answer the forwarded call. HS1 will return to the idle screen.
TONE. Buttons pressed after this send touch tone signals.
*
SELECT on HS1 to forward the call to HS2. HS1 will display: CALL
• Only one handset of your phone system can be in use (off hook) at a time. For example, if HS1 is on a call and HS2 presses TALK, CAN’T CONNECT will display.
• For clearer reception while on a call, press the CHAN button until the interference has been eliminated.
• If HS2 cannot be found, HS1 will generate a sad tone and continue the call automatically. Before HS2 answers, HS1 can
press
TALK to cancel the forward function and continue the external call.
• If HS2 does not respond to a forwarded call within 30 seconds, HS1
will ring until pressed to pick up the call. If HS1 doesn’t answer within another 30 seconds, the call will end automatically.
TALK is
Basic Operation
www.vtechphones.com
BASIC OPERATION
11
Telephone Operation
Display Screen Messages
Screen Displays: When:
** RINGING **
CONNECTING...
PHONE ON
CHARGING
** PAGING **
BATTERY LOW
SCANNING...
CAN’T CONNECT
RINGER OFF
There is a call coming in.
The handset is waiting for dial tone.
The handset is in use.
The handset is in the base and the battery is charging.
The base is paging the handset.
The battery needs to be recharged.
The handset is changing to another of the 30 channels available.
Displays and a sad tone sounds when the base power is off and TALK is pressed.
The handset ringer is turned off.
BASIC OPERATION
12
www.vtechphones.com
Speed Dialing
You can store telephone numbers you call frequently in two different ways, as speed dial numbers, or in the directory. Each number can have up to 24 digits. You will program names to go with the numbers, each can have up to 15 characters.
Up to ten numbers and names can be stored, total. You can store as many as nine numbers with names into speed dial memory locations you assign (1 through 9). You can also store numbers with names alphabetically in the directory. See Telephone Directory for instructions.
Store a Number/Name in Speed Dial
1. Press PROG on the handset.
2. Press
3. Press SELECT The screen displays ENTER 1-9.
4. Press the key (1 through 9) for the memor y location where you want to store this entry. The screen displays ENTER NAME.
5. Using the chart on the next page, enter up to 15 characters for the name you’re storing with the number. Use
6. When you nish entering the name, press SELECT. The screen displays ENTER NUMBER.
7. Enter the telephone number using the number keys. Use After at least one digit has been entered, press REDIAL/PAUSE to store pauses in the dialing sequence, if necessary. Press REDIAL /PAUSE to display the last number dialed.
8. Press SE LEC T to store your entr y. The scre en displays DISTINCT RI NG? an d the current setting.
9. Press or
calls from this number by changing to a distinctive ringing pattern after the rst ring. Choose
N for a normal ringing pattern.
10. Press SELECT to conrm your selection. If you chose Y, a D will be displayed with the
director y entry.
until the screen displays SPEED DIAL.
or
to backspace and make corrections; use
to change the setting. Choose Y (for yes) if you wish the phone to alert you to
to advance and add a space.
to backspace and make corrections.
• The entries you stored in speed dial memory will be marked with 01 through 09 in the telephone directory.
• Each handset’s speed dial entries are independent from the other. For example, a speed dial entry stored in HS1 cannot be accessed/dialed by HS2.
OFF at
• Press any time to exit memory mode.
Basic Operation
www.vtechphones.com
BASIC OPERATION
13
Speed Dialing
• When directory memory is full the screen displays
MEMORY FULL,
an error tone sounds, and you cannot store a new number until you delete a record in speed dial memory or the directory.
• If the speed dial location is not empty, your new entry will be stored in place of the old and the
rst entry will be
deleted. Take caution to not save over entries you do not wish to delete from memory.
BASIC OPERATION
14
Press Once Twice 3 Times 4 Times 5 Times 6 Times
1 2 3 4 5 6 7 8 9 0
*
#
1
A B C 2
D E F 3
G H I 4
J K L 5
M N O 6
P Q R S 7
T U V 8
W X Y Z 9
0
*
& , - . #
www.vtechphones.com
Speed Dialing
Edit a Number/Name in Speed Dial
1. Press and hold the memory location key (1 through 9) of the entry you wish to edit.
2. When the screen displays the entry you want to edit, press SELECT. Then press or
3. Press
SELECT. The screen displays the name and number. The
cursor appears at the end of the name. Use
SELECT to move on to edit the number. Use to backspace and make corrections. Press
SELECT to move to edit the distinctive ring setting. Press SELECT to save.
until EDIT ashes.
and the dial pad keys to edit the name. Press
,
Delete a Number/Name in Speed Dial
1. Press and hold the memory location key (1 through 9) of the entry you wish to delete.
2. When the screen displays the entry you want to delete, press SELECT. Then press or
3. Press
4. Press or
5. Press
SELECT, the screen displays:
SELECT. You’ll hear a conrmation beep.
until YES ashes.
until ERASE ashes.
Dial a Speed Dial Number
Press and hold the memory location key (1 through 9) of the entry you wish to dial.
Press TALK to dial the displayed memory number.
Reassign Locations in Speed Dial
1. Press and hold the memory location key (1 through 9) of the
entry you wish to reassign.
2. When the screen displays the entry you want to reassign, press SELECT. Then press until SPEED ashes.
3. Press
4. Press the keys (1 through 9) to reassign this entry into another memory location.
SELECT. The screen displays ENTER 1-9.
www.vtechphones.com
SPEED EDIT ERASE
8005959511 01
SPEED EDIT ERASE
8005959511 01
SPEED EDIT ERASE
8005959511 01
BASIC OPERATION
Basic Operation
15
• Press REDIAL/ PAUSE to display
the last number dialed from this phone to store it in speed dial memory.
• Each handset’s
speed dial entries are independent from the other. For example, a speed dial entry stored in HS1 cannot be accessed/dialed by HS2.
Telephone Directory
Your phone can store 10 (including the nine speed dial entries) numbers with names (up to 15 characters for the name and 24 digits for the number) in each handset.
When memory is full the screen displays MEMORY FULL, an error tone sounds, and you will not be able to store a new number until you delete a stored number.
Store a Number/Name in the Directory
1. Press PROG. The screen displays DIRECTORY.
2. Press SELECT. The screen displays ENTER NAME.
3. Using the chart on page 14, enter up to 15 characters for the name you’re storing with the number. Use
to backspace and make corrections; use or
4. When you nish entering the name, press SELECT. The screen displays ENTER NUMBER.
5. Enter the telephone number. Use to backspace and make corrections. Press REDIAL/PAUSE to store a pause in the dialing sequence.
-OR- Press REDIAL/PAUSE if you wish to display and then store the last number dialed.
6. Press SELECT. The screen displays DISTINCT RING? and the current setting.
7. Press or to calls from this number by changing to a distinctive ringing pattern after the rst ring. Choose N for a normal ringing pattern.
8. Press SELECT to conrm your selection. If you chose Y, a D will be displayed with the directory entry.
to change the setting. Choose Y (for yes) if you wish the phone to alert you
to advance and add a space.
BASIC OPERATION
16
www.vtechphones.com
Telephone Directory
Edit a Number/Name in the Directory
1. Press
2. Press
-OR-
Press the dial pad key for the rst letter of the entr y you want to edit.
3. When the screen displays the entry you want to edit, press SELECT. Then press or
4. Press SELECT. The screen displays the name and number. The cursor appears at the end of the name. Use pad keys to edit the name. Press SELECT to move on to edit the number. Use distinctive ring setting. Use the and keys to change the setting.”
5. Press SELECT to save the edited information.
Delete a Number/Name in the Directory
1. Press
2. Press or
-OR-
Press the dial pad key for the rst letter of the entr y you want to
delete.
3. When the screen displays the entry you want to delete, press SELECT. Then press or
4. Press SELECT. The screen displays ERASE NO YES and the number.
The current choice ashes.
5. Press
6. Press SELECT. You’ll hear a conrmation beep.
(DIR). The screen displays DIRECTORY.
to scroll alphabetically through the entries stored in the directory.
or
until EDIT ashes.
and the dial
,
to back space and make corrections. Press SELECT to move on to edit the
(DIR). The screen displays DIRECTORY.
to scroll alphabetically through entries in the directory.
until ERASE ashes.
until YES ashes.
or
SPEED EDIT ERASE
8005959511
SPEED EDIT ERASE
8005959511
Press OFF at
any time to exit directory
Basic Operation
www.vtechphones.com
BASIC OPERATION
17
• Press OFF at any time to exit direc­tory.
Telephone Directory
Dial a Number from the Directory
1. Press
2. Press or
-OR-
Press the dial pad key for the rst letter of the entr y you want to dial.
3. When the number you want to dial is displayed, press TALK.
Move a Number/Name to the Memory
1. Press
2. Press or
-OR-
Press the dial pad key for the rst letter of the entr y you want to move.
3. When the screen displays the entry you want to move, press SELECT. Then press or
4. Press
5. Press the key (1 through 9) to move this entry from the normal directory to the speed dial memory
and assign the memor y location. You’ll hear a conrmation beep. A memory location number
(01 through 09) will be displayed with this entry.
(DIR). The screen displays DIRECTORY.
to scroll alphabetically through entries stored in directory.
(DIR). The screen displays DIRECTORY.
to scroll alphabetically through directory.
until SPEED ashes.
SELECT. The screen displays ENTER 1-9.
SPEED EDIT ERASE
8005959511
BASIC OPERATION
18
www.vtechphones.com
Caller ID Operation
Your phone has a caller ID (CID) with call waiting feature that works with service from your local phone service provider. Caller ID with call waiting lets you see who’s calling before you answer the phone, even when you’re on another call.
You may need to change your phone service to use this feature. Contact your service provider if:
• You have both caller ID and call waiting, but as separate services (you may need combined service)
• You have only caller ID service, or only caller waiting service.
• You don’t subscribe to any caller ID or call waiting services.
You can use this product with regular caller ID service, and you can use this product’s other features without subscribing to either caller ID or combined caller ID with call waiting service.
There are fees for caller ID services, and they may not be available in all areas.
This product can provide information only if both you and the caller are in areas offering caller ID service, and if both telephone companies use compatible equipment.
Caller’s name
Party has called
NEW
OLD
*
2 or more times Caller’s telephone number
Long distance call
VTech L 800-595-9511 5/01 5:40 28
Date of call Time of call Position in call history
AM
PM
Basic Operation
www.vtechphones.com
BASIC OPERATION
19
• If you answer a call before the caller ID information appears on the screen, it will not be in the call history.
• Each handset’s call log is independent from the other handset. For example, when you delete one or all call log entries in one handset, they will not be deleted from the other handset.
Caller ID Operation
About Call History (Caller ID)
Your phone can store up to 30 calls in its caller ID memory. The most recent call will have the highest number. When the memory is full, the oldest call will be deleted to make room for new incoming call information. For each call that comes in, the screen displays the following information between the
rst and second rings:
• Your caller’s name (15 letters are sent by your telephone company).
• The caller’s area code and telephone number.
• The time and date of the call.
• The repeat tag (*) in the upper right corner, indicating the party has called more than once.
Review Call History
1. Press (CID) to view call histor y.
2. Use and
Delete Records from Call History
Delete a Specic Call:
1. Locate the record you want to delete from call history.
2. Press DELETE. You’ll hear a conrmation beep.
Delete All Calls:
1. With the handset in idle (off) mode, press and hold DELETE. The screen displays ERASE ALL
NO YES. The current choice ashes.
2. Press
3. Press SELECT. You’ll hear a conrmation beep.
to scroll through records in call history.
until YES ashes.
BASIC OPERATION
20
www.vtechphones.com
Caller ID Operation
Dial a Displayed Number
1. Locate the record in call history that you want to dial.
2. If you wish to change how the number is dialed, press #. The screen displays alternate dialing sequences available for this call.
3. Press SELECT. Press or
4. Press SELECT again. The number is automatically dialed.
-OR-
When the number is correctly displayed for dialing, press TALK.
Store a Call History Record in the Directory
1. Locate the record in the call history you want to store in the directory.
2. If you wish to change how the number is stored, press #. The screen displays alternate dialing sequences available for this call.
3. Press SELECT, then press or
4. Press SELECT three times. The screen displays:
5. Press
6. Press SELECT. You’ll hear a conrmation beep. If you choose Y in step 5 a D will be displayed with the directory entry.
to select Y or N for distinctive ringer.
or
Screen Displays: When:
PRIVATE
UNKNOWN
* (after name)
until DIAL ashes.
until PROGRAM ashes.
The other party is blocking name and/or number information.
Your phone company is unable to receive information about this caller’s name and/or number.
This caller has called you more than once.
595-9511 5/01 5:40PMOLD28
DIAL PROGRAM
800-595-9511
5/01 5:40PM OLD28
DIAL PROGRAM
800-595-9511
5/01 5:40PM OLD28
DISTINCT RING? N 800-595-9511
• Press OFF at any time to exit call history.
Basic Operation
www.vtechphones.com
BASIC OPERATION
21
If you repeate dly get a
“CLICK”
low battery indicator, even after chargi ng overnight, th e ba tt er y should be replaced.
• To reduce the risk of re
or injury to persons or damage to the telephone, charge the battery provided
with or identied for use
with this product only in accordance with the instructions and limitations
specied in the user’s
manual.
• Battery power is consumed whenever the handset is off the base unit or charger, even when the handset is not in use. The longer you leave the handset off the . base unit or charger, the shorter you can actually talk on the handset. Actual battery performance depends on a combination of how often the handset is in use and how often it is not in use.
• Onc e th e bat tery is ful ly charged, you do not have to charge it again until BATTERY LOW is displayed or ashes. This will maximize the battery life.
22
Batteries
Battery Care and Maintenance
After your battery is fully charged, you can expect the following performance:
Operation Operating time
While in use (talking) up to 4 hours
While not in use (standby*) up to 4 days
* Handset is off the base unit or charger but not in use.
• The battery needs charging when: — A new battery is installed in the handset.
— The phone beeps twice every ve seconds.
— The screen displays
• Place the handset in the base. The battery is typically fully charged at least 16 hours.
• You can keep the battery fully charged by returning the handset to the base after each use.
Replacing the Handset Battery
1. Remove the battery compartment cover on the handset by pressing
2. Lift out the old battery and disconnect.
3. Align the two holes in the new battery’s plug with the socket pins,
4. Replace the cover by sliding it up into place.
5. The new battery must be charged before using the phone. Place the
BASIC OPERATION
BATTERY LOW and the low battery icon.
on the indentation and sliding the cover downward.
and snap the plug into place. Snap the battery in the compartment, as described in Installation, on page 4.
handset in the base and allow it to charge for at least 16 hours the
rst charge. The telephone might operate before that, but for best
performance, let the battery charge fully.
www.vtechphones.com
Troubleshooting
If you have difculty operating your phone, the suggestions below should solve the problem. If you still have difculty after
trying these suggestions, call VTech Communications at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377.
Problem Suggestion
My phone doesn’t work at all.
I cannot get a dial tone.
• Make sure the power cord is plugged in.
• Make sure the telephone line cord is plugged rmly into the base unit and the telephone wall
jack.
• Charge the battery in the handset at least 16 hours. For optimum daily performance, return the handset to its base when not in use.
• Reset the base. Unplug the unit’s electrical power. Wait for over 15 seconds then plug it back in. Allow up to one minute for the handset and base to reset.
• You may need to purchase a new battery, please refer to the Batteries section of this user’s manual.
• First try all the suggestions above.
• Move the handset closer to the base. You might have moved out of range.
• Your line cord might be malfunctioning. Try installing a new line cord.
• If the previous suggestions don’t work, disconnect the base unit from the telephone jack and connect a different phone. If there is no dial tone on that phone either, the problem is in your wiring or local service. Contact your local telephone company.
Additional Information
www.vtechphones.com
ADDITIONAL INFO
23
Troubleshooting
Problem Suggestion
I cannot dial out. • Make sure you have a dial tone before dialing. The handset may take a second or two to nd the
My hand s e t b e eps fo ur time s and isn ’t performing normally.
ADDITIONAL INFO
24
base and produce a dial tone. This is normal. Wait an extra second before dialing.
• Make sure your phone is set to the correct dial mode for the type of service that you have (pulse or touchtone). Refer to the Installation section of this user’s manual to set the dial mode.
• If the other phones in your home are having the issue, the problem is in your wiring or local service. Contact your local telephone company (charges may apply.)
• Eliminate any background noise. Noise from a television, radio or other appliance may cause the
phone to not dial out properly. If you cannot eliminate the background noise, rst try muting the
handset before dialing, or dialing from another room in your home with less background noise.
• Make sure the power cord is securely plugged into the base. Plug the unit into a different, working outlet not controlled by a wall switch.
• Move the handset closer to the base. You might have moved out of range.
• Reset the base. Unplug the unit’s electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the handset and base to reset.
• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: wireless routers, radios, radio towers, pager towers, cell phones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless phones.
www.vtechphones.com
Troubleshooting
Problem Suggestion
CAN’T CONNECT
displays on my handset.
The batteries will not hold a charge.
• Only one handset of your phone system can be in use (off hook) at a time. For example, if HS1 is on a call and HS2 presses TALK, CAN’T CONNECT will display. Be sure only one handset is in use at a time.
• Move the handset closer to the base. You might have moved out of range.
• Reset the base. Unplug the unit’s electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the handset and base to reset.
• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: wireless routers, radios, radio towers, pager towers, cell phones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless phones.
• You are trying to use both system handsets at the same time. Be sure to only use one system handset at a time.
• Make sure the battery is plugged into the handset.
• Be sure to use the AC power adaptor provided with your phone.
• Charge the battery in the handset at least 16 hours. For optimum daily performance, return the handset to its base when not in use.
• You may need to purchase a new battery, please refer to the Batteries section of this user’s manual.
• Your phone might be malfunctioning. Please refer to the Warranty section of this user’s manual for further instruction.
Additional Information
www.vtechphones.com
ADDITIONAL INFO
25
Troubleshooting
Problem Suggestion
I get noise, static, or weak signal even when I’m near the base.
I hear noi se i n th e handset, and none of th e k ey s o r b ut tons work.
• Press the CHAN button while on a call until the interference has been eliminated.
• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: wireless routers, radios, radio towers, pager towers, cell phones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless phones.
• Microwaves operate on the same frequency as your phone. It is normal to experience static on your phone while the microwave is running. Do not install this phone in the same outlet or near the microwave.
• If your phone is plugged in with a modem or surge protector, plug the phone (or modem/surge protector) into a different location. If this solves the problem, re-locate your phone or modem farther apart from one another, or use a different surge protector.
• Relocate your phone to a higher location. The phone will likely get better reception not installed in a low area.
• If the other phones in your home are having the issue, the problem is in your wiring or local service. Contact your local telephone company (charges may apply.)
• Make sure the power cord is plugged in.
ADDITIONAL INFO
26
www.vtechphones.com
Troubleshooting
Problem Suggestion
I hear other calls while using my phone
• Disconnect your base unit from the telephone jack, and plug in a regular telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company.
My handset does not ring when I receive a call.
• Make sure you have the ringer activated. Refer to the section(s) on ringer selection in this user’s manual.
• Make sure the telephone line cord is plugged rmly into the base unit and the telephone jack.
Make sure the power cord is plugged in.
• You may be too far from the base unit.
• Charge the battery in the handset at least 16 hours. For optimum daily performance, return the handset to its base when not in use.
• You may have too many extension phones on your telephone line to allow all of them to ring. Try unplugging some of the other phones.
• The layout of your home or ofce might be limiting the operating range. Try moving the base to another location, preferably on an upper oor.
• If the other phones in your home are having the issue, the problem is in your wiring or local service. Contact your local telephone company (charges may apply.)
• Test a working phone at the phone jack. If another phone has the same problem, the problem is the phone jack. Contact your local telephone company (charges may apply.)
• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: wireless routers, radios, radio towers, pager towers, cell phones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless phones.
• Your line cord might be malfunctioning. Try installing a new line cord.
www.vtechphones.com
ADDITIONAL INFO
Additional Information
27
Troubleshooting
Problem Suggestion
My calls fade or cut in and out while I’m using my handset.
My Caller ID isn’t working.
• Press the CHAN button while on a call until the interference has been eliminated.
• Other electronic products can cause interference with your cordless phone. Try installing your phone as far away from these types of electronic devices as possible: wireless routers, radios, radio towers, pager towers, cell phones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless phones.
• Microwaves operate on the same frequency as your phone. It is normal to experience static on your phone while the microwave is running. Do not install this phone in the same outlet or near the microwave.
• If your phone is plugged in with a modem or surge protector, plug the phone (or modem/surge protector) into a different location. If this solves the problem, re-locate your phone or modem farther apart from one another, or use a different surge protector.
• Relocate your phone to a higher location. The phone will get better reception not installed in a low area.
• If the other phones in your home are having the issue, the problem is in your wiring or local service. Contact your local telephone company (charges may apply.)
• Caller ID is a subscription service. You must subscribe to this service for this feature to work on your phone.
• Your caller must be calling from an area that supports caller ID.
• Both you and your caller’s telephone companies must use caller ID compatible equipment.
ADDITIONAL INFO
28
www.vtechphones.com
Troubleshooting
Problem Suggestion
Common cure for electronic equipment.
If the unit does not seem to be responding normally, then try putting the handset in its base. If it does not seem to respond, do the following (in the order listed):
1. Disconnect the power to the base.
2. Disconnect the handset battery, and spare battery, if applicable.
3. Wait a few minutes.
4. Connect power to the base.
5. Re-install the battery(ies).
6. Wait for the handset to re-establish its link with the base. To be safe, allow up to one minute for this to take place.
If you subscribe to DSL service:
If you hear noise during conversations and/or your caller ID features aren’t functioning properly, install a noise
lter to the telephone line between the base unit and the
telephone line jack. Contact your DSL provider to obtain
a noise lter.
To single telephone jack (RJ11C)
Telephone line cord
Noise lter
(For xDSL users)
Additional Information
www.vtechphones.com
ADDITIONAL INFO
29
Maintenance
Taking care of your telephone
Your cordless telephone contains sophisticated electronic parts, so it must be treated with care.
Avoid rough treatment
Place the handset down gently. Save the original packing materials to protect your telephone if you ever need to ship it.
Avoid water
Your telephone can be damaged if it gets wet. Do not use the handset outdoors in the rain, or handle it with wet hands. Do not install your base unit near a sink, bathtub or shower.
Electrical storms
Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own safety, use caution when using electric appliances during storms.
Cleaning your telephone
Your telephone has a durable plastic casing that should retain its luster for many years. Clean it only with a soft cloth slightly dampened with water or a mild soap. Do not use excess water or cleaning solvents of any kind.
Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If your base unit should fall into water, DO NOT RETRIEVE IT
UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the unit out by the unplugged cords.
Warranty Statement
What does this limited warranty cover?
• The manufacture r of this VTech product, VTech C ommunicat ions, warrants to the holder of a valid p roof of purchase (“Consum er” or “ you”) t hat t he p roduct and a ll access ories provid ed by VTech in the sales pack age (“Produc t”) are free from materi al defects in materia l and workmanship, pur suant to the following term s and condition s, when in stalled an d used norm ally and in accordan ce with op eration in structio ns. This li mited warra nty exten ds only to t he Consume r for Produc ts purcha sed and us ed in the Unite d States of Ame rica.
What will VTech Communications do if the Product is not free from material defects in materials and workmanship during the limited warranty period (“Materially Defective Product”)?
• Durin g the limited warranty period, V Tech’s aut horized service representat ive will repair or replace at VTech’s option, without charge, a Materiall y Defec tive Prod uct. If we repair this produ ct, we may use new or refurb ished repl acement pa rts. If we c hoose to rep lace this p roduct, we may replace i t with a new or refurbish ed produc t of the same or sim ilar design. V Tech will return re paired or repl acement pro ducts to you in wor king cond ition. VTech wil l retain defec tive parts , modules, or eq uipment. Re pair or replac ement of Produ ct, at VTech’s opti on, is your exclu sive remedy. You shou ld expect the r epair or repl acement to ta ke approximate ly 30 days.
How long is the limited warranty period?
• The limit ed warranty peri od for the product exten ds for ONE (1) YEAR from the date of purcha se if we repair or replace a Materiall y Defective Produ ct under the terms of this limited war ranty. This limi ted warrant y also applies to re paired or repla cement Produ cts for a period of ei ther (a) 90 days from the dat e the repaired or rep lacement Pro duct is shipp ed to you or (b) the tim e remaining o n the origina l one-year war ranty; whi chever is long er.
What is not covered by this limited warranty?
This limited warranty does not cover
ADDITIONAL INFO
30
www.vtechphones.com
Warranty Statement
1. P roduct th at has been subjecte d to misuse, accident , shipping or other ph ysical dam age, impro per instal lation, ab normal op eration or h andling, n eglect, inundatio n, re,
water or othe r liquid intr usion; or
2. Prod uct that has be en damaged du e to repair, altera tion or modi cation by anyo ne other than a n authorized s ervice re presentat ive of VTech; or
3. Produ ct to the exten t that the prob lem experien ced is cause d by signal co nditions, n etwork reli ability or c able or anten na systems; or
4. Produc t to the extent th at the proble m is caused by us e with non-V Tech electric al access ories; or
5. Produ ct whose warr anty/quali ty sticker s, Product se rial number s plates or ele ctronic se rial number s have been remov ed, altered or r endered ill egible; or
6. Produ ct purch ased, u sed, ser viced, or ship ped for repair from out side th e United States, or used for commercial or inst itutional purposes (i ncluding but not li mited to Produc ts used for ren tal purpos es ); or
7. Produc t returned wit hout valid pr oof of purcha se (see 2 below); or
8. Charges fo r installati on or set up, adju stment of cus tomer contr ols, and inst allation or r epair of system s outside th e unit.
How do you get warranty service?
• To obtain warranty ser vice in the United States of America, call 1-800 -595-9 511 for i nstructi ons regar ding whe re to ret urn the Product. Before c alling fo r servi ce, pleas e
check t he user’s manu al. A check of th e Product co ntrols and fe atures may save you a s ervice ca ll.
• Excep t as provided by appli cable law, you assum e the risk of loss or damage du ring transit an d transpor tation and are resp onsible for del ivery or handli ng charges incu rred
in the tr ansport of Product (s) to the servi ce locati on. VTech will return repa ired or repl aced prod uct under t his limite d warranty to you, trans portatio n, deliver y or handli ng charge s prepaid. V Tech assumes no ri sk for damage o r loss of the Pro duct in tran sit.
• If t he Produ ct failu re is n ot covered by this li mited war ranty, or proof o f purcha se does not meet t he terms of this lim ited warr anty, VTech will notify you and wi ll reque st
that you authorize the cost o f repair pr ior to any f urther r epair acti vity. You must p ay for the cost of re pair and r eturn ship ping cost s for the r epair of Pro ducts th at are not covered by t his limited wa rranty.
What must you return with the Product to get warranty service?
1. R eturn the ent ire origina l package and c ontents inc luding the Pr oduct to the V Tech serv ice locati on along with a d escripti on of the malfu nction or di fcult y;
2. Incl ude “valid p roof of purch ase” (sales re ceipt) ident ifying th e Product pur chased (Pro duct mode l) and the date of p urchase or re ceipt; and
3. Provid e your name, com plete and cor rect mailin g address, an d telephone n umber.
Other Limitations
• This warranty is the complete and exclusive agreement between you and VTech. It supersedes all other written or oral communications related to this Product. VTech provides
no other warranties for this product. The warranty exclusively describes all of VTech’s responsibilities regarding the product. There are no other express warranties. No one is
authorized to make modications to this limited warranty and you should not rely on any such modication.
State Law Rights: This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
Limitations:
Implied warranties, including those of tness for a particular purpose and merchantability (an unwritten warranty that the product is t for ordinary use) are limited to
one year from date of purchase. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
• In
no event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost prots or revenue, inability to use the
product, or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
Additional Information
www.vtechphones.com
ADDITIONAL INFO
31
Important Safety Instructions
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of re, electric shock and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink or swimming pool).
5. Do not place this product on an unstable surface, such as a table, shelf or stand. The product may fall, causing serious damage.
6. Slots and openings in the back or bottom of the base unit and handset are provided for ventilation . To prote ct th em from overhea ting, thes e ope nings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not install this product where the cord may have anyone walking on it.
9. Never push objects of any kind into this product through slots in the base or handset as they may touch dangerous voltage points or short out parts that could result
in a risk of re or electric shock. Never spill liquid of any kind on the product.
10. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the base or handset
other than specied access doors may expose you to dangerous voltages or other risk s. I ncor rect rea ssem bling can cau se e lect ric shoc k wh en the
pro duct is subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk of re or electric shock.
12. Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled onto the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions,
as improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product
to normal operation. E. If the product has been dropped and the base and/or handset has been damaged. F. If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
15. Only put t he handset of your telephone next to your ear when it is in normal talk.
FCC, ACTA and IC Regulations
FCC Part 15
This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep­tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
ADDITIONAL INFO
32
www.vtechphones.com
FCC, ACTA and IC Regulations
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The base unit shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more. If you choose to use a clipping device, please make sure to only use the supplied VTech belt clip.
FCC Part 68 and ACTA
This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The
label on the back or bottom of this equipment contains, among other things, a product identier in the format US:AAAEQ##TXXXX. This identier must be provided to
your local telephone company upon request.
The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.
The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called.
The REN for this product is encoded as the 6th and 7th characters following the US: in the product identier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be ve (5.0) or less. For more information, please contact your local telephone company.
This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this
equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualied
installer.
If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty.
If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is
required to notify you before interrupting service. If advance notice is not practical, you will be notied as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to le a complaint with the FCC. Your telephone company may make changes in its
facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned.
Additional Information
www.vtechphones.com
ADDITIONAL INFO
33
FCC, ACTA and IC Regulations
If this product is equipped with a corded or cordless handset, it is hearing aid compatible.
If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, re, medical) in these locations. If you do store or
test emergency numbers, please:
• Remain on the line and briey explain the reason for the call before hanging up.
• Perform such activities in off-peak hours, such as early morning or late evening.
Industry Canada
This equipment complies with regulations RSS210 and CS-03 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
The term “IC:” before the certication/registration number only signies that the Industry Canada technical specications were met.
The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the
devices does not exceed ve.
ADDITIONAL INFO
34
www.vtechphones.com
The RBRC®Seal
The RBRC® Seal
The RBRC® Seal on the nickel-cadmium battery indicates that VTech Communications, Inc. is voluntarily participating in an industry program to collect and recycle these batteries at the end of their useful lives, when taken out of service within the United States and Canada.
The RBRC® program provides a convenient alternative to placing used nickel-cadmium batteries into the trash or municipal waste, which may be illegal in
your area. VTech’s participation in RBRC® makes it easy for you to drop off the spent battery at local retailers participating in the RBRC® program or at authorized VTech product service centers. Please call 1-800-8-BATTERY™ for information on Ni-Cd battery recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources.
RBRC® is a registered trademark of Rechargeable Battery Recycling Corporation.
Additional Information
www.vtechphones.com
ADDITIONAL INFO
35
Technical Specications
Enhanced 2.4GHz technology–your phone operates on a dual band transmission that combines the best of 2.4GHz and 900MHz technologies, providing enhanced performance over standard cordless telephones.
Frequency Control Crystal controlled
Transmit Frequency Base: 2410.2–2418.9 MHz
Receive Frequency Base: 912.75–917.10 MHz
Channels 30
Nominal Effective Range Maximum power allowed by FCC and IC. Actual operating range may
Size Handset: 185.5mm X 53.4mm X 39.0mm
Weight Handset: 116 grams
Power Requirements Handset: 3.6V 300mAH Ni-Cd Battery
Memory Speed Dial: 9 Memory locations, 24 digits per location
ADDITIONAL INFO
36
PLL synthesizer
Handset: 912.75–917.10 MHz
Handset: 2410.2–2418.9 MHz
vary according to environmental conditions at the time of use.
Base: 88.8mm X 107.5mm X 122.7mm Charger: 76.0mm X 81.0mm X54.4mm
Base: 133.2 grams Charger: 41.2 grams
Base: 9V AC @ 250mA Charger: 6V DC @ 200mA
Directory: 10 Memory locations, 24 digits per location CID: 30 Memory locations
www.vtechphones.com
Index
A
About Call History (Caller ID) 20
B
Base Operation 10 Batteries 22 Battery Care 22 Before You Begin 3
C
Call forward 11 Caller ID Operation 19 Check for Dial Tone 7 Charge the Handset Battery 7
D
Delete a Number/Name 15, 17 Delete Records from Call History 20 Dial a Displayed Number 21 Dial a Number from the Directory 18 Dial a Speed Dial Number 15 Display Screen Messages 12
E
Edit a Number/Name 15, 17
F
FCC, ACTA and IC Regulations 32
G
GETTING STARTED 3
H
Handset Operation 9
I
Important Safety Instructions 32 Installation 4 Install Handset Battery 4
L
Locate Handset 10
M
Move a Number/Name 18 Make a Call 9 Modular telephone jack 5
O
Off 9 Operating Range 11
P
Page (Locate Handset) 10 Parts Checklist 3 Program (PROG) 9
R
RBRC 34 Reassign Locations 15
Review Call History 20 Replacing the Handset Battery 22
S
Set Language 7 Set the Dial Mode 7 Set Handset Date and Time 8 Speed Dialing 13-15 Store a CID Record 21 Store a Number/Name 13, 16
T
Telephone Directory 16–18 Telephone Operation 9-12 Troubleshooting 23-29
W
Wall Mounting 6 Warranty 30–31
www.vtechphones.com
INDEX
37
VTECH TELECOMMUNICATIONS LTD.
A member of THE VTECH GROUP OF COMPANIES.
Distributed in the U.S.A. by VTech Communications, Inc. Beaverton, Oregon
Distributed in Canada by VTech Telecommunications Canada, Ltd., Richmond, B.C.
Copyright ©2005 for VTECH TELECOMMUNICATIONS LTD.
Printed in China.
91-000439-040-000
Model: t2340
User’s Manual
w w w . v t e c h p h o n e s . c o m
Loading...
