VTech CTM-A242SD User Manual

A n a l o g C o n t e m p o r a r y S e r i e s Master User Guide

Models: Analog corded lobby hotel telephone - A2100, Analog corded 1-line hotel telephone - A2210, Analog corded 2-line hotel telephone - A2220, Analog corded trimstyle hotel telephone - A2310, Analog cordless 1-line hotel telephone - A2410/CTM-A2411/CTM-A2411-BATT, Analog cordless 2-line hotel telephone - A2420/CTM-A2421/CTM-A2421-BATT, Analog corded/cordless 1-line hotel telephone - CTM-A2510, Analog cordless charging base - C4000/C4001, Analog cordless charging stand - C4010/C4011, Analog cordless 1-line accessory handset - C4100/CTM-C4101, Analog cordless 2-line accessory handset - C4200/CTM-C4201, Analog cordless 1-line accessory PetiteTM - CTM-A241P, Analog cordless 2-line accessory PetiteTM - CTM-A242P, Analog cordless 1-line accessory handset and charger bundle - CTM-A241HS, Analog cordless 2-line accessory handset and charger bundle - CTM-A242HS, Analog cordless 1-line accessory handset with speed dials and charger bundle

- CTM-A241SD, and

Analog cordless 2-line accessory handset with speed dials and charger bundle

- CTM-A242SD

Important safety instructions

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of re, electric shock

and injury, including the following:

This product should be installed by a qualied technician.

This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone

Network (PSTN) or Plain Old Telephone Services (POTS).

Read and understand all instructions.

Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or swimming pool, or in a wet

6. basement or shower.

Do not place this product on an unstable table, shelf, stand or other unstable surfaces.

Slots and openings in the back or bottom of the telephone base and handset are provided for ventilation. To protect them from

overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided.

This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the

type of power supply on the premises, consult your dealer or local power company.

Do not allow anything to rest on the power cord. Do not install this product where the cord may be walked on.

10.

Never push objects of any kind into this product through the slots in the telephone base or handset because they may touch

11. dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product.

To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or

12. removing parts of the telephone base or handset other than specied access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.

Do not overload wall outlets and extension cords.

13.

Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions:

14.

When the power supply cord or plug is damaged or frayed.

•

If liquid has been spilled onto the product.

•

If the product has been exposed to rain or water.

•

If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by

•

the operation instructions. Improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation.

If the product has been dropped and the telephone base and/or handset has been damaged.

•

If the product exhibits a distinct change in performance.

•

Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning.

15.

Do not use the telephone to report a gas leak in the vicinity of the leak. Under certain circumstances, a spark may be created

16. when the adapter is plugged into the power outlet, or when the handset is replaced in its cradle. This is a common event associated with the closing of any electrical circuit. The user should not plug the phone into a power outlet, and should not put a charged handset into the cradle, if the phone is located in an environment containing concentrations of ammable or amesupporting gases, unless there is adequate ventilation. A spark in such an environment could create a re or explosion. Such environments might include: medical use of oxygen without adequate ventilation; industrial gases (cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc.

Only put the handset of your telephone next to your ear when it is in normal talk mode.

17.

The power adapters are intended to be correctly oriented in a vertical or oor mount position. The prongs are not designed to

18. hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.

Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a re. They may explode. Check

19. with local codes for possible special disposal instructions.

In wall mounting position, make sure to mount the telephone base on the wall by aligning the eyelets with the mounting studs of

20. the wall plate. Then slide the telephone base down on both mounting studs until it locks into place. Refer to the full instructions

in Installation in the user’s manual.

CAUTION: Keep small metallic objects such as pins and staples away from the handset receiver.

21.

CAUTION: There may be a risk of explosion if a wrong type of handset battery is used (A2410, A2420, C4100, C4200,

22.

CTM-A241HS, CTM-A241SD, CTM-A242HS, CTM-A242SD, CTM-A2411, CTM-A2411-BATT, CTM-A2421, CTM-A2421-BATT, CTM-A2510, CTM-C4101 and CTM-C4201). Use only the supplied rechargeable battery (BT264392/BT266342) or replacement battery (BT266342). Dispose of used batteries according to the information in The RBRC® seal in the user’s manual.

SAVE THESE INSTRUCTIONS

Table of contents

Parts checklist ..............................................................................................................................1

Telephone layout ..........................................................................................................................4

Analog corded lobby - A2100 .........................................................................................................4

Analog corded 1-line - A2210 .........................................................................................................5

Analog corded 2-line - A2220 .........................................................................................................6

Analog corded trimstyle - A2310 ....................................................................................................7

Analog cordless 1-line - A2410 .......................................................................................................8

Analog cordless 1-line - CTM-A2411/CTM-A2411-BATT ................................................................9

Analog cordless 1-line accessory Petite - CTM-A241P ...............................................................10

Analog cordless 2-line - A2420 ..................................................................................................... 11

Analog cordless 2-line - CTM-A2421/CTM-A2421-BATT ............................................................12

Analog cordless 2-line accessory Petite - CTM-A242P ...............................................................13

Analog corded/cordless 1-line - CTM-A2510 ...............................................................................14

Analog cordless charging base - C4000/C4001 ..........................................................................15

Analog cordless charging stand - C4010/C4011 ..........................................................................16

Analog cordless 1-line accessory handset - C4100 .....................................................................17

Analog cordless 1-line accessory handset - CTM-C4101 ............................................................18

Analog cordless 1-line accessory handset and charger bundle - CTM-A241HS ........................19

Analog cordless 1-line accessory handset with speed dials and charger bundle - CTM-A241SD ....20

Analog cordless 2-line accessory handset - C4200 .....................................................................21

Analog cordless 2-line accessory handset - CTM-C4201 ............................................................22

Analog cordless 2-line accessory handset and charger bundle - CTM-A242HS ........................23

Analog cordless 2-line accessory handset with speed dials and charger bundle - CTM-A242SD ...24

Installation ..................................................................................................................................25

Analog corded lobby/1-line/2-line - A2100/A2210/A2220 .............................................................25

Analog corded trimstyle - A2310 ..................................................................................................27

Analog cordless 1-line/2-line - A2410/CTM-A2411/A2420/CTM-A2421 .......................................29

Analog cordless 1-line/2-line - CTM-A2411-BATT/CTM-A2421-BATT.........................................31

Analog cordless 1-line/2-line - A2410/A2420 ................................................................................34

Analog cordless 1-line/2-line - CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT ....36

Analog cordless 1-line/2-line accessory Petite - CTM-A241P/CTM-A242P .................................38

Analog corded/cordless 1-line - CTM-A2510 ...............................................................................41

Analog cordless charging base - C4000 ......................................................................................46

Analog cordless charging base - C4001 ......................................................................................47

Analog cordless charging stand - C4010 .....................................................................................48

Analog cordless charging stand - C4011/ CTM-A241HS/CTM-A241SD/CTM-A242HS/CTM-A242SD ...49

Analog cordless 1-line/2-line accessory handset - C4100/C4200/CTM-A241HS/CTM-A242HS ....50

Analog cordless 1-line/2-line accessory handset - CTM-A241SD/CTM-A242SD/CTM-C4101/CTM-C4201 ...52

Telephone settings ....................................................................................................................54

Analog corded lobby/1-line/2-line/trimstyle - A2100/A2210/A2220/A2310 ...................................54

Analog cordless 1-line/2-line - A2410/CTM-A2411/CTM-A2411-BATT/A2420/CTM-A2421/

CTM-A2421-BATT ...................................................................................................................56

Analog corded/cordless 1-line - CTM-A2510 ...............................................................................56

Analog cordless 1-line/2-line accessory handset - CTM-A241SD/CTM-A242SD/CTM-C4101/

CTM-C4201 ..............................................................................................................................56

Analog cordless 1-line/2-line accessory Petite - CTM-A241P/CTM-A242P ................................56

Telephone operation ..................................................................................................................60

Analog corded lobby - A2100 .......................................................................................................60

Analog corded 1-line - A2210 .......................................................................................................61

Analog corded 2-line - A2220 .......................................................................................................63

Analog corded trimstyle - A2310 ..................................................................................................65

Analog cordless 1-line - A2410/CTM-A2411/CTM-A2411-BATT ..................................................66

Analog cordless 1-line accessory Petite - CTM-A241P ...............................................................69

Analog cordless 2-line - A2420/CTM-A2421/CTM-A2421-BATT .................................................70

Analog cordless 2-line accessory Petite - CTM-A242P ...............................................................73

Analog corded/cordless 1-line - CTM-A2510 ...............................................................................75

Appendix .....................................................................................................................................78

Handset battery ............................................................................................................................78

Troubleshooting ............................................................................................................................79

Precautions for users of implanted cardiac pacemakers ..............................................................82

Operating range............................................................................................................................82

About cordless telephones ...........................................................................................................82

The RBRC® seal ...........................................................................................................................82

VTech Hospitality limited warranty program .................................................................................83

FCC, ACTA and IC regulations ....................................................................................................84

Energy-saving charging mode .....................................................................................................85

Maintenance .................................................................................................................................86

Technical specications ...............................................................................................................87

Index ............................................................................................................................................91

Parts checklist

BY 1021

Items contained in the respective telephone package:

Model name Model number Parts included

Parts checklist

Analog corded lobby

Analog corded 1-line

Analog corded 2-line

Analog corded trimstyle

Analog cordless 1-line

A2100

A2210

A2220

A2310

A2410

Telephone base with faceplate and overlay

Corded handset

Mounting bracket

Telephone line cord

Telephone line cords (2)

Analog cordless 1-line

Analog cordless 1-line accessory Petite

Analog cordless 2-line

CTM-A2411/ CTM-A2411-BATT

CTM-A241P

A2420

Telephone base with faceplate and overlay

Power adapter with RJ-45 cord

Telephone base with faceplate and overlay

faceplate and overlay

Cordless handset

Telephone line cord

Corded handset

Cordless handset

Mounting bracket

Battery

Mounting bracket

Battery

Screw

Battery (2)

Power adapter

ScrewTelephone base with

Power adapter with RJ-45 cord

Screws (2)

Power adapter with RJ-45 cord

Telephone line cord

Parts checklist

BY 1021

HOLD FLASH

REDIAL

FIND HANDSET

MUTE

SPEAKER

VOLUME

IN USE

BY 1021

Items contained in the respective telephone package:

Model name Model number Parts included

Analog cordless 2-line

Analog cordless 2-line accessory Petite

Analog corded/ cordless 1-line

CTM-A2421/ CTM-A2421-BATT

CTM-A242P

CTM-A2510

faceplate and overlay

Power adapter with RJ-45 cord

Telephone base with faceplate and overlay

Cordless handset

Telephone line cord

Corded handset

Mounting bracket

Cordless handset

Battery (2)

Mounting bracket

Screws (2)Telephone base with

Power adapter

Battery Screws (2)

Analog cordless charging base

Analog cordless charging stand

Analog cordless 1-line accessory handset

C4000

C4001

C4010

C4011

C4100

Telephone line cord

Charging base

Charging stand

Cordless

Battery Screw

handset

Charging stand

Charger power adapter

Mounting bracket with a s crew

Power adapter with RJ-45 cord

Power adapter

Power adapter with RJ-45 cord

Power adapter

BY 1021

Parts checklist

BY 1021

Items contained in the respective telephone package:

Model name Model number Parts included

Parts checklist

Analog cordless 1-line accessory handset

Analog cordless 2-line accessory handset

Analog cordless 1-line accessory handset and charger bundle

Analog cordless 2-line accessory handset and charger bundle

CTM-C4101

C4200

CTM-C4201

CTM-A241HS

CTM-A242HS

Cordless handset

Battery Screws (2)

Battery Screw

Battery Screws (2)

Battery Screw

Charging stand

Battery Screw

Charging stand

Power adapter

Analog cordless 1-line accessory handset with speed dials and charger bundle

Analog cordless 2-line accessory handset with speed dials and charger bundle

CTM-A241SD

CTM-A242SD

Cordless handset

Battery Screws (2)

Charging stand

Power adapter

Telephone layout

Analog corded lobby - A2100

DATA port

Switch hook

Wall mount clip

RINGER VOL

+/VOLUME

-/VOLUME

Telephone layout

Analog corded 1-line - A2210

MESSAGE WAITING LED

DATA port

Switch hook

Wall mount clip

Sticker covering jumpers

RINGER VOL

Speed Dial keys

PAUSE (recessed key)

PROGRAM (recessed key)

FLASH

MUTE

+/VOLUME

-/VOLUME

/SPEAKER

HOLD

Telephone layout

Analog corded 2-line - A2220

MESSAGE WAITING LED

DATA port

Switch hook

Wall mount clip

Sticker covering jumpers

RINGER VOL

Speed Dial keys

PAUSE (recessed key)

PROGRAM (recessed key)

FLASH

MUTE

+/VOLUME

-/VOLUME

LINE 1 LINE 2

/SPEAKER

CONF HOLD

Telephone layout

Analog corded trimstyle - A2310

MESSAGE WAITING LED

Telephone layout

MUTE

MUTE LED

Switch hook

-/VOLUME/+

FLASH

FAX/DATA port

Wall mount clip

RINGER VOL

Telephone layout

Analog cordless 1-line - A2410

Wall mount clip

/FIND HANDSET

MESSAGE WAITING LED

DATA port

Speed Dial keys

PAUSE (recessed key) PROGRAM (recessed key)

INT

REDIAL

FLASH

MUTE

+/VOLUME

-/VOLUME

MESSAGE WAITING LED

TALK

REDIAL

/SPEAKER

INTERCOM

/SPEAKER

HOLD

CHARGE LED

IN USE LED

-/VOLUME/+

OFF

HOLD

FLASH

MUTE

LOW BATTERY LED

Telephone layout

Analog cordless 1-line - CTM-A2411/CTM-A2411-BATT

Wall mount clip

/FIND HANDSET

MESSAGE WAITING LED

DATA port

Telephone layout

Speed Dial keys

PAUSE (recessed key) PROGRAM (recessed key)

Speed Dial key

REDIAL

FLASH

MUTE

+/VOLUME

-/VOLUME

MESSAGE WAITING LED

TALK

FLASH

/SPEAKER

MESSAGES

LOW BATTERY LED

/SPEAKER

HOLD

CHARGE LED

IN USE LED

-/VOLUME/+

HOLD OFF

REDIAL MUTE

Speed Dial keys

Telephone layout

Analog cordless 1-line accessory Petite - CTM-A241P

MESSAGE WAITING LED

Switch hook

Wall mount clip

Speed Dial keys

/USB CHARGE ONLY

(USB port for charging only)

MUTE

IN USE light

FLASH +/VOLUME

-/VOLUME RINGER VOL

HOLD

Speed Dial key

Telephone layout

Analog cordless 2-line - A2420

Wall mount clip

/FIND HANDSET

MESSAGE WAITING LED

DATA port

Telephone layout

Speed Dial keys

PAUSE (recessed key) PROGRAM (recessed key) INT

REDIAL

FLASH

MUTE +/VOLUME

-/VOLUME

MESSAGE WAITING LED

LINE 1 LINE 2

CONF

LINE 1

CONF

/SPEAKER

INTERCOM

/SPEAKER

HOLD

CHARGE LED

LINE 2

HOLD

MUTE

LOW BATTERY LED

-/VOLUME/+

OFF

FLASH

REDIAL

Telephone layout

Analog cordless 2-line - CTM-A2421/CTM-A2421-BATT

Wall mount clip

/FIND HANDSET

MESSAGE WAITING LED

DATA port

Speed Dial keys

PAUSE (recessed key) PROGRAM (recessed key)

Speed Dial key

REDIAL

FLASH

MUTE +/VOLUME

-/VOLUME

MESSAGE WAITING LED

LINE 1 LINE 2

LOW BATTERY LED

CONF

LINE 1

FLASH

/SPEAKER

MESSAGES

/SPEAKER

HOLD

CHARGE LED

-/VOLUME/+

LINE 2 CONF

OFF HOLD

REDIAL MUTE

Speed Dial keys

Telephone layout

Analog cordless 2-line accessory Petite - CTM-A242P

MESSAGE WAITING LED

Telephone layout

Switch hook

Wall mount clip

Speed Dial keys

/USB CHARGE ONLY

(USB port for charging only)

Speed Dial key

MUTE

LINE 1

LINE 2

FLASH

+/VOLUME

-/VOLUME RINGER VOL

HOLD

CONF

Telephone layout

Analog corded/cordless 1-line - CTM-A2510

MESSAGE WAITING LED

DATA port

Wall mount clip

Speed Dial keys

PAUSE (recessed key) PROGRAM (recessed key)

Speed Dial key

REDIAL

FIND HANDSET

MUTE

+/VOLUME

-/VOLUME

MESSAGE WAITING LED

/SPEAKER

MESSAGES

LOW BATTERY LED

TALK

FLASH

/SPEAKER

FLASH

HOLD

IN USE LED

-/VOLUME/+

HOLD

OFF

REDIAL MUTE

Speed Dial keys

CHARGE LED

Telephone layout

Analog cordless charging base - C4000/C4001

Telephone layout

Wall mount clip

CHARGE LED

Telephone layout

Analog cordless charging stand - C4010/C4011

CHARGE LED

Telephone layout

Analog cordless 1-line accessory handset - C4100

MESSAGE WAITING LED

Telephone layout

-/VOLUME/+

TALK

REDIAL

/SPEAKER

INTERCOM

OFF

HOLD

FLASH

MUTE

LOW BATTERY LED

Telephone layout

Analog cordless 1-line accessory handset - CTM-C4101

MESSAGE WAITING LED

-/VOLUME/+

TALK

FLASH

/SPEAKER

MESSAGES

LOW BATTERY LED

HOLD OFF

REDIAL MUTE

Speed Dial keys

Telephone layout

Analog cordless 1-line accessory handset and charger bundle - CTM-A241HS

MESSAGE WAITING LED

Telephone layout

-/VOLUME/+

TALK

REDIAL

/SPEAKER

INTERCOM

OFF

HOLD

FLASH

MUTE

LOW BATTERY LED

CHARGE LED

Telephone layout

Analog cordless 1-line accessory handset with speed dials and charger bundle - CTM-A241SD

-/VOLUME/+

MESSAGE WAITING LED

TALK

FLASH

/SPEAKER

MESSAGES

LOW BATTERY LED

HOLD OFF

REDIAL MUTE

Speed Dial keys

CHARGE LED

Telephone layout

Analog cordless 2-line accessory handset - C4200

Telephone layout

MESSAGE WAITING LED

LINE 1

CONF

/SPEAKER

INTERCOM

-/VOLUME/+

LINE 2

OFF

HOLD

FLASH

MUTE

LOW BATTERY LED

REDIAL

Telephone layout

Analog cordless 2-line accessory handset - CTM-C4201

MESSAGE WAITING LED

LINE 1

FLASH

/SPEAKER

MESSAGES

LOW BATTERY LED

-/VOLUME/+

LINE 2 CONF

OFF HOLD

REDIAL MUTE

Speed Dial keys

Telephone layout

Analog cordless 2-line accessory handset and charger bundle - CTM-A242HS

Telephone layout

MESSAGE WAITING LED

LINE 1

CONF

/SPEAKER

INTERCOM

-/VOLUME/+

LINE 2

OFF

HOLD

FLASH

MUTE

LOW BATTERY LED

REDIAL

CHARGE LED

Telephone layout

Analog cordless 2-line accessory handset with speed dials and charger bundle - CTM-A242SD

MESSAGE WAITING LED

LINE 1

FLASH

/SPEAKER

MESSAGES

LOW BATTERY LED

-/VOLUME/+

LINE 2 CONF

OFF HOLD

REDIAL MUTE

Speed Dial keys

CHARGE LED

Installation

Analog corded lobby/1-line/2-line - A2100/A2210/A2220

Telephone base installation

This telephone can be adapted to desktop use or mount on a standard telephone wall plate.

Installation option - desktop position

Turn the telephone base over with the bottom side facing up. Connect the coiled handset cord to the telephone base.

Coiled handset cord jack

Insert the tabs into the grooves to afx the mounting bracket in place.

Installation

Install the telephone base as shown below.

Telephone line jac k

Telephone wall jack

If you have High S peed Internet

Access service, a DSL filter (not

included) is required.

Telephone line cord

Installation

Analog corded lobby/1-line/2-line - A2100/A2210/A2220

Installation option - converting from desktop to wall mount position

To mount the telephone base on the wall:

Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn

(180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the telephone base. This protruding edge holds the handset when the phone is mounted on the wall.

Protruding edge

Turn the telephone base over with the bottom side facing up. To remove the mounting bracket, rmly push both tabs downward

and pull up until both tabs release from the grooves.

Mounting bracket

Mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone

base down on both mounting studs until it locks into place.

Eyelets

Place the handset on the telephone base cradle.

Installation

Analog corded trimstyle - A2310

Telephone base installation

The telephone can be adapted to desktop use or mount on a standard telephone wall plate.

Installation option - desktop position

Turn the telephone base over with the bottom side facing up. Connect the telephone line cord to the telephone base and route

along the wire duct.

Wire duct

Telephone line jac k

Position the mounting bracket as shown. Insert the two small tabs of the mounting bracket into the lower slots on the telephone

base. Then press the large tab on the mounting bracket and rmly push it into the upper groove on the telephone base.

Installation

Install the telephone base as shown below. Then connect the coiled handset cord to the telephone base.

Telephone wall jack

If you have High Speed Internet

Access service, a DSL filter (not

included) is required.

Installation

Analog corded trimstyle - A2310

Installation option - converting from desktop to wall mount position

To mount the telephone base on the wall:

Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn

(180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the charging base. This protruding edge holds the cordless handset when the phone is mounted on the wall.

Protruding edge

Unplug the telephone line cord from the telephone wall jack. Then press the large tab on the mounting bracket to remove it from

the upper groove on the telephone base.

Turn the mounting bracket upside down. Remove the telephone line cord from the wire duct and then route it through the

rectangular hole on the mounting bracket. Insert the small tabs on the mounting bracket into the upper slots on the telephone base. Then press the large tab on the mounting bracket and rmly push it into the lower groove on the telephone base.

Mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone

base down on both mounting studs until it locks into place. Place the handset on the telephone base cradle.

Eyelets

Telephone wall jack

If you have High Speed Internet Access service, a DSL filter (not included) is required.

Installation

Analog cordless 1-line/2-line - A2410/CTM-A2411/A2420/CTM-A2421

Telephone base installation

This telephone can be adapted to desktop use or mount on a standard telephone wall plate.

Installation option - desktop position

Turn the telephone base over with the bottom side facing up. Insert the tabs into the grooves to afx the mounting bracket in place.

Plug the power adapter into an electrical outlet not controlled by a wall switch.

Electrical outlet not controlled by a wall switch

Installation

RJ-45 cord

Telephone line cord

RJ-45 cord

Power c ord jack

Power adapter

Telephone line cord

Telephone wall jack

If you have High S peed Internet Acc ess service,

a DSL filter (not included)

is required.

When the telephone base has been initially installed, press /SPEAKER on the telephone base. Listen for a dial tone and then

press /SPEAKER again to hang up.

CAUTION:

Use only the supplied RJ-45 cord and power adapter. RJ-45 cord is not designed for use in any other IT devices. Misuse of RJ-45 cord on your other IT devices shall be prohibited. To order a replacement, visit our website at www.vtechhotelphones.com or call 1-888-907-2007.

Installation

Analog cordless 1-line/2-line - A2410/CTM-A2411/A2420/CTM-A2421

Installation option - converting from desktop to wall mount position

To mount the telephone base on the wall:

Unplug the power adapter and telephone line cord. Disconnect the power cord from the telephone base.

Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn

(180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the telephone base. This protruding edge holds the handset when the phone is mounted on the wall.

Protruding edge

Turn the telephone base over with the bottom side facing up. To remove the mounting bracket, rmly push both tabs downward

and pull up until both tabs release from the grooves.

Mounting bracket

Mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone

base down on both mounting studs until it locks into place.

Eyelets

Connect the power cord to the telephone base. Plug the power adapter into an electrical outlet not controlled by a wall switch,

and plug the telephone line cord into the telephone wall jack. Then place the cordless handset on the telephone base cradle.

Installation

BY 1021

Analog cordless 1-line/2-line - CTM-A2411-BATT/CTM-A2421-BATT

Telephone base backup battery installation

You can install a backup battery in the telephone base to guarantee continual operation during a power outage. The telephone base backup battery only supports complete operation for the telephone base and handset on line 1 during a power outage.

You can buy rechargeable battery (BT264392/BT266342) for the telephone base. When the battery is installed and AC power is connected, the battery will be recharged.

You should replace the installed battery when the LED next to the battery compartment ashes. Install the battery as shown below.

Insert a 5 mm standard screwdriver in the provided slot and then twist and lift to remove the battery compartment cover.

Plug the battery connector securely into the socket inside the battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

To replace the cover, align all the tabs on the telephone base battery cover against the corresponding grooves on the telephone

base, then rmly push downward until all the tabs lock in the grooves. Install the screw at the bottom of the handset.

1 2 3

Screw

LED

Replace a telephone base backup battery

Insert a 5 mm standard screwdriver in the provided slot and then twist and lift to remove the battery compartment cover.

Unplug the battery connector from the socket and then remove the battery from the battery compartment.

Follow Step 2 to Step 4 in Telephone base backup battery installation above to install a new battery.

CAUTIONS:

There may be a risk of explosion if a wrong type of battery is used. Use only rechargeable battery (BT264392/BT266342). To order a battery,

•

visit our website at www.vtechhotelphones.com or call 1-888-907-2007. Dispose of used batteries according to the information in The RBRC® seal on page 82.

•

Installation

Analog cordless 1-line/2-line - CTM-A2411-BATT/CTM-A2421-BATT

Telephone base installation

This telephone can be adapted to desktop use or mount on a standard telephone wall plate.

Installation option - desktop position

Turn the telephone base over with the bottom side facing up. Insert the tabs into the grooves to afx the mounting bracket

in place.

Plug the power adapter into an electrical outlet not controlled by a wall switch.

Electrical outlet not controlled by a wall switch

RJ-45 cord

Telephone line cord

RJ-45 cord

Power c ord jack

Power adapter

Telephone line cord

Telephone wall jack

If you have High S peed Internet Acc ess service,

a DSL filter (not included)

is required.

When the telephone base has been initially installed, press /SPEAKER on the telephone base. Listen for a dial tone and then

press /SPEAKER again to hang up.

CAUTION:

Installation

Analog cordless 1-line/2-line - CTM-A2411-BATT/CTM-A2421-BATT

Installation option - converting from desktop to wall mount position

To mount the telephone base on the wall:

Unplug the power adapter and telephone line cord. Disconnect the power cord from the telephone base.

Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn

(180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the telephone base. This protruding edge holds the handset when the phone is mounted on the wall.

Protruding edge

Turn the telephone base over with the bottom side facing up. To remove the mounting bracket, rmly push both tabs downward

and pull up until both tabs release from the grooves.

Mounting bracket

Installation

Mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone

base down on both mounting studs until it locks into place.

Eyelets

Connect the power cord to the telephone base. Plug the power adapter into an electrical outlet not controlled by a wall switch,

and plug the telephone line cord into the telephone wall jack. Then place the cordless handset on the telephone base cradle.

Installation

BY 1021

Analog cordless 1-line/2-line - A2410/A2420

Handset battery installation

Install the battery as shown below.

Gently lift the handset cover. Do not detach the speaker wires between the handset cover and the handset.

Plug the battery connector securely into the socket inside the handset battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then

rmly push downward until all the tabs lock in the grooves. Then install the screw at the bottom of the handset.

1 2 3 4

FCC ID

Replace a handset battery

Use a 5 mm standard screwdriver to open the screw cover and remove the screw. Insert the screwdriver in the provided slot and

then twist and lift to open the bottom part.

Screw cover

Use your thumb to slide along the sides of the handset carefully to release the tabs on the handset cover from the slots on the

sides of the handset. Then gently detach the handset cover from the handset.

Do not detach the speaker wires between the handset cover and the handset.

Unplug the battery connector from the socket and then remove the battery from the handset battery compartment.

Follow Step 2 to Step 4 in Handset battery installation above to install a new battery.

CAUTIONS:

There may be a risk of explosion if a wrong type of handset battery is used. Use only the supplied rechargeable battery (BT264392/BT266342)

•

or replacement battery (BT266342). To order a replacement, visit our website at www.vtechhotelphones.com or call 1-888-907-2007.

FCC ID is shown on the back of the cordless handset body after the handset cover is removed.

•

Dispose of used batteries according to the information in The RBRC® seal on page 82.

•

Installation

Analog cordless 1-line/2-line - A2410/A2420

Handset registration

Place the cordless handset on the telephone base cradle. Handset registration happens automatically the rst time a cordless handset is placed on the telephone base. When the registration process completes, the MESSAGE WAITING LED ashes once and you hear 3 rising beeps as conrmation. Each telephone base accommodates up to 4 cordless handsets. When the telephone base

has already registered 4 cordless handsets, one of the registered cordless handsets must be deregistered or registered to another

telephone base before adding a new cordless handset.

Handset deregistration

When a registered cordless handset is idle, press *331734# and then press HOLD. You hear 3 rising beeps as conrmation when the deregistration process completes.

Any A2410 handset can register to any A2410 telephone base. Any A2420 handset can register to any A2420 telephone base. When a registered cordless handset is idle, place it on another telephone base. This cordless handset automatically registers to the

new telephone base.

Handset battery charging

The battery must be fully charged before using the cordless handset for the rst time. The CHARGE LED turns on when the cordless handset is charging on the telephone base, charging base or charging stand. The battery is fully charged after 16 hours of continuous charging. For best performance, keep the cordless handset in the telephone base, charging base or charging stand when not in use.

Installation

BY 1021

Analog cordless 1-line/2-line - CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT

Handset battery installation

Install the battery as shown below.

Plug the battery connector securely into the socket inside the handset battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then

rmly push downward until all the tabs lock in the grooves. Then install the screws at both ends of the handset.

1 2 3

FCC ID

Replace a handset battery

Use a 5 mm standard screwdriver to open the screw cover and remove the screw.

Insert the screwdriver in the provided slot and then twist and lift to open the bottom part.

Screw cover

-OR-

Open the bottom part manually at the recessed area to avoid scratching the plastic.

Recessed area

Use your thumb to slide along the sides of the handset carefully to release the tabs on the handset cover from the slots on the

sides of the handset. Then gently detach the handset cover from the handset.

CAUTIONS:

•

Unplug the battery connector from the socket and then remove the battery from the handset battery compartment. Follow Step 2 to Step 4 in Handset battery installation above to install a new battery.

There may be a risk of explosion if a wrong type of handset battery is used. Use only the supplied rechargeable battery (BT264392/BT266342) or replacement battery (BT266342). To order a replacement, visit our website at www.vtechhotelphones.com or call 1-888-907-2007.

FCC ID is shown on the back of the cordless handset body after the handset cover is removed.

Dispose of used batteries according to the information in The RBRC® seal on page 82.

Installation

Analog cordless 1-line/2-line - CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT

Handset registration

To register a cordless handset to the telephone base:

cordless handsets or accessory Petite phones must be deregistered or registered to another telephone base before adding a new

cordless handset or accessory Petite phone.

To register a cordless handset to the telephone base without placing it on the telephone base:

When the telephone base is idle, press 123 on the telephone base and then press HOLD. The MESSAGE WAITING LED on the base turns on for about 90 seconds. Press 123 on the cordless handset and then press HOLD. The MESSAGE WAITING LED on

the handset turns on for 90 seconds. When the registration process completes, you hear 3 rising beeps as conrmation. When the

telephone base has already registered 4 cordless handsets or accessory Petite phones, one of the registered cordless handsets or accessory Petite phones must be deregistered or registered to another telephone base before adding a new cordless handset or

accessory Petite phone.

Handset deregistration

When a registered cordless handset is idle, press *331734# and then press HOLD. You hear 3 rising beeps as conrmation when the deregistration process completes.

Any CTM-A2411/CTM-A2411-BATT handset can register to any A2410/CTM-A2411/CTM-A2411-BATT telephone base. Any CTM-A2421/CTM-A2421-BATT handset can register to any A2420/CTM-A2421/CTM-A2421-BATT telephone base.

When a registered cordless handset is idle, place it on another telephone base. This cordless handset automatically registers to the new telephone base.

Handset battery charging

Installation

Analog cordless 1-line/2-line accessory Petite - CTM-A241P/CTM-A242P

Accessory Petite installation

The telephone can be adapted to desktop use or mounted on a standard telephone wall plate.

Installation option - desktop position

Turn the phone base over with the bottom side facing up. Connect the small end of the power adapter cord on the top of the phone.

Power jack

Position the mounting bracket as shown. Insert the two small tabs of the mounting bracket into the lower slots on the phone.

Then press the large tab on the mounting bracket and rmly push it into the upper groove at the bottom.

Install the phone as shown below. Then connect the coiled handset cord at the side of the phone.

Electrical outlet not controlled by a wall switch

Power adapter

Power c ord

Installation

Analog cordless 1-line/2-line accessory Petite - CTM-A241P/CTM-A242P

Installation option - converting from desktop to wall mount position

To mount the phone on the wall:

Set aside the handset. On the phone cradle, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees). It

locks into place with the protruding edge pointing towards the upper edge of the phone. This protruding edge holds the corded handset when the phone is mounted on the wall.

Protruding edge

Press the large tab on the mounting bracket to remove it from the upper groove on the phone.

Installation

Turn the mounting bracket upside down. Insert the small tabs on the mounting bracket into the upper slots on the phone. Then

press the large tab on the mounting bracket and rmly push it into the lower groove on the base.

Mount the phone on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the phone down on both

mounting studs until it locks into place. Place the handset on the phone cradle.

Installation

Analog cordless 1-line/2-line accessory Petite - CTM-A241P/CTM-A242P

Accessory Petite registration

To register an accessory Petite to a CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT/CTM-A2510 telephone base:

When the telephone base is idle, press 123 and then press HOLD. The MESSAGE WAITING LED turns on for about 90 seconds. Press 123 and then HOLD on the accessory Petite, the MESSAGE WAITING LED on the accessory Petite turns on for 90 seconds.

When the registration process completes, you hear 3 rising beeps as conrmation. When the telephone base has already

registered 4 cordless handsets or accessory Petite phones, one of the registered cordless handsets or accessory Petite phones

must be deregistered or registered to another telephone base before adding a new cordless handset or accessory Petite phone.

Accessory Petite deregistration

When a registered accessory Petite is idle, press *331734# and then press HOLD. You hear 3 rising beeps as conrmation when the deregistration process completes.

Any analog cordless 1-line accessory Petite can register to any CTM-A2411/CTM-A2411-BATT/CTM-A2510 telephone base. Any analog cordless 2-line accessory Petite can register to any CTM-A2421/CTM-A2421-BATT telephone base.

Installation

Analog corded/cordless 1-line - CTM-A2510

Telephone base installation

This telephone can be adapted to desktop use or mount on a standard telephone wall plate.

Installation option - desktop position

Turn the telephone base over with the bottom side facing up. Connect the coiled handset cord to the telephone base.

Coiled handset cord jack

Insert the tabs into the grooves to afx the mounting bracket in place.

Installation

Install the telephone base as shown below.

RJ-45 cord

Power c ord jack

Telephone line cord

RJ-45 cord

Electrical outlet not controlled by a wall switch

Power adapter

Telephone line cord

Telephone wall jack

If you have High S peed Internet Acc ess service,

a DSL filter (not included)

is required.

CAUTION:

Installation

Analog corded/cordless 1-line - CTM-A2510

Installation option - converting from desktop to wall mount position

To mount the telephone base on the wall:

Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn

(180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the telephone base. This protruding edge holds the handset when the phone is mounted on the wall.

Protruding edge

Turn the telephone base over with the bottom side facing up. To remove the mounting bracket, rmly push both tabs downward

and pull up until both tabs release from the grooves.

Mounting bracket

Mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone

base down on both mounting studs until it locks into place.

Eyelets

Place the handset on the telephone base cradle.

Installation

BY 1021

Analog corded/cordless 1-line - CTM-A2510

Handset battery installation

Install the battery as shown below.

Plug the battery connector securely into the socket inside the handset battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then

rmly push downward until all the tabs lock in the grooves. Then install the screws at both ends of the handset.

1 2 3

FCC ID

Replace a handset battery

Use a 5 mm standard screwdriver to open the screw cover and remove the screw.

Insert the screwdriver in the provided slot and then twist and lift to open the bottom part.

Installation

Screw cover

-OR-

Open the bottom part manually at the recessed area to avoid scratching the plastic.

Recessed area

Use your thumb to slide along the sides of the handset carefully to release the tabs on the handset cover from the slots on the

sides of the handset. Then gently detach the handset cover from the handset.

CAUTIONS:

•

Unplug the battery connector from the socket and then remove the battery from the handset battery compartment. Follow Step 2 to Step 4 in Handset battery installation above to install a new battery.

FCC ID is shown on the back of the cordless handset body after the handset cover is removed.

Dispose of used batteries according to the information in The RBRC® seal on page 82.

Installation

Analog corded/cordless 1-line - CTM-A2510

Handset registration

on the handset turns on for 90 seconds. When the registration process completes, you hear 3 rising beeps as conrmation. When

the telephone base has already registered 4 cordless handsets, one of the registered cordless handsets must be deregistered or

registered to another telephone base before adding a new cordless handset.

Handset deregistration

When a registered cordless handset is idle, press *331734# and then press HOLD. You hear 3 rising beeps as conrmation when the deregistration process completes.

Any CTM-A2510 handset can register to any CTM-A2510 telephone base. Deregister the registered cordless handset from its base (see Handset deregistration above) and then register it to a new telephone base (see Handset registration above).

Handset battery charging

The battery must be fully charged before using the cordless handset for the rst time. The CHARGE LED turns on when the cordless handset is charging on the charging base or charging stand. The battery is fully charged after 16 hours of continuous

charging. For best performance, keep the cordless handset in the charging base or charging stand when not in use.

Installation

Analog corded/cordless 1-line - CTM-A2510

Charging stand installation

The charging stand is designed for desktop use. Install the charging stand as shown below.

Electrical outlet not controlled by a wall switch

Power adapter

Installation

Power c ord

Installation

Analog cordless charging base - C4000

Charging base installation

The charging base can be adapted to desktop use or mount on a standard telephone wall plate.

Installation option - desktop position

Turn the charging base over with the bottom side facing up. Position the mounting bracket as shown. Connect the power cord to

the charging base and route the cord out from the large eyelet on the mounting bracket.

Power c ord jack

Insert the tabs of the mounting bracket as the direction shown below. Then tighten the screw to afx the mounting bracket.

Screw

Plug the power adapter into an electrical outlet not controlled by a wall switch.

Installation option - converting from desktop to wall mount position

Unplug the power adapter from the electrical outlet.

Remove the cordless handset from the charging base if necessary. On the charging base cradle, place a coin in the slit of the

wall mount clip and rotate a half turn (180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the charging base. This protruding edge holds the cordless handset when the charging base is mounted on the wall.

Protruding edge

Loosen the screw from the mounting bracket and remove the mounting bracket from the grooves.

Screw

Turn the mounting bracket upside down. Insert the tabs of the mounting bracket into the lower grooves on the charging base.

Then tighten the screw to afx the mounting bracket.

Eyelets

Mount the charging base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the charging

base down on both mounting studs until it locks into place. Plug the power adapter into an electrical outlet not controlled by a wall switch.

Installation

Analog cordless charging base - C4001

Charging base installation

The charging base can be adapted to desktop use or mount on a standard telephone wall plate.

Installation option - desktop position

Turn the charging base over with the bottom side facing up. Position the mounting bracket as shown. Connect the power cord to

the charging base and route the cord out from the large eyelet on the mounting bracket.

Power c ord jack

Insert the tabs of the mounting bracket as the direction shown below. Then tighten the screw to afx the mounting bracket.

Screw

Installation

Plug the power adapter into an electrical outlet not controlled by a wall switch.

Installation option - converting from desktop to wall mount position

Unplug the power adapter from the electrical outlet.

Remove the cordless handset from the charging base if necessary. On the charging base cradle, place a coin in the slit of the

Protruding edge

Loosen the screw from the mounting bracket and remove the mounting bracket from the grooves.

Screw

Rotate the mounting bracket. Insert the tabs of the mounting bracket into the lower grooves on the charging base. Then tighten

the screw to afx the mounting bracket.

Eyelets

Mount the charging base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the charging

base down on both mounting studs until it locks into place. Plug the power adapter into an electrical outlet not controlled by a wall switch.

Installation

Analog cordless charging stand - C4010

Charging stand installation

The charging stand is designed for desktop use. Install the charging stand as shown below.

Electrical outlet not controlled by a wall switch

Power adapter

RJ-45 cord

Installation

Analog cordless charging stand - C4011/ CTM-A241HS/CTM-A241SD/CTM-A242HS/CTM-A242SD

Charging stand installation

The charging stand is designed for desktop use. Install the charging stand as shown below.

Electrical outlet not controlled by a wall switch

Power adapter

Installation

Power c ord

Installation

BY 1021

Analog cordless 1-line/2-line accessory handset - C4100/C4200/CTM-A241HS/CTM-A242HS

Handset battery installation

Install the battery as shown below.

Gently lift the handset cover. Do not detach the speaker wires between the handset cover and the handset.

Plug the battery connector securely into the socket inside the handset battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then

rmly push downward until all the tabs lock in the grooves. Then install the screw at the bottom of the handset.

1 2 3 4

FCC ID

Replace a handset battery

Use a 5 mm standard screwdriver to open the screw cover and remove the screw. Insert the screwdriver in the provided slot and

then twist and lift to open the bottom part.

Screw cover

Use your thumb to slide along the sides of the handset carefully to release the tabs on the handset cover from the slots on the

sides of the handset. Then gently detach the handset cover from the handset.

Do not detach the speaker wires between the handset cover and the handset.

Unplug the battery connector from the socket and then remove the battery from the handset battery compartment.

Follow Step 2 to Step 4 in Handset battery installation above to install a new battery.

CAUTIONS:

There may be a risk of explosion if a wrong type of handset battery is used. Use only the supplied rechargeable battery (BT264392/BT266342) or

•

replacement battery (BT266342). To order a replacement, visit our website at www.vtechhotelphones.com or call 1-888-907-2007. FCC ID is shown on the back of the cordless handset body after the handset cover is removed.

•

Dispose of used batteries according to the information in The RBRC® seal on page 82.

•

Installation

Analog cordless 1-line/2-line accessory handset - C4100/C4200/CTM-A241HS/CTM-A242HS

Handset registration

has already registered 4 cordless handsets, one of the registered cordless handsets must be deregistered or registered to another

telephone base before adding a new cordless handset.

Handset deregistration

When a registered cordless handset is idle, press *331734# and then press HOLD. You hear 3 rising beeps as conrmation when the deregistration process completes.

Any C4100/CTM-A241HS handset can register to any A2410 telephone base. Any C4200/CTM-A242HS handset can register to any A2420 telephone base.

When a registered cordless handset is idle, place it on another telephone base. This cordless handset automatically registers to the new telephone base.

Handset battery charging

Installation

BY 1021

Analog cordless 1-line/2-line accessory handset - CTM-A241SD/CTM-A242SD/CTM-C4101/ CTM-C4201

Handset battery installation

Install the battery as shown below.

Plug the battery connector securely into the socket inside the handset battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then

rmly push downward until all the tabs lock in the grooves. Then install the screws at both ends of the handset.

1 2 3

FCC ID

Replace a handset battery

Use a 5 mm standard screwdriver to open the screw cover and remove the screw.

Insert the screwdriver in the provided slot and then twist and lift to open the bottom part.

Screw cover

-OR-

Open the bottom part manually at the recessed area to avoid scratching the plastic.

Recessed area

Use your thumb to slide along the sides of the handset carefully to release the tabs on the handset cover from the slots on the

sides of the handset. Then gently detach the handset cover from the handset.

Unplug the battery connector from the socket and then remove the battery from the handset battery compartment.

Follow Step 2 to Step 4 in Handset battery installation above to install a new battery.

CAUTIONS:

•

FCC ID is shown on the back of the cordless handset body after the handset cover is removed. Dispose of used batteries according to the information in The RBRC® seal on page 82.

Installation

Analog cordless 1-line/2-line accessory handset - CTM-A241SD/CTM-A242SD/CTM-C4101/ CTM-C4201

Handset registration

To register a cordless handset to an A2410/A2420/CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT telephone base:

cordless handsets or accessory Petite phones must be deregistered or registered to another telephone base before adding a new

cordless handset or accessory Petite phone.

To register a cordless handset to a CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT/CTM-A2510 telephone base without placing it on the telephone base:

the handset turns on for 90 seconds. When the registration process completes, you hear 3 rising beeps as conrmation. When the

accessory Petite phone.

Handset deregistration

When a registered cordless handset is idle, press *331734# and then press HOLD. You hear 3 rising beeps as conrmation when the deregistration process completes.

Any CTM-A241SD/CTM-C4101 handset can register to any A2410/CTM-A2411/CTM-A2411-BATT/CTM-A2510 telephone base. Any CTM-A242SD/CTM-C4201 handset can register to any A2421/CTM-A2421/CTM-A2421-BATT telephone base.

Deregister the registered cordless handset from its base (see Handset deregistration above) and then register it to a new telephone base (see Handset registration above).

Handset battery charging

Installation

Telephone settings

FAX/DATA

RINGER

Analog corded lobby/1-line/2-line/trimstyle - A2100/A2210/A2220/A2310

Default settings are indicated by asterisks (*).

Setting Options Adjustable by:

Handset earpiece volume (for models A2210 and A2220 only)

Handset earpiece volume (for model A2310 only)

Speakerphone volume (for models A2210 and A2220 only)

Ringer volume Low, Medium*, High User and administrator

Ringer tone Tone 1*, Tone 2, Tone 3 Administrator only

Flash (for models A2210 and A2220 only)

Voicemail voltage detection

(for models A2210, A2220 and A2310 only)

Ringer tone

There are 3 ringer tone options. For 2-line model (A2220), changing the ringer tone of either LINE 1 or LINE 2 applies to both phone lines.

To change the ringer tone:

Turn the telephone base over with the bottom side facing up.

For lobby (A2100), 1-line (A2210) and 2-line (A2220) models, remove the mounting bracket if it is in desktop position. To

•

remove the mounting bracket, rmly push both tabs downward and pull up until they release from the grooves.

For trimstyle model (A2310), remove the mounting bracket. To remove the mounting bracket, rmly press down the tab on it

•

and pull out to detach it from the telephone base.

1, 2*, 3, 4 User and administrator

1, 2, 3*, 4, 5 User and administrator

1, 2, 3, 4, 5*, 6, 7, 8 User and administrator

1 (100ms), 2 (300ms), 3* (600ms) Administrator only

Disable voicemail voltage detection,

Administrator only

Periodic low voltage pulse detection method, Steady high voltage and periodic high voltage

pulse detection method

Mounting bracket

(For A2100, A2210 or A2220)

Slide the ringer tone switch to select the desired detented position using a narrow object such as a standard screwdriver.

(For A2310)

Ringer tone switch

(For A2100, A2210 or A2220)

Install the mounting bracket accordingly.

(For A2310)

Flash

For 1-line and 2-line models (A2210 and A2220), there are 3 ash duration options that can be programmed.

To change the ash duration:

Remove the faceplate and overlay if they are on the telephone base. Press /SPEAKER on the telephone base or lift the

handset. Then press the recessed PROGRAM key. The MUTE key ashes when in administrator mode. Press FLASH and you hear 3 beeps. Then press a dialing key, 1 (100ms), 2 (300ms) or 3 (600ms), to select the desired ash

duration. Press the recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

Telephone settings

Analog corded lobby/1-line/2-line/trimstyle - A2100/A2210/A2220/A2310

Voicemail voltage detection

For 1-line and 2-line models (A2210 and A2220), there are 3 options to set the voicemail voltage detection on the telephone base.

To disable the voicemail voltage detection:

Remove the faceplate and overlay if they are on the telephone base. Then remove the sticker

1. on the telephone base.

Use a narrow object to unplug all the jumpers from the telephone base.

2. Place the sticker back in place.

To set the voicemail voltage detection by the periodic low voltage pulse detection method:

Remove the faceplate and overlay if they are on the telephone base. Then remove the sticker

1. on the telephone base.

Use a narrow object to unplug all the jumpers from the telephone base. Then plug the jumpers

into 1, 2 and 3.

Place the sticker back in place.

To set the voicemail voltage detection by the steady high voltage and periodic high voltage pulse detection method:

Remove the faceplate and overlay if they are on the telephone base. Then remove the sticker

1. on the telephone base.

Use a narrow object to unplug all the jumpers from the telephone base. Then plug the jumpers

into 1, 2 and 4.

Place the sticker back in place.

1 2 3 4

Jumper

For trimstyle model (A2310), there are 3 options to set the voicemail voltage detection on the telephone base.

To disable the voicemail voltage detection:

Remove the sticker at the bottom of the telephone base.

1. Use a narrow object to unplug all the jumpers from the telephone base.

2. Place the sticker back in place.

To set the voicemail voltage detection by the periodic low voltage pulse detection method:

Remove the sticker at the bottom of the telephone base.

1. Use a narrow object to unplug all the jumpers from the telephone base. Then plug the jumpers into

1, 2

and 3.

Place the sticker back in place.

To set the voicemail voltage detection by the steady high voltage and periodic high voltage pulse detection method:

Remove the sticker at the bottom of the telephone base.

1. Use a narrow object to unplug all the jumpers from the telephone base. Then plug the jumpers into 1, 2 and 4.

2. Place the sticker back in place.

Speed Dial keys

For 1-line and 2-line models (A2210 and A2220), there are up to 10 programmable guest-service (Speed Dial) keys. Program these keys to automatically dial telephone numbers or to activate telephone system features.

To program a Speed Dial key:

Remove the faceplate and overlay if they are on the telephone base. Press /SPEAKER on the telephone base or lift the

1. handset. Then press the recessed PROGRAM key. The MUTE key ashes when in administrator mode.

Press the desired Speed Dial key where the telephone number is to be stored. You hear 3 beeps.

2. Enter the telephone number (up to 16 digits).

To insert a pause in the stored number, press the recessed PAUSE key.

•

The telephone stores the number automatically when 16 digits are entered. When the number has less than 16 digits, press the

recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

Telephone settings

To clear the programmed Speed Dial key:

Remove the faceplate and overlay if they are on the telephone base. Press /SPEAKER on the telephone base or lift the

1. handset. Then press the recessed PROGRAM key. The MUTE key ashes when in administrator mode.

Press the Speed Dial key where the telephone number is to be deleted. You hear 3 beeps. Press the recessed PROGRAM key

again. You hear 3 rising beeps as conrmation.

Telephone settings

Analog cordless 1-line/2-line - A2410/CTM-A2411/CTM-A2411-BATT/A2420/CTM-A2421/ CTM-A2421-BATT Analog corded/cordless 1-line - CTM-A2510 Analog cordless 1-line/2-line accessory handset - CTM-A241SD/CTM-A242SD/CTM-C4101/ CTM-C4201 Analog cordless 1-line/2-line accessory Petite - CTM-A241P/CTM-A242P

Default settings are indicated by asterisks (*).

Setting Options Adjustable by:

Listening volume - handset 1, 2, 3, 4*, 5, 6 User and administrator

Speakerphone volume - handset 1, 2, 3, 4*, 5, 6 User and administrator

Speakerphone volume - telephone base 1, 2, 3, 4*, 5, 6 User and administrator

Ringer volume - telephone base 1, 2*, 3 User and administrator

Ringer tone - telephone base Tone 1*, Tone 2, Tone 3 Administrator only

Flash 1 (100ms), 2 (300ms), 3* (600ms) Administrator only

RF transmission power - telephone base 1 (low), 2* (middle), 3 (high) Administrator only

Hold 00 (auto-release disabled), 01 - 14, 15*, 16 - 99 minutes Administrator only

Voicemail voltage detection -

Steady high voltage, periodic high

• voltage pulse and periodic low voltage pulse detection method

FSK detection method

•

Panasonic

•

Voicemail voltage detection -

Line reversal method•

Voicemail voltage detection -

Siemens•

Speed Dial number share 0 (disable), 1 (enable) Administrator only

0 (disable), 1 (enable) Administrator only

0 (disable), 1 (auto), 2 (default 0), 3 (default 1) Administrator only

0 (disable), 1 (50Hz), 2 (25Hz), 3 (20Hz) Administrator only

Ringer tone

There are 3 ringer tones options that can be assigned to the telephone base. For 2-line models (A2420/CTM-A2421/ CTM-A2421-BATT), changing the ringer tone of either LINE 1 or LINE 2 applies to both phone lines.

To change the ringer tone:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

Press 00 and you hear 3 beeps. Then press a dialing key, 1, 2 or 3, to select the desired ringer tone. You hear 3 rising beeps

2. as conrmation.

Flash

There are 3 ash duration options that can be programmed.

To change the ash duration:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press FLASH and you hear 3 beeps. Then press a dialing key, 1 (100ms), 2 (300ms) or 3 (600ms), to select the desired ash

2. duration. You hear 3 rising beeps as conrmation.

RF transmission power

There are 3 RF transmission power options on the telephone base that can be programmed.

To change the RF transmission power control level:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press 01 and you hear 3 beeps. Then press a dialing key, 1 (low - coverage of 25% of maximum working distance), 2 (middle -

2. coverage of 50% maximum working distance) or 3 (high - coverage of 100% of maximum working distance), to select the desired RF transmission power control level. You hear 3 rising beeps as conrmation.

Telephone settings

Hold

The call on hold timeout duration can be programmed from 01 to 99 minutes. Select 00 to disable the auto-release feature on call on hold.

To change the call on hold timeout duration:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press 02 and you hear 3 beeps. Then press the dialing keys from 00 to 99 minutes. You hear 3 rising beeps as conrmation.

Voicemail voltage detection

There are several voicemail voltage detection methods on the telephone base that can be programmed.

To disable the voicemail voltage detection:

Remove the faceplate and overlay if they are on the telephone base.

1. Press the recessed PROGRAM key, then press 100.

2. Press the recessed PROGRAM key, then press 110.

3. Press the recessed PROGRAM key, then press 120.

4. Press the recessed PROGRAM key, then press 130.

5. Press the recessed PROGRAM key, then press 140.

To set the voicemail voltage detection by the steady high voltage, periodic high voltage pulse and periodic low voltage pulse detection method:

Follow Step 1 to Step 6 in To disable the voicemail voltage detection above.

1. Press the recessed PROGRAM key.

2. Press 10 and you hear 3 beeps. Then press 1 to enable the setting. You hear 3 rising beeps as conrmation.

To set the voicemail voltage detection by the line reversal method:

Follow Step 1 to Step 6 in To disable the voicemail voltage detection above.

1. Disable voicemail signal to the telephone.

2. Press the recessed PROGRAM key.

3. Press 11 and you hear 3 beeps. Then press 1 (auto). You hear 3 rising beeps as conrmation.

4. Get a dial tone. Wait for about 3 seconds and then hang up.

5. After about 15 seconds, when the MESSAGE WAITING LED is off, enable voicemail signal to the telephone.

6. After about 15 seconds, when the MESSAGE WAITING LED is on, disable voicemail signal to the telephone. After about

7. 15 seconds, the MESSAGE WAITING LED is off if you successfully completes the setting.

If you fail to set the above setting, follow below steps to set another setting.

Follow Step 1 to Step 6 in To disable the voicemail voltage detection above.

1. Disable voicemail signal to the telephone.

2. Press the recessed PROGRAM key.

3. Press 11 and you hear 3 beeps. Then press 2 (default 0) or 3 (default 1). You hear 3 rising beeps as conrmation. After about

15 seconds, if the MESSAGE WAITING LED is on, repeat the steps above to try another setting. After about 15 seconds, when the MESSAGE WAITING LED is off, enable voicemail signal to the telephone.

5. After about 15 seconds, when the MESSAGE WAITING LED is on, disable voicemail signal to the telephone. After about

15 seconds, the MESSAGE WAITING LED is off if you successfully completes the setting.

To set the voicemail voltage detection by the FSK detection method:

Follow Step 1 to Step 6 in To disable the voicemail voltage detection above.

1. Press the recessed PROGRAM key.

2. Press 12 and you hear 3 beeps. Then press 1 to enable the setting. You hear 3 rising beeps as conrmation.

Telephone settings

To set the voicemail voltage detection by the Siemens detection method:

Follow Step 1 to Step 6 in To disable the voicemail voltage detection above.

1. Disable voicemail signal to the telephone.

2. Press the recessed PROGRAM key.

3. Press 13 and you hear 3 beeps. Then press 1 (50Hz), 2 (25Hz) or 3 (20Hz). You hear 3 rising beeps as conrmation.

4. After about 15 seconds, when the MESSAGE WAITING LED is off, enable voicemail signal to the telephone. After about

15 seconds, if the MESSAGE WAITING LED is still off, repeat the steps above to try another setting. Disable voicemail signal to the telephone. After about 15 seconds, the MESSAGE WAITING LED is off if you successfully

6. completes the setting.

To set the voicemail voltage detection by the Panasonic detection method:

Follow Step 1 to Step 6 in To disable the voicemail voltage detection above.

1. Press the recessed PROGRAM key.

2. Press 14 and you hear 3 beeps. Then press 1 to enable the setting. You hear 3 rising beeps as conrmation.

Speed Dial keys

For an A2410/A2420 telephone base, there are up to 10 programmable guest-service (Speed Dial) keys. For a CTM-A2411/ CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT/CTM-A2510 telephone base, there are up to 11 programmable guest-service

(Speed Dial) keys. Program these keys to automatically dial telephone numbers or to activate telephone system features.

To program a Speed Dial key on the telephone base:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press the desired Speed Dial key where the telephone number is to be stored. You hear 3 beeps.

2. Enter the telephone number (up to 32 digits).

To insert a pause in the stored number, press the recessed PAUSE key.

•

The telephone stores the number automatically when 32 digits are entered. When the number has less than 32 digits, press the

recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

To clear the programmed Speed Dial key on the telephone base:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press the Speed Dial key where the telephone number is to be deleted. You hear 3 beeps. Press the recessed PROGRAM key

again. You hear 3 rising beeps as conrmation.

For a CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT/CTM-A2510/CTM-A241SD/CTM-A242SD/CTM-C4101/ CTM- C4201 cordless handset, there are 3 programmable keys. Program these keys to automatically dial telephone numbers or to

activate telephone system features.

To program the MESSAGES key on the cordless handset:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press 60 and you hear 3 beeps.

Enter the telephone number (up to 32 digits).

To insert a pause in the stored number, press the recessed PAUSE key.

•

The telephone stores the number automatically when 32 digits are entered. When the number has less than 32 digits, press the

recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

To clear the programmed MESSAGES key on the cordless handset:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

Press 60 and you hear 3 beeps.

Press the recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

Telephone settings

To program a Speed Dial key on the cordless handset:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

Press 61 or 62 for the desired Speed Dial key where the telephone number is to be stored (61 indicates the Speed Dial key

2. below REDIAL key and 62 indicates the Speed Dial key below MUTE key) and you hear 3 beeps.

Enter the telephone number (up to 32 digits).

To insert a pause in the stored number, press the recessed PAUSE key.

•

The telephone stores the number automatically when 32 digits are entered. When the number has less than 32 digits, press the

recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

To clear the programmed Speed Dial key:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

Press 61 or 62 for the desired Speed Dial key where the telephone number is to be deleted (61 indicates the Speed Dial key

below REDIAL key and 62 indicates the Speed Dial key below MUTE key) and you hear 3 beeps.

Press the recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

When a CTM-A241SD/CTM-A242SD/CTM-C4101/CTM-C4201 is registered to an A2410/A2420 telephone base, you can program these keys using the cordless handset.

To program the MESSAGES/Speed Dial key on a CTM-A241SD/CTM-A242SD/CTM-C4101/CTM-C4201 cordless handset:

Press 234 and then HOLD when the cordless handset is not in use.

Press the MESSAGES key or the desired Speed Dial key where the telephone number is to be stored. You hear 3 beeps.

Enter the telephone number (up to 32 digits).

To insert a pause in the stored number, press the recessed PAUSE key.

•

The telephone stores the number automatically when 32 digits are entered. When the number has less than 32 digits, press the

4. desired Speed Dial key where the telephone number is to be stored. You hear 3 rising beeps as conrmation.

Telephone settings

To clear the MESSAGES/Speed Dial key on a CTM-A241SD/CTM-A242SD/CTM-C4101/CTM-C4201 cordless handset:

Press 234 and then HOLD when the cordless handset is not in use.

Press the MESSAGES key or the desired Speed Dial key where the telephone number is to be deleted. You hear 3 rising beeps

as conrmation.

When a CTM-A241P/CTM-A242P is registered to a CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT/ CTM-A2510 telephone base, you can program these keys using the telephone base or share the same Speed Dial numbers with

the telephone base.

To enable the Speed Dial number sharing from the telephone base:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press 03 and you hear 3 beeps. Then press 1 to enable. You hear 3 rising beeps as conrmation.

If you program a different set of Speed Dial numbers to the accessory Petite, you must disable the Speed Dial number sharing before you can program the Speed Dial numbers.

To disable the Speed Dial number sharing from the telephone base:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press 03 and you hear 3 beeps. Then press 0 to disable. You hear 3 rising beeps as conrmation.

To program a Speed Dial key on a CTM-A241P/CTM-A242P cordless accessory Petite using the telephone base:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

1. Press 70-79 or 7* for the desired Speed Dial key where the telephone number is to be stored and you hear 3 beeps.

Enter the telephone number (up to 32 digits).

To insert a pause in the stored number, press the recessed PAUSE key.

•

The telephone stores the number automatically when 32 digits are entered. When the number has less than 32 digits, press the

recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

To clear the programmed Speed Dial key using the telephone base:

Remove the faceplate and overlay if they are on the telephone base. Then press the recessed PROGRAM key.

Press 70-79, or 7* for the desired Speed Dial key where the telephone number is to be deleted and you hear 3 beeps.

Press the recessed PROGRAM key again. You hear 3 rising beeps as conrmation.

Telephone operation

Analog corded lobby - A2100

Receive a call

The telephone rings when there is an incoming call. Lift the corded handset from the telephone base to answer.

Place a call

Lift the corded handset and it automatically connects to the operator. Refer to your PABX user’s manual for automatic dialing.

End a call

Place the corded handset in the telephone base.

Volume

Listening volume and ringer volume can be adjusted from the telephone base.

To adjust the listening volume: During a call, press +/VOLUME or -/VOLUME to adjust the listening volume. The next call returns to the default listening volume.

To adjust the ringer volume: At any time, slide the RINGER VOL switch on the right side of the telephone base to adjust the ringer volume.

Data port

You can connect your modem or fax machine to the telephone line through the DATA port.

Telephone operation

Analog corded 1-line - A2210

Using the corded handset and the telephone base

The corded handset and the telephone base speakerphone cannot be used at the same time. However, calls can be switched

between the corded handset and the telephone base speakerphone.

Receive a call

When there is an incoming call, the telephone rings and the MESSAGE WAITING LED ashes.

To answer a call using the corded handset:

Lift the corded handset from the telephone base.

To answer a call using the telephone base: On the telephone base, press /SPEAKER. The /SPEAKER key illuminates when in speakerphone mode.

Place a call

Lift the corded handset or press /SPEAKER on the telephone base. Listen for a dial tone and then dial the desired number, or press a Speed Dial key to dial a programmed number. The /SPEAKER key illuminates when in speakerphone mode.

End a call

Place the corded handset in the telephone base, or press /SPEAKER when in speakerphone mode.

Switch a call between the corded handset and the telephone base speakerphone

To switch a call from the corded handset to the telephone base speakerphone, press /SPEAKER on the telephone base, then

•

place the corded handset on the telephone base cradle.

To switch a call from the telephone base speakerphone to the corded handset currently on the telephone base cradle, lift the

•

corded handset from the telephone base cradle.

To switch a call from the telephone base speakerphone to the corded handset which is not on the telephone base cradle, press

•

/SPEAKER on the telephone base.

Share a call

During a call, parallel telephones (telephones on the same line) can join the call.

To join a call: During a call, lift the corded handset or press /SPEAKER to join.

Volume

Listening volume and ringer volume can be adjusted from the telephone base.

To adjust the listening volume: During a call, press +/VOLUME or -/VOLUME to adjust the listening volume. The next call returns to the default listening volume.

To adjust the ringer volume: At any time, slide the RINGER VOL switch on the right side of the telephone base to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the telephone base to put your current call on hold and take

1. the new incoming call.

Press FLASH or the switch hook once rapidly at any time to switch back and forth between calls.

Mute

To mute the microphone:

During a call, press MUTE on the telephone base. The MUTE key illuminates when the mute function is turned on. You can hear

1. the party on the other end but they cannot hear you.

Press MUTE again to resume the conversation. The light on the MUTE key turns off.

Telephone operation

Analog corded 1-line - A2210

Hold

When a call is placed on hold, any parallel phone that tries to use the same phone line will take the call off hold and pick the call.

To place a call on hold:

During a call, press HOLD on the telephone base to place that call on hold. The HOLD key ashes when the call is placed

1. on hold.

To release the call from hold, press /SPEAKER, HOLD or lift the handset from the telephone base cradle.

Data port

You can connect your modem or fax machine to the telephone line through the DATA port.

Telephone operation

Analog corded 2-line - A2220

Using the corded handset and the telephone base

The corded handset and the telephone base speakerphone cannot be used at the same time. However, calls can be switched

between the corded handset and the telephone base speakerphone.

Receive a call

When there is a line 1 incoming call, the telephone rings. The MESSAGE WAITING LED and LINE 1 key ash.

•

When there is a line 2 incoming call, the telephone rings. LINE 2 key ashes.

•

To answer a call using the corded handset:

Lift the cordless handset. It automatically connects to the ringing line. The respective line key illuminates when in use.

To answer a call using the telephone base:

Press the ashing line key for the ringing line, or press /SPEAKER. It automatically connects to the ringing line. The respective line key and the /SPEAKER key illuminate when in use.

Place a call

Lift the corded handset, or press LINE 1, LINE 2, or /SPEAKER on the telephone base. Listen for a dial tone and then dial the desired number, or press a Speed Dial key to dial a programmed number. The respective line key illuminates when in use. The

/SPEAKER key illuminates when in speakerphone mode.

End a call

Place the corded handset in the telephone base, or press /SPEAKER or the active line key when in speakerphone mode.

Switch a call between the corded handset and the telephone base speakerphone

To switch a call from the corded handset to the telephone base speakerphone, press /SPEAKER on the telephone base,

•

then place the corded handset on the telephone base cradle. The active line is selected. When both lines are in use or on hold, LINE 1 is selected.

To switch a call from the telephone base speakerphone to the corded handset currently on the telephone base cradle, lift the

•

corded handset from the telephone base cradle. The active line is selected. When both lines are in use or on hold, LINE 1 is selected.

To switch a call from the telephone base speakerphone to the corded handset which is not on the telephone base cradle, press

•

/SPEAKER on the telephone base. The active line is selected. When both lines are in use or on hold, LINE 1 is selected.

Share a call

During a call, parallel telephones (telephones on the same line) can join the call.

To join a call: During a call on line 1 or line 2, press the respective LINE 1 or LINE 2 key to join.

Speakerphone

When the telephone is idle, press /SPEAKER. The rst available line is selected, starting with line 1.

• During a call on the handset, press /SPEAKER. The active line is selected. When both lines are in use or on hold, LINE 1

•

is selected.

Volume

Listening volume and ringer volume can be adjusted from the telephone base.

To adjust the listening volume: During a call, press +/VOLUME or -/VOLUME to adjust the listening volume. The next call returns to the default listening volume.

Telephone operation

To adjust the ringer volume: At any time, slide the RINGER VOL switch on the right side of the telephone base to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the telephone base to put your current call on hold and take the

1. new incoming call.

Press FLASH or the switch hook once rapidly at any time to switch back and forth between calls.

Telephone operation

Analog corded 2-line - A2220

Mute

To mute the microphone:

During a call, press MUTE on the telephone base. The MUTE key illuminates when the mute function is turned on. You can hear

the party on the other end but they cannot hear you. Press MUTE again to resume the conversation. The light on the MUTE key turns off.

Hold

When a call is placed on hold, any parallel phone that tries to use the same phone line will take the call off hold and pick the call.

To place a call on hold:

During a call, press HOLD on the telephone base to place that call on hold. The respective line key ashes when the call is

1. placed on hold.

Press the ashing line key or /SPEAKER to release the call from hold. The respective line key illuminates when in use. When

both lines are on hold, press /SPEAKER releases the call on line 1.

Conference call

This telephone allows three-way conversations.

To initiate a conference call:

Place a call to the rst party.

1. Press HOLD to place the rst party on hold.

2. Place a second call on the other line.

3. Once the second party is on the line, press CONF to start a three-way conference.

To initiate a conference call while both calls are on hold: Press CONF to start a three-way conference.

To end a conference call:

Press a line key to maintain the connection with that line and drop the other line.

• When the conference call is in speakerphone mode, press CONF or /SPEAKER on the telephone base to end.

•

When the conference call is in handset earpiece mode, place the corded handset back in the telephone base to end.

•

When there is more than one telephone on the conference call, the call ends when all telephones hang up.

•

Data port

You can connect your modem or fax machine to the telephone line through the DATA port. The data port routes to line 2.

Telephone operation

Analog corded trimstyle - A2310

Receive a call

When there is an incoming call, the telephone rings and the MESSAGE WAITING LED ashes.

To answer a call:

Lift the corded handset from the telephone base.

Place a call

Lift the corded handset from the telephone base. Listen for a dial tone and then dial the desired number.

End a call

Place the corded handset in the telephone base.

Share a call

During a call, parallel telephones (telephones on the same line) can join the call. If the parallel telephone is a 2-line model, this telephone can only share call on one of the lines.

To join a call:

During a call, lift the corded handset to join.

Volume

Listening volume and ringer volume can be adjusted.

To adjust the listening volume: During a call, press -/VOLUME/+ to adjust the listening volume. The next call returns to the default listening volume.

To adjust the ringer volume: At any time, slide the RINGER VOL switch on the right side of the telephone base to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the handset to put your current call on hold and take the new

1. incoming call.

Press FLASH or the switch hook once rapidly at any time to switch back and forth between calls.

Mute

To mute the microphone:

During a call, press MUTE on the handset. The MUTE LED ashes when the mute function is turned on. You can hear the party

1. on the other end but they cannot hear you.

Press any key to resume the conversation. The MUTE LED turns off.

Data port

You can connect your modem or fax machine to the telephone line through the FAX/DATA port.

Telephone operation

Analog cordless 1-line - A2410/CTM-A2411/CTM-A2411-BATT

Using the cordless handset and the telephone base

The cordless handset and the telephone base cannot be used on the same call. However, calls can be switched between the cordless handset and the telephone base speakerphone.

When the cordless handset or the telephone base is in use, the TALK key on the cordless handset and the IN USE LED on the

telephone base illuminate.

Receive a call

When there is an incoming call, the telephone rings. The IN USE LED and the MESSAGE WAITING LED on the telephone base ash, and the TALK key on the cordless handset ashes.

To answer a call using the cordless handset while it is not on the telephone base, charging base or charging stand:

On the cordless handset, press TALK or /SPEAKER. The TALK key illuminates when in use. The /SPEAKER key illuminates when in speakerphone mode.

To answer a call using the cordless handset while it is resting on the telephone base, charging base or charging stand: Lift the cordless handset from the telephone base, charging base or charging stand. The TALK key illuminates when in use. The

/SPEAKER key illuminates when in speakerphone mode.

To answer a call using the telephone base: On the telephone base, press /SPEAKER. The IN USE LED and the /SPEAKER key illuminate when in use.

Place a call

To place a call using the A2410 cordless handset:

On the cordless handset, press TALK or /SPEAKER. Listen for a dial tone and then dial the desired number, or press a Speed Dial key on the telephone base to dial a programmed number. The TALK key illuminates when in use. The /SPEAKER key illuminates when in speakerphone mode.

To place a call using the CTM-A2411/CTM-A2411-BATT cordless handset:

On the cordless handset, press TALK or /SPEAKER. Listen for a dial tone and then dial the desired number, or press a Speed Dial key on the telephone base or cordless handset to dial a programmed number. The TALK key illuminates when in use.

The /SPEAKER key illuminates when in speakerphone mode.

To place a call using the telephone base:

On the telephone base, press /SPEAKER. Listen for a dial tone and then dial the desired number, or press a Speed Dial key to dial a programmed number. The IN USE LED and the /SPEAKER key illuminate when in use.

End a call

To end a call when using the cordless handset:

Press OFF on the cordless handset or place it in the telephone base, charging base or charging stand. The call ends when all handsets hang up.

To end a call when using the telephone base: Press /SPEAKER.

Switch a call between the cordless handset and the telephone base speakerphone

To switch a call from the cordless handset to the telephone base speakerphone, press /SPEAKER on the telephone base.

• To switch a call from the telephone base speakerphone to the cordless handset which is not on the telephone base cradle,

• press TALK or /SPEAKER on the cordless handset.

To switch a call from the telephone base speakerphone to the cordless handset currently on the telephone base cradle, lift the

•

cordless handset from the telephone base.

Share a call

A maximum of four cordless handsets or accessory Petites can be used at the same time on an external call.

To join a call:

During a call, press TALK or /SPEAKER on another cordless handset to join.

Telephone operation

Analog cordless 1-line - A2410/CTM-A2411/CTM-A2411-BATT

Handset speakerphone

During a call, press /SPEAKER on the cordless handset to switch between speakerphone mode and handset earpiece mode.

Redial

The last dialed number on the cordless handset or the telephone base is stored for 15 minutes.

To redial the last dialed number from the cordless handset: Press TALK or /SPEAKER. Listen for a dial tone. Then press REDIAL.

To redial the last dialed number from the telephone base: Press /SPEAKER. Listen for a dial tone. Then press REDIAL.

Volume

Listening volume can be adjusted on the cordless handset and the telephone base.

To adjust the listening volume:

During a call on the handset, press -/VOLUME/+ on it to adjust the listening volume. The next call returns to the default

•

listening volume.

During a call on the telephone base, press +/VOLUME or -/VOLUME on it to adjust the listening volume. The next call returns to

•

the default listening volume.

Ringer volume of the telephone base can be adjusted.

To adjust the ringer volume of the telephone base: When the telephone base is idle, press +/VOLUME or -/VOLUME on it to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the cordless handset or telephone base to put the current call

on hold and take the new incoming call. Press FLASH at any time to switch back and forth between calls.

Mute

To mute the microphone:

During a call, press MUTE on the cordless handset or telephone base. The MUTE key illuminates when the mute function is

1. turned on. You can hear the party on the other end but they cannot hear you.

Press MUTE again to resume the conversation. The light on the MUTE key turns off.

Hold

When a call is placed on hold, any parallel phone that tries to use the same phone line will take the call off hold and pick the call.

To place a call on hold on the cordless handset:

During a call, press HOLD on the cordless handset. The TALK key on the cordless handset and the HOLD key on the

1. telephone base ash when the call is on hold.

Press TALK or /SPEAKER to release the call from hold, or the call will end automatically after the preset call on hold duration.

To place a call on hold on the telephone base:

During a call, press HOLD on the telephone base. The HOLD key ashes when the call is on hold.

1. Press /SPEAKER to release the call from hold, or the call will end automatically after the preset call on hold duration.

Telephone operation

Analog cordless 1-line - A2410/CTM-A2411/CTM-A2411-BATT

Intercom (for A2410 only)

Use this feature for conversations between two cordless handsets, or a cordless handset and the telephone base.

To initiate an intercom call:

On the cordless handset, press INTERCOM when it is not in use. It beeps and the INTERCOM key illuminates. All destination

• cordless handsets (except the cordless handset on the telephone base) and the telephone base ring, and the INTERCOM/INT keys ash.

-OR-

On the telephone base, press INT when it is not in use. It beeps and the INT key illuminates. All destination cordless handsets

•

(except the cordless handset on the telephone base) ring and the INTERCOM keys ash.

To initiate an intercom call during a call:

During a call on the cordless handset, press HOLD to put the current call on hold. Then press INTERCOM. It beeps and the

•

INTERCOM key illuminates. All destination cordless handsets (except the cordless handset on the telephone base) and the telephone base ring, and the INTERCOM/INT keys ash.

-OR-

During a call on the telephone base, press HOLD to put the current call on hold. Then press INT. It beeps and the INT key

• illuminates. All destination cordless handsets (except the cordless handset on the telephone base) ring and the

INTERCOM keys ash.

To answer an intercom call:

Lift the cordless handset from the telephone base cradle, or press INTERCOM or /SPEAKER on the cordless handset.

•

-OR-

Press INT or /SPEAKER on the telephone base.

•

To answer an incoming call during an intercom call: Press TALK on the cordless handset or press /SPEAKER twice on the telephone base. The intercom call ends automatically.

To end an intercom call:

Place the cordless handset in the telephone base cradle, or press OFF on the cordless handset.

•

-OR-

Press INT or /SPEAKER on the telephone base.

•

Find handset

Use this feature to nd all registered cordless handsets.

To start paging:

Press /FIND HANDSET on the telephone base when the telephone is not in use. All idle cordless handsets beep for 60 seconds.

To end paging:

Press /FIND HANDSET again on the telephone base.

•

-OR-

Press any key on the cordless handset to stop the paging tone.

•

Data port

You can connect your modem or fax machine to the telephone line through the DATA port.

Telephone operation

Analog cordless 1-line accessory Petite - CTM-A241P

Receive a call

When there is an incoming call, the telephone rings. The IN USE LED ashes.

To answer a call: Lift the corded handset from the accessory phone base. The IN USE LED illuminates.

Place a call

Lift the corded handset. Listen for a dial tone and then dial the desired number, or press a Speed Dial key to dial a programmed number. The IN USE LED illuminates.

End a call

Place the corded handset back to the phone cradle.

Switch a call between the accessory Petite and the telephone base speakerphone

To switch a call from the accessory Petite to the telephone base speakerphone, press /SPEAKER on the telephone base.

• To switch a call from the telephone base speakerphone to the accessory Petite, lift the corded handset from the accessory

•

phone base.

Share a call

A maximum of four cordless handsets or accessory Petite phones can be used at the same time on an external call.

To join a call:

During a call, lift the corded handset to join.

Volume

Listening volume and ringer volume can be adjusted from the accessory phone base.

To adjust the listening volume: During a call, press +/VOLUME or -/VOLUME to adjust the listening volume. The next call returns to the default listening volume.

To adjust the ringer volume: At any time, slide the RINGER VOL switch on the right side of the accessory phone base to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the accessory phone base to put your current call on hold and

1. take the new incoming call.

Press FLASH or the switch hook once rapidly at any time to switch back and forth between calls.

Mute

To mute the microphone:

During a call, press MUTE on the accessory Petite. The MUTE key illuminates when the mute function is turned on. You can

1. hear the party on the other end but they cannot hear you.

Press MUTE again to resume the conversation. The light on the MUTE key turns off.

Hold

When a call is placed on hold, any parallel phone that tries to use the same phone line will take the call off hold and pick the call.

To place a call on hold:

During a call, press HOLD on the accessory Petite to place that call on hold. The IN USE LED ashes when the call is placed

1. on hold.

To release the call from hold, press the switch hook once rapidly.

Telephone operation

USB port

The port on the side of the accessory Petite can be used for charging devices (up to 1A @ 5.1V).

Telephone operation

Analog cordless 2-line - A2420/CTM-A2421/CTM-A2421-BATT

Using the cordless handset and the telephone base

The cordless handset and the telephone base cannot be used on the same call. However, calls can be switched between the cordless handset and the telephone base speakerphone.

When the cordless handset or the telephone base is in use, the corresponding line keys on the cordless handset and the telephone

base illuminate.

Receive a call

When there is an incoming call, the telephone rings. The corresponding line key and the MESSAGE WAITING LED on the telephone base ash, and the corresponding line key on the cordless handset ashes.

To answer a call using the cordless handset while it is not on the telephone base, charging base or charging stand:

On the cordless handset, press the ashing line key for the ringing line, or press /SPEAKER. It automatically connects to the ringing line. The respective line key illuminates when in use. The /SPEAKER key illuminates when in speakerphone mode.

To answer a call using the cordless handset while it is resting on the telephone base, charging base or charging stand:

Pick up the cordless handset from the telephone base. It automatically connects to the ringing line. The respective line key

illuminates when in use.

To answer a call using the telephone base:

On the telephone base, press the ashing line key for the ringing line, or press /SPEAKER. It automatically connects to the ringing line. The respective line key and the /SPEAKER key illuminate when in use.

Place a call

To place a call using the A2420 cordless handset:

On the cordless handset, press LINE 1, LINE 2 or /SPEAKER. Listen for a dial tone and then dial the desired number, or press a Speed Dial key on the telephone base to dial a programmed number. The line key illuminates when in use. The /SPEAKER key illuminates when in speakerphone mode.

To place a call using the CTM-A2421/CTM-A2421-BATT cordless handset:

On the cordless handset, press LINE 1, LINE 2 or /SPEAKER. Listen for a dial tone and then dial the desired number, or press a Speed Dial key on the telephone base or cordless handset to dial a programmed number. The line key illuminates when in use. The

/SPEAKER key illuminates when in speakerphone mode.

To place a call using the telephone base:

On the telephone base, press LINE 1, LINE 2 or /SPEAKER. Listen for a dial tone and then dial the desired number, or press a Speed Dial key to dial a programmed number. The line key and the /SPEAKER key illuminate when in use.

End a call

To end a call when using the cordless handset:

Press OFF on the cordless handset or place it in the telephone base, charging base or charging stand. The call ends when all handsets hang up.

To end a call when using the telephone base: Press /SPEAKER or the respective line key on the telephone base.

Switch a call between the cordless handset and the telephone base speakerphone

To switch a call from the cordless handset to the telephone base speakerphone, press the respective line key or /SPEAKER

•

on the telephone base.

To switch a call from the telephone base speakerphone to the cordless handset which is not on the telephone base cradle, press

• the respective line key or /SPEAKER on the cordless handset.

To switch a call from the telephone base speakerphone to the cordless handset currently on the telephone base cradle, lift the

•

cordless handset from the telephone base.

Share a call

A maximum of four cordless handsets or accessory Petite phones can be used at the same time on an external call. If both lines are in use, a maximum of three cordless handsets or accessory Petite phones can be used on one line and the fourth handset or accessory Petite phone can be used on the other line at the same time.

To join a call: During a call on line 1 or line 2, press the respective LINE 1, LINE 2 or /SPEAKER on another cordless handset to join.

Handset speakerphone

During a call on the handset, press /SPEAKER on the cordless handset to switch between speakerphone mode and handset

earpiece mode.

Telephone operation

Analog cordless 2-line - A2420/CTM-A2421/CTM-A2421-BATT

Speakerphone

When the telephone is idle, press /SPEAKER on the cordless handset or the telephone base. The rst available line is selected, starting with line 1.

Redial

The last dialed number on the cordless handset or telephone base is stored for 15 minutes.

To redial the last dialed number from the handset or telephone base: Press LINE 1, LINE 2 or /SPEAKER. Listen for a dial tone. Then press REDIAL.

Volume

Listening volume can be adjusted on the cordless handset and the telephone base.

To adjust the listening volume:

During a call on the handset, press -/VOLUME/+ on it to adjust the listening volume. The next call returns to the default

•

listening volume.

During a call on the telephone base, press +/VOLUME or -/VOLUME on it to adjust the listening volume. The next call returns to

•

the default listening volume.

Ringer volume of the telephone base can be adjusted.

To adjust the ringer volume of the telephone base: When the telephone base is idle, press +/VOLUME or -/VOLUME on it to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the cordless handset or telephone base to put the current call

1. on hold and take the new incoming call.

Press FLASH at any time to switch back and forth between calls.

Mute

To mute the microphone:

During a call, press MUTE on the cordless handset or telephone base. The MUTE key illuminates when the mute function is

1. turned on. You can hear the party on the other end but they cannot hear you.

Press MUTE again to resume the conversation. The light on the MUTE key turns off.

Hold

When a call is placed on hold, any parallel phone that tries to use the same phone line will take the call off hold and pick the call.

To place a call on hold:

During a call, press HOLD on the cordless handset or telephone base to place that call on hold. The corresponding line key

1. ashes when the call is on hold.

Press the ashing line key or /SPEAKER to release the call from hold, or the call will end automatically after the preset call on

2. hold duration. When both lines are on hold, press /SPEAKER releases the call on line 1.

Intercom (for A2420 only)

To initiate an intercom call:

On the cordless handset, press INTERCOM when it is not in use. It beeps and the INTERCOM key illuminates. All destination

•

cordless handsets (except the cordless handset on the telephone base) and the telephone base ring, and the INTERCOM/INT keys ash.

-OR-

On the telephone base, press INT when it is not in use. It beeps and the INT key illuminates. All destination cordless handsets

•

(except the cordless handset on the telephone base) ring and the INTERCOM keys ash.

Telephone operation

To initiate an intercom call during a call:

During a call on the cordless handset, press HOLD to put the current call on hold. Then press INTERCOM. It beeps and the

• INTERCOM key illuminates. All destination cordless handsets (except the cordless handset on the telephone base) and the

telephone base ring, and the INTERCOM/INT keys ash.

-OR-

During a call on the telephone base, press HOLD to put the current call on hold. Then press INT. It beeps and the INT key illuminates.

•

All destination cordless handsets (except the cordless handset on the telephone base) ring and the INTERCOM keys ash.

Telephone operation

Analog cordless 2-line - A2420/CTM-A2421/CTM-A2421-BATT

To answer an intercom call:

Lift the cordless handset from the telephone base cradle, or press INTERCOM on the cordless handset.

•

-OR-

Press INT or /SPEAKER on the telephone base.

•

To answer an incoming call during an intercom call:

Press the ashing line key on the cordless handset or telephone base, or press /SPEAKER twice on the telephone base. The intercom call ends automatically.

To end an intercom call:

Place the cordless handset on the telephone base cradle, or press OFF on the cordless handset.

•

-OR-

Press INT on the telephone base.

•

Conference call

This telephone allows three-way conversations.

To initiate a conference call:

Place a call to the rst party.

1. Press HOLD to place the rst party on hold.

2. Place a second call on the other line.

3. Once the second party is on the line, press CONF to start a three-way conference.

To initiate a conference call while both calls are on hold: Press CONF to start a three-way conference.

To switch a conference call from the telephone base to the cordless handset:

During a conference call on the telephone base, press /SPEAKER or CONF on the cordless handset, or lift the cordless

•

handset from the telephone base.

During a conference call on the telephone base, press HOLD on the telephone base and then press CONF on the

•

cordless handset.

To switch a conference call from the cordless handset to the telephone base:

During a conference call on the cordless handset, press /SPEAKER or CONF on the telephone base.

• During a conference call on the cordless handset, press HOLD on the cordless handset and then press CONF on

• the telephone base.

To end a conference call:

Press a line key to maintain the connection with that line and drop the other line.

• When the conference call is at the telephone base, press /SPEAKER or CONF on the telephone base.

• When the conference call is on the cordless handset, press OFF on the cordless handset, or place it back in the telephone base,

• charging base or charging stand.

When there is more than one cordless handset on the conference call, the call ends when all handsets hang up.

•

Find handset

Use this feature to nd all registered cordless handsets.

To start paging: Press /FIND HANDSET on the telephone base when the telephone is not in use. All idle cordless handsets beep for 60 seconds.

To end paging:

Press /FIND HANDSET again on the telephone base.

•

-OR-

Press any key on the handset to stop the paging tone.

•

Data port

You can connect your modem or fax machine to the telephone line through the DATA port. The data port routes to line 2.

Telephone operation

Analog cordless 2-line accessory Petite - CTM-A242P

Receive a call

When there is a line 1 incoming call, the telephone rings. The LINE 1 key ashes.

•

When there is a line 2 incoming call, the telephone rings. The LINE 2 key ashes.

•

To answer a call:

Lift the corded handset. It automatically connects to the ringing line. The respective line key illuminates when in use.

Place a call

Lift the corded handset then press LINE 1 or LINE 2. Listen for a dial tone and then dial the desired number, or press a Speed Dial key to dial a programmed number. The respective line key illuminates when in use.

End a call

Place the corded handset back to the phone cradle.

Switch a call between the accessory Petite and the telephone base speakerphone

To switch a call from the accessory Petite to the telephone base speakerphone, press /SPEAKER on the telephone base.

• To switch a call from the telephone base speakerphone to the accessory Petite, lift the corded handset from the accessory

•

phone base.

Share a call

A maximum of four cordless handsets or accessory Petite phones can be used at the same time on an external call.

To join a call:

During a call on line 1 or line 2, press the respective LINE 1 or LINE 2 key to join.

Volume

Listening volume and ringer volume can be adjusted from the accessory phone base.

To adjust the listening volume: During a call, press +/VOLUME or -/VOLUME to adjust the listening volume. The next call returns to the default listening volume.

To adjust the ringer volume: At any time, slide the RINGER VOL switch on the right side of the accessory Petite to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the accessory Petite to put your current call on hold and take

1. the new incoming call.

Press FLASH or the switch hook once rapidly at any time to switch back and forth between calls.

Mute

To mute the microphone:

During a call, press MUTE on the accessory Petite. The MUTE key illuminates when the mute function is turned on. You can

hear the party on the other end but they cannot hear you. Press MUTE again to resume the conversation. The light on the MUTE key turns off.

Hold

When a call is placed on hold, any parallel phone that tries to use the same phone line will take the call off hold and pick the call.

To place a call on hold:

During a call, press HOLD on the accessory Petite to place that call on hold. The respective line key ashes when the call is

1. placed on hold.

Press the ashing line key to release the call from hold. The respective line key illuminates when in use.

Telephone operation

Analog cordless 2-line accessory Petite- CTM-A242P

Conference call

This telephone allows three-way conversations.

To initiate a conference call:

Place a call to the rst party.

1. Press HOLD to place the rst party on hold.

2. Place a second call on the other line.

3. Once the second party is on the line, press CONF to start a three-way conference.

To initiate a conference call while both calls are on hold: Press CONF to start a three-way conference.

To end a conference call:

Press a line key to maintain the connection with that line and drop the other line.

• Place the corded handset back in the accessory phone base to end.

• When there is more than one phone devices on the conference call, the call ends when all phone devices hang up.

•

USB port

The port on the side of the accessory phone base can be used for charging devices (up to 1A @ 5.1V).

Telephone operation

Analog corded/cordless 1-line - CTM-A2510

Using the corded handset, cordless handset and the telephone base

The corded handset, cordless handset and the telephone base cannot be used on the same call. However, calls can be switched

among the corded handset, cordless handset and the telephone base speakerphone. When the corded handset, cordless handset or the telephone base is in use, the TALK key on the cordless handset and the IN USE

LED on the telephone base illuminate.

Receive a call

When there is an incoming call, the telephone rings. The IN USE LED and the MESSAGE WAITING LED on the telephone base ash, and the TALK key on the cordless handset ashes.

To answer a call using the corded handset: Lift the corded handset from the telephone base. The IN USE LED on the telephone base illuminates.

To answer a call using the cordless handset while it is not on the charging base or charging stand:

On the cordless handset, press TALK or /SPEAKER. The TALK key illuminates when in use. The /SPEAKER key illuminates when in speakerphone mode.

To answer a call using the cordless handset while it is resting on the charging base or charging stand:

Lift the cordless handset from the charging base or charging stand. The TALK key illuminates when in use. The /SPEAKER key illuminates when in speakerphone mode.

To answer a call using the telephone base: On the telephone base, press /SPEAKER. The IN USE LED and the /SPEAKER key illuminate when in use.

Place a call

To place a call using the corded handset:

Lift the corded handset from the telephone base. Listen for a dial tone and then dial the desired number, or press a Speed Dial key on the telephone base or cordless handset to dial a programmed number. The IN USE key illuminates when in use.

To place a call using the cordless handset:

The /SPEAKER key illuminates when in speakerphone mode.

To place a call using the telephone base:

End a call

To end a call when using the corded handset:

Place the corded handset in the telephone base. The call ends when all handsets hang up.

To end a call when using the cordless handset: Press OFF on the cordless handset or place it in the charging base or charging stand. The call ends when all handsets hang up.

To end a call when using the telephone base: Press /SPEAKER.

Switch a call among the corded handset, cordless handset and the telephone base speakerphone

To switch a call from the corded or cordless handset to the telephone base speakerphone, press /SPEAKER on the

•

telephone base.

To switch a call from the telephone base speakerphone to the cordless handset which is not on the charging base or charging

• stand, press TALK or /SPEAKER on the cordless handset.

To switch a call from the telephone base speakerphone to the corded handset, lift the corded handset from the telephone base.

•

Telephone operation

Share a call

A maximum of four cordless handsets or accessory Petite phones can be used at the same time on an external call.

To join a call:

During a call, press TALK or /SPEAKER on another cordless handset to join.

Telephone operation

Analog corded/cordless 1-line - CTM-A2510

Handset speakerphone

During a call, press /SPEAKER on the cordless handset to switch between speakerphone mode and handset earpiece mode.

Redial

The last dialed number on the cordless handset or the telephone base is stored for 15 minutes.

To redial the last dialed number from the corded handset: Lift the corded handset from the telephone base. Listen for a dial tone. Then press REDIAL.

To redial the last dialed number from the cordless handset: Press TALK or /SPEAKER. Listen for a dial tone. Then press REDIAL.

To redial the last dialed number from the telephone base: Press /SPEAKER. Listen for a dial tone. Then press REDIAL.

Volume

Listening volume can be adjusted on the cordless handset and the telephone base.

To adjust the listening volume:

During a call on the handset, press -/VOLUME/+ on it to adjust the listening volume. The next call returns to the default

•

listening volume.

During a call on the telephone base, press +/VOLUME or -/VOLUME on it to adjust the listening volume. The next call returns to

•

the default listening volume.

Ringer volume of the telephone base can be adjusted.

To adjust the ringer volume of the telephone base: When the telephone base is idle, press +/VOLUME or -/VOLUME on it to adjust the ringer volume.

Call waiting

When you hear a call waiting tone during a call, press FLASH on the cordless handset or telephone base to put the current call

on hold and take the new incoming call. Press FLASH or the switch hook once rapidly at any time to switch back and forth between calls.

Mute

To mute the microphone:

During a call, press MUTE on the cordless handset or telephone base. The MUTE key illuminates when the mute function is

1. turned on. You can hear the party on the other end but they cannot hear you.

Press MUTE again to resume the conversation. The light on the MUTE key turns off.

Hold

When a call is placed on hold, any parallel phone that tries to use the same phone line will take the call off hold and pick the call.

To place a call on hold on the cordless handset:

During a call, press HOLD on the cordless handset. The TALK key on the cordless handset and the HOLD key on the

1. telephone base ash when the call is on hold.

Press TALK or /SPEAKER to release the call from hold, or the call will end automatically after the preset call on hold duration.

To place a call on hold on the telephone base:

During a call, press HOLD on the telephone base. The HOLD key ashes when the call is on hold.

1. Press /SPEAKER to release the call from hold, or the call will end automatically after the preset call on hold duration.

Telephone operation

Analog corded/cordless 1-line - CTM-A2510

Find handset

Use this feature to nd all registered cordless handsets.

To start paging:

Press FIND HANDSET on the telephone base when the telephone is not in use. All idle cordless handsets beep for 60 seconds.

To end paging:

Press FIND HANDSET again on the telephone base.

•

-OR-

Press any key on the cordless handset to stop the paging tone.

•

Data port

You can connect your modem or fax machine to the telephone line through the DATA port.

Telephone operation

Appendix

Handset battery

It takes up to 16 hours for the battery to be fully charged. When it is fully charged, you can expect the following performance:

Operation Operating time

While in handset use (talking*) Up to 7 hours

While in speakerphone mode (talking*) Up to 5 hours

While not in use (standby**) Up to 7 days

* Operating times vary depending on your actual use and the age of the battery.

** Handset is not charging or in use.

The battery needs charging when:

A new battery is installed in the handset.

•

LOW BATTERY LED ashes on the cordless handset.

•

CAUTION:

To reduce the risk of re or injury, read and follow these instructions:

Use only the supplied rechargeable battery (BT264392/BT266342) or replacement battery (BT266342). To order a replacement,

•

visit our website at www.vtechhotelphones.com or call 1-888-907-2007.

Do not dispose of the battery in a re. Check with local waste management codes for special disposal instructions.

•

Do not open or mutilate the battery. Released electrolyte is corrosive and may cause burns or injury to the eyes or skin. The

•

electrolyte may be toxic if swallowed.

Exercise care in handling the battery in order not to create a short circuit with conductive materials.

•

Charge the battery provided with or identied for use with this product only in accordance with the instructions and limitations

•

specied in this manual.

Observe proper polarity orientation between the battery and metallic contacts.

•

To prevent re or shock hazard, do not expose this product to water or any type of moisture.

•

Appendix

Troubleshooting

If you have difculty with the telephones, please try the suggestions below. For customer service, visit our website at www.vtechhotelphones.com or call 1-888-907-2007.

For corded telephones:

The telephone does not work at all.

Make sure the telephone line is plugged into the TEL port of the telephone base.

•

Make sure the telephone line cord is plugged rmly into the telephone wall jack.

•

Disconnect the telephone base from the telephone wall jack and plug in a working telephone. If the other telephone does not

•

work, the problem is probably in the wiring or telephone service. Contact your telephone service provider (charges may apply).(charges may apply)..

There is no dial tone.

Try all the above suggestions.

•

The telephone line cord may be defective. Install a new telephone line cord.

•

Disconnect the telephone base from the telephone wall jack and connect a different telephone. If there is no dial tone on this

•

telephone either, the problem is in your wiring or telephone service. Contact your telephone service provider (charges(charges may apply)..

I cannot dial out.

Try all the above suggestions.

•

Make sure there is a dial tone before dialing.

•

Eliminate any background noise. Mute the telephone before dialing, if applicable, or dial from another room in your unit with less

•

background noise. If other telephones in your hotel are having the same problem, the problem is in the wiring or telephone service. Contact your

•

telephone service provider (charges may apply).

The telephone does not ring when there is an incoming call.

Make sure the telephone line cord is plugged in properly (pages 25, 27 and 41).

•

If other telephones in your hotel are having the same problem, the problem is in the wiring or telephone service. Contact your

•

telephone service provider (charges may apply). Test a working telephone at the telephone wall jack. If another telephone has the same problem, the problem is in the telephone

•

wall jack. Contact your telephone service provider (charges may apply). The telephone line cord may be defective. Install a new telephone line cord.

•

There is interference during a telephone conversation.

If there is High Speed Internet Access (HSIA) available at the premises through a telephone line, you may need to install a DSL

•

lter (DSL - digital subscriber line) between the telephone line cord and the telephone wall jack. The lter prevents noise and caller ID problems caused by DSL interference. Contact your DSL service provider for more information about DSL lters.

If your telephone is plugged in with a modem or a surge protector, plug the telephone (or modem/surge protector) into a different

•

location. If this doesn’t solve the problem, relocate your telephone or modem farther apart from each other, or use a different surge protector.

Disconnect the telephone base from the telephone wall jack. Plug in a different telephone. If calls are still not clear, the problem is

•

probably in the wiring or local telephone service. Contact your telephone service provider (charges may apply). If other telephones in your hotel are having the same problem, the problem is in the wiring or telephone service. Contact your

•

telephone service provider (charges may apply).

I hear other calls when using the telephone.

Disconnect the telephone base from the telephone wall jack. Plug in a different telephone. If you still hear other calls, the problem

•

is probably in the wiring or telephone service. Contact your telephone service provider (charges may apply).

Appendix

Troubleshooting

For cordless telephones:

The telephone does not work at all.

Make sure the RJ-45 cord is plugged into the TEL port of the telephone base.

•

Make sure the power adapter is securely plugged into an outlet not controlled by a wall switch.

•

Make sure the telephone line cord is plugged rmly into the power adapter and the telephone wall jack.

•

Make sure the battery is installed and charged correctly (pages 34, 36 and 43). For optimum daily performance, return the

•

cordless handset to the telephone base, charging base or charging stand after use.

Unplug the electrical power to the telephone base. Wait for approximately 15 seconds, then plug it back in. Allow up to one minute

•

for the cordless handset and telephone base to synchronize. Charge the battery in the cordless handset for up to 16 hours.

•

If the battery is completely depleted, it may take up to 30 minutes to charge the cordless handset before the LOW BATTERY LED

•

ashes on the cordless handset. Remove and install the battery again. If that still does not work, it may be necessary to purchase a new battery.

•

Disconnect the telephone base from the telephone wall jack and plug in a working telephone. If the other telephone does not

•

work, the problem is probably in the wiring or telephone service. Contact your telephone service provider (charges may apply).

There is no dial tone.

Try all the above suggestions.

•

Move the cordless handset closer to the telephone base or adjust the setting of RF transmission power (page 56). It may be out

•

of range. The telephone line cord may be defective. Install a new telephone line cord.

•

Disconnect the telephone base from the telephone wall jack and connect a different telephone. If there is no dial tone on this

•

telephone either, the problem is in your wiring or telephone service. Contact your telephone service provider (charges may apply).

I cannot dial out.

Try all the above suggestions.

•

Make sure there is a dial tone before dialing. It is normal if the cordless handset takes a second or two to synchronize with the

•

telephone base before producing a dial tone. Wait an extra second before dialing. Eliminate any background noise. Mute the telephone before dialing, or dial from another room in your unit with less

•

background noise. If other telephones in your hotel are having the same problem, the problem is in the wiring or telephone service. Contact your

•

telephone service provider (charges may apply).

The LOW BATTERY LED ashes on the cordless handset.

Place the cordless handset in the telephone base, charging base or charging stand for recharging.

•

Remove and install the battery again and use it until fully depleted, then charge the cordless handset in the telephone base,

•

charging base or charging stand for up to 16 hours. If the above measures do not correct the problem, replace the battery.

•

The battery does not charge in the cordless handset or the battery does not accept charge.

Make sure the cordless handset is placed in the telephone base, charging base or charging stand correctly. The CHARGE LED

•

should be on. Remove and install the battery again, then charge for up to 16 hours.

•

If the cordless handset is in the telephone base, charging base or charging stand but the CHARGE LED is not on, refer to

•

The CHARGE LED is off below. If the battery is completely depleted, charge it for at least 30 minutes before use.

•

If the above measures do not correct the problem, replace the battery..

•

The CHARGE LED is off.

Clean the charging contacts on the cordless handset, telephone base, charging base and charging stand each month with a

•

pencil eraser or a dry non-abrasive fabric. Make sure the power adapter and telephone line cord are plugged in correctly and securely.

•

Unplug the power adapter. Wait for 15 seconds before plugging it back in. Allow up to one minute for the cordless handset and

•

telephone base to reset.

Appendix

Troubleshooting

For cordless telephones:

The telephone does not ring when there is an incoming call.

Make sure the telephone line cord and the power adapter are plugged in properly (page 29).

•

The cordless handset may be too far from the telephone base. Move it closer to the telephone base.

•

Adjust the setting of RF transmission power (page 56). It may be out of range.

•

If other telephones in your hotel are having the same problem, the problem is in the wiring or telephone service. Contact your

•

telephone service provider (charges may apply).

Other electronic products such as HAM radios and other DECT phones can cause interference with your cordless phone. Try

•

installing your phone as far away as possible from these types of electronic devices.

Test a working telephone at the telephone wall jack. If another telephone has the same problem, the problem is in the telephone

•

wall jack. Contact your telephone service provider (charges may apply). The telephone line cord may be defective. Install a new telephone line cord.

•

Remove and install the battery again and place the cordless handset in the telephone base. Wait for the handset to synchronize

•

with the telephone base. Allow up to one minute for this to take place.

The cordless handset beeps and is not performing normally.

Make sure the power cord is securely plugged into the telephone base. Plug the telephone base into a different working electrical

•

outlet not controlled by a wall switch.

Move the cordless handset closer to the telephone base or adjust the setting of RF transmission power ((page 56). It may be out It may be out

•

of range. Reset the telephone base by unplugging the electrical power to the base. Wait for 15 seconds and plug it back in again. Allow up

•

to one minute for the cordless handset and the telephone base to synchronize.

Other electronic products such as HAM radios and other DECT phones can cause interference with your cordless phone. Try

•

installing your phone as far away as possible from these types of electronic devices.

There is interference during a telephone conversation or the call fades in and out when I am using the cordless handset.

Move the handset closer to the telephone base or adjust the setting of RF transmission power ((page 56). It may be out of range. It may be out of range.

•

If there is High Speed Internet Access (HSIA) available at the premises through a telephone line, you may need to install a DSL

•

Appliances or other cordless telephones plugged into the same circuit as the telephone base can cause interference. Try moving

•

the appliance or telephone base to another outlet.

Other electronic products such as HAM radios and other DECT phones can cause interference with your cordless phone. Try

•

installing your phone as far away as possible from these types of electronic devices.

If your telephone is plugged in with a modem or a surge protector, plug the telephone (or modem/surge protector) into a different

•

location. If this doesn’t solve the problem, relocate your telephone or modem farther apart from each other, or use a different surge protector.

The location of your telephone base can impact the performance of your cordless phone. For better reception, install the

•

telephone base in a centralized location within the room, away from walls or other obstructions. Disconnect the telephone base from the telephone wall jack and plug in a corded telephone. If calls are still not clear, the

•

problem is probably in the wiring or telephone service. Contact your telephone service provider (charges may apply). If other telephones in your hotel are having the same problem, the problem is in the wiring or telephone service. Contact your

•

telephone service provider (charges may apply).

I hear other calls when using the telephone.

Disconnect the telephone base from the telephone wall jack. Plug in a different telephone. If you still hear other calls, the

•

problem is probably in the wiring or telephone service. Contact your telephone service provider (charges may apply).

I hear noise on the cordless handset and the keys do not work.

Make sure the telephone line cord is plugged in securely.

•

Common cure for electronic equipment.

If the telephone is not responding normally, put the cordless handset in the telephone base. If it does not x the problem, try the

•

following (in the order listed):

1. Disconnect the power to the telephone base.

2. Disconnect the battery on the cordless handset.

3. Wait a few minutes before connecting power to the telephone base.

4. Install the battery again and place the cordless handset in the telephone base.

5. Wait for the cordless handset to synchronize with the telephone base. Allow up to one minute for this to take place.

Appendix

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones):

Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference

between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration,

WTR recommends to physicians that:

Pacemaker patients

Should keep wireless telephones at least six inches from the pacemaker.

•

Should NOT place wireless telephones directly over the pacemaker, such as in a breast pocket, when it is turned ON.

•

Should use the wireless telephone at the ear opposite the pacemaker.

•

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless telephones.

Operating range

The cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so,

the cordless handset and telephone base can communicate over only a certain distance - which can vary with the locations of the

telephone base, cordless handset, the weather, and the layout of the hotel. When the cordless handset is out of range while on a call, the cordless handset rapidly beeps three times. If there is a call while the handset is out of range, it may not ring, or if it does ring, the call may not connect well when you answer

the call. Move closer to the telephone base to answer the call.

If the handset moves out of range during a telephone conversation, there may be interference. To improve reception, move closer to the telephone base.

About cordless telephones

Privacy: The same features that make a cordless telephone convenient create some limitations. Telephone calls are transmitted

• between the telephone base and the cordless handset by radio waves, so there is a possibility that the cordless telephone

conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.

Electrical power: The telephone base of the cordless telephone must be connected to a working electrical outlet. The electrical

•

outlet should not be controlled by a wall switch. Calls cannot be made from the cordless handset if the telephone base is unplugged, switched off or if the electrical power is interrupted.

Potential TV interference: Some cordless telephones operate at frequencies that may cause interference to televisions and

•

VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR often reduces or eliminates the interference.

Rechargeable batteries: Exercise care in handling batteries in order not to create a short circuit with conducting material such as

•

rings, bracelets and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the battery and the battery charger.

Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do not burn or puncture the battery.

•

Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

The RBRC® seal

The RBRC® seal on the nickel-metal hydride battery indicates that VTech Communications, Inc. is voluntarily participating in an industry program to collect and recycle these batteries at the end of their useful lives, when taken out of service within the United

States and Canada.

The RBRC® program provides a convenient alternative to placing used nickel-metal hydride batteries into the trash or municipal

waste, which may be illegal in your area.

VTech’s participation in RBRC

program or at authorized VTech product service centers. Please call 1 (800) 8 BATTERYTM for information on Ni-MH battery recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources.

RBRC® is a registered trademark of Rechargeable Battery Recycling Corporation.

makes it easy for you to drop off the spent battery at local retailers participating in the RBRC®

Appendix

VTech Hospitality limited warranty program

VTech Communications, Inc., the manufacturer of VTech Hospitality Product (“Product”), warrants to the holder of a valid proof of purchase (“end user” or “you”) that the Product and all accessories provided by VTech in the Product’s package are free from

defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in

accordance with the Product’s operating instructions. The limited warranty extends to the end user of this Product and applies only if such Product is purchased through a United States of America and/or Canadian distributor. The limited warranty period for this

Product is determined based on the following:

5 Years – Analog Models

All Classic Models – corded and cordless

• All Contemporary Models – corded and cordless

• All TrimStyle Models

•

2 Years – SIP Non-Display Models

All Classic Models – corded and cordless

• All Contemporary Models – corded and cordless

• All TrimStyle Models

•

During the limited warranty period, VTech’s authorized service representative will repair or replace, at VTech’s option, without

charge, a Product that is not free from defects in materials and workmanship. If VTech’s authorized service representative repairs the Product, new or refurbished replacement parts may be used. If the Product is replaced, it may be replaced with a new or refurbished Product of the same or similar design. Repair or replacement of Product, at VTech’s option, is the exclusive remedy.

The limited warranty period for the Product begins on the date that the end user takes possession of the Product. This limited

warranty also applies to repaired or replacement Products for a period of either: (a) 90 days from the date the repaired or

replacement Product is shipped to you; or (b) the time remaining on the original limited warranty as described above; whichever is longer.

This limited warranty does not cover:

Product or parts that have been subjected to misuse, accident, shipping or other physical damage, improper installation,

abnormal operation or handling, neglect, inundation, re, water or other liquid intrusion; or Product that has been damaged due to repair, alteration or modication by anyone other than an authorized service

representative of VTech; or Product to the extent that the problem experienced is caused by signal conditions, network reliability or cable or antenna

systems; or Product to the extent that the problem is caused by use with non-VTech accessories; or

Product whose warranty/quality stickers, product serial number plates or electronic serial numbers have been removed, altered

or rendered illegible; or

Product purchased, used, serviced, or shipped for repair from outside the United States or Canada, or used for non-approved

commercial or institutional purposes (including but not limited to Products used for rental purposes); or Product returned without valid proof of purchase; or

Charges or costs incurred by the end user, and risk of loss or damage, in removing and shipping the Product, or for installation

or set up, adjustment of customer controls, and installation or repair of systems outside the unit. Line cords or coil cords, plastic overlays, connectors, power adapters and batteries, if the Product is returned without them.

VTech will charge the end user at then-current prices for each of the missing items. NiCd or NiMH handset batteries, or power adapters, which, under all circumstances, are covered by a one (1) year warranty only.

10.

Except as provided by applicable law, you assume the risk of loss or damage during transit and transportation and are responsible for delivery or handling charges incurred in the transport of Product(s) to the service location. VTech’s authorized service representative will return repaired or replaced product under this limited warranty to you. Transportation, delivery and handling charges are prepaid. VTech assumes no risk for damage or loss of the Product in transit.

If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty,

VTech will notify you and will request that you authorize the cost of repair and return shipping costs for the repair of Products that

not covered by this limited warranty. You must pay for the cost of repair and return shipping costs for the repair of Products that are not covered by this limited warranty.

Other limitations

This warranty is the complete and exclusive agreement between you and VTech. It supersedes all other written or oral communications related to this Product. VTech provides no other warranties for this Product, whether express or implied, oral or written, or statutory. The warranty exclusively describes all of VTech’s responsibilities regarding the Product. No one is authorized to make modications to this warranty and you should not rely on any such modication.

VTech’s liability to end user hereunder shall not exceed the purchase price of the Product. In no event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost prots or revenue, inability to use

the product, or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of

this Product. Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

This warranty gives you specic legal rights, and you also have other rights which vary from state to state or province to province.

Appendix

FCC, ACTA and IC regulations

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the

Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

•

Changes or modications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation. For cordless telephone only - Privacy of communications may not be ensured when using this telephone.

For cordless telephone only - To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy

that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more.

This Class B digital apparatus complies with Canadian ICES-003.

FCC Part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for

Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identier

in the format US:AAAKXNANXXXX. This identier must be provided to your telephone service provider upon request. The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with applicable Part

68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See the installation instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still

have them ring when you are called. The REN for this product is encoded as the 6th and 7th characters following the US: in the product identier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be ve (5.0) or less. For more information, please contact your telephone service provider.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone service provider or a qualied installer.

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under VTech Hospitality limited warranty program in the user’s manual.

If this equipment is causing harm to the telephone network, your telephone service provider may temporarily discontinue your telephone service. Your telephone service provider is required to notify you before interrupting service. If advance notice is not practical, you will be notied as soon as possible. You will be given the opportunity to correct the problem and your telephone service provider is required to inform you of your right to le a complaint with the FCC. Your telephone service provider may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. Your telephone service provider is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible. If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, re, medical) in

these locations. If you do store or test emergency numbers, please: Remain on the line and briey explain the reason for the call before hanging up. Perform such activities in off-peak hours, such as early morning or late evening.

When the adjunct is used with a leased system, permission of the owner of the equipment must be obtained for connection of the

adjunct because modication of the host system is often required. This product can only be connected to the host equipment and never directly to the network.

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference, including interference that may cause undesired operation. The term ‘’IC:‘’ before the certication/registration number only signies that the Industry Canada technical specications were met. This product meets the applicable Industry Canada technical specications.

Appendix

Energy-saving charging mode

When this mode is activated, all telephone functions, except handset battery charging, will be disabled.

To activate the energy-saving charging mode in A2410/A2420/CTM-A2411/CTM-A2421:

Unplug the telephone base power adapter from the power outlet. Unplug the telephone line cord from the telephone wall jack.

Make sure all handsets are plugged with charged batteries before proceeding.

While you press and hold /FIND HANDSET, plug the telephone base power back to the power outlet.

After about 20 seconds, when the IN USE light starts ashing, release /FIND HANDSET and then press it again within

2 seconds. When the telephone base successfully enters the energy-saving charging mode, all keys on the telephone base should not respond.

Press *331734# and then press HOLD to deregister each handset manually.

When the phone successfully enters the energy-saving mode, the IN USE light turns off and you hear 3 rising beeps. When the phone fails to enter this mode, repeat Step 1 through Step 3 above.

Note: The telephone base will be powered up as normal if you fail to press /FIND HANDSET within 2 seconds in Step 3.

To deactivate the energy-saving charging mode:

Unplug the telephone base power adapter from the power outlet. Then plug the telephone base power adapter and the

telephone line cord back in. Then the telephone base is powered up as normal. Register the handsets back to the telephone base. See page 35 or 37 for handset registration instructions.

To activate the energy-saving charging mode in CTM-A2411-BATT/CTM-A2421-BATT:

Unplug the telephone base power adapter from the power outlet. Unplug the telephone line cord from the telephone wall jack,

and the backup battery from the telephone base. Make sure all handsets are plugged with charged batteries before proceeding.

While you press and hold /FIND HANDSET, plug the telephone base power back to the power outlet.

After about 20 seconds, when the IN USE light starts ashing, release /FIND HANDSET and then press it again within

2 seconds. When the telephone base successfully enters the energy-saving charging mode, all keys on the telephone base should not respond.

Press *331734# and then press HOLD to deregister each handset manually.

When the phone successfully enters the energy-saving mode, the IN USE light turns off and you hear 3 rising beeps. When the phone fails to enter this mode, repeat Step 1 through Step 3 above.

Note: The telephone base will be powered up as normal if you fail to press /FIND HANDSET within 2 seconds in Step 3.

To deactivate the energy-saving charging mode:

Unplug the telephone base power adapter from the power outlet. Then plug the telephone base power adapter and the

telephone line cord back in, and plug the backup battery back in the telephone base. Then the telephone base is powered up as normal.

To activate the energy-saving charging mode in CTM-A2510:

When a registered cordless handset is idle, press *331734# and then press HOLD. You hear 3 rising beeps.

•

To deactivate the energy-saving charging mode:

•

To activate the energy-saving charging mode in cordless handsets (C4100/C4200/CTM-A241HS/CTM-A242HS/ CTM-A241SD/CTM-A242SD/CTM-C4101/CTM-C4201):

When a registered cordless handset is idle, press *331734# and then press HOLD. You hear 3 rising beeps. Then put the

•

handset into the charging base (C4000/C4001) or charging stand (C4010/C4011/CTM-A241HS/CTM-A242HS/CTM-A241SD/

CTM-A242SD).

To deactivate the energy-saving charging mode:

•

Appendix

Maintenance

Taking care of the telephone

The telephone contains sophisticated electronic parts, so it must be treated with care.

Avoid rough treatment

Place the handset down gently. Save the original packing materials to protect the telephone if you ever need to ship it.

Avoid water

The telephone can be damaged if it gets wet. Do not use the handset outdoors in the rain, or handle it with wet hands. Do not install the telephone base near a sink, bathtub or shower.

Electrical storms

Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own safety, take caution when using electrical appliances during storms.

Cleaning the telephone

The telephone has a durable plastic casing that should retain its luster for many years. Clean it only with a soft cloth slightly dampened with water or mild soap. Do not use excess water or cleaning solvents of any kind.

Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND/OR TELEPHONE LINE CORD FROM THE WALL. Then remove the telephone by the unplugged cords.

Appendix

Technical specications

Analog corded lobby - A2100

Power requirement Line powered 24V or 48V

Size Telephone base: 8.03 x 5.98 x 3.74 in (204 x 152 x 95 mm)

Corded handset: 8.39 x 1.85 x 1.58 in (213 x 47 x 40 mm)

Analog corded 1-line/2-line - A2210/A2220

Power requirement Line powered 24V or 48V

Message waiting signal Steady/periodic high voltage pulse or periodic low voltage pulse

Speed Dial memory Telephone base: up to 10 memory locations; up to 16 digits

Size Telephone base: 8.03 x 5.98 x 3.74 in (204 x 152 x 95 mm)

Corded handset: 8.39 x 1.85 x 1.58 in (213 x 47 x 40 mm)

Analog corded trimstyle - A2310

Power requirement Line powered 24V or 48V

Message waiting signal Steady/periodic high voltage pulse and periodic low voltage pulse

Size Telephone base: 8.47 x 2.87 x 2.17 in (215 x 73 x 55 mm)

Corded handset: 8.39 x 1.85 x 1.65 in (213 x 47 x 42 mm)

Analog cordless 1-line/2-line - A2410/A2420

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency Handset: 1921.536-1928.448 MHz

Telephone base: 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirements Handset: 2.4V Ni-MH battery

Telephone base: 6V DC @600mA

Message waiting signal Steady/periodic high voltage pulse, periodic low voltage pulse, reverse polarity, FSK, Siemens

and/or Panasonic

Speed Dial memory Telephone base: up to 10 memory locations; up to 32 digits

Size Telephone base: 8.03 x 6.06 x 3.78 in (204 x 154 x 96 mm)

Handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)

Appendix

Technical specications

Analog cordless 1-line/2-line - CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency Handset: 1921.536-1928.448 MHz

Telephone base: 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirements Handset: 2.4V Ni-MH battery

Telephone base: 6V DC @600mA, Telephone base backup battery (for CTM-A2411-BATT/CTM-A2421-BATT): 2.4V Ni-MH battery

Message waiting signal Steady/periodic high voltage pulse, periodic low voltage pulse, reverse polarity, FSK, Siemens

and/or Panasonic

Speed Dial memory Telephone base: up to 11 memory locations; up to 32 digits

Handset: up to 3 memory locations; up to 32 digits

Size Telephone base: 8.03 x 6.06 x 3.78 in (204 x 154 x 96 mm)

Handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)

Analog cordless 1-line/2-line desket - CTM-A241P/CTM-A242P

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirement 5.1V DC @1.3 A

USB port Provide charging current up to 1A

Speed Dial memory Accessory Petite: up to 11 memory locations; up to 32 digits

Size Accessory Petite: 8.03 x 6.06 x 3.78 in (204 x 154 x 96 mm)

Corded handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)

Analog corded/cordless 1-line - CTM-A2510

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency Handset: 1921.536-1928.448 MHz

Telephone base: 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirements Handset: 2.4V Ni-MH battery

Telephone base: 6V DC @600mA Charging stand: 6V DC @400mA

Message waiting signal Steady/periodic high voltage pulse, periodic low voltage pulse, reverse polarity, FSK, Siemens

and/or Panasonic

Speed Dial memory Telephone base: up to 11 memory locations; up to 32 digits

Cordless handset: up to 3 memory locations; up to 32 digits

Size Telephone base: 8.03 x 6.06 x 3.78 in (204 x 154 x 96 mm)

Handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm) Charging stand: 3.78 x 2.80 x 4.29 in (96 x 71 x 109 mm)

Appendix

Technical specications

Analog cordless charging base - C4000

Power requirement 6V DC @600mA

Size 8.11 x 3.70 x 2.87 in (206 x 94 x 73 mm)

Analog cordless charging base - C4001

Power requirement 6V DC @400mA

Size 8.11 x 3.70 x 2.87 in (206 x 94 x 73 mm)

Analog cordless charging stand - C4010

Power requirement 6V DC @600mA

Size 3.78 x 2.80 x 4.29 in (96 x 71 x 109 mm)

Analog cordless charging stand - C4011

Power requirement 6V DC @400mA

Size 3.78 x 2.80 x 4.29 in (96 x 71 x 109 mm)

Analog cordless 1-line/2-line accessory handset - C4100/C4200

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirement 2.4V Ni-MH battery

Message waiting signal Steady/periodic high voltage pulse, periodic low voltage pulse, reverse polarity, FSK, Siemens

and/or Panasonic

Size 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)

Analog cordless 1-line/2-line accessory handset - C4101/C4201

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirement 2.4V Ni-MH battery

Message waiting signal Steady/periodic high voltage pulse, periodic low voltage pulse, reverse polarity, FSK, Siemens

and/or Panasonic

Speed Dial memory Handset: up to 3 memory locations; up to 32 digits

Size 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)

Appendix

Technical specications

Analog cordless 1-line/2-line accessory handset and charger bundle - CTM-A241HS/CTM-A242HS

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirement Cordless handset: 2.4V Ni-MH battery

Charging stand: 6V DC @400mA

Message waiting signal Steady/periodic high voltage pulse, periodic low voltage pulse, reverse polarity, FSK, Siemens

and/or Panasonic

Size Cordless handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)

Charging stand: 3.78 x 2.80 x 4.29 in (96 x 71 x 109 mm)

Analog cordless 1-line/2-line accessory handset with speed dials and charger bundle - CTM-A241SD/CTM-A242SD

Frequency Control Crystal controlled PLL synthesizer

Transmit frequency 1921.536-1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to

environmental conditions at the time of use.

Power requirement Cordless handset: 2.4V Ni-MH battery

Charging stand: 6V DC @400mA

Message waiting signal Steady/periodic high voltage pulse, periodic low voltage pulse, reverse polarity, FSK, Siemens

and/or Panasonic

Speed Dial memory Handset: up to 3 memory locations; up to 32 digits

Size Cordless handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)

Charging stand: 3.78 x 2.80 x 4.29 in (96 x 71 x 109 mm)

Index

A2100 4, 25–26, 54–55, 60 A2210 5, 25–26, 54–55, 61–62 A2220 6, 25–26, 54–55, 63– 64 A2310 7, 27–28, 54–55, 65 A2410 8, 29–30, 34–35, 56–59, 66– 68 A2420 11, 29–30, 34–35, 56–59, 70–72 Answer an intercom call 68, 72

Battery charging 31, 35, 37, 44, 51, 53 Battery installation 31, 34, 36, 43, 50, 52

C4000 15, 46 C4001 15, 47 C4010 16, 48 C4011 16, 49 C4100 17, 50–51 C4200 21, 50– 51 Call waiting 61, 63, 65, 67, 69, 71, 73, 76 Cardiac pacemakers 82 Charging 31, 35, 37, 44, 51, 53 Checklist 1–3 Conference call 64, 72, 74 CTM-A2411 9, 29–30, 36– 37, 56–59, 66 –68 CTM-A2411-BATT 9, 31–33, 36–37, 56–59, 66– 68 CTM-A241HS 19, 49, 50–51 CTM-A241P 10, 38–40, 56–59, 69 CTM-A241SD 20, 49, 52–53, 56–59 CTM-A2421 12, 29–30, 36–37, 56–59, 70–72 CTM-A2421-BATT 12, 31–33, 36– 37, 56–59, 70–72 CTM-A242HS 23, 49, 50–51 CTM-A242P 13, 38–40, 56–59, 73–74 CTM-A242SD 24, 49, 52–53, 56–59 CTM-A2510 14, 41–45, 56–59, 75–77 CTM-C4101 18, 52–53, 56–59 CTM-C4201 22, 52– 53, 56 –59

Data port 60, 62, 64, 65, 68, 72, 77 Default settings 54, 56 Deregister a handset 35, 37, 44, 51, 53 Deregister an accessory Petite 40

End a call 60, 61, 63, 65, 66, 69, 70, 73, 75 End a conference call 64, 72, 74 End an intercom call 68, 72 Energy-saving charging mode 85

FCC, ACTA and IC regulations 84 Find handset 68, 72, 77 Flash 54, 56, 61, 63, 65, 67, 69, 71, 73, 76

Handset battery 78 Handset battery installation 34, 36, 43, 50, 52 Handset battery replacement 34, 36, 43, 50, 52 Handset charging 35, 37, 44, 51, 53 Handset deregistration 35, 37, 44, 51, 53 Handset registration 35, 37, 44, 51, 53 Handset speakerphone 67, 70, 76 Hold 56, 57, 62, 64, 67, 69, 71, 73, 76

Initiate a conference call 64, 72, 74 Initiate an intercom call 68, 71 Installation 25–53 Intercom 68, 71–72

Join a call 61, 63, 65, 66, 69, 70, 73, 75

Layout 4–24 Limited warranty 83 Listening volume 60, 61, 63, 65, 67, 69, 71, 73, 76

Maintenance 86 Mute 61, 64, 65, 67, 69, 71, 73, 76

Operating range 82 Operation 60–77

Pacemaker patients 82 Paging handset 68, 72, 77 Parts checklist 1–3 Place a call 60, 61, 63, 65, 66, 69, 70, 73, 75

Range 82 Receive a call 60, 61, 63, 65, 66, 69, 70, 73, 75 Redial 67, 71, 76 Register a handset 35, 37, 44, 51, 53 Register a handset to another telephone base 35, 37, 44, 51, 53 Register an accessory Petite 40 Register an accessory Petite to another telephone base 40 Replace a handset battery 34, 36, 43, 50, 52 Replace a telephone base backup battery 31 RF transmission power 56 Ringer tone 54, 56 Ringer volume 54, 56, 60, 61, 63, 65, 67, 69, 71, 73, 76

Settings 54– 59 Share a call 61, 63, 65, 66, 69, 70, 73, 75 Speakerphone 54, 56, 61, 63, 66, 67, 69, 70, 71, 73, 75, 76 Speed Dial keys 55, 58–59

Technical specications 87–90 Troubleshooting 79 –81

USB port 69, 74

Voicemail voltage detection 55, 57–58 Volume 54, 56, 60, 61, 63, 65, 67, 69, 71, 73, 76

Wall mount 26, 28, 30, 33, 39, 42, 46, 47 Warranty 83

VTECH TELECOMMUNICATIONS LTD.

Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008.

Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W 1L5.

A member of THE VTECH GROUP OF COMPANIES.

VTech is the registered trademark of VTech Holdings Limited.

Petite™ Phone is a trademark of VTech Communications, Inc.

91-003835-060-100

VTech CTM-A242SD User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Parts checklist

Telephone layout

Analog corded lobby - A2100

Analog corded 1-line - A2210

Analog corded 2-line - A2220

Analog corded trimstyle - A2310

Analog cordless 1-line - A2410

Analog cordless 1-line - CTM-A2411/CTM-A2411-BATT

Analog cordless 1-line accessory Petite - CTM-A241P

Analog cordless 2-line - A2420

Analog cordless 2-line - CTM-A2421/CTM-A2421-BATT

Analog cordless 2-line accessory Petite - CTM-A242P

Analog corded/cordless 1-line - CTM-A2510

Analog cordless charging base - C4000/C4001

Analog cordless charging stand - C4010/C4011

Analog cordless 1-line accessory handset - C4100

Analog cordless 1-line accessory handset - CTM-C4101

Analog cordless 1-line accessory handset and charger bundle - CTM-A241HS

Analog cordless 1-line accessory handset with speed dials and charger bundle - CTM-A241SD

Analog cordless 2-line accessory handset - C4200

Analog cordless 2-line accessory handset - CTM-C4201

Analog cordless 2-line accessory handset and charger bundle - CTM-A242HS

Analog cordless 2-line accessory handset with speed dials and charger bundle - CTM-A242SD

Installation

Analog corded lobby/1-line/2-line - A2100/A2210/A2220

Analog corded trimstyle - A2310

Analog cordless 1-line/2-line - A2410/CTM-A2411/A2420/CTM-A2421

Analog cordless 1-line/2-line - CTM-A2411-BATT/CTM-A2421-BATT

Analog cordless 1-line/2-line - A2410/A2420

Analog cordless 1-line/2-line - CTM-A2411/CTM-A2411-BATT/CTM-A2421/CTM-A2421-BATT

Analog cordless 1-line/2-line accessory Petite - CTM-A241P/CTM-A242P

Analog corded/cordless 1-line - CTM-A2510

Analog cordless charging base - C4000

Analog cordless charging base - C4001

Analog cordless charging stand - C4010

Analog cordless charging stand - C4011/ CTM-A241HS/CTM-A241SD/CTM-A242HS/CTM-A242SD

Analog cordless 1-line/2-line accessory handset - C4100/C4200/CTM-A241HS/CTM-A242HS

Analog cordless 1-line/2-line accessory handset - CTM-A241SD/CTM-A242SD/CTM-C4101/ CTM-C4201

Telephone settings

Analog corded lobby/1-line/2-line/trimstyle - A2100/A2210/A2220/A2310

Telephone operation

Analog corded lobby - A2100

Analog corded 1-line - A2210

Analog corded 2-line - A2220

Analog corded trimstyle - A2310

Analog cordless 1-line - A2410/CTM-A2411/CTM-A2411-BATT

Analog cordless 1-line accessory Petite - CTM-A241P

Analog cordless 2-line - A2420/CTM-A2421/CTM-A2421-BATT

Analog cordless 2-line accessory Petite - CTM-A242P

Analog corded/cordless 1-line - CTM-A2510

Appendix

Handset battery

Troubleshooting

Precautions for users of implanted cardiac pacemakers

Operating range

About cordless telephones

The RBRC® seal

VTech Hospitality limited warranty program

FCC, ACTA and IC regulations

Energy-saving charging mode

Maintenance

Index
