V-Tech C5-F4 User Manual

Product Information

CAT5 Accessories

C5-F4

DESCRIPTION FEATURES

CAT5 system branch controller with four
outputs

DIMENSION

140mm

C5-F4 Distributor

88mm

32mm

36mm

120

► Branch controller for 4 apartments and

serve as oor distributor;

► RJ45 connection port;

► Strong anti-interference ability;

► Signal isolation device;

► One audio and one video channel;

HI

1. Parts and Funcons

IN-USE

VD-SET

POWER

P+ P-

LINK

JWB(OUT)JWB(IN)

*P+, P-: Power input, DC 18V

*JWB (IN): Bus Signal Input. The port

is a RJ45 port includes audio, data
& video. It can be connected to last
distributor or C5-IPC

*JWB (OUT): Bus Signal Output. The

port is a RJ45 port includes audio,
data & video. It can be connected to
next distributor

*PORT-A, PORT-B, PORT-C, PORT-D:

4 output, it can be connected to indoor
monitors

*VD-SET: Setting for video matching

PORT-DPORT-CPORT-BPORT-A

*LINK: Signal indicator. Flicker means

signal is transmitted in bus

*Power: Power indicator. Always ON

*IN-USE: Status Indicator. ON while

working

2. Unit Mounng

Direct Wall Mounting DIN Rail Mounting

3. Specicaon

*Power supply: DC 24V

*Standby current: 10mA

*Working current: 150mA

*Working temperature: -100C~400C

*Connection port: RJ45

*Dimension: 88(H)×140(W)×32(D)mm

4. Ordering Informaon

Model No. Brief Description Remark

C5-F4 branch controller with four outputs One audio&one video channel

5. Packing Informaon

Dimensions: 123(H)X160(W)X35(D)mm

Gross Weight: 0.30Kg

Carton: 530 (H)×340 (W)×258 (D)mm

Quanlity: 58PCS
