Vtech 9141 User Manual

TABLE OF CONTENTS
INTRODUCTION...............................................................................................................3
Parts Check List:.................................................................................................................4
IMPORT ANT SAFETY INSTR UCTIONS.........................................................................5
REPLACING THE HANDSET BATTERY...........................................................................7
SP ARE BA TTER Y CHARGER............................................................................................8
GETTING ST ARTED ............................................................................................................9
Setting Up Y our VT9141.....................................................................................................9
HANDSET FEA TURES..................................................................................................11
INT .COM/LOW BA TT LED .............................................................................................11
PHONE KEY ................................................................................................................11
TONE/* KEY..................................................................................................................11
HOLD KEY .....................................................................................................................11
PGM KEY .....................................................................................................................11
MEM KEY ..................................................................................................................11
VOLUME SWITCH.........................................................................................................11
CHAN KEY ..................................................................................................................11
HANDSET JACK.........................................................................................................11
OFF KEY.................................................................................................................11
INT .COM KEY..............................................................................................................11
PRV KEY..................................................................................................................11
REDIAL/P AUSE KEY.....................................................................................................11
BASE UNIT FEA TURES................................................................................................12
PRIV ACY KEY ..............................................................................................................12
IN USE LED .............................................................................................................12
POWER LED ................................................................................................................12
FLASH KEY ..............................................................................................................12
REDIAL KEY ...................................................................................................................12
MUTE KEY/LED..........................................................................................................12
HOLD KEY ..................................................................................................................12
MEMORY KEY.................................................................................................................12
SP ARE BA TT LED ..........................................................................................................12
CHARGE LED................................................................................................................12
VOLUME UP KEY......................................................................................................13
VOLUME DOWN KEY....................................................................................................13
TONE/* KEY................................................................................................................13
SPEAKERPHONE KEY ................................................................................................13
SPEAKERPHONE LED ................................................................................................13
INTERCOM KEY/LED ....................................................................................................13
TONE/PLUSE SWITCH.................................................................................................13
RINGER SWITCH..........................................................................................................13
MAKING CALLS..............................................................................................................14
ANSWER A CALL.............................................................................................................15
TO PUT A CALL ON HOLD ...........................................................................................15
THE MUTE FEA TURE....................................................................................................15
1
TABLE OF CONTENTS
SWITCHING FROM BASE UNIT (SPEAKERPHONE) TO THE HANDSET...........16
SWITCHING FROM HANDSET TO THE BASE UNIT (SPEAKERPHONE)..........16
JOIN A CONVERSA TION...............................................................................................16
PREVENT A THIRD PARTY FROM JOINING YOUR CONVERSA TION...............17
USING THE INTERCOM.................................................................................................17
IF Y OUR PHONE RINGS DURING AN INTERCOM CONVERSATION.................18
USING THE INTERCOM DURING A PHONE CALL.................................................19
TEMPORARY T ONE FEA TURE....................................................................................19
PROGRAMMING THE RINGER TYPE.........................................................................19
TURNING OFF THE RINGERS .....................................................................................20
CHECKING THE RINGER..............................................................................................20
MEMORY DIALING..........................................................................................................20
TO ST ORE A NUMBER INTO MEMOR Y ......................................................................20
TO SPEED DIAL A STORED NUMBER......................................................................21
TO CHANGE OR REPLACE A STORED NUMBER....................................................21
STORING SPECIAL CODES AND PAUSES..............................................................21
USING REDIAL...............................................................................................................22
STORING A REDIAL NUMBER IN MEMOR Y DIAL...................................................22
TONE DEFINITIONS.........................................................................................................22
CHANGING CHANNELS...............................................................................................23
OPTIONAL HEADSET INST ALLATION AND OPERA TING INSTRUCTIONS ........23
MAINTENANCE...............................................................................................................25
IN CASE OF DIFFICUL TY ...............................................................................................26
WARRANTY STA TEMENT ...............................................................................................28
FCC AND IC REGULA TIONS..........................................................................................30
TECHNICAL SPECIFICA TIONS....................................................................................33
2
INTRODUCTION
Congratulations! You have purchased one of the best performing cordless telephones on the market! The VT 9141 is a single line 900 MHz cordless phone with speakerphone & secondary key­pad in Base Unit.
The VT 9141 has automatic security code reset. This means that one of more than 65 thousand possible digital se­curity codes is randomly selected ev­ery time the handset is placed in the base unit. The handset and base unit will recognize each other based on this security code, which minimizes the chances of another cordless phone us­ing your telephone line. The base unit stores the current security code and channel in memory even if the unit is unplugged.
FEATURES:
10 Number Speed Dial Memory (16-
digit each). 30 Channels of operation. Automatic Search for Available Chan-
nel. Manual Channel Change on Hand-
set. REDIAL feature. Programmable Ringer Types. Low Battery Detect and Warning in-
dicator. Hearing-Aid Compatible Receiver. Easy answer - when the phone rings
simply press any key on the handset
to answer . Except OFF. Removable battery pack. Touch Tone and Pulse Dialing. Temporary Tone Mode. Spare battery charger in the Base
Unit.
Handset and speakerphone hold. Automatic release from hold when
an extension telephone is activated.
Handset and speakerphone volume
control. Flash. Ringer switch in base(High-Low-Off). Three-way conversation between
caller, handset and speakerphone. Two-way intercom between handset
and base.
2.5mm headset jack in handset. Belt clip on the handset. Privacy communication option in two-
way conversation between caller
and handset or caller and speaker-
phone. Long battery life (4 hours talk time/6
day standby).
This manual is designed to familiarize you with the VT 9141. To get the most use out of your VT 9141, we strongly recommend you read the manual be­fore using your phone.
3
INTRODUCTION
Parts Check List:
1. Base unit
2. Handset
3. AC adapter
4. Telephone line cord
5. Battery pack
6. Belt clip
7. Wall mounting bracket
900
MH
Z
CORDLESS VT9141
REDIAL
PRIVACY
MUTE
MEMORY
HOLD
FLASH
SPARE BATT
CHARGE
IN USE
REQULARY CLEAN CHARGE CONTACTS WITH AN ERASER FOR SERVICE CALL VTECH AT
X-XXX-XXX-XXXX
POWER
2
ABC
13
DEF
4
GHI5JKL6MNO
7PQRS 8
TUV9WXYZ
TONE
OPER
0
INTERCOM
SPEAKERPHONE
MIC
VOL
Base Handset
INT.COM/LOW BATT
PHONE
CHAN
FLASH
2ABC13DEF
4GHI 5JKL 6MNO
7PQRS 8TUV 9WXYZ
TONE
OPER
0
HOLD
PRV
PGM
MEM REDIAL
900
CORDLESS
MHz
OFF
INT.COM
PAUSE
Adaptor Telephone Line Cord
Battery Pack
Belt Clip
Wall Mounting Brac ket
4
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, in­cluding the following:
1. Read and understand all instruc­tions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink, or swimming pool).
5. Do not place this product on an un­stable cart, stand, or table. The prod­uct may fall, causing serious dam­age to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To protect it from over­heating, these openings must not be blocked by placing the product on the bed, sofa, rug, or other simi­lar surface. This product should never be placed near or over a ra­diator or heat register. This product should not be placed in a built-in installation where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this prod­uct where the cord will be abused by persons walking on it.
9. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
10.To reduce the risk of electric shock, do not disassemble this product. If service or repair work is required, contact VTech Customer Service at 1-800-595-9511. Opening or re­moving cabinet parts other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the ap­pliance is subsequently used.
11.Do not overload wall outlets and ex­tension cords as this can result in the risk of fire or electric shock.
12.Unplug this product from the wall outlet :
A.When the power supply cord or
plug is damaged or frayed.
B.If liquid has been spilled into the
product.
C.If the product has been exposed
to rain or water.
D.If the product does not operate
normally by following the operat­ing instructions. Adjust only those controls that are covered by the operating instructions because improper adjustment of other con­trols may result in damage and
5
IMPORTANT SAFETY INSTRUCTIONS
will often require extensive work to restore the product to normal operation.
E.If the product has been dropped
and the cabinet has been dam­aged.
F.If the product exhibits a distinct
change in performance.
13. Avoid using a telephone (other than a cordless type) during an electri­cal storm. There may be a remote risk of electric shock from lighting.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
SA VE THESE INSTRUCTIONS
The RBRCTM Seal
The RBRC® Seal on the nickel-cadmium battery indicates that VTech
Communications,INC. is voluntarily participating in an industry program to collect and recycle batteries at the end of their useful lives,when taken out of service within the United States and Canada. The RBRC® program provides a convenient alternative to placing used nickel-cadmium batteries into the trash or municipal waste,which may be illegal in some areas.
VTech’s partnership with RBRC® makes it easy for
you to drop off the spent battery at local retailers participating in the RBRC program or at authorized VTech product service centers. Please call 1-800-8-BATTERYTM for information on Ni-Cd battery recycling and disposal bans/restrictions in your area.VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources.
RBRC® is a registered trademark of Rechargeable Battery Recycling Corporation.
6
REPLACING THE HANDSET BATTERY
1. Remove the battery case by press-
ing on the ridged lines and sliding downward.
2. Discard the old battery pack. Don’t
put the old battery pack in a trash compactor or a fire - it could burst.
IMPORTANT: Do not dispose of
this battery in household gar­bage. For information on recy­cling or proper disposal, consult your local solid waste collection or disposal organization.
3. Place the new battery pack in the
battery compartment. Make sure the metal contacts on the underside of the battery are aligned with charg­ing contacts in the battery compart­ment.
cradle of the base unit to allow it to charge for 16 hours.
CAUTION:To reduce the Risk of
Fire or Injury to Persons, Read and Follow these Instructions:
1. Use only VTECH battery.
2. Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to the eyes or skin. It may be toxic if swallowed.
3. Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, bracelets, and keys. The battery or conductor may overheat and cause burns.
4. Do not dispose of the battery in a fire. The cell may explode.
+
-
4. The new battery pack must be charged before using your tele­phone. Place the handset in the
7
SPARE BATTERY CHARGER
Y our VTech VT 9141 is equipped with a spare battery charger built-in to the base unit. The spare battery charger allows you to always have a charged battery available, should your handset battery discharge during normal use.
To install the Spare Battery Pack:
1. Open the base unit battery compart­ment.
2. Place the spare battery pack in the battery compartment. Make sure the metal contacts on the underside of the battery are aligned with charg­ing contacts in battery compartment.
3. Replace the battery compartment cover.
4. When the battery is installed prop­erly, the spare battery LED on the base unit will be illuminated.
5. The spare battery will be fully charged
after 24 hrs. Please note that the spare battery LED will always be il­luminated when a spare battery is installed.
8
GETTING STARTED
Setting Up Your VT9141
1. Choose an area near an electrical outlet and a telephone wall jack.
2. Plug the AC power adapter into an electrical outlet and the DC connec­tor to the back of the base unit.
NOTE: Connect power to the base unit before placing the handset in the cradle.
3. Set the T ONE/PULSE s witch on the base unit. If you have touch tone service on your phone line, set the switch to TONE. If you have rotary service, set the switch to PULSE.
4. Set the RINGER switch to high, low or off on the base unit.
5. CHARGE THE HANDSET BA TTER- IES BEFORE USE. The batteries recharge automatically whenever the handset is in the base unit cradle. The batteries must be charged for 16 hours before using your phone for the first time.
6. Connect the telephone line cord. In-
sert one end of the telephone line cord into the jack at the rear of the base unit. Plug the other end into a telephone wall jack. Make sure the plugs snap securely into place.
7. CHECK FOR A DIAL TONE. After the batteries are charged, pick up the handset and press the PHONE key. The IN USE indicator should light up, and you should hear a dial tone. If not, see IN CASE OF DIFFI­CUL TY.
CAUTION:
1. Never install telephone wiring dur­ing a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specifi­cally designed for wet locations.
3. Never touch uninsulated telephone wires or terminals unless the tele­phone line has been disconnected at the network interface.
4. Use caution when installing or modi­fying telephone lines.
RINGER LEVEL
OFF
LOW
RINGER LEVEL
OFF
LOW
DIAL MODE
PULSE
TONE
HIGH
AC ELECTRICAL
DIAL MODE
HIGH
PULSE
TONE
OUTLET
CAUTION: Use only the AC adapter shipped with your VT
9141. This is a Class 2 AC adapter , specifi­cally designed for
TELEPHONE
WALL JACK
use with the VT 9141.
9
WALL MOUNTING
The Wall Mount adaptor is designed to fit on standard Wall Mount plates.
1. Choose a spot near an electrical outlet and a telephone jack. Y our phone requires a modular tele­phone jack and a standard electri­cal outlet (120V AC). The power cord is six feet long; make sure there is an electrical outlet within reach of the base. The outlet should not be controlled by a wall switch. If the switch is ever turned off, the phone will not operate.
2. Position the wall mount adapter on the base. Line up the tabs on the wall mount adapter with the holes on the bottom of the base. Snap the wall mount adapter firmly in place.
wooden
stud
wallboard
3. Mount the base on the wall. Posi- tion the base so the mounting studs will fit into the holes on the bottom of the base. P osition the po wer cord to extend down the wall the phone is to be mounted on. Slide the base down on the mounting studs until it locks into place.
4. Connect the telephone cord. The telephone line cord has a snap-in plug at each end. Insert one of the plugs into the jack on the bottom of the base. Insert the other end of the plug into the wall jack.
5. Connect the power cord. Plug the DC connector into the DC jack at the rear of the base unit. Plug the AC power adaptor into an electrical outlet.
TONE
DIAL MODE
PULSE
HIGH
LOW
RINGER LEVEL
OFF
10
HANDSET FEATURES
INT.COM/LOW
BATT LED
It will illuminate while
*
using Intercom. It will flash slowly if
*
Handset battery level is low.
PHONE KEY
*
Press this key to make a call.
*
Press this key during a call to flash the line.
TONE/* KEY
*
In TONE dialing mode, this key is used as a normal number key.
*
In PULSE dialing mode, this key is used to switch to Temporary TONE dialing mode.
HOLD KEY
When the handset is in
*
use, press this key to hold the line. To release the hold mode, press the PHONE key.
PGM KEY
*
In handset idle mode, press this key to enter PROGRAM mode.
MEM KEY
*
Press this key to enter memory dial mode.
VOLUME SWITCH
Set earpiece volume to HIGH, MEDIUM or LOW, depending on your preference.
INT.COM/LOW BATT
PHONE
FLASH
4GHI 5JKL 6MNO
7PQRS 8TUV 9WXYZ
TONE
HOLD
PGM
900
CORDLESS
CHAN
2ABC13DEF
OPER
0
PRV
MEM REDIAL
MHz
OFF
INT.COM
PAUSE
CHAN KEY
Pressing the CHAN key
*
when the handset is in use will activate a channel change to the next free channel. This is used if you are experiencing noise or interference on the current channel.
HEADSET JACK
Connect a 2.5mm
*
headset to the jack for hands free operation.
OFF KEY
*
Press this key to exit all modes.
INT.COM KEY
*
Press this key will ring the base to establish an intercom call.
PRV KEY
*
During a call, press the PRV key to prevent the base unit (speakerphone) from joining the conversation. Press the PRV key a second time to cancel PRV mode.
REDIAL/PAUSE KEY
Press this key to dial the last
*
number called on your phone.
*
During Speed Dial programming, press this key to insert a 2 second PAUSE in the dialing sequence.
11
BASE UNIT FEATURES
PRIVACY KEY
In speakerphone mode, Pressing this
*
key will prevent the handset from joining the conversation.Press this key a second time to cancel PRV mode.
900
MHZ
CORDLESS
ARGE
RASER
CH AT
XXX
VT9141
MIC
REDIAL
PRIVACY
FLASH
POWER
13
4
GHI5JKL6MNO
7
PQRS8TUV9WXYZ
TONE
INTERCOM
MEMORY
CHARGE
IN USE
2
ABC
OPER
0
SPEAKERPHONE
MUTE
HOLD
SPARE BATT
DEF
IN USE LED
It illuminates whenever the
*
handset is being used.
*
The LED also flashes with the cadence of the incoming ring.
POWER LED
It illuminates when the base
*
power adapter is plugged in and power is applied to the base unit.
FLASH KEY
Press this key to FLASH the
*
line, This is used with services such as call waiting.
VOL
REDIAL KEY
*
Press this key to dial the last number called from the Base.
MUTE KEY/LED
Press this key during active
*
call to disable the microphone.
*
While the SPEAKERPHONE is on, this LED will illuminate after pressing the MUTE key.
HOLD KEY
Press this key to place a
*
Speakerphone call on hold.
*
Press SPEAKERPHONE to return to the call.
MEMORY KEY
Press this key to enter Memory
*
(Speed Dial) mode.
SPARE BATT LED
The SPARE BATT LED will
*
light when battery is placed in the spare-battery charger in the base.
CHARGE LED
Immediately after placing the
*
handset in the base cradle, It flashes to indicate that initialization (assigning a new security code) is in progress.
*
The CHARGE LED will stop flashing when initialization completes.
The CHARGE LED illuminates
*
steadily to indicate that the handset battery is being charged.
12
BASE UNIT FEATURES
900
MHZ
ARGE ASER CH AT
1
CORDLESS VT9141
MIC
REDIAL
PRIVACY
FLASH
POWER
13
4
GHI5JKL6MNO
7
PQRS8TUV9WXYZ
TONE
INTERCOM
MEMORY
CHARGE
IN USE
2
ABC
OPER
0
SPEAKERPHONE
MUTE
HOLD
SPARE BATT
DEF
VOL
Press this key to adjust the speaker
*
volume. There are total of 8 volume level settings.
VOLUME DOWN KEY
*
Press this key to adjust the speaker volume. There are total of 8 volume level settings.
TONE/* KEY
In PULSE dialing mode, this key
*
is used to switch to Temporary Tone dialing mode.
SPEAKERPHONE KEY
Press this key to activate the
*
base speakerphone. Press this key again,will turn the phone off.
SPEAKERPHONE LED
VOLUME UP KEY
*
This LED illuminates when the Speakerphone is in use. It flashes slowly when the Speakerphone call is on hold.
INTERCOM KEY/LED
Press this key to establish an intercom call with the handset.
*
This LED will flash after pressing the
*
INTERCOM key on base and illuminate after an intercom call is established.
TONE/PULSE SWITCH
This switch will switch the phone between
*
TONE dialing and PULSE dialing.
RINGER SWITCH
This switch will set the base ringer to
*
HIGH, LOW or OFF.
13
TONE
DIAL MODE
PULSE
HIGH
LOW
OFF
RINGER LEVEL
PRODUCT CONTAINS NICKEL-CADMIUM
BATTERY: MUST BE RECYCLED OR DISPOSED
OF PROPERLY. DO NOT BURN OR
PUNCTURE BATTERY. LIKE OTHER BATTERIES
OF THIS TYPE. IF IT IS BURNED OR
PUNCTURED. IT COULD RELEASE TOXIC
MATERIAL WHICH COULD CAUSE INJURY.
Cd
xxx xx xx xxxxxx xxx
OPERATING INSTRUCTIONS
IMPORTANT: Whenever the
handset battery is removed, the handset must be reinitialized on the base unit cradle after the bat­tery is replaced.The CHARGE LED on the base unit will flash during the initialization.
MAKING CALLS
You can make calls directly from the handset whether you are at the base or away from it. You can also make calls on the speakerphone without using the handset.
From the Handset
INT.COM/LOW BA TT
PHONE
FLASH
13
4
GHI5JKL6MNO
CHAN
2
ABC
900
MHz
CORDLESS
OFF
DEF
1.Pick up the handset and press PHONE.
2.When you hear a dial tone, dial the number. The LEDIN USE” (on the base unit) and “PHONE” (on the handset) will light up.
INT.COM/LOW BA TT
PHONE
FLASH
13
4
GHI5JKL6MNO
CHAN
2
ABC
900
MHz
CORDLESS
OFF
DEF
1.Place the Handset back in the Base; OR,
2.Press OFF on the Handset.
From the Base
7
PQRS
8
TUV9WXYZ
TONE
OPER
0
INTERCOM
SPEAKERPHONE
MIC
The base unit allows you to make and receive calls without using the hand­set. You can use the speakerphone on base while the handset is in or out of the base.
1.Press the SPEAKERPHONE on the base unit.
If you make a mistake when dialing, press OFF to hang up, then press PHONE to get the dial tone again.
You must always press PHONE before you can dial a call on the handset.
Disconnecting
To end a call,
2.You will hear the dial tone over the speaker.
3.Adjust the volume controls on the face of the base unit if necessary.
4.Dial the number on the dial pad of the base unit.
5.When the party answers, speak to­ward the microphone.
14
900
MH
900
MH
OPERATING INSTRUCTIONS
Disconnecting
7
PQRS
8
TUV9WXYZ
TONE
OPER
0
INTERCOM
SPEAKERPHONE
MIC
To end the call and hang up, press SPEAKERPHONE again on the base unit.
ANSWER A CALL
You can answer a call directly from the handset whether you are at the base or away from it. You can also answer it on the speakerphone with­out using the handset.
By Handset
1.If your phone rings when the hand­set is in the base, just pick up the handset to answer call.
The PHONE light on Handset and the
IN USE light on the Base will be lit.
By Base Unit
The base will ring when you have an incoming call. You can answer by pressing any key on base.
TO PUT A CALL ON HOLD
While using the speakerphone or the handset, you can put a call on hold by pressing HOLD. The speaker­phone LED on the base unit and the phone indicator on the handset will blink to show a call is on hold.
Z
CORDLESS VT9141
PRIVACY
FLASH
POWER
IN USE
REDIAL
MEMORY
CHARGE
MUTE
HOLD
SPARE BATT
To return to the call, press PHONE key or SPEAKPHONE key.
If a call is on HOLD using the VT 9141 and the user picks up another phone on the same line, the VT 9141 will au­tomatically take itself off HOLD and turn OFF.
2.If the handset rings when it is away from the base, press any key, ex­cept OFF to answer the call.
INT.COM/LOW BA TT
PHONE
FLASH
13
4
GHI5JKL6MNO
CHAN
2
ABC
900
MHz
CORDLESS
OFF
DEF
THE MUTE FEATURE
Z
CORDLESS VT9141
PRIVACY
FLASH
POWER
IN USE
REDIAL
MEMORY
CHARGE
MUTE
HOLD
SPARE BATT
1.When you press the MUTE key while using the speakerphone, you can hear your party’s voice, but your
15
7
PQRS8TUV9WXYZ
TONE
0
OPER
HOLD
PRV
INT.COM
PGM
MEM REDIAL
PAUSE
OPERATING INSTRUCTIONS
party can’t hear you.
2.While the call is muted, the MUTE indicator will be lit.
3.To go back to the two-way conver­sation, press MUTE again.
TIPS ON USING THE VT 9141 SPEAK­ERPHONE:
1. Adjust the Speakerphone volume to a comfortable listening level by
pressing the VOL UP or DOWN
keys.
CLEAN CHARGE WITH AN ERASER
E CALL VTECH AT
XXX-XXXX
2
ABC
13
4
GHI5JKL6MNO
7
PQRS
TONE
8
TUV9WXYZ
OPER
0
DEF
VOL
2. If there is background noise in the area where you are using the Speak­erphone, (people talking, a radio or television playing, for example), you may experience some degree of “chopping” or “dropout” as your party speaks. To remedy this, do the following:
* Try to lower the source of the back-
ground noise in your environment; otherwise;
* When it’s your party’s turn to talk,
press the MUTE key. The MUTE LED will glow. When it is your turn to speak, press MUTE again to re­activate the Base Unit microphone.
SWITCHING FROM THE BASE UNIT (SPEAKERPHONE) TO THE HAND­SET
If you are on a call using the Base Unit (Spearkerphone) and the Handset is in the base, you can automatically switch from the speakerphone to the handset by picking up the handset.
SWITCHING FROM HANDSET TO THE BASE UNIT (SPEAKPHONE)
To switch back to the base unit (speak­erphone), you must first press the HOLD key on the handset, then press the
SPEAKERPHONE key on the base.
NOTE:You cannot switch back to
the Speakerphone just by return­ing the Handset to the Base. That will disconnect the call.
JOINING A CONVERSA TION
From Base
X-XXX-XXX-XXXX
4
GHI5JKL6MNO
7
PQRS
TONE
INTERCOM
MIC
8
TUV9WXYZ
OPER
0
SPEAKERPHONE
16
VOL
7PQRS 8TUV 9WXYZ
TONE
0
OPER
HOLD
PRV
INT.COM
PGM
MEM REDIAL
PAUSE
OPERATING INSTRUCTIONS
1.If someone is speaking on the hand­set, you can join the conversation just by pressing SPEAKERPHONE on the base unit.
2.Either party can then leave the con­versation by pressing OFF(on the handset) or SPEAKERPHONE (on the base unit).
From Handset
INT.COM/LOW BA TT
PHONE
CHAN
FLASH
2
ABC
13
4
GHI5JKL6MNO
900
MHz
CORDLESS
OFF
DEF
Press PHONE on handset to join the conversation;
Press OFF to leave the conversation.
1.If you are using the speakerphone, someone at the handset can join the conversation by pressing PHONE on the handset.
2.Leave by pressing OFF key.
To disconnect the call, both the hand­set and the base unit must hang up . Otherwise the call will still remain con­nected.
PREVENT A THIRD PARTY FROM JOINING YOUR CONVERSATION
TONE
OPER
0
HOLD
PGM
PRV
INT.COM
MEM REDIAL
PAUSE
To prevent other person from hearing your conversation press the PRV key on the handset, or PRIVACY key on the base.
To release the privacy function in order to have 3-way conversation, you can
1.press INTERCOM key on base or INT.COM on handset,
2.Then press PHONE key(on hand­set) and SPEAKPHONE key(on base).
Alternatively , y ou can press PR V again to let the other party (base or handset) to join the conversation.
USING THE INTERCOM
You can use your VT 9141 cordless telephone as a two-way intercom be­tween the base unit and the handset. This doesn’t tie up your telephone line. You can still receive calls when using the intercom.
The intercom function can be activated by either the handset or the base unit.
17
OPERATING INSTRUCTIONS
From Handset
TONE
OPER
0
HOLD
PGM
PRV
INT.COM
MEM REDIAL
PAUSE
1.press INT.COM key.
2.The INT.COM indicator will b link and a tone will sound.
3.The base will ring and then auto­matically enter intercom mode.
4.Speak towards the microphone.
From the base
TONE
OPER
0
Note:
1.The handset will ring a maximum of 1 minute.
2.If the handset is in use, it will ring only once.
To end the intercom at the base, press INTERCOM again. To end the intercom at the handset press OFF.
If you receive an intercom call when you are on a phone call on base unit,
1.Press INTERCOM on base unit.
2. Press INT.COM key on handset to initiate intercom.
If you receive an intercom call when you are on a phone call on handset,
1. Press INT.COM key on handset,
2. Intercom is set up after a signal is heard.
INTERCOM
MIC
SPEAKERPHONE
1.Press INTERCOM.
2.The INT.COM indicator will b link and a tone will sound.
3.To answer the page at the handset press INT.COM and speak with the person at the base unit.
To return to the phone call, press
PHONE (for handset) or SPEAKER­PHONE (for base unit).
IF YOUR PHONE RINGS DURING AN INTERCOM CONVERSATION
If you receive a call while using the in­tercom, your phone will ring normally. You can answer the incoming call by pressing PHONE or SPEAKER- PHONE. However, by answering the incoming call you will automatically dis­connect the intercom.
18
OPERATING INSTRUCTIONS
USING THE INTERCOM DURING A PHONE CALL
The HOLD feature allows you to put a phone call on hold and use the inter­com without disconnecting your caller. It works at the handset or the base.
While you are on the call,
1.Press the INTERCOM key to auto­matically place the active call on hold, and to establish an intercom call between the handset and base.
TONE
OPER
0
HOLD
PGM
PRV
INT.COM
MEM REDIAL
PAUSE
2.To end the intercom conversation, press OFF on the handset or INTER- COM on the base unit.
3.To return to the call, press PHONE or SPEAKERPHONE.
When the handset is paged from the base while in-use, the handset will only ring once.
TEMPORARY T ONE FEA TURE
To do this:
1.Dial the call normally.
2.Activate the temporary tone feature by pressing TONE (the ke y).
3.Press the numbers or symbols you
*
need, and your phone will send the proper signals.
This works on the Handset and the Base Unit.
T o end the call,press OFF (if calling from the handset) or SPEAKERPHONE (if calling from the base), or place the handset back in the base. The phone will automatically go back to rotary(dial­pulse) service.
If you have touch-tone service, (TONE- PULSE switch set to TONE), just enter the codes normally.
PROGRAMMING THE RINGER TYPE
The VT 9141 cordless phone has four different types of ringing tones. The handset can have their ringer types programmed independently by the fol­lowing procedure.
T o progr am, The handset m ust be OFF. To select a different ringer type do the
following:
If you have rotary(dial-pulse) telephone service, (TONE/PULSE switch is set to PULSE), this feature allows you to en­ter special codes and tones to operate answering machines, use electronic banking services, calling cards, or other special services.
19
FLASH
4
GHI5JKL6MNO
OPERATING INSTRUCTIONS
TONE
OPER
0
HOLD
PGM
PRV
INT.COM
MEM REDIAL
PAUSE
1.Press PGM
2.Press the # key
3.Press a key 1..4 to select a ringer type
The VT 9141 will ring once to show the type of ringer selected.
4.Press the OFF key to exit.
TURNING OFF THE RINGERS
To turn off the ringer on the handset do the following:
2
ABC
13
4
GHI5JKL6MNO
7
PQRS8TUV9WXYZ
TONE
DEF
OPER
0
1.Press PGM
2.Press the # key
CHECKING THE RINGER
To check the ringer which is currently programmed do the following:
7
PQRS8TUV9WXYZ
TONE
OPER
0
HOLD
PGM
PRV
INT.COM
MEM REDIAL
PAUSE
1.Press PGM
2.Press the # key
3.Press 0
The phone will ring once to show ringer selected.
4.Press the OFF key to exit
MEMORY DIALING
The VT 9141 cordless phone can store up to 10 different phone numbers that you can dial just by pressing MEM and the memory location.
TO STORE A NUMBER INTO MEMORY
The handset must be OFF.
3.Press 5 to turn off the ringer
4.Press the OFF key to exit
To tur n off the ringer on the base unit set the RINGER switch to OFF.
20
OPERATING INSTRUCTIONS
base unit.
TONE
OPER
HOLD
PGM
0
PRV
INT.COM
MEM REDIAL
PAUSE
1.Press PHONE or SPEAKER­PHONE to get a dial tone.
2.Press MEM and the number key (0-
9).
1. Press PGM
2. Press the number of the memory location you wish to store the phone number in(0-9). The Handset will beep once.
3. Using the dialpad, dial the number you want to store. The number can be up to 16 digits long.
4. Press MEM to store the number into its assigned memory location.
If programming has been success-
ful, a happy tone will be generated.
If programming was unsuccessful, a
sad tone is generated.
If more than 16 digits are keyed in or
the phone is left unattended in pro­gram mode for more than 30 sec­onds, it will generate a sad tone and automatically exit program mode.
Follow the steps above for each num-
ber you want to store, assigning each phone number to a different memory key.
TO SPEED DIAL A STORED NUMBER
You can speed dial from the handset or
INT.COM/LOW BA TT
PHONE
FLASH
13
4
GHI5JKL6MNO
CHAN
2
ABC
900
MHz
CORDLESS
OFF
DEF
For example, to dial the number you assigned to key ‘8’, you would press
PHONE, MEM, 8.
TO CHANGE OR REPLACE A STORED NUMBER
You can change or replace a stored number just by storing a new number in its place.
STORING SPECIAL CODES AND PAUSES
To inser t a pause in a phone number, press REDIAL/PAUSE at the appropri- ate point when storing the number. This inserts a 2 second pause. For longer pauses, press REDIAL/PAUSE two or more times. Each press makes the pause 2 seconds longer and is treated as a stored digit.
If your phone is connected to a PBX you can store the PBX access number and a pause before the phone number . For example, to store 9-PAUSE-555-
21
TONE
0
OPER
TONE
0
OPER
OPERATING INSTRUCTIONS
1234, in memory location 8, do the fol­lowing:
HOLD
PGM
PRV
INT.COM
MEM REDIAL
PAUSE
1. Press PGM
2. Press 8
3. Press 9
4. Press REDIAL/PAUSE
5. Dial 555-1234
6. Press MEM
USING REDIAL
The VT 9141 cordless phone automati- cally stores the last number you dialed in a special redial memory.
2.Press REDIAL. This feature is also available on the
Base Unit.
STORING A REDIAL NUMBER IN MEMORY DIAL
To store the last number you dialed as a regular Speed Dial number,
TONE
OPER
0
HOLD
PRV
INT.COM
PGM
MEM REDIAL
PAUSE
1.Press PGM;
2.Press a number key;
3.Press REDIAL;
4.Press MEM.
TONE DEFINITIONS
To dial the number again,
HOLD
PGM
PRV
MEM REDIAL
1.Press PHONE.
INT.COM
PAUSE
A long warbling tone signifies an
incoming call. This r inger is pro­grammable for Handset.
A series of 4 continuous medium/
low beeps signifies a page.
A short beep when you press
PHONE signifies the batteries need charging.
Two long and low pitch buzzing tone
signifies an invalid key operation and is called a “sadtone”.
22
OPERATING INSTRUCTIONS
A quick cadence comprising high/
low frequency tones signifies cor­rect operation upon completion of a programming sequence. This is called a “happy tone”.
CHANGING CHANNELS
INT.COM/LOW BA TT
PHONE
FLASH
13
4
GHI5JKL6MNO
CHAN
2
ABC
900
MHz
CORDLESS
OFF
DEF
If you notice interference when using your handset, press CHAN to switch to a clear channel. This function is only available when you are on a call or us­ing intercom.
OPTIONAL HEADSET INSTALLATION AND OPERATING INSTRUCTIONS
Your VT9141 cordless telephone is equipped with a 2.5mm Headset Jack for use with an optional accessory Headset for hands-free operation.
If you choose to use the Headset op­tion, you must do the following:
INSTALLATION
Obtain an optional accessory Headset, which is compatible with the VT9141.
Please contact VTech Communications Customer Service, toll-free at 1-800- 595-9511 for dealer information in your local area. You can also purchase a compatible Headset directly from VT ech Communications Customer Service.
Once you have a compatible 2.5mm Headset, locate the Headset Jack on the Handset of your VT9141. Connect the plug of the Headset to the jack on the cordless Handset. The plug should
INT.COM/LOW BATT
900
MHz
CORDLESS
OFF
PHONE
CHAN
FLASH
2
ABC
13
DEF
4
GHI5JKL6MNO
7
PQRS8TUV9WXYZ
TONE
OPER
0
HOLD
PRV
INT.COM
PGM
MEM REDIAL
PAUSE
23
OPERATING INSTRUCTIONS
fit securely. Do not force the connec­tion.
NOTE: Whenever a compatible Headset is connected to the cordless Handset, the micro­phone on the Handset will be MUTED. This is done to limit the effect of background noise.
The following operational characteris­tics apply to VTech Headsets. The same may also apply to other (non-VTech) compatible headsets, but VTech as­sumes no responsibility for their per­formance.
The VTech brand compatible Head-
set has a monaural design which is reversible, so you can wear your Headset on either the left or right ear, leaving one ear free for room con­versation
ON RIGHT EAR
ON LEFT EAR
The headband can be adjusted to fit
the contour of your head. Using both hands, slide the headband up or down so that it rests comfortably on your head with the speaker cushion centered against your ear.
For maximum sound quality, the flex-
ible microphone should be posi­tioned at the corner of your mouth, about one inch from your mouth.
ONE INCH
The VT 9141 is also equipped with a
detachable belt clip. Align the pins on the inside edge of the belt clip with the notches on the side of the VT 9141 handset. The belt clip should snap securely into place. Do not force the connection. See Illustra­tion.
24
MAINTENANCE
TAKING CARE OF YOUR TELE­PHONE.
Y our VT ech VT 9141 cordless telephone contains sophisticated electronic parts so it must be treated with care.
Avoid rough treatment
Place the handset down gently . Sa ve
the original packing materials to pro­tect your telephone if you ever need to ship it.
Avoid water
Your telephone can be damaged if it
gets wet. Do not use the handset outdoors in the rain, or handle it with wet hands. Do not install your base unit near a sink, bathtub or shower.
Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If your base unit should fall into water,
DO NOT RETRIEVE IT UNTIL YOU UN­PLUG THE POWER CORD AND TELE­PHONE LINE CORDS FROM THE WALL. Then pull the unit out by the
unplugged cords.
water or a mild soap. Do not use excess water or cleaning solvents of any kind.
ELECTRICAL STORMS
Electrical storms can sometimes
cause power surges harmful to elec­tronic equipment.
For your own safety, use caution
when using electric appliances dur­ing storms.
Cleaning your telephone
Your telephone has a durable plas-
tic casing that should retain its lus­ter for many years. Clean it only with a soft cloth slightly dampened with
25
IN CASE OF DIFFICULTY
If you have difficulty operating your phone, the suggestions below should solve the problem. If you still have dif­ficulty after trying these suggestions, In the US call:
VTECH Communications at
1-800-595-9511
In Canada call:
VTECH Electronics at
1-800-267-7377.
THE PHONE DOESN’T WORK AT ALL.
Make sure the power cord is
plugged in.
Make sure the telephone line cord
is plugged firmly into the base unit and the telephone wall jack.
Make sure the batteries are prop-
erly charged. If the Low Battery in­dicator is on, the battery needs charging. If the IN USE and PHONE indicators do not light when you press PHONE, you must charge the batteries.
If you recently installed a new bat-
tery pack, make sure it is installed correctly.
your wiring or local service. Call your local telephone company.
Y OU GET NOISE, ST A TIC, OR A WEAK SIGNAL EVEN WHEN YOU’RE NEAR THE BASE UNIT.
Place the handset in the base mo-
mentarily to re-set the security code. Then press PHONE to get a line.
Check the Low Battery indicator. If it
is on, place the handset in the base cradle for recharging the battery.
Household appliances plugged into the same circuit as the base unit can sometimes cause interference. Try moving the appliance or the base unit to another outlet.
Y OU GET NOISE, ST A TIC, OR A WEAK SIGNAL WHEN Y OU’RE AWA Y FROM THE BASE UNIT.
Y ou ma y be out of range. Either move
closer to the base, or relocate the base unit.
The la yout of your home ma y be lim-
iting the range. Try moving the base unit to the second or third floor, or to some other location.
NO DIAL TONE.
First check all the suggestions
above.
If you still don’t hear a dial tone, dis-
connect the base unit from the tele­phone jack and connect a different phone. If there is no dial tone on that phone either, the problem is in
THE HANDSET DOES NOT RING WHEN YOU RECEIVE A CALL.
Ensure that the ringer is turned on.
Make sure the telephone line cord
is plugged firmly into the base unit and the telephone jack.Make sure the power cord is plugged in.
26
IN CASE OF DIFFICULTY
You may be too far from the base
unit.
You may have too many extension
phones on your telephone line to allow all of them to ring. Try unplug­ging some of the other phones.
THE BASE DOES NOT RING
Make sure the BASE RINGER
switch is not set to off.
There may be too many extension
phones on your line. Try unplugging one of the other phones.
YOUR CALLER FADES IN AND OUT.
You may be nearly out of range. Mo ve
closer, or relocate the base.
YOU HEAR OTHER CALLS WHILE USING YOUR PHONE.
Replace the handset in the base
cradle, wait a few moments and try again.
Change the channel by pressing
CHAN key on handset.
plugged in.
Your base unit and handset may not
be operating on the same channel or security code. Place the handset in the cradle for a few moments to reload the security code and reset the channel.
COMMON CURE FOR ELECTRONIC EQUIPMENT
Electronics, like people, can sometimes get confused. If the unit does not seem to be responding normally , then try put­ting the handset in the cradle to re-ini­tialize the unit. If it still does not seem to respond, perform the following steps (in the order listed):
1.Disconnect the power to the base.
2.Disconnect the handset battery.
3.Remove the spare battery from the
base unit spare battery charger, if in use.
4.Wait a few minutes.
5.Connect power to the base.
6.Connect the handset battery.
Disconnect your base unit from the
telephone jack, and plug in a regu­lar corded telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company.
YOU HEAR NOISE IN THE HANDSET, AND NONE OF THE KEYS OR BUT­TONS WORK.
Make sure the power cord is
7.Put the handset in the base to re-
initialize.
27
WARRANTY STATEMENT
WHA T DOES OUR WARRANTY COVER?
Any defect in material or workmanship.
FOR HOW LONG AFTER THE ORIGINAL PURCHASE?
One Year.
WHAT WILL VTECH DO?
At our option, repair or replace your unit.
HOW DO I SEND MY UNIT, IN OR OUT OF W ARRANTY?
Call VTECH Communications customer service for Return Authorization at:
1-800-595-9511, In Canada call VTech Electronics at 1-800-267-7377.
Properly pack your unit. Include any cables & accessories which were origi-
nally provided with the product. We recommend using the original carton and packing materials.
Include in the package a copy of the sales receipt or other evidence of date of
original purchase (if the unit was purchased within the last twelve months).
Print your name and address, along with a description of the defect, and in-
clude this in the package.
Include payment for any service or repair not covered by warranty, as deter-
mined by VTECH Communications.
In the US, ship the unit via UPS Insured, or equivalent to:
VTECH COMMUNICATIONS
11035 SW 11th Street
Bldg. B Suite 270
Beaverton, OR 97005
In Canada ship the unit via UPS Insured, or equivalent to:
VTECH ELECTRONICS Suite 200-7671 Alderbridge Way Richmond, B.C. V6X 1Z9
VTECH Communications assumes no responsibility for units sent without prior Return Authorization.
28
WARRANTY STATEMENT
VTECH Communications assumes no WARRANTY ST ATEMENT responsibil­ity for units sent without prior Return Authorization.
WHA T DOES OUR WARRANTY NOT COVER?
Batteries;
Damage from misuse, neglect, or acts of nature (lightning, floods, power surges,
etc.); Products which may have been modified or incorporated into other products;
Products purchased outside the USA;
Products serviced by the owner or a service facility not expressly authorized by
VTECH Communications; Products purchased more than 12 months from current date.
HOW DOES STATE LA W RELATE T O THIS W ARRANTY?
This warranty gives you specific rights. You may also have other rights which
vary from state to state.
29
FCC AND IC REGULATIONS
This equipment complies with Parts 15 and 68 of the Federal Communications Commission (FCC) rules for the United States. It also complies with regula­tions RSS210 and CS-03 of Industry and Science Canada. Operation is subject to the following two conditions: (1) this device may not cause interfer­ence, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
The underside of the Base Unit con­taining engravements of either the FCC registration number and Ringer Equivalence Number (REN), or the IC registration number . You must, upon request, provide this information to your local telephone company.
This equipment is compatible with in­ductively coupled hearing aids.
Should you experience trouble with this telephone equipment, please contact:
In the United States: VTECH COMMUNICATIONS 1-800-595-9511. In Canada: VTECH ELECTRONICS 1-800-267-7377.
The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected.
FCC Part 15
Warning: Changes or modifica­tions to this unit not expressly approved by the party respon­sible for compliance's could void the user’s authority to operate the equipment.
The equipment has been tested and found to comply with part 15 of the FCC rules. These limits are designed to pro­vide reasonable protection against harmful interference in a residential in­stallation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not oc­cur in a particular installation. If this equipment does cause harmful inter­ference to radio or television reception, which can be determined by turning the equipment off and on, the user is en­couraged to try and correct the inter­ference by one or more of the following measures:
- Reorient or relocate the receiving an­tenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet or on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Part 68
The FCC requires that you connect your cordless telephone to the nation­wide telephone network through a modular telephone jack (USOC RJ11C, RJ11W or RJ14).
Your telephone company may discon­tinue your service if your equipment causes harm to the telephone network.
30
FCC AND IC REGULATIONS
They will notify you in advance of dis­connection, if possible. During notifi­cation, you will be informed of your right to file a complaint with the FCC.
Occasionally, your telephone company may make changes in its facilities, equipment, operation, or procedures that could affect the operation of your equipment. If so, you will be given ad­vance notice of the change to give you an opportunity to maintain uninter­rupted service.
The Base Unit contains no user serv­iceable parts. The Handset contains a user replaceable battery pack.
If it is determined that your telephone equipment is malfunctioning, the FCC requires that it not be used and that it be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents or by others who may be authorized by the FCC. For repair procedures, follow the in­structions outlined under the Limited Warranty.
This equipment may not be used on coin service provided by the phone company or Party Lines.
The REN is useful in determining the number of devices you may connect to your telephone line and still enable the devices to ring when you receive a call. The general rule is that the REN value should not exceed 5.0 total; however, contact your local telephone company for the specific number in your area.
IC (Industry Canada)
This telephone is registered for use in Canada.
Notice:The Ringer Equivalence Number(REN) assigned to each termi­nal device denotes the percentage of the total load to be connected to a tel­ephone loop which is used by the de­vice, to prevent overloading. The ter­mination of a loop may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalent Numbers of all de­vices not exceed 5.0.
Notice: The Industry Canada la­bel identifies certified equipment. This certification means that the equipment meets certain tele­communications network protec­tive, operational and safety re­quirements. The Department does not guarantee the equip­ment will operate to the user's sat­isfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the lo­cal telecommunications company. The equipment must also be installed us­ing an acceptable method of connec­tion. The customer should be aware that compliance with the above condi­tions may not prevent degradation of services in some situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the
31
FCC AND IC REGULATIONS
telecommunications company cause to request the user to disconnect the equipment.
Users should ensure, for their own pro­tection, that the electrical ground con­nections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected to­gether. This precaution may be par­ticularly important in rural areas.
Caution: Users should not at­tempt to make such connections themselves, but should contact the appropriate electrical inspec­tion authority, or electrician, as appropriate.
Y our VTech VT 9141 is designed to op­erate at the maximum power allowed by the FCC and IC. This means your Handset and Base Unit can communi­cate only over a certain distance - which will depend on the location of the Base Unit and Handset, weather, and the con­struction and layout of your home or office.
32
TECHNICAL SPECIFICATIONS
FREQUENCY CONTROL
Crystal Controlled Dual PLL Syn-
thesizer
TRANSMIT FREQUENCY
Handset:923.10 MHz to 927.75
MHz (All thirty channels within this range)
Base:902.30 MHz to 906.65 MHz
(All thirty channels within this range)
RECEIVE FREQUENCY
Handset:902.3 MHz to 906.65 MHz
(All thirty channels within this range)
Base:923.10 MHz to 927.75 MHz
(All thirty channels within this range)
NOMINAL EFFECTIVE RANGE
Maximum power allowed by FCC.
Actual operating range may vary ac­cording to environmental conditions at the time of use.
WEIGHT
Handset: 171 grams Base: 485 grams
POWER REQUIREMENTS
Handset:Self-contained nickel-cad-
mium rechargeable battery supply,
3.6V nominal, 400mAh capacity.
Power Adapter: 9V DC@400mA
SPECIFICATIONS ARE TYPI­CAL AND MA Y CHANGE WITH­OUT NOTICE.
The range quoted for this phone is
based on open field measurements under ideal conditions.
SIZE
Handset:17.3cm x 5.6cm x 3.8cm
(L x W x T) maximum (antenna excluded)
Base:21.9cm x 16.4cm x 5.4cm
(L x W x T) maximum (antenna excluded)
33
34
35
Loading...
