Installation

Parts checklist

Remember to save your sales receipt and original packaging in case it is necessar y to ship your telephone for warranty service. Check to make sure the telephone package includes the following:

1. Handsets (2 for 6041/6044, 3 for 6051)

2. Chargers (1 for 6041/6044, 2 for 6051)

3. Charger adapters (1 for 6041/6044, 2 for 6051)

4. Base power adapter

5. Telephone line cord

6. Batteries (2 for 6041/6044, 3 for 6051)

7. Battery compartment covers (2 for 6041/6044, 3 for 6051)

8. Telephone base

9. User’s manual

1. Handsets

4. Base power adapter

2. Chargers

5. Telephone line cord

3. Charger adapters

6. Batteries

To p urc has e

• re pl ace men t ba tt eri es, or obtain a replacement power adapter, vi si t our website a t www. vte chpho nes. com or call 1 (800) 595-9511. In Canada go to www.vtechcanada. com or dial 1 (800) 267-7377.

For 6044,

• the battery compartment covers are attached to the handsets.

Installation

Basic operation

7. Battery compartment covers

www.vtechphones.com

8. Telephone base

9. User’s manual

If the handset will

• not be used for a long period of time, remove the bat tery to prevent possible leakage.

To p urc has e

• re pl ace men t ba tt eri es, vi sit our website at ww w. vt ec hph one s. co m or call 1 (800) 595-9511. In Canada go to www.vtechcanada. com or dial 1 (800) 267-7377.

Installation

Install handset battery

• Remove battery compartment cover by pressing on the indentation and sliding it downwards (only for 6044).

• Align the two holes in the plug with the socket pins according to the color-coded label in the battery compartment, then snap the plug into place.

• Place the battery into the compartment.

• Position the battery compartment cover and slide it upwards until it clicks into place.

• Put the handset in the telephone base or the charger to charge the new battery for at least 16 hours. The battery may have enough charge for short calls. For best performance, charge it for at least 16 hours.

You can keep the battery charged by returning the handset to the telephone base or charger after each use. When the batter y power is fully depleted, a full recharge takes about 16 hours.

For further information on batteries, please see the

color-coded label

Battery section on page 30.

www.vtechphones.com

Installation

Telephone base installation

Install the telephone base and the charger as shown below. Choose a location away from any electronic equipment and appliances such as personal computers, computer routers, television sets, microwave ovens, and refrigerators. Avoid excessive heat, cold, dust or moisture.

1. Plug the telephone line cord into a telephone wall jack.

2. Plug the power adapter into an electrical outlet not controlled by a wall switch.

Use only the

• VTech batteries and power adapters (or equivalent) supplied with this telephone. To obtain a replacement, visit our website at www.vtechphones. com or call 1 (800) 595-9511. In Canada go to www.vtechcanada. com or dial 1 (800) 267-7377.

•

This power unit is intended to be correctly oriented

in a vertical or oor

mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-thetable or cabinet outlet.

Installation

Basic operation

www.vtechphones.com

Installation

Desk/table bracket installation

The telephone base comes with the desk/table bracket installed and ready for tabletop use.

To remove the bracket:

1. Push the bracket away from the telephone base as shown below. Do not remove the bracket by force to avoid breakage of the tabs.

Dial type

If you have touch-tone service, your telephone is ready to use as soon as the battery is charged.

If you have pulse (rotary) service, the dial type must be changed. To change the dial type, see Dial type on page 12.

To install the bracket:

1. Align the tabs of the bracket with the slots at the bottom of the telephone base as shown in the diagram.

2. Slide the bracket towards the center of the tele phone base until it click s into place.

www.vtechphones.com

Installation

If you subscribe to DSL service

If you receive high speed internet through your telephone line (commonly referred to as DSL), and you are experiencing interference during telephone conversations and/or your caller ID features are

not functioning properly, install a DSL lter to the telephone line between the telephone base and the telephone wall jack. Contact your DSL provider for a DSL lter.

DSL lter (for

DSL users)

To single telephone jack (RJ11C) Telephone line cord

Installation

Basic operation

www.vtechphones.com

Telephone settings

Handset layout

1. Earpiece

/ (directory/volume)

(speakerphone)

5. Dialing keys (0-9, *, #)

6. REDIAL/PAUSE

7. Microphone

8. Handset display

9. MENU/SELECT

10. CID/

11. OFF/CLEAR

12. MUTE/REMOVE

13. INT (intercom)

/FLASH

(caller ID/volume)

2 3

10 11

12 13

www.vtechphones.com

Telephone settings

Telephone base layout

1. CHARGE light

2. IN USE light

3. VOICEMAIL light

4. FIND HANDSET

Telephone settings

Basic operation

1 2 3

www.vtechphones.com

Telephone settings

When entering

• the date or time, if the digit is single, a zero must be

entered rst (i.e.

if the time is 6:08, you must enter

0608).

If you have

• more than one handset, setting the date and time on one handset will apply to all other handsets.

Date and time

• Press MENU/SELECT to display menu when in idle mode.

• Press

• Use the keypad to set the year. Press

• Use the keypad to set the date. Press

•

Use the keypad to set the time. Press or to select a.m. or p.m.

or to reach DATE/TIME. Press MENU/SELECT.

MENU/SELECT. MENU/SELECT.

Press MENU/SELECT.

• The screen displays STORED

and you’ll hear a conrmation beep.

Ring melody

There are ten ring melodies for the handset to choose from.

• Press

• The screen displays STORED

MENU/SELECT to display menu when in idle mode.

or to reach SETUP HS. Press MENU/SELECT. or to reach RING MELODY. Press MENU/SELECT, and

a checkmark is shown next to the current ring melody.

or to scroll through the choices and a sample of each

ring melody will be played. Press MENU/SELECT.

and you’ll hear a conrmation beep.

www.vtechphones.com

YeAr 200\

dAte \1/01

tIMe \2:12AM

rING MelodY rING voluMe

MelodY 1 MelodY 2

Stored

Telephone settings

Ring volume

The handset ringer volume can be adjusted from ve levels.

• Press

Battery low tone

The handset is preset to beep when the battery level is low. If you wish to change this setting:

• Press

• A checkmark is shown next to the current selection. Press

• The screen displays STORED

MENU/SELECT to display menu when in idle mode.

or to reach SETUP HS. Press MENU/SELECT. or to reach RING VOLUME. Press MENU/SELECT. or to scroll through the choices and a sample of each ring

volume will be played. Press MENU/SELECT to conrm. The screen displays STORED

MENU/SELECT to display the menu when in idle mode.

or to reach SETUP HS. Press MENU/SELECT. or to reach TONES. Press MENU/SELECT. or to reach BATTERY LOW. Press MENU/SELECT.

to choose ON or OFF. Press MENU/SELECT.

and you’ll hear a conrmation beep.•

and you’ll hear a conrmation beep.

toNeS HANdSet NAMe

BAtterY low out of rANGe

oN off

The handset will

• not ring when the ringer volume is at the lowest setting. A ringer off icon will be displayed.

While the

• telephone is ringing, you can temporarily silence the ringer by pressing

OFF/CLEAR MUTE/REMOVE

The ringer off icon

will display on the handset. The next call will ring normally.

Telephone settings

Basic operation

www.vtechphones.com

Telephone settings

Press OFF/CLEAR

• at anytime to return to the previous screen.

Press and hold

•

OFF/CLEAR

anytime to exit the menu.

Out of range tone

The handset will beep during a conversation when it is out of range from the telephone base. This tone is preset to ON. If you wish to change this setting:

• Press

• A checkmark is shown next to the current selection. Press

• The screen displays STORED

MENU/SELECT to display the menu when in idle mode.

or to reach SETUP HS. Press MENU/SELECT. or to reach TONES. Press MENU/SELECT. or to reach OUT OF RANGE. Press MENU/SELECT.

to choose ON or OFF. Press MENU/SELECT.

and you’ll hear a conrmation beep.

Key tone

The handset is preset to beep whenever any button is pressed. To change this setting:

• Press

• A checkmark is shown next to the current selection. Press

• The screen displays STORED

MENU/SELECT to display the menu when in idle mode.

or to reach SETUP HS. Press MENU/SELECT. or to reach TONES. Press MENU/SELECT. or to reach KEY BEEPS. Press MENU/SELECT.

or to

select ON or OFF. Press MENU/SELECT.

and you’ll hear a conrmation beep.

www.vtechphones.com

toNeS HANdSet NAMe

out of rANGe KeY BeePS

oN off

Telephone settings

Edit handset name

• Press MENU/SELECT to display the menu when in idle mode.

• Press

Press MUTE/REMOVE to backspace and erase characters. Press and

•

hold MUTE/REMOVE to delete the entire entry. Press * to alternate between uppercase and lowercase.

• Use the keypad to enter characters (see the chart on page 18). Press

MENU/SELECT.

• The screen displays STORED

or to reach SETUP HS. Press MENU/SELECT. or to reach HANDSET NAME. Press MENU/SELECT.

and you’ll hear a conrmation beep.

Language

To change the language for all screen displays:

• Press

• A checkmark is shown next to the current selection. Press

• Press

• The screen displays STORED

MENU/SELECT to display menu when in idle mode.

or to reach SETUP HS. Press MENU/SELECT. or to reach LANGUAGE. Press MENU/SELECT.

to choose the desired language.

MENU/SELECT.

and you’ll hear a conrmation beep.

www.vtechphones.com

HANdSet NAMe lANGuAGe

eNter NAMe HANdSet

lANGuAGe reSet

A handset name

• can be up to 14 characters.

Only handset

• display screens are affected by the language setting.

Basic operation

Telephone settings

The clear voicemail

• feature only turns off the displayed

NEW VOICEMAIL

message and VOICEMAIL light on the telephone base. It does not delete your voicemail message(s). Use this feature when the telephone indicates there is voicemail when you have none or you have accessed your voicemail from a remote location (while away from home). If there is actually a new voicemail message, your local telephone company will continue to send a signal which will cause the

NEW VOICEMAIL

message in the handset and the telephone base VOICEMAIL light to

ash.

Dial type

The dial type is preset to touch tone. If you have pulse (rotary) service, the dial type must be changed.

• Press MENU/SELECT to display menu when in idle mode.

• Press

or to reach SETUP BS. Press MENU/SELECT. or to reach DIAL T YPE. Press MENU/SELECT.

• A checkmark is shown next to the current selection. Press

to choose between TONE and PULSE. Press MENU/SELECT.

• The screen displays STORED

and you’ll hear a conrmation beep.

Clear voicemail

If you subscribe to voicemail services provided by your local telephone company, NEW VOICEMAIL will appear on the handset display and the VOICEMAIL light on the telephone base will ash when you have a new voicemail message. This feature allows you to turn off these indicators.

• Press

• The screen displays INDICATOR OFF?

• The screen displays STORED

MENU/SELECT to display the menu when in idle mode.

or to reach SETUP BS. Press MENU/SELECT. or to reach CLR VOICEMAIL. Press MENU/SELECT.

Press MENU/SELECT.

and you’ll hear a conrmation beep.

www.vtechphones.com

dIAl tYPe clr voIceMAIl

toNe PulSe

clr voIceMAIl reSet

INdIcAtor off?

Telephone settings

Reset to default settings

The handset and the telephone base can be individually reset to their default settings by selecting RESET in the SETUP HS or SETUP BS menus respectively.

• Press

•

• Press or to reach RESET. Press MENU/SELECT.

• The screen displays RESET?

• The screen displays STORED

MENU/SELECT to display menu when in idle mode.

Press or to reach SETUP HS or SETUP BS. Press MENU/SELECT.

Press MENU/SELECT to conrm or

OFF/CLEAR to exit to the previous menu.

and you’ll hear a conrmation beep.

Temporary tone dialing

If you have pulse (rotary) service, you can change from pulse to touch tone dialing during a call by pressing *TONE. This is useful if you need to send touch tone signals for access to telephone banking or long distance services.

Press /FLASH.

•

Press *TONE. Buttons pressed after this send touch tone signals.

• Dial the number.

• After hanging up, the telephone automatically returns to pulse

• dial service.

www.vtechphones.com

reSet rING MelodY

reSet?

When the handset

• or telephone base settings are reset to default, all items stored in memory will be deleted. This includes the directory and call log entries.

Basic operation

Press or to

• adjust the listening volume during a conversation.

Basic operation

Make, answer and end calls

• Press /FLASH or , then use the keypad to dial a number.

-OR-

•

Dial a number (press MUTE/REMOVE to make corrections) and then press

/FLASH or .

• Press /FLASH, or any dialing keys (0-9, * or #) to answer an

incoming call.

• Press OFF/CLEAR or put the handset back in the telephone base or

charger to end a call.

• The call timer will be activated during a call to show call duration.

Options while on calls Speakerphone

•

Press to alternate between speakerphone and normal handset use.

Mute

•

Press MUTE/REMOVE on the handset to silence the microphone during a conversation. You can still hear the caller but the caller cannot hear you.

• The screen displays

• Press MUTE /REMOVE again to resume conversation.

Call waiting

If you subscribe to call waiting service and you are on a call when a new call comes in, you will hear a beep. The caller ID information will be displayed if you subscribe to caller ID service from your local telephone company.

• Press the current call on hold.

• Press

/FLASH on the handset to answer the incoming call and put

/FLASH at anytime to alternate between calls.

MUTE.

www.vtechphones.com

PHoNe 00:00:10 595-9511

MUTE

Basic operation

Intercom call

This feature allows conversation between handsets.

• For 6051, press Use the keypad to select a destination handset. The screen of the originating

• handset displays CALLING HANDSET X

For 6041/6044, press INT on a handset and its screen displays

• CALLING HANDSET X.

• The destination handset rings and its screen displays CALLING FROM:

HANDSET X

•

Press /FLASH or on the destination handset to answer the call.

• To end an intercom call, press OFF/CLEAR on the handset or by placing the handset back on the telephone base or charger.

Multiple handset use

While on a call, the person on the other handset can join the conversation.

• Press join the conference conversation at the same time.)

• Press OFF/CLEAR, or place the handset in the telephone base or charger to drop out of the call. The external call will not be terminated until both handsets hang up.

Answer an external call during an intercom call

There will be an alert tone to signify an incoming external call during an intercom call and the screen displays CALL WAITING.

Disconnect the intercom call by pressing OFF/CLEAR and the handset will ring.

• Press

• incoming call.

INT on a handset and its screen displays NUMBER.

/FLASH or to join the conversation. (Only two handsets can

/FLASH, or any dialing keys (0-9, * or #) to answer the

www.vtechphones.com

cAllING

HANdSet X

cAllING froM:

HANdSet X

coNf 00:02:48

Basic operation

If the destination

• handset does not answer, press

OFF/CLEAR

the originating handset to return to the external call.

Transfer an external call

An external call can be forwarded to another handset during a conversation.

• For 6041/6044, press

CALLING HANDSET X while putting the external call on hold. For 6051, press INT on the originating handset and its screen displays

•

NUMBER while putting the external call on hold. Use the keypad to select a destination handset and its screen will display CALLING HANDSET X.

• The destination handset rings and its screen displays CALLING FROM:

HANDSET X

• After the destination handset answers, press MENU/SELECT and then press or to reach CONFERENCE.

•

Press MENU/SELECT to let the destination handset join the conversation.

• Press MENU/SELECT and the screen displays END CONFERENCE and then press MENU/SELECT to return to the intercom conversation.

•

During the intercom conversation, press MENU/SELECT and or to reach OTHER CALL to return to the external call and put the intercom on hold. Repeat this step to switch between the external and intercom calls.

• Press OFF/CLEAR on the originating handset to forward the external call to the destination handset.

INT on the originating handset and its screen displays

Find handset

• Press FIND HANDSET on the telephone base to locate the handset. All handsets will ring and PAGING will ash on the screen of all handsets.

•

Press FIND HANDSET again or put the handsets back on the telephone base or charger to stop the paging tone.

www.vtechphones.com

coNfereNce otHer cAll

otHer cAll coNfereNce

eNd coNfereNce

PAGING

Advanced operation

Review the directory

• Press / to enter the directory.

• Press

-OR-

• Press

or to browse and press OFF/CLEAR to exit.

MENU/SELECT to display menu when in idle mode.

or to reach DIRECTORY. Press MENU/SELECT. or to reach REVIEW. Press MENU/SELECT. or to browse and press OFF/CLEAR to exit.

Search the directory

Entries are sorted alphabetically and names beginning with numbers

are listed rst.

An alphabetical search can be done after entering the directory. Enter

the rst letter of the name using the char t on page 18. The rst name

beginning with that letter will be displayed.

For example, press 5 (JKL) once to nd Jenny, twice to nd Kristen, or three times to nd Linda.

-OR-

You can search the directory by pressing

or on the handset.

www.vtechphones.com

dIrectorY cAll loG

Advanced operation

revIew Store

vtecH 1-595-9511

Press

•

repeatedly to alternate between uppercase and lowercase when entering characters.

Advanced operation

Character chart

Use the keypad and the chart below to enter a name (up to 15 characters). Each press of a particular key causes the characters to be displayed in the following order:

Number key

1 space 1 * ? ! / ( )

2 A B C 2

3 D E F 3

4 G H I 4

5 J K L 5

6 M N O 6

7 P Q R S 7

8 T U V 8

9 W X Y Z 9

0 0

* Uppercase/lowercas e

# #

• Press MUTE /REMOVE to backspace and erase a single character.

•

Press and hold MUTE/REMOVE to delete the entire entry.

•

Press and hold REDIAL/PAUSE to insert a dialing pause (P will be displayed on screen) when entering a telephone number.

1 2 3 4 5 6 7 8 9

www.vtechphones.com

Characters b y number of key presses

, - . &

Advanced operation

Store a directory entry

• Press MENU/SELECT twice to enter the DIRECTORY.

• Press

• The screen displays ENTER NUMBER number and then press MENU/SELECT.

• The screen displays ENTER characters and then press MENU/SELECT.

• The screen displays STORED

or to reach STORE and then press MENU/SELECT.

. Use the keypad to enter the

NAME. Use the keypad to enter the

and you’ll hear a conrmation beep.

Dial a directory entry

• Press / to enter the directory.

• Press

search to nd it.

• Press

-OR-

• Press

search to nd it.

• Press

or to scroll to the desired entry, or use the alphabetical

/FLASH or to dial.

MENU/SELECT to display menu when in idle mode.

or to reach DIRECTORY. Press MENU/SELECT. or to reach REVIEW. Press MENU/SELECT.

or to scroll to the desired entry, or use the alphabetical

/FLASH or to dial.

www.vtechphones.com

Store revIew

eNter NuMBer

Advanced operation

eNter NAMe

Stored

Advanced operation

Press OFF/CLEAR

• to return to the previous screen. Press and hold

OFF/CLEAR

exit the menu if you do not want to delete all the entries.

Edit a directory entry

• Press / or MENU/SELECT three times to enter the directory.

• Press

search to nd the number. Press MENU/SELECT.

•

The screen displays ENTER NUMBER. Use MUTE/REMOVE and the keypad to edit the number and press MENU/SELECT.

• The screen displays ENTER NAME. Use MUTE / keypad to edit the name and then press MENU/SELECT.

• The screen displays STORED

or to scroll to the desired entry or use the alphabetical

REMOVE and

and you’ll hear a conrmation beep.

Delete from the directory

• Press / or MENU/SELECT three times to enter the directory.

• Press

To delete one entry

• Press

• The screen displays DELETED

To delete all entries

•

Press and hold MUTE/REMOVE.

• The screen displays DELETE ALL?

• The screen displays DELETED

or to scroll to the desired entry

MUTE/REMOVE.

and you’ll hear a conrmation beep.

and there is a conrmation beep.

www.vtechphones.com

Press MENU/SELECT.

the

eNter NuMBer

eNter NAMe

Stored

deleted

delete All?

Advanced operation

About caller ID

If you subscribe to caller ID service from your local telephone company, this feature displays the name and telephone number of the caller before answering a call (even when you are on another call). The caller ID features of this product will work only if you subscribe to caller ID service and both you and the caller are in areas offering caller ID service, and if both telephone companies use compatible equipment.

Contact your local telephone company if:

you have both caller ID and call waiting, but as separate services (you may need combined service),

•

• you have only caller ID service, or only call waiting ser vice,

• you do not subscribe to caller ID or call waiting services but wish to try them.

There may be fees for these services, and they may not be available in all areas.

This product can be used without subscribing to either caller ID or combined caller ID with call waiting service, although the caller ID features of this product will not function.

Advanced operation

www.vtechphones.com

Due to regional

• service differences, the caller ID information may not be available for every incoming call. In addition, the callers may intentionally block their name and/or telephone number.

The time is

• automatically set and updated with incoming caller ID information if you subscribe to this service.

Advanced operation

Call log

The information of the caller will be displayed if you subscribe to caller ID service from your local telephone company.

• The call log can store up to 50 entries. Each entry may consist of a number up to 20 digits and a name up to

• 15 characters. If the number consists of more than 20 digits, the last 20 digits will be displayed and stored. If the name consists of more than 15

characters, the rst 15 characters will be displayed and stored.

•

Entries are displayed in chronological order with the most recent entry rst.

• When the call log is full, the oldest entry will be deleted to make room for the new incoming call information.

• The screen displays EMPTY if there is no record in the call log.

• The screen displays NEW if there are new call log entries (missed and unread calls).

• Duplicate or anonymous calls (no caller ID information) will be stored in the call log.

Review the call log

• Press CID/ to enter the call log.

-OR-

Press MENU/SELECT. Press or to select CALL LOG.

•

• Press

• The name (if available), number, date and time of the incoming call are

MENU/SELECT and then press or to browse through the

entries.

displayed on the screen.

JoHNNY fu

2-345-6789

New

05:27PM 11/23

eMPtY

www.vtechphones.com

Advanced operation

Dial a call log number

• Press CID/ to enter the call log.

-OR-

Press MENU/SELECT. Press or to select CALL LOG.

•

• Press

Store a call log number

• Press CID/ to enter the call log.

-OR-

•

• Press MENU/SELECT and the screen displays ENTER NAME.

• Use the keypad to enter the name and then press

• The screen displays STORED

MENU/SELECT and then press or to scroll to the desired

entry.

/FLASH or to dial.

Press MENU/SELECT. Press or to select CALL LOG. Press MENU/SELECT and then press or to scroll to the desired

entry.

MENU/SELECT.

and you’ll hear a conrmation beep.

eNter NAMe

Stored

While reviewing

• the call log, press # repeatedly to display the other dialing options. Available options are: 1 + area code + number, area code + number, 1 + number, number only. The various dialing options are:

595-9511 1-595-9511 800-595-9511 1-800-595-9511

Advanced operation

www.vtechphones.com

Press and hold

•

OFF/CLEAR

exit the menu if you do not want to delete all the entries or press

OFF/CLEAR

to return to the previous screen.

Advanced operation

Delete from the call log

• Press CID/ to enter the call log.

-OR-

Press MENU/SELECT. Press or to select CALL LOG, then

•

press MENU/SELECT.

To delete one entry

• Press MUTE/REMOVE.

• The screen displays

To delete all entries

•

Press and hold MUTE/REMOVE when in the CALL LOG.

• The screen displays DELETE ALL?

• The screen displays DELETED

or to scroll to the desired entry and then press

DELETED and you’ll hear a conrmation beep.

Press MENU/SELECT.

and you’ll hear a conrmation beep.

deleted

delete All?

www.vtechphones.com

Advanced operation

Redial

The redial list can store up to 10 of the most recently dialed numbers.

• When there are already 10 entries in the redial list, the oldest entry will be deleted to make room for the new one.

• The screen displays EMPTY if there is no record on the list.

Review redial

• Press REDIAL/PAUSE to enter the redial list.

• Press

Store a redial number to the directory

• Press REDIAL/PAUSE to enter the redial list.

• Press

• The screen displays ENTER NAME

• Use the keypad to enter the name and then press

• The screen displays STORED

or to browse through the entries.

or to scroll to the desired entry. Press MENU/SELECT.

MENU/SELECT.

and you’ll hear a conrmation beep.

Advanced operation

www.vtechphones.com

Press and hold

•

OFF/CLEAR

exit the menu if you do not want to delete all the entries. Press

OFF/CLEAR

to return to the previous screen.

Advanced operation

Dial from redial

• Press REDIAL/PAUSE to enter the redial list.

• Press

Delete from redial

• Press REDIAL/PAUSE to enter the redial list.

To delete one entry

• Press MUTE/REMOVE.

• The screen displays

To delete all entries

•

Press and hold MUTE/REMOVE.

• The screen displays DELETE ALL?

• The screen displays DELETED

or to scroll to the desired entry.

/FLASH or to dial.

or to scroll to the desired entry and then press

DELETED and you’ll hear a conrmation beep.

Press MENU/SELECT.

and you’ll hear a conrmation beep.

deleted

delete All?

www.vtechphones.com

Handset and telephone base indicators

Handset light

• On when the handset speakerphone is in use.

Telephone base lights

IN USE • Flashes when there is an incoming call.

• On when the handset is in use.

VOICEMAIL • Flashes when there is a new network message (a subscription service

CHARGE • On when the handset is in the telephone base.

Handset icons

from your local telephone company is required).

• Ringer off.

(Battery indicator)

MUTE

• Cycles (low, medium, and full) when handset battery is charging.

•

Flashes when the battery power is low.

• The microphone is muted temporarily during a conversation.

www.vtechphones.com

Appendix

Handset display screen messages

Display: When:

cAll

cAllING HANdSet X

cAllING froM: HANdSet X

cHArGING

coNNectING...

eMPtY

eNded

full

INtercoM

lINe IN uSe

low BAtterY

rINGer Mute

New

New voIceMAIl

Not AvAIlABle

No lINe

There is an incoming call.

Calling another handset.

Other handset is calling.

A handset with low batter y has been placed on the telephone base to

The cordless handset is searching for the telephone base.

There are no entries in the call log, directory, or redial list.

You have just ended a call.

The directory is full.

The handset is on an intercom call.

Another handset connected to the same line is in use.

The battery needs to be recharged.

The ringer is muted temporarily when there is an incoming call.

There are un-reviewed calls in the call log.

There is new voicemail message.

There is no line or the handset is out of range from the telephone base.

-OR-

If one handset is already viewing the call log and another handset attempts to review it.

There is no telephone line connected.

www.vtechphones.com

recharge.

Handset display screen messages

Display: When:

PAGING

PHoNe

PlAce IN cHArGer

wArNING cHecK BAtterY!

The handset locator has been activated or the handset is being paged.

The handset is in use.

The battery is very low. The handset should be placed on the telephone base to recharge.

The battery is not installed or not installed properly in the handset.

-OR -

The battery needs to be replaced.

-OR -

An incorrect battery has been installed by mistake. Use only the supplied VTech battery.

Call log display screen messages

Display: When:

PrIvAte NAMe

PrIvAte NuMBer

PrIvAte cAller

uNKNowN NAMe

uNKNowN NuMBer

uNKNowN cAller

loNG dIStANce or l

(before caller’s number)

The caller is blocking name information.

The caller is blocking telephone number information.

The caller is blocking name and number information.

This caller’s name is unavailable.

This caller’s number is unavailable.

No call information is available about this caller.

This is a long distance call.

Appendix

www.vtechphones.com

Battery

After the battery is fully charged for 16 hours, you can expect the following performance:

Operation Operating time

While in use (talking)

While not in use (standby*)

*Hands et is off t he telep hone ba se but not i n use.

The battery needs charging when:

• A new battery is installed in the handset.

• Battery indicator on screen is ashing.

CAUTION:

1. Use only the supplied battery (part number 89-1326-00-00) or equivalent. To order a replacement, visit our website at www.vtechphones.com or call 1 (800) 595-9511. In Canada go to www.vtechcanada.com or dial 1 (800) 267-7377.

2. Do not dispose of the battery in a re. Check with local waste management codes for special disposal instructions.

3. Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may cause burns or injury to the eyes or skin. The electrolyte may be toxic if swallowed.

4. Exercise care in handling batteries in order not to create a short circuit by letting them come into contact with conductive materials such as rings, bracelets, and keys. The battery and/or conductor may overheat and cause burns.

5. Charge the batter y(ies) provided with or identied for use with this product only in accordance with the instructions and limitations specied in this manual.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO WATER OR ANY TYPE OF MOISTURE.

10 hours

100 hours

www.vtechphones.com

Important safety instructions

When usi ng your tele phone eq uipmen t, basic s afety pr ecauti ons shou ld always be f ollowed:

1. Rea d and under stand a ll instr uction s.

2. Foll ow all warn ings and i nstru ctions m arked on th e produc t.

3. Unp lug this p roduc t from the wa ll outle t before cl eaning. D o not use li quid or aer osol cl eaners . Use a damp c loth for c leaning .

4. Do no t use this p roduc t near water (fo r example, n ear a bathtu b, kitch en sink, or s wimmin g pool).

5. Do no t place th is produ ct on an un stable s urfac e such as a ta ble, she lf or stan d. This pro duct may f all, caus ing seri ous dama ge.

6. Slo ts an d ope nings in th e bac k or botto m of the te lephon e bas e and handset are provi ded fo r vent ilation . To prote ct t hem fr om over heatin g, th ese o pening s must not be blocke d by placing the pr oduct on a sof t sur face such as a bed, sofa or rug. Thi s produc t should neve r be placed nea r or over a radiator or heat re gister. This pr oduct sh ould not be plac ed in an are a where pro per venti lation i s not provi ded.

7. Thi s produc t should be oper ated only fro m the type of power sou rce indi cated on the mark ing label . If you are not sure of the type of powe r supply in your hom e, consult you r dealer or l ocal po wer compa ny.

8. Do no t allow any thing to r est on the p ower cord . Do not ins tall thi s produc t where th e cord may b e walked on.

9. Neve r push objects of any kind into this pro duct throu gh slots in the telepho ne base or handset as they may touch dang erous volta ge points or create a short cir cuit that could

result in a r isk of re o r electr ic shoc k. Never sp ill liqu id of any kin d on the pro duct.

To reduce the risk of electr ic shock , do not disassem ble this prod uct, but take it to an authoriz ed servi ce facilit y. Opening or removi ng parts of the telep hone base or hand set other

10.

than spe cied a ccess d oors may ex pose you to d angero us voltag es or other r isks. In correc t reass emblin g can caus e elect ric shoc k when th e produc t is subs equentl y used.

11. D o not overl oad wall ou tlets an d extensi on cord s as this ca n result i n the risk o f re or elec tric sh ock.

12. U nplug th is produ ct from t he wall out let and ref er serv icing to a n authori zed ser vice fac ility u nder the f ollowin g condi tions:

A. When the power s upply c ord or plug i s damage d or frayed. B. If liquid has b een spil led onto t he produ ct. C. If t he prod uct has be en expos ed to rain or w ater. D. If t he prod uct doe s not opera te normal ly by follo wing the o peratin g instru ction s. Adjust o nly thos e contr ols that ar e covered by t he operat ion inst ructi ons, as im proper

adjustm ent of othe r contro ls may resul t in damag e and ofte n requir es extens ive work by a n authori zed techn ician to r estore th e produ ct to norm al operat ion.

E. If the produ ct has bee n droppe d and the te lephon e base and /or hand set has bee n damage d. F. If the pro duct exh ibits a d istinc t change i n perfo rmanc e.

13. The power u nit is intende d to be corre ctly o riente d in a v ertic al or  oor mo unt po sition. The pr ongs a re not design ed to h old th e plug in plac e if i t is pl ugged into a ceiling ,

under-th e-tab le or cabi net outl et.

14. Avo id using a t elepho ne (other th an cordl ess) durin g an elec trical s torm. Th ere is a remo te risk of el ectri c shock f rom ligh tning.

15. D o not use th e teleph one to rep ort a gas l eak in the v icinit y of the le ak.

16. O nly put th e hands et of your tele phone n ext to your ea r when it is i n normal t alk mode.

CAUTION: Use o nly the po wer adapte r provid ed with th is produ ct. To purcha se, visit o ur websit e at www.vte chphon es.com o r call 1 (80 0) 595-9 511. In Canada go to www.vtec hcana da.com o r dial 1 (80 0) 267-7377.

SAVE THESE INSTRUCTIONS

www.vtechphones.com

Appendix

Troubleshooting

If you have difculty with your telephone, please try the suggestions below. For Customer Service, visit our website at www. vtechphones.com, or call 1 (800) 595-9511; in Canada go do www.vtechcanada.com or dial 1 (800) 267-7377.

Problem Suggestion

My telephone does not work at all.

LOW BATTERY is displayed on screen.

• Make sure the batter y is installed and charged c orrectly (page 2). For optimum daily performance, return the cordless handset to the telephone base or charger after use.

• Make sure the power adapter is securely plugged into an outlet not controlled by a wall switch.

•

Make sure the telephone line cord is plugged rmly into the telephone base and the wall jack.

• Unplug the unit’s electrical power. Wait for approximately 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to synchronize.

• Charge the battery in the cordless handset for at least 16 hours.

• Remove and re-insert the battery. If that still does not work, it may be necessary to purchase a new battery.

• Disconnect the telephone base from the jack and plug in a working telephone. If this telephone does not work, the problem is probably in the wiring or the local service. Call the local telephone company.

• Place the handset in the telephone base or charger for recharging.

• Remove and re-install the battery and use it normally until fully discharged, then recharge the handset on the telephone base or charger for 16 hours.

• If the above measures do not correct the problem, the battery may need to be replaced.

www.vtechphones.com

Troubleshooting

Problem Suggestion

The battery does not charge in the handset or the handset battery does not accept charge.

The CHARGE light is off.

• Make sure the handset is placed in the telephone base or charger correctly. The CHARGE

light on the telephone base or charger should be on.

• Remove the battery from the handset and then re-install it in the handset. Put the handset back to the telephone base or charger and charge for 16 hours.

• If the cordless handset is in the charger or in the telephone base but the CHARGE light is not on, see The CHARGE light is off in this section.

• It may be necessary to purchase a new battery. Please see the Battery section of this user’s manual (page 30).

• The telephone might be malfunctioning. Please see the Warranty section of this user’s manual (page 42) for further instruction.

• Clean the charging contacts on the cordless handset(s) and telephone base each month using a pencil eraser or a dry non-abrasive fabric.

• Make sure the power adapter and telephone line cords are plugged in correctly and securely.

• Unplug the power adapter. Wait for 15 seconds before plugging it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• The telephone might be malfunctioning. Please see the Warranty section of this user’s manual (page 42) for further instruction.

Appendix

www.vtechphones.com

Troubleshooting

Problem Suggestion

There is no dial tone. • First, try all the above suggestions.

• Move the cordless handset closer to the telephone base. It might be out of range.

• The telephone line cord might be malfunctioning. Try installing a new telephone line cord.

• Disconnect the telephone base from the telephone jack and connect a different telephone. If there is no dial tone on the other telephone either, the problem is in your wiring or local service. Contact your local telephone company.

My handset dis play s

CONNECTING...

My handset dis play s

NOT AVAILABLE

•

Move the handset closer to the telephone base. You might have moved out of range.

•

Make sure no other handset is reviewing the call log when an attempt is denied.

•

www.vtechphones.com

Troubleshooting

Problem Suggestion

The telephone does not ring when there is an incoming call.

• Make sure the ringer is on (see page 9).

• Make sure the telephone line cord and power adapter are plugged in properly (page 3).

• The cordless handset may be too far from the telephone base. Move it closer to the telephone base.

• There may be too many extension telephones on the telephone line to allow all of them to ring simultaneously. Try unplugging some of them.

• If the other telephones in your home are having the same problem, the problem is in the wiring or local service. Contact the local telephone company (charges may apply).

• Other electronic products can cause interference to your cordless telephone. Try installing your telephone as far away as possible from the following electronic devices: wireless routers, radios, radio towers, pager towers, cellular telephones, digital telephones, intercoms, room monitors, televisions, VCRs, personal computers, kitchen appliances, and other cordless telephones.

•

Test a working telephone at the telephone jack. If another telephone has the same problem, the problem is in the telephone jack. Contact your local telephone company (charges may apply)

• The telephone line cord might be malfunctioning. Try installing a new telephone line cord.

• Remove and re-insert the battery and place the cordless handset in the telephone base.

• Wait for the cordless handset to synchronize with the telephone base. Allow up to one minute for this to take place.

Appendix

www.vtechphones.com

Troubleshooting

Problem Suggestion

I cannot dial out. • First, try all the above suggestions.

• Make sure there is a dial tone before dialing. It is normal if the cordless handset takes a second or two to synchronize with the telephone base before producing a dial tone. Wait an extra second before dialing.

•

Make sure the telephone is set to the correct dial type (pulse dial or tone dial) for the service in your area. See the Dial type section on page 12 to set the dial type.

• If the other telephones in your home are having the same problem, the problem is in the wiring or local service. Contact your local telephone company (charges may apply).

• Eliminate any background noise. Noise from a television, radio, or other appliances may cause

the telephone not to dial out properly. If you cannot eliminate the background noise, rst try

muting the cordless handset before dialing, or dialing from another room in your home with less background noise.

www.vtechphones.com

Troubleshooting

Problem Suggestion

There is noise or interference during a telephone conversation.

My calls cut in and out when I am using the cordless handset.

• The handset may be out of range. Move it closer to the telephone base.

• Appliances or other cordless telephones plugged into the same circuit as the telephone base can cause interference. Try moving the appliance or telephone base to another outlet.

• If your telephone is plugged in with a modem or a surge protector, plug the telephone (or modem/surge protector) into a different location. If this solves the problem, re-locate your telephone or modem farther apart from each other, or use a different surge protector.

• The layout of your home or ofce might be limiting the operating range. Try moving the telephone

base to another location, preferably a higher location for better reception.

• Disconnect the telephone base from the modular jack and plug in a corded telephone. If calls are still not clear, the problem is probably in the wiring or local service. Contact the local telephone company (charges may apply).

• If the other telephones in your home are having the same problem, the problem is in the wiring or local service. Contact the local telephone company (charges may apply).

• Do you have DSL service? If yes, you need to have a DSL lter installed at every telephone jack that has a telephone connected to it. Contact your DSL service provider for lter information.

Appendix

www.vtechphones.com

Troubleshooting

Problem Suggestion

I hear other calls when using the telephone.

• Disconnect the telephone base from the telephone jack. Plug in a different telephone. If there are still other calls, the problem is probably in the wiring or local service. Call your local telephone company.

I hear noise in the cordless handset, and none of the keys or buttons work.

My caller ID features are not working properly

• Make sure the telephone line cord is plugged in securely. Remove and re-insert the battery.

•

• Caller ID is a subscription service. You must subscribe to this service from your local telephone company for this feature to work on your telephone.

• The caller may not be calling from an area which supports caller ID.

• Both you and the caller’s telephone companies must use equipment which are compatible with caller ID ser vice.

• If you subscribe to DSL service, install a DSL lter to the telephone line between the telephone base and the telephone line jack. Contact your DSL service provider for lter information.

www.vtechphones.com

Troubleshooting

Problem Suggestion

The system does not receive caller ID or the system does not display caller ID during call waiting.

• Make sure you subscribe to caller ID with call waiting features provided by the local telephone company.

• The caller may not be calling from an area which supports caller ID.

• Both you and the caller’s telephone companies must use equipment which are compatible with caller ID ser vice.

• If you subscribe to DSL service, install a DSL lter to the telephone line between the telephone base and the telephone line jack. Contact your DSL service provider for lter information.

Appendix

www.vtechphones.com

Troubleshooting

Problem Suggestion

My cordless handset beeps and is not performing normally.

Common cure for electronic equipment

• Make sure the power cord is securely plugged into the telephone base. Plug the unit into a different working electrical outlet not controlled by a wall switch.

• Move the cordless handset closer to the telephone base. It may be out of range.

• Reset the telephone base by unplugging the unit’s electrical power. Wait for 15 seconds and plug it back in again. Allow up to one minute for the cordless handset and the telephone base to synchronize.

• Other electronic products can cause interference to your cordless telephone. Try installing your telephone as far away from these electronic devices as possible: wireless routers, radios, radio towers, pager towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.

• If the unit is not responding normally, try putting the cordless handset in the telephone base or the charger. If it does not seem to respond, try the following (in the order listed):

• Disconnect the power to the telephone base.

• Disconnect the battery on the cordless handset.

• Wait a few minutes before connecting power to the telephone base.

• Re-install the battery and place the cordless handset into the telephone base or charger.

• Wait for the cordless handset to synchronize its connection with the telephone base. Allow up to one minute for this to take place.

www.vtechphones.com

Operating range

This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can

communicate over only a certain distance --- which can vary with the locations of the telephone base and handset, the weather, and the layout of your home or ofce.

When the handset is out of range, the handset will display CONNECTING. The user can access the handset directory, and certain parts of the menu system, i.e. handset setting, but not the time setting and telephone base setting. NOT AVAILABLE will be displayed if access is denied. If there is a call while the handset is out of range, it might not ring, or if it does ring, the call might not connect well when you press the telephone base, then press /FLASH to answer the call. If the handset moves out of range during a telephone conversation, there might be interference. To improve reception, move closer to the telephone base.

/FLASH. Move closer to

Maintenance

Taking car e of your te lepho ne

Your cordless telep hone co ntains s ophis ticate d elect ronic parts, s o it must be treated with care.

Avoid roug h treatment

Place the handse t down gently. Save the origina l packing materi als to protect your telepho ne if you ever need to ship it.

Avoid wate r

Your teleph one ca n be da maged if it g ets wet. Do not use th e hand set out doors in the rain, or hand le it w ith wet hands. Do not insta ll the teleph one base near a sink, bat htub or shower.

Elect rical s torms

Electr ical storms can sometimes caus e power sur ges harmful to ele ctron ic equi pment. For your own safety, take caution w hen usin g elect ric app lianc es during storms.

Clean ing your te lephone

Your telephon e has a durab le plastic casin g that shou ld retain its luster for many years. Cl ean it only with a soft c loth slightly dampened with water or a mil d soap. Do not use excess water or clean ing solvents of any k ind.

Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the unit out by the unplugged cords.

Appendix

www.vtechphones.com

About cordless telephones

Privacy: The same feature s that make a cordless telephone convenient create some limi tations. Telephone calls are trans mitted between the telephone base and

•

the cordless handset by radio waves, so there is a pos sibili ty that the cordless telepho ne conversations could be intercepted by radio receiving equipment within

range of t he cord less han dset. Fo r this rea son, you should no t think of c ordless telep hone co nversat ions as being as pr ivate as th ose on corded tel ephones.

Elect rical Power : The telephone base of this cordless telephone must be connected to a worki ng electri cal outlet. The electrica l outlet should not be controlled

•

by a wall swit ch. Call s cannot be made from the cordless handset if the tel ephone base is un plugg ed or switched of f, or if the electr ical power is inter rupted .

Potent ial T V Inte rfer ence: Some c ordless telephones operate at freq uenci es that may caus e inter ferenc e to tel evisio ns and VCR s. To minimi ze or prevent

•

such inter ferenc e, do not place the telephon e base of the cordless tele phone near or on top of a TV or VCR. If interference is exper ience d, moving the cordl ess telephone far ther away fr om the TV or VCR will of ten red uce or eliminate t he inter ference.

•

Recha rgea ble Batteries: This product cont ains eithe r Nickel- Cadmium or Nickel-Met al Hydride rec hargeable batter ies. Exerc ise care in handling batteries in

order not to create a short circui t with conducting materia l such as rings, bracelets, and keys. The battery or condu ctor may overheat and cause harm. Observe proper p olarity between the batter y and the batter y charger.

•

Nickel -M etal Hydri de R echargeab le B atte ries: Disp ose of these b atteri es in a safe manner. Do no t bur n or punc ture. Like other batteries of th is t ype, if

burned o r punctured, they could release c austic materia l which c ould cause injury.

Warranty

What do es this l imited warran ty cove r?

The manufacturer of this V Tech Prod uct warrants to the holde r of a valid pr oof of purch ase (“ Consumer” or “you”) that the Product and all ac cesso ries provide d in t he sales package (“Prod uct ”) are free from defects in materia l and workmanship, pursuant to the foll owing terms and conditions , when installed and used normal ly and in accor dance with the Produ ct operating instru ction s. This limited warranty extends on ly to the Consumer for Product s purchased and used in the

United States of Am erica a nd Canad a.

What wil l VTech do if the Product is not free f rom def ects i n mater ials an d workma nship during th e limited warranty period (“ Mate rially D efec tive Product ”)?

During the limited warranty period, VTech’s auth orized service representative will repair or replace at VTech’s option, without charge, a Materially Defective Product. If we repair the Product, we may use new or refurbished replacement parts. If we choose to replace the Product, we may replace it with a new or refurbished Produ ct of the same or similar design. We will retain defec tive parts, modules, or equipment . Repair or replacement of the Product, at VTech’s option, is your exclusive remedy. VTech will return rep aired or r eplacement Pro ducts to you in working conditio n. You should ex pect the repair o r replacement to take appr oximate ly 30 days.

How long i s the limited warrant y perio d?

The limite d warranty period for the Product extends for ONE (1) YEAR from the date of purchas e. If VTech repairs or repl aces a Materially Defec tive Produ ct under the terms of this limited warran ty, this limited warra nty als o applie s to repaire d or replac ement Pro duct for a period of ei ther (a) 90 days from the date th e repaire d or replacement Pr oduct is shipped to you or (b) the time re mainin g on the original o ne-year warrant y; whic hever is longer.

What is not covered by this limited warran ty?

This lim ited warr anty does not cover:

1. Produ ct t hat ha s been subjecte d to misus e, ac cident, sh ipping or other physical d amage, impr oper installation , abn ormal oper ation or handlin g, ne glect ,

inundation, re, water or other liqui d intrus ion; or

2. Produ ct that ha s been da maged du e to repair, alteratio n or modi cation by anyone o ther tha n an autho rized servic e repres entati ve of VTech; or

3. Produ ct to the ex tent that the problem experienc ed is cau sed by sig nal con ditions, network reli abilit y, or cable o r antenna systems; or

www.vtechphones.com

Warranty

4. Produ ct to the ex tent that the problem is caused by us e with no n-VTech acc essor ies; or

5. Produ ct whos e warranty/qual ity sti ckers, p roduc t serial number p lates or el ectro nic serial numb ers have be en remove d, altered or rend ered ill egibl e; or

6. Produc t purchased, used, servi ced, or shipped for repair from outside the United States of Ameri ca or Canada, or used for commercia l or inst itution al purposes (inclu ding but not limit ed to Products us ed for rental purp oses); or

7. Produ ct retur ned wit hout valid proof of purcha se (see item 2 below); or

8. Charg es for ins tallation or set u p, adjust ment of cu stomer c ontrols, and installation or re pair of systems outside the unit.

How do you get warranty se rvic e?

To obtain warranty ser vice in the United States of America, please call 1 (800) 595-9511; In Canada, please call 1 (800) 267-7377. NOTE: Before calling for service, please r eview the user’s manual - a che ck of the Pr oduct contro ls and features may save you a ser vice ca ll.

Except as prov ided by appli cable law, you assume the risk of loss or damage during transit and transp orta tion and are responsibl e for deliver y or handling charges incurr ed in the tra nspor t of the Prod uct(s) to the ser vice locati on. VTech will return rep aired or replaced Product under thi s limited wa rrant y to you, trans port ation, deliver y or handling charges prepaid. VTech assumes no risk for damage or loss of the Produ ct in transit. If the Product failure is not covered by this limited warrant y, or proof of pur chase does not meet th e terms of thi s limited warrant y, VTech will notif y you and will request th at you authorize the cost of repair pr ior to any fur ther repair ac tivit y. You must pay for th e cost of repair and r eturn sh ipping costs for the repair of Prod ucts th at are not covered by th is limited warran ty.

What must you ret urn with t he Prod uct to get warra nty se rvic e?

Return the entire o riginal package and contents in cludi ng the Pro duct to t he VTech ser vic e location alon g with a description of th e malfun ction o r dif culty; and

2. Include “valid proo f of purchase” (sal es rece ipt) iden tifying the Pro duct purchas ed (Product mod el) and th e date of purchase or recei pt; and

3. Provid e your name, compl ete and correct m ailing address , and tele phone nu mber.

Other Limita tions

This warrant y is the c omplete and exclus ive agr eement between you and VTech. It supersedes all other writ ten or oral communicat ions related to this Pro duct. VTech prov ides no other war rantie s for thi s Produ ct. The warrant y exclu sively d escribes all of VTech’s res ponsi biliti es rega rding t he Product. There are n o other

express w arranties. No on e is autho rized to ma ke modi catio ns to this l imited warrant y and you sh ould not r ely on any such mod icat ion. State/ Provinc ial Law Rights: Th is warra nty gives you spe cic le gal rig hts, and you may also have other ri ghts, which var y from st ate to state or provin ce to prov ince. Limitations: Impli ed wa rranti es, i nclud ing those of  tness for a par ticular pur pose and merchantab ility (an u nwrit ten warrant y th at th e Product is  t for ordinary

use) are li mited to one year from d ate of purchase. Some s tates/provin ces do not allow limit ations on how l ong an i mplie d warran ty lasts, so the above limit ation may not app ly to you. In no event shall VTech be liable for any i ndirec t, s pecia l, in cidental, consequenti al, or simi lar d amages (inc luding, but not limited to lost

prots o r revenue, inabili ty to use t he Produ ct or oth er asso ciated equipme nt, the c ost of sub stitute equipm ent, and claims by t hird par ties) re sultin g from the u se

of this Produ ct. S ome st ates/p rovinc es do not al low th e exclu sion or limitation of incident al or conse quenti al dam ages, so the above limitation o r exclusion m ay not appl y to you.

Please retain your original sales receipt as proof of purchase.

Appendix

www.vtechphones.com

FCC, ACTA and IC regulations

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

•

Changes or modications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or by stander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more. If you choose to use a clipping device, please make sure to only use the supplied VTech belt clip.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation.

Privacy of communications may not be ensured when using this telephone.

FCC Part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The

label on the back or bottom of this equipment contains, among other things, a product identier in the format US:AAAEQ##TXXXX. This identier must be provided to

your local telephone company upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called.

The REN for this product is encoded as the 6th and 7th characters following the US: in the product identier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be ve (5.0) or less. For more information, please contact your local telephone company.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equip-

ment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualied installer.

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty.

www.vtechphones.com

FCC, ACTA and IC regulations

If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is

required to notify you before interrupting service. If advance notice is not practical, you will be notied as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to le a complaint with the FCC. Your telephone company may make changes in its

facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, re, medical) in these locations. If you do store or

test emergency numbers, please:

Remain on the line and briey explain the reason for the call before hanging up.

• Perform such activities in off-peak hours, such as early morning or late evening.

•

Industry Canada

This equipment complies with regulations RSS-213 and CS-03 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

The term ‘’IC: ‘’ before the certication/registration number only signies that the Industry Canada technical specications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the

devices does not exceed ve.

This Class B digital apparatus complies with Canadian ICES-003.

The RBRC® seal

The RBRC® Seal on th e nickel -meta l-hydr ide bat tery in dicates that VTech Communicatio ns, Inc. i s volunt arily pa rtic ipatin g in an indus try program to c ollec t and recycle the se batteries at th e end of their useful lives, w hen taken out of ser vice w ithin the United S tates an d Canada .

The RBRC waste, wh ich may be i llegal in your area.

VTech’s par ticip ation in R BRC® makes it ea sy for you to dr op off t he spent batter y at local retail ers par tici pating in the RBRC® progra m or at auth orized V Tech produ ct ser vice c enters. Please c all 1-8 00 -8 -BATT ERYT M for informatio n on Ni-MH battery recycling and disposal ban s/restricti ons in your area. VTech’s involvement in thi s progra m is part of its com mitment to prote cting our enviro nment and conservi ng natural resources.

RBRC

progra m provid es a convenient alternati ve to placi ng used nickel- metal -hydri de batteries into the tra sh or muni cipal

is a regi stere d trad emark o f Rechargea ble Batter y Recycling Cor porat ion.

Appendix

www.vtechphones.com

Technical specications

Frequency control Crystal controlled

PLL synthesizer

Frequency Handset: 1921.536 - 1928.448 MHz

Telephone base: 1921.536 - 1928.448 MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according

to environmental conditions at the time of use.

Size

Weight Handset: 131.0 grams (including battery)

Power requirements

Memory Director y: 50 memory locations; up to 24 digits and 15 characters

Handset: 170.9mm X 48.1mm X 25.8mm Telephone base: 129.5mm X 123.8mm X 95.0mm Charger: 84.0mm X 99.0mm X 102.0mm

Telephone base: 181.6 grams Charger: 101.4 grams

Handset: DC 2.4V 600mAh NiMH battery Telephone base: DC 6V @ 300mA Charger: AC 6V @ 300mA

Call log: 50 memory locations; up to 20 digits and 15 characters

www.vtechphones.com

Index

About caller ID 21 About cordless telephones 42 Advanced operation 17 Answer an external call during an intercom call 15

Basic operation 14 Battery 9, 30

Caller ID 21 Call log 22, 29 Call waiting 14 Character chart 18 Clear voicemail 12

Date and time 8 Delete from redial 26 Delete from the call log 24 Delete from the directory 20 Desk/table bracket installation 4 Dial a call log number 23 Dial a directory entry 19 Dial a redial number 26

Dial type 4, 12 Director y 17

DSL lter 5

Edit a directory entr y 20 Edit handset name 11

FCC, ACTA and IC regulations 44 Find handset 16

Handset and telephone base indicators 27 Handset display screen messages 28 Handset icons 27 Handset layout 6 Handset light 27

Important safety instructions 31 Index 47 Installation 1 Install handset battery 2 Internet 4 Intercom call 15

www.vtechphones.com

Index

Key tone 10 Language 11

Maintenance 41 Make, answer and end calls 14 Multiple handset use 15 Mute 14

Operating range 41 Options while on calls 14 Out of range tone 10

Parts checklist 1

Redial 25 Reset to default settings 13 Review redial 25 Review the call log 22 Review the directory 17 Ring melody 8 Ring volume 9

Search the director y 17 Speakerphone 14 Store a directory entry 19 Store a redial number to the director y 25 Store a call log number 23

Technical specications 46 Telephone base 3, 7 Telephone base lights 27 Telephone settings 6 Temporary tone dialing 13 The RBRC® seal 45 Transfer an external call 16 Troubleshooting 32

Volume 9

Warranty 42

www.vtechphones.com

VTECH TELECOMMUNICATIONS LTD.

A member of THE VTECH GROUP OF COMPANIES.

Distributed in the U.S.A. by VTech Communications, Inc. Beaverton, Oregon

Distributed in Canada by VTech Telecommunications Canada, Ltd., Richmond, B.C.

Printed in China.

91-001081-090-100

Models:

6041/6044/6051

User’s manual

w w w . vt e c h ph o n e s . c o m

VTech 6051, 6044, 6041 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Installation

Parts checklist

Installation

Install handset battery

Telephone base installation

Desk/table bracket installation

Dial type

If you subscribe to DSL service

Telephone settings

Handset layout

Telephone base layout

Date and time

Ring melody

Ring volume

Battery low tone

or to reach SETUP HS. Press MENU/SELECT. or to reach RING VOLUME. Press MENU/SELECT. or to scroll through the choices and a sample of each ring

Out of range tone

Key tone

Edit handset name

Language

or to reach SETUP HS. Press MENU/SELECT. or to reach LANGUAGE. Press MENU/SELECT.

Dial type

Clear voicemail

Reset to default settings

Basic operation

Mute

Call waiting

MUTE

Intercom call

Multiple handset use

Answer an external call during an intercom call

Transfer an external call

Find handset

Press FIND HANDSET again or put the handsets back on the telephone base or charger to stop the paging tone.

Advanced operation

Directory

Review the directory

or to reach DIRECTORY. Press MENU/SELECT. or to reach REVIEW. Press MENU/SELECT. or to browse and press OFF/CLEAR to exit.

Search the directory

Advanced operation

Dial a directory entry

Call log

Review the call log

Press MENU/SELECT. Press or to select CALL LOG.

Dial a call log number

Redial

Review redial

Handset and telephone base indicators

Handset light

Telephone base lights

Handset icons

Handset display screen messages

Call log display screen messages

Battery

Important safety instructions

Troubleshooting

Operating range

Maintenance

About cordless telephones

Warranty

FCC, ACTA and IC regulations

The RBRC® seal

Index
