VTech DS3111-4, DS3111-3, TM3111-2, 3111-2 User Manual

This manual has all the feature operations and troubleshooting necessary to install
and operate your new VTech telephone. Please review this manual thoroughly to ensure proper installation and operation of this innovative and feature rich VTech
product. For support, shopping, and everything new at VTech, visit our website at
www.vtechphones.com. In Canada, go to www.vtechcanada.com.
Congratulations
on purchasing your new VTech product.
Before using this telephone, please read the
on page 48 of this manual.
www.vtechphones.com
Installation . . . . . . . . . . . . . . . . . .1
Parts checklist . . . . . . . . . . . . . . . . 1
Telephone base & charger installation . . . . 2
DSL lter . . . . . . . . . . . . . . . . . . . 3
Battery installation . . . . . . . . . . . . . . 4
Battery charging . . . . . . . . . . . . . . . 5
Adding a new handset . . . . . . . . . . . . 6
Replacing a handset . . . . . . . . . . . . . 8
Belt clip & headset . . . . . . . . . . . . . . 9
Handset layout . . . . . . . . . . . . . . . 10
Telephone base layout . . . . . . . . . . . 11
Telephone settings . . . . . . . . . . . . 12
Ringer volume . . . . . . . . . . . . . . . 12
Ringer tone . . . . . . . . . . . . . . . . . 12
Key tone . . . . . . . . . . . . . . . . . . 13
Language . . . . . . . . . . . . . . . . . . 13
Clear voicemail . . . . . . . . . . . . . . . 14
Voicemail setup . . . . . . . . . . . . . . . 15
Basic operation . . . . . . . . . . . . . . 17
Make, answer and end calls . . . . . . . . 17
Speakerphone . . . . . . . . . . . . . . . 17
Mute. . . . . . . . . . . . . . . . . . . . . 17
Call waiting . . . . . . . . . . . . . . . . . 18
Volume . . . . . . . . . . . . . . . . . . . 18
Ringer mute. . . . . . . . . . . . . . . . . 18
Multiple handset use . . . . . . . . . . . . 18
Voicemail . . . . . . . . . . . . . . . . . . 19
Find handset . . . . . . . . . . . . . . . . 19
Intercom. . . . . . . . . . . . . . . . . . . 20
Answer an incoming call during
an intercom call . . . . . . . . . . . . . . 20
Transfer an external call . . . . . . . . . . 21
Switch between external and internal calls . 22
Advanced operation. . . . . . . . . . . . 23
Directory . . . . . . . . . . . . . . . . . . 23
Store a directory entry . . . . . . . . . . . 23
Table of contents
i
www.vtechphones.com
Table of contents
Character chart . . . . . . . . . . . . . . . 24
Search the directory . . . . . . . . . . . . 25
Dial a directory entry . . . . . . . . . . . . 25
Edit a directory entry . . . . . . . . . . . . 26
Delete from the directory . . . . . . . . . . 26
About caller ID . . . . . . . . . . . . . . . 27
Caller ID. . . . . . . . . . . . . . . . . . . 28
Review the call log . . . . . . . . . . . . . 29
Make CID entries ready to dial . . . . . . . 29
Dial a call log entry . . . . . . . . . . . . . 30
Save an entry to the directory . . . . . . . 30
Delete from the call log . . . . . . . . . . . 31
Call log display screen messages . . . . . 31
Redial . . . . . . . . . . . . . . . . . . . . 32
Review redial . . . . . . . . . . . . . . . . 32
Dial from redial . . . . . . . . . . . . . . . 32
Delete from redial . . . . . . . . . . . . . . 32
Handset display screen messages . . . 33
Handset indicators . . . . . . . . . . . . 36
Telephone base indicators
& charger indicator . . . . . . . . . . . 37
Battery . . . . . . . . . . . . . . . . . . . 38
Troubleshooting . . . . . . . . . . . . . . 39
Important safety instructions . . . . . . 48
Operating range . . . . . . . . . . . . . . 49
Maintenance . . . . . . . . . . . . . . . . 49
About cordless telephones. . . . . . . . 50
Warranty . . . . . . . . . . . . . . . . . . 50
FCC, ACTA and IC regulations . . . . . . 52
The RBRC® Seal . . . . . . . . . . . . . . 53
Technical specications . . . . . . . . . 54
Index . . . . . . . . . . . . . . . . . . . . 55
ii
www.vtechphones.com
1
Installation
Basic operation
Installation
Parts checklist
Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.
• To purchase replacement batteries, visit our website at www. vtechphones.com or call at 1 (800) 595-9511 in the United States. In Canada, go to www.vtechcanada. com or call 1 (800) 267-7377.
Handsets
(2 for DS3111-2/TM3111-2, 3 for DS3111-3, 4 for DS3111-4)
User’s manual
Batteries
(2 for DS3111-2/TM3111-2, 3 for DS3111-3, 4 for DS3111-4)
Telephone base
Chargers
(1 for DS3111-2/TM3111-2, 2 for DS3111-3, 3 for DS3111-4)
Charger adapters
(1 for DS3111-2/TM3111-2, 2 for DS3111-3, 3 for DS3111-4)
Telephone base power adapter
Telephone line cord
Belt clips
(2 for DS3111-2/TM3111-2, 3 for DS3111-3, 4 for DS3111-4)
Battery compartment covers
(2 for DS3111-2/TM3111-2, 3 for DS3111-3, 4 for DS3111-4)
Quick start guide
www.vtechphones.com
2
• Use only the VTech batteries and power adapters supplied with this telephone. To obtain a replacement, visit our website at www.vtechphones. com or call 1 (800) 595-9511. In Canada, go to www.vtechcanada. com or call 1 (800) 267-7377.
• The power adapters are intended to be correctly oriented
in a vertical or oor
mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling or an under-the-table/ cabinet outlet.
Installation
Telephone base & charger installation
We recommend that you install the telephone base away from any electronic equipment and appliances such as personal computers, computer routers, television sets, microwave ovens, and refrigerators. Avoid excessive heat, cold, dust or moisture. When a location is selected, install the telephone base and the charger as shown below. The telephone base is designed for desk or tabletop use
only. Make sure that the electrical outlet is not controlled by a wall switch.
Telephone wall jack
Electrical outlet not controlled by a wall switch
Telephone base power adapter
Charger adapter
Telephone line cord
MANUFACTURED IN CHINA
COMPLIES WITH 47 CFR PART 68
REGISTRATION NO.: US:EW7W401B80-565600
RINGER EQUIVALENCE: 0.1B
USOC JACK: RJ11C/RJ11W
HAC FCC ID: EW780-5656-00
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE; AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF
COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE.
DC 6V 300mA
CLASS 2 POWER SOURCE ONLY
TELEPHONE
EQUIPMENT
DSL lter (not
included) required if you have DSL high-speed Internet service
www.vtechphones.com
3
Installation
Basic operation
Installation
DSL lter (not included) If you subscribe to Digital Subscriber Line (DSL) high-speed Internet service
through your telephone line, you must have a DSL lter between the telephone base and the telephone wall jack. The lter prevents noise and caller ID problems
caused by DSL interference. Please contact your DSL service provider for more
information about DSL lters.
Telephone line cord
DSL lter (not included)
required if you have DSL high-speed Internet service
MANUFACTURED IN CHINA
COMPLIES WITH 47 CFR PART 68
REGISTRATION NO.: US:EW7W401B80-565600
RINGER EQUIVALENCE: 0.1B
USOC JACK: RJ11C/RJ11W
HAC FCC ID: EW780-5656-00
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE; AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF
COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE.
DC 6V 300mA
CLASS 2 POWER SOURCE ONLY
TELEPHONE
EQUIPMENT
Connect to a standard electrical outlet not controlled by a wall switch
www.vtechphones.com
4
• If the handset will not be used for a long time, disconnect the battery to avoid potential damage.
• To purchase replacement batteries, visit our website at www. vtechphones. com or call 1 (800) 595-9511 in the United States. In Canada, go to www. vtechcanada. com or call 1 (800) 267-7377.
Installation
Battery installation
Install the handset battery by following these steps:
Press the tab and slide the battery compartment cover down. Align the two holes of the battery plug with the socket pins in the handset battery
compartment, matching the red and black wires of the color-coded label. Place the battery in the compartment with the wires in the lower right corner.
Align the cover at against the battery compartment, then slide it up until it
clicks into place.
1.
2.
3.
4.
BT8000/ BT6010
www.vtechphones.com
5
Installation
Basic operation
Charger adapter
Electrical outlet not controlled by a wall switch
Place the handset in the telephone base or charger. The CHARGE light is on when the handset is properly positioned in the telephone base or charger.
• Use only the power adapters and batteries (or equivalent) supplied with your VTech telephone.
Installation
Battery charging
The battery may have enough charge for short calls. For best performance, charge the battery for at least 16 hours before use. When the battery power is low, LOW BATTERY will be displayed and the battery indicator will ash on the handset screen. When fully charged, the handset battery provides approximately eight hours of talk time and four days of standby time.
For further information on battery, please see the Battery section on page 38.
CHARGE light
Telephone base power adapter
CHARGE light
www.vtechphones.com
6
Installation
Adding a new handset
Your telephone can accomodate up to ve cordless handsets. You can add new
handsets (DS3101, purchased separately) to the DS3111-2/TM3111-2/DS3111- 3/DS3111-4 at any time, but each handset must be registered with the telephone
base before use. The DS3111-2/TM3111-2/DS3111-3/DS3111-4 comes with two/three/four registered
handsets (named HANDSET 1, 2, 3 and 4). Additional handsets will be assigned numbers in the order they are registered (HANDSET 3, 4 and 5). You can register
a maximum of ve handsets.
Before using a new DS3101 handset, you must register it with the telephone base. Each handset must be registered separately.
To register a handset to your telephone base When rst purchased, all optional accessory handsets show
NOT REGISTRED on the screen. The handset may need to
be charged for at least ve minutes before registering to the
telephone base. To register a handset:
Place the unregistered handset in the telephone base or charger. If PRESS FIND HNDST 4 SEC ON BASE does not appear on the handset screen after a few seconds,
1.
• If the registration is not successful, the display will show NOT REGISTERED. To reset the handset, remove the handset from the telephone base or charger and place it back in. Try the registration process again.
• You cannot register a handset if any system handset is in use.
NOT REGISTERED
PRESS FIND HNDST
4 SEC ON BASE
www.vtechphones.com
7
Installation
Basic operation
PLEASE WAIT...
HANDSET X
REGISTERED
Installation
• If you experience
difculty
registering a handset, see the Troubleshooting section on
page 40.
remove the handset and place it in the telephone base or charger again.
On the telephone base, press and hold FIND HANDSET for about four seconds (until the red IN USE light on the telephone base turns on) and then release the button. The handset will show PLEASE WAIT... and it will take about 10 seconds to complete the registration process. The handset will show REGISTERED and will beep if registration is successful.
When the registration is complete, the newly registered handset will be assigned the next available handset registration number. For instance, if you already have HANDSET 1 and HANDSET 2, the next registered handset will be HANDSET 3.
2.
www.vtechphones.com
8
NOT REGISTERED
To de-register all handsets
Press and hold FIND HANDSET on the telephone base for about 10 seconds (until the IN USE light on the telephone base turns on and starts to flash), then release the FIND HANDSET button.
Immediately press and release FIND HANDSET again. You must press FIND HANDSET while the IN USE light is still flashing. The IN USE light will flash for approximately seven seconds.
Soon, all handsets registered to the telephone base will show CONNECTING... and it will take about 10 seconds to complete the de-registration process. All handsets will show NOT REGISTERED if de-registration is successful.
After deleting the registrations of all handsets, you will need to individually register each handset with the telephone base (see page 6 for registration instructions).
1.
2.
3.
Replacing a handset
When you are replacing rather than adding a handset, for your handsets to be numbered sequentially, you need to delete all the handset registrations on the
telephone base, then register all handsets again.
Installation
• If the de­registration process is not successful, you may need to reset the system and try again. To reset: pick up the registered handset and press the /FLASH button, then press the OFF/CLEAR button and place the handset back into the telephone base. You may also reset by unplugging the power from the telephone base, then plugging it back in.
• You cannot de-register the handset(s) if a system telephone is in use.
www.vtechphones.com
9
Installation
Basic operation
Belt clip & headset (optional)
For hands-free telephone conversations, use any industry standard 2.5mm headset (purchased separately). For optimal results, use a VTech 2.5mm headset.
Whenever a compatible headset is connected to the cordless handset, the microphone on the handset will be muted.
Belt clip
To install the belt clip, snap the belt clip into the notches on both sides of the handset.
Headset
Plug the 2.5 mm headset into the jack on the side of the handset (beneath the
small rubber ap).
IC:xxxxX-xxxxxxxx
FCC ID: XXxxx-xxxx-xx
IC:xxxxX-xxxxxxxx
FCC ID: XXxxx-xxxx-xx
To release the belt clip from the handset, carefully pry one side up from the notch. The belt clip will now easily detach from the handset.
IC:xxxxX-xxxxxxxx
FCC ID: XXxxx-xxxx-xx
• To purchase a headset, visit our website at www. vtechphones.com or call 1 (800) 595-9511 in the United States. In Canada, go to www.vtechcanada. com or call 1 (800) 267-7377.
• If the sound quality of the headset is unsatisfactory, try unplugging and
rmly plugging it in
again.
Installation
www.vtechphones.com
10
Installation
Handset layout
1. Earpiece
2.
MENU/SELECT
SKIP
(page 15)
3. Headset jack (2.5mm) (page 9)
4.
CID (caller ID) (page 28)
PLAY
(page 15)
5.
/FLASH
6. Dialing keys (
0-9, *, #)
7.
VOICEMAIL (page 19)
8.
REDIAL/PAUSE
(page 32)
9. Microphone
10. Handset display
11.
VOL / (volume) (page 18)
12.
(directory) (page 23)
ERASE (page 15)
13.
(speakerphone) (page 17)
14.
OFF/CLEAR
15.
#(page 29)
16.
INT (intercom) (page 20)
17.
MUTE/REMOVE (page 17)
17
www.vtechphones.com
11
Installation
Basic operation
Installation
Telephone base layout
1. CHARGE light (page 37)
2.
IN USE light (page 37)
3.
VOICEMAIL light (page 37)
4.
FIND HANDSET (page 19)
1
2
3
4
www.vtechphones.com
12
Telephone settings
Ringer volume
The ringer volume can be adjusted either by the volume control on the right side of the handset or in the handset menu.
To change the ringer volume:
1. Press the volume button
VOL or VOL to display the
current ringer volume level on the screen when the handset is not in use.
2. Press
VOL or VOL to choose the desired volume level.
When nished, the new volume level will be saved.
-OR-
1. Press
MENU/SELECT when the handset is not in use.
2. Press
or to select RINGER VOLUME, then press
MENU/SELECT.
3. Press
or to adjust the volume. A sample of each ringer
volume will be played when scrolling through the choices.
4. Press
MENU/SELECT to save, and you will hear a
conrmation tone.
Ringer tone
This feature allows you to choose one of the ringer tones. To choose a ringer tone:
Press
MENU/SELECT when the handset is not in use.
Press or to select RINGER TONE, then press MENU/SELECT.
1.
2.
• The ringer will be off if the ringer volume is set to zero, and the ringer off icon will be displayed.
If the ringer volume is turned off while scrolling through the options in RINGER TONE, the sample of ringer tone will not be heard.
RINGER VOLUME
>RINGER VOLUME RINGER TONE
RINGER TONE
1
>RINGER TONE KEY TONE
www.vtechphones.com
13
Basic operation
Telephone settings
>KEY TONE
LANGUAGE
Telephone settings
KEY TONE
ON
LANGUAGE ENGLISH
>LANGUAGE
CLR VOICE MAIL
Press or to choose the desired ringer tone. A sample of each ringer tone will be played when scrolling through the choices.
Press MENU/SELECT to save, and you will hear a conrmation tone.
Key tone
If the key tone is set to off, you will not hear a beep tone when you press any of the handset keys.
Press
MENU/SELECT when the handset is not in use.
Press
or to select KEY TONE, then press
MENU/SELECT. Press
or to choose between ON or OFF.
Press
MENU/SELECT to save, and you will hear a
conrmation tone.
Language The language menu allows you to select between ENGLISH,
FRANÇAIS or ESPAÑOL to be used in all menus and screen
displays. To change the language:
Press
MENU/SELECT when the handset is not in use.
Press
or to select LANGUAGE, then press
MENU/SELECT. Press
or to scroll through the choices.
Press
MENU/SELECT to save, and you will hear a
conrmation tone.
3.
4.
1.
2.
3.
4.
1.
2.
3.
4.
www.vtechphones.com
14
Telephone settings
>CLR VOICE MAIL
VOICEMAIL SETUP
TURN INDICATOR
OFF?
Clear voicemail
If you subscribe to voicemail service provided by your local telephone company, NEW VOICE MAIL and the icon will appear on the handset display and the VOICEMAIL lights on
the telephone base and handsets will ash when you have a
new voicemail message. To turn off these indicators:
Press
MENU/SELECT when the handset is not in use.
Press or to select CLR VOICE MAIL, and then press MENU/SELECT.
The screen displays TURN INDICATOR OFF? Press
MENU/SELECT to conrm, and you will hear a
conrmation tone.
The clear voicemail feature only turns off the handset display and the VOICEMAIL lights on the telephone base and handsets. It does not delete your voicemail messages. Contact your local telephone company for more information.
1.
2.
3.
4.
www.vtechphones.com
15
Basic operation
Telephone settings
Telephone settings
>VOICEMAIL SETUP
DIRECTORY
>ACCESS NUMBER
PASSWORD
Voicemail setup
If you subscribe to voicemail service provided by your local telephone company, this feature allows you to use the VOICEMAIL, PLAY, SKIP and ERASE buttons to access your voicemail when you have a new voicemail message. Before completing these steps, be sure to have your access number and password (provided by your local telephone company) to access your voicemail. You will also need the codes to play, skip and erase your messages.
Contact your local telephone company for more information. To program the ACCESS NUMBER button:
Press
MENU/SELECT when the handset is not in use.
Press
or to select VOICEMAIL SETUP, then press
MENU/SELECT. Press
or to select ACCESS NUMBER, then press
MENU/SELECT. Use the dial pad to enter the access number. Press
MUTE/REMOVE to delete characters if necessary. Press
MENU/SELECT. You will hear a conrmation tone.
To program the PASSWORD, PLAY, SKIP and ERASE buttons, follow steps 1 and 2 above. Next, select the command you wish to program, and press MENU/SELECT. Use the dialing keys to enter the corresponding code for that command, and press MENU/SELECT to conrm.
1.
2.
3.
4.
5.
www.vtechphones.com
16
Telephone settings
A single pause
(approximately three seconds) is automatically programmed between the access number and the password when you program your VOICEMAIL button so that your voicemail service will recognize your password. Depending on your voicemail service, you may need to program an extra pause between the access number and your password.
Voicemail setup
To program a pause:
Press MENU/SELECT when the handset is not in use. Press or to select VOICEMAIL SETUP, then press MENU/SELECT twice. The blinking cursor should be at the end of your access number. Press and hold
the REDIAL/PAUSE button until a P appears. Press MENU/SELECT. You will hear a conrmation tone.
To reset all codes to the default ones:
Press MENU/SELECT when the handset is not in use. Press or to select VOICEMAIL SETUP, then press MENU/SELECT. Press or to select RESET ALL CODES, then press MENU/SELECT. The screen displays RESET CODES? Press MENU/SELECT. You will hear a conrmation tone.
1.
2.
3.
4.
1.
2.
3.
4.
5.
www.vtechphones.com
17
Basic operation
Basic operation
Make, answer and end calls
To make a call, press /FLASH or , then dial the number.
-OR- Dial the number, and then press
/FLASH or (predial).
• To answer a call, press
/FLASH, or any dialing keys (0-9,
#, *).
• To end a call, press
OFF/CLEAR, or put the handset in the
telephone base or charger.
Speakerphone
• During a call, press
on the handset to select between
speakerphone and normal handset use.
Mute
This feature allows you to silence the microphone during a conversation. You can still hear the caller, but the caller cannot hear you.
• To activate the mute feature during a call, press MUTE/REMOVE on the handset. The screen will display MUTE.
• Press MUTE/REMOVE again to resume the conversation.
PHONE 00:00:01
MUTED
MUTE
• The screen displays the elapsed time as you talk (in hours, minutes and seconds).
• While entering a number to dial before
/FLASH or
is pressed, press MUTE/REMOVE or OFF/CLEAR to backspace.
• Press and hold
REDIAL/PAUSE
to insert a three­second pause.
www.vtechphones.com
18
Basic operation
Call waiting
If you subscribe to call waiting service, you will hear a tone if there is an incoming call during a telephone conversation.
Press /FLASH on the handset to answer the new incoming call and put the current call on hold.
Press /FLASH at anytime to alternate between calls.
Volume
During a call, use the volume button on the right side of the handset to adjust the listening volume of the speakerphone and earpiece.
• Press the VOL or VOL volume control key to adjust the
volume to a comfortable level.
Ringer mute
This feature allows you to mute the ringer temporarily when the telephone is ringing.
• Press OFF/CLEAR or MUTE/REMOVE on the handset to
temporarily silence the ringer. The next call will ring normally.
Multiple handset use
While on a call with one handset, any other system handset can join the call.
Press /FLASH or on another handset to join the conversation. Press OFF/CLEAR or place the handset in the telephone base or charger to
drop out of the call. The external call will not be terminated until both handsets hang up.
A maximum of two handsets can be connected to the external call, if another one wants to join the conversation, it will display UNABLE
TO CALL TRY AGAIN.
RINGER MUTE
www.vtechphones.com
19
Basic operation
• Once the
VOICEMAIL button is pressed, the
CID , and MENU/SELECT
buttons will be disabled and replaced by PLAY, ERASE and SKIP respectively.
If the ringer volume is turned off, the handset will not ring when you press FIND HANDSET.
Basic operation
Voicemail
If you subscribe to voicemail service and you have a new voicemail message, the VOICEMAIL lights on the telephone
base and handsets will ash, and the handsets will display
NEW VOICE MAIL and the icon.
Press the VOICEMAIL button and the handset will dial the telephone number for access to your voicemail messages.
Use the PLAY, SKIP or ERASE buttons as you listen to your messages.
To setup the voicemail buttons, see the Voicemail setup section on page 15.
Contact your local telephone company for more information about voicemail service.
Find handset
This feature allows the telephone base to page all system handsets for up to 60 seconds.
• Press
FIND HANDSET on the telephone base. All the
handsets ring and the screens display ** PAGING **.
• To stop paging, press
FIND HANDSET again on the
telephone base, /FLASH, or any dialing keys (0-9,
#, *) on the handset.
HANDSET 1
NEW VOICE MAIL
** PAGING **
www.vtechphones.com
20
CALLING
HANDSET X
HANDSET X IS CALLING
Intercom
The intercom feature allows conversation between one handset and another.
Press INT to initiate the intercom feature. The originating handset screen displays INTERCOM TO: Dial the number associated with the handset you are trying
to contact. The originating handset screen displays CALLING
HANDSET X. The destination handset rings and displays HANDSET X IS CALLING.
Press /FLASH, , INT or any dialing keys (0-9,#,*) on the ringing handset to answer the intercom call.
To end an intercom call, press INT, OFF/CLEAR, or place the handset back in the telephone base or charger.
Answer an incoming call during an intercom call
During an intercom call, there will be an alert tone to signify an incoming (external) call.
• To answer the incoming call, press
/FLASH on the handset,
and the intercom call will be ended automatically.
• To terminate the intercom call without answering the
incoming call, press OFF/CLEAR on the handset.
1.
2.
3.
4.
5.
6.
INTERCOM TO:
INTERCOM ENDED
Basic operation
www.vtechphones.com
21
Basic operation
Basic operation
• If the destination handset does not answer the intercom call, the originating handset can return to the external call by pressing
/FLASH, OFF/
CLEAR or INT. After 100 seconds, the originating handset screen will display
UNABLE TO CALL TRY AGAIN and
reconnect to the external call automatically. The destination handset returns to the idle mode.
Transfer an external call
You can transfer an external call from one handset to another handset.
During an external call, press INT to initiate the intercom feature. The originating handset screen displays TRANSFER TO: Dial the destination handset number. The originating handset screen displays CALLING HANDSET X. The destination
handset rings and displays HANDSET X IS CALLING. To answer a call at the destination handset, press /FLASH, , INT or any
dialing keys (0-9, #, *). Now the party at the originating handset can have a conversation with the
party at the destination handset, and the screen displays INTERCOM. Press OFF/CLEAR on the originating handset to transfer the call to the destination handset. The originating handset will show CALL TRANSFERED then returns to the idle mode. Now the destination handset can talk with the external call.
-OR- Press and hold INT on the originating handset to let the destination handset
join the external conversation.
1.
2.
3.
4.
5.
6.
www.vtechphones.com
22
Switch between external and internal calls
When on an external call and you wish to make an intercom call to another system handset without ending the external call:
During an external call, press INT to initiate the intercom feature. The originating handset screen displays TRANSFER TO: Dial the number associated with the handset you are trying to intercom. The originating handset screen displays CALLING HANDSET X. The destination
handset rings and displays HANDSET X IS CALLING. Press /FLASH, , INT or any dialing keys (0-9, #, *) on the destination
handset to answer the internal call. Press INT on the originating handset to switch between the external call (outside)
and intercom call.
1.
2.
3.
4.
5.
6.
Basic operation
www.vtechphones.com
23
Advanced operation
Directory
The directory is shared by all handsets. The directory can store up to 50 entries. Each entry may consist of a number up to 32 digits and a name up to 16 characters. Only one handset can review the directory at a time.
• Press
when the handset is not in use.
Store a directory entry
Press MENU/SELECT twice when the handset is not in use. Press or to reach STORE, and then press MENU/SELECT. The screen displays ENTER NUMBER. Use the dial pad to enter the number.
Press MUTE/REMOVE to backspace and erase digits. Press and hold MUTE/REMOVE to erase the entire entry. Press and hold REDIAL/PAUSE to insert a three-second
dialing pause.
Press MENU/SELECT to conrm. The screen displays ENTER NAME. Use the dial pad (see
the Character chart on page 24) to enter the name.
Press MUTE/REMOVE to backspace and erase characters. Press and hold MUTE/REMOVE to erase the entire entry.
Press MENU/SELECT to conrm.
1.
2.
3.
4.
5.
6.
7.
Advanced operation
>DIRECTORY
CALL LOG
ENTER NUMBER
800-595-95_
If a handset attempts to enter the directory while another handset is in the directory,
NOT AVAILABLE AT THIS TIME will
be displayed. Press OFF/CLEAR
to exit to the previous menu at anytime.
DIRECTORY EMPTY will be
displayed on screen when there is no entry in the directory.
When the directory is full and you attempt to save an entry, the screen will display LIST FULL.
If you attempt to save a number already stored in the directory, the screen will display ALREADY SAVED.
>STORE
REVIEW
VTECH
800-595-9511
ENTER NAME
VTECH_
www.vtechphones.com
24
Advanced operation
Character chart
Use the dial pad and the chart below to enter a name (up to 16 characters). Each press of a particular key causes the characters to be displayed in the following order:
When you enter a name, the handset will automatically
display the rst
character of each word in uppercase.
Number key
Characters by number of key presses
1 2 3 4 5 6 7 8 9 1 1 # , - . & 2 A B C 2 a b c 3 D E F 3 d e f 4 G H I 4 g h i 5 J K L 5 j k l 6 M N O 6 m n o 7 P Q R S 7 p q r s 8 T U V 8 t u v 9 W X Y Z 9 w x y z 0 0
*
*
? ! / ( ) @
# space
www.vtechphones.com
25
Advanced operation
Advanced operation
Search the directory
Entries are sorted alphabetically, and names beginning with
numbers are presented rst.
To search for directory entries in alphabetical order:
• Press
when the handset is not in use.
-OR
-
• Press
MENU/SELECT three times to select REVIEW and
enter the directory.
• Use the dial pad to enter the rst letter of the name to search
for. See Character chart on page 24.
For example, if you have Jenny, Kristen, and Linda in the directory, press 5 (JKL) once to nd Jenny. Press 5 (JKL)
twice to nd Kristen. Press 5 (JKL) three times to nd Linda.
Press 5 (JKL) a fourth time to return to Jenny. Dial a directory entry
• Press
to enter the directory when the handset is not
in use.
• Press
or to scroll to the desired entry, or use the
alphabetical search to nd it.
• Press
/FLASH or to dial the selected entry.
VTECH 800-595-9511
While reviewing the phone number of an entry which is longer than 16
digits, only the rst
13 digits will be shown. Press * or # to scroll to the additional digits.
www.vtechphones.com
26
Edit a directory entry
Press when the handset is not in use. Press or to scroll to the desired entry. Press MENU/SELECT, and the screen displays EDIT NUMBER. Use the dial pad to enter the number.
Press MUTE/REMOVE to backspace and erase digits. Press and hold MUTE/REMOVE to erase the entire entry. Press and hold REDIAL/PAUSE to insert a three-second
dialing pause. Press or to move the cursor right or left.
Press MENU/SELECT to conrm. The screen displays EDIT NAME. Use the dial pad (see the Character chart
on page 24) to enter the name.
Press MUTE/REMOVE to backspace and erase characters. Press and hold MUTE/REMOVE to erase the entire entry. Press or to move the cursor right or left.
Press MENU/SELECT to conrm.
Delete from the directory
• Press
to enter the directory, or press MENU/SELECT three times to enter
the directory.
• Press or to scroll to the desired entry, or use the alphabetical search to nd it.
• Press MUTE/REMOVE to delete the selected entry and you will hear a
conrmation tone.
1.
2.
3.
4.
5.
6.
7.
EDIT NUMBER
595-9511_
Advanced operation
EDIT NAME
VTECH_
www.vtechphones.com
27
Advanced operation
Advanced operation
About caller ID
If you subscribe to caller ID service from your local telephone company, this feature displays the name and telephone number of the caller before answering a call (even when on another call). The caller ID features of this product will work only if you subscribe to caller ID service and both you and the caller are in areas offering caller ID service, and if both telephone companies use compatible equipment.
Contact your local telephone company if:
you have both caller ID and call waiting, but as separate services (you may need combined service),
• you have only caller ID service, or only call waiting service,
• you do not subscribe to caller ID or call waiting services but wish to subscribe. There may be fees for these services, and they may not be available in all areas. This product can be used without subscribing to either caller ID or combined caller
ID with call waiting service, although the caller ID features of this product will not function.
www.vtechphones.com
28
• Due to regional service differences, the caller ID information may not be available for every incoming call. In addition, the callers may intentionally block their names and/or telephone numbers.
CALL LOG EMPTY
Advanced operation
HANDSET X
XX MISSED CALLS
Caller ID
If you subscribe to caller ID service, information about each
caller will be displayed after the rst or second ring. This
information will be stored in the call log and shared by all handsets.
• The call log can store up to 50 entries.
• You can review, dial, and copy the entr y into the directory.
• Entries are displayed in reverse chronological order, from the latest to the earliest entry.
• When the call log is full, the earliest entry will be deleted to make room for new incoming call information.
XX MISSED CALLS and the NEW icon will be displayed if there are new call log entries (including missed and un­reviewed calls.)
CALL LOG EMPTY will be displayed if there is no record in the call log.
>CALL LOG
RINGER VOLUME
VTECH
800-595-9511 NEW 3:45
AM
2/23
www.vtechphones.com
29
Advanced operation
Only one handset can review the directory or call log at a time. If another handset attempts to enter the call log, it will display NOT
AVAILABLE AT THIS TIME.
Review the call log
To access the call log:
Press
CID when the handset is not in use.
-OR-
Press MENU/SELECT when the handset is not in use. Press or to select CALL LOG, then press MENU/SELECT.
• When in the call log, press
or to scroll through the records.
• The name (if available), number, date and time of all incoming calls are displayed on the screen.
There will be an error tone when the list reaches the beginning or end of the call log.
Make CID entries ready to dial
Although the call log entries you receive have 10 digits, (the area code plus the seven-digit number), in some areas, you may need to dial only the seven digits, or a 1 plus the seven digits, or a 1 plus the area code plus the seven digits. You can change the number of digits that you dial from the call log.
While reviewing the call log, press # repeatedly to display these dialing options for local and long distance numbers before dialing or saving the telephone number. See an example at right.
Advanced operation
800-595-9511 1-800-595-9511 1-595-9511 595-9511
VTECH
800-595-9511
3:45
AM
2/23
VTECH
800-595-9511
3:45
AM
2/23
www.vtechphones.com
30
SAVED
Dial a call log entry
• When in the call log, press or to scroll to the desired entry.
Press # repeatedly to display the possible dialing options. Press /FLASH or to dial the selected entry.
Save an entry to the directory
When in the call log, press or to scroll to the desired entry. If you want to select the dailing options, press # repeatedly to scroll to the desired number.
Press MENU/SELECT to save the entry.
If the entry has a name and a number, the screen will
display SAVED.
If the entry already exists in the directory, the screen will
display ALREADY SAVED.
If the entry only has a name or a number,
EDIT NAME or
EDIT NUMBER will be displayed. Use the dial pad to enter
the name or number, and then press MENU/SELECT to save the entry.
If there is no caller ID information, the attempt to save will be rejected and the screen will display UNABLE TO SAVE.
1.
2.
Advanced operation
• When saving or deleting a number on one handset, it will automatically update all other handsets.
ALREADY SAVED
UNABLE TO SAVE
VTECH
800-595-9511
3:45
AM
2/23
www.vtechphones.com
31
Advanced operation
DELETE ALL
CALLS?
Advanced operation
Call log display screen messages
Display: Means:
PRIVATE NAME
The caller is blocking the name information.
PRIVATE NUMBER
The caller is blocking the telephone number infor mation.
PRIVATE CALLER
The caller is blocking the name and number information.
UNKNOWN NAME
This caller’s name is unavailable.
UNKNOWN NUMBER
This caller’s number is unavailable.
UNKNOWN CALLER
No information is available about this caller.
LONG DISTANCE
This is a long distance call.
Delete from the call log
• While in the call log, press
or to scroll to the desired
entry.
• Press
MUTE/REMOVE to delete an entry.
-OR-
Press and hold MUTE/REMOVE to delete all entries and the screen displays DELETE ALL CALLS? Press MENU/SELECT
to conrm and you will hear a conrmation tone, or press
OFF/CLEAR to exit and return to the previous menu.
www.vtechphones.com
32
Advanced operation
Redial
The telephone stores the ve most recently dialed numbers on
the redial list. You can review or redial these numbers.
• When there are already ve entries on the redial list, the
earliest entry is deleted to make room for the latest entry.
• Entries are displayed in reverse chronological order, i.e. from the most recent to the earliest entry.
Review redial
• Press
REDIAL/PAUSE when the handset is not in use.
• Press
or , or press REDIAL/PAUSE repeatedly to browse
through the entries.
Dial from redial
• Press
REDIAL/PAUSE when the handset is not in use.
• Press
or to scroll to the desired entry.
• Press
/FLASH or to dial the number.
Delete from redial
• Press
REDIAL/PAUSE when the handset is not in use.
• Press
or to scroll to the desired entry.
• Press
MUTE/REMOVE to delete the selected entry and you
will hear a conrmation tone.
www.vtechphones.com
33
Appendix
Handset display screen messages
ALREADY SAVED
The telephone number entered is already stored in the directory.
CALL LOG EMPTY
There are no call log entries.
CALLING HANDSET X
Calling another handset.
CHARGING
A handset with low battery has been placed in the telephone base or charger to recharge.
CONNECTING...
The cordless handset is searching for the telephone base.
DIRECTORY EMPTY
There is no directory entry.
ENDED
You have just ended a call.
HANDSET X IS CALLING
Handset X is calling.
INTERCOM
The handset is on an intercom call.
INTERCOM ENDED
An intercom call is terminated.
INTERCOM TO:
The INT button is pressed to initiate an intercom call.
www.vtechphones.com
34
INCOMING CALL
There is an incoming external call.
LINE IN USE
A handset or an extension on the same telephone line is in use.
LIST FULL
The directory is full.
LOW BATTERY
The battery needs to be recharged.
MICROPHONE ON
MUTE has been turned off and the person on the other end can hear you.
XX MISSED CALLS
There are un-reviewed calls in your call log.
MUTED
The microphone is temporarily turned off during a call.
NEW VOICE MAIL
There are new voicemail message(s).
NO LINE
There is no telephone line connected.
NOT AVAILABLE AT THIS TIME
Access is denied when the handset is out of range from the telephone base. Attempt to review the directory or call log is denied when another handset is reviewing it.
Handset display screen messages
www.vtechphones.com
35
Appendix
Handset display screen messages
OUTSIDE
Connected to the external call during call transfer.
NO SIGNAL, CALL ENDED
Communication between handset and telephone base is lost during an external call.
** PAGING **
The cordless handset locator has been activated.
PHONE
The handset is in use.
PLACE IN CHARGER
The battery is very low. The handset should be placed in the telephone base or charger.
RINGER MUTE
The ringer is muted temporarily during incoming call.
SAVED
The call log entry has been saved in the directory.
SPEAKER
The handset speakerphone is in use.
UNABLE TO SAVE
You are attempting to save caller ID entry with no name or number in the directory.
WARNING CHECK BATTERY!
The battery is not installed or not installed properly in the handset.
-OR -
The battery needs to be replaced.
-OR -
An incorrect battery has been installed. Use only the supplied VTech battery or equivalent.
www.vtechphones.com
36
Handset indicators
Handset indicators
• On when the handset speakerphone is in use.
MUTE
• Microphone is muted.
• Ringer off.
NEW
• New call log entries.
• On when there is new voicemail message(s).
(Battery indicator)
• Cycles (low, medium, and full) when handset battery is charging. On when the battery is fully charged.
• Flashes when a low battery condition is detected.
www.vtechphones.com
37
Appendix
Telephone base indicators
IN USE • On when the handset is in use or you are registering a handset.
• Flashes while there is an incoming call; or an extension on the same telephone line is in use; or you are registering a handset on the telephone base.
VOICEMAIL • Flashes when there is a new voicemail message. (A subscription service from your local
telephone company is required.)
CHARGE • On when the handset is properly positioned in the telephone base.
Telephone base indicators & charger indicator
Charger indicator
CHARGE • On when the handset is properly positioned in the charger.
www.vtechphones.com
38
Battery
After the battery is fully charged, you can expect the following performance:
Operation Operating time
While in use (talking) 8 hours
While not in use (standby*) 96 hours (4 days)
*The handset is off the telephone base or charger but not in use.
The battery needs charging when:
• A new battery is installed in the handset.
• The handset beeps.
LOW BATTERY is displayed and the battery indicator on the handset display is ashing.
CAUTION:
To reduce the risk of re or injury, read and follow these instructions:
Use only the batteries provided or equivalent. To order a replacement, visit our website at www. vtechphones.com or call 1 (800) 595-9511. In Canada, go to www.vtechcanada.com or call 1 (800) 267-7377.
Do not dispose of the battery(ies) in a re. They may explode. Check with local waste management codes for special
disposal instructions. Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may cause burns or injury to the eyes or
skin. The electrolyte may be toxic if swallowed. Exercise care in handling batteries in order not to create a short circuit with conductive materials such as rings, bracelets,
and keys. The battery and/or conductor may overheat and cause burns.
Charge the battery(ies) provided with or identied for use with this product only in accordance with the instructions and limitations specied in this manual.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO WATER OR ANY TYPE OF MOISTURE.
1.
2.
3.
4.
5.
www.vtechphones.com
39
Appendix
Troubleshooting
Problem Suggestion
My telephone does not work at all.
Make sure the battery is installed and charged correctly (pages 4 and 5). For optimum daily performance, return the cordless handset to the telephone base or charger after use.
Make sure the power adapter is securely plugged into an outlet not controlled by a wall switch.
Make sure the telephone line cord is plugged rmly into the telephone base and the modular
wall jack. Unplug the unit’s electrical power. Wait for approximately 15 seconds, then plug it back in. Allow
up to one minute for the cordless handset and telephone base to synchronize. Charge the battery in the cordless handset for at least 16 hours. Remove and re-insert the battery. If that still does not work, it may be necessary to purchase
a new battery.
If you have difculty operating your telephone, please try the suggestions below. For Customer
Service, visit our website at www.vtechphones.com, or call 1 (800) 595-9511. In Canada, go to www. vtechcanada.com or call 1 (800) 267-7377.
www.vtechphones.com
40
Problem Suggestion
Registration failure. Only one handset can be registered at a time. If you have multiple handsets to register, please
follow the steps on page 6 for the rst handset. Once a handset has been successfully registered,
repeat the steps for each handset that needs to be registered. Make sure that the telephone base and handset(s) are in idle mode when registering a
handset. Follow the steps on page 47 for the common cure for electronic equipment.
LOW BATTERY
is
displayed on screen.
Place the handset in the telephone base or charger for recharging. Remove and re-install the battery and use it normally until fully discharged, then recharge the
handset in the telephone base or charger for 16 hours. If the above measures do not correct the problem, the battery may need to be replaced.
Troubleshooting
www.vtechphones.com
41
Appendix
Troubleshooting
Problem Suggestion
The battery does not charge in the handset or the handset battery does not accept charge.
Make sure the handset is placed in the telephone base or charger correctly. The CHARGE light on the telephone base or charger should be on.
Remove the battery from the handset and re-install it to the handset. Put the handset back in the telephone base or charger and let it charge for at least 16 hours.
If the cordless handset is in the charger or in the telephone base but the CHARGE light is not on, refer to the steps on this page for The CHARGE light is off.
It may be necessary to purchase a new battery. Please refer to the Battery section (page 38) of this user’s manual.
The CHARGE light is off.
Clean the charging contacts on the cordless handset(s), telephone base and charger each month using a pencil eraser or a dry non-abrasive fabric.
Make sure the power adapter is plugged in correctly and securely. Unplug the power adapter. Wait for 15 seconds before plugging it back in. Allow up to one
minute for the cordless handset and telephone base to reset.
www.vtechphones.com
42
Troubleshooting
Problem Suggestion
There is no dial tone. Ensure the handset has been registered to the telephone base (page 6).
Move the cordless handset closer to the telephone base. It might be out of range. The telephone line cord might be malfunctioning. Try installing a new telephone line cord. Disconnect the telephone base from the telephone jack and connect a working telephone. If
there is no dial tone on that telephone either, the problem is in your wiring or local service. Contact your local telephone company.
I cannot dial out. First, try all the above suggestions.
Make sure there is a dial tone before dialing. It is normal if the cordless handset takes a second or two to synchronize with the telephone before producing a dial tone. Wait for a dial tone before dialing.
If the other telephones in your home are having the same problem, the problem is in the wiring or local service. Contact your local telephone company (charges may apply).
Eliminate any background noise. Noise from a television, radio, or other appliances may cause
the telephone to not dial out properly. If you cannot eliminate the background noise, rst try
muting the cordless handset before dialing, or dial from another room in your home with less background noise.
www.vtechphones.com
43
Appendix
Troubleshooting
Problem Suggestion
The telephone does not ring when there is an incoming call.
Ensure the handset has been registered to the telephone base (page 6). Make sure the ringer is on (page 12). Make sure the telephone line cord and power adapter are plugged in properly (page 2). The cordless handset may be too far from the telephone base. Move it closer to the telephone
base. There may be too many extension telephones on the telephone line to allow all of them to ring
simultaneously. Try unplugging some of them. If the other telephones in your home are having the same problem, the problem is in the wiring
or local service. Contact the local telephone company (charges may apply). Other electronic products can cause interference to your cordless telephone. Try installing your
telephone as far away as possible from the following electronic devices: wireless routers, radios, radio towers, pager towers, cellular telephones, digital telephones, intercoms, room monitors, televisions, VCRs, personal computers, kitchen appliances, and other cordless telephones.
Test a working telephone at the telephone jack. If another telephone has the same problem, the problem is in the telephone jack. Contact your local telephone company (charges may apply).
The telephone line cord might be malfunctioning. Try installing a new telephone line cord. Re-install the battery and place the cordless handset in the telephone base. Wait for the cordless handset to synchronize with the telephone base. Allow up to one minute
for this to take place.
www.vtechphones.com
44
Troubleshooting
Problem Suggestion
There is noise or interference during a telephone conversation.
-OR-
My calls fade out when I am using the cordless handset.
The handset may be out of range. Move it closer to the telephone base. Appliances or other cordless telephones plugged into the same circuit as the telephone base
can cause interference. Try moving the appliance or telephone base to another outlet. Other electronic products can cause interference to your cordless telephone. Try installing
your telephone as far away as possible from the following electronic devices: wireless routers, radios, radio towers, pager towers, cellular telephones, digital telephones, intercoms, room monitors, televisions, VCRs, personal computers, kitchen appliances, wireless routers, and other cordless telephones.
If your telephone is plugged in with a modem or a surge protector, plug the telephone (or modem/surge protector) into a different location. If this solves the problem, re-locate your telephone or modem farther apart from each other, or use a different surge protector.
The layout of your home or ofce might be limiting the operating range. Try moving the telephone
base to another location, preferably a higher location for better reception. Disconnect the telephone base from the modular jack and plug in a corded telephone. If calls
are still not clear, the problem is probably in the wiring or local service. Contact your local service company (charges may apply).
If the other telephones in your home are having the same problem, the problem is in the wiring or local service. Contact the local telephone company (charges may apply).
Do you subscribe DSL Internet service? If yes, you must install a DSL lter to the telephone line
between the telephone base and the telephone line jack. Contact your DSL service provider
for lters and installation instructions.
www.vtechphones.com
45
Appendix
Troubleshooting
Problem Suggestion
I hear other calls when using the telephone.
Disconnect the telephone base from the telephone jack. Plug in a different telephone. If you still hear other calls, the problem is probably in the wiring or local service. Call your local telephone company.
I hear noise in the cordless handset, and none of the keys or buttons work.
Make sure the telephone line cord is plugged in securely. Remove the battery from the handset and re-install it.
My caller ID features are not working properly.
Caller ID is a subscription service. You must subscribe to this service from your local telephone company for this feature to work on your telephone.
The caller may not be calling from an area which supports caller ID. Both you and the caller’s telephone companies must use equipment which are compatible
with caller ID service.
If you subscribe to DSL Internet service, you must install a DSL lter to the telephone line
between the telephone base and the telephone line jack. Contact your DSL service provider
for lter information.
www.vtechphones.com
46
Problem Suggestion
The system does not receive caller ID or the system does not display caller ID during call waiting.
Make sure you subscribe to caller ID with call waiting features services provided by the local telephone company.
The caller may not be calling from an area which supports caller ID. Both you and the caller’s telephone companies must have compatible caller ID systems.
If you subscribe to DSL Internet service, you must install a DSL lter to the telephone line
between the telephone base and the telephone line jack. Contact your DSL service provider
for lter information.
Caller ID entries do not match the numbers I need to dial.
Although the call log entries you receive have 10 digits, (the area code plus the seven-digit number) in some areas, you may need to dial only the seven digits, or a 1 plus the seven digits, or a 1 plus the area code plus the seven digits. You can change the number of digits that you dial from the call log. While reviewing the call log, press # repeatedly to display these dialing options for local and long distance numbers before dialing or saving the telephone number.
Troubleshooting
www.vtechphones.com
47
Appendix
Troubleshooting
Problem Suggestion
My cordless handset beeps and is not performing normally.
Make sure the power cord is securely plugged into the telephone base. Plug the unit into a different working electrical outlet not controlled by a wall switch.
Move the cordless handset closer to the telephone base. It may be out of range. Reset the telephone base by unplugging the unit’s electrical power. Wait for 15 seconds and
plug it back in again. Allow up to one minute for the cordless handset and the telephone base to synchronize.
Other electronic products can cause interference to your cordless telephone. Try installing your telephone as far away from these electronic devices as possible: wireless routers, radios, radio towers, pager towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.
Common cure for electronic equipment.
If the unit is not responding normally, try putting the cordless handset in the telephone base or the charger. If it does not seem to respond, try the following (in the order listed):
Disconnect the power to the telephone base. Disconnect the battery from the cordless handset. Wait a few minutes before connecting power to the telephone base. Re-install the battery and place the cordless handset into the telephone base or charger. Wait for the cordless handset to synchronize its connection with the telephone base. Allow up
to one minute for this to take place.
www.vtechphones.com
48
Important safety instructions
When using your telephone equipment, basic safety precautions should always be followed:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bathtub, kitchen sink, or swimming pool).
5. Do not place this product on an unstable surface such as a table, shelf or stand. This product may fall, causing serious damage.
6. Slots and openings in the back or bottom of the telephone base and handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in an area where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not install this product where the cord may be walked on.
9. Never push objects of any kind into this product through slots in the telephone base or handset as they may touch dangerous voltage
points or create a short circuit that could result in a risk of re or electric shock. Never spill liquid of any kind on the product.
10.
To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing
parts of the telephone base or handset other than specied access doors may expose you to dangerous voltages or other risks. Incorrect
reassembling can cause electric shock when the product is subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk of re or electric shock.
12. Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled onto the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operation instructions, as improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation. E. If the product has been dropped and the telephone base and/or handset has been damaged. F. If the product exhibits a distinct change in performance.
13. The power unit is intended to be correctly oriented in a vertical or oor mount position. The prongs are not designed to hold the plug in
place if it is plugged into a ceiling, under-the-table or cabinet outlet.
14. Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning.
15. Do not use the telephone to report a gas leak in the vicinity of the leak.
16. Only put the handset of your telephone next to your ear when it is in normal talk mode.
CAUTION: Use only the power adapter provided with this product. To purchase, visit our website at www.vtechphones.com or call 1 (800) 595-9511. In Canada, go to www.vtechcanada.com or dial 1 (800) 267-7377.
SAVE THESE INSTRUCTIONS
www.vtechphones.com
49
Appendix
Operating range
This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance ----which can vary with the locations of the telephone base and
handset, the weather, and the layout of your home or ofce.
When the handset is out of range, the handset will display CONNECTING.... The user can access certain parts of the menu system, i.e.
handset setting, but not the handset directory and call log. NOT AVAILABLE AT THIS TIME will be displayed if access is denied. If there is a call while the handset is out of range, it might not ring, or if it does ring, the call might not connect well when you press /FLASH.
Move closer to the telephone base, then press /FLASH to answer the call. If the handset moves out of range during a telephone conversation, there might be interference. To improve receiption, move closer to the telephone base.
Maintenance
Taking care of your telephone
Your cordless telephone contains sophisticated electronic par ts, so it must be treated with care.
Avoid rough treatment
Place the handset down gently. Save the original packing materials to protect your telephone if you ever need to ship it.
Avoid water
Your telephone can be damaged if it gets wet. Do not use the handset outdoors in the rain, or handle it with wet hands. Do not install your telephone base near a sink, bathtub or shower.
Electrical storms
Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own safety, use caution when using electrical appliances during storms.
Cleaning your telephone
Your telephone has a durable plastic casing that should retain its luster for many years. Clean it only with a soft cloth slightly dampened with water or a mild soap. Do not use excess water or cleaning solvents of any kind.
Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If your telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the unit out by the unplugged cords.
www.vtechphones.com
50
About cordless telephones
Privacy: the same features that make a cordless telephone convenient create some limitations. Telephone calls are transmitted between the base and the
cordless handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.
Electrical power: The telephone base of this cordless telephone must be connected to a working electric al outlet. The electrical outlet should not be controlled by a wall switch. Calls cannot be made from the cordless handset if the telephone base is unplugged or switched off, or if the electrical power is interrupted.
Potential TV interference: Some cordless telephones operate at frequencies that may cause inter ference to televisions and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR will often reduce or eliminate the inter ference. (Applies to 25 channel cordless telephones only).
Rechargeable batteries: This product c ontains either Nickel-Cadmium or Nickel-Metal Hydride rechargeable batteries. Exercise care in handling batteries in order not to create a short circuit conducting material such as rings, bracelets, and keys. The batter y or conductor may overheat and cause harm. Obser ve proper polarity between the batter y and the battery charger.
Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release c austic material which could cause injury.
Warranty
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the holder of a valid proof of purchase (“Consumer” or “you”) that the Product and all accessories provided in the sales package (“ Product ”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the Product operating instructions. This limited warranty extends only to the Consumer for Products purchased and used in the United States of America and Canada.
What will VTech do if the Product is not free from defects in materials and workmanship during the limited warranty period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized service representative will repair or replace at VTech’s option, without charge, a Materially Defective Product. If we repair the Product, we may use new or refurbished replacement parts. If we choose to replace the Product, we may replace it with a new or refurbished Product of the same or similar design. We will retain defective parts, modules, or equipment. Repair or replacement of the Product, at V Tech’s option, is your exclusive remedy. VTech will return repaired or replacement Products to you in working condition. You should expect the repair or replacement to take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for ONE (1) YEAR from the date of purchase. If VTech repairs or replaces a Materially Defective Product under the terms of this limited warranty, this limited warranty also applies to the repaired or replacement Product for a period of either (a) 9 0 days from the date the repaired or replacement Product is shipped to you or (b) the time remaining on the original one-year warranty; whichever is longer.
What is not covered by this limited warranty?
This limited warrant y does not cover:
1. Product that has been subjected to misuse, accident, shipping or other physical damage, improper installation, abnormal operation or handling, neglect,
inundation, re, water or other liquid intrusion; or
www.vtechphones.com
51
Appendix
2. Product that has been damaged due to repair, alteration or modication by anyone other than an authorized ser vice representative of VTech; or
3. Product to the extent that the problem experienced is caused by signal conditions, network reliability, or cable or antenna systems; or
4. Product to the extent that the problem is caused by use with non-VTech accessories; or
5. Product whose warranty/quality stickers, product serial number plates or electronic serial numbers have been removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair from outside the United States of America or Canada, or used for commercial or institutional purposes (including but not limited to Products used for rental purposes); or
7. Product returned without valid proof of purchase (see item 2 below); or
8. Charges for installation or set up, adjustment of customer controls, and installation or repair of systems outside the unit.
How do you get warranty service?
To obtain warranty service in the United States of America, please call 1 (800) 595-9511; In Canada, please call 1 (800) 267-7377. NOTE: Before calling for service, please review the user’s manual - a check of the Product controls and features may save you a ser vice call.
Except as provided by applicable law, you assume the risk of loss or damage during transit and transpor tation and are responsible for delivery or handling charges incurred in the transport of the Product(s) to the service location. VTech will return the repaired or replaced Product under this limited warranty to you, transpor tation, delivery or handling charges prepaid. VTech assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by this limited warrant y, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of Products that are not covered by this limited warranty.
What must you return with the Product to get warranty service?
1.
Return the entire original package and contents including the Product to the VTech service location along with a description of the malfunction or dif culty; and
2. Include “valid proof of purchase” (sales receipt) identifying the Product purchased (Product model) and the date of purchase or receipt; and
3. Provide your name, complete and correct mailing address, and telephone number.
Other Limitations
This warranty is the complete and exclusive agreement bet ween you and VTech. It supersedes all other written or oral communications related to this Product. VTech provides no other warranties for this Product. The warrant y exclusively describes all of VTech’s responsibilities regarding the Product. There are no other
express warranties. No one is authorized to make modications to this limited warranty and you should not rely on any such modication. State/Provincial Law Rights: This warranty gives you specic legal rights, and you may also have other rights, which vary from state to state or province to province. Limitations: Implied warranties, including those of tness for a particular purpose and merchantability (an unwritten warranty that the Product is t for ordinary
use) are limited to one year from date of purchase. Some states/provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. In no event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost
prots or revenue, inability to use the Product or other associated equipment, the cost of substitute equipment, and claims by third par ties) resulting from the use
of this Product. Some states/provinces do not allow the exclusion or limitation of incidental or c onsequential damages, so the above limitation or exclusion may not apply to you.
Please retain your original sales receipt as proof of purchase.
Warranty
www.vtechphones.com
52
FCC, ACTA and IC regulations
FCC Part 15
This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
Changes or modications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this telephone.
To ensure the safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more. If you choose to use a clipping device, please make sure to only use the supplied VTech belt clip.
This Class B digital apparatus complies with Canadian ICES-003.
FCC Part 68 and ACTA
This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The
label on the back or bottom of this equipment contains, among other things, a product identier in the format US:AAAEQ##TXXXX. This identier must be provided to
your local telephone company upon request.
The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with the applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. They are designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.
The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called.
The REN for this product is encoded as the 6th and 7th characters following the US: in the product identier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be ve (5.0) or less. For more information, please contact your local telephone company.
This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this
equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualied installer.
If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty.
www.vtechphones.com
53
Appendix
The RBRC® Seal on the nickel-metal-hydride battery indicates that VTech Communications, Inc. is voluntarily participating in an industry program to collect and recycle these batteries at the end of their useful lives, when taken out of service within the United States and Canada.
The RBRC® program provides a convenient alternative to placing used nickel-metal-hydride batteries into the trash or municipal waste,which may be illegal in your area.
VTech’s participation in RBRC® makes it easy for you to drop off the spent battery at local retailers par ticipating in the RBRC® program or at authorized VTech product service centers. Please call 1-800 -8-BATTERYTM for information on Ni-MH batter y recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment
and conserving natural resources.
RBRC® is a registered trademark of Rechargeable Battery Recycling Corporation.
The RBRC® Seal
If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is
required to notify you before interrupting service. If advance notice is not practical, you will be notied as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to le a complaint with the FCC. Your telephone company may make changes in its
facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned.
If this product is equipped with a corded or cordless handset, it is hearing aid compatible.
If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, re, medical) in these locations. If you do store or
test emergency numbers, please:
Remain on the line and briey explain the reason for the call before hanging up.
Perform such activities in off-peak hours, such as early morning or late evening.
Industry Canada
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.
The term ‘’IC: ‘’ before the certication/registration number only signies that the Industry Canada technical specications were met.
The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone
interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does
not exceed ve. This product meets the applicable Industry Canada technical specications.
FCC, ACTA and IC regulations
www.vtechphones.com
54
Technical specications
Frequency control Crystal controlled
PLL synthesizer
Transmit frequency Telephone base: 1921.536-1928.448 MHz
Handset: 1921.536-1928.448 MHz
Channels 5
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according
to environmental conditions at the time of use.
Size Handset: 149.7mm X 53.1mm X 36.8mm
Telephone base: 101.2mm X 118.6mm X 98.5mm Charger: 88.8mm X 105.6mm X 84.5mm
Weight Handset: 148.9 grams (including battery)
Telephone base: 155.0 grams Charger: 90.0 grams
Power requirements Handset: 2.4V DC 600mAH NiMH battery
Telephone base: 6V DC @ 300mA Charger: 6V DC @200mA
Memory Directory: 50 memory locations; up to 32 digits and 16 characters per location
Call log: 50 memory locations; up to 24 digits and 16 characters per location
www.vtechphones.com
55
Appendix
Index
A
About caller ID 27 About cordless telephones 50 Adding a new handset 6 Advanced operation 23 Answer an incoming call during an intercom call 20
B
Basic operation 17 Battery 38 Battery charging 5 Battery installation 4 Belt clip & headset 9
C
Caller ID 28 Call log display screen messages 31 Call waiting 18 Character chart 24 Charger indicator 37 Clear voicemail 14
D
Delete from redial 32 Delete from the call log 31 Delete from the directory 26 De-register all handsets 8
Dial a call log entry 30 Dial a directory entry 25 Dial from redial 32 Dialing options 29 Directory 23
DSL lter 3
E
Edit a directory entry 26
F
FCC, ACTA and IC regulations 52 Find handset 19
H
Handset display screen messages 33 Handset indicators 36 Handset layout 10
I
Important safety instructions 48 Installation 1 Intercom 20
K
Key tone 13
www.vtechphones.com
56
Index
L
Language 13
M
Maintenance 49 Make, answer and end calls 17 Make CID entries ready to dial 29 Multiple handset use 18 Mute 17
O
Operating range 49
P
Parts checklist 1
R
Redial 32 Registration of new handset 6 Review redial 32 Review the call log 29 Ringer tone 12 Ringer mute 18 Ringer volume 12
S
Save an entry to the directory 30 Search the directory 25 Speakerphone 17 Store a directory entry 23 Switch between external and internal calls 22
T
Technical specications 54
Telephone base & charger installation 2 Telephone base indicators & charger indicator 37 Telephone base layout 11 Telephone settings 12
The RBRC® Seal 53 Transfer an external call 21 Troubleshooting 39
V
Voicemail 19 Voicemail setup 15 Volume 18
W
Warranty 50
VTECH TELECOMMUNICATIONS LTD.
A member of THE VTECH GROUP OF COMPANIES.
Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon
Distributed in Canada by VTech Technologies Canada, Ltd., Richmond, B.C.
Copyright ©2008 for VTECH TELECOMMUNICATIONS LTD.
Printed in China.
91-001410-080-100
User’s manual
w w w . v t e c h p h o n e s . c o m
Models: DS3111-2/TM3111-2 DS3111-3/DS3111-4
Loading...
