VTech 2600 User Manual

Introduction

EXPAND YOUR v 2651 OR v 2656 SYSTEM. YOUR BASE
CAN SUPPORT UP TO 4 HANDSETS!!!

IMPORTANT:

The

v 2600

You must have one of these models in order to use this accessory Handset.
This manual is designed to familiarize you with the

registration and basic functions. For detailed operational instructions, please refer
to the

To order additional system Handsets (model# v 2600), battery packs, or
headsets, call VTech Communications, Inc. at 1-800-595-9511. In Canada, call
1-800-267-7377.

is an Accessory Handset for use with the

v 2651

or

v 2656

User's Manuals.

STOP!!

v 2651

or

v 2656

v 2600

Accessory Handset setup,

system.

If you have questions about this product, or if you're having difficulty with
setup or operation, do not return your phone to the store. Call our Customer
Support Center at:

In Canada, call
1-800-267-7377

1-800-595-9511

1

Important Safety Instructions

When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury, including the following:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners

or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water (for example, near a bath tub, kitchen sink,

or swimming pool).

5. Do not place this product on an unstable cart, stand, or table. The product may

fall, causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom are provided for ventilation.

To protect it from overheating, these openings must not be blocked by placing the
product on the bed, sofa, rug, or other similar surface. This product should never
be placed near or over a radiator or heat register. This product should not be placed
in a built-in installation where proper ventilation is not provided.

7. This product should be operated only from the type of power source indicated on

the marking label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.

8. Do not allow anything to rest on the power cord. Do not locate this product where

the cord will be abused by persons walking on it.

9. Never push objects of any kind into this product through cabinet slots as they may

touch dangerous voltage points or short out parts that could result in a risk of fire
or electric shock. Never spill liquid of any kind on the product.

10. To reduce the risk of electric shock, do not disassemble this product, but take it

to a VTech authorized service facility. Opening or removing cabinet parts other than
specified access doors may expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock when the appliance is
subsequently used.

11. Do not overload wall outlets and extension cords as this can result in the risk of

fire or electric shock.

12. Unplug this product from the wall outlet and refer servicing to VTECH under the

following conditions:
A.When the power supply cord or plug is damaged or frayed.
B.If liquid has been spilled into the product.
C.If the product has been exposed to rain or water.
D.If the product does not operate normally by following the operating instructions.

Adjust only those controls that are covered by the operating instructions, because
improper adjustment of other controls may result in damage.

E.If the product has been dropped and the cabinet has been damaged.
F.If the product exhibits a distinct change in performance.

13. Avoid using a telephone (other than a cordless type) during an electrical storm.

There may be a remote risk of electric shock from lighting.

14. Do not use the telephone to report a gas leak in the vicinity of the leak.

VTECH COMMUNICATIONS, INC.

Customer Service : 1-800-595-9511. In Canada, call VTech Telecommunications
Canada Ltd . at 1-800-267-7377.

SAVE THESE INSTRUCTIONS

2

3

Getting Started

Setup

Installation of Battery Pack in Handset

Registration And Operation Of The VTECH v 2600
Accessory Handset

Your v 2651 or v 2656 system can support up to 4 Handsets.
The accessory Handset v 2600 consists of the following:

Setup Of The v 2600
Accessory Handset

Follow the steps below:

1. Remove the battery cover by pressing

on the indent and sliding downward.

2. Align the two holes in plug with the

socket pins. Insert the plug into
socket. Place the battery pack into
the compartment with the wires in
one of the lower corners, along the
bottom of the battery pack.

3. Replace the battery cover by sliding

it upwards.

4. If the new battery pack is not already

charged, place the handset in the
base unit, or a remote charging stand,
and allow it to charge for 12 hours.
After the first charge, a drained
Handset battery pack will recharge in
approximately 8 hours.

The original Handset that is shipped with your v 2651 or v 2656 will be automatically
registered to the Base. This Handset is HANDSET 1.

As you register additional Handsets to the system, they will be assigned extension
numbers in the following order: HANDSET 2 , HANDSET 3 , HANDSET 4 .

Whenever a Handset battery pack is installed, the Handset will automatically begin

SEARCHING FOR BASE (if previously registered), or it will prompt you to ENTER
BASE ID to register the new Handset.

1. Plug the AC power adapter into an

electrical outlet.

2. Install the battery pack, as described

on the following page.

4

BEFORE USING YOUR HANDSET(S), CAREFULLY PEEL OFF THE PROTECTIVE
FILM, COVERING THE DISPLAY.

5

Registration

The Handset Layout

NOTE: Your Handset that comes with the v 2651/2656 system is registered
to the Base at the factory. The following steps are for registration of
additional Handsets (model# v 2600):

Enter Base ID Code

1. After charging the Handset, remove it from its

Charge Cradle. If the screen will displays
SEARCHING FOR BASE, press NEW. If the
screen displays ENTER BASE ID, go to step 2.

2. Enter the 15 digit Base ID Code, located on the

underside of the Base Unit. The ID Code can
include numbers (0-9) and characters (*).

3. Press

WAIT!!

OK

. The Handset will display: PLEASE

4. Wait approximately 15 seconds. The Handset will

display:

FOUND BASE
NOTE: Occasionally, it will take longer than 15

second for the Handset to find the Base Unit.
This is normal.

If the Handset displays: BASE BUSY TRY LATER,
this indicates that the system is in use. Wait until
the Base Unit is in the idle (on hook) mode, and
repeat steps 2 to 4.

1

2

3

4

5

6

7

1. Antenna

2. Earpiece

3. Scroll Keys

4. Headset Jack (2.5mm)

8

9

10

11

12

8. LCD Display

9. Select/Menu

10. Off (Clear)

11. Intercom

Congratulations! You can now enjoy the benefits of your
VTech multi-Handset system.

6

5. On (Flash)

6. Dialing Keys (0-9, *, #)

7. Handsfree Speakerphone

7

12. Microphone

Handset Operation

Handset Indicators

Headset OperationAdditional Information

Handset Icons

Icon

M
H
E

Description

Line In Use indicator
On steady with no number next to it when a parallel set is in use.
On steady with one or more numbers next to it, indicating
which extensions are using the line. For example, 12 indicates

that Handset 1 and Handset 2 are on an outside call.

Intercom indicator
On steady with the extension numbers currently on an
intercom call. For example, 02 indicates that the Base and
Handset 2 are on an intercom call.

Battery indicator
Cycles (Low, Medium, and High) when Handset battery is charging.
Flashes when a low battery condition is detected.

Mute indicator
On steady when the Handset microphone is muted.

Hold indicator
On steady when the line is on hold.

Range Extender indicator
On steady when the Range Extender is on.

Handset Registration indicator

FF is displayed when a Handset is either not registered, or is

searching for a Base unit.

Charger LED indicator

Charger LED
Charging

Lights whenever the Handset is placed in the charger cradle.

Your cordless telephone is equipped with a 2.5mm Headset Jack for use with an optional
accessory Headset for hands-free operation. If you choose to use the Headset option,
you must obtain an optional accessory Headset, which is compatible with the Handset.

To purchase a Headset, call VTech Customer Service at 1-800-595-9511; in
Canada, call 1-800-267-7377.

Once you have a compatible 2.5mm Headset, locate the Headset Jack on the Handset.
Connect the plug on the Headset cord to the jack (under a small rubber flap) on the
cordless Handset. The plug should fit securely. Do not force the connection.

NOTE :

Whenever a compatible Headset is connected to the
cordless Handset, the microphone on the Handset will
be muted. This is done to limit the effect of background
noise.

Belt Clip

Your Handset is equipped with an attached belt clip.
At the top of the Handset, slide the clip away from
the body of the Handset by pushing on the indent
with your finger.

CAUTION: The Belt Clip is designed to remain attached
to the Handset. Do not attempt to remove it.

8

9

Maintenance

In Case Of Difficulty

Taking Care Of Your Telephone

Your cordless telephone contains sophisticated electronic parts, so it must be treated
with care.

Avoid rough treatment

Place the Handset down gently. Save the original packing materials to protect your
telephone if you ever need to ship it.

Avoid water

Your telephone can be damaged if it gets wet. Do not use the Handset outdoors in the
rain, or handle it with wet hands. Do not install your Base Unit near a sink, bathtub or
shower.

Electrical storms

Electrical storms can sometimes cause power surges harmful to electronic equipment.
For your own safety, use caution when using electric appliances during storms.

Cleaning your telephone

Your telephone has a durable plastic casing that should retain its luster for many years.
Clean it only with a soft cloth slightly dampened with water or a mild soap. Do not
use excess water or cleaning solvents of any kind.

Remember that electrical appliances can cause serious injury if used when you are
wet or standing in water. If your Base Unit should fall into water, DO NOT RETRIEVE

IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM
THE WALL. Then pull the unit out by the unplugged cords.

Periodic cleaning of the charge contacts

For optimum performance, regularly clean the metal charge contacts located
in the Base Unit charge cradle and on the bottom of the Handset. Gently rub
the contacts with a clean pencil eraser. In most environments, monthly contact
maintenance is sufficient.

If you have difficulty operating your phone, the suggestions below should solve the problem.
If you still have difficulty after trying these suggestions, call VTECH Communications
at 1-800-595-9511. In Canada, call VTECH Telecommunications Canada Ltd at 1-800­267-7377.

The Phone Doesn't Work At All

• Make sure the Power Cord is plugged

• Make sure the telephone line cord is plugged firmly into the Base Unit and the
telephone wall jack.

• Make sure the batteries are properly charged. If the 'LOW BATTERY' message
is shown, the battery pack needs charging.

• Is the Handset registered to the Base? See Registration.

No Dial Tone

• First check all the suggestions above.

• If you still don't hear a dial tone, disconnect the Base Unit from the telephone jack
and connect a different phone. If there is no dial tone on that phone either, the
problem is in your wiring or local service. Call your local telephone company.

You Get Noise, Static, Or A Weak Signal Even When You're
Near The Base Unit

• Household appliances plugged into the same circuit as the Base Unit can sometimes
cause interference. Try moving the appliance or the Base Unit to another outlet.

You Get Noise, Static, Or A Weak Signal When You're Away
From The Base Unit

• You may be out of range. Either move closer to the Base, or relocate the Base
Unit.

• The layout of your home may be limiting the range. Try moving the Base Unit to
another position.

The Handset Does Not Ring When You Receive A Call

• Make sure you have the Handset ringer activated. To set the ringer, see HANDSET
SETTINGS and BASE SETTINGS in the v 2651 or v 2656 User’s Manual.

• Make sure the telephone line cord is plugged firmly into the Base Unit and the
telephone jack. Make sure the power cord is plugged in.

• You may be too far from the Base Unit.

10 11

In Case Of Difficulty

Warranty Statement

• You may have too many extension phones on your telephone line to allow all of
them to ring. Try unplugging some of the other phones.

You Hear Other Calls While Using Your Phone

• Disconnect your Base Unit from the telephone jack, and plug in a regular telephone.
If you still hear other calls, the problem is probably in your wiring or local service.
Call your local telephone company.

You Hear Noise In The Handset, And None Of The Keys
Or Buttons Work

• Make sure the power cord is plugged in.

Common Cure For Electronic Equipment

If the unit does not seem to be responding normally, then try putting the Handset in the
cradle. If it does not seem to respond, do the following (in the order listed) :

1. Disconnect the power to the Base.

2. Remove the Handset battery pack.

3. Wait a few minutes.

4. Connect power to the Base.

5. Re-install the battery pack.

6. Watch for Handset to display :

then

What does this limited warranty cover?

• The manufacturer of this VTECH product, VTECH Communications, warrants to the

holder of a valid proof of purchase (“Consumer” or “you”) that the product and all
accessories provided by VTECH in the sales package (“Product”) are free from material
defects in material and workmanship, pursuant to the following terms and conditions,
when installed and used normally and in accordance with operation instructions. This
limited warranty extends only to the Consumer for Products purchased and used in
the United States of America.

What will VTECH Communications do if the Product is not free from
material defects in materials and workmanship during the limited
warranty period (“Materially Defective Product”)?

• During the limited warranty period, VTECH’s authorized service representative will

repair or replace at VTECH’s option, without charge, a Materially Defective Product.
If we repair this product, we may use new or refurbished replacement parts. If we
choose to replace this product, we may replace it with a new or refurbished product
of the same or similar design.VTECH will return repaired or replacement products to
you in working condition. VTECH will retain defective parts, modules, or equipment.
Repair or replacement of Product, at VTECH’s option, is your exclusive remedy. You
should expect the repair or replacement to take approximately 30 days.

How Long is the limited warranty period ?

• The limited warranty period for the product extends for ONE(1)YEAR from the date

of purchase if we repair or replace a Materially Defective Product the terms of this
limited warranty. This limited warranty also applies to repaired or replacement Products
for a period of either (a) 90 days from the date the repaired or replacement Product
is shipped to you or (b) the time remaining on the original one-year limited warranty;
whichever is longer.

What is not covered by this limited warranty ?

This limited warranty does not cover

1. Product that has been subjected to misuse, accident, shipping or other physical
damage, improper installation, abnormal operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or

2. Product that has been damaged due to repair, alteration or modification by anyone
other than an authorized service representative of VTECH; or

3. Product to the extent that the problem experienced is caused by signal conditions,
network reliability or cable or antenna systems; or

4. Product to the extent that the problem is caused by use with non-VTECH electrical
accessories; or

5. Product whose warranty/quality stickers, Product serial numbers plates or electronic
serial numbers have been removed, altered or rendered illegible; or

6. Product purchased, used, serviced, or shipped for repair from outside the United

12 13

Warranty Statement

Warranty Statement

States, or used for commercial or institutional purposes (including but not limited to
Products used for rental purposes); or

7. Product returned without valid proof of purchase (see 2 below); or

8. Charges for installation or set up, adjustment of customer controls, and installation
or repair of systems outside the unit.

How do you get warranty service?

• To obtain warranty service in the United States of America, call 1-800-595-9511 for
instructions regarding where to return the Product. Before calling for service, please
check the user’s manual. A check of the Product controls and features may save you
a service call.

• Except as provided by applicable law, you assume the risk of loss or damage during
transit and transportation and are responsible for delivery or handling charges incurred
in the transport of Product(s) to the service location. VTECH will return repaired or
replaced product under this limited warranty to you, transportation, delivery or handling
charges prepaid. VTECH assumes no risk for damage or loss of the Product in transit.

• If the Product failure is not covered by this limited warranty, or proof of purchase does
not meet the terms of this limited warranty, VTECH will notify you and will request that
you authorize the cost of repair prior to any further repair activity. You must pay for
the cost of repair and return shipping costs for the repair of Products that are not covered
by this limited warranty.

What must you return with the Product to get warranty service?

1. Return the entire original package and contents including the Product to the VTECH

service location along with a description of the malfunction or difficulty;

2. Include “valid proof of purchase” (sales receipt) identifying the Product purchased
(Product model) and the date of purchase or receipt; and

3. Provide your name, complete and correct mailing address, and telephone number.

Other Limitations

• This warranty is the complete and exclusive agreement between you and VTECH.

It supersedes all other written or oral communications related to this Product. VTECH
provides no other warranties for this product. The warranty exclusively describes all
of VTECH’s responsibilities regarding the product.

Limitations: Implied warranties, including those of fitness for a particular purpose
and merchantability (an unwritten warranty that the product is fit for ordinary use)
are limited to one year from date of purchase. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.

• In no event shall VTECH be liable for any indirect, special, incidental, consequential,
or similar damages (including, but not limited to lost profits or revenue, inability to
use the product, or other associated equipment, the cost of substitute equipment,
and claims by third parties) resulting from the use of this product. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.

There are no other express warranties. No one is authorized to make modifications
to this limited warranty and you should not rely on any such modification.

State Law Rights: This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.

14

15

FCC, ACTA and IC Regulations

FCC, ACTA and IC Regulations

This equipment complies with Parts 15 of the Federal Communications Commission (FCC)
rules for the United States. It also complies with regulations RSS210 and CS-03 of Industry
and Science Canada. Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.

A label is located on the underside of the Base Unit containing either the FCC registration
number and Ringer Equivalence Number (REN) or the IC registration number and Load
Number. You must, upon request, provide this information to your local telephone company.

This equipment is compatible with inductively coupled hearing aids.
Should you experience trouble with this telephone equipment, please contact:

VTech Communications Inc

CUSTOMER SERVICE at 1-800-595-9511. In Canada, call VTech Telecommunications
Canada Ltd at 1-800-267-7377.

For repair/warranty information, the telephone company may ask you to disconnect this
equipment from the line network until the problem has been corrected.

FCC Part 15

Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.

The equipment has been tested and found to comply with part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try and correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet or on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.
To comply with FCC RF exposure requirements, the Base Unit should be installed with

its antenna located at 5 cm or more from persons.

FCC and ACTA Information

If this equipment was approved for connection to the telephone network prior to July
23,2001, it was registered with the Federal Commissions (FCC) in accordance with
Part 68 of its rules. If the equipment was approved after that date, it complies with
the Part 68 rules and with Technical Requirements for Connection of Equipment to
the Telephone Network adopted by the Administrative Council for Terminal Attachments
(ACTA). We are required to provide you with the following information.

1. Connection and use with the nationwide telephone network

The plug and jack used to connect this equipmet to the premises wiring and the telephone
network must comply with the applicable Part 68 rules and technical requirements
adopted by ACTA. A compliant telephone cord and modular plug is provided with this
product. It is designed to be connected to a compatible modular jack that is also
compliant. An RJ11 jack should normally be used for connecting to a single line and
an RJ14 jack for two lines. See Installation Instructions in the user's manual. This
equipment may not be used with Coin Telephone Lines or with Party Lines.

2. Product identifier and REN information

The label on the back or bottom of this equipment contains, among other things, an
identifier indicating product approval and the Ringer Equivalence Number (REN). This
information must be provided to your local telephone company upon request, For equipment
approved prior to July 23,2001, the product identifier is preceded by the phrase "FCC
Reg No." and the REN is listed separately. For equipment approved after that date, the
product identifier is preceded by "US" and a colon (:), and the REN is encoded in the
product identifier as the sixth and seventh characters following the colon. For example,
the product identifier US: AAAEQ03T123XYZ would indicate an REN of 0.3.
The REN is used to determine how many devices you may connect to your telephone
line and still have them ring when you are called. In most , but not all areas, the sum
of all RENS should be five (5.0) or less, You may want to connect your local telephone
company for more information.

3. Repair instructions

If the equipment is malfunctioning, it must be unplugged from the modular jack until
the problem has been corrected. Repairs to this telephone equipment can only be made
by the manufacturer or its authorized agents. For repair procedures, follow the
instructions outlined under the Limited Warranty.

4. Rights of the telephone company

If this equipment is causing harm to the telephone network, the telephone company
may temporarily discontinue your telephone service. The telephone company is required
to notify you before interrupting service. If advance notice is not practical, you will be
notified as soon as possible. You will be given the opportunity to correct the problem
and the telephone company is required to inform you of your right to file a complaint

1716

FCC, ACTA and IC Regulations

FCC, ACTA and IC Regulations

with the FCC. Your telephone company may make changes in facilities, equipment,
operation, or procedures that could affect the proper functioning of this product. The
telephone company is required to notify you if such changes are planned.

5. Hearing aid compatibility

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

6. Programming/testing of emergency numbers

If this product has memory dialing locations, you may choose to store police, fire
department and emergency medical service telephone number in this locations. If you
do, please keep three things in mind:

a. We recommend that you also write the telephone number on the directory card, so

that you can still dial the emergency number manually if the memory dialing feature
doesn't work.

b. This feature is provided only as a convenience, and the manufacturer assumes no

responsibility for customer reliance upon the memory feature.

c. Testing the emergency telephone numbers you have stored is not recommended.

However, if you do make a call to an emergency number:

• You must remain on the line and briefly explain the reason for the call before hanging up.

• Programming/testing of emergency numbers should be performed during off-peak

hours, such as in the early morning or late evening, when the emengency services
tend to be less busy.

IC (Industry Canada)

This telephone is registered for use in Canada.

Notice:

This equipment meets the applicable Industry Canada Terminal Equipment Technical
Specifications. This is confirmed by the registration number. The abbreviation, IC, before
the registration number signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical specifications were met. It does
not imply that Industry Canada approved the equipment.

Notice:

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN
assigned to each terminal equipment provides an indication of the maximum number
of terminals allowed to be connected to a telephone interface. The termination on an
interface may consist of any combination of devices subject only to the requirement
that the sum of the Ringer Equivalence Numbers of all the devices does not exceed
five.

Before installing this equipment, users should ensure that it is permissible to be connected
to the facilities of the local telecommunications company. The equipment must also be
installed using an acceptable method of connection. The customer should be aware that
compliance with the above conditions may not prevent degradation of services in some
situations.

Repairs to certified equipment should be made by an authorized Canadian maintenance
facility designated by the supplier. Any repairs or alterations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications company cause
to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of
the power utility, telephone lines and internal metallic water pipe system, if present, are
connected together. This precaution may be particularly important in rural areas.

Caution :

Users should not attempt to make such connections themselves, but should contact the
appropriate electrical inspection authority, or electrician, as appropriate.

Your telephone is designed to operate at the maximum power allowed by the FCC and
IC. This means your Handset and Base Unit can communicate only over a certain distance

- which will depend on the location of the Base Unit and Handset, weather, and the
construction and layout of your home or office.

R

The RBRC Seal

The RBRC® Seal on the nickel-cadmium battery indicates that VTech
Communications, Inc. is voluntarily participating in an industry program to
collect and recycle these batteries at the end of their useful lives, when taken
out of service within the United States and Canada.

The RBRC
cadmium batteries into the trash or municipal waste, which may be illegal in your area.
VTech’s participation in RBRC
retailers participating in the RBRC® program or at authorized VTech product service

centers.Please call 1-800-8-BATTERY
disposal bans/restrictions in your area.VTech’s involvement in this program is part of its
commitment to protecting our environment and conserving natural resources.

RBRC ® is a registered trademark of Rechargeable Battery Recycling Corporation.

®

program provides a convenient alternative to placing used nickel-

®

makes it easy for you to drop off the spent battery at local

TM

for information on Ni-Cd battery recycling and

18

19

Technical Specifications

FREQUENCY CONTROL

Crystal controlled
PLL synthesizer

TRANSMIT FREQUENCY

2401.056 - 2482.272 MHz

RECEIVE FREQUENCY

2401.056 - 2482.272 MHz

CHANNELS

95 Channels

NOMINAL EFFECTIVE
RANGE

Maximum power allowed by FCC and IC.
Actual operating range may vary according
to environmental conditions at the time of
use.

SIZE

Handset : 171.5mm x 53mm x 45mm

(including antenna)

Charger : 102.6mm x 74.9mm x 52.7mm

WEIGHT

Handset : 134 grams

(excluding battery pack)

Charger : 234.8 grams

POWER REQUIREMENTS

Handset : 600mAh Ni-Cd Battery

Pack

Charger : 9 VDC @ 150mA

MEMORY

Speed Dial : 50 Memory locations;

32 digits per location.

CID : Alphanumeric Display

50 Memory locations

SPECIFICATIONS ARE TYPICAL
AND MAY CHANGE WITHOUT

NOTICE.

VTECH TELECOMMUNICATIONS LTD.
A member of THE VTECH GROUP OF COMPANIES.

Distributed in the U.S.A. by VTech Communications Inc.; Beaverton, Oregon.

20

Distributed in Canada by VTech Telecommunications Canada Ltd., Suite 200, 7671
Alderbridge Way, Richmond, B.C. V6X 1Z9.

Copyright 2003 for VTECH TELECOMMUNICATIONS LTD.
Printed in China

91-5370-10-00
ISSUE 0
