VTech 202ca User Manual
1
Electronic Emission Notices
Federal Communications Commission (FCC) Statement (00302C)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with instructions contained in this manual, may cause harmful interference
to radio and television communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- REORIENT OR RELOCA TE THE RECEIVING ANTENNA
- INCREASE THE SEP ARATION BETWEEN THE EQUIPMENT AND THE RECEIVER
- CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM
THA T OF THE RECEIVER
- CONSUL T THE DEALER OR AN EXPERIENCED AUDIO/TELEVISION TECHNICIAN
NOTE: Connecting this device to peripheral devices that do not comply with Class B
requirements, or using an unshielded peripheral data cable, could also result in
harmful interference to radio or television reception.
The user is cautioned that any changes or modifications not expressly approved
by the party responsible for compliance could void the user’s authority to operate
this equipment.
To ensure that the use of this product does not contribute to interference, it is
necessary to use shielded I/O cables.
Copyright
This manual is copyrighted with all rights reserved. No portion of this manual may be
copied or reproduced by any means.
While every precaution has been taken in the preparation of this manual, no responsibility
for errors or omissions is assumed. Neither is any liability assumed for damages resulting
from the use of the information contained herein.
Trademarks
All brand names, logos and registered trademarks mentioned are property of their
respective owners.
2
Technical Reference Booklet
Table of Contents
HARDWARE CONFIGURATION .................................................................... 3
Key Features ............................................................................................................... 3
Motherboard Layout .................................................................................................... 5
Jumper Settings ........................................................................................................... 6
CPU Speed Selection ............................................................................................ 6
CK1, CK4 - System Bus Frequency ..................................................................... 6
EDS1 - On Board AC97 Codec Sound ................................................................. 6
JBAT - CMOS Clear............................................................................................... 6
JVSB1 - Keyboard Power Select......................................................................... 6
Pin Assignment ..................................................................................................... 7
HARDWARE SETUP ...................................................................................... 8
T o Install DIMMs ........................................................................................................... 8
Installing a New Processor ......................................................................................... 9
To Install a Processor to ZIF Socket ........................................................................... 9
Connect the processor Fan Connector ...................................................................... 9
Setting the Processor Speed ...................................................................................... 9
BIOS SETUP .................................................................................................. 10
Starting Setup .............................................................................................................. 10
Main Menu.................................................................................................................... 1 1
Standard CMOS Features ........................................................................................... 12
Advanced BIOS Features ........................................................................................... 1 4
Advanced Chipset Features ....................................................................................... 14
Integrated Peripherals ................................................................................................. 14
Power Management Setup.......................................................................................... 14
PnP/PCI Configurations ................................................................................................ 14
PC Health Status.......................................................................................................... 14
Frequency/Voltage Control ......................................................................................... 14
Set Supervisor/User Password .................................................................................. 14
Flash Update Procedure ............................................................................................. 16
SOFTWARE INSTALLATION .......................................................................... 17
PC-Cillin 2000 Installation for WIN®9X ........................................................................ 17
Installing WIN®9X Driver for
Intel® 815/815E/815P/815EP Chipset Products .......................................................... 17
Sound Driver Installation ............................................................................................. 19
3
HARDWARE CONFIGURATION
Key Features :
Chipset
• Intel® 815E/815EP Chipset.
Processor
• Full support for the Intel® Pentium® III and Celeron® processors (FC-PGA package)
using PGA370 socket.
• Support for Intel® Celeron® processors (FC-PGA package) and
Intel® Pentium® III processors (100MHz/133MHz system bus).
• 66/100/133MHz System Bus Frequency.
VRM 8.4 (Voltage Regulator Modules) on Board
• Flexible motherboard design with on board VRM 8.4, easy to upgrade with
future Intel® Pentium® III and Celeron® (FC-PGA package) processors.
System Memory
• A total of three 168-pin DIMM sockets.
• Supports up to 3 double sided DIMMs at 100MHz system memory bus.
• Supports up to 2 double sided or 3 single sided DIMMs at 133MHz system memory
bus.
• Memory size up to 512M bytes.
• 32MB to 256MB using 16Mb/32Mb/64Mb/128Mb/256Mb technology.
• Support for x8, x16 DRAM device widths.
• Supports single & double sided DIMMs.
• Unbuffered, Non-ECC SDRAM only Supported.
System BIOS
• Firmware Hub with security feature.
• PnP, APM, ATAPI and Windows® 95/98/2000.
• Full support of ACPI & DMI.
• Auto detects and supports LBA harddisks with capacities over 8.4GB.
• Easy to upgrade BIOS by end-user.
On-board I/O
• On board two PCI fast IDE ports supporting up to 4 ATA, ATA2 , Ultra DMA33/66/
100 IDE HDDs, CD-ROMs, ZIP drives and LS-120 drives as boot drive.
• Support Bus Master IDE, Read transfers up to 100MB/s, Writes to 89MB/s.
• One ECP/EPP parallel port.
• Two 16550 Compatible UART serial ports.
• One floppy port support two FDDs of 360KB, 720KB, 1.2MB, 1.44MB and
2.88MB capacity.
• Four USB ports.
• PS/2 keyboard connector.
• PS/2 mouse is supported.
• Infrared (IrDA) is supported via a header.
Plug-and-Play
• Supports Plug and Play specification 1.1.
• Plug and Play for DOS, Windows® 3.X, Windows® 95/98 as well as
Windows® 2000.
• Fully steerable PCI interrupts.
Hardware Configuration
4
Technical Reference Booklet
On-board VGA (only for Intel® 815E chipset)
• 3D Hyper Pipelined Architecture.
• Full 2D H/W Acceleration.
• Motion Video Acceleration.
• Up to 1600x1200 in 8 bit Color at 85MHz Refresh.
• H/W Motion Compensation Assistance for S/W MPEG2 Decode.
• Software DVD at 30fps.
• Integrated 24-bit 230MHz RAMDAC.
Display Cache Interface multipexed on the AGP interface (only for
Intel® 815E chipset)
• 32-bit data interface.
• 133MHz SDRAM interface only.
• Flexible AGP In-Line Memory Module (AIMM) Implementation.
• Support for two 1Mx16,or one 2Mx32 on AIMM card.
• 4MB max addressable.
On-board AC97 Sound (optional)
• Integrated AC97 controller with standard AC97 Codec.
• Direct Sound and Sound Blaster compatible.
• Full-Duplex 16-bit record and play back.
• PnP and APM 1.2 support.
• Win® 95/98, NT drivers ready.
• Line-in, Line-out, Mic-in and MIDI/Game port.
Power Management
• Supports SMM, APM and ACPI.
• Break switch for instant suspend/resume on system operations.
• Energy star “Green PC” compliant.
• Hardware monitoring circuit is supported, provide voltage, temperature, fan
speed, etc. monitoring (optional).
• WOL (Wake-On-Lan) header support.
• External Modem Ring-in Wake-up support.
Expansion Slots
• 1 CNR slot (shares 1 PCI slot).
• 1 AGP slot.
• 4 PCI bus master slots - ver. 2.1 compliant (1 PCI shares with CNR slot).
CAUTION
Static electricity can harm delicate components of the motherboard. To prevent
damage caused by static electricity, discharge the static electricity from your
body before you touch any of the computers electronic components.
5
Hardware Configuration
Motherboard Layout
The following diagrams show the relative positions of the jumpers, connectors, major
components and memory banks on the motherboard.
NOTE
1) Be sure to check the cable orientation in order to match the colored strip to
the pin 1 end of the connector.
2) When you start up the system, please wait for 5 seconds after you power
on AC.
# The “VGA Connector” is installed for Intel® 815E chipset version only.
6
Technical Reference Booklet
Jumper Settings
This chapter explains how to configure the motherboard’s hardware. Before using your
computer, make sure all jumpers and DRAM modules are set correctly. Refer to this
chapter whenever in doubt.
CPU Speed Selection
In this motherboard, jumperless feature is implemented such that no jumper is required to
be set for different type of CPU installed.
Notice:
1. Be sure to save the CMOS setting when exit the CMOS.
2. The CPU is frequency multiplier locked, no CPU speed change will be seen
even if the frequency multiplier setting in CMOS setup is changed.
CK1, CK4 - System Bus Frequency
CK1 CK4 CPU Clock Speed
Open Open 133MHz
Open Close 100MHz
Close* Close* Auto*
EDS1 - On Board AC97 Codec Sound
EDS1 Function
2-3* AC97 Sound Enable*
1-2 AC97 Sound Disable
JBAT - CMOS Clear
JBAT Selection
1-2* Normal*
2-3 CMOS Clear
JVSB1 - Keyboard Power Select
JVSB1 Select
2-3* Powered by +5V*
1-2 Powered by +5V Standby
(Allows Keyboard Power On)
CK1JVSB1
1
JBA T
1
1
Close Open * = Default setting.
EDS1
CK4
1
1 1
1
1
1
