Vortexx Pressure washers User Manual

Owner’s Manual
Part# VXMANUAL Revised (12.13.13) V3
Owner’s Manual Owner’s Manual
Thanks for purchasing a Vortexx Pressure Washer. You have chosen the best in innovation and design in the pressure washer industry. Vortexx products are proudly designed and manufactured in Michigan with local and imported components. We exclusively use premium grade Honda Engines to power our Pressure Washers and we strive to use only quality grade materials and test all components for your satisfaction and safety. When operated and maintained according to the instructions in this manual, your Vortexx pressure washer will provide many years of dependable service.
Read this manual carefully and become familiar with your pressure washer. Know its applications, its limitations and any hazards involved. Vortex Industries Inc. reserves the right to change, alter or otherwise improve the product and this document at any time without notice. This manual is an important part of your pressure washer and should be kept with the unit. By reading and following the simple safety, operation, maintenance steps described in this manual, you will receive years of trouble free and safe cleaning excellence. The contents of this manual are based on current information at the time of publication. Vortex Industries Inc. reserves the right to make changes in price, color, materials,
equipment, specications or models at any time without notice. Please visit our website at www. vortexxpressurewashers.com for the most recent product updates or to nd a local authorized Vortexx
Pressure Washer dealer.
Once the unit has been un-crated, immediately write in the serial number of your unit in the space provided below. Follow the instructions completely and save them for future reference.
Product Identication: Please register at www.vortexxpressurewashers.com within 30 days of purchase. Note you may also detach the last page of this manual and follow the mailing instructions.
Serial #_________________________________________ Date Purchased:______________________________
Dealer Name______________________________________ Phone:____________________________________
Upon delivery, inspect your unit for damage and if something appears to be damaged, le a claim with the transportation company immediately. Be sure that all damaged parts are replaced and that the mechanical problems are corrected prior to operation of the unit. If you require service, contact Vortexx Pressure Washers at service@vortexindustriesinc.com. Please include the following information:
1. Model Number 2. Serial Number 3. Date and Place of Purchase
You may also nd a local authorized Vortexx dealer or service center on the web at www.vortexxpressurewashers.com. If you have specic questions or would like troubleshooting info about the Honda Engine or the pump on this product, please refer to the included engine and pump manuals.
Vortex Industries, Inc, 739 S. Mill, Plymouth, MI 48170 Copyright © 2013 Vortexx Industries, Inc. All rights reserved. No part of this material may be reproduced or transmitted in any form by any means without the express written permission of Vortex Industries, Inc.
TABLE OF CONTENTS
Operator Safety
Safety Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Product Description and Diagrams. . . . . . . . 4
How to Operate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
How to Maintain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
2
Understanding the Machine Safety Labels
The machine safety label shown below is placed on your machine to draw attention to potential safety hazards.
Hazard Symbols and Meanings
Safety Rules: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING) to alert you to hazards.
DANGER indicates a hazard which, if not avoided, will result in death or serious injury.
WARNING indicates a hazard which, if not avoided, could result in death or
serious injury.
CAUTION indicates a hazard which, if not avoided, might result in minor or moderate injury and or potential damage to property or equipment.
Warning Label
A warning label (Figure 1) is provided on your unit to inform you of potential safety hazards. If the label becomes damaged or illegible, replace it by contacting your local Vortexx dealer to obtain a new one or requesting one by sending an email to info@vortexindustriesinc.com.
gure 1
3
18
13
Right Side View
15
17
Owner’s Manual Owner’s Manual
19
2
Note: Replace red shipping oil plug with yellow and black vented cap provided.
16
Le Side View
14
12
3
6
7
8
1
9
5
4
1. Spray Tips Detergent, 0°, 15°, 25° and 40°: for various high pressure cleaning applications.
2. High Pressure Hose
3. Pressure Control Knob Varies pressure of high pressure spray.
4. Water Inlet Connection for garden hose with lter.
5. Quick Connect for High Pressure Hose.
6. Pump Develops high pressure.
7. Oil Level Indicator Level (included on some units) should be at halfway
8. Detergent Siphoning Tube/Filter Use to siphon pressure washer safe detergent into the low pressure stream.
9. Choke Lever Prepares a cold engine for starting.
10. Fuel Valve Used to turn fuel supply on and off to engine.
11. Recoil Starter Used for starting the engine manually.
12. Throttle Lever Sets engine in starting mode for recoil starter.
13. Engine Switch Set switch to “On” for recoil starting. Set switch to “Off” to stop a running engine.
14. Air Filter Protects engine by ltering dust and debris out of intake air.
15. Fuel Tank. Fill tank with regular unleaded fuel. Always leave room for fuel expansion.
16. Spray Gun and Extension with trigger lock.
17. Oil Dipstick
18. Wand Quick Connect Fitting
19. Tow and StowTM Gravity Handle
10
11
4
