GROUND LINK
Owner's Manual
DIGITAL MUSIC CORPORATION
Table of Contents
________________________________________________________
1. Introduction . . . . . . . . . . . . . . . . . . 3
1.1 Overview
1.2 Top Panel
1.3 Rear Panel
1.4 Unpacking
2. Using Ground Link with a Ground Control . . . 5
2.1 Quick Setup
2.2 Advanced Setup
3. Using Ground Link without a Ground Control . . 7
3.1 Single-Channel MIDI Foot Controllers
3.2 Multiple-Channel MIDI Foot Controllers
3.3 No MIDI Controller
4. Warranty . . . . . . . . . . . . . . . . . . 3
1. Introduction
______________________________________________________
1.1 Overview
The Ground Link provides direct on/off control of the eight audio loops in the
GCX Guitar Audio Switcher. Also, if used in conjunction with Ground
Control Version 2.00 or higher, each button can be assigned to any loop of up
to four GCXs, any MIDI controllers, or Sequencer Start/Stop.
2
The Ground Link can be used with Ground Control, other MIDI controllers, or
as a stand-alone controller for the GCX. The Ground Link can store 128
combinations of GCX loop settings for recall by any MIDI controller.
The Ground Link is powered by the GCX using a standard 5-pin MIDI cable.
1.2 Top Panel
• Foot Buttons - control GCX loops or user-defined functions.
• Status LEDs - show current status of each button function.
1.3 Rear Panel
• MIDI IN* - receives MIDI data from the Ground Control or other MIDI
controller.
• GCX OUT - sends MIDI data to the GCX, and echoes data from the MIDI
IN.
• STORE - stores combinations of GCX loop settings.
DIGITAL MUSIC CORPORATION
* Warning: The MIDI IN jack is not standard MIDI. To avoid damage, please refer
to Section 3, "Using Ground Link Without a Ground Control", before connecting this
jack to anything other than a Ground Control.
1.4 Unpacking
Your factory carton should contain:
1. This manual
2. Ground Link
3. Warranty card
Please fill out the enclosed warranty card and return it to Digital Music Corp.
By registering, you enable us to send you important information about related
products, updates and accessories.
3
DIGITAL MUSIC CORPORATION
2. Using Ground Link With a Ground Control
________________________________________________________
The Ground Link is an optional part of the Ground Control System, and is
most conveniently used with the Ground Control Programmable MIDI Foot
Controller. The Ground Link is connected between the Ground Control and
the GCX as follows with standard 5-pin MIDI cables.
1. Connect a MIDI cable from the MIDI Out of the Ground Control to the
MIDI In of the Ground Link.
4
2. Connect another MIDI cable from the GCX Out of the Ground Link to the
Pedal In of the GCX.
Because the GCX powers the Ground Control and Ground Link through the
MIDI cables, both cables must have all five pins wired. You do not need the
power adapter that comes with the Ground Control.
GCX loop settings are stored by Ground Control, therefore the STORE button
is not used.
2.1 Quick Setup
If you are already using a Ground Control and GCX, adding Ground Link to
the system will not affect their operation. Now with Ground Link, you have
direct control over individual loops of the GCX. To change the state of a GCX
loop (turn it ON or OFF), press the foot button on the Ground Link that
corresponds to that GCX loop (button 1 controls loop 1, button 2 controls loop
2, etc.). The LEDs on the Ground Link indicate whether loops are ON or OFF.
Using the Ground Link does not affect
the Ground Link to turn GCX loops on or off, and then select a Ground
DIGITAL MUSIC CORPORATION
the Ground Control presets. If you use
Control preset, the GCX will change to the loop settings defined in the preset.
The Ground Link LEDs will show the present loop status.
2.2 Advanced Setup
Note: The following advanced setup options require Ground Control version
2.00 or higher. If your Ground Control has version 1.00, contact the factory
for update information.
You can use Ground Control to redefine the functions of the Ground Link
buttons. Each Ground Link button can be used to control either:
• one loop on any of four GCXs
• any ON/OFF MIDI Controller
5
• Sequencer start/stop
Please refer to the Ground Control manual (or addendum) for instructions on
redefining Ground Link button functions.
DIGITAL MUSIC CORPORATION
3. Using Ground Link Without a Ground Control
________________________________________________________
With the Ground Link, you can control the GCX Guitar Audio Switcher from
any MIDI foot controller. You can also use the Ground Link as a stand-alone
controller for the GCX. However, because the GCX powers the Ground Link
6
through the MIDI cable, you must connect the Ground Link directly
GCX with a standard MIDI cable. Also, all five pins of the MIDI cable must be
wired. The MIDI OUT of your foot controller, if you are using one, is
connected to the MIDI IN of the Ground Link.
3.1 Single-Channel MIDI Foot Controllers
This section applies to foot controllers that send MIDI Program Change
messages on one MIDI channel only. After connecting your MIDI foot
controller, Ground Link, and GCX as described above, you can control the
GCX by pressing the Ground Link foot buttons to turn GCX loops on and off.
When you change programs with your MIDI foot controller, the Ground Link
responds by changing the GCX loop settings. Program the desired GCX loop
settings as follows:
to the
1. Select a program on your MIDI foot controller.
2. Use the Ground Link buttons to turn GCX loops on or off as desired.
3. Press and hold the STORE button on the Ground Link until the LEDs flash.
Now, when you select that program, the Ground Link and GCX will revert to
the loop settings you have just programmed.
3.2 Multiple-Channel MIDI Foot Controllers
DIGITAL MUSIC CORPORATION
When using MIDI foot controllers that send Program Change messages on
more than one MIDI Channel, the Ground Link and GCX will function as
described in section 3.1 above, but only repond to MIDI channel 1.
(Actually, until the Ground Link receives a Program Change message on MIDI
channel 1, it will respond to all Program Change messages.)
3.3 No MIDI Controller
The Ground Link can be used as a stand-alone controller for your GCX simply
7
by using the Ground Link buttons to control the GCX loops individually.
What you sacrifice by not using the Ground Link with a MIDI foot controller
is the ability to store preset combinations of GCX loop settings.
Connect a standard 5-pin MIDI cable from the GCX OUT of the Ground Link
to the PEDAL IN of the GCX. Because the GCX powers the Ground Link
through the MIDI cable, the cable must have all five pins wired.
To change the state of a GCX loop (turn it ON or OFF), press the foot button
on the Ground Link that corresponds to that GCX loop (button 1 controls loop
1, button 2 controls loop 2, etc.). The LEDs on the Ground Link indicate
whether loops are ON or OFF.
The STORE button on the rear panel of the Ground Link is non-functional
when used without a MIDI foot controller.
DIGITAL MUSIC CORPORATION
Warranty Information
________________________________________________________
Digital Music Corp. warrants this product against any defects that are due to faulty
material or workmanship for a period of five years from the date of original retail
purchase. This warranty does not include damage to the product resulting from
accident or misuse, and is valid only to the original retail purchaser.
If the product should become defective within the warranty period, Digital Music
Corp. will repair it or elect to replace it free of charge, provided it is returned freight
pre-paid to Digital Music Corp. with a valid Return Merchandise Authorization
number (RMA#).
This warranty shall not apply to any goods that have been repaired or altered by
anyone other than the manufacturer. There are no warranties which extend beyond the
terms described herein.
Should you experience any difficulty with this Digital Music product, contact us as
described below. If it is determined that the product must be returned to the factory
for repair, you will be issued an RMA and given shipping and packaging instructions.
How to Reach Us
You can reach us by the following:
Tel: 707 545 0600
Fax: 707 545 9777
Email: info@voodoolab.com
Website: www.voodoolab.com
Mail: 3165 Coffey Lane
Santa Rosa, CA 95403
8
Digital Music Corp., Ground Control, GCX, Ground Link, and Ground Control
System are trademarks of Digital Music Corporation.
Copyright 1998 by Digital Music Corp. All rights reserved. No part of this publication may
be reproduced or transmitted by any means or in any form, without the express prior consent
in writing from Digital Music Corp.
