SIGNATURE SERVER® CLASSIC MILK STATIONS
FEATURES
❑ Vollrath’s Signature Server
double-wall construction with a 300 Series stainless steel liner
❑ Reinforced stainless steel unibody construction provides extra
durability in a lightweight, mobile base
❑ Base is 18-gauge 300 Series stainless steel clad with black
laminate. Optional colors and finishes are also available.
❑ Three double-wall sliding doors
❑ Dispenser mechanism consists of two removable stainless steel
self-leveling dispenser platforms.
❑ Molded trays with 1" (2.5 cm) sides are provided to hold milk
cartons.
❑ Dispenser may be removed and standard 13" x 13"
(33 cm x 33 cm) crates stacked into the well.
❑ Top is one-piece 18-gauge stainless steel
❑ Optional 14 gauge work surface available
❑ Thermostatically controlled, field adjustable compressor with
Signature Server® Classic Milk Stations
R134A refrigerant
❑ Foamed-in-place polyurethane insulation
DESCRIPTION
Signature Server® Classic is the choice when functionality and
modular ease of use are your top priorities. Signature Server® Serving
Equipment is an industry standard, with updated features to better
serve the operator.
®
Note: Signature Server
cancelled or returned.
equipment orders cannot be
❑ Standard drain exits through bottom of base.
❑ Unit is NSF certified in accordance with the performance
requirements of NSF Standard 7, Section 6.
❑ Heavy-duty 4" (10 cm) swivel casters with brakes
❑ 8 ft. (2.4 m) cord
WARRANTY: All models shown come with Vollrath’s standard
warranty against defects in materials and workmanship. For full
warranty details, please refer to the Vollrath Equipment and
Smallwares Catalog.
MODELS AND OPTIONS
Base Options
Capacity Color (Black is standard)
Item
No
Width
37001 60" (152) 6/288 10/360 36681 36688 36694 Choose from:
37002 74" (188) 8/384 15/450 36682 36689 36695
* Does not use self-dispensers
Case
Carton*
Tra y
Carton
Matte
Laminate
Wood
Grain
Stainless
Steel
Breath Guards Lighting Accessories
Progressive,
Contemporary,
Traditional, Classic
Cafeteria, Classic
Economy Buffet,
®
Access
and Classic
Speed Serve. See
Breath Guard spec
sheets for selection
information.
Use only Vollrath accessories, including breath guards.
Vollrath is not responsible for the fit or installation of custom
made accessories and components. Custom accessories
and components may void agency listings.
®
Classic Milk Stations feature
Not Available Choose from:
Plate rests, cutting
boards, end shelf, tray
slides, false bottoms,
bag in box,
stationary legs. See
Accessories spec
sheet for selection
information.
Signature Server
®
Classic Milk Stations
The Vollrath Company, L.L.C.
Due to continued product improvement, please consult
www.vollrathco.com for current product specifications.
Approvals Date
SIGNATURE SERVER® CLASSIC MILK STATIONS
www.vollrathco.com
The Vollrath Company, L.L.C.
1236 North 18th Street
Sheboygan, WI 53081-3201 U.S.A.
Customer Service: 800.628.0830
Canada Customer Service: 800.695.8560
Main Fax: 800.752.5620 or 920.459.6573
Technical Services: 800.628.0832
Technical Services Fax: 920.459.5462
Top Vi ew
End View
28
(71)
Clearance between base
and floor 5¼ (13.3)
Operator Side View
A
3
4
(
8
6
.
4
)
Power Supply Cord/Plug
5-15R
120V
DIMENSIONS Dimensions shown in inches (cm).
Classic Milk Stations
®
Signature Server
SPECIFICATIONS
Item
No
37001
37002 74" (188) 120 ¼ 4.9 5-15P
(A)
Width
60" (152)
Compressor
Volts
120 ¼ 4.9 5-15P
(HP)
The Vollrath Company, L.L.C.
Total
Amps
Receptacles
Plug
©
2012 The Vollrath Company L.L.C. Form Number L35539 5/12
Printed in USA
