Vodafone 533 User Manual

English

Congratulations! you have just purchased this phone from Vodafone. It is recommended that you read this handbook carefully in order to use your phone eff iciently and in the best conditions.

Your phone can be used internationally on different networks (GSM 900 MHz, DCS 1800 MHz and DCS 1900 MHz) depending on the roaming arrangements with your network provider.

This phone is approved to meet European standards.

WARNING

Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it in the event of y our phone being stolen, in order to prevent it from being used, even with a different SIM card. In order to display the IMEI on your phone's screen, type: *#06#.

SAGEM is a trademark of Sagem Mobiles, SAFRAN group. T9® Text Input is a trademark of ©Tegic Communications Inc. Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The WAP navigator and some message software (i-mode™) are under licence Openwave. The WAP navigator and the software included are the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of these software programs. The Bluetooth

word mark and logos are owned by the

Bluetooth® SIG, Inc. Bluetooth® QDID (Qualified Design ID):

B013487. microSD™ is a trade mark of SD Card Association. Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France. Windows is a trademark of Microsoft Corporation.

Contents

Health and Safety information .............................. 7

SAR...................................................................... 7

Advice for limiting exposure to radiofre quency (RF)

fields..................................................................... 8

Safety................................................................... 8

Environment....................................................... 11

Charging the battery .......................................... 11

Menus.................................................................... 14

Description ........................................................... 16

Installing th e SIM card and the battery .............. 19

Inserting the memory card................................. 20

Using the memory card...................................... 20

Navigation principles........................................... 21

Idle scree n ............ ............. ... .. .............................. 2 2

Icons .................................................................. 22

Activating your phone ......................................... 23

Information on the Vodafone SIM card.............. 23

Getting started ................................................... 23

PIN number........................................................ 23

Setting time and date......................................... 24

Network.............................................................. 25

Easy Search for a menu or a contact name....... 25

First call.............................................................. 25

Receiving a call.................................................. 26

Call log............................................................... 27

Increase the efficiency of your phone................ 27

Switching off....................................................... 27

Contacts................................................................ 28

Using the phonebook.........................................28

Storing a new con ta ct ........ .. ................ .............. 28

Calling a contact ................................................ 29

Contents

Contact options.................................................. 29

Groups............................................................... 32

Messages.............................................................. 33

Creating a message........................................... 33

Receiving messages.......................................... 35

Inbox.................................................................. 36

Drafts ................................................................. 36

Sent message s............................ ... ... .. .............. 36

Outbox ............................................................... 37

Vodafone Mail.................................................... 37

Call Voice Mail................... ................ ............... . 37

Live! Studio........................................................ 37

Templates.......................................................... 37

Local information ............................................... 37

Advanced........................................................... 37

Camera.................................................................. 39

Taking and saving a photo................................. 39

Taking a video . ............................ ...................... 41

My Files................................................................. 42

Vodafone live!....................................................... 43

Entertainment....................................................... 44

Music player....................................................... 44

FM Radio ........................................................... 45

Messenger......................................................... 46

Games ............................................................... 46

Download Applications .......... ............................ 46

Organiser & Tools........ ... .. ................ ................ .. . 47

Services............................................................. 47

Alarm ................................................................. 47

Stopwatch.......................................................... 47

Timer.................................................................. 47

Calendar............................................................ 47

ToDo.................................................................. 48

Calculator........................................................... 49

Unit Converter.................................................... 49

Contents 5

Settings................................................................. 50

Phone................................................................. 50

Connectivity....................................................... 54

Network.............................................................. 56

Memory.............................................................. 58

Multimedia.......................................................... 58

Calls................................................................... 59

Messaging.......................................................... 61

Security.............................................................. 61

Technical features................................................ 64

Warranty................................................................ 66

End User Licence Agreement (EULA), for the

software ................................................................ 71

Java™ .................................................................... 78

Troubleshooting................................................... 83

Customer care...................................................... 87

Index...................................................................... 88

Contents

Health and Safety information

SAR

THIS MODEL MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits f or exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRP and include safety margins designed to ensure the protection of all persons, regardless of age and health.

The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when tested at the ear was a range of functions, t hey c an be used in other positions, such as on the body as described in this user guide (**).

As SAR is measured utilizing the devices highest transmitting power the actual SAR of this dev ice while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum level required to reach the network.

The World Health Organization has stated that present scientific information does not indicate the need for any special precautions for the use of mobile devices. They note that if you want to reduce your exposure then you can do so by limiting the length of calls or using a 'hands-free' device to keep the mobile phone away from the head and body. Additional Information can be found on the websites of the World Health Organization (http://www.who.int/emf

W/kg (*). As mobile devices offer

)

(*) The tests are carried out in accordance with international

guidelines for testing.

(**) Please see the Distance of operation section about body

worn operation, on page 10.

Health and Safety information 7

Advice for limiting exposure to radiofrequenc y (RF) field s

For individuals concerned about limiting their exposure to RF fields, the World Health Organization (WHO) provides the following advice:

Precautionary measures: Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If individuals are concerned, they might choose to limit their own or their children’s RF exposure by limiting t he length of calls, or using "hands-free" devices to keep mobile phones away from the head and body.

Further information on this subject can be obtained from the WHO home page http://www.who.int/peh-emf 193: June 2000.

WHO Fact sheet

Safety

Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use.

As a general rule, always switch off your phone wherever the use of a phone is prohibited.

Use of your phone is subject to safety measures designed to protect users and their environment.

Do not use your phone in damp areas (bathroom, swimming pool…). Protect it from liquids and other moisture.

Do not expose your phone to extreme temperatures lower than

- 10°C and higher than + 55°C. The physicochemical processes created by chargers impose

temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures.

Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested).

Health and Safety information

Electrical safety

Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line volt age must be exactly the one indicated on the charger’s serial plate.

Aircraft safety

When travelling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs. This mobile phone is considered as an electronic device, with no radio functions, once you activate the flight mode. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecut ed or banned from using cellular networks in the future if you do not abide by these regulations.

Explosive materials

Please comply with warning signs at petrol stations asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way.

Electronic equipment

To avoid the risk of demagnetisation, do not leave electronic devices close to your phone for long periods.

Electronic medical equipment

Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 15 cm be maintained between the phone and an implant. Your doctor or the manufacturers of such equipment will be able to give you any advice you may need in this area.

Hospitals

Always make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff.

Health and Safety information 9

Road safety

Do not use your phone when driving. In order to give your f ull attention to driving, stop and park safely before making a call. You must comply with any current legislation.

Distance of operation

This phone model has been tested and meets radiofrequency exposure guidelines when used as follows:

- against the ear: make or receive a phone call and hold the

phone as you would a wireline telephone,

- body worn: when transmitting, place the phone in a carry

accessory that contains no metal and positions the phone a minimum of 1.5 cm form your body. Use of other accessories may not ensure compliance with radiofrequency exposure guidelines. If you do not use a body worn accessory and are not holding the phone at the ear, position the phone a minimum of 1.5 cm from your body,

- data operation: when using a data feature, position the

phone a minimum of 1.5 cm from your body for the whole duration of the data transmission.

Accessories

We advise you the use of SAGEM brand accessories for optimal operation of your phone and accessories.

Using the music player

This product has been designed to comply with prevailing legislation regarding the limitation of maximum audio volume levels.

- Prolonged listening at high volume with a headset

or earphones can damage your hearing.

- If you experience ringing in your ears, reduce the

volume or stop using the product.

- Only use the headset or earphones supplied with

the product or else use compatible accessories.

Health and Safety information

Environment

Packaging

To facilitate the recycling of packaging materials, please obey the sorting rules instituted locally for this type of waste.

Batteries

Spent batteries must be deposited at the designated collection points.

The produc t

The crossed-out waste bin mark affixed t o the product (including its accessories) means that it belongs t o the family of electrical and electronic equipment.

To promote the recycling and recovery of waste electrical and electronic equipment (WEEE) and at the same time safeguard the environment, European regulations require you to comply with the selective waste sorting rules instituted locally for this type of waste.

Charging the battery

Your phone is powered by a rechargeable battery. A new battery must be charged for 4 hours at least before being used for the fi rst time. It reaches its optimum capacity after a few cycles of use.

When your battery has been discharged, the phone displays the state (empty battery icon flashes). In this case recharge your battery for at least 15 minutes before making any calls in order not to be cut off in the

Note:

Each SAGEM telephone has a specific charger with the appropriate connectors for the telephone with which it is sold. Using any other charger, or using the charger with any dev ice other than the telephone will lead to an exclusion of warranty.

Health and Safety information 11

middle of a call.

To recharge the battery:

- Remove the connector protective cover.

- Plug the end of the cable into the phone connector.

- Connect the charger to a socket

The phone is then charging up. The battery icon scrolls up and down to indicate that it is charging. When the battery is fully charged, the charging stops on its own. Disconnect the cable.

When charging, the battery may warm up, this is normal. When you recharge the battery, make sure that the mains

socket where you plug in the charger is easy to access. When you charge the battery, the socket on which the c harger

is plugged must be easily accessible..

WARNING

If the battery has entirely discharged, the phone cannot start. Plug the phone into the charger. The phone will switch on after a f ew minutes of charge. You can us e the phone again when the

Start

option is displayed on the

screen.

Health and Safety information

WARNING

There is danger of explosion if the battery is placed in an incorrect way or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to open the battery casing. Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue. The use of other types of chargers or batteries may be dangerous or invalidate the warranty. Used batteries must be disposed of in the appropriate places. We recommend you to take the battery out if you plan not to use the phone for extended periods. You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery. The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power supply plug, etc). If the battery has entirely discharged, the phone cannot start. Plug the phone to the charger. The phone will switch on after a few minutes of charge. You can use t he phone again when the

Start

option is displayed on the screen.

Health and Safety information 13

Menus

Entertainment

Music player FM Radio Messenger Games Download

Applications

Vodafone live!

Vodafone live! Go to URL Bookmarks Saved pages

Calls Camera Messages

Create Message Inbox Drafts Sent Messages Outbox Vodafone Mail (*) Call Voice Mail Live! Studio (*)

History Vodafone Mail (*) What’s New? Live! Studio (*) Music Games Pictures News Sport

(*) Service depending on the operator

Templates Local info. Advanced

My Files

Menus

Organiser &

Tools

Services Alarm Stopwatch Timer Calendar Todo Calculator Unit Converter

Contacts Settings

Phone Connectivity Memory Multimedia Calls Messaging Security

Menus 15

Description

Right key

- In idle screen: shortcut to

several functions.

- In menus: access to the

selection shown on screen in the tab

Stop key

- Short press: switch on

- Long press

: switch off

- In call context: reject a call -

hang up

- In menus: return to idle scr ee n

# key

Microphone

WARNING:

you are not obstructing the microphone in call context

Ensure that

When composing a message

- Long press: a shortcut to

change the T9 dictionnary

- Short press

: inserts symbols

- In idle screen: Long press: silent mode

- In call reception mode: Short press

: stops ring tone

- In ring tone setting mode: act i vate/deactivate ring tone

- Stops sound in video or message playing, or in a game

Description

The

navigator

allows you:

- to navigate in the various functions pressing the relevant

direction (up, down, right, left),

- to confirm your selection pressing the central part (

In idle screen, pressing Pressing

followed by one of the nine keys of the keypad,

goes to the main menu.

you can display a menu directly.

Note:

the phone menus being numbered, you can directly

access a menu typing the various numbers.

Left key

- In idle screen: shortcut to

several functions

- In menus: access to the

selection shown on screen in the tab

St art key

- In dialling/phonebook/call log

context: call - receiving a call

- Short press

: Activate/Deactivate hands-free mode during a call (

WARNING

do not use the phone in hands-free mode near to your ear, or you may suffer hearing loss)

- In idle screen: displays the call

log

* key

When composing a message

- Short press: upper case/lower

case/figures

- Long press

: switches from one

input mode to another (ABC/T9)

Description 17

Camera

From idle screen

- change the ringtones

volume

From camera preview screen

- change the zoom level

From music player screen

- Short press: change the

volume

- Long press:

change the

music track

During call

- change the volume

From idle screen

- Long press: launch the

camera preview

During camera preview screen

- Short press: takes the


During incoming call

Connector for charger, hands free kit and USB cable.

Note:

into the packaging box.

- stops the ring tone

covers are available

Alphanumeric keypad

A long press on the key 1 calls voicemail (if the number has been stored in

Voicemail

2 to 9

A long press on one of the 2 to 9 keys immediately displays the phonebook on the contact corresponding to the letters on the key.

Settings/Calls/Set

menu)

Description

Installing the SIM card an d the bat t er y

Ensure that the phone is switch ed off and the charger disconnected.

1 Open the back cover using the notch located at the bottom of

the phone. Take out battery if already installed.

2 Open the metallic lock, slide the SIM card into the card holder

with fold face down and cut corner, close the metallic lock.

3 Place the battery by positioning first the bottom of it, as

shown on the battery.

4 Place the back cover, clicking in first the upper part then the

lower part.

Description 19

WARNING

Depending on the model, network configuration and associated subscription cards, certain functions may not be available. Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card. In order to display the IMEI on your phone's screen, type: *#06#.

Inserting the memory card

- Remove the back cover.

- Insert the memory card pushing it

until it into place.

- Replace the back cover.

To remove the card, first make sure that no application is accessing the card, then slightly push the top edge of the card to release it and pull it out of the slot.

Using the memory card

The memory card is very fragile. Take care when you insert or remove the memory card.

Some memory cards must be formatted with a PC before first use with the phone.

Description

Navigation principles

These basic principles provide a great intuitiveness to your phone.

Validate Cancel

The thumbnails at the bottom of the screen refer to the

Right keys

by pressing the

Left key

or the navigator.

Right key

Left

and

From the idle mode, pressing the navigator display s the icons of the main menus.

When pressing the navigator followed by a figure, you can display a menu directly. For instance, pressing the navigator then

the the The

8 displays the Phonebook. Left key Right key

is used to go from a menu to a sub-menu.

is used to go from a sub-menu to a menu.

key (press briefly) is used to go back to the idle

screen (current function is abandoned).

Navigation principles 21

Idle screen

The idle screen contains the following information:

Icons

1 - The title bar icons:

Battery (if it flashes red, the battery must be charged immediately)

Silent mode (the ringtone is off) Only emergency call is possible Roaming

Signal strength level (between 0 and 5 bars)

Message received (read your message), flashing:

memory full (delete some messages)

Grey: GPRS unavailable

Blue: GPRS connection

1 2

Vodafone

Flashing: GPRS connection on hand

WAP connection

Gray: bluetooth disconnect; Blue: bluetooth connect

2 - Network provider 3 - Date and time, in digital or analog mode 4 - Thumbnail centred on bottom line:

The main " Menu " thumbnail shows that the menus can be accessed by pressing

. Information messages on calls, messages or network messages received may also be displayed. They can be deleted by pressing the

key briefly.

Idle screen

Activating your phone

Information on the Vodafone SIM card

To use your phone, you need Vodafone SIM card. It contains personal information that you can modify:

- Secret codes (PIN(s): Personal

Identification Numbers), these codes allow you to protect access to your SIM card and phone

- Phonebook

- Messages

- How special services work.

WARNING

This card must be handled and stored with care to avoid being damaged. If you should lose y our SIM card, contact Vodafone immediately. Please keep your SIM card out of reach of young children.

Getting started

You are now ready to use your phone for the first time. Switch on the phone by pressing the key. Enter your PIN code then the date and time.

PIN number

This is your SIM's secret code. If access to the Vodafone SIM card is protected, the device

prompts you to enter the PIN: Enter the code

between 4 and 8 digits given to you when the SIM card was issued. These digits do not appear on the screen for security reasons.

Press [

Activating your phone 23

] or the navigator to validate.

If your phone indicates that the SIM is missing, press the

key to switch off your phone and check that the SIM card

is correctly installed.

WARNING

If a wrong PIN is entered three times in succ ession, your SIM card is blocked. You must then:

- Enter the PUK (Personal Unblocking Key) code

provided by your operator, and validate.

- Enter your PIN and validate.

- Enter your PIN again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the Vodafone SIM card is permanently locked. You must then contact your operator to obtain a new card.

Setting time and date

When you use your phone for the first time, you need to set the date and time. In due course, when the battery is completely discharged, or if it has been removed, you will be prompted systematically to confirm date and time.

Setting the date

Set the date by entering it directly in numerical form or by using the navigator to increase or decrease the default values.

Use the navigator to access the next (or last) data input field. Once the date is correct, press the

Left key

to validate.

Setting the time

Same procedure as for setting the date.

Activating your phone

Network

The phone will now search for a network on which it can make calls. If it finds one, it displays t he name of the network on the screen. You are then ready to send or receive a call.

If the network’s name appears, calls are possible on your operator's network.

If the letter possible on a roaming networkprovider.

and a network name are displayed, calls are

If the letter

is displayed without any network name, only the emergency services are accessible (ambulance, police, fire brigade). If the network icon flashes, the phone is in permanent search mode. There is no network available. The received signal strength indicator displays the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

Easy Search for a menu or a contact name

From the idle screen, use the alphanumeric keypad keys to enter the first several letters of the menu or name that you want to find into the phonebook.

Example

«Networks» is displayed on the idle screen. To find contact «Mike», press 6 and 4; the name of the contact

: press 6 and 3, the menu of «Messages» and

is displayed on the idle screen. Select the correct menu or contact with the navigator up and down, and then enter the menu or display the contact detail with the OK key.

First call

Dial the number you want to call. Press the key. During the call, the call in progress icon f lashes on s creen and

tones may indicate the establishment of the call. While a call is connecting, the phone icon is flashing.

Activating your phone 25

You can adjust the sound level (volume) by pressing the side

volume keys. At the end of the conversation press the key to hang up.

Calling voicemail

In the idle screen, press and hold down the 1 key.

International call

Press (hold down) 0 to display « + », then dial the country code without waiting for the dial tone, then the number of the called party.

Emergency services

Depending on the operators you can obtain the emergency service with or without a SIM card. It is enough to be in an area served by a network. To obtain the international emergency service, dial

112

then press the key.

Receiving a call

When you receive a call, the number of your corres pondent is displayed when it is presented by the network.

Press the key or the

Left key

To refuse the call, press the key or the To stop the ring tone, without refusing the call, press the camera

key on the right side.

Hands-free mode

To change to hands-free mode during a call,

- short press on the key then press [

activation of the amplified mode.

to answer, and speak.

Right key

Yes

] to confirm

- press [

Options

confirm.

WARNING:

in this mode do not position the phone near

your ear.

] and select

Amplified mode ON

Activating your phone

then

When a call is on hand, pressing [

access to different functions.

Options

] allows you to have

Pressing [ temporarily when you do not want that your correspondent listens when you want to speak to other people.

Mute on

] allows you to switch off the sound

Call log

From the idle screen, press the key to access the call log divided into five lists that you can display by the navigator: all calls, dialed calls, received calls, missed calls and call manager.

Various options are proposed: store a number in your phonebook, call, send a message, etc.

You can also make a call to a number by pressing the

key.

Increase the efficiency of your phone

- Don't press the keys when not necessary: each keypress

activates the backlight, and uses power.

- Don't obstruct the antenna with your fingers.

Activation of the Bluetooth® function reduces the life time of the phone. We recommend you deactivate it when not in use.

Switching off

Press the key (long press). The end message is displayed. The phone switches off.

Activating your phone 27

Contacts

The phonebook allows you to store numbers that you call regularly. These numbers can be stored on the SIM card or on the phone.

To store a contact on the phone memory, the following fields can be filled: last name, first name, numbers, emails, URL, address, company, birthday, comments, ringtone, photo.

To store a contact on the SIM card, only the last name and number fields can be filled.

Using the phonebook

Enter the already get some (otherwise, go to

When a contact is selected, an icon is displayed in the title bar.

You can search for a contact quickly by typing the first letters (up to three). You can display it by pressing the navigator.

Contacts

contact stored in the SIM card contact stored in the phone contact stored in the Fixed Dialling. See

Settings/Security/PIN2 Advanced/Confidentiality/Fixed dialling

more details about this activation.

menu, the contacts list is displayed if you

Storing a new contact

and

Settings/Security

menus for

Storing a new contact

There are two ways to store a contact:

1) by selecting

Contacts/[Options

] then

Add phone contact

Add SIM contact

Contacts/Add contact/Phone, SIM card

Vodafone 533 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
