Secure Configuration
vRealize Operations Manager 6.4
Secure Configuration
You can find the most up-to-date technical documentation on the VMware Web site at:
hps://docs.vmware.com/
The VMware Web site also provides the latest product updates.
If you have comments about this documentation, submit your feedback to:
docfeedback@vmware.com
Copyright © 2017 VMware, Inc. All rights reserved. Copyright and trademark information.
VMware, Inc.
3401 Hillview Ave.
Palo Alto, CA 94304
www.vmware.com
2 VMware, Inc.
Contents
Secure Conguration 5
vRealize Operations Manager Security Posture 7
1
Secure Deployment of vRealize Operations Manager 9
2
Verify the Integrity of Installation Media 9
Hardening the Deployed Software Infrastructure 9
Reviewing Installed and Unsupported Software 10
VMware Security Advisories and Patches 11
Secure Conguration of vRealize Operations Manager 13
3
Secure the vRealize Operations Manager Console 14
Change the Root Password 14
Managing Secure Shell, Administrative Accounts, and Console Access 15
Set Boot Loader Authentication 19
Single-User or Maintenance Mode Authentication 20
Monitor Minimal Necessary User Accounts 20
Monitor Minimal Necessary Groups 20
Reseing the vRealize Operations Manager Administrator Password (Linux) 21
Congure NTP on VMware Appliances 22
Disable the TCP Timestamp Response on Linux 22
Enable FIPS 140-2 Mode 22
TLS for Data in Transit 23
Application Resources That Must be Protected 26
Congure PostgreSQL Client Authentication 27
Apache Conguration 28
Disable Conguration Modes 29
Managing Nonessential Software Components 29
Windows Installed Deployment 32
Linux Installed Deployment 34
Endpoint Operations Management Agent 36
Additional Secure Conguration Activities 41
VMware, Inc.
Network Security and Secure Communication 43
4
Conguring Network Seings for Virtual Application Installation 43
Conguring Ports and Protocols 51
Auditing and Logging on your vRealize Operations Manager System 53
5
Securing the Remote Logging Server 53
Use an Authorized NTP Server 53
Client Browser Considerations 53
3
Secure Configuration
Index 55
4 VMware, Inc.
Secure Configuration
The documentation for Secure Conguration is intended to serve as a secure baseline for the deployment of
vRealize Operations Manager. Refer to this document when you are using system-monitoring tools to
ensure that the secure baseline conguration is monitored and maintained for any unexpected changes on
an ongoing basis.
Hardening activities that are not already set by default can be carried out manually.
Intended Audience
This information is intended for administrators of vRealize Operations Manager.
VMware Technical Publications Glossary
VMware Technical Publications provides a glossary of terms that might be unfamiliar to you. For denitions
of terms as they are used in VMware technical documentation, go to
hp://www.vmware.com/support/pubs.
VMware, Inc.
5
Secure Configuration
6 VMware, Inc.
vRealize Operations Manager
Security Posture 1
The security posture of vRealize Operations Manager assumes a complete secure environment based on
system and network conguration, organizational security policies, and best practices. It is important that
you perform the hardening activities according to your organization's security policies and best practices.
The document is broken down into the following sections:
Secure Deployment
n
Secure Conguration
n
Network Security
n
Communication
n
The guide details the installation of the Virtual Application. However, the following deployment types are
also discussed:
“Linux Installed Deployment,” on page 34
n
“Windows Installed Deployment,” on page 32
n
To ensure that your system is securely hardened, review the recommendations and assess them against your
organization's security policies and risk exposure.
VMware, Inc.
7
Secure Configuration
8 VMware, Inc.
Secure Deployment of
vRealize Operations Manager 2
You must verify the integrity of the installation media before you install the product to ensure authenticity
of the downloaded les.
This chapter includes the following topics:
“Verify the Integrity of Installation Media,” on page 9
n
“Hardening the Deployed Software Infrastructure,” on page 9
n
“Reviewing Installed and Unsupported Software,” on page 10
n
“VMware Security Advisories and Patches,” on page 11
n
Verify the Integrity of Installation Media
After you download the media, use the MD5/SHA1 sum value to verify the integrity of the download.
Always verify the SHA1 hash after you download an ISO, oine bundle, or patch to ensure the integrity
and authenticity of the downloaded les. If you obtain physical media from VMware and the security seal is
broken, return the software to VMware for a replacement.
Procedure
Compare the MD5/SHA1 hash output with the value posted on the VMware Web site.
u
SHA1 or MD5 hash should match.
N The vRealize Operations Manager 6.x-x.pak les are signed by the VMware software
publishing certicate. vRealize Operations Manager validates the signature of the PAK le before
installation.
Hardening the Deployed Software Infrastructure
As part of your hardening process, you must harden the deployed software infrastructure that supports
your VMware system.
Before you harden your VMware system, review and address security deciencies in your supporting
software infrastructure to create a completely hardened and secure environment. Software infrastructure
elements to consider include operating system components, supporting software, and database software.
Address security concerns in these and other components according to the manufacturer's
recommendations and other relevant security protocols.
VMware, Inc.
9
Secure Configuration
Hardening the VMware vSphere Environment
vRealize Operations Manager relies on a secure VMware vSphere environment to achieve the greatest
benets and a secured infrastructure.
Assess the VMware vSphere environment and verify that the appropriate level of vSphere hardening
guidance is enforced and maintained.
For more guidance about hardening, see hp://www.vmware.com/security/hardening-guides.html.
Hardening for Linux Installation
Review the recommendations set out in the appropriate Linux hardening and secure best practice
guidelines, and ensure that your Linux hosts are appropriately hardened. If you do not follow the hardening
recommendations, the system might be exposed to known security vulnerabilities from insecure
components on Linux releases.
vRealize Operations Manager is supported for installation on Red Hat Enterprise Linux (RHEL) 6, starting
with version 6.5.
Hardening for Windows Installation
Review the recommendations set out in the appropriate Windows hardening and secure best practice
guidelines, and ensure that your Windows Server host is appropriately hardened. If you do not follow the
hardening recommendations, the system might be exposed to known security vulnerabilities from insecure
components on Windows releases.
Contact your Microsoft vendor for hardening practices of Microsoft products.
Reviewing Installed and Unsupported Software
Vulnerabilities in unused software might increase the risk of unauthorized system access and disruption of
availability. Review the software that is installed on VMware host machines and evaluate its use.
Do not install software that is not required for the secure operation of the system on any of the
vRealize Operations Manager node hosts. Uninstall unused or nonessential software.
Installing unsupported, untested, or unapproved software on infrastructure products such as
vRealize Operations Manager is a threat to the infrastructure.
To minimize the threat to the infrastructure, do not install or use any third-party software that is not
supported by VMware on VMware supplied hosts.
Assess your vRealize Operations Manager deployment and inventory of installed products to verify that no
unsupported software is installed.
For more information about the support policies for third-party products, see the VMware support at
hps://www.vmware.com/support/policies/thirdparty.html.
Verify Third-Party Software
Do not use third-party software that VMware does not support. Verify that all third-party software is
securely congured and patched in accordance with third-party vendor guidance.
Inauthentic, insecure, or unpatched vulnerabilities of third-party software installed on VMware host
machines might put the system at risk of unauthorized access and disruption of availability. All software
that VMware does not supply must be appropriately secured and patched.
If you must use third-party software that VMware does not support, consult the third-party vendor for
secure conguration and patching requirements.
10 VMware, Inc.
VMware Security Advisories and Patches
VMware occasionally releases security advisories for products. Being aware of these advisories can ensure
that you have the safest underlying product and that the product is not vulnerable to known threats.
Assess the vRealize Operations Manager installation, patching, and upgrade history and verify that the
released VMware Security Advisories are followed and enforced.
It is recommended that you always remain on the most recent vRealize Operations Manager release, as this
will include the most recent security xes also.
For more information about the current VMware security advisories, see
hp://www.vmware.com/security/advisories/.
Chapter 2 Secure Deployment of vRealize Operations Manager
VMware, Inc. 11
Secure Configuration
12 VMware, Inc.
Secure Configuration of
vRealize Operations Manager 3
As a security best practice, you must secure the vRealize Operations Manager console and manage Secure
Shell (SSH), administrative accounts, and console access. Ensure that your system is deployed with secure
transmission channels.
You must also follow certain security best practices for running Endpoint Operations Management agents.
This chapter includes the following topics:
“Secure the vRealize Operations Manager Console,” on page 14
n
“Change the Root Password,” on page 14
n
“Managing Secure Shell, Administrative Accounts, and Console Access,” on page 15
n
“Set Boot Loader Authentication,” on page 19
n
“Single-User or Maintenance Mode Authentication,” on page 20
n
“Monitor Minimal Necessary User Accounts,” on page 20
n
“Monitor Minimal Necessary Groups,” on page 20
n
“Reseing the vRealize Operations Manager Administrator Password (Linux),” on page 21
n
“Congure NTP on VMware Appliances,” on page 22
n
“Disable the TCP Timestamp Response on Linux,” on page 22
n
“Enable FIPS 140-2 Mode,” on page 22
n
“TLS for Data in Transit,” on page 23
n
“Application Resources That Must be Protected,” on page 26
n
“Congure PostgreSQL Client Authentication,” on page 27
n
“Apache Conguration,” on page 28
n
“Disable Conguration Modes,” on page 29
n
“Managing Nonessential Software Components,” on page 29
n
“Windows Installed Deployment,” on page 32
n
“Linux Installed Deployment,” on page 34
n
“Endpoint Operations Management Agent,” on page 36
n
“Additional Secure Conguration Activities,” on page 41
n
VMware, Inc.
13
Secure Configuration
Secure the vRealize Operations Manager Console
After you install vRealize Operations Manager, you must log in for the rst time and secure the console of
each node in the cluster.
Prerequisites
Install vRealize Operations Manager.
Procedure
1 Locate the node console in vCenter or by direct access.
In vCenter, press Alt+F1 to access the login prompt. For security reasons, vRealize Operations Manager
remote terminal sessions are disabled by default.
2 Log in as root.
vRealize Operations Manager does not allow you to access the command prompt until you create a root
password.
3 At the password prompt, press Enter.
4 At the old password prompt, press Enter.
5 At the prompt for a new password, enter the root password that you want and note it for future
reference.
6 Reenter the root password.
7 Log out of the console.
Change the Root Password
You can change the root password for any vRealize Operations Manager master or data node at any time by
using the console.
The root user bypasses the pam_cracklib module password complexity check, which is found in
etc/pam.d/common-password. All hardened appliances enable enforce_for_root for the pw_history module,
found in the etc/pam.d/common-password le. The system remembers the last ve passwords by default. Old
passwords are stored for each user in the /etc/security/opasswd le.
Prerequisites
Verify that the root password for the appliance meets your organization’s corporate password complexity
requirements. If the account password starts with $6$, it uses a sha512 hash. This is the standard hash for all
hardened appliances.
Procedure
1 Run the # passwd command at the root shell of the appliance.
2 To verify the hash of the root password, log in as root and run the # more /etc/shadow command.
The hash information appears.
3 If the root password does not contain a sha512 hash, run the passwd command to change it.
14 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Manage Password Expiry
Congure all account password expirations in accordance with your organization's security policies.
By default, all hardened VMware appliances use a 60-day password expiry. On most hardened appliances,
the root account is set to a 365-day password expiry. As a best practice, verify that the expiry on all accounts
meets security and operation requirements standards.
If the root password expires, you cannot reinstate it. You must implement site-specic policies to prevent
administrative and root passwords from expiring.
Procedure
1 Log in to your virtual appliance machines as root and run the # more /etc/shadow command to verify
the password expiry on all accounts.
2 To modify the expiry of the root account, run the # passwd -x 365 root command.
In this command, 365 species the number of days until password expiry. Use the same command to
modify any user, substituting the specic account for root and replacing the number of days to meet
the expiry standards of the organization.
By default, the root password is set for 365 days.
Managing Secure Shell, Administrative Accounts, and Console Access
For remote connections, all hardened appliances include the Secure Shell (SSH) protocol. SSH is disabled by
default on the hardened appliance.
SSH is an interactive command-line environment that supports remote connections to a
vRealize Operations Manager node. SSH requires high-privileged user account credentials. SSH activities
generally bypass the role-based access control (RBAC) and audit controls of the
vRealize Operations Manager node.
As a best practice, disable SSH in a production environment and enable it only to diagnose or troubleshoot
problems that you cannot resolve by other means. Leave it enabled only while needed for a specic purpose
and in accordance with your organization's security policies. If you enable SSH, ensure that it is protected
against aack and that you enable it only for as long as required. Depending on your vSphere conguration,
you can enable or disable SSH when you deploy your Open Virtualization Format (OVF) template.
As a simple test to determine whether SSH is enabled on a machine, try to open a connection by using SSH.
If the connection opens and requests credentials, then SSH is enabled and is available for making
connections.
Secure Shell Root User
Because VMware appliances do not include precongured default user accounts, the root account can use
SSH to directly log in by default. Disable SSH as root as soon as possible.
To meet the compliance standards for nonrepudiation, the SSH server on all hardened appliances is
precongured with the AllowGroups wheel entry to restrict SSH access to the secondary group wheel. For
separation of duties, you can modify the AllowGroups wheel entry in the /etc/ssh/sshd_config le to use
another group such as sshd.
The wheel group is enabled with the pam_wheel module for superuser access, so members of the wheel
group can use the su-root command, where the root password is required. Group separation enables users
to use SSH to the appliance, but not to use the su command to log in as root. Do not remove or modify other
entries in the AllowGroups eld, which ensures proper appliance function. After making a change, restart
the SSH daemon by running the # service sshd restart command.
VMware, Inc. 15
Secure Configuration
Enable or Disable Secure Shell on a vRealize Operations Manager node
You can enable Secure Shell (SSH) on a vRealize Operations Manager node for troubleshooting. For
example, to troubleshoot a server, you might require console access to the server. This is through SSH.
Disable SSH on a vRealize Operations Manager node for normal operation.
Procedure
1 Access the console of the vRealize Operations Manager node from vCenter.
2 Press Alt + F1 to access the login prompt then log in.
3 Run the #chkconfig command.
4 If the sshd service is o, run the #chkconfig sshd on command.
5 Run the #service sshd start command to start the sshd service.
6 Run the #service sshd stop command to stop the sshd service.
Create a Local Administrative Account for Secure Shell
You must create local administrative accounts that can be used as Secure Shell (SSH) and that are members
of the secondary wheel group, or both before you remove the root SSH access.
Before you disable direct root access, test that authorized administrators can access SSH by using
AllowGroups, and that they can use the wheel group and the su command to log in as root.
Procedure
1 Log in as root and run the following commands.
# useradd -d /home/vropsuser -g users -G wheel –m
# passwd username
Wheel is the group specied in AllowGroups for SSH access. To add multiple secondary groups, use -G
wheel,sshd.
2 Switch to the user and provide a new password to ensure password complexity checking.
# su – username
username@hostname:~>passwd
If the password complexity is met, the password updates. If the password complexity is not met, the
password reverts to the original password, and you must rerun the password command.
After you create the login accounts to allow SSH remote access and use the su command to log in as
root using the wheel access, you can remove the root account from the SSH direct login.
3 To remove direct login to SSH, modify the /etc/ssh/sshd_config le by replacing (#)PermitRootLogin
yes with PermitRootLogin no.
What to do next
Disable direct logins as root. By default, the hardened appliances allow direct login to root through the
console. After you create administrative accounts for nonrepudiation and test them for wheel access (su-
root), disable direct root logins by editing the /etc/securetty le as root and replacing the tty1 entry with
console.
16 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Restrict Secure Shell Access
As part of your system hardening process, restrict Secure Shell (SSH) access by conguring the
tcp_wrappers package appropriately on all VMware virtual appliance host machines. Also maintain
required SSH key le permissions on these appliances.
All VMware virtual appliances include the tcp_wrappers package to allow tcp-supported daemons to
control the network subnets that can access the libwrapped daemons. By default, the /etc/hosts.allow le
contains a generic entry, sshd: ALL : ALLOW, that allows all access to the secure shell. Restrict this access as
appropriate for your organization.
Procedure
1 Open the /etc/hosts.allow le on your virtual appliance host machine in a text editor.
2 Change the generic entry in your production environment to include only the local host entries and the
management network subnet for secure operations.
sshd:127.0.0.1 : ALLOW
sshd: [::1] : ALLOW
sshd: 10.0.0.0 :ALLOW
In this example, all local host connections and connections that the clients make on the 10.0.0.0 subnet
are allowed.
3 Add all appropriate machine identication, for example, host name, IP address, fully qualied domain
name (FQDN), and loopback.
4 Save the le and close it.
Maintain Secure Shell Key File Permissions
To maintain an appropriate level of security, congure Secure Shell (SSH) key le permissions.
Procedure
1 View the public host key les, located in /etc/ssh/*key.pub.
2 Verify that these les are owned by root, that the group is owned by root, and that the les have
permissions set to 0644.
The permissions are (-rw-r--r--).
3 Close all les.
4 View the private host key les, located in /etc/ssh/*key.
5 Verify that root owns these les and the group, and that the les have permissions set to 0600.
The permissions are (-rw-------).
6 Close all les.
Harden the Secure Shell Server Configuration
Where possible, the Virtual Application Installation (OVF) has a default hardened conguration. Users can
verify that their conguration is appropriately hardened by examining the server and client service in the
global options section of the conguration le.
If possible, restrict use of the SSH server to a management subnet in the /etc/hosts.allow le.
VMware, Inc. 17
Secure Configuration
Procedure
1 Open the /etc/ssh/sshd_config server conguration le and verify that the seings are correct.
Setting Status
Server Daemon Protocol Protocol 2
Ciphers Ciphers aes256-ctr,aes128-ctr
TCP Forwarding AllowTCPForwarding no
Server Gateway Ports Gateway Ports no
X11 Forwarding X11Forwarding no
SSH Service Use the AllowGroups eld and specify a group permied to access
GSSAPI Authentication GSSAPIAuthentication no, if unused
Kerberos Authentication KerberosAuthentication no, if unused
Local Variables (AcceptEnv global option)
Tunnel Conguration PermitTunnel no
Network Sessions MaxSessions 1
Strict Mode Checking Strict Modes yes
Privilege Separation UsePrivilegeSeparation yes
rhosts RSA Authentication RhostsRSAAuthentication no
Compression Compression delayed or Compression no
Message Authentication code MACs hmac-sha1
User Access Restriction PermitUserEnvironment no
and add members to the secondary group for users permied to ue
the service.
Set to disabled by commenting out or enabled for only LC_*
or LANG variables
2 Save your changes and close the le.
Harden the Secure Shell Client Configuration
As part of your system hardening monitoring process, verify hardening of the SSH client by examining the
SSH client conguration le on virtual appliance host machines to ensure that it is congured according to
VMware guidelines.
Procedure
1 Open the SSH client conguration le, /etc/ssh/ssh_config, and verify that the seings in the global
options section are correct.
Setting Status
Client Protocol
Client Gateway Ports
GSSAPI Authentication
Local Variables (SendEnv global
option)
CBC Ciphers
Message Authentication Codes
2 Save your changes and close the le.
Protocol 2
Gateway Ports no
GSSAPIAuthentication no
Provide only LC_* or LANG variables
Ciphers aes256-ctr,aes128-ctr
Used in the MACs hmac-sha1 entry only
18 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Disable Direct Logins as Root
By default, the hardened appliances allow you to use the console to log in directly as root. As a security best
practice, you can disable direct logins after you create an administrative account for nonrepudiation and test
it for wheel access by using the su-root command.
Prerequisites
Complete the steps in the topic called “Create a Local Administrative Account for Secure Shell,” on
n
page 16.
Verify that you have tested accessing the system as an administrator before you disable direct root
n
logins.
Procedure
1 Log in as root and navigate to the /etc/securetty le.
You can access this le from the command prompt.
2 Replace the tty1 entry with console.
Disable SSH Access for the Admin User Account
As a security best practice, you can disable SSH access for the admin user account. The
vRealize Operations Manager admin account and the Linux admin account share the same password.
Disabling SSH access to the admin user enforces defense in depth by ensuring all users of SSH rst login to
a lesser privileged service account with a password that diers from the vRealize Operations Manager
admin account and then switch user to a higher privilege such as the admin or root.
Procedure
1 Edit the /etc/ssh/sshd_config le.
You can access this le from the command prompt.
2 Add the DenyUsers admin entry anywhere in the le and save the le.
3 To restart the sshd server, run the service sshd restart command.
Set Boot Loader Authentication
To provide an appropriate level of security, congure boot loader authentication on your VMware virtual
appliances. If the system boot loader requires no authentication, users with console access to the system
might be able to alter the system boot conguration or boot the system to single user or maintenance mode,
which can result in denial of service or unauthorized system access.
Because boot loader authentication is not set by default on the VMware virtual appliances, you must create a
GRUB password to congure it.
Procedure
1 Verify whether a boot password exists by locating the password --md5 <password-hash> line in
the /boot/grub/menu.lst le on your virtual appliances.
2 If no password exists, run the # /usr/sbin/grub-md5-crypt command on your virtual appliance.
An MD5 password is generated, and the command supplies the md5 hash output.
3 Append the password to the menu.lst le by running the # password --md5 <hash from grub-md5-
crypt> command.
VMware, Inc. 19
Secure Configuration
Single-User or Maintenance Mode Authentication
If the system does not require valid root authentication before it boots into single-user or maintenance
mode, anyone who invokes single-user or maintenance mode is granted privileged access to all les on the
system.
Procedure
Review the/etc/inittab le and ensure that the following two lines appear: ls:S:wait:/etc/init.d/rc
u
S and ~~:S:respawn:/sbin/sulogin.
Monitor Minimal Necessary User Accounts
You must monitor existing user accounts and ensure that any unnecessary user accounts are removed.
Procedure
Run the host:~ # cat /etc/passwd command and verify the minimal necessary user accounts:
u
bin:x:1:1:bin:/bin:/bin/bash
daemon:x:2:2:Daemon:/sbin:/bin/bash
haldaemon:x:101:102:User for haldaemon:/var/run/hald:/bin/false
mail:x:8:12:Mailer daemon:/var/spool/clientmqueue:/bin/false
man:x:13:62:Manual pages viewer:/var/cache/man:/bin/bash
messagebus:x:100:101:User for D-Bus:/var/run/dbus:/bin/false
nobody:x:65534:65533:nobody:/var/lib/nobody:/bin/bash
ntp:x:74:106:NTP daemon:/var/lib/ntp:/bin/false
polkituser:x:103:104:PolicyKit:/var/run/PolicyKit:/bin/false
postfix:x:51:51:Postfix Daemon:/var/spool/postfix:/bin/false
root:x:0:0:root:/root:/bin/bash
sshd:x:71:65:SSH daemon:/var/lib/sshd:/bin/false
suse-ncc:x:104:107:Novell Customer Center User:/var/lib/YaST2/suse-ncc-fakehome:/bin/bash
uuidd:x:102:103:User for uuidd:/var/run/uuidd:/bin/false
wwwrun:x:30:8:WWW daemon apache:/var/lib/wwwrun:/bin/false
nginx:x:105:108:user for nginx:/var/lib/nginx:/bin/false
admin:x:1000:1003::/home/admin:/bin/bash
tcserver:x:1001:1004:tc Server User:/home/tcserver:/bin/bash
postgres:x:1002:100::/var/vmware/vpostgres/9.3:/bin/bash
Monitor Minimal Necessary Groups
You must monitor existing groups and members to ensure that any unnecessary groups or group access is
removed.
Procedure
Run the <host>:~ # cat /etc/group command to verify the minimum necessary groups and group
u
membership.
audio:x:17:
bin:x:1:daemon
cdrom:x:20:
console:x:21:
daemon:x:2:
dialout:x:16:u1,tcserver,postgres
disk:x:6:
floppy:x:19:
20 VMware, Inc.
haldaemon:!:102:
kmem:x:9:
mail:x:12:
man:x:62:
messagebus:!:101:
modem:x:43:
nobody:x:65533:
nogroup:x:65534:nobody
ntp:!:106:
polkituser:!:105:
public:x:32:
root:x:0:admin
shadow:x:15:
sshd:!:65:
suse-ncc:!:107:
sys:x:3:
tape:!:103:
trusted:x:42:
tty:x:5:
utmp:x:22:
uuidd:!:104:
video:x:33:u1,tcserver,postgres
wheel:x:10:root,admin
www:x:8:
xok:x:41:
maildrop:!:1001:
postfix:!:51:
users:x:100:
vami:!:1002:root
nginx:!:108:
admin:!:1003:
vfabric:!:1004:admin,wwwrun
Chapter 3 Secure Configuration of vRealize Operations Manager
Resetting the vRealize Operations Manager Administrator Password (Linux)
As a security best practice, you can reset the vRealize Operations Manager password on Linux clusters for
vApp or Linux installations.
Procedure
1 Log in to the remote console of the master node as root.
2 Enter the $VMWARE_PYTHON_BIN $VCOPS_BASE/../vmware-
vcopssuite/utilities/sliceConfiguration/bin/vcopsSetAdminPassword.py --reset command and
follow the prompts.
VMware, Inc. 21
Secure Configuration
Configure NTP on VMware Appliances
For critical time sourcing, disable host time synchronization and use the Network Time Protocol (NTP) on
VMware appliances. You must congure a trusted remote NTP server for time synchronization. The NTP
server must be an authoritative time server or at least synchronized with an authoritative time server.
The NTP daemon on VMware virtual appliances provides synchronized time services. NTP is disabled by
default, so you need to congure it manually. If possible, use NTP in production environments to track user
actions and to detect potential malicious aacks and intrusions through accurate audit and log keeping. For
information about NTP security notices, see the NTP Web site.
The NTP conguration le is located in the /etc/ntp.conf le on each appliance.
Procedure
1 Navigate to the /etc/ntp.conf conguration le on your virtual appliance host machine.
2 Set the le ownership to root:root.
3 Set the permissions to 0640.
4 To mitigate the risk of a denial-of-service amplication aack on the NTP service, open
the /etc/ntp.conf le and ensure that the restrict lines appear in the le.
restrict default kod nomodify notrap nopeer noquery
restrict -6 default kod nomodify notrap nopeer noquery
restrict 127.0.0.1
restrict -6 ::1
5 Save any changes and close the les.
For information on NTP security notices, see hp://support.ntp.org/bin/view/Main/SecurityNotice.
Disable the TCP Timestamp Response on Linux
Use the TCP timestamp response to approximate the remote host's uptime and aid in further aacks.
Additionally, some operating systems can be ngerprinted based on the behavior of their TCP time stamps.
Procedure
Disable the TCP timestamp response on Linux.
u
a To set the value of net.ipv4.tcp_timestamps to 0, run the sysctl -w net.ipv4.tcp_timestamps=0
command.
b Add the ipv4.tcp_timestamps=0 value in the default sysctl.conf le.
Enable FIPS 140-2 Mode
The version of OpenSSL that is shipped with vRealize Operations Manager 6.3 and later releases is FIPS
140-2 certied. However, the FIPS mode is not enabled by default.
You can enable the FIPS mode if there is a security compliance requirement to use FIPS certied
cryptographic algorithms with the FIPS mode enabled.
Procedure
1 To replace the mod_ssl.so le run the following command:
cd /usr/lib64/apache2-prefork/
cp mod_ssl.so mod_ssl.so.old
cp mod_ssl.so.FIPSON.openssl1.0.2 mod_ssl.so
22 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
2 Modify your Apache2 conguration by editing the /etc/apache2/ssl-global.conf le.
3 Search for the <IfModule mod_ssl.c> line and add the SSLFIPS on directive below it.
4 To reset the Apache conguration, run the service apache2 restart command.
TLS for Data in Transit
As a security best practice, ensure that the system is deployed with secure transmission channels.
Configure Strong Protocols for vRealize Operations Manager
Protocols such as SSLv2 and SSLv3 are no longer considered secure. In addition, it is recommended that you
disable TLS 1.0. Enable only TLS 1.1 and TLS 1.2.
Verify the Correct Use of Protocols in Apache HTTPD
vRealize Operations Manager disables SSLv2 and SSLv3 by default. You must disable weak protocols on all
load balancers before you put the system into production.
Procedure
1 Run the grep SSLProtocol /usr/lib/vmware-vcopssuite/utilities/conf/vcops-apache.conf | grep -
v '#' command from the command prompt to verify that SSLv2 and SSLv3 are disabled.
If the protocols are disabled, the command returns the following output: SSLProtocol All -SSLv2 -
SSLv3
2 To also disable the TLS 1.0 protocol, run the sed -i "/^[^#]*SSLProtocol/ c\SSLProtocol All -SSLv2
-SSLv3 -TLSv1" /usr/lib/vmware-vcopssuite/utilities/conf/vcops-apache.conf command from the
command prompt.
3 To restart the Apache2 server, run the /etc/init.d/apache2 restart command from the command
prompt.
Verify the Correct Use of Protocols in the GemFire TLS Handler
vRealize Operations Manager disables SSLv3 by default. You must disable weak protocols on all load
balancers before you put the system into production.
Procedure
1 Verify that the protocols are enabled. To verify that the protocols are enabled, run the following
commands on each node:
grep cluster-ssl-protocol /usr/lib/vmware-vcops/user/conf/gemfire.properties | grep -v '#'
The following result is expected:
cluster-ssl-protocols=TLSv1.2 TLSv1.1 TLSv1
grep cluster-ssl-protocol /usr/lib/vmware-vcops/user/conf/gemfire.native.properties | grep -
v '#'
The following result is expected:
cluster-ssl-protocols=TLSv1.2 TLSv1.1 TLSv1
grep cluster-ssl-protocol /usr/lib/vmware-vcops/user/conf/gemfire.locator.properties | grep -
v '#'
The following result is expected:
cluster-ssl-protocols=TLSv1.2 TLSv1.1 TLSv1
VMware, Inc. 23
Secure Configuration
2 Disable TLS 1.0.
a Navigate to the administrator user interface at url/admin .
b Click Bring .
c To disable SSLv3 and TLS 1.0, run the following commands:
d Navigate to the administrator user interface.
e Click Bring Online.
3 Reenable TLS 1.0.
a Navigate to the administrator user interface to bring the cluster oine: url/admin.
b Click Bring .
sed -i "/^[^#]*cluster-ssl-protocol/ c\cluster-ssl-protocols=TLSv1.2
TLSv1.1" /usr/lib/vmware-vcops/user/conf/gemfire.properties
sed -i "/^[^#]*cluster-ssl-protocol/ c\cluster-ssl-protocols=TLSv1.2
TLSv1.1" /usr/lib/vmware-vcops/user/conf/gemfire.native.properties
sed -i "/^[^#]*cluster-ssl-protocol/ c\cluster-ssl-protocols=TLSv1.2
TLSv1.1" /usr/lib/vmware-vcops/user/conf/gemfire.locator.properties
Repeat this step for each node
c To ensure that SSLv3 and TLS 1.0 are disabled, run the following commands:
sed -i "/^[^#]*cluster-ssl-protocol/ c\cluster-ssl-protocols=TLSv1.2 TLSv1.1
TLSv1" /usr/lib/vmware-vcops/user/conf/gemfire.properties
sed -i "/^[^#]*cluster-ssl-protocol/ c\cluster-ssl-protocols=TLSv1.2 TLSv1.1
TLSv1" /usr/lib/vmware-vcops/user/conf/gemfire.native.properties
sed -i "/^[^#]*cluster-ssl-protocol/ c\cluster-ssl-protocols=TLSv1.2 TLSv1.1
TLSv1" /usr/lib/vmware-vcops/user/conf/gemfire.locator.properties
Repeat this step for each node.
d Navigate to the administrator user interface to bring the cluster online.
e Click Bring Online.
Configure vRealize Operations Manager to Use Strong Ciphers
For maximum security, you must congure vRealize Operations Manager components to use strong ciphers.
To ensure that only strong ciphers are selected, disable the use of weak ciphers. Congure the server to
support only strong ciphers and to use suciently large key sizes. Also, congure the ciphers in a suitable
order.
vRealize Operations Manager disables the use of cipher suites using the DHE key exchange by default.
Ensure that you disable the same weak cipher suites on all load balancers before you put the system into
production.
Using Strong Ciphers
The encryption cipher negotiated between the server and the browser determines the key exchange method
and encryption strength that is used in a TLS session.
24 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Verify the Correct Use of Cipher Suites in Apache HTTPD
For maximum security, verify the correct use of cipher suites in Apache hpd.
Procedure
1 To verify the correct use of cipher suites in Apache hpd, run the grep
SSLCipherSuite /usr/lib/vmware-vcopssuite/utilities/conf/vcops-apache.conf | grep -v '#'
command from the command prompt.
If Apache hpd uses the correct cipher suites, the command returns the following output:
SSLCipherSuite kECDH+AESGCM:ECDH+AESGCM:RSA+AESGCM:kECDH+AES:ECDH+AES:RSA+AES:!aNULL!ADH:!
EXP:!MD5:!3DES:!CAMELLIA:!PSK:!SRP:!DH
2 To congure the correct use of cipher suites, run the sed -i "/^[^#]*SSLCipherSuite/
c\SSLCipherSuite kECDH+AESGCM:ECDH+AESGCM:RSA+AESGCM:kECDH+AES:ECDH+AES:RSA+AES:\!aNULL\!
ADH:\!EXP:\!MD5:\!3DES:\!CAMELLIA:\!PSK:\!SRP:\!DH" /usr/lib/vmwarevcopssuite/utilities/conf/vcops-apache.conf command from the command prompt.
Run this command if the output in Step 1 is not as expected.
This command disables all cipher suites that use DH and DHE key exchange methods.
3 Run the /etc/init.d/apache2 restart command from the command prompt to restart the Apache2
server.
4 To reenable DH, remove !DH from the cipher suites by running the sed -i "/^[^#]*SSLCipherSuite/
c\SSLCipherSuite kECDH+AESGCM:ECDH+AESGCM:RSA+AESGCM:kECDH+AES:ECDH+AES:RSA+AES:\!aNULL\!
ADH:\!EXP:\!MD5:\!3DES:\!CAMELLIA:\!PSK:\!SRP" /usr/lib/vmwarevcopssuite/utilities/conf/vcops-apache.conf command from the command prompt.
5 Run the /etc/init.d/apache2 restart command from the command prompt to restart the Apache2
server.
Verify the Correct Use of Cipher Suites in GemFire TLS Handler
For maximum security, verify the correct use of cipher suites in GemFire TLS Handler.
Procedure
1 To verify that the cipher suites are enabled, run the following commands on each node to verify that the
protocols are enabled:
grep cluster-ssl-ciphers /usr/lib/vmware-vcops/user/conf/gemfire.properties | grep -v '#'
grep cluster-ssl-ciphers /usr/lib/vmware-vcops/user/conf/gemfire.native.properties | grep -v
'#'
grep cluster-ssl-ciphers /usr/lib/vmware-vcops/user/conf/gemfire.locator.properties | grep -v
'#'
2 Congure the correct cipher suites.
a Navigate to the administrator user interface at URL/admin.
b To bring the cluster oine, click Bring .
VMware, Inc. 25
Secure Configuration
c To congure the correct cipher suites, run the following commands:
sed -i "/^[^#]*cluster-ssl-ciphers/ c\cluster-ssl-
ciphers=TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256" /usr/lib/vmware-
vcops/user/conf/gemfire.properties
sed -i "/^[^#]*cluster-ssl-ciphers/ c\cluster-ssl-
ciphers=TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256" /usr/lib/vmware-
vcops/user/conf/gemfire.native.properties
sed -i "/^[^#]*cluster-ssl-ciphers/ c\cluster-ssl-
ciphers=TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256" /usr/lib/vmware-
vcops/user/conf/gemfire.locator.properties
Repeat this step for each node.
d Navigate to the administrator user interface at URL/admin.
e Click Bring Online.
Application Resources That Must be Protected
As a security best practice, ensure that the application resources are protected.
Follow the steps to ensure that the application resources are protected.
Procedure
1 Run the Find / -path /proc -prune -o -type f -perm +6000 -ls command to verify that the les
have a well dened SUID and GUID bits set.
The following list appears:
354131 24 -rwsr-xr-x 1 polkituser root 23176 /usr/lib/PolicyKit/polkit-set-default-helper
354126 20 -rwxr-sr-x 1 root polkituser 19208 /usr/lib/PolicyKit/polkit-grant-
helper
354125 20 -rwxr-sr-x 1 root polkituser 19008 /usr/lib/PolicyKit/polkit-explicit-
grant-helper
354130 24 -rwxr-sr-x 1 root polkituser 23160 /usr/lib/PolicyKit/polkit-revoke-
helper
354127 12 -rwsr-x--- 1 root polkituser 10744 /usr/lib/PolicyKit/polkit-grant-
helper-pam
354128 16 -rwxr-sr-x 1 root polkituser 14856 /usr/lib/PolicyKit/polkit-read-auth-
helper
73886 84 -rwsr-xr-x 1 root shadow 77848 /usr/bin/chsh
73888 88 -rwsr-xr-x 1 root shadow 85952 /usr/bin/gpasswd
73887 20 -rwsr-xr-x 1 root shadow 19320 /usr/bin/expiry
73890 84 -rwsr-xr-x 1 root root 81856 /usr/bin/passwd
73799 240 -rwsr-xr-x 1 root root 238488 /usr/bin/sudo
73889 20 -rwsr-xr-x 1 root root 19416 /usr/bin/newgrp
73884 92 -rwsr-xr-x 1 root shadow 86200 /usr/bin/chage
73885 88 -rwsr-xr-x 1 root shadow 82472 /usr/bin/chfn
73916 40 -rwsr-x--- 1 root trusted 40432 /usr/bin/crontab
296275 28 -rwsr-xr-x 1 root root 26945 /usr/lib64/pt_chown
353804 816 -r-xr-sr-x 1 root mail 829672 /usr/sbin/sendmail
278545 36 -rwsr-xr-x 1 root root 35792 /bin/ping6
278585 40 -rwsr-xr-x 1 root root 40016 /bin/su
278544 40 -rwsr-xr-x 1 root root 40048 /bin/ping
278638 72 -rwsr-xr-x 1 root root 69240 /bin/umount
278637 100 -rwsr-xr-x 1 root root 94808 /bin/mount
26 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
475333 48 -rwsr-x--- 1 root messagebus 47912 /lib64/dbus-1/dbus-daemon-launch-
helper
41001 36 -rwsr-xr-x 1 root shadow 35688 /sbin/unix_chkpwd
41118 12 -rwsr-xr-x 1 root shadow 10736 /sbin/unix2_chkpwd
2 Run the find / -path */proc -prune -o -nouser -o -nogroup command to verify that all the les in
the vApp have an owner.
All the les have an owner if there are no results.
3 Run the find / -name "*.*" -type f -perm -a+w | xargs ls -ldb command to verify that none of the
les are world writable les by reviewing permissions of all the les on the vApp.
None of the les must include the permission xx2.
4 Run the find / -path */proc -prune -o ! -user root -o -user admin -print command to verify that
the les are owned by the correct user.
All the les belong to either root or admin if there are no results.
5 Run the find /usr/lib/vmware-casa/ -type f -perm -o=w command to ensure that les in
the /usr/lib/vmware-casa/ directory are not world writable.
There must be no results.
6 Run the find /usr/lib/vmware-vcops/ -type f -perm -o=w command to ensure that les in
the /usr/lib/vmware-vcops/ directory are not world writable.
There must be no results.
7 Run the find /usr/lib/vmware-vcopssuite/ -type f -perm -o=w command to ensure that les in
the /usr/lib/vmware-vcopssuite/ directory are not world writable.
There must be no results.
Configure PostgreSQL Client Authentication
You can congure the system for client authentication. You can congure the system for local trust
authentication. This allows any local user, including the database super user to connect as a PostgreSQL user
without a password. If you want to provide a strong defense and if you do not have signicant trust in all
local user accounts, use another authentication method. The md5 method is set by default. Verify that md5
is set for all local and host connections.
You can nd the client authentication conguration seings for the Postgres service instance
in /storage/db/vcops/vpostgres/data/pg_hba.conf. Verify that md5 is set for all local and host connections.
The client authentication conguration seings for the postgres-repl service instance can be found
in /storage/db/vcops/vpostgres/repl/pg_hba.conf. Verify that md5 is set for all local and host connections.
N Do not modify client conguration seings for the PostgreSQL user account.
VMware, Inc. 27
Secure Configuration
Apache Configuration
Disable Web Directory Browsing
As a security best practice, ensure that a user cannot bowse through a directory because it can increase the
risk of exposure to directory traversal aacks.
Procedure
Verify that web directory browsing is disabled for all directories.
u
a Open the /etc/apache2/default-server.conf and /usr/lib/vmware-
vcopssuite/utilities/conf/vcops-apache.conf les in a text editor.
b
Verify that for each <Directory> listing, the option called Indexes for the relevant tag is omied
from the Options line.
Remove the Sample Code for the Apache2 Server
Apache includes two sample Common Gateway Interface (CGI) scripts, printenv and test-cgi. A
production Web server must contain only components that are operationally necessary. These components
have the potential to disclose critical information about the system to an aacker.
As a security best practice, delete the CGI scripts from the cgi-bin directory.
Procedure
To remove test-cgi and prinenv scripts, run the rm /usr/share/doc/packages/apache2/test-cgi and
u
rm /usr/share/doc/packages/apache2/printenv commands.
Verify Server Tokens for the Apache2 Server
As part of your system hardening process, verify server tokens for the Apache2 server. The Web server
response header of an HTTP response can contain several elds of information. Information includes the
requested HTML page, the Web server type and version, the operating system and version, and ports
associated with the Web server. This information provides malicious users important information without
the use of extensive tools.
The directive ServerTokens must be set to Prod. For example, ServerTokens Prod. This directive controls
whether the response header eld of the server that is sent back to clients includes a description of the
operating system and information about compiled-in modules.
Procedure
1 To verify server tokens, run the cat /etc/apache2/sysconfig.d/global.conf | grep ServerTokens
command.
2 To modify ServerTokens OS to ServerTokens Prod, run the sed -i
's/\(ServerTokens\s\+\)OS/\1Prod/g' /etc/apache2/sysconfig.d/global.conf command.
Disable the Trace Method for the Apache2 Server
In standard production operations, use of diagnostics can reveal undiscovered vulnerabilities that lead to
compromised data. To prevent misuse of data, disable the HTTP Trace method.
Procedure
1 To verify the Trace method for the Apache2 server, run the following command grep
TraceEnable /usr/lib/vmware-vcopssuite/utilities/conf/vcops-apache.conf.
28 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
2 To disable the Trace method for the Apache2 server, run the following command sed -i
"/^[^#]*TraceEnable/ c\TraceEnable off" /usr/lib/vmware-vcopssuite/utilities/conf/vcopsapache.conf.
Disable Configuration Modes
As a best practice, when you install, congure, or maintain vRealize Operations Manager, you can modify
the conguration or seings to enable troubleshooting and debugging of your installation.
Catalog and audit each of the changes you make to ensure that they are properly secured. Do not put the
changes into production if you are not sure that your conguration changes are correctly secured.
Managing Nonessential Software Components
To minimize security risks, remove or congure nonessential software from your
vRealize Operations Manager host machines.
Congure all software that you do not remove in accordance with manufacturer recommendations and
security best practices to minimize its potential to create security breaches.
Secure the USB Mass Storage Handler
Secure the USB mass storage handler to prevent it from loading by default on vRealize appliances and to
prevent its use as the USB device handler with the vRealize appliances. Potential aackers can exploit this
handler to install malicious software.
Procedure
1 Open the/etc/modprobe.conf.local le in a text editor.
2 Ensure that the install usb-storage /bin/true line appears in the le.
3 Save the le and close it.
Secure the Bluetooth Protocol Handler
Secure the Bluetooth protocol handler on your vRealize Appliances to prevent potential aackers from
exploiting it.
Binding the Bluetooth protocol to the network stack is unnecessary and can increase the aack surface of the
host. Prevent the Bluetooth protocol handler module from loading by default on vRealize Appliances.
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
2 Ensure that the line install bluetooth /bin/true appears in this le.
3 Save the le and close it.
Secure the Stream Control Transmission Protocol
Prevent the Stream Control Transmission Protocol (SCTP) module from loading on vRealize appliances by
default. Potential aackers could exploit this protocol to compromise your system.
Congure your system to prevent the SCTP module from loading unless it is absolutely necessary. SCTP is
an unused IETF-standardized transport layer protocol. Binding this protocol to the network stack increases
the aack surface of the host. Unprivileged local processes might cause the kernel to dynamically load a
protocol handler by using the protocol to open a socket.
VMware, Inc. 29
Secure Configuration
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
2 Ensure that the following line appears in this le.
install sctp /bin/true
3 Save the le and close it.
Secure the Datagram Congestion Control Protocol
As part of your system hardening activities, prevent the Datagram Congestion Control Protocol (DCCP)
module from loading on vRealize appliances by default. Potential aackers can exploit this protocol to
compromise your system.
Avoid loading the DCCP module, unless it is absolutely necessary. DCCP is a proposed transport layer
protocol, which is not used. Binding this protocol to the network stack increases the aack surface of the
host. Unprivileged local processes can cause the kernel to dynamically load a protocol handler by using the
protocol to open a socket.
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
2 Ensure that the DCCP lines appear in the le.
install dccp /bin/true
install dccp_ipv4 /bin/true
install dccp_ipv6 /bin/true
3 Save the le and close it.
Secure Reliable Datagram Sockets Protocol
As part of your system hardening activities, prevent the Reliable Datagram Sockets (RDS) protocol from
loading on your vRealize appliances by default. Potential aackers can exploit this protocol to compromise
your system.
Binding the RDS protocol to the network stack increases the aack surface of the host. Unprivileged local
processes might cause the kernel to dynamically load a protocol handler by using the protocol to open a
socket.
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
2 Ensure that the install rds /bin/true line appears in this le.
3 Save the le and close it.
Secure the Transparent Inter-Process Communication Protocol
As part of your system hardening activities, prevent the Transparent Inter-Process Communication protocol
(TIPC) from loading on your virtual appliance host machines by default. Potential aackers can exploit this
protocol to compromise your system.
Binding the TIPC protocol to the network stack increases the aack surface of the host. Unprivileged local
processes can cause the kernel to dynamically load a protocol handler by using the protocol to open a
socket.
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
30 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
2 Ensure that the install tipc /bin/true line appears in this le.
3 Save the le and close it.
Secure Internet Packet Exchange Protocol
Prevent the Internetwork Packet Exchange (IPX) protocol from loading vRealize appliances by default.
Potential aackers could exploit this protocol to compromise your system.
Avoid loading the IPX protocol module unless it is absolutely necessary. IPX protocol is an obsolete
network-layer protocol. Binding this protocol to the network stack increases the aack surface of the host.
Unprivileged local processes might cause the system to dynamically load a protocol handler by using the
protocol to open a socket.
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
2 Ensure that the line install ipx /bin/true appears in this le.
3 Save the le and close it.
Secure Appletalk Protocol
Prevent the Appletalk protocol from loading on vRealize appliances by default. Potential aackers might
exploit this protocol to compromise your system.
Avoid loading the Appletalk Protocol module unless it is absolutely necessary. Binding this protocol to the
network stack increases the aack surface of the host. Unprivileged local processes might cause the system
to dynamically load a protocol handler by using the protocol to open a socket.
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
2 Ensure that the line install appletalk /bin/true appears in this le.
3 Save the le and close it.
Secure DECnet Protocol
Prevent the DECnet protocol from loading on your system by default. Potential aackers might exploit this
protocol to compromise your system.
Avoid loading the DECnet Protocol module unless it is absolutely necessary. Binding this protocol to the
network stack increases the aack surface of the host. Unprivileged local processes could cause the system
to dynamically load a protocol handler by using the protocol to open a socket.
Procedure
1 Open the DECnet Protocol /etc/modprobe.conf.local le in a text editor.
2 Ensure that the line install decnet /bin/true appears in this le.
3 Save the le and close it.
Secure Firewire Module
Prevent the Firewire module from loading on vRealize appliances by default. Potential aackers might
exploit this protocol to compromise your system.
Avoid loading the Firewire module unless it is absolutely necessary.
VMware, Inc. 31
Secure Configuration
Procedure
1 Open the /etc/modprobe.conf.local le in a text editor.
2 Ensure that the line install ieee1394 /bin/true appears in this le.
3 Save the le and close it.
Kernel Message Logging
The kernel.printk specication in the /etc/sysctl.conf le species the kernel print logging
specications.
There are 4 values specied:
console loglevel. The lowest priority of messages printed to the console.
n
default loglevel. The lowest level for messages without a specic log level.
n
The lowest possible level for the console log level.
n
The default value for console log level.
n
There are eight possible entries per value.
define KERN_EMERG "<0>" /* system is unusable */
n
define KERN_ALERT "<1>" /* action must be taken immediately */
n
define KERN_CRIT "<2>" /* critical conditions */
n
define KERN_ERR "<3>" /* error conditions */
n
define KERN_WARNING "<4>" /* warning conditions */
n
define KERN_NOTICE "<5>" /* normal but significant condition */
n
define KERN_INFO "<6>" /* informational */
n
define KERN_DEBUG "<7>" /* debug-level messages */
n
Set the kernel.printk values to 3 4 1 7 and ensure that the line kernel.printk=3 4 1 7 exists in
the /etc/sysctl.conf le.
Windows Installed Deployment
Using Windows Time Service
For critical time sourcing, you must disable host time synchronization and use authorized time servers.
You can use authorized time servers in a production environment as a way to track user actions and to
identify potential malicious aacks and intrusion through accurate auditing and logging.
32 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
TLS for Data in Transit
As a security best practice, ensure that the system is deployed with secure transmission channels.
Configure vRealize Operations Manager to Use Strong Ciphers
The encryption strength that is used in a TLS session is determined by the encryption cipher negotiated
between the server and the browser. To ensure that only strong ciphers are selected, you must modify the
server to disable the use of weak ciphers. In addition, you must congure the ciphers in a suitable order. You
must congure the server to support only strong ciphers and to use suciently large key sizes.
Configure Strong Protocols for vRealize Operations Manager
Protocols such as SSLv2 and SSLv3 are no longer considered secure including SSLv2 and SSLv3. As a best
security practice for transport layer protection, provide support for only the TLS protocols.
Prior to production, you must verify that SSLv2 and SSLv3 are disabled.
Disable Weak Ciphers
Disable cipher suites that do not oer authentication such as NULL cipher suites, NULL, or eNULL. No
authentication makes them vulnerable to man-in-the-middle aacks.
You must also disable the anonymous Die-Hellman key exchange (ADH), export level ciphers (EXP,
ciphers containing DES), key sizes smaller than 128 bits for encrypting payload trac, the use of MD5 as a
hashing mechanism for payload trac, IDEA Cipher Suites, and RC4 cipher suites because they are all
vulnerable to aacks.
Disable Weak Ciphers in Apache HTTPD Handler
Disable the weak ciphers and enable strong ciphers that are used in the Apache HTTPD handler.
Prerequisites
For maximum security, review the Apache HTTPD handler ciphers on the vRealize Operations Manager
against the list of acceptable ciphers and disable all of the ciphers that are considered weak. This will help to
prevent man-in-the middle aacks.
Procedure
1 Open the C:\vmware\vrealize-operations\vmware-vcopssuite\utilities\conf le in a text editor.
2 Verify that the le contains the line SSLCipherSuite HIGH:!aNULL!ADH:!EXP:!MD5:!3DES:!CAMELLIA:!
PSK:!SRP:!DH:@STRENGTH.
3 Save the changes you made and close the le.
Enable Diffie-Hellman Key Exchange
Die-Hellman key exchange has weaknesses. Disable all cipher suites that contain DH, DHE, and EDH.
These cipher suites are now disabled by default. You can enable them if you need to use them.
Procedure
1 Open the C:\vmware\vrealize-operations\vmware-vcopssuite\utilities\conf le.
2 Find the line SSLCipherSuite HIGH:!aNULL!ADH:!EXP:!MD5:!3DES:!CAMELLIA:!PSK:!SRP:!DH:@STRENGTH.
3 Remove !DH: so that the line now reads SSLCipherSuite HIGH:!aNULL!ADH:!EXP:!MD5:!3DES:!
CAMELLIA:!PSK:!SRP:@STRENGTH.
4 Save and close the le.
VMware, Inc. 33
Secure Configuration
Disable Configuration Modes
As a best practice, when you install, congure, or maintain vRealize Operations Manager, you can modify
the conguration or seings to enable troubleshooting and debugging of your installation.
Catalog and audit each of the changes you make to ensure that they are properly secured. Do not put the
changes into production if you are not sure that your conguration changes are correctly secured.
Verifying the Host Server's Secure Baseline
You can use the Microsoft Baseline Security Analyzer (MBSA) to check whether your server has the latest
updates or hot xes. You can use MBSA to install any missing security patches from Microsoft to keep your
server up-to-date with Microsoft security recommendations. You can download this tool from Microsoft.
The latest tool, at the time this document was published, can be found here: hp://www.microsoft.com/en-
us/download/details.aspx?id=7558.
N Contact your Microsoft vendor for guidance on the most appropriate use of this tool.
Verifying that the Host Server Is Securely Configured
You can use the Windows Security Conguration Wizard (SCW) and the Microsoft Security Compliance
Manager toolkit to verify that the host server is securely congured.
1 Start the SCW from the administrative tools of your Windows server. This tool can identify the roles of
your server and the installed features including networking, Windows rewalls, and registry seings.
2 Compare the report with the latest hardening guidance from the relevant Microsoft Security
Compliance Manager (SCM) for your Windows server.
3 Based on the results, you can congure the security seings for each feature such as network services,
account seings, and Windows rewalls, and apply the seings to your server.
For more information on the SCW tool, go to hp://technet.microsoft.com/en-us/library/cc754997.aspx.
N Contact your Microsoft vendor for guidance on the most appropriate use of these tools.
Linux Installed Deployment
Enabling NTP Service
For critical time sourcing, you can disable the host time synchronization and use the Network Time Protocol
(NTP). NTP in production is a means to accurately track user actions and to realize potential malicious
aacks and intrusion through accurate audit and log keeping.
The ntp daemon is included on the appliance and is used to provide synchronized time services. You can
nd the conguration le for NTP in /etc/ntp.conf.
TLS for Data in Transit
As a security best practice, ensure that the system is deployed with secure transmission channels.
Configure Strong Protocols for vRealize Operations Manager
Protocols such as SSLv2 and SSLv3 are no longer considered secure including SSLv2 and SSLv3. As a best
security practice for transport layer protection, provide support for only the TLS protocols.
Prior to production, you must verify that SSLv2 and SSLv3 are disabled.
34 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Configure vRealize Operations Manager to Use Strong Ciphers
The encryption strength that is used in a TLS session is determined by the encryption cipher negotiated
between the server and the browser. To ensure that only strong ciphers are selected, you must modify the
server to disable the use of weak ciphers. In addition, you must congure the ciphers in a suitable order. You
must congure the server to support only strong ciphers and to use suciently large key sizes.
Disable Weak Ciphers
Disable cipher suites that do not oer authentication such as NULL cipher suites, NULL, or eNULL. No
authentication makes them vulnerable to man-in-the-middle aacks.
You must also disable the anonymous Die-Hellman key exchange (ADH), export level ciphers (EXP,
ciphers containing DES), key sizes smaller than 128 bits for encrypting payload trac, the use of MD5 as a
hashing mechanism for payload trac, IDEA Cipher Suites, and RC4 cipher suites because they are all
vulnerable to aacks.
Disable Weak Ciphers in Apache HTTPD Handler
Disable the weak ciphers and enable strong ciphers that are used in the Apache HTTPD handler. To prevent
man-in-the-middle aacks, review the Apache HTTPD handler ciphers on vRealize Operations Manager
against the list of acceptable ciphers and disable all of the ciphers that are considered weak.
Procedure
1 Open the /usr/lib/vmware-vcopssuite/utilities/conf/vcops-apache.conf le in a text editor.
2 Verify that the le contains the line SSLCipherSuite HIGH:!aNULL!ADH:!EXP:!MD5:!3DES:!CAMELLIA:!
PSK:!SRP:!DH:@STRENGTH.
3 Save and close the le.
Enable Diffie-Hellman Key Exchange
Die-Hellman key exchange has weaknesses. You must disable all cipher suites that contain DH, DHE, and
EDH. These cipher suites are disabled by default. These can be enabled if you need to use them.
Procedure
1 Open the /usr/lib/vmware-vcopssuite/utilities/conf/vcops-apache.conf le.
2 Find the line SSLCipherSuite HIGH:!aNULL!ADH:!EXP:!MD5:!3DES:!CAMELLIA:!PSK:!SRP:!DH:@STRENGTH.
3 Remove !DH: so that the line reads SSLCipherSuite HIGH:!aNULL!ADH:!EXP:!MD5:!3DES:!CAMELLIA:!
PSK:!SRP:@STRENGTH.
4 Save and close the le.
Disable Configuration Modes
As a best practice, when you install, congure, or maintain vRealize Operations Manager, you can modify
the conguration or seings to enable troubleshooting and debugging of your installation.
Catalog and audit each of the changes you make to ensure that they are properly secured. Do not put the
changes into production if you are not sure that your conguration changes are correctly secured.
Verifying the Host Server's Secure Configuration
For the secure operation of vRealize Operations Manager, you must secure and verify the hardening
activities.
For more information, see the Red Hat Enterprise Linux 6 hardening guidance in accordance with your
organization's security policies.
VMware, Inc. 35
Secure Configuration
Endpoint Operations Management Agent
The Endpoint Operations Management agent adds agent-based discovery and monitoring capabilities to
vRealize Operations Manager.
The Endpoint Operations Management agent is installed on the hosts directly and might or might not be at
the same level of trust as the Endpoint Operations Management server. Therefore, you must verify that the
agents are securely installed.
Security Best Practices for Running Endpoint Operations Management Agents
You must follow certain security best practices while using user accounts.
For a silent installation, remove any credentials and server certicate thumbprints that were stored in
n
the AGENT_HOME/conf/agent.properties le.
Use a vRealize Operations Manager user account reserved specically for
n
Endpoint Operations Management agent registration. For more information, see the topic called "Roles
and Privileges" in vRealize Operations Manager in the vRealize Operations Manager Help.
Disable the vRealize Operations Manager user account that you use for agent registration after the
n
installation is over. You must enable the user ’s access for agent administration activities. For more
information, see the topic called Conguring Users and Groups in vRealize Operations Manager in the
vRealize Operations Manager Help.
If a system that runs an agent is compromised, you can revoke the agent certicate using the
n
vRealize Operations Manager user interface by removing the agent resource. See the section called
Revoking an Agent for more detail.
Minimum Required Permissions for Agent Functionality
You require permissions to install and modify a service. If you want to discover a running process, the user
account you use to run the agent must also have privileges to access the processes and programs. For
Windows operating system installations, you require permissions to install and modify a service. For Linux
installations, you require permission to install the agent as a service, if you install the agent using a RPM
installer.
The minimum credentials that are required for the agent to register with the vRealize Operations Manager
server are those for a user granted the Agent Manager role, without any assignment to objects within the
system.
Linux Based Platform Files and Permissions
After you install the Endpoint Operations Management agent, the owner is the user that installs the agent.
The installation directory and le permissions such as 600 and 700, are set to the owner when the user who
installs the Endpoint Operations Management agent extracts the TAR le or installs the RPM.
N When you extract the ZIP le, the permissions might not be correctly applied. Verify and ensure that
the permissions are correct.
All the les that are created and wrien to by the agent are given 700 permissions with the owner being the
user who runs the agent.
36 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Table 3‑1. Linux Files and Permissions
Permissi
Directory or File
agent directory/bin 700 Owner Yes Yes Yes
agent directory/conf 700 Owner Yes Yes Yes
agent directory/log 700 Owner Yes Yes No
agent directory/data 700 Owner Yes Yes Yes
agent directory/bin/ep-
agent.bat
agent directory/bin/epagent.sh
agent directory/conf/*
(all les in the conf
directory)
agent directory/log/*
(all les in the log
directory)
agent directory/data/*
(all les in the data
directory)
ons
600 Owner Yes Yes No
700 Owner Yes Yes Yes
600 Owner Yes Yes Yes
600 Owner Yes Yes No
600 Owner Yes Yes No
Groups or
Users Read Write Execute
Group No No No
All No No No
Group No No No
All No No No
Group No No No
All No No No
Group No No No
All No No No
Group No No No
All No No No
Group No No No
All No No No
Group No No No
All No No No
Group No No No
All No No No
Group No No No
All No No No
Windows Based Platform Files and Permissions
For a Windows based installation of the Endpoint Operations Management agent, the user installing the
agent must have permissions to install and modify the service.
After you install the Endpoint Operations Management agent, the installation folder including all
subdirectories and les should only be accessible by the SYSTEM, the administrators group, and the
installation user. When you install the Endpoint Operations Management agent using ep-agent.bat, ensure
that the hardening process succeeds. As the user installing the agent, it is advised that you take note of any
error messages. If the hardening process fails, the user can apply these permissions manually.
VMware, Inc. 37
Secure Configuration
Table 3‑2. Windows Files and Permissions
Directory or File
<agent
directory>/bin
<agent
directory>/conf
<agent
directory>/log
<agent
directory>/data
<agent
directory>/bin/hqagent.bat
<agent
directory>/bin/hqagent.sh
<agent
directory>/conf/*
(all les in the conf
directory)
<agent
directory>/log/*
(all les in the log
directory)
Groups or
Users Full Control Modify
Read and
Execute Read Write
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
Yes - - - -
User
Users - - - -
38 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Table 3‑2. Windows Files and Permissions (Continued)
Directory or File
<agent
directory>/data/*
(all les in data
directory)
Groups or
Users Full Control Modify
SYSTEM Yes - - - -
Administrator Yes - - - -
Installation
User
Users - - - -
Yes - - - -
Read and
Execute Read Write
Open Ports on Agent Host
The agent process listens for commands on two ports 127.0.0.1:2144 and 127.0.0.1:32000 that are
congurable. These ports might be arbitrarily assigned, and so, the exact port number might vary. The agent
does not open ports on external interfaces.
Table 3‑3. Minimum Required Ports
Port Protocol Direction Comments
443 TCP Outgoing Used by the agent for outgoing connections over HTTP, TCP, or ICMP.
2144 TCP Listening Internal Only. Congurable. Used for inter-process communication between
the agent and the command line that loads and congures it. The agent process
listens on this port.
N The port number is assigned arbitrarily and might dier.
32000 TCP Listening Internal Only. Congurable. Used for inter-process communication between
the agent and the command line that loads and congures it. The agent process
listens on this port.
N The port number is assigned arbitrarily and might dier.
Revoking an Agent
If for any reason you need to revoke an agent, for example when a system with a running agent is
compromised, you can delete the agent resource from the system. Any subsequent request will fail
verication.
Use the vRealize Operations Manager user interface to revoke the agent certicate by removing the agent
resource. For more information, see “Removing the Agent Resource,” on page 39.
When the system is secured again, you can reinstate the agent. For more information, see “Reinstate an
Agent Resource,” on page 40.
Removing the Agent Resource
You can use the vRealize Operations Manager to revoke the agent certicate by removing the agent
resource.
Prerequisites
To preserve the continuity of the resource with previously recorded metric data, take a record of the
Endpoint Operations Management agent token that is displayed in the resource details.
Procedure
1 Navigate to the Inventory Explorer in the vRealize Operations Manager user interface.
2 Open the Adapter Types tree.
3 Open the EP Ops Adapter list.
VMware, Inc. 39
Secure Configuration
4 Select EP Ops Agent - *HOST_DNS_NAME*.
5 Click Edit Object.
6 Record the agent ID, which is the agent token string.
7 Close the Edit Object dialog box .
8 Select EP Ops Agent - *HOST_DNS_NAME* and click Delete Object.
Reinstate an Agent Resource
When the secure state of a system is recovered, you can reinstate a revoked agent. This ensures that the
agent continues to report on the same resources without losing historical data. To do this you must create a
new Endpoint Operations Management token le by using the same token recorded before you removed the
agent resource. See the section called Removing The Agent Resource.
Prerequisites
Ensure that you have the recorded Endpoint Operations Management token string.
n
Use the resource token recorded prior to removing the agent resource from the
n
vRealize Operations Manager server.
Ensure that you have the Manage Agent privilege.
n
Procedure
1 Create the agent token le with the user that runs the agent.
For example, run the command to create a token le containing the 123-456-789 token.
On Linux:
n
echo 123-456-789 > /etc/epops/epops-token
On Windows:
n
echo 123-456-789 > %PROGRAMDATA%\VMware\Ep Ops Agent\epops-token
In the example, the token le is wrien to the default token location for that platform
2 Install a new agent and register it with the vRealize Operations Manager server. Ensure that the agent
loads the token you inserted in the token le.
You must have the Manage Agent privilege to perform this action.
Agent Certificate Revocation and Update of Certificates
The reissue ow is initiated from the agent using the setup command line argument. When an agent that is
already registered uses the setup command line argument ep-agent.sh setup and lls in the required
credentials, a new registerAgent command is sent to the server.
The server detects that the agent is already registered and sends the agent a new client certicate without
creating another agent resource. On the agent side, the new client certicate replaces the old one. In cases
where the server certicate is modied and you run the ep-agent.sh setup command, you will see a
message that asks you to trust the new certicate. You can alternatively provide the new server certicate
thumbprint in the agent.properties le prior to running the ep-agent.sh setup command, in order to make
the process silent.
Prerequisites
Manage agent privilege to revoke and update certicates.
40 VMware, Inc.
Chapter 3 Secure Configuration of vRealize Operations Manager
Procedure
On Linux based operating systems, run the ep-agent.sh setup command on the agent host. On
u
Windows based operating systems, run the ep-agent.bat setup command.
If the agent detects that the server certicate has been modied, a message is displayed. Accept the new
certicate if you trust it and it is valid.
Patching and Updating the Endpoint Operations Management Agent
If required, new Endpoint Operations Management agent bundles are available independent of
vRealize Operations Manager releases.
Patches or updates are not provided for the Endpoint Operations Management agent. You must install the
latest available version of the agent that includes the latest security xes. Critical security xes will be
communicated as per the VMware security advisory guidance. See the topic on Security Advisories.
Additional Secure Configuration Activities
Verify Server User Account Settings
It is recommended that you verify that no unnecessary user accounts exist for local and domain user
accounts and seings.
Restrict any user account not related to the functioning of the application to those accounts required for
administration, maintenance, and troubleshooting. Restrict remote access from domain user accounts to the
minimum required to maintain the server. Strictly control and audit these accounts.
Delete and Disable Unnecessary Applications
Delete the unnecessary applications from the host servers. Each additional and unnecessary application
increases the risk of exposure because of their unknown or unpatched vulnerabilities.
Disabling Unnecessary Ports and Services
Verify the host server's rewall for the list of open ports that allow trac.
Block all the ports that are not listed as a minimum requirement for vRealize Operations Manager in the
“Conguring Ports and Protocols,” on page 51 section of this document, or are not required. In addition,
audit the services running on your host server and disable those that are not required.
VMware, Inc. 41
Secure Configuration
42 VMware, Inc.
Network Security and Secure
Communication 4
As a security best practice, review and edit the network communication seings of your VMware virtual
appliances and host machines. You must also congure the minimum incoming and outgoing ports for
vRealize Operations Manager.
This chapter includes the following topics:
“Conguring Network Seings for Virtual Application Installation,” on page 43
n
“Conguring Ports and Protocols,” on page 51
n
Configuring Network Settings for Virtual Application Installation
To ensure that your VMware virtual appliance and host machines allow only safe and essential
communication, review and edit their network communication seings.
Prevent User Control of Network Interfaces
As a security best practice, restrict the ability to change the network interface seing to privileged users. If
users manipulate network interfaces, it might result in bypassing network security mechanisms or denial of
service. Ensure that network interfaces are not congured for user control.
Procedure
1 To verify user control seings, run the #grep -i '^USERCONTROL=' /etc/sysconfig/network/ifcfg*
command.
2 Make sure that each interface is set to NO.
Set the Queue Size for TCP Backlog
As a security best practice, congure a default TCP backlog queue size on VMware appliance host machines.
To mitigate TCP denial or service aacks, set an appropriate default size for the TCP backlog queue size. The
recommended default seing is 1280.
Procedure
1 Run the # cat /proc/sys/net/ipv4/tcp_max_syn_backlog command on each VMware appliance host
machine.
VMware, Inc.
43
Secure Configuration
2 Set the queue size for TCP backlog.
a Open the /etc/sysctl.conf le in a text editor.
b Set the default TCP backlog queue size by adding the following entry to the le.
net.ipv4.tcp_max_syn_backlog=1280
c Save your changes and close the le.
Deny ICMPv4 Echoes to Broadcast Address
Responses to broadcast Internet Control Message Protocol (ICMP) echoes provide an aack vector for
amplication aacks and can facilitate network mapping by malicious agents. Conguring your system to
ignore ICMPv4 echoes provides protection against such aacks.
Procedure
1 Run the # cat /proc/sys/net/ipv4/icmp_echo_ignore_broadcasts command to verify that the system is
not sending responses to ICMP broadcast address echo requests.
2 Congure the host system to deny ICMPv4 broadcast address echo requests.
a Open the /etc/sysctl.conf le on a Windows host machine in a text editor.
b If the value for this entry is not set to 1, add the net.ipv4.icmp_echo_ignore_broadcasts=1 entry.
c Save the changes and close the le.
Configure the Host System to Disable IPv4 Proxy ARP
IPv4 Proxy ARP allows a system to send responses to ARP requests on one interface on behalf of hosts
connected to another interface. You must disable IPv4 Proxy ARP to prevent unauthorized information
sharing. Disable the seing to prevent leakage of addressing information between the aached network
segments.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv4/conf/*/proxy_arp|egrep "default|all" command to verify
whether the Proxy ARP is disabled.
2 Congure the host system to disable IPv4 Proxy ARP.
a Open the /etc/sysctl.conf le in a text editor.
b If the values are not set to 0, add the entries or update the existing entries accordingly. Set the value
to 0.
net.ipv4.conf.all.proxy_arp=0
net.ipv4.conf.default.proxy_arp=0
c Save any changes you made and close the le.
Configure the Host System to Ignore IPv4 ICMP Redirect Messages
As a security best practice, verify that the host system ignores IPv4 Internet Control Message Protocol
(ICMP) redirect messages. A malicious ICMP redirect message can allow a man-in-the-middle aack to
occur. Routers use ICMP redirect messages to notify hosts that a more direct route exists for a destination.
These messages modify the host's route table and are unauthenticated.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv4/conf/*/accept_redirects|egrep "default|all" command
on the host system to check whether the host system ignores IPv4 redirect messages.
44 VMware, Inc.
Chapter 4 Network Security and Secure Communication
2 Congure the host system to ignore IPv4 ICMP redirect messages.
a Open the /etc/sysctl.conf le.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv4.conf.all.accept_redirects=0
net.ipv4.conf.default.accept_redirects=0
c Save the changes and close the le.
Configure the Host System to Ignore IPv6 ICMP Redirect Messages
As a security best practice, verify that the host system ignores IPv6 Internet Control Message Protocol
(ICMP) redirect messages. A malicious ICMP redirect message might allow a man-in-the-middle aack to
occur. Routers use ICMP redirect messages to tell hosts that a more direct route exists for a destination.
These messages modify the host's route table and are unauthenticated.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/accept_redirects|egrep "default|all" command
on the host system and check whether it ignores IPv6 redirect messages.
2 Congure the host system to ignore IPv6 ICMP redirect messages.
a Open the /etc/sysctl.conf to congure the host system to ignore the IPv6 redirect messages.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.accept_redirects=0
net.ipv6.conf.default.accept_redirects=0
c Save the changes and close the le.
Configure the Host System to Deny IPv4 ICMP Redirects
As a security best practice, verify that the host system denies IPv4 Internet Control Message Protocol (ICMP)
redirects. Routers use ICMP redirect messages to inform servers that a direct route exists for a particular
destination. These messages contain information from the system's route table that might reveal portions of
the network topology.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv4/conf/*/send_redirects|egrep "default|all" on the host
system to verify whether it denies IPv4 ICMP redirects.
2 Congure the host system to deny IPv4 ICMP redirects.
a Open the /etc/sysctl.conf le to congure the host system.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv4.conf.all.send_redirects=0
net.ipv4.conf.default.send_redirects=0
c Save the changes and close the le.
VMware, Inc. 45
Secure Configuration
Configure the Host System to Log IPv4 Martian Packets
As a security best practice, verify that the host system logs IPv4 Martian packets. Martian packets contain
addresses that the system knows to be invalid. Congure the host system to log the messages so that you
can identify miscongurations or aacks in progress.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv4/conf/*/log_martians|egrep "default|all" command to
check whether the host logs IPv4 Martian packets.
2 Congure the host system to log IPv4 Martian packets.
a Open the /etc/sysctl.conf le to congure the host system.
b If the values are not set to 1, add the following entries to the le or update the existing entries
accordingly. Set the value to 1.
net.ipv4.conf.all.log_martians=1
net.ipv4.conf.default.log_martians=1
c Save the changes and close the le.
Configure the Host System to use IPv4 Reverse Path Filtering
As a security best practice, congure your host machines to use IPv4 reverse path ltering. Reverse path
ltering protects against spoofed source addresses by causing the system to discard packets with source
addresses that have no route or if the route does not point towards the originating interface.
Congure your system to use reverse-path ltering whenever possible. Depending on the system role,
reverse-path ltering might cause legitimate trac to be discarded. In such cases, you might need to use a
more permissive mode or disable reverse-path ltering altogether.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv4/conf/*/rp_filter|egrep "default|all" command on the
host system to check whether the system uses IPv4 reverse path ltering.
2 Congure the host system to use IPv4 reverse path ltering.
a Open the /etc/sysctl.conf le to congure the host system.
b If the values are not set to 1, add the following entries to the le or update the existing entries
accordingly. Set the value to 1.
net.ipv4.conf.all.rp_filter=1
net.ipv4.conf.default.rp_filter=1
c Save the changes and close the le.
Configure the Host System to Deny IPv4 Forwarding
As a security best practice, verify that the host system denies IPv4 forwarding. If the system is congured
for IP forwarding and is not a designated router, it could be used to bypass network security by providing a
path for communication that is not ltered by network devices.
Procedure
1 Run the # cat /proc/sys/net/ipv4/ip_forward command to verify whether the host denies IPv4
forwarding.
46 VMware, Inc.
Chapter 4 Network Security and Secure Communication
2 Congure the host system to deny IPv4 forwarding.
a Open the /etc/sysctl.conf to congure the host system.
b If the value is not set to 0, add the following entry to the le or update the existing entry
accordingly. Set the value to 0.
net.ipv4.ip_forward=0
c Save the changes and close the le.
Configure the Host System to Deny Forwarding of IPv4 Source Routed Packets
Source-routed packets allow the source of the packet to suggest that routers forward the packet along a
dierent path than what is congured on the router, which can be used to bypass network security
measures.
This requirement applies only to the forwarding of source-routed trac, such as when IPv4 forwarding is
enabled and the system is functioning as a router.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv4/conf/*/accept_source_route|egrep "default|all"
command to verify whether the system does not use IPv4 source routed packets
2 Congure the host system to deny forwarding of IPv4 source routed packets.
a Open the /etc/sysctl.conf le with a text editor.
b If the values are not set to 0, ensure that net.ipv4.conf.all.accept_source_route=0 and the
et.ipv4.conf.default.accept_source_route=0 are set to 0.
c Save and close the le.
Configure the Host System to Deny IPv6 Forwarding
As a security best practice, verify that the host system denies IPv6 forwarding. If the system is congured
for IP forwarding and is not a designated router, it can be used to bypass network security by providing a
path for communication that is not ltered by network devices.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/forwarding|egrep "default|all" command to verify
whether the host denies IPv6 forwarding.
2 Congure the host system to deny IPv6 forwarding.
a Open the /etc/sysctl.conf to congure the host system.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.forwarding=0
net.ipv6.conf.default.forwarding=0
c Save the changes and close the le.
VMware, Inc. 47
Secure Configuration
Configure the Host System to Use IPv4 TCP Syncookies
As a security best practice, verify that the host system uses IPv4 Transmission Control Protocol (TCP)
Syncookies. A TCP SYN ood aack might cause a denial of service by lling a system's TCP connection
table with connections in the SYN_RCVD state. Syncookies are used so as not to track a connection until a
subsequent ACK is received, verifying that the initiator is aempting a valid connection and is not a ood
source.
This technique does not operate in a fully standards-compliant manner, but is only activated when a ood
condition is detected, and allows defence of the system while continuing to service valid requests.
Procedure
1 Run the # cat /proc/sys/net/ipv4/tcp_syncookies command to verify whether the host system uses
IPv4 TCP Syncookies.
2 Congure the host system to use IPv4 TCP syncookies.
a Open the /etc/sysctl.conf to congure the host system.
b If the value is not set to 1, add the following entry to the le or update the existing entry
accordingly. Set the value to 1.
net.ipv4.tcp_syncookies=1
c Save the changes and close the le.
Configure the Host System to Deny IPv6 Router Advertisements
As a security best practice, verify that the host system denies the acceptance of router advertisements and
Internet Control Message Protocol (ICMP) redirects unless necessary. A feature of IPv6 is how systems can
congure their networking devices by automatically using information from the network. From a security
perspective, it is preferable to manually set important conguration information rather than accepting it
from the network in an unauthenticated way.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/accept_ra|egrep "default|all" command on the
host system to verify whether the system denies the acceptance of router advertisements and ICMP
redirects unless necessary.
2 Congure the host system to deny IPv6 router advertisements.
a Open the /etc/sysctl.conf le.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.accept_ra=0
net.ipv6.conf.default.accept_ra=0
c Save the changes and close the le.
48 VMware, Inc.
Chapter 4 Network Security and Secure Communication
Configure the Host System to Deny IPv6 Router Solicitations
As a security best practice, verify that host system denies IPv6 router solicitations unless necessary. The
router solicitations seing determines how many router solicitations are sent when bringing up the
interface. If addresses are assigned statically, there is no need to send any solicitations.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/router_solicitations|egrep "default|all"
command to verify whether the host system denies IPv6 router solicitations unless necessary.
2 Congure the host system to deny IPv6 router solicitations.
a Open the /etc/sysctl.conf.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.router_solicitations=0
net.ipv6.conf.default.router_solicitations=0
c Save the changes and close the le.
Configure the Host System to Deny IPv6 Router Preference in Router Solicitations
As a security best practice, verify that your host system denies IPv6 router solicitations unless necessary. The
router preference in the solicitations seing determines router preferences. If addresses are assigned
statically, there is no need to receive any router preference for solicitations.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/accept_ra_rtr_pref|egrep "default|all" on the
host system to verify whether the host system denies IPv6 router solicitations.
2 Congure the host system to deny IPv6 router preference in router solicitations.
a Open the /etc/sysctl.conf le.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.accept_ra_rtr_pref=0
net.ipv6.conf.default.accept_ra_rtr_pref=0
c Save the changes and close the le.
Configure the Host System to Deny IPv6 Router Prefix
As a security best practice, verify that the host system denies IPv6 router prex information unless
necessary. The accept ra pinfo seing controls whether the system accepts prex information from the
router. If addresses are statically assigned, the system does not receive any router prex information.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/accept_ra_pinfo|egrep "default|all" to verify if
that system denies IPv6 router prex information.
VMware, Inc. 49
Secure Configuration
2 Congure the host system to deny IPv6 router prex.
a Open the /etc/sysctl.conf le.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.accept_ra_pinfo=0
net.ipv6.conf.default.accept_ra_pinfo=0
c Save the changes and close the le.
Configure the Host System to Deny IPv6 Router Advertisement Hop Limit Settings
As a security best practice, verify that the host system denies IPv6 router advertisement Hop Limit seings
from a router advertisement unless necessary. The accept_ra_defrtr seing controls whether the system
will accept Hop Limit seings from a router advertisement. Seing it to 0 prevents a router from changing
your default IPv6 Hop Limit for outgoing packets.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/accept_ra_defrtr|egrep "default|all" command
to verify that the host system denies IPv6 router Hop Limit seings.
2 If the values are not set to 0, congure the host system to deny IPv6 router advertisement Hop Limit
seings.
a Open the /etc/sysctl.conf le.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.accept_ra_defrtr=0
net.ipv6.conf.default.accept_ra_defrtr=0
c Save the changes and close the le.
Configure the Host System to Deny IPv6 Router Advertisement Autoconf Settings
As a security best practice, verify that the host system denies IPv6 router advertisement autoconf seings.
The autoconf seing controls whether router advertisements can cause the system to assign a global unicast
address to an interface.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/autoconf|egrep "default|all" command to verify
whether the host system denies IPv6 router advertisement autoconf seings.
2 If the values are not set to 0, congure the host system to deny IPv6 router advertisement autoconf
seings.
a Open the /etc/sysctl.conf le.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.autoconf=0
net.ipv6.conf.default.autoconf=0
c Save the changes and close the le.
50 VMware, Inc.
Chapter 4 Network Security and Secure Communication
Configure the Host System to Deny IPv6 Neighbor Solicitations
As a security best practice, verify that the host system denies IPv6 neighbor solicitations unless necessary.
The dad_transmits seing determines how many neighbor solicitations are to be sent out per address
including global and link-local, when you bring up an interface to ensure the desired address is unique on
the network.
Procedure
1 Run the # grep [01] /proc/sys/net/ipv6/conf/*/dad_transmits|egrep "default|all" command to
verify whether the host system denies IPv6 neighbor solicitations.
2 If the values are not set to 0, congure the host system to deny IPv6 neighbor solicitations.
a Open the /etc/sysctl.conf le.
b If the values are not set to 0, add the following entries to the le or update the existing entries
accordingly. Set the value to 0.
net.ipv6.conf.all.dad_transmits=0
net.ipv6.conf.default.dad_transmits=0
c Save the changes and close the le.
Configure the Host System to Restrict IPv6 Maximum Addresses
As a security best practice, verify that the host restricts the maximum number of IPv6 addresses that can be
assigned. The maximum addresses seing determines how many global unicast IPv6 addresses can be
assigned to each interface. The default is 16 but you must set the number to the statically congured global
addresses required.
Procedure
1 Run the # grep [1] /proc/sys/net/ipv6/conf/*/max_addresses|egrep "default|all" command to
verify whether the host system restricts the maximum number of IPv6 addresses that can be assigned.
2 If the values are not set to 1, congure the host system to restrict the maximum number of IPv6
addresses that can be assigned.
a Open the /etc/sysctl.conf le.
b Add the following entries to the le or update the existing entries accordingly. Set the value to 1.
net.ipv6.conf.all.max_addresses=1
net.ipv6.conf.default.max_addresses=1
c Save the changes and close the le.
Configuring Ports and Protocols
As a security best practice, disable all non-essential ports and protocols.
Congure the minimum incoming and outgoing ports for vRealize Operations Manager components as
required for important system components to operate in production.
VMware, Inc. 51
Secure Configuration
Minimum Default Incoming Ports
As a security best practice, congure the incoming ports required for vRealize Operations Manager to
operate in production.
Table 4‑1. Minimum Required Incoming Ports
Port Protocol Comments
443 TCP Used to access the vRealize Operations Manager user
123 UDP Used by vRealize Operations Manager for Network
5433 TCP Used by the master and replica nodes to replicate the
7001 TCP Used by Cassandra for secure inter-node cluster
9042 TCP Used by Cassandra for secure client-related
6061 TCP Used by clients to connect to the GemFire Locator to get
10000-10010 TCP and UDP GemFire Server ephemeral port range used for unicast
20000-20010 TCP and UDP GemFire Locator ephemeral port range used for unicast
interface and the vRealize Operations Manager
administrator interface.
Time Protocol (NTP) synchronization to the master
node.
global database (vPostgreSQL ) when high availability is
enabled .
communication.
Do not expose this port to the internet. Add this port to a
rewall.
communication among nodes.
Do not expose this port to the internet. Add this port to a
rewall.
connection information to servers in the distributed
system. Also monitors server load to send clients to the
least-loaded servers.
UDP messaging and for TCP failure detection in a peerto-peer distributed system.
UDP messaging and for TCP failure detection in a peerto-peer distributed system.
Table 4‑2. Optional Incoming Ports
Port Protocol Comments
22 TCP Optional. Secure Shell (SSH). The SSH
service listening on port 22, or any
other port, must be disabled in a
production environment, and port 22
must be closed.
80 TCP Optional. Redirects to 443.
3091-3101 TCP When Horizon View is installed, used
to access data for
vRealize Operations Manager from
Horizon View.
52 VMware, Inc.
Auditing and Logging on your
vRealize Operations Manager System 5
As a security best practice, set up auditing and logging on your vRealize Operations Manager system.
The detailed implementation of auditing and logging is outside the scope of this document.
Remote logging to a central log host provides a secure store for logs. By collecting log les to a central host,
you can easily monitor the environment with a single tool. You can also perform aggregate analysis and
search for coordinated aacks on multiple entities within the infrastructure. Logging to a secure, centralized
log server can help prevent log tampering and also provide a long-term audit record.
This chapter includes the following topics:
“Securing the Remote Logging Server,” on page 53
n
“Use an Authorized NTP Server,” on page 53
n
“Client Browser Considerations,” on page 53
n
Securing the Remote Logging Server
As a security best practice, ensure that the remote logging server can be congured only by an authorized
user and is secure.
Aackers who breach the security of your host machine might search for and aempt to tamper with log
les to cover their tracks and maintain control without being discovered.
Use an Authorized NTP Server
Ensure that all the host systems use the same relative time source, including the relevant localization oset.
You can correlate the relative time source to an agreed-upon time standard such as Coordinated Universal
Time (UTC).
You can easily track and correlate an intruder's actions when you review the relevant log les. Incorrect time
seings can make it dicult to inspect and correlate log les to detect aacks, and can make auditing
inaccurate. You can use at the least three NTP servers from outside time sources or congure a few local
NTP servers on a trusted network that obtain their time from at least three outside time sources.
Client Browser Considerations
As a security best practice, do not use vRealize Operations Manager from untrusted or unpatched clients or
from clients that use browser extensions.
VMware, Inc.
53
Secure Configuration
54 VMware, Inc.
Index
A
administrative accounts 15
agent certificate revocation 40
apache configuration 28
Apache httpd 23
application resources, protect 26
auditing 53
authorized NTP server 53
B
best practices, End Point Operations
Management agents 36
Bluetooth protocol handler 29
boot loader authentication 19
browser considerations 53
C
cipher suites in GemFire 25
cipher suites in Apache httpd 25
client configuration, secure shell 18
configuration, PostgreSQL client
authentication 27
configuration modes, disable 29, 34, 35
configure 29
configure network settings for OVF 43
configure network time protocol 22
configure strong protocols 33, 34
console access 15
D
data in transit 23, 33, 34
Datagram Congestion Control Protocol 30
DECnet Protocol, secure 31
deny forwarding 47
deny ICMPv4 echoes to broadcast address 44
deny IPv6 router settings 50
deny IPv6 router advertisement hop limit 50
Diffie-Hellman 35
Diffie-Hellman key exchange 33
disable, unnecessary applications 41
disable browsing 28
disable direct logins 19
disable directory browsing 28
disable SSH access for the admin user
account 19
disable TCP timestamp response 22
disable the trace method:Apache2 server 28
disable unnecessary ports 41
disable unnecessary services 41
disable weak ciphers 33, 35
E
enabling FIPS 140-2 mode 22
End Point Operations Management agent 36
F
file permissions, secure shell 17
G
GemFire TLS handler protocols 23
glossary 5
H
hardening infrastructure 9
hardening for Linux installation 10
hardening for windows installation 10
hardening the vSphere environment 10
host server secure configuration 35
host server securely configured 34
host server's secure baseline 34
I
infrastructure, hardening 9
intended audience 5
inventory of unsupported software 10
IPV4 source routed packets 47
IPv4, deny 1Pv4 forwarding 46
IPv4, deny IPv4 ICMP redirects 45
IPv4, disable proxy ARP 44
IPv4, ignore ICMP redirect messages 44
IPv4, ignore IPv4 reverse path filtering 46
IPv4, log IPv4 Martian packets 46
IPv4, use IPv4 TCP syncookies 48
IPv6 autoconf settings 50
IPv6, deny IPv6 forwarding 47
IPv6, deny IPv6 neighbor solicitations 51
IPv6, deny IPv6 router advertisements 48
IPv6, deny IPv6 router prefix 49
IPv6, deny IPv6 router solicitations 49
VMware, Inc.
55
Secure Configuration
IPv6, deny IPv6 router preference in router
solicitations 49
IPv6, ignore ICMP redirect messages 45
IPv6, restrict IPv6 maximum addresses 51
K
kernel message logging 32
L
local administrative account, creating 16
logging 53
M
maintenance mode authentication 20
managing nonessential software 29
minimal necessary groups 20
minimal user accounts 20
minimum incoming ports 52
minimum permissions, agent functionality 36
monitor minimal necessary groups 20
monitor minimal user accounts 20
N
network settings 43
network time protocol 34
O
open ports on agent host 39
OVF, network settings 43
P
password expiry 15
patching 41
platform files and permissions, Linux 36
platform files and permissions, Windows 37
ports
incoming 43
outgoing 43
ports and protocols, configuring 51
prevent user control 43
R
reinstate an agent resource 40
remote logging server > securing 53
remove the agent resource 39
removing sample code:Apache2 server 28
resetting the password on Linux clusters 21
review installed software 10
revoking an agent 39
root password, change 14
root user, secure shell 15
S
secure
Appletalk Protocol 31
Firewire Module 31
Internet Packet Exchange Protocol 31
Reliable Datagram Sockets protocol 30
Transparent Inter-Process Communication
protocol 30
secure configuration 13
Secure Shell, restricting access 17
secure deployment of vRealize Operations
Manager 9
secure remote logging server 53
secure shell client configuration 18
secure shell file permissions 17
secure shell server configuration 17
Secure Shell, managing 15
secure the console 14
security posture 7
security advisories, patches 11
server configuration, secure shell 17
single-user authentication 20
Stream Control Transmission Protocol 29
strong protocols 33, 34
strong ciphers 33, 35
strong ciphers, configure 24
strong protocols, configure 23
T
TCP backlog queue size 43
third-party software 10
TLS for data in transit 23, 33, 34
U
unnecessary applications, delete 41
updates 41
updating certificates 40
USB mass storage handler 29
V
verify, server user account settings 41
verify secure baseline 34
verify server tokens:apache2 server 28
verifying the installation media 9
virtual appliances
Bluetooth protocol handler 29
boot loader authentication 19
configure network time protocol 22
enable or disable Secure Shell 16
USB mass storage handler 29
virtual machines, disable IPv4 proxy ARP 44
virtual machines, deny ICMPv4 echoes to
broadcast address 44
56 VMware, Inc.
vRealize Operations Manager administrative
password 21
W
weak ciphers, configure 33, 35
Windows time service 32
Index
VMware, Inc. 57
Secure Configuration
58 VMware, Inc.
Loading...
