Vizio M70-D3, M80-D3 User Manual
VIZIO
QUICK START GUIDE
M70-D3 & M80-D3
Please read this guide before using the product.
Safety Information - M-Series Display
IMPORTANT SAFETY INSTRUCTIONS
Your display is designed and manufactured to operate within dened design limits.
Misuse may result in electric shock or re. To prevent your display from being
damaged, the following instructions should be observed for the installation, use,
and maintenance of your display. Read the following safety instructions before
operating your display. Keep these instructions in a safe place for future reference.
• To reduce the risk of electric shock or component damage, switch o the power
before connecting other components to your display.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
• Unplug the power cord before cleaning your display.
• When moving your display from an area of low temperature to an area of high
temperature, condensation may form in the housing. Wait before turning on your
display to avoid causing re, electric shock, or component damage.
English - ii
• A distance of at least three feet should be maintained between your display and
any heat source, such as a radiator, heater, oven, amplier etc. Do not install your
display close to smoke. Operating your display close to smoke or moisture may
cause re or electric shock.
• Slots and openings in the back and bottom of the cabinet are provided for
ventilation. To ensure reliable operation of your display and to protect it from
overheating, be sure these openings are not blocked or covered. Do not place your
display in a bookcase or cabinet unless proper ventilation is provided.
• Never push any object into the slots and openings on your display cabinet. Do
not place any objects on the top of your display. Doing so could short circuit parts
causing a re or electric shock. Never spill liquids on your display.
• Your display should be operated only from the type of power source indicated on
the label. If you are not sure of the type of power supplied to your home, consult
your dealer or local power company.
• Do not apply pressure or throw objects at your display. This may compromise the
integrity of the display. The manufacturer’s warranty does not cover user abuse or
improper installations.
• The power cord must be replaced when using dierent voltage than the voltage
specied. For more information, contact your dealer.
• When connected to a power outlet, power is always owing into your display. To
totally disconnect power, unplug the power cord.
• Do not overload power strips and extension cords. Overloading can result in re
or electric shock.
• The wall socket should be installed near your display and easily accessible.
• Only power of the marked voltage can be used for your display. Any other voltage
than the specied voltage may cause re or electric shock.
• Do not touch the power cord during lightning. To avoid electric shock, avoid
handling the power cord during electrical storms.
• Unplug your display during a lightning storm or when it will not be used for long
period of time. This will protect your display from damage due to power surges.
• Do not attempt to repair or service your display yourself. Opening or removing the
back cover may expose you to high voltages, electric shock, and other hazards. If
repair is required, contact your dealer and refer all servicing to qualied service
personnel.
• WARNING: Keep your display away from moisture. Do not expose your display to
rain or moisture. If water penetrates into your display, unplug the power cord and
contact your dealer. Continuous use in this case may result in re or electric shock.
• Do not use your display if any abnormality occurs. If any smoke or odor becomes
apparent, unplug the power cord and contact your dealer immediately. Do not try
to repair your display yourself.
• Avoid using dropped or damaged appliances. If your display is dropped and the
housing is damaged, the internal components may function abnormally. Unplug the
power cord immediately and contact your dealer for repair. Continued use of your
display may cause re or electric shock.
• Do not install your display in an area with heavy dust or high humidity. Operating
h
your display in environments with heavy dust or high humidity may cause re or
electric shock.
• Follow instructions for moving your display. Ensure that the power cord and any
other cables are unplugged before moving your display.
• When unplugging your display, hold the AC/DC power adapter, not the cord. Pulling
on the power cord may damage the wires inside the cord and cause re or electric
shock. When your display will not be used for an extended period of time, unplug
the power cord.
• To reduce risk of electric shock, do not touch the connector with wet hands.
• Insert batteries in accordance with instructions. Incorrect polarities may cause the
batteries to leak which can damage the remote control or injure the operator. Do
not expose batteries to excessive heat such as sunshine, re or the like.
• If any of the following occurs, contact the dealer:
• The power cord fails or frays.
• Liquid sprays or any object drops into your display.
• Your display is exposed to rain or other moisture.
• Your display is dropped or damaged in any way.
• The performance of your display changes substantially.
• This apparatus shall not be exposed to dripping or splashing and no objects lled
with liquids, such as vases, shall be placed on the apparatus.
• The mains plug or appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
• CAUTION: These servicing instructions are for use by qualied service personnel
only. To reduce the risk of electric shock, do not perform any servicing other than
that contained in the operating instructions unless you are qualied to do so.
• The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
DANGEROUS VOLTAGE within the product’s enclosure that may be of
sucient magnitude to constitute a risk of electrical shock to persons.
• Please use caution around the display: pulling or pushing on the
display may cause the display to tip or fall over resulting in personal
injury and/or property damage.
• WARNING: Exposure to loud sounds can damage your hearing causing hearing
loss and tinnitus (ringing or buzzing in the ears). with continued exposure to loud
noises, ears may become accustomed to the sound level, which may result in
permanent damage to hearing without any noticeable discomfort.
• Install the TV where it cannot be pulled, pushed or knocked over.
• Do not allow children to hang onto the product.
• WARNING: This product includes small parts and cables that may present a choking
hazard to young children, and the packaging may cause suocation. Always keep
the cables, parts and packaging out of the reach of young children.
• Store the accessories (remote, batteries, etc.) in a location safely out of the reach
of children.
• The American Academy of Pediatrics discourages television viewing for children
younger than two years of age.
English - iii
Safety Information - Tablet Remote
Read all the safety information below before using your VIZIO Tablet Remote. For
additional information, read the User Manual available directly through the VIZIO
SmartCast™ application on your Tablet Remote.
Driving Safely
Use of your Tablet Remote while driving may cause distractions and may be prohibited
in some places. Always comply with local laws and regulations when driving. Driving
safely is your primary responsibility. If you do use your Tablet Remote while driving,
against the reconsecration of VIZIO, NEVER type or read content, navigate on the
Internet, or perform any other activity that takes your attention away from the road.
ALWAYS keep your eyes on the road and your hands on the wheel.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or strokes when exposed to
ashing lights such as when playing games or watching video, even if those conditions
have not been previously diagnosed. If you or anyone in your family has a history of
seizures or strokes, or if you have any other reason to think you or someone under your
supervision may be susceptible to epileptic seizures or strokes, consult a doctor before
playing games or watching video on your Tablet Remote. If you experience headaches,
blackouts, seizures, convulsion, eye or muscle twitching, loss of awareness, involuntary
movement, or disorientation stop using your Tablet Remote and consult a doctor. To
reduce risk hold your Tablet Remote at an arms-length distance from your eyes, use it in
a well-lit room, take frequent breaks and stop if you are tired.
Warning About Hearing Damage
Exposure to loud sounds can damage your hearing causing hearing loss and tinnitus
(ringing or buzzing in the ears). With continued exposure to loud noises, ears may
become accustomed to the sound level, which may result in permanent damage to
hearing without any noticeable discomfort.
LOUD SOUNDS + TIME = HEARING LOSS
The more time you spend exposed to loud sounds, the more likely you are to damage
your hearing.
• Limit the amount of time you spend using headphones, or earpieces.
• Do not turn up the volume to block out surrounding noise.
• If you can’t hear people speaking, turn down the volume.
If you experience a sensation of pressure or fullness in your ears, ringing in your ears,
or mued speech or believe you may have experienced noise induced hearing loss, and
you should have your hearing checked by an ear doctor.
Repetitive Motion
Repetitively performing actions such as pressing keys or typing, may result in occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your body. Take
breaks often and if you continue to have discomfort during or after such use, stop use
and see a doctor.
English - iv
Glass Parts
Your Tablet Remote may contain glass parts. Dropping your Tablet Remote on a hard
surface or a substantial impact to your Tablet Remote could break this glass. If the glass
breaks, do not touch or attempt to remove it. Stop using your Tablet Remote until the
glass is replaced by an authorized service center.
Potentially Explosive Atmosphere
When you are in an area with potentially explosive atmosphere turn o your Tablet
Remote. Do not remove, install, or charge batteries to avoid creating sparks that
can cause an explosion or re resulting in serious injury or even death. Areas with
potentially explosive atmospheres are often, but not always, clearly marked. Potential
areas may include fueling areas, fuel or chemical transfer or storage facilities, or areas
where the air contains chemicals or particles, such as grain dust, or metal powders, or
areas where you would normally be advised to turn o your engine.
Care and Maintenance
Do not use volatile solvents to clean this product. Such chemicals may damage it. To
clean product, gently wipe it with a clean, dry, soft cloth.
Battery Disposal and Recycling
You must dispose of this product properly, according to local laws and regulations.
Because this product contains electronic components and a battery, it must be disposed
of separately from household waste. Contact VIZIO or visit www.vizio.com/environment
to learn about disposal and recycling options.
Aircraft
Turn o your Tablet Remote whenever instructed to do so by airline sta. If your Tablet
Remote has an airplane mode or similar feature, consult airline sta about using it in
ight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or debrillator, consult with
your doctor before using your Tablet Remote. Persons with implantable medical devices
should observe the following precautions:
• When your Tablet Remote is ON, always keep it safely away from the implantable
medical device.
• Immediately turn your Tablet Remote OFF if you have any reason to suspect that
interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical device.
If you have any questions about using your Tablet Remote with your implantable medical
device, consult with your doctor.
Operating Temperature
Your Tablet Remote is designed to operate between the temperatures of 32° to 95° F (0°
to 35° C).
Award-Winning Customer Care At Your Convenience.
NEED HELP?
Go to: support.vizio.com
Find help with:
•
New product setup
• Connecting your devices
• Technical problems
• Product updates and more
Live chat
support available
You can also contact our
popular support team at:
Phone: (877) 698-4946 (toll-free)
Hours of Operation:
Monday - Friday: 7 am to 11 pm (CSt)
Saturday - Sunday: 9 am to 6 p m (CSt)
Se habla Español • Nous parlons Français
Table of Contents
Package Contents .........................................................................................................................7
This is your Tablet Remote ..........................................................................................................10
Charging your Tablet Remote. ......................................................................................................... 11
This is your basic remote .............................................................................................................12
Inserting and replacing batteries. ................................................................................................... 13
Installing the Display Stands .......................................................................................................14
First-Time Setup............................................................................................................................16
Sleep mode and unlocking the Tablet Remote. ........................................................................20
Getting familiar with Android™. ...................................................................................................21
Adding more Apps. .........................................................................................................22
Getting started with the VIZIO SmartCast
Account Setup .................................................................................................................................... 24
Selecting a Cast device ...................................................................................................................... 25
Basic display functions. .................................................................................................................... 26
Category Pages .................................................................................................................................. 27
Using your smartphone or tablet as a remote .........................................................................28
Minimum Recommended Requirements. ...................................................................................... 29
Getting started with the Google Cast. ........................................................................................30
How to cast content .......................................................................................................................... 31
Wall-mounting the Display ..........................................................................................................32
Additional connections ................................................................................................................34
Connecting an audio device ............................................................................................................. 34
Regulatory Information................................................................................................................36
Limited Warranty ..........................................................................................................................40
Legal Information .........................................................................................................................42
English - vi
™
app. ........................................................................24
Package Contents
VIZIO UHD Home
Theater Display
Multi-Language
Quick Start Guide
Display
Stands
6” Tablet
Remote
4 x Phillips
Screws
Power
Cable
Wireless
Charging Dock
HDMI
Cable
Power Adapter and
Micro-USB power cable
Basic Remote
w/Batteries
English - 7
Welcome to VIZIO SmartCast
Your new VIZIO Home Theater Display™ is part of the all-new collection of home
theater displays, sound bars and home audio speakers that can all be controlled by
one ingenious app: the VIZIO SmartCast app.
With the app, you can browse movies, TV shows, music and more from multiple
sources or apps in one view, without having to switch back and forth between those
apps or sources. And then just tap to cast the content to your VIZIO display - from
anywhere in your home. It works over WiFi, so you can control your VIZIO display
from any room, and keep using your VIZIO Tablet Remote to continue browsing,
play games, text or even watch another show, without disrupting what’s playing
on your display. With VIZIO SmartCast, what you love doesn’t change, but how you
experience it will never be the same.
Now let’s get you into setup so you can start casting!
™
!
English - 9
This is your Tablet Remote
The 6″ Android Tablet Remote brings the way
you interact up to speed with the rest of your
entertainment experience. Simply tap, swipe, or
use voice controls to access a library of casting
content.
In addition, it’s a Android tablet where you’ll
have access to thousands of apps and vast
library of content already available, creating an
amazing second screen experience.
English - 10
Volume
buttons
Power button
Left Front
Top
Bottom
Headphone port
Micro-USB
port
Charging your Tablet Remote.
Your Tablet Remote is charged and ready for
you to use. When you need to recharge the
battery, simply plug the Tablet Remote into a
power outlet using the USB power cable and
power adapter.
To charge your Tablet Remote using the wireless
charging dock, connect it to a wall outlet using
the USB cable and power adapter. Then simply
place the Tablet Remote on the dock.
Micro-USB power cable
Wireless charging dock
OR
Power adapter
Micro-USB
power cable
English - 11
This is your basic remote
English - 12
Turn the Display on or o.
POWER
LINK
Activate pairing mode
on display.
VOLUME
Increase or decrease the
loudness of the audio.
MUTE
Turn the audio on or o.
INPUT
Change the currently
displayed input.
ASPECT RATIO
Cycle through the dierent
aspect ratio modes.
CHANNEL UP/DOWN
Not supported on this model.
PIC
Cycles through the dierent
picture setting modes.
PLAY/PAUSE
Play and pause content.
Inserting and replacing batteries.
Two AAA batteries are included for you to use with
the basic remote control.
To insert/replace the batteries:
1. Find the notch on the back of the remote. Insert a
coin and pry open the back cover.
2. Remove the back cover and insert two AAA
batteries (included). Be sure to align the + and -
signs on the batteries and remote.
Visit http://support.vizio.com/ if you
have any questions.
1
WARNING: keep the remote control
batteries away from children. It may
cause choking and/or lead to a re or
chemical burn if mishandled. Do not
dispose of batteries in re. Replace only
with batteries of the correct type.
2
English - 13
Installing the Display Stands
1
It is recommended that two people take
part in the stand installation.
Remove any plastic lm from the Home Theater
Display and stands.
Place the display screen-down on a clean, at
surface. To prevent scratches or damage to
the screen, place the display on a soft surface
such as a carpet, rug, or blanket, and avoid any
sharp edges.
Make sure the top and bottom edges of the screen
are being supported by the surface to avoid damage.
English - 14
Î
P
Loading...
