Vivotek FE8181 Installation Guide
FE8181
Fixed Dome
Network Camera
Quick Installation Guide
繁中 日本語
English
Dansk
Indonesia
簡中
Français
Deutsch
Español Português
5MP • 360° Surround View • 10M IR • PoE
Italiano
Türkçe
Polski
Русский
Česky Svenska
Dutch
Warning Before Installation
English
Power off the Network Camera as
soon as smoke or unusual odors
are detected.
Do not place the Network Camera
on unsteady surfaces.
Do not insert sharp or tiny
objects into the Network Camera.
1
Package Contents
FE8181
Alignment Sticker
D
r
i
l
l
h
o
l
e
e
l
o
h
l
l
i
r
D
Refer to your user's manual for
the operating temperature.
Do not touch the Network Camera
during a lightning storm.
Do not drop the Network Camera.
Screws / Anchors / Cable tie
Software CD
5
1
0
G
0
0
1
0
2
0
Quick Installation Guide
Power & I/O Cables
(Sold Separately in US & Canada)
EN - 1
Physical Description
2
Inner View
Contacts
Lens
J7
J6
Headers
Cabling Cutout
Contacts for IR units
Ethernet 10/100 RJ45 Socket
Reset Button
Status LEDs
EN - 2
MicroSD/SDHC/SDXC Card Slot
Outer View
IR lights hidden beneath panel
English
Built-in Microphone
Dome Cover
IMPORTANT:
8181
083236
Record the MAC address under the
camera base before installing the
camera.
Hardware Installation
3
First, open the dome cover by pressing the release button. You may squeeze the opposite edge of
the dome cover if the dome cover does not come off easily. Then, follow the steps below to install the
camera to either a ceiling or a wall.
Slide cover
Release button
If you plan to route cables from the side of camera, remove the rubber slide cover from the dome cover.
EN - 3
