Vivotek FD8361L User Manual

VIVOTEK
Table of Contents
Overview.......................................................................................................................................................3
Installation ....................................................................................................................................................7
Hardware Installation �������������������������������������������������������������������������������������������������������������������������������7
Ready to Use �����������������������������������������������������������������������������������������������������������������������������������������14
Accessing the Network Camera .................................................................................................................16
Main Page ..................................................................................................................................................21
Client Settings ............................................................................................................................................25
Conguration ..............................................................................................................................................27
Video �����������������������������������������������������������������������������������������������������������������������������������������������������56
Homepage Layout ��������������������������������������������������������������������������������������������������������������������������������� 76
Appendix ..................................................................................................................................................105
Technical Specications ����������������������������������������������������������������������������������������������������������������������155
2 - User's Manual
VIVOTEK
Overview
VIVOTEK’s FD8361L is the latest professional-series outdoor fixed dome network camera featuring
superb megapixel image quality and exceptional bandwidth efciency. With day & night functionality and
a weatherproof housing, it is especially suitable for tough outdoor surveillance environments such as parking lots and streets�
Featuring a 2-megapixel sensor, the FD8361L is able to provide extremely wide coverage with the nest
details� Additionally, the camera is incorporated with high performance H�264 compression technology,
and has adopted a number of innovative bandwidth-efcient technologies built into the camera, including
cropping, ePTZ, and activity adaptive streaming� In order to adapt to constantly changing outdoor lighting conditions, the FD8361L features an auto-iris lens to protect from damage induced by direct sunlight� The camera also comes with a removable IR-cut
lter and IR illuminators for superior image quality around the clock. For protection against the elements,
the camera is furnished with an IP66-rated housing and vandal-proof casing to withstand rain, dust, and vandalism� The PoE-powered heater and fan further enhance the FD8361L’s performance and reliability in extremely cold and warm weather� The integrated BNC connector allowing the FD8361 to be connected directly to an analog monitor provides enhanced flexibility and usability and ease of installation� Other advanced features include a 3-axis mechanism for flexible installation, 802�3af PoE, SD/SDHC card slot, and tamper detection� With the included ST7501 32-CH recording software, the FD8361 is the ultimate camera for demanding outdoor environments�
Read Before Use
The use of surveillance devices may be prohibited by law in your country� The Network Camera is not
only a high-performance web-ready camera but can also be part of a exible surveillance system. It is
the user’s responsibility to ensure that the operation of such devices is legal before installing this unit for its intended use�
It is important to rst verify that all contents received are complete according to the Package Contents
listed below� Take note of the warnings in the Quick Installation Guide before the Network Camera is installed; then carefully read and follow the instructions in the Installation chapter to avoid damage due to faulty assembly and installation� This also ensures the product is used properly as intended�
The Network Camera is a network device and its use should be straightforward for those who have basic networking knowledge� It is designed for various applications including video sharing, general security/ surveillance, etc� The Configuration chapter suggests ways to best utilize the Network Camera and ensure proper operations� For creative and professional developers, the URL Commands of the Network Camera section serves as a helpful reference to customizing existing homepages or integrating with the current web server�
Package Contents
■ FD8361L
■ Bottom Base
■ Alignment Sticker / Ceiling Hole Template Sticker
■ L-type Hex Key Wrench / RJ45 Female/Female Coupler / Silica Gel / Screws
■ Quick Installation Guide / Warranty Card
■ Software CD
User's Manual - 3
VIVOTEK
Physical Description
Inner View
Vari-focal Lens (f= 3~9 mm)
SD/SDHC Card Slot
Status LED Recessed Reset Button
Focus Controller
Zoom Controller
AC24V AC24V
IR LEDs (18 units, distance 20m)
Light Sensor
Rotation Adjustment Screw
Tilt Adjustment Screw
Pan Adjustment Screw
NTSC/PAL Video Output Switch
BNC Video Output
General I/O Terminal Block
Ethernet 10/100 RJ45 Plug
Ground
4 - User's Manual
Operating environment: -20° ~ 50°C
When the temparature inside the Network Camera reaches over 50°C, the fan will operate automatically; when the temparature inside the Network Camera drops to 0°C, the heater and fan will both operate automatically�
Fan
Heater
Outer View
AC24V AC24V
Camera Base
IP66-rated Vandal-proof Dome Cover
AC24V AC24V
VIVOTEK
c
b
a
IP66-rated Vandal-proof Bottom Base
c
Record the MAC address under the camera base before installing the camera�
Network Camera
Model No: FD8361
MAC:0002D1083236
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
RoHS
Made in Taiwan
V I
CLASS A
a
Hole a~c: Holes to secure the bottom base�
b
General I/O Terminal Block
This Network Camera provides a general I/O terminal block which is used to connect external
input / output devices. The pin denitions are described below.
AC24V
AC24V
AC24V: Power in AC 24V AC24V: Power in AC 24V
Pin Name Specification AC24V Power in AC 24V AC 24V ± 5% AC24V Power in AC 24V AC 24V ± 5%
User's Manual - 5
VIVOTEK
Hardware Reset
SD/SDHC Card Slot
Status LED Recessed Reset
Button
The reset button is used to reset the system or restore the factory default settings� Sometimes resetting the system can return the camera to normal operation� If the system problems remain after reset, restore the factory settings and install again�
Reset: Press and release the recessed reset button with a paper clip or thin object� Wait for the Network Camera to reboot�
Restore: Press and hold the recessed reset button until the status LED rapidly blinks� Note that all settings will be restored to factory default� Upon successful restore, the status LED will blink green and red during normal operation�
SD/SDHC Card Capacity
This network camera is compliant with SD/SDHC 32GB and other preceding standard SD cards�
6 - User's Manual
VIVOTEK
Installation
Hardware Installation
First, use a screwdriver to loose the three screws and detach the dome cover from the camera base� Then, follow the steps below to install the camera to either a ceiling or a wall�
AC24V AC24V
Ceiling mount (with the bottom base)
1� Attach the supplied alignment sticker to the ceiling� 2� Using the 10 circles on the sticker, drill at least 2 pilot holes symmetrically on each side into
the ceiling� Then hammer the four supplied plastic anchors into the holes�
3� Through the four holes on the bottom base, insert the four supplied screws into the corre-
sponding holes and secure the bottom base with a screwdriver�
4� Feed the cables through hole A or B� If you want to use hole B, remove the rubber stopper
with a screwdriver�
5� Secure the camera base to the bottom base with three supplied screws�
A
1
2
4
B
5
3
User's Manual - 7
VIVOTEK
Wall mount (with the bottom base)
1� Attach the supplied alignment sticker to the wall� 2� Using the 10 circles on the sticker, drill at least 2 pilot holes symmetrically on each side into
the wall� Then hammer the four supplied plastic anchors into the holes�
3� Using the four holes on the bottom base, insert the four supplied screws to corresponding
holes and secure the bottom base with a screwdriver�
4� Feed the cables through hole A or B� If you want to use hole B, remove the rubber stopper
with a screwdriver�
5� Secure the camera base to the bottom base with three supplied screws�
1
3
2
4
A
B
5
8 - User's Manual
VIVOTEK
Drop-ceiling mount (without the bottom base)
1� Attach the supplied ceiling hole template sticker to the ceiling� 2� Open a hole along the inner circle of the sticker� 3� Using the 3 circles on the sticker, drill 3 pilot holes into the ceiling� Then hammer the three
supplied plastic anchors into the holes� 4� Mount the Network Camera to the ceiling and feed the cables through� 5� Using the three holes on the side of the camera base, insert the three supplied screws into
the corresponding holes and secure them with a screwdriver�
5
4
1
2
Drill hole
Ceiling Hole Template Sticker
3
NOTE
► The ground wire is directly connected and xed on the FD8361 housing as shown below.
GND
User's Manual - 9
VIVOTEK
L
A
N (
Local Area Network)
R
o
u
t
e
r
I
P
a
d
dre
s
s
W
A
N (Wide Area Network )
R
o
u
t
e
r
I
P
a
d
dre
s
s
f
r
o
m
I
S
P
Network Deployment
Setting up the Network Camera over the Internet
This section explains how to congure the Network Camera to an Internet connection�
1� Connect the power cable to the AC 24V terminal block�
2. Use the supplied RJ45 female/female coupler to connect the Network Camera to a switch.
Use a Category 5 Cross Cable when Network Camera is directly connected to PC�
AC24V
AC24V
AC24V AC24V
AC24V: Power in AC 24V AC24V: Power in AC 24V
POW
ER
L I
N
C
O
LL
I S
K
RE
ION
CEIVE
1
PARTITIO
2
3
N
4
5
There are several ways to set up the Network Camera over the Internet� The rst way is to set up the Network Camera behind a router� The second way is to utilize a static IP� The third way is to use PPPoE�
Internet connection via a router
Before setting up the Network Camera over the Internet, make sure you have a router and follow the steps below�
1� Connect your Network Camera behind a router, the Internet environment is illustrated below�
Regarding how to obtain your IP address, please refer to Software Installation on page 13 for details�
IP address : 192.168.0.3 Subnet mask : 255.255.255.0 Default router : 192.168.0.1
IP address : 192.168.0.2 Subnet mask : 255.255.255.0 Default router : 192.168.0.1
10 - User's Manual
Internet
Cable or DSL Modem
WAN (Wide Area Network ) Router IP address : from ISP
LINK
POWER
COLLISION
RECEIVE
1
2
PARTITION
3
4
5
LAN (Local Area Network) Router IP address : 192.168.0.1
VIVOTEK
2� In this case, if the Local Area Network (LAN) IP address of your Network Camera is 192�168�0�3, please forward the following ports for the Network Camera on the router�
■ HTTP port
■ RTSP port
■ RTP port for video
■ RTCP port for video
If you have changed the port numbers on the Network page, please open the ports accordingly on your router� For information on how to forward ports on the router, please refer to your router’s user’s manual�
3� Find out the public IP address of your router provided by your ISP (Internet Service Provider)� Use the public IP and the secondary HTTP port to access the Network Camera from the Internet� Please refer to Network Type on page 37 for details�
Internet connection with static IP
Choose this connection type if you are required to use a static IP for the Network Camera� Please refer to LAN on page 37 for details�
Internet connection via PPPoE (Point-to-Point over Ethernet)
Choose this connection type if you are connected to the Internet via a DSL Line� Please refer to PPPoE on page 38 for details�
User's Manual - 11
VIVOTEK
Set up the Network Camera through Power over Ethernet (PoE)
When using a PoE-enabled switch
The Network Camera is PoE-compliant, allowing transmission of power and data via a single Ethernet cable� Follow the below illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable�
AC24V AC24V
power + data transmission
POWER
COLLISION
1
LINK
RECEIVE
2
PARTITION
3
4
5
PoE Switch
When using a non-PoE switch
If your switch/router does not support PoE, use a PoE power injector (optional) to connect between the Network Camera and a non-PoE switch�
AC24V AC24V
12 - User's Manual
PoE Power Injector
(optional)
POWER
COLLISION
1
2
3
4
5
Non-PoE Switch
LINK
RECEIVE
PARTITION
VIVOTEK
Software Installation
Installation Wizard 2 (IW2), free-bundled software included on the product CD, helps you set up your Network Camera on the LAN�
1� Install IW2 under the Software Utility directory from the software CD� Double click the IW2 shortcut on your desktop to launch the program�
2� The program will conduct an analysis of your network environment� After your network environment is analyzed, please click Next to continue the program�
3� The program will search for all VIVOTEK network devices on the same LAN�
4� After searching, the main installer window will pop up� Click on the MAC and model name which matches the product label on your device to connect to the Network Camera via Internet Explorer�
Network Camera
Model No: FD8361L
RoHS
MAC:0002D1730202
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
V I
CLASS A
Made in Taiwan
00-02-D1-73-02-02 192.168.5.151 FD8361L
0002D1730202
User's Manual - 13
VIVOTEK
Ready to Use
1� Access the Network Camera on the LAN� 2� Retrieve live video through a web browser or recording software�
Adjusting the Lens
Based on the live image retrieved from the camera, adjust the camera lens by doing the following:
To adjust the viewing angle -- 3-axis mechanism design
1� Loosen the pan adjustment screw and then turn the lens module left and right� Upon
completion, tighten the screw�
2� Loosen the tilt adjustment screws on both side of the camera and then turn the lens module
up and down� Upon completion, tighten the screws�
3� Loosen the rotation adjustment screw and then turn the lens to adjust the image orientation�
Upon completion, tighten screw�
The sophisticated 3-axis mechanism
Rotate the screw Turn the lens
Loosen
1
Tighten
Loosen
2
Tighten
design offers very flexible, easy hardware installation for either ceiling or wall mount�
Loosen
Tighten
3
14 - User's Manual
Pan 350°
Tilt 85°
Rotate 350°
VIVOTEK
To adjust the zoom factor and focus range
1� Loosen the zoom controller to adjust the zoom factor� Upon completion, tighten the zoom
controller�
2� Loosen the focus controller to adjust the focus range� Upon completion, tighten the focus
controller�
AV Out
Audio In
Ext PAL
1 2
ON
Int. NTSC
1 2 3 4
Loosen
W
T
N
Tighten
8
DO NOT over rotate the lens� Doing so will damage the camera lens module
Completion
1. Rotate the black cover inside the dome cover to t the lens shooting direction.
2� Attach the dome cover to camera� 3� Secure the two dome screws with a screwdriver� Finally, make sure all parts of the camera are
securely installed�
2
1
3
3
3
User's Manual - 15
VIVOTEK
Accessing the Network Camera
This chapter explains how to access the Network Camera through web browsers, RTSP players, 3GPP-compatible mobile devices, and VIVOTEK recording software�
Using Web Browsers
Use Installation Wizard 2 (IW2) to access to the Network Cameras on the LAN� If your network environment is not a LAN, follow these steps to access the Network Camera: 1� Launch your web browser (ex� Microsoft
2. Enter the IP address of the Network Camera in the address eld. Press Enter� 3� The live video will be displayed in your web browser�
4. If it is the rst time installing the VIVOTEK network camera, an information bar will pop up as
shown below� Follow the instructions to install the required plug-in on your computer�
®
Internet Explorer, Mozilla Firefox, or Netscape)�
NOTE
► For Mozilla Firefox or Netscape users, your browser will use Quick Time to stream the live
video. If you donn’t have Quick Time on your computer, please download it rst, then launch
the web browser�
16 - User's Manual
VIVOTEK
► By default, the Network Camera is not password-protected. To prevent unauthorized access,
it is highly recommended to set a password for the Network Camera� For more information about how to enable password protection, please refer to Security on page 30�
► If you see a dialog box indicating that your security settings prohibit running ActiveX
®
Controls, please enable the ActiveX
Controls for your browser�
®
1� Choose Tools > Internet Options > Security > Custom Level�
2. Look for Download signed ActiveX
®
controls; select Enable or Prompt� Click OK�
3. Refresh your web browser, then install the Active X
complete installation�
®
control� Follow the instructions to
User's Manual - 17
VIVOTEK
Using RTSP Players
To view the MPEG-4 streaming media using RTSP players, you can use one of the following players that support RTSP streaming�
Quick Time Player
Real Player
VLC media player 1� Launch the RTSP player�
mpegable Player
2� Choose File > Open URL� A URL dialog box will pop up� 3� The address format is rtsp://<ip address>:<rtsp port>/<RTSP streaming access name for
pvPlayer
stream1 or stream2>
As most ISPs and players only allow RTSP streaming through port number 554, please set the RTSP port to 554� For more information, please refer to RTSP Streaming on page 49� For example:
rtsp://192.168.5.151:554/live.sdp
4� The live video will be displayed in your player�
For more information on how to configure the RTSP access name, please refer to RTSP
Streaming on page 49 for details�
Video 16:38:01 2009/10/03
18 - User's Manual
VIVOTEK
Using 3GPP-compatible Mobile Devices
To view the streaming media through 3GPP-compatible mobile devices, make sure the Network Camera can be accessed over the Internet� For more information on how to set up the Network Camera over the Internet, please refer to Setup the Network Camera over the Internet on page 10�
To utilize this feature, please check the following settings on your Network Camera:
1� Because most players on 3GPP mobile phones do not support RTSP authentication, make
sure the authentication mode of RTSP streaming is set to disable� For more information, please refer to RTSP Streaming on page 49�
2� As the the bandwidth on 3G networks is limited, you will not be able to use a large video size�
Please set the video streaming parameters as listed below�
For more information, please refer to Viewing Window on page 62�
Video Mode MPEG-4 Frame size 176 x 144 Maximum frame rate 5 fps Intra frame period 1S Video quality (Constant bit rate) 40kbps
3� As most ISPs and players only allow RTSP streaming through port number 554, please set
the RTSP port to 554� For more information, please refer to RTSP Streaming on page 49�
4� Launch the player on the 3GPP-compatible mobile devices (ex� Real Player)�
5� Type the following URL commands into the player�
The address format is rtsp://<public ip address of your camera>:<rtsp port>/<RTSP streaming access name for stream 3>�
For example:
rtsp://192.168.5.151:554/live.sdp
User's Manual - 19
VIVOTEK
Using VIVOTEK Recording Software
The product software CD also contains recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras� Please install the recording software; then launch the program to add the Network Camera to the Channel list� For detailed information about how to use the recording software, please refer to the user’s manual of the software or download it from http://www�vivotek�com�
20 - User's Manual
VIVOTEK
Main Page
This chapter explains the layout of the main page� It is composed of the following sections: VIVOTEK INC� Logo, Host Name, Camera Control Area, Configuration Area, Menu, and Live Video Window�
VIVOTEK INC. Logo
Camera Control Area
Configuration Area
VIVOTEK INC. Logo
Click this logo to visit the VIVOTEK website�
Host Name
The host name can be customized to t your needs. For more information,
28�
please refer to
Host Name
Live View Window
System on page
Camera Control Area
Video Stream: This Network Cmera supports multiple streams (stream 1 ~ 4) simultaneously� You can select either one for live viewing� For more information about multiple streams, please refer to page 62 for detailed information�
IR Illuminators: Click to turn on the IR LEDs for 20 seconds�
PTZ Panel: This Network Camera supports “digital“ (e-PTZ) pan/tilt/zoom control� Please refer to Camera Control on page 72 for detailed information�
Global View: Click on this item to display the Global View window� The Global View window contains a full view image (the largest frame size of the captured
video) and a oating frame (the viewing region of the
curruent video stream)� The floating frame allows users to control the e-PTZ function (Electronic Pan/Tilt/Zoom)� For more information about e-PTZ operation, please refer to E-PTZ Operation on page 72� For more information about how to set up the viewing region of the current video stream, please refer to Viewing Windows on page 62�
The viewing region of the current video stream
The largest frame size
User's Manual - 21
VIVOTEK
Conguration Area
Client Settings: Click this button to access the client setting page� For more information, please refer to Client Settings on page 25�
Conguration: Click this button to access the conguration page of the Network Camera. It is suggested
that a password be applied to the Network Camera so that only the administrator can configure the Network Camera� For more information, please refer to Conguration on page 27�
Language: Click this button to choose a language for the user interface� Language options are available in: English, Deutsch, Español, Français, Italiano,
日本語
, Português,
簡体中文
, and
繁體中文
�
Live Video Window
■ The following window is displayed when the video mode is set to H�264 / MPEG-4:
MPEG-4 Protocol and Media Options
Video Title
Title and Time
2010/10/30 13:44:17
Video 13:44:17 2010/10/30
Time
Video Control Buttons
Video Title: The video title can be congured. For more information, please refer to Video Settings on page 56�
H�264 / MPEG-4 Protocol and Media Options: The transmission protocol and media options for H�264 / MPEG-4 video streaming. For further conguration, please refer to Client Settings on page 25�
Time: Display the current time. For further conguration, please refer to Video Settings on page 56�
Title and Time: The video title and time can be stamped on the streaming video. For further conguration, please refer to Video Settings on page 56�
Video Control Buttons: Depending on the Network Camera model and Network Camera conguration, some buttons may not be available�
Snapshot: Click this button to capture and save still images� The captured images will be displayed
in a pop-up window� Right-click the image and choose Save Picture As to save it in JPEG (*.jpg) or BMP
(*.bmp) format.
Digital Zoom: Click and uncheck “Disable digital zoom” to enable the zoom operation� The navigation
screen indicates the part of the image being magnied. To control the zoom level, drag the slider bar. To
move to a different area you want to magnify, drag the navigation screen�
22 - User's Manual
VIVOTEK
Pause: Pause the transmission of the streaming media� The button becomes the Resume button
after clicking the Pause button�
Stop: Stop the transmission of the streaming media� Click the Resume button to continue
transmission�
Start MP4 Recording: Click this button to record video clips in MP4 file format to your computer�
Press the
Stop MP4 Recording button to end recording� When you exit the web browser, video
recording stops accordingly. To specify the storage destination and le name, please refer to MP4 Saving Options on page 26 for details�
Full Screen: Click this button to switch to full screen mode� Press the “Esc” key to switch back to normal
mode�
■ The following window is displayed when the video mode is set to MJPEG:
Video Title
Title and Time
Video Control Buttons
2010/10/30 13:44:17
Video 13:44:17 2010/10/30
Time
Video Title: The video title can be congured. For more information, please refer to Video Settings on page 56�
Time: Display the current time� For more information, please refer to
Video Settings on page 56�
Title and Time: Video title and time can be stamped on the streaming video� For more information, please refer to Video Settings on page 56�
Video Control Buttons: Depending on the Network Camera model and Network Camera conguration, some buttons may not be available�
Snapshot: Click this button to capture and save still images� The captured images will be displayed
in a pop-up window� Right-click the image and choose Save Picture As to save it in JPEG (*.jpg) or BMP
(*.bmp) format.
Digital Zoom: Click and uncheck “Disable digital zoom” to enable the zoom operation� The navigation
screen indicates the part of the image being magnied. To control the zoom level, drag the slider bar. To
move to a different area you want to magnify, drag the navigation screen�
User's Manual - 23
VIVOTEK
Start MP4 Recording: Click this button to record video clips in MP4 file format to your computer�
Press the
Stop MP4 Recording button to end recording� When you exit the web browser, video
recording stops accordingly. To specify the storage destination and le name, please refer to MP4 Saving Options on page 26 for details�
Full Screen: Click this button to switch to full screen mode� Press the “Esc” key to switch back to
normal mode�
24 - User's Manual
VIVOTEK
Client Settings
This chapter explains how to select the stream transmission mode and saving options on the local computer� When completed with the settings on this page, click Save on the page bottom to enable the settings�
H.264 / MPEG-4 Protocol Options
H.264/MPEG-4 Protocol Options
Depending on your network environment, there are four transmission modes of H�264 or MPEG-4 streaming:
UDP unicast: This protocol allows for more real-time video streams� However, network packets may be
lost due to network burst trafc and images may be broken. Activate UDP connection when occasions
require time-sensitive responses and the video quality is less important� Note that each unicast client connecting to the server takes up additional bandwidth and the Network Camera allows up to ten simultaneous accesses�
UDP multicast: This protocol allows multicast-enabled routers to forward network packets to all clients requesting streaming media� This helps to reduce the network transmission load of the Network Camera while serving multiple clients at the same time� Note that to utilize this feature, the Network Camera must be configured to enable multicast streaming at the same time� For more information, please refer to RTSP Streaming on page 49�
TCP: This protocol guarantees the complete delivery of streaming data and thus provides better video quality� The downside of this protocol is that its real-time effect is not as good as that of the UDP protocol�
HTTP: This protocol allows the same quality as TCP protocol without needing to open specic ports for streaming under some network environments� Users inside a firewall can utilize this protocol to allow streaming data through�
User's Manual - 25
VIVOTEK
MP4 Saving Options
Users can record live video as they are watching it by clicking Start MP4 Recording on the main
page. Here, you can specify the storage destination and le name.
Folder: Specify a storage destination for the recorded video les.
File name prex: Enter the text that will be appended to the front of the video le name.
Add date and time sufx to the le name: Select this option to append the date and time to the end of the le name.
CLIP_20100811-180853
File name prefix
Date and time suffix
The format is: YYYYMMDD_HHMMSS
Local Streaming Buffer Time
Due to the unsteady bandwidth ow, the live streaming may lag and not be very smoothly. If you enable
this option, the live streaming will be stored on the camera’s buffer area for a few seconds before playing on the live viewing window� This will help you see the streaming more smoothly� If you enter 3000 Millisecond, the streaming will delay 3 seconds�
26 - User's Manual
VIVOTEK
Conguration
Click Configuration on the main page to enter the camera setting pages� Note that only
Administrators can access the conguration page.
VIVOTEK offers an easy-to-use user interface that helps you set up your network camera with minimal effort� To simplify the setting procedure, two types of user interfaces are available: Advanced Mode for professional users and Basic Mode for entry-level users� Some advanced functions (HTTPS/ SNMP/ Access list/ Homepage layout/ Application/ Recording/ System log/ View parameters) are not displayed in Basic Mode�
If you want to set up advanced functions, please click [Advanced Mode] on the bottom of the
conguration list to quickly switch to Advanced Mode.
In order to simplify the user interface, the detailed information will be hidden unless you click on
the function item. When you click on the rst sub-item, the detailed information for the rst sub-
item will be displayed; when you click on the second sub-item, the detailed information for the
second sub-item will be displayed and that of the rst sub-item will be hidden.
The following is the interface of the Basic Mode and the Advanced Mode:
Basic Mode
Configuration List
Click to switch to Advanced Mode
Firmware Version
User's Manual - 27
VIVOTEK
Advanced Mode
Configuration List
Click to switch to Basic Mode
Firmware Version
Each function on the conguration list will be explained in the following sections. Those functions that are
displayed only in Advanced Mode are marked with
Advanced Mode
� If you want to set up advanced
functions, please click [Advanced Mode] on the bottom of the conguration list to quickly switch over.
System
This section explains how to congure the basic settings for the Network Camera, such as the
host name and system time� It is composed of the following three columns: System, System Time and DI and DO. When nished with the settings on this page, click Save at the bottom of the page to enable the settings�
System
Host name: Enter a desired name for the Network Camera� The text will be displayed at the top of the main page�
Turn off the LED indicators: If you do not want to let others know that the network camera is in operation, you can select this option to turn off the LED indicators�
28 - User's Manual
VIVOTEK
System Time
Keep current date and time: Select this option to preserve the current date and time of the Network Camera� The Network Camera’s internal real-time clock maintains the date and time even when the power of the system is turned off�
Synchronize with computer time: Select this option to synchronize the date and time of the Network Camera with the local computer� The read-only date and time of the PC is displayed as updated�
Manual: The administrator can enter the date and time manually� Note that the date and time format are [yyyy/mm/dd] and [hh:mm:ss]�
Automatic: The Network Time Protocol is a protocol which synchronizes computer clocks by periodically querying an NTP Server�
NTP server: Assign the IP address or domain name of the time-server� Leaving the text box blank connects the Network Camera to the default time servers�
Update interval: Select to update the time using the NTP server on an hourly, daily, weekly, or monthly basis�
Time zone
Advanced Mode
: Select the appropriate time zone from the list� If you want to upload
Daylight Savings Time rules on the Maintenance page, please refer to Upload / Export Daylight Saving Time Conguration File on page 102 for details�
User's Manual - 29
VIVOTEK
Security
This section explains how to enable password protection and create multiple accounts�
Root Password
The administrator account name is “root”, which is permanent and can not be deleted� If you want to add
more accounts in the Manage User column, please apply the password for the “root” account rst.
1� Type the password identically in both text boxes, then click Save to enable password protection� 2� A window will be prompted for authentication; type the correct user’s name and password in their
respective elds to access the Network Camera.
Manage Privilege
Digital Output & IR illuminators / PTZ control: You can modify the manage privilege of operators or viewers� Check or uncheck the item, then click Save to enable the settings� If you give Viewers the privilege, Operators will also have the ability to control the Network Camera through the main page� (Please refer to Main Page on page 21�)
Allow anonymous viewing: If you check this item, any client can access the live stream without entering a User ID and Password�
Advanced Mode
Manage User
Administrators can add up to 20 user accounts� 1� Input the new user’s name and password� 2� Select the privilege level for the new user account� Click Add to enable the setting�
Access rights are sorted by user privilege (Administrator, Operator, and Viewer)� Only administrators can
access the Conguration page. Though operators cannot access the Conguration page, they can use
the URL Commands to get and set the value of parameters� For more information, please refer to URL Commands of the Network Camera on page 105� Viewers access only the main page for live viewing�
Here you also can change a user’s access rights or delete user accounts� 1� Select an existing account to modify� 2� Make necessary changes and click Update or Delete to enable the setting�
30 - User's Manual
Loading...
+ 126 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
