Vivotek FD7141, FD7141V User Manual

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

2 - User's Manual

Table of Contents

Overview.......................................................................................................................................................3

Read Before Use ��3

Package Contents �� 3

Physical Description �� 4

Installation ....................................................................................................................................................8

Hardware Installation ��8

Network Deployment �� 10

Software Installation �� 13

Ready to Use ��14

Adjusting the Lens ��14

Completion ��15

Accessing the Network Camera .................................................................................................................16

Using Web Browsers ��16

Using RTSP Players ��18

Using 3GPP-compatible Mobile Devices ��19

Using VIVOTEK Recording Software �� 20

Main Page ..................................................................................................................................................21

Client Settings ............................................................................................................................................25

Conguration ..............................................................................................................................................27

System ��28

Security ��30

HTTPS ��31

Network ��36

DDNS ��47

Access List ��49

Audio and Video �� 52

Motion Detection ��60

Homepage Layout �� 64

Application ��67

Recording �� 80

System Log ��83

View Parameters �� 84

Maintenance ��85

Appendix ....................................................................................................................................................89

URL Commands for the Network Camera ��89

Technical Specications ��127

Technology License Notice ��128

Electromagnetic Compatibility (EMC) ��129

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 3

Overview

VIVOTEK FD7141 is a professional-grade vandal and weather-proof fixed dome network camera integrating the latest features required for outdoor surveillance into a discreet, compact package� The FD7141’s IP66 rating ensures protection from water and dust and its vandal-proof design provides additional protection in high risk environments� With the built-in heater and fan, the FD7141 can also operate in an extended temperature range required by many of today’s demanding installations�

Boasting a Wide Dynamic Range CMOS sensor, the FD7141 can cope with challenging lighting conditions and provide image quality superior to other products in its class� The camera

delivers true day and night functionality with a removable IR-cut lter and built-in IR illuminators.

Installation is also suited for both wall and ceiling with the unique 3-axis rotation design�

The FD7141 supports tamper detection, which detects video loss from events such as blockage or spray-painting� Also incorporated are advanced features including simultaneous dual streams, 802�3af compliant PoE, two-way audio via SIP protocol, built-in SD/SDHC card slot, drop-ceiling mount, and HTTPS encrypted data transmission for a robust outdoor security solution�

Read Before Use

The use of surveillance devices may be prohibited by law in your country� The Network Camera

is not only a high-performance web-ready camera but can also be part of a exible surveillance

system� It is the user’s responsibility to ensure that the operation of such devices is legal before installing this unit for its intended use�

It is important to rst verify that all contents received are complete according to the Package

Contents listed below� Take note of the warnings in the Quick Installation Guide before the Network Camera is installed; then carefully read and follow the instructions in the Installation chapter to avoid damage due to faulty assembly and installation� This also ensures the product is used properly as intended�

The Network Camera is a network device and its use should be straightforward for those who have basic networking knowledge� It is designed for various applications including video sharing,

general security/surveillance, etc. The Conguration chapter suggests ways to best utilize the

Network Camera and ensure proper operations� For creative and professional developers, the

URL Commands of the Network Camera section serves as a helpful reference to customizing

existing homepages or integrating with the current web server�

Package Contents

■ FD7141(V)

■ Bottom Base / Plastic Cover (FD7141V only)

■ Power Adapter

■ Alignment Sticker / Ceiling Hole Template Sticker

■ L-type Hex Key Wrench / RJ45 Female/Female Coupler / Slica Gel / Screws

■ Quick Installation Guide

■ Warranty Card

■ Software CD

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

4 - User's Manual

Physical Description

Tilt Screw

SD Card

Slot

IR LEDs

Recessed Reset Button

Status LED

Light Sensor

Pan Screw

Lens

Inner View

N.C.

AC24V AC24V

Focus Controller

Zoom Controller

Image Adjustment Screw

Ethernet 10/100 RJ45 Plug

Audio Out (green)

Microphone In (pink)

Power Cord Socket (black)

General I/O Terminal Block

Ground

Fan

The fan will operate when the temparature inside the Network Camera reaches over 50°C�

f= 3�3~12 mm (FD7141 Lens) f= 9~22 mm (FD7141V Lens)

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 5

Bottom Base

Outer View

Dome Cover

N.C.

AC24V

Camera Base

a

b

c

Record the MAC address under the camera base before installing the camera�

Network Camera

Model No: FD7141

Made in Taiwan

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Pat. 6,930,709

RoHS

V I

MAC:0002D1083236

a

b

c

Hole a~c: Holes for ceiling mount or for attaching the bottom base�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

6 - User's Manual

General I/O Terminal Block

This Network Camera provides a general I/O terminal block which is used to connect external

input / output devices. The pin denitions are described below.

Pin Name Specification N�C� No Connector N�C� No Connector N�C� No Connector

AC24V Power in AC 24V AC 24V ± 5% AC24V Power in AC 24V AC 24V ± 5%

GND Ground

DI Digital Iutput OPEN/Short-to-GND, isolation 2kV

DO Digital Output Max� 40VDC, max� 400mA, isolation 2kV

+12V Power +12V 12VDC ± 10%, max� 0�4A

DI/DO Diagram

Please refer to the following illustration for the connection method�

N.C.

AC24V

GND DI DO +12V

N�C�: No Connector N�C�: No Connector N�C�: No Connector AC24V: Power in AC 24V AC24V: Power in AC 24V

GND: Ground DI : Digital Input DO : Digital Output +12V : Power, 12V DC

12V

+12V

Digital output

PIN 1

Power+12V

PIN 2

Digital input

PIN 3

Ground

PIN 4

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 7

Hardware Reset

The reset button is used to reset the system or restore the factory default settings� Sometimes resetting the system can return the camera to normal operation� If the system problems remain after rebooting, restore the factory settings and install again�

Reset: Press and release the reset button with a paper clip or thin object� Wait for the Network Camera to reboot�

Restore: Press and hold the reset button until the status LED rapidly blinks red and green simultaneously� Note that all settings will be restored to factory default�

SD Card Capacity

This network camera is compliant with SDHC 16GB / 8GB and other preceding standard SD cards�

Reset Button

Status LED

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

8 - User's Manual

Installation

Hardware Installation

First, use a screwdriver to loose the three screws and detach the dome cover from the camera base� Then, follow the steps below to install the camera to either a ceiling or a wall�

Ceiling mount with the bottom base

1� Attach the supplied alignment sticker to the ceiling� 2� Using the 10 circles on the sticker, drill 2 pilot holes symmetrically on each side into the ceil-

ing� Then hammer the four supplied plastic anchors into the holes�

3� Through the four holes on the bottom base, insert the four supplied screws into the corre-

sponding holes and secure the bottom base with a screwdriver�

4� Feed the cables through hole A or B� If you want to use hole B, remove the rubber stopper

with a screwdriver�

5� Secure the camera base to the bottom base with three supplied screws�

N.C. N.C.

N.C. AC24V

AC24V

123

4

5

A

B

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 9

Wall mount with the bottom base

1� Attach the supplied alignment sticker to the wall� 2� Using the 10 circles on the sticker, drill 2 pilot holes symmetrically on each side into the wall�

Then hammer the four supplied plastic anchors into the holes�

3� Using the four holes on the bottom base, insert the four supplied screws to corresponding

holes and secure the bottom base with a screwdriver�

4� Feed the cables through hole A or B� If you want to use hole B, remove the rubber stopper

with a screwdriver�

5� Secure the camera base to the bottom base with three supplied screws�

1

2

3

5

A

B

4

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

10 - User's Manual

Ceiling mount without the bottom base (Embedded)

1� Attach the supplied ceiling hole template sticker to the ceiling� 2� Open a hole along the inner circle of the sticker� 3� Using the 3 circles on the sticker, drill 3 pilot holes into the ceiling� Then hammer the three

supplied plastic anchors into the holes� 4� Mount the Network Camera to the ceiling and feed the cables through� 5� Using the three holes on the side of the camera base, insert the three supplied screws into

the corresponding holes and secure them with a screwdriver�

Network Deployment

Setup the Network Camera over the Internet

This section explains how to congure the Network Camera to an Internet connection�

1� If you have external devices such as sensors and alarms, make the connection from the

general I/O terminal block�

2� Use the supplied RJ45 female/female coupler to connect the Network Camera to a switch.

Use a Category 5 Cross Cable when Network Camera is directly connected to PC�

3� Connect the power cable from the Network Camera to a power outlet�

1

5

2

3

4

Ceiling Hole Template Sticker

Drill hole

N.C. N.C.

N.C. AC24V

AC24V

POW

ER

C O

LL

I S

ION

L I

N

K RE CEIVE

PARTITIO

N

1

2

3

4

5

N.C.

AC24V

N�C�: No Connector N�C�: No Connector N�C�: No Connector AC24V: Power in AC 24V AC24V: Power in AC 24V

GND: Ground DI : Digital Input DO : Digital Output +12V : Power, 12V DC

GND DI DO +12V

1

2

3

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 11

There are several ways to set up the Network Camera over the Internet� The rst way is to set up the Network Camera behind a router� The second way is to utilize a static IP� The third way is to use PPPoE�

Internet connection via a router

Before setting up the Network Camera over the Internet, make sure you have a router and follow the steps below�

1� Connect your Network Camera behind a router, the Internet environment is illustrated below�

Regarding how to obtain your IP address, please refer to Software Installation on page 13 for details�

IP address : 192.168.0.3 Subnet mask : 255.255.255.0 Default router : 192.168.0.1

IP address : 192.168.0.2 Subnet mask : 255.255.255.0 Default router : 192.168.0.1

LAN (Local Area Network) Router IP address : 192.168.0.1

WAN (Wide Area Network ) Router IP address : from ISP

Cable or DSL Modem

POWER

COLLISION

LINK RECEIVE

PARTITION

1

2

3

4

5

Internet

2� In this case, if the Local Area Network (LAN) IP address of your Network Camera is 192�168�0�3, please forward the following ports for the Network Camera on the router�

■ HTTP port

■ RTSP port

■ RTP port for audio

■ RTCP port for audio

■ RTP port for video

■ RTCP port for video

If you have changed the port numbers on the Network page, please open the ports accordingly on your router� For information on how to forward ports on the router, please refer to your router’s user’s manual�

3� Find out the public IP address of your router provided by your ISP (Internet Service Provider)� Use the public IP and the secondary HTTP port to access the Network Camera from the

Internet� Please refer to Network Type on page 36 for details�

Internet connection with static IP

Choose this connection type if you are required to use a static IP for the Network Camera� Please refer to LAN on page 36 for details�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

12 - User's Manual

Internet connection via PPPoE (Point-to-Point over Ethernet)

Choose this connection type if you are connected to the Internet via a DSL Line� Please refer to PPPoE on page 37 for details�

Set up the Network Camera through Power over Ethernet (PoE)

When using a PoE-enabled switch

The Network Camera is PoE-compliant, which allows it to be powered via a single Ethernet cable� If your switch/router supports PoE, refer to the following illustration to connect the Network Camera to a PoE-enabled switch/router via an Ethernet cable�

When using a non-PoE switch

If your switch/router does not support PoE, use a PoE power injector (optional) to connect between the Network Camera and a non-PoE switch/router�

POWER

COLLISION

LINK RECEIVE

PARTITION

1

2

3

4

5

N.C. N.C.

N.C.

AC24V

power + data transmission

PoE Switch

POWER

COLLISION

LINK

RECEIVE

PARTITION

1

2

3

4

5

N.C.

N.C. N.C.

AC24V

Non-PoE Switch

PoE Power Injector

(optional)

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 13

Software Installation

Installation Wizard 2 (IW2), free-bundled software included on the product CD, helps you set up

your Network Camera on the LAN�

1� Install IW2 from the Software Utility directory on the software CD� Double click the IW2 shortcut on your desktop to launch the program�

2� The program will conduct an analysis of your network environment� After your network environment is analyzed, please click Next to continue the program�

3� The program will search for all VIVOTEK network devices on the same LAN�

4� After searching, the main installer window will pop up� Click on the MAC and model name

which matches the product label on your device to connect to the Network Camera via Internet Explorer�

0002D1083236

Network Camera

Model No: FD7141

Made in Taiwan

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Pat. 6,930,709

RoHS

V I

MAC:0002D1083236

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

14 - User's Manual

Ready to Use

1� Access to the Network Camera from the Internet� 2� Retrieve live video through a web browser or recording software� Please refer to page 16 for detailed information�

Adjusting the Lens

Based on the live image retrieved from the camera, adjust the camera lens by doing the following:

To adjust the viewing angle

1� Loosen the pan screw and then turn the lens module left and right� Upon completion, tighten

the pan screw�

2� Loosen the tilt screws on both sides of the camera and turn the lens module up and down�

Upon completion, tighten the tilt screws�

3� Loosen the image adjustment screw and then turn the lens to adjust the image orientation�

Upon completion, tighten the image adjustment screw�

http://192.168.5.109/index.html

3

1

2

Loosen

Tighten

Loosen

Tighten

Loosen

Tighten

Rotate the screw Turn the lens

Pan 350°

Tilt 95°

Rotate 350°

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 15

To adjust the zoom factor and focus range

1. Loosen the zoom controller, then adjust the zoom factor by moving the controller left and right. Upon completion, tighten the zoom controller.

2� Loosen the focus controller, then adjust the focus range by moving the controller left and right�

Upon completion, tighten the focus controller�

Note

If you are using FD7141V (f= 9~22 mm), please hold the supplied plastic cover in front of the lens while adjusting the focus controller as shown below�

Completion

Attach the dome cover to camera� Secure the three dome screws with a screwdriver� Finally, make sure all parts of the camera are securely installed�

W

T

8

N

DO NOT over tighten the controllers� Doing so will damage the camera lens module�

Loosen

Tighten

axis of the lens

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

16 - User's Manual

Accessing the Network Camera

This chapter explains how to access the Network Camera through web browsers, RTSP players, 3GPP-compatible mobile devices, and the VIVOTEK recording software�

Using Web Browsers

Use Installation Wizard 2 (IW2) to access to the Network Cameras installed on the LAN.

If your network environment is not the LAN, follow these steps to access the Network Camera:

1. Launch your web browser (eg. Microsoft® Internet Explorer, Mozilla Firefox, or Netscape).

2. Enter the IP address of the Network Camera in the address eld. Press Enter�

3� The live video will be displayed in your web browser�

4. If this is the rst time installing the VIVOTEK network camera, an information bar will pop up

as shown below� Follow the instructions to install the required plug-in on your computer�

NOTE

► For Mozilla Firefox or Netscape users, your browser will use Quick Time to stream the live

video. If you do not have Quick Time on your computer, please install it rst, then launch the

web browser�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 17

► By default, the Network Camera is not password-protected. To prevent unauthorized access,

it is highly recommended to set a password for the Network Camera� For more information about how to enable password protection, please refer to Security on page 30�

► If you see a dialog box indicating that your security settings prohibit running ActiveX

®

Controls, please enable the ActiveX® Controls for your browser.

1� Choose Tools > Internet Options > Security > Custom Level�

2. Look for Download signed ActiveX

®

controls; select Enable or Prompt� Click OK�

3. Refresh your web browser, then install the Active X

®

control� Follow the instructions to

complete installation�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

18 - User's Manual

Using RTSP Players

To view the MPEG-4 streaming media using RTSP players, you can use one of the following applications that support RTSP streaming�

Quick Time Player

Real Player

VLC media player

mpegable Player

pvPlayer

As most ISPs and players only allow RTSP streaming through port number 554, please set the RTSP port to 554� For more information, please refer to RTSP Streaming on page 45� For example:

4� The live video will be displayed in your player�

For more information on how to configure RTSP access name, please refer to RTSP Streaming on page 45 for details�

rtsp://192.168.5.151:554/live.sdp

Video 16:38:01 2008/01/03

1� Launch a RTSP player� 2� Choose File > Open URL� An URL dialog box will pop up� 3� The address format is rtsp://<ip address>:<rtsp port>/<RTSP streaming access name for

stream1 or stream2>

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 19

Using 3GPP-compatible Mobile Devices

To view the streaming media through 3GPP-compatible mobile devices, make sure the Network Camera can be accessed over the Internet� For more information on how to set up the Network Camera over the Internet, please refer to Setup the Network Camera over the Internet on page 10�

To utilize this feature, please check the following settings on your Network Camera:

1� Because most players on 3GPP mobile phones do not support RTSP authentication, make

sure the authentication mode of RTSP streaming is set to disable�

For more information, please refer to RTSP Streaming on page 45�

2. As the the bandwidth on 3G networks is limited, larger video sizes are not available. Please

set the video and audio streaming parameters as listed below�

For more information, please refer to Audio and Video on page 52�

Video Mode MPEG-4 Frame size 176 x 144 Maximum frame rate 5 fps Intra frame period 1S Video quality (Constant bit rate) 40kbps Audio type (GSM-AMR) 12.2kbps

3� As most ISPs and players only allow RTSP streaming through port number 554, please set

the RTSP port to 554� For more information, please refer to RTSP Streaming on page 45�

4� Launch the player on the 3GPP-compatible mobile device (ex� Real Player)�

5� Type the following URL commands into the player�

rtsp://<public ip address of your camera>:<rtsp port>/<RTSP streaming access name for stream1 or stream2>� For example:

rtsp://192.168.5.151:554/live.sdp

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

20 - User's Manual

Using VIVOTEK Recording Software

The product software CD also contains VIVOTEK’s recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras� Please install the recording software, then launch the program to add the Network Camera to the Channel list� For detailed information about how to use the recording software, please refer to the user’s manual of the software or download the manual from http://www�vivotek�com�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 21

Main Page

This chapter explains the layout of the main page� It is composed of the following sections: VIVOTEK INC� Logo, Host Name, Camera Control Area, Configuration Area, Menu, and Live Video Window�

VIVOTEK INC. Logo

Click this logo to visit VIVOTEK website�

Host Name

The host name can be customized to t your needs. For more information,

please refer to

System on page

28�

Camera Control Area

Video Stream: This Network Cmera supports MJPEG or MPEG-4 dual streams simultaneously. You can select either one for live viewing�

Digital Output: Click to turn the digital output device on or off�

IR illuminators: Click to turn on the IR LEDs for 20 seconds�

Conguration Area

Client Settings: Click this button to access the client setting page� For more information, please refer to Client Settings on page 25�

Conguration: Click this button to access the conguration page of the Network Camera. It is suggested

that a password be applied to the Network Camera so that only the administrator can configure the Network Camera� For more information, please refer to Conguration on page 27�

Language: Click this button to choose a language for the user interface� Language options are available in: English, Deutsch, Español, Français, Italiano,

日本語

, Português,

簡体中文

, and

繁體中文

�

Logo of VIVOTEK INC.

Live View Window

Camera Control Area

Configuration Area

Host Name

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

22 - User's Manual

Live Video Window

■ The following window is displayed when the video mode is set to MPEG-4:

Video Title: The video title can be congured.

For more information, please refer to Video Settings on page

52�

MPEG-4 Protocol and Media Options: The transmission protocol and media options for MPEG-4 video streaming. For further conguration, please refer to Client Settings on page 25�

Time: Display the current time. For further conguration, please refer to Video Settings on page 52�

Title and Time: The video title and time can be stamped on the streaming video. For further conguration, please refer to Video settings on page 52�

Video and Audio Control Buttons: Depending on the Network Camera model and Network Camera

conguration, some buttons may not be available.

Snapshot: Click this button to capture and save still images� The captured images will be displayed

in a pop-up window� Right-click the image and choose Save Picture As to save it in JPEG (*.jpg) or BMP

(*.bmp) format.

Digital Zoom: Click and uncheck “Disable digital zoom” to enable the zoom operation. The navigation

screen indicates the part of the image being magnied. To control the zoom level, drag the slider bar. To

move to a different area you want to magnify, drag the navigation screen image�

Pause: Pause the transmission of the streaming media� The button becomes the Resume button

after clicking the Pause button�

Stop: Stop the transmission of the streaming media� Click the Resume button to continue

transmission�

Start MP4 Recording: Click this button to record video clips in MP4 file format� Press the

Stop MP4 Recording button to end recording� When you exit the web browser, video recording stops accordingly. To specify the storage destination and le name, please refer to MP4 Saving Options on page 26 for details�

Video and Audio Control Buttons

MPEG-4 Protocol and Media Options

Video Title

Time

Title and Time

Video 10:11:50 2008/01/09

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 23

Volume: If the Mute function is not activated, move the slider bar to adjust the volume on the

local computer�

Mute: Turn off the volume on the local computer� The button becomes the Audio On button after

clicking the Mute button�

Talk: Click this button to talk to people around the Network Camera� Audio will project from

the external speaker connected to the Network Camera� Click this button

again to end talking

transmission�

Mic Volume: When the Mute function is not activated, move the slider bar to adjust the

microphone volume on the local computer�

Mute: Turn off the Mic volume on the local computer� The button becomes the Mic On button

after clicking the Mute button�

Full Screen: Click this button to switch to full screen mode. Press the “Esc” key to switch back to normal

mode�

■ The following window is displayed when the video mode is set to MJPEG:

Video Title: The video title can be congured. For more information, please refer to Video Settings on page 52�

Time: Display the current time� For more information, please refer to

Video Settings on page 52�

Title and Time: Video title and time can be stamped on the streaming video� For more information, please refer to

Video Settings on page 52�

Video and Audio Control Buttons: Depending on the Network Camera model and Network Camera

conguration, some buttons may not be available.

Snapshot: Click this button to capture and save still images� The captured images will be displayed

in a pop-up window. Right-click the image and choose Save Picture As to save it in JPEG (*.jpg) or BMP (*.bmp) format.

Digital Zoom: Click and uncheck “Disable digital zoom” to enable the zoom operation. The navigation

screen indicates the part of the image being magnied. To control the zoom level, drag the slider bar. To

move to a different area you want to magnify, drag the navigation screen�

Time

Video Title

Title and Time

Video Control Buttons

Video 10:11:50 2008/01/09

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

24 - User's Manual

Start MP4 Recording: Click this button to record video clips in MP4 file format to your computer�

Press the

Stop MP4 Recording button to end recording� When you exit the web browser, video

recording stops accordingly. To specify the storage destination and le name, please refer to MP4 Saving Options on page 26 for details�

Full Screen: Click this button to switch to full screen mode. Press the “Esc” key to switch back to normal

mode�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 25

Client Settings

This chapter explains how to select the stream transmission mode and saving options on the local computer. When nished with the settings on this page, click Save on the page bottom to enable the settings�

MPEG-4 Media Options

Select to stream video or audio data or both� This is enabled only when the video mode is set to MPEG-4�

MPEG-4 Protocol Options

Depending on your network environment, there are four transmission modes for MPEG-4 streaming:

UDP unicast: This protocol allows for better real-time audio and video streams� However, network

packets may be lost due to network burst trafc and images may be broken. Activate the UDP connection

when occasions require time-sensitive responses and the video quality is less important� Note that each unicast client connecting to the server takes up additional bandwidth and the Network Camera allows up to ten simultaneous accesses�

UDP multicast: This protocol allows multicast-enabled routers to forward network packets to all clients requesting streaming media� This helps to reduce the network transmission load of the Network Camera

while serving multiple clients at the same time. Note that to utilize this feature, the Network Camera must be congured to enable multicast streaming at the same time. For more information, see RTSP

Streaming on page 34�

TCP: This protocol guarantees the complete delivery of streaming data and thus provides better video quality� The downside of this protocol is that its real-time effect is not as good as that of the UDP protocol�

HTTP: This protocol allows for the same transmission quality as the TCP protocol without needing to

open specic ports for streaming under some network environments. Users inside a rewall can utilize

this protocol to allow streaming data through�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

26 - User's Manual

MP4 Saving Options

Users can record live video as they are watching by clicking Start MP4 Recording on the main page�

Here, you can specify the storage destination and le name.

Folder: Specify the storage destination for the recorded video les.

File name prex: Enter the text that will be appended to the front of the video le name.

Add date and time sufx to the le name: Select this option to append the date and time to the end of the le name.

CLIP_20080108-180853

Date and time sufﬁx

The format is: YYYYMMDD_HHMMSS

File name preﬁx

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 27

Conguration

Click Configuration on the main page to enter the camera setting pages� Note that only

Administrators can access the conguration page.

VIVOTEK offers an easy-to-use user interface that helps you set up your network camera with minimal effort� To simplify the setting procedure, two types of user interfaces are available: Advanced Mode for professional users and Basic Mode for entry-level users� Some advanced functions (HTTPS/ Access list/ Homepage layout/ Application/ Recording/ System log/ View parameters) are not displayed in Basic Mode�

If you want to set up advanced functions, please click [Advanced Mode] on the bottom of the

conguration list to quickly switch to Advanced Mode.

In order to simplify the user interface, the detailed information will be hidden unless you click

on the function item. When you click on the rst sub-item, the detailed information for the rst

subitem will be displayed; when you click on the second sub-item, the detailed information for

the second sub-item will be displayed and that of the rst sub-item will be hidden.

The following is the user interface of the Basic Mode and the Advanced Mode:

Basic Mode

Click to Switch to Advanced Mode

Firmware Version

Configuration List

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

28 - User's Manual

Advanced Mode

Each function on the conguration list will be explained in the following sections. Those functions

that are displayed only in Advanced Mode are marked with

Advanced Mode

� If you want to set

up advanced functions, please click [Advanced Mode] on the bottom of the conguration list to quickly switch over�

System

This section explains how to congure the basic settings for the Network Camera, such as the

host name and system time� It is composed of the following three columns: System, System Time and DI and DO. When nished with the settings on this page, click Save at the bottom of the page to enable the settings�

System

Host name: Enter the desired name for the Network Camera� The text will be displayed at the top of the main page�

Click to Switch to Basic Mode

Firmware Version

Configuration List

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 29

System Time

Keep current date and time: Select this option to preserve the current date and time of the Network Camera� The Network Camera’s internal real-time clock maintains the date and time even when the system power is turned off�

Sync with computer time: Select this option to synchronize the date and time of the Network Camera with the local computer� The read-only date and time of the PC is displayed when updated�

Manual: The administrator can enter the date and time manually� Note that the date and time format are [yyyy/mm/dd] and [hh:mm:ss]�

Automatic: The Network Time Protocol is a protocol which synchronizes computer clocks by periodically querying an NTP Server�

NTP server: Assign the IP address or domain name of the time-server� Leaving the text box blank connects the Network Camera to the default time servers�

Update interval: Select to update the time using the NTP server on an hourly, daily, weekly, or monthly basis�

Time zone

Advanced Mode

: Select the appropriate time zone from the list. If you want to upload

Daylight Savings Time rules on the Maintenance page, please refer to Upload / Export Daylight Saving Time Conguration File on page 86 for details�

DI and DO

Digital input: Select High or Low to dene the normal status for the digital input. The Network Camera will report the current status�

Digital output: Select Grounded or Open to dene the normal status for the digital output. The Network Camera will show whether the trigger is activated or not�

VIVOTEK - A Leading Provider of Multimedia Communication Solutions

30 - User's Manual

Security

This section explains how to enable password protection and create multiple accounts�

Root Password

The administrator account name is “root”, which is permanent and can not be deleted. If you want to add more accounts in the Manage User section, please set the password for the “root” account rst.

1� Type the password in both text boxes, then click Save to enable password protection� 2� A window will be prompted for authentication; type the correct user’s name and password in their

respective elds to access the Network Camera.

Manage Privilege

Advanced Mode

Digital Output: You can modify the manage privilege of operators or viewers. Check or uncheck the item, then click Save to enable the settings� If you give Viewers the privilege, Operators will also have the ability to control the Network Camera through the main page� (Please refer to Main Page on page 21�)

Allow anonymous viewing: If you check this item, any client can access the live stream without entering a User ID and Password�

Manage User

Administrators can add up to 20 user accounts� 1� Input the new user’s name and password� 2� Select the privilege level for the new user account� Click Add to enable the setting�

Access rights are sorted by user privilege (Administrator, Operator, and Viewer)� Only administrators can

access the Conguration page. Though operators cannot access the Conguration page, they can use

the URL Commands to get and set the value of parameters� For more information, please refer to URL Commands of the Network Camera on page 89� Viewers access only the main page for live viewing�

Here you also can change a user’s access rights or delete user accounts� 1� Select an existing account to modify� 2� Make necessary changes and click Update or Delete to enable the setting�

Vivotek FD7141, FD7141V User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
