Preface
Copyright
©2013 Vivitek Corporation. is a trademark of Vivitek Corporation. Other
trademarks are the properties of their respective owners. Values, weights and dimensions
are approximate. Specications are subject to change without prior notice.
Disclaimer
The information in this document is subject to change without notice. The manufacturer
makes no representations or warranties with respect to the contents hereof and
specically disclaims any implied warranties of merchantability or tness for any particular
purpose. The manufacturer reserves the right to revise this publication and to make
changes from time to time in the content hereof without obligation of the manufacturer to
notify any person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand
Corporation with issued registrations and pending applications in
other countries throughout the world.
HDMI, the HDMI Logo, and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
MHL, the MHL logo, and Mobile High-Denition Link are trademarks
or registered trademarks of MHL licensing, LLC.
All other product names used in this manual are the properties of their respective owners
and are acknowledged.
ii
Page 3
Important Safety Information
Important:
It is strongly recommended that you read this section carefully before using the Qumi.
These safety and usage instructions that will make sure you enjoy many years of safe use
of the Qumi. Keep this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous
situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or
cause personal injury.
Throughout this manual, component parts and items in the OSD (On-Screen Display)
menus are denoted in bold font as in this example:
“Press the Menu button on the remote control to open the Main menu.”
General Safety Information
• Do not open the unit case. There are no user-serviceable parts in the unit. For
servicing, contact qualied service personnel.
• Follow all warnings and cautions in this manual and on the unit case.
• The projection light source is extremely bright by design. To avoid damage to eyes,
do not look into the lens when the LED illumination is on.
• Do not place the unit on an unstable surface or stand.
• Avoid using the system near water, in direct sunlight, or near a heating device.
• Do not place heavy objects such as books or bags on the unit.
iii
Page 4
Qumi Installation Notice
• Allow at least a 50cm clearance around the exhaust vent.
Minimum 100mm
• Make sure that the intake vents do not recycle hot air from the exhaust vent.
• When operating the Qumi in an enclosed space, make sure that the surrounding air
temperature within the enclosure does not exceed operating temperature while the
Qumi is running, and the air intake and exhaust vents are unobstructed.
Minimum 500mm
• All enclosures should pass a certied thermal evaluation to make sure that the Qumi
does not recycle exhaust air, as this may cause the device to shutdown even if the
enclosure temperature is with the acceptable operating temperature range.
Caution:
Avoid using the Qumi in dusty environments.
iv
Page 5
Power Safety
• Only use the supplied power cord.
• Do not place anything on the cord. Place the cord where it will not be in the way of
foot trafc.
• Remove the battery from the remote control when storing or not in use for a
prolonged period.
Cleaning the Qumi
• Unplug the cord before cleaning. See Cleaning the Qumi on page 45.
Note:
The Qumi will be warm after usage. Allow Qumi to cool down before storing in a
compartment.
Regulatory Warnings
Before installing and using the Qumi, read the regulatory notices in the Regulatory
Compliance on page 57.
Symbol Explanations
DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use
of separate recycling collection services.
Main Features
• Lightweight unit, easy to pack away and transport.
• Compatible with all major video standards including NTSC, PAL, and SECAM.
• A high brightness rating allows for presentations in daylight or in lit rooms.
• Supports data resolution up to UXGA at 16.7 million colors to deliver crisp, clear
images.
• Flexible setup allows for front, rear, ceiling and rear ceiling projections.
• Line-of-vision projections remain square, with advanced keystone correction for
angled projections.
• Input source automatically detected.
About this manual
This manual is intended for end users and describes how to install and operate the Qumi.
Wherever possible, relevant information—such as an illustration and its description—has
been kept on one page. This printer-friendly format is both for your convenience and to
help save paper, thereby protecting the environment. It is suggested that you only print
sections that are relevant to your needs.
v
Page 6
Table of Contents
Preface .................................................................................................................. ii
Chapter 1 At a Glance ................................................................ 1
Overview ................................................................................................................ 1
Accessories ........................................................................................................... 3
Remote Control ...................................................................................................... 4
Qumi and Remote Control Buttons ........................................................................ 4
Media Player Screen ............................................................................................. 5
Chapter 2 Getting Started .......................................................... 6
What You Need ...................................................................................................... 6
Setting Up Qumi .................................................................................................... 7
Setting Up the Remote Control ............................................................................ 13
Chapter 3 Qumi Media Suite .................................................... 14
Overview .............................................................................................................. 14
Music ...................................................................................................................15
Movies .................................................................................................................17
Photos ..................................................................................................................18
Ofce Viewer ........................................................................................................19
Wi ....................................................................................................................... 20
Web browser ........................................................................................................ 23
Wi Display .......................................................................................................... 24
Settings ................................................................................................................ 25
Chapter 4 On-Screen Display (OSD) Settings........................ 27
OSD Menu Controls ............................................................................................. 27
Setting the OSD Language .................................................................................. 28
OSD Menu Overview ........................................................................................... 29
Image Menu ......................................................................................................... 30
Settings 1 Menu ................................................................................................... 34
Settings 2 Menu ................................................................................................... 39
Chapter 5 Taking Care of Your Qumi ...................................... 45
Cleaning the Qumi ............................................................................................... 45
Cleaning the Lens ................................................................................................ 45
Troubleshooting ...................................................................................................46
Vivitek Support Site ..............................................................................................50
Specications ....................................................................................................... 51
Projection Distance vs. Projection Size ............................................................... 52
Projection Distance and Size Table ..................................................................... 52
Timing Mode Table ............................................................................................... 53
2Dà3D Timing Table ........................................................................................... 54
3D Timing Table ................................................................................................... 55
Qumi Dimensions ................................................................................................ 56
Regulatory Compliance ....................................................................................... 57
Safety Certications ............................................................................................. 57
Disposal and Recycling ....................................................................................... 57
vi
Page 7
Chapter 1 At a Glance
Overview
Front/Top/Right View
Keypad
See Keypad - On-Screen Display
(OSD) buttons
Cooling Vent
Do not cover
Projection Lens
Keypad
Enter Cursor
Change settings in the OSD
Left Cursor
Navigate and change settings
in the OSD
Down Cursor
Navigate and change settings
in the OSD
Lens
Zoom / Focus ring
Zoom / Focus the projected
Cooling Vent
Do not cover
Up Cursor
Navigate and change settings
in the OSD
Return
Return the previous OSD
menu
Menu
Open and exit the OSD
Power Switch
Turn on/off the Qumi
Right Cursor
Navigate and change settings in the
OSD
1
Page 8
Rear/Top/Left View
AC In
Connect the supplied power
cord
USB
Connect an USB Flash Disc
HDMI 1/ MHL
Connect a HDMI / MHL cable
from a HDMI / MHL device
IR Receiver
Receive IR signal from the
remote control
HDMI 2
Connect a HDMI cable from a
HDMI device
Connect the VGA cable from
VGA
a VGA device
Audio Out
Connect an audio cable to
speakers or headphones
Audio in (L&R)
Connect the Audio in (L&R)
cable from an audio device
Video
Connect the video cable from
a video device
Bottom View
Rubber Foot Pad
Stability and maintain cooling
ventilation
Tilt adjuster
Rotate adjuster lever to adjust angle
position
Tripod Connecting Slot
Tripod not included
Cooling Vent
Do not cover
2
Page 9
Accessories
Along with the Qumi, the following accessories are included:
Remote Control
(With one 3V CR2025 battery)
Standard HDMI Cable
VGA Cable
MHL cable
Regional Power Cord
Documentation Kit
WARRANTY
(User Manual, Quick Start Guide, Warranty
Card)
Carrying Case
Lens Cap
WiFi Dongle (Optional)
Contact your dealer immediately if any items are missing, appear damaged, or if the unit
does not work. It is recommended that you keep the original packing material should you
ever need to return the equipment for warranty service.
Note:
Accessories will vary from model to model.
3
Page 10
Remote Control
Up Cursor
Navigate and change settings in the OSD.
Cursor navigation when using web
browser.
ON/OFF
Turn on or off Qumi.
Left Cursor
Navigate and change settings in the OSD.
Cursor navigation when using web
browser.
Mouse
Mouse left key when using the Web
browser.
Menu
Open and exit the OSD.
Page Up/Down
Page up and down when using the Web
browser.
Enter
Change settings in the OSD.
Enter function when using web browser.
Right Cursor
Navigate and change settings in the OSD.
Cursor navigation when using web
browser.
Down Cursor
Navigate and change settings in the OSD.
Cursor navigation when using web
browser.
Exit
Close the OSD.
Exit function when using web browser.
Mute
Mute the built-in speaker.
Source
Change the input source.
Volume Up/Down
Change the volume.
Important:
1. Be sure nothing obstructs the path between the remote control and the Qumi. If the path
between the remote control and the Qumi is obstructed, the signal can bounce off certain
reective surfaces.
2. The buttons and keys on the Qumi have the same layout and similar functions as the
corresponding buttons on the remote control. This user’s manual describes the functions
based on the remote control.
Qumi and Remote Control Buttons
The Qumi can be operated using the remote control or the keypad on the top of the
Qumi. All operations can be carried out with the remote control; however, the keypad
on the Qumi carries out the same operations as the remote control by pressing a
combination of keys.
The remote control is not only used to navigate the cursor in the menus, but can also be
used to control the media functions (music and video playback). For more details about
how to control the media functions with the remote control, please refer to 14.
4
Page 11
Media Player Screen
The media player screen is the main interface for the Qumi Q7 Series. If a USB Flash Disc
is plugged in when powering on the Qumi, the media player screen appears. In the media
player screen, you can choose the type of media to display by selecting:
• Music – A music player that supports many types of audio les, ready to play music.
• Movie – An easy to use movie player that displays multiple movie formats.
• Photo – A photo viewer that contains slide show functionality.
• Ofce viewer – A document viewer that displays documents.
• Wi Display – Use this to congure the connection to a wireless access point.
• Web browser – A Web browser for surng the Internet.
• Wi – Use this to choose a Wi-Fi access point.
• Settings – The settings of the Qumi can be adjusted in this menu.
Note:
Wi & Web browser functions are only available with Q7’s dongle.
5
Page 12
Chapter 2 Getting Started
What You Need
Many types of external devices and peripherals can be connected to the Qumi. External or
portable music players can be connected to play music. DVD, VCD and VHS players can
be connected to play movies. Camcorders and digital cameras can also be used to play
videos and display photos. Computers can be connected, as well as peripherals such as
USB Flash Disc to display documents and other types of media.
These devices can be connected to the Qumi by using an appropriate cable. Make sure
that the connecting device has an appropriate output connector.
Connect HDMI / MHL peripherals
Insert USB Flash Disc
Connect AC power cord
Connect HDMI peripherals
Warning:
As a safety precaution, disconnect all power to the Qumi and connecting devices before
making connections.
HDMI 1 / MHL HDMI 2
USB
Connect video device
VGA
VIDEO
L - AUDIO - R
Connect VGA device
Connect to an audio device
AUDIO OUT
K
Connect AUDIO IN device
6
Page 13
Setting Up Qumi
Connecting to an HDMI Device
Connect your Qumi to an HDMI device by using an HDMI cable.
SmartphoneCamera
HDMI 1 / MHL HDMI 2
USB
VGA
VIDEO
L - AUDIO - R
AUDIO OUT
K
Game
Console
Connecting to an MHL Device
Connect your Qumi to a MHL-compatible device by using an MHL cable.
HDMI 1 / MHL HDMI 2
USB
VGA
VIDEO
L - AUDIO - R
AUDIO OUT
K
Personal
Computer
TouchpadSmartphone
Note:
For some MHL compatible devices, whose output is not thru micro-USB, an extra cable
adaptor may be required.
Connecting to a Personal Computer
Connect your Qumi to a personal computer by using a VGA cable.
HDMI 1 / MHL HDMI 2
USB
VGA
VIDEO
Note:
The personal computer must have a VGA output port to use the VGA cable to connect to
the Qumi.
L - AUDIO - R
AUDIO OUT
K
Personal
Computer
7
Page 14
Inserting a USB Flash Disc
Connect a USB Flash Disc to the Qumi by inserting the storage device(s) into the
appropriate port.
HDMI 1 / MHL HDMI 2
USB
VGA
VIDEO
L - AUDIO - R
AUDIO OUT
K
Connecting Video
Connect audio/video devices to the Qumi by using the audio/video cable.
HDMI 1 / MHL HDMI 2
USB
VGA
VIDEO
L - AUDIO - R
AUDIO OUT
K
Game
Console
Connecting Audio
DVD
Player
Connect earphones or mini speakers to the Qumi by inserting into the Audio Out port.
HDMI 1 / MHL HDMI 2
USB
VGA
VIDEO
L - AUDIO - R
AUDIO OUT
K
Earphone Mini Speaker
8
Page 15
Starting and Shutting down the Qumi
1.
Connect the AC power cord to
the Qumi. Connect the other end
of the AC power cord to a wall
outlet.
2.
Press the POWER button to
turn on the Qumi.
The Qumi splash screen
displays and connected devices
are detected.
See Setting an Access
Password (Security Lock) on
page 11 if security lock is
enabled.
3.
If more than one input device is
connected, press the SOURCE
button on the remote control
and use the ▲ or ▼ buttons to
select the applicable device or
press ▲ and ▼ or ◄ and ► at
the same time on the keypad on
the Qumi.
• VGA: Analog RGB,
Component: DVD
input YCbCr / YPbPr,
or HDTV input YPbPr
• Composite Video:
Traditional composite video
• HDMI 1 / MHL: HDMI / DVI /
MHL
• HDMI 2: HDMI / DVI
• USB: USB Flash Disc
9
Page 16
4.
Press the POWER button to
turn off the Qumi.
5.
When the “Power Off? /Press
Power again” message appears,
press the POWER button.
The projector turns off.
Adjusting the Image
Use the Image-zoom control (on the
projector) to resize the projected image
and screen size (B).
Use the Image-focus control (on the
projector) to sharpen the projected
image (A).
B
A
10
Page 17
Setting an Access Password (Security Lock)
To prevent unauthorized use of the Qumi, you can create a password. When the access
password function is enabled, the password must be entered after the Qumi has been
turned on.
Creating a password can be done by performing the following steps:
1.
Press the MENU button on the
remote control or press MENU
on the keypad to open the
On-Screen Display (OSD)
menu.
2.
Move the cursor to the Settings
1 tab and scroll down to select
Advanced 1.
3.
Press the ▲ or ▼ button to
select Security Lock and press
.
4.
Press the ◄ or ► button to
enable or disable the security
lock function.
A password dialog box
automatically appears.
5.
You can use the ▲▼◄►
buttons located either on top
of the Qumi or on the remote
control to enter the password.
Any combination of the
navigation buttons can be used
(ve must be chosen).
Press the navigation buttons in
any order to set the password.
Then press the MENU button to
exit the dialog box.
11
Page 18
6.
Important:
Keep the password in a safe place. Without the password, you will not be able to use
the Qumi. If you lose the password, contact your reseller for information on resetting the
password.
The password conrmation
menu appears when you
power on the Qumi when the
Security Lock is enabled.
Enter the password that was
created in step 5.
Using a Tripod
The Qumi can be used with a tripod by connecting
the tripod to the bottom of the Qumi. Many typical
tripods can be connected.
Supported Tripod Specications:
• Type: Mini tripod
• Slot size: 1/4-20 L6.3 mm
Adjusting Projector Level
Take note of the following when setting up the projector:
• The projector table or stand should be level and sturdy.
• Position the projector so that it is perpendicular to the screen.
• Ensure the cables are in a safe location. You could trip over them.
To adjust the angle of the picture, turn the tilt-adjuster right or left until the desired angle
has been achieved.
12
Page 19
Setting Up the Remote Control
The remote control comes with one (1) 3V lithium
battery (CR2025). The battery is pre-installed in
the remote control.
To begin using the remote control, remove the
plastic tab (A) from the battery compartment.
Replacing the Remote Control Batteries
A
1.
Remove the battery
compartment cover
by sliding the cover
towards the arrow
(A). Then pull out
the cover towards
the arrow (B).
A
Caution:
1. Use only a 3V lithium battery (CR2025).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the battery when not using the Qumi for prolonged periods.
B
2.
Remove the old
battery and insert
the new battery
with the positive
side facing up.
3.
Install the cover.
Operating Range
The remote control uses infrared (IR) transmission to control the Qumi. It is not necessary
to point the remote directly at the Qumi.
The remote control functions properly within a radius of approximately 7 meters (23 feet)
and 15 degrees above or below the Qumi level (if the remote is not held perpendicular to
the sides or rear of the Qumi).
If the Qumi is unresponsive to the remote control, move closer towards the Qumi.
13
Page 20
Chapter 3 Qumi Media Suite
Overview
The Qumi Media Suite is designed to provide easy access to your les from an inserted
USB Flash Disc. Music, movies, pictures and documents can be displayed.
The media suite menu contains 8 applications that can be accessed:
• Music – A music player that supports many types of audio les, ready to play music.
• Movie – An easy to use movie player that displays multiple movie formats.
• Photo – A photo viewer that contains slide show functionality.
• Ofce viewer – A document viewer that displays documents.
• Wi Display – Use this to congure the connection to a wireless access point.
• Web browser – A Web browser for surng the Internet.
• Wi – Use this to choose a Wi-Fi access point.
• Settings – The settings of the Qumi can be adjusted in this menu.
Note:
1. Wi & Web browser functions are only available with Q7’s dongle.
2. Plug a USB hub into Qumi’s USB socket, then plug the Q7 Wi-Fi dongle, keyboard and
mouse into the USB hub to surf the Internet easily.
14
Page 21
Music
Supported Formats:
The music player can play music les in the following formats:
• MP3 (up to 256Kbps bit-rate)
• WMA, MID, MIDI, MP1, MP2, OGG, AAC, AMR, WAV, AC3, M4A, AWB, APE
Playing your Track
To open the music list, perform the following:
1. Press the ◄ or ► button to select the Music icon in the media suite menu.
2. Press
3. Select the folder containing the desired song.
4. Press
A song can be paused or can be played by selecting the Pause/Play button in the music
player interface.
When the cursor is selecting the progress bar, a song can be paused or can be played by
pressing
to open the le directory.
to play the desired song.
.
Control Interface
The music player interface contains the following controls:
15
Page 22
The music player provides controls to navigate through a song playlist. The following table
provides a description the controls.
ACTION DESCRIPTION
/ /
/
/
Toggle speaker output to Left/Right/Stereo
Return to previous/Forward to next track
Pause/Play track
Stop playback
Return to the previous menu
The order of songs and playback mode can be adjusted. The following table provides a
description of the playback modes.
ACTION DESCRIPTION
Songs in the playlist will play in a continuous order
All songs in the playlist will repeat
Only the current song playing will repeat
All songs in the playlist will be shufed during playback
16
Page 23
Movies
Supported Formats
The following video formats are supported:
• H.264 video up to 720p at 30 frames per second; Main Prole level 3.1 with AAC-LC
audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov le formats
• MPEG-4 video up to 2.5 Mbps, 640 by 480 pixels at 30 frames per second; Simple
Prole with AAC-LC audio up to 160 Kbps per channel, 48kHz, stereo audio in .m4v,
.mp4, and .mov le formats
• Motion JPEG (M-JPEG) up to 35 Mbps, 1280 by 720 pixels, 30 frames per second,
audio in U-Law, PCM stereo audio in .avi les
• Unicode subtitle le: .ssa, .ass, .srt, .smi
Watching Your Movie
To open a list of movies, perform the following:
1. Press the ◄ or ► button to select the Movie icon in the media suite menu.
2. Press
3. Select the folder containing the desired movie le.
4. Press
While a movie is playing, the control interface can be hidden. To hide the control interface,
press the ▲ button or
The control interface will automatically disappear if there is no user input for 5 seconds.
to open the le directory.
to play the desired movie le.
. Press the ▲ button or again to show the control interface.
Control Interface
The following playback functions are controlled by the remote control, which are shown in
the table below:
ACTION DESCRIPTION
Return to the previous menu
/
/
/
/
Pause/Play track
Show or hidden subtitle (if have)
Return to previous/Forward to next track
Full screen display or Actual Movie Size display
17
Page 24
Photos
Supported Formats
The photo viewer can open the following types of image les:
• BMP (up to 4000 x 3000 pixels)
• PNG (up to 4000 x 3000 pixels)
• JPG (up to 4000 x 3000 pixels)
Viewing Your Photo
When a USB Flash Disc is inserted, the Flash Disc folder icon will display in the le
directory.
To open a photo in photo viewer, perform the following:
1. Press the ◄ or ► button to select the Photo icon in the media suite menu.
2. Press
3. Select the folder containing the desired photo.
4. Press
To view the details of the photos, navigate to a photo. The details of the photo will appear
on the bottom of the screen.
To view photos in full screen mode, perform the following:
1. Navigate to a photo.
2. Press
To utilize the Zoom-In tool, press
In order to zoom out to the default size of the image, press the Exit key.
While a photo is displayed, the control interface can be hidden. To hide the control
interface, press the ▲ button or
interface.
to open the le directory.
to display the desired photo.
to view the photo in full screen mode.
. (2X, 4X, 8X, 16X).
. Press the ▲ button or again to show the control
Control Interface
The photo viewer contains the following controls:
ACTION DESCRIPTION
Return to the previous menu.
Sets the Slide Show interval.
View photos in Slide Show mode.
Rotate the photo in a counter-clockwise position.
Rotate the photo in a clockwise position.
18
Page 25
Supported Formats
The document viewer in the Qumi Media Suite can open the following types of documents:
®
• Microsoft
• Microsoft
transitions)
• Microsoft
• Adobe
• Text (.txt)
Selecting Your Document
To open a le in document viewer, perform the following:
1. Press the ◄ or ► button to select the Ofce Viewer icon in the media suite menu.
Word (97-2007, .doc/.docx)
®
PowerPoint (97-2007, .ppt/.pptx) (not support Animation and slide
®
Excel (97-2007, .xls/.xlsx)
®
PDF (.pdf) (PDF 1.0, 1.1, 1.2, 1.3 and 1.4)
2. Press
to open the le directory.
3. Select the folder containing the desired le.
4. Press
Once a le is open, press
to display the desired le.
to zoom in for a larger view of the le. Files can be zoomed
in 2X, 4X, 8X and 16X views. Use the navigation keys to move the view of the le.
To proceed to the next page or return to a previous page, press the ▲ or ▼ button.
Note:
You cannot move to the previous or next page if the view is zoomed in.
Control Interface
The ofce viewer does not contain a dedicated control interface.
19
Page 26
Turning on WiFi
Insert the Q7 WiFi dongle in the Qumi to surf the Web through a web browser.
To turn on WiFi, perform the following:
1. Press the ◄ or ► button to select the Wi icon in the media suite menu.
2. Press
• Device Name / SSID: Enter the Service Set Identier here.
• WiFi: Enable WiFi function and connecting to an exist WiFi AP.
• WiFi hotspot: Let Q7 to be an AP and allowed PC to do WiFi display.
to enter Network Settings.
3. Press the ◄ or ► button to select Enable and then press
function.
4. Press the ▲ or ▼ button to select an AP and then press
Note:
1. The Wi function is only available with Q7’s dongle.
2. WiFi and WiFi hotspot can not work at the same time.
3. Press Page Up on the remote control to return to the top of the function area. From
here, you can refresh the AP list.
4. Press Page Down to move to the bottom of the AP list when in the function area.
to turn on WiFi
to connect.
20
Page 27
WiFi Control Interface
The WiFi Setting contains the following controls:
ACTION DESCRIPTION
Return to Main Window.
/
Enable/Disable WiFi.
WiFi conguration.
21
Page 28
WiFi Congure
The WiFi Congure setting lets you setup a dynamic (Default) or static IP connection.
ACTION DESCRIPTION
IP Address Congure the IP address of the projector here.
Netmask Congure the subnet mask here.
Gateway Congure the IP address of the default gateway here.
DNS Congure the IP address of the DNS server here.
WiFi hotspot control interface
The WiFi hotspot interface lets you enable or disable the use of a hotspot through the
Qumi. Select Use default IP or Use other IP, then click Apply to congure the WiFi hotspot
interface.
22
Page 29
Web browser
Visiting a website
1. Plug the Q7 Wi-Fi Dongle into Qumi’s USB socket.
2. Press ▲ ▼ ◄ ► on the remote control to control the cursor. See Remote Control on
page 4.
3. Use the remote control for navigation control. Press the Q icon (bottom-right) to
access the address bar.
4. Press
to display the virtual keyboard, or press in the address bar.
Control Interface
The Main bar contains the following controls:
ACTION DESCRIPTION
Go back one page.
Go to next page.
Reload current page/Stop loading current page.
Back to Home page.
Enter bookmark page.
Add/Delete current page to bookmark
Click to enter URL input page.
Zoom in/out page.
Clear History and Exit browser.
23
Page 30
Set Wi Display
1. Plug the Q7 Wi-Fi Dongle into Qumi’s USB socket.
2. Set Network settings > Wi to Enabled and Wi hotspot to Enabled.
3. Press the ◄ or ► button to select the Wi Display icon in the media suite menu.
24
Page 31
Settings
System Options
The system options menu displays the system and rmware information. The Information
menu provides details about the software version.
Play Mode
The play mode menu displays settings for both video and music player options. The
following settings are available:
• Repeat None – The videos or music tracks will not repeat after it is completed.
• Shufe – The order of videos or music tracks will play in a random order.
• Repeat One – A selected video or music track will continuously repeat after it is
completed.
• Repeat All – All videos or music tracks in a playlist will repeat after all of the les in
the playlist have been completed.
Note:
The Qumi media suite always supplies an output of 1280x800 resolution to the system, so
the OSD displays a resolution of 1280x800 as its received signal. This does not indicate
the actual resolution of the actual multimedia les.
USB Options
The USB Mass Storage option allows you to connect a personal computer with a USB
cable to transfer les between the Qumi and personal computer.
Note:
The Qumi media suite only supports input from USB Flash Disc.
System Upgrade
The System Upgrade option allows you to perform rmware upgrades through a USB
Flash Disc.
Copy the latest rmware onto the USB Flash Disc and insert into the Qumi.
25
Page 32
AutoPlay Option
Use the AutoPlay Option menu to congure what the Qumi automatically plays when
powered on. The following settings are available when AutoPlay is ON.
• AutoPlay – Turn on or off auto play.
• AutoPlay Type – Automatically play photo or video les when powered on.
• File Path – Automatically play les in the root of USB or local memory.
To use AutoPlay on Qumi:
1. Connect PC to Qumi using a USB cable.
2. Move media les to respective folder (Movies for movie les or Photos for image
les).
To use AutoPlay on USB Flash Disc:
1. Create Movies or Photos folder in USB Flash Disc.
2. Copy media les to respective folder (Movies for movie les or Photos for image
les).
3. Remove USB Flash Disc and insert in Qumi.
Note:
1. AutoPlay les on USB Flash Disc must be named Movies or Photos for this function to
play media les.
2. Built-in memory for Qumi Q7 is 4GB.
26
Page 33
Chapter 4 On-Screen Display (OSD) Settings
OSD Menu Controls
The Qumi has an On-Screen Display (OSD) settings menu that allows you to make
adjustments and changes to settings, such as display settings and audio settings. There
are 3 menus within the OSD menu:
• Image – Various aspects of the image quality can be adjusted in this menu.
• Setting 1 – Default language and other settings can be adjusted in this menu.
• Setting 2 – Auto source and other settings can be adjusted in this menu.
If the interface is set on AV-IN, HDMI/MHL or VGA, the OSD menu can be accessed by
pressing the MENU button on the remote control or keypad.
If the interface is set on the Qumi Media Suite menu, the OSD menu can be accessed by
pressing the MENU button on the remote control or pressing MENU on the keypad.
Note:
If the OSD menu is inactive for 15 seconds, the OSD menu will close.
Navigating the OSD
The remote control cursor buttons or the buttons on the top of the Qumi can be used to
navigate and make changes to the OSD settings.
1. Enter the OSD menu.
2. Press the ◄ or
► button to move
through the 3 menus.
3. Press the ▲ or ▼
button to move the
cursor up and down
within in a menu and
press
4. Press ◄ or ► to
change the values for
specic settings.
5. Press MENU button
or EXIT on the
remote control to
close the OSD or
close a submenu.
Note:
Depending on the video source, not all items in the OSD can be modied. For example,
the Horizontal/Vertical Position items in the Image > Computer menu can only be modied
when the Qumi is connected to a PC through a VGA cable. Settings that are not enabled
or that cannot be modied are gray in color.
.
27
Page 34
Setting the OSD Language
The language that is displayed in the OSD can be changed. To change the language in
the OSD, perform the following steps:
1. Enter the OSD menu. Press the ◄ or ► button to select the Setting 1 and press
2. Press the ▲ or ▼ button to move to the Advanced 1 menu.
3. Press to enter the Advanced 1 sub menu.
4. Press the ▲ or ▼ button until the cursor highlights the Language setting and
press
.
.
5. Press the cursor button until the language you want is highlighted.
6. Press the EXIT button or MENU button four to close the OSD.
28
Page 35
OSD Menu Overview
Use the following illustration to quickly nd a setting or determine the range for a setting.
Settings 1
Settings 2
Display Mode
Brightness
Contrast
Computer
Auto Image
Advanced
Color Manager
Source
Projection
Aspect Ratio
Keystone
Digital Zoom
Audio
Advanced 1
Advanced 2
Auto Source
No Signal Power O (min)
Auto Power On
LEDMode
Reset All
Status
Advanced 1
Advanced 2
Presentation, Bright, Game, Movie, TV, sRGB, User, User1
Horizontal Position
Vertical Position
Frequency
Tracking
Brilliant Color
Sharpness
Gamma
Color Temperature
Video AGC
Video Saturation
Video Tint
Red
Green
Blue
Reference Input Source Select (IR/Keypad)
Normal, Real, Ceiling, Real+Ceiling
Fill, 4:3, 16:9, Letter Box, Native, 2.35:1
Volume
Mute
Language
Security Lock
Blank Screen
Splash Logo
Closed Captioning
KeypadLock
3D Setting
Auto Keystone
Test Pattern
H Image Shift
V Image Shift
O, On
O, On
Eco, Normal
Active Source
Video Information
LED Hours (Eco, Normal)
Menu Position
Translucent Menu
Low Power Mode
Fan Speed
Sleep Timer
Source Filter
1.8, 2.0, 2.2, 2.4, B&W, Linear
Warm, Normal, Cold
English, Français, Deutsch, Español, Português, 簡体中文, 繁體中文, Italiano,
Norsk, Svenska, Nederlands, Русский, Polski, Suomi, Ελληνικά, 䚐ạ㛨, Magyar,
Čeština, ﺍﻝﻉﺭﺏﻱﺓ, Türkçe, Việt, 日本語, ไทย, ﻑﺍﺭﺱی, תירבע
Blank, Red, Green, Blue, White
3D Sync Invert
3D Format
2D to 3D
2D to 3D Deep
None, Grid, White, Red, Green, Blue, Black
Center, Down, Up, Left, Right
0%, 25%, 50%, 75%, 100%
Normal, High
Composite Video
HDMI 1 / MHL
O, On
O, On
O, On
O, On
O, On
O, On
3D
O, On
O, On
VGA
HDMI 2
USB
O, DLP-Link, IR
O, On
Frame Sequential, Top/Bottom, Side-By-Side
O, On
Inward 1, Inward 2, Inward 3, Outward 1, Outward 2, Outward 3
Disable, Enable
Disable, Enable
Disable, Enable
Disable, Enable
Disable, Enable
29
Page 36
Image Menu
To access the Image menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Image menu.
3. Press the ▲ or ▼ button to move the cursor up or down in the Image menu and
press
4. Press the ◄ or ► button to change values for each applicable setting.
.
ITEM DESCRIPTION
Display Mode Press the ◄ or ► button to set the display mode.
Brightness Press the ◄ or ► button to adjust the display brightness.
Contrast Press the ◄ or ► button to adjust the display contrast.
Computer
Auto Image
Advanced
Color Manager
Note:
Color Manager is adjustable only when the Display Mode is set to User1.
Press
31.
Press to enter automatically adjustment for phase, tracking,
size and position.
Press to enter the Advanced menu. See Advanced on page
32.
Press to enter the Color Manager menu. See Color Manager
on page 33.
to enter the Computer menu. See Computer on page
30
Page 37
Computer
To access the Computer menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Image menu.
3. Press the ▲ or ▼ button to move to the Computer menu and press
4. Press the ◄ or ► button to change values for each applicable setting.
ITEM DESCRIPTION
Horizontal Position
Vertical Position
Press the ◄ or ► button to adjust the display position to left or
right.
Press the ◄ or ► button to adjust the display position to up or
down.
.
Frequency Press the ◄ or ► button to adjust the A/D sampling clock.
Tracking Press the ◄ or ► button to adjust the A/D sampling dot.
Note:
Items in the Computer menu can only be modied when the Qumi is connected to a PC
through a VGA cable. Settings that are not enabled or that cannot be modied are gray in
color.
31
Page 38
Advanced
To access the Advanced menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Image menu.
3. Press the ▲ or ▼ button to move to the Advanced menu and press
4. Press the ▲ or ▼ button to move the cursor up or down in the Advanced menu.
.
ITEM DESCRIPTION
Brilliant Color Press the ◄ or ► button to adjust the brilliant color value.
Sharpness Press the ◄ or ► button to adjust the display sharpness level.
Gamma
Color Temperature Press the ◄ or ► button to adjust the color temperature.
Video AGC
Video Saturation Press the ◄ or ► button to adjust the video saturation.
Video Tint Press the ◄ or ► button to adjust the video tint/hue.
Note:
Video AGC, Video Saturation, Video Tint and Closed Caption settings are adjustable only
when the source is from composite video.
Press the ◄ or ► button to adjust the gamma correction of the
display.
Press the ◄ or ► button to enable or disable the Automatic Gain
Control for video source.
32
Page 39
Color Manager
To access the Color Manager menu and adjust the settings, perform the following:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Image menu.
3. Press the ▲ or ▼ button to move the cursor up or down in the Color Manager menu
and press
4. Press the ◄ or ► button to change values for each applicable setting.
.
ITEM DESCRIPTION
Red Press the ◄ or ► button to adjust the LED Red PWM.
Green Press the ◄ or ► button to adjust the LED Green PWM.
Blue Press the ◄ or ► button to adjust the LED Blue PWM.
33
Page 40
Settings 1 Menu
To access the Settings 1 menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Settings 1 menu.
3. Press the ▲ or ▼ button to move the cursor up and down in the Settings 1 menu
and press
4. Press the ◄ or ► button to change values for each applicable setting.
.
ITEM DESCRIPTION
Source
Projection
Aspect Ratio Press the ◄ or ► button to adjust the video aspect ratio.
Keystone Press the ◄ or ► button to adjust the display keystone.
Digital Zoom Press the ◄ or ► button to adjust the digital zoom in or zoom out.
Audio
Advanced 1
Advanced 2
Press
Press the ◄ or ► button to choose from four projection methods:
Front, Rear, Ceiling-Front, Ceiling-Rear.
Press
Press
36.
Press to enter the Advanced 2 menu. See Advanced 2 on page
38.
to enter the Source menu.
to enter the Audio menu. See Audio on page 35.
to enter the Advanced 1 menu. See Advanced 1 on page
34
Page 41
Audio
To adjust the audio settings, press to enter the Audio sub menu.
ITEM DESCRIPTION
Volume Press the ◄ or ► button to adjust the audio volume.
Mute Press the ◄ or ► button to turn on or off the speaker.
35
Page 42
Advanced 1
To adjust the advanced settings, press to enter the Advanced 1 sub menu.
ITEM DESCRIPTION
Language Press the ◄ or ► button to select a different localization menu.
Security Lock
Blank Screen
Splash Logo Press the ◄ or ► button to show logo or not.
Colsed Captioning Press the ◄ or ► button to enable or disable colsed captioning.
Keypad Lock
3D Setting
Auto Keystone Press the ◄ or ► button to enable or disable automatic keystone.
Note:
To use the 3D function, the Play Movie in 3D setting found in your player under the 3D Disc
Menu must be enabled. 3D functionality works when the input source supports 120Hz.
1. The 3D OSD menu item is gray if there is no appropriate 3D source. This is the default setting.
2. When the projector is connected to an appropriate 3D source, the 3D OSD menu item is
enabled for selection.
3. Use 3D glasses to view a 3D image.
4. You need 3D content from a 3D DVD or 3D media le.
5. You need to enable the 3D source (some 3D DVD content may have a 3D on-off selection
feature).
6. You need DLP link 3D or IR 3D shutter glasses. With IR 3D shutter glasses, you need to install
a driver on your PC and connect a USB emitter.
7. The 3D mode of the OSD needs to match the type of glasses (DLP link or IR 3D).
8. Power on the glasses. Glasses normally have a power on-off switch. Each type of glasses has
their own conguration instructions. Please follow the conguration instructions that come with
your glasses to nish the setup process.
Press the ◄ or ► button to enable or disable security lock
function.
Press the ◄ or ► button to select different color to blank the
screen.
Press the ◄ or ► button to enable or disable keypad lock
function.
Press
to enter the 3D menu. See 3D Setting on page 37.
36
Page 43
3D Setting
To adjust the 3D settings, press to enter the 3D Setting sub menu.
ITEM DESCRIPTION
3D Press the ◄ or ► button to select Off, DLP-Link or IR.
3D Sync Invert Press the ◄ or ► button to turn 3D sync Invert on or off.
3D Format
2Dto3D Press the ◄ or ► button to enable or disable 2Dto3D function.
2Dto3D Deep Press the ◄ or ► button to select different 2Dto3D deep.
Press the ◄ or ► button to select Frame Sequential,
Top / Bottom, Side by Side.
37
Page 44
Advanced 2
To adjust the advanced settings, press to enter the Advanced 2 sub menu.
ITEM DESCRIPTION
Test Pattern Press the ◄ or ► button to select different test pattern.
H Image Shift Press the ◄ or ► button to shift the horizontal position.
V Image Shift Press the ◄ or ► button to shift the vertical position.
38
Page 45
Settings 2 Menu
To access the Settings 2 menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Settings 2 menu.
3. Press the ▲ or ▼ button to move the cursor up and down in the Settings 2 menu
and press
4. Press the ◄ or ► button to change values for each applicable setting.
.
ITEM DESCRIPTION
Auto Source
No Signal Power Off
(min)
Auto Power On Press the ◄ or ► button to enable or disable automatic power on.
LED Mode
Reset All
Status
Advanced 1
Advanced 2
Press the ◄ or ► button to enable or disable automatic source
detection.
Press the ◄ or ► button to automatically turn the projector lamp
off when there is no signal.
Press the ◄ or ► button to select the LED mode for higher
brightness or lower brightness to save LED life.
Press
on page 40.
Press
Press
42.
Press to enter the Advanced 2 menu. See Advanced 2 on page
43.
to reset all items to factory preset values. See Reset All
to enter the Status menu. See Status on page 41.
to enter the Advanced 1 menu. See Advanced 1 on page
39
Page 46
Reset All
To reset all of the menu items to the factory default values (except Language and Security
Lock), perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Settings 2 menu.
3. Press the ▲ or ▼ button to select the Reset All menu and press
.
40
Page 47
Status
To see the status of the Qumi, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Settings 2 menu.
3. Press the ▲ or ▼ button to select the Status menu and press
ITEM DESCRIPTION
Active Source Displays the activated source.
Video Information
LED Hours
Displays resolution/video information for RGB source and color
standard for Video source.
LED use information is displayed (in hours). Eco and Normal
counters are separated.
.
41
Page 48
Advanced 1
To access the Advanced 1 menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Settings 2 menu.
3. Press the ▲ or ▼ button to select the Advanced 1 menu and press
4. Press the ▲ or ▼ button to move the cursor up or down in the Advanced 1 menu.
5. Press the ◄ or ► button to change values for each applicable setting.
.
ITEM DESCRIPTION
Menu Position Press the ◄ or ► button to select different OSD location.
Translucent Menu
Low Power Mode
Fan Speed
Press the ◄ or ► button to select OSD background translucent
level.
Press the ◄ or ► button to enable (<0.5W power consumption) or
disable low power mode.
Note:
Enable Low Power Mode to completely power down when
the projector is turned off. Disable Low Power Mode to allow
multimedia functionality when the projector is turned off.
Press the ◄ or ► button to enter and toggle between Normal and
High fan speeds.
Note:
We recommend selecting high speed in high temperature, high
humidity, or high altitude (higher than 1500m/4921ft) areas.
42
Page 49
Advanced 2
To access the Advanced 2 menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Settings 2 menu.
3. Press the ▲ or ▼ button to select the Advanced 2 menu and press
4. Press the ▲ or ▼ button to move the cursor up or down in the Advanced 2 menu.
5. Press the ◄ or ► button to change values for each applicable setting.
ITEM DESCRIPTION
Sleep Timer
Source Filter
White Calibration
Press the ◄ or ► button to adjust the time for automatically lamp
off (in minutes).
Press or ► to enter the Source Filter menu. See Source Filter
on page 44.
Press or ► to active the white calibration for re-build LED
sensor data.
or ►.
43
Page 50
Source Filter
To adjust the source lter, press or ► to enter the Source Filter sub menu.
ITEM DESCRIPTION
VGA
Composite Video
HDMI 1 / MHL
HDMI 2
USB
Press the ◄ or ► button to enable or disable VGA source in auto
search loop.
Press the ◄ or ► button to enable or disable Composite Video
source in auto search loop.
Press the ◄ or ► button to enable or disable HDMI 1 / MHL
source in auto search loop.
Press the ◄ or ► button to enable or disable HDMI 2 source in
auto search loop.
Press the ◄ or ► button to enable or disable USB source in auto
search loop.
44
Page 51
Chapter 5 Taking Care of Your Qumi
Cleaning the Qumi
Cleaning the Qumi to remove dust and grime will help provide trouble-free operation.
Warning:
1. The Qumi should be turned off and unplugged before cleaning. Failure to do so may
result in injury or damage to the system.
2. Use only a dampened cloth when cleaning. Do not allow water to enter the ventilation
openings on the Qumi.
3. If a small amount of water gets into the interior of the Qumi while cleaning, unplug the
Qumi and set in a well ventilated area for several hours before using.
4. If a large amount of water gets into the interior of the Qumi when cleaning, unplug the
Qumi and have it serviced.
Cleaning the Lens
Optical lens cleaning solutions can be purchased from most camera and other retail
stores. To clean the Qumi lens, perform the following steps:
1. Apply a small amount of the optic lens cleaning solution to a clean and soft cloth. (Do
not apply the cleaning solution directly to the lens.)
2. Gently wipe the lens in a circular motion.
Caution:
1. Do not use abrasive cleaners or solvents.
2. To prevent discoloration or fading, do not allow the cleaning solution to contact the Qumi
case.
45
Page 52
Troubleshooting
Common Problems and Solutions
These guidelines provide tips to deal with problems you may encounter while using the
Qumi. If the problem remains unresolved, contact your dealer for assistance.
The problem sometimes can be as simple as a wire that is not completely connected.
Review the following possible issues before proceeding to the problem-specic solutions.
• Use another electrical device to conrm that the electrical outlet is properly working.
• Make sure that the Qumi is turned on.
• Make sure all connections are securely connected.
• Make sure that the connected device is turned on.
• Make sure that the connected PC is not in suspend or sleep mode.
• Make sure the connected notebook computer is properly congured for an external
display.
Tips for Troubleshooting
In each problem-specic section, perform the steps in the order suggested. Doing so may
help solve the problem more quickly.
In order to avoid replacing non-defective parts, try to nd and isolate the problem.
For example, if you replace batteries and the problem remains, put the original batteries
back and move to the next step.
Keep a record of the steps you take when troubleshooting. The information may be useful
for reference when calling technical support or for bringing the Qumi to service personnel.
46
Page 53
LED Error Messages
ERROR CODE MESSAGES
POWER
BLUE BLINK
TEMP
BLUE BLINK
Over temperature error (Inlet air ) - ON
LED over temperature (Red) - 1
LED over temperature (Green) - 2
Fan 1 (Power) error 6 1
Fan 2 (System) error 6 2
Fan 3 (LED) error 6 3
Red LED Thermistor error 8 1
Green LED HSK Thermistor error 8 2
In the event of an LED error, disconnect the AC power cord and wait for one (1) minute
before restarting the Qumi.
If there is any other situation that isn’t listed in the chart above, please contact your
service center.
Image Problems
Problem: No image appears on the screen
1. Verify that the settings on your personal computer are properly congured.
2. Turn off all of the equipment and power up the equipment again in the correct order.
Problem: The image is blurred
1. Adjust the Focus on the Qumi.
2. Make sure the Qumi-to-screen distance is within the specied range.
3. Clean the Qumi lens with optical lens cleaning cloth if it is dirty.
Problem: The image is wider at the top or bottom (trapezoid effect)
1. Position the Qumi so that it is perpendicular to the screen as much as possible.
2. Adjust the Keystone settings in the OSD to correct the problem or set Auto Keystone
to On.
Problem: The image is reversed
Check the orientation of the Projection setting in the Settings 1 menu in the OSD.
Problem: The image is streaked
1. Set the Frequency and Tracking settings on the Computer menu in the OSD to the
default settings.
2. Connect the Qumi to another computer to make sure that the problem is not caused
by a computer’s video card.
47
Page 54
Adjust the Contrast setting in the Image menu in the OSD.
Problem: The color of the projected image does not match the source image
Adjust the Color Temperature and Gamma settings in the Image menu in the OSD.
Remote Control Problems
Problem: The Qumi does not respond to the remote control
1. Aim the remote control towards remote sensor on the Qumi.
2. Make sure the path between remote and sensor is not obstructed.
3. Turn off any uorescent lights in the room.
4. Check to see if the battery polarity is correct.
5. Replace the batteries.
6. Turn off other Infrared-enabled devices in the vicinity.
7. Have the remote control serviced.
Audio Problems
Problem: There is no sound
1. Adjust the volume of the audio source.
2. Check the audio cable connection.
3. Test the output of the audio source with other speakers.
4. Have the Qumi serviced.
Problem: The sound is distorted
1. Check the audio cable connection.
2. Test the output of the audio source with other speakers.
3. Have the Qumi serviced.
48
Page 55
FAQs
1. Does Qumi work with a personal computer, notebook or netbook?
Yes. Use the provided VGA cable or HDMI cable. The Qumi can connect to a PC,
notebook or netbook if they have an appropriate HDMI or VGA port. To play audio, a
stereo audio cable is required to connect to the Qumi’s audio port.
2. Is it possible to connect the Qumi to a game console, such as a Microsoft
Xbox or Sony® PS3?
Yes. The Qumi can be used to display content from an Xbox or PS3 console. This
can be done by connecting the HDMI cable from the game console to the Qumi.
3. Can the Qumi project content from a television?
Watching television content can be done by connecting a cable box, digital set-topbox or satellite receiver because televisions are only able to produce images on its
own screen. For example, if a cable box is used, it can be connected by an HDMI
cable to the Qumi.
4. How can MHL connect to the Qumi?
Use support MHL cable to connect MHL device.
Please visit www.mhlconsortium.org/productlist/ for more information
®
5. How are images from a digital camera or a USB Flash Disc displayed?
Images and other content can be displayed by connecting the following devices to
the Qumi:
• USB Flash Disc, hard drive, card reader
• Digital camera
• Smart phone
• Multimedia storage viewer
Once the devices are connected, images can be displayed by using the Qumi Media
Suite.
6. Which cable is required to video devices to the Qumi?
Video devices can be connected to the Qumi by using an Audio/Video or HDMI cable
if the devices contain the appropriate ports. To play audio, an RCA cable connected
can also be connected to the Qumi.
7. What type of video formats does the Qumi support?
H.264, MPEG-4, VC-1, WMV9, DivX(Xvid), Real Video, AVS and MJPEG.
8. What type of audio formats does the Qumi support?
MP3 and WMA.
9. What type of document formats does the QUMI support?
®
Microsoft
Ofce 2003 and Microsoft® Ofce 2007 (Word, Excel®, PowerPoint®),
Adobe® PDF and text les (txt).
49
Page 56
10. What type of photo formats does the QUMI support?
JPEG, PNG and BMP.
11. How long will the LED light source in the Qumi last and can it be replaced?
The Qumi does not use a typical UHP lamp. It uses a set of Light Emitting Diodes
(LED) to illuminate and project images. LED’s have a greater lifespan than
conventional lamps. Qumi LED’s are estimated to last for approximately 30,000
hours. The lifespan of the LED depends on factors such as brightness, usage,
environmental conditions. LED brightness can decrease over time. The LED module
is not replaceable.
12. Why do I need to re-adjust the focus on my Qumi after it’s powered up?
For the best picture quality, adjustment of the focus ring may be necessary once the
operational temperature has been met.
Please visit www.vivitekcorp.com for more information, support and product registration.
50
Page 57
MODEL
RESOLUTION
PROjECTION DISTANCE
PROjECTION SCREEN SIzE
(DIAGONAL)
PROjECTION LENS
THROW RATIO
CORRECTION
PROjECTION METHODS
DATA COMPATIBILITY
SAFETY CERTIFICATION
OPERATION TEMPERATURE
Qumi Q7 Series
HD (720p - 1280x800)
800mm ~ 3000mm (31.5” ~ 118.11”)
762mm ~ 2718mm (30” ~ 107”)
Manual focus and Zoom
1.3/1.43 : 1
+40 step = 30°
-40 step = -30°
Front, Rear, Desktop, Front-Ceiling, Rear-Ceiling
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, Mac
480i, 480p, 720p, 1080i, 1080p
HDTV (720p, 1080i/p), NTSC/NTSC 4.43, PAL
(B/G/H/I/M/N/60), SECAM
FCC-B, UL, CCC, CE, C-Tick, KC, CB, PSE, NOM,
PCT, PSB, RoHS, ICES-003(Canada)
5° ~ 35°C
DIMENSIONS (WXHXD)
AC INPUT
POWER CONSUMPTION
AUDIO SPEAKER
INPUT TERMINALS
OUTPUT TERMINALS
Note:
For questions regarding product specications, please contact your local distributor.
238mm (9.37”) x 40mm (1.57”) x 180mm (7.09”)
AC Universal 100 - 240V
150W, <0.5W (Standby Mode)
2W speaker x 2
VGA x 1
Video x 1
Audio in x 1(L&R)
HDMI x 2 (HDMI1 available for MHL function)
USB type A x 1
3.5mm earphone jack (volume control) x 1
51
Page 58
Projection Distance vs. Projection Size
Projection Distance and Size Table
DIAGONAL
762/30 646/25 404/16 840/33
1016/40 862/34 538/21 1120/44
1270/50 1077/42 673/26 1400/55
1524/60 1292/51 808/32 1680/66
1778/70 1508/59 942/37 1960/77
2032/80 1723/68 1077/42 2240/88
2286/90 1939/76 1212/48 2520/99
2540/100 2154/85 1346/53 2800/110
2794/110 2369/93 1481/58 3080/121
IMAGE WIDTH
IMAGE HIGH
PROJECTION
DISTANCE
52
Page 59
Timing Mode Table
SIGNAL RESOLUTION
NTSC — 15.734 60.0 O — — —
PAL/SECAM — 15.625 50.0 O — — —
720 x 400 37.9 85.0 — — O O
640 x 480 31.5 60.0 — — O O
640 x 480 37.9 72.8 — — O O
640 x 480 37.5 75.0 — — O O
640 x 480 43.3 85.0 — — O O
800 x 600 35.2 56.3 — — O O
800 x 600 37.9 60.3 — — O O
800 x 600 48.1 72.2 — — O O
800 x 600 46.9 75.0 — — O O
800 x 600 53.7 85.1 — — O O
800 x 600
(for 3D)
1024 x 768 48.4 60.0 — — O O
1024 x 768 56.5 70.1 — — O O
H-SYNC
(KHZ)
76.3 120.0 — — O O
(HZ)
COMPONENT RGB
VESA
1024 x 768 60.0 75.0 — — O O
1024 x 768 68.7 85.0 — — O O
1024 x 768
(for 3D)
1280 x 760 45.0 60.0 — — O O
1280 x 720
(for 3D)
1280 x 800 49.7 59.8 — — O O
1280 x 800 62.8 74.9 — — O O
1280 x 800 71.6 84.8 — — O O
1280 x 1024 64.0 60.0 — — O O
1280 x 1024 80.0 75.0 — — O O
1280 x 1024 91.1 85.0 — — O O
1400 x 1050 65.3 60.0 — — O O
1440 x 900 55.9 60.0 — — O O
1600 x 1200 75.0 60.0
1920 x 1080 67.2 60.0 — — O O
640 x 480 35.0 66.68 — — O O
97.6 120.0 — — O O
91.5 119.9 — — O O
Apple
SDTV
®
Mac
832 x 624 49.725 74.55 — — O O
1024 x 768 60.24 75.0 — — O O
1152 x 870 68.68 75.06 — — O O
480i 15.734 60.0 — O — O
576i 15.625 50.0 — O — O
53
Page 60
EDTV
480p 31.469 60.0 — O — O
576p 31.25 50.0 — O — O
720p 37.5 50.0 — O — O
720p 45.0 60.0 — O — O
HDTV
1080i 33.8 60.0 — O — O
1080i 28.1 50.0 — O — O
1080p 67.5 60.0 — O — O
1080p 56.3 50.0 — O — O
O: Frequency supported
—: Frequency not supported
*: Displayable level
2Dà3D Timing Table
The unit automatically determines PC signals to select the appropriate resolution.
Some signals may require manual adjustment.
SIGNAL 2D RESOLUTION H-SYNC (KHZ)
640 x 480 31.5 60
800 x 600 37.9 60.3
1024 x 768 48.4 60
1280 x 720 45.0 60
1280 x 768 47.8 60
1280 x 800 49.7 60
1280 x 1024 64 60
1400 x 1050 65.3 60
1440 x 900 55.9 60
480i 15.734 60
SDTV
576i 15.625 50
576p 31.3 50
EDTV
480p 31.5 60
720p 37.5 50
720p 45 60
1080i 33.8 60
HDTV
1080i 28.1 50
1080p 67.5 60
1080p 56.3 50
HDMI
(DIGITAL)
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O: Frequency supported
54
Page 61
3D Timing Table
The unit automatically determines PC signals to select the appropriate resolution.
Some signals may require manual adjustment.
3D RESOLUTION HDMI 3D FORMAT
800 x 600 @ 120Hz
1024 x 768 @ 120Hz
1280 x 720 @ 120Hz
HD 1080p 24 FPS
SD 720p 60 FPS
SD 720p 50 FPS
HD 1080i 50 SBSH
SD 720p 60 SBSH
SD 720p 50 SBSH
O: Frequency supported
O
O
O
O
O
O
O
O
O
Frame sequential
Frame sequential
Frame sequential
Frame packing
Frame packing
Frame packing
Side-by-side
Side-by-side
Side-by-side
55
Page 62
Qumi Dimensions
124.66
180.0 mm
40.0 mm
238.0 mm
238.0 mm
69.66
Tripod Hole: :#1/4-20 Max L=0.3 inch
Ceiling Mount Hole: M4xP0.7 L=8 mm (Max)
34.66
87.90
99.90
170.10
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum
screw depth of 8 mm (0.31 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The
ceiling mount load capacity must exceed the weight of the installed equipment, and as an
additional precaution be capable of withstanding three times the weight of the equipment
(not less than 5.15 kg) over a period of 60 seconds.
Do not cover the cooling vent.
56
Page 63
Regulatory Compliance
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his/her own expense.
Changes or modications not expressly approved by the parties responsible for
compliance could void the user’s authority to operate the equipment.
Canada
This class B digital apparatus complies with Canadian ICES-003.
FCC-B, UL, CCC, CE, C-Tick, KC, CB, PSE, NOM, PCT, PSB, RoHS, ICES-003 (Canada)
Disposal and Recycling
This product may contain other electronic waste that can be hazardous if not disposed of
properly. Recycle or dispose in accordance with local, state, or federal Laws. For more
information, contact the Electronic Industries Alliance at www.eiae.org.
57
Loading...
