Vivitek D967-BK, D966HD-WT User manual

Copyright

This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may
be reproduced without written consent of the author.

© Copyright 2013

Disclaimer

The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of
the manufacturer to notify any person of such revision or changes.

Trademark Recognition

Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations
and pending applications in other countries throughout the world.

HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.

All other pro
acknowledged.

duct names used in this manual are the properties of their respective owners and are

— i —

DLP Projector—User’s Manual

Important Safety Information

Important:

It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.

Symbols Used

Warning symbols are used on the unit and in this manual to alert you of hazardous situations.

The following styles are used in this manual to alert you to important information.

Note:

Provides additional information on the topic at hand.

Important:

Provides additional information that should not be overlooked.

Caution:

Alerts you to situations that may damage the unit.

Warning:

Alerts you to situations that may damage the unit, create a hazardous environment, or cause
personal injury.

Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”

General Safety Information

 Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in

the unit. For servicing, contact qualified service personnel.

 Follow all warnings and cautions in this manual and on the unit case.

 The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the

lens when the lamp is on.

 Do not place the unit on an unstable surface, cart, or stand.

 Avoid using the system near water, in direct sunlight, or near a heating device.

 Do not place heavy objects such as books or bags on the unit.

— ii —

Projector Installation Notice

 Place the projector in a horizontal position

The tilt angle of the projector should not exceed 15 degrees, nor should the projector be
installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease
dramatically, and may lead to other unpredictable damages.

 Allow at least 50 cm clearance around the exhaust vent.

Preface

 Ensure that the intake vents do not recycle hot air from the exhaust vent.

 When operating the projector in an enclosed space, ensure that the surrounding air temperature

within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.

 All enclosures should pass a certified thermal evaluation to ensure that the projector does not

recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable operation temperature range.

–iii –

DLP Projector—User’s Manual

Verify Installation Location

 To supply power, the 3-blade (with earthing lead) socket should be used to ensure proper

grounding and equalized ground potential for all of the equipment in the Projector System.

 The power code provided with the Projector should be used. In case of any missing item, other

qualified 3-blade (with earthing lead) power cord can be used as substitution; however, do not use
2-blade power cord.

 Verify if the voltage is stable, grounded properly and there is no electricity leakage.

 Measure total power consumption which should not higher the safety capacity and avoid safety

issue and short circuit.

 Turn on Altitude Mode when located in high altitude areas

 The projector can only be installed upright or inverted.

 When installation the bracket, make sure the weight limit is not exceed and firmly secured.

 Avoid installing near air conditioner duct or subwoofer.

 Avoid installing at high temperature, insufficient cooling and heavy dust locations.

 Keep your product away from fluorescent lamps to avoid malfunction

caused by IR interference

 The VGA IN connector should be connected to the VGA IN port. Note that it should be inserted

tightly, with the screws on both sides securely fastened to ensure proper connection of the signal
wire for achieving optimal display effect.

 The AUDIO IN connector should be connected to the AUDIO IN port and CANNOT be connected

to AUDIO OUT or other ports like BNC, RCA; otherwise, it will lead to mute output and even
DAMAGE the port.

 Install the projector above 200cm to avoid damage.

 The power cord and signal cable should be connected before power on the projector. During the

projector starting and operating process, DO NOT insert or remove the signal cable or the power
cord to avoid damaging the projector.

Cooling notes

Air outlet

 Make sure the air outlet is 50cm clear of any obstruction to ensure proper cooling.

 Air outlet location should not be in front of the lens of other projector to avoid causing illusions.

 Keep the outlet at least 100cm away from the inlets of other projectors

 The projector generates a massive amount of heat during use. The internal fan dissipates the heat

of the projector when shutting down, and such process may continue for a certain period. After the
project enters STANDBY MODE status, press the AC power button to turn off the projector and
remove the power cord. DO NOT remove the power cord during the shutdown process, as it may
cause damage to the projector. In the meantime, the delayed heat radiating will also affect the
service life of the projector. The shutdown process may vary depending on the model used.
Whatever the case may be, be sure to disconnect the power cord till after the projector enters the
STANDBY status.

Air inlet

 Make sure there is no object blocking air input within 30 cm.

 Keep the inlet away from other heat sources

 Avoided heavy dust area

— iv —

Preface

Power Safety

 Only use the supplied power cord.

 Do not place anything on the power cord. Place the power cord where it will not be in the way of

foot traffic.

 Remove the batteries from the remote control when storing or not in use for a prolonged period.

Replacing the Lamp

Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 46
for clear and safe instructions for this procedure. Before replacing the lamp:

 Unplug the power cord.

 Allow the lamp to cool for about one hour.

Caution:

In rare cases the lamp bulb may burn out during normal operation and cause glass dust or shards
to be discharged outward from the rear exhaust vent.

Do not inhale or do not touch glass dust or shards. Doing so could result in injury.

Always keep your face away from the exhaust vent so that you do not suffer from the gas and
broken shards of the lamp.

Cleaning the Projector

 Unplug the power cord before cleaning. See Cleaning the Projector page 49.

 Allow the lamp to cool for about one hour.

Regulatory Warnings

Before installing and using the projector, read the regulatory notices in the Regulatory Compliance on
page 62.

Important Recycle Instructions:

Hg

Lamp(s) inside this product contain mercury. This product may contain other electronic waste that
can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal
Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG

specific disposal information check WWW.LAMPRECYCLE.ORG.

Symbol Explanations

DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use
of separate recycling collection services.

. For lamp

–v –

DLP Projector—User’s Manual

Table of Contents

GETTING STARTED........................................................................................................................................................... 1

PACKING CHECKLIST ........................................................................................................................................................... 1

VIEWS OF PROJECTOR PARTS............................................................................................................................................... 2

Front-right View ............................................................................................................................................................ 2

Top view—On-screen Display (OSD) buttons and LEDs....................................................................................... 3

Rear view....................................................................................................................................................................... 4

Bottom view................................................................................................................................................................... 6

REMOTE CONTROL PARTS ................................................................................................................................................... 7

REMOTE CONTROL OPERATING RANGE ............................................................................................................................... 9

PROJECTOR AND REMOTE CONTROL BUTTONS.................................................................................................................... 9

INSERTING THE REMOTE CONTROL BATTERIES ................................................................................................................. 10

SETUP AND OPERATION............................................................................................................................................... 11

STARTING AND SHUTTING DOWN THE PROJECTOR............................................................................................................. 11

SETTING AN ACCESS PASSWORD (SECURITY LOCK) .......................................................................................................... 13

ADJUSTING THE PROJECTOR LEVEL ................................................................................................................................... 15

ADJUSTING THE ZOOM, FOCUS AND KEYSTONE ................................................................................................................ 16

ADJUSTING THE VOLUME .................................................................................................................................................. 17

ON-SCREEN DISPLAY (OSD) MENU SETTINGS ...................................................................................................... 18

OSD MENU CONTROLS ..................................................................................................................................................... 18

Navigating the OSD ................................................................................................................................................... 18

SETTING THE OSD LANGUAGE .......................................................................................................................................... 19

OSD MENU OVERVIEW ..................................................................................................................................................... 20

IMAGE MENU..................................................................................................................................................................... 21

Computer Menu.......................................................................................................................................................... 22

Advanced Feature...................................................................................................................................................... 23

Color Manager ............................................................................................................................................................ 24

SETTINGS 1 MENU ............................................................................................................................................................. 25

Audio ............................................................................................................................................................................ 26

Advanced 1 Feature................................................................................................................................................... 27

Advanced 2 Feature................................................................................................................................................... 29

SETTINGS 2 MENU ............................................................................................................................................................. 30

Status ........................................................................................................................................................................... 31

Advanced 1 Feature................................................................................................................................................... 32

Advanced 2 Feature................................................................................................................................................... 44

MAINTENANCE AND SECURITY.................................................................................................................................. 46

REPLACING THE PROJECTION LAMP................................................................................................................................... 46

Resetting the Lamp.................................................................................................................................................... 48

CLEANING THE PROJECTOR................................................................................................................................................ 49

Cleaning the Lens ...................................................................................................................................................... 49

Cleaning the Case...................................................................................................................................................... 49

USING THE KENSINGTON

®

LOCK & USING THE SECURITY BAR......................................................................................... 50

Using the Kensington® Lock ..................................................................................................................................... 50

Using the Security Bar............................................................................................................................................... 50

TROUBLESHOOTING...................................................................................................................................................... 51

COMMON PROBLEMS AND SOLUTIONS ............................................................................................................................... 51

TIPS FOR TROUBLESHOOTING ............................................................................................................................................ 51

LED ERROR MESSAGES..................................................................................................................................................... 52

IMAGE PROBLEMS.............................................................................................................................................................. 52

LAMP PROBLEMS ............................................................................................................................................................... 53

REMOTE CONTROL PROBLEMS .......................................................................................................................................... 53

AUDIO PROBLEMS ............................................................................................................................................................. 54

HAVING THE PROJECTOR SERVICED .................................................................................................................................. 54

HDMI Q & A .................................................................................................................................................................... 55

— vi —

Preface

SPECIFICATIONS............................................................................................................................................................. 56

SPECIFICATIONS................................................................................................................................................................. 56

PROJECTION DISTANCE VS. PROJECTION SIZE.................................................................................................................... 57

Projection Distance and Size Table......................................................................................................................... 57

TIMING MODE TABLE ........................................................................................................................................................ 59

PROJECTOR DIMENSIONS ................................................................................................................................................... 61

REGULATORY COMPLIANCE....................................................................................................................................... 62

FCC WARNING .................................................................................................................................................................. 62

CANADA ............................................................................................................................................................................ 62

SAFETY CERTIFICATIONS ................................................................................................................................................... 62

APPENDIX I........................................................................................................................................................................ 63

RS-232C PROTOCOL.......................................................................................................................................................... 63

APPENDIX II....................................................................................................................................................................... 68

D967 / D966HD / D968U FAMILY..................................................................................................................................... 68

–vii –

DLP Projector—User’s Manual

GETTING STARTED

Packing Checklist

Carefully unpack the projector and check that the following items are included:

DLP PROJECTOR

R

EMOTE CONTROL

WITH TWO AAA BATTERIES)

(

L

ENS CAP RGB CABLE POWER CORD

C

ARRYING CASE

PTIONAL)

(O

CD-ROM

HIS USER’S MANUAL)

(T

Q

UICK START GUIDE WARRANTY CARD

Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It
is recommend that you keep the original packing material should you ever need to return the equipment
for warranty service.

Caution:

Avoid using the projector in dusty environments.

– 1 –

DLP Projector—User’s Manual

Views of Projector Parts

Front-right View

12 34

5

6

ITEM LABEL DESCRIPTION SEE PAGE

1.

Height-adjuster button Push to release height adjuster

15

2.

3.

4.

5.

Height adjuster Adjusts level of projector

Lens Projection Lens

IR receiver Receive IR signal from remote control

Focus ring Focuses the projected image

7

16

6.

7.

Important:

Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.

Zoom ring Enlarges the projected image

Function keys

See Top view—On-screen Display (OSD) but­tons and LEDs.

3

— 2 —

DLP Projector—User’s Manual

0

Top view—On-screen Display (OSD) buttons and LEDs

6

5

7

4
3

2

8
9

1

1

11
12

ITEM LABEL DESCRIPTION SEE PAGE

1.

2.

(Power button)

BLANK Displays a blank screen and mutes audio

Turns the projector On or Off.

11

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

◄ (Left cursor) /
Volume-

Enter Enter or confirm highlighted OSD menu item

MENU Opens and exits OSD menus

▲ (Up cursor) /
Keystone+

AUTO Optimizes image size, position, and resolution

► (Right cursor) /
Volume+

SOURCE Enter the Source menu

▼ (Down cursor) /
Keystone-

LAMP LED Flashing

TEMP LED Flashing Error code

Navigates and changes settings in the OSD
Quick Menu – For Volume

Navigates and changes settings in the OSD
Quick Menu – For Keystone

Navigates and changes settings in the OSD
Quick Menu – For Volume

Navigates and changes settings in the OSD
Quick Menu – For Keystone

Lamp is not ready (warming up/shutting down/cooling)
(see LED Error Messages on pag

18

18

18

e 52)

– 3 –

DLP Projector—User’s Manual

3

45679101113

8

Rear view

1 2

14

1718

16

15

12

ITEM LABEL DESCRIPTION SEE PAGE

1.

2.

3.

AC IN Connect the POWER cable

(USB)

VGA OUT

Connect the USB cable from a computer

Connect the RGB cable to a display
(Loop Thru only for VGA IN-1)

11

4.

5.

6.

7.

8.

9.

10.

11.

12.

13.

14.

15.

LAN Connect a LAN cable from Ethernet

VGA IN 1 Connect the RGB cable from a computer or component device

VGA IN 2 Connect the RGB cable from a computer or component device

DP Connect a DISPLAYPORT CABLE from a DISPLAYPORT device

AUDIO IN Connect an AUDIO cable from audio device

HDMI 1 / 2 Connect the HDMI cable from a HDMI device

3D SYNC

DC 12V TRIGGER

Speaker Outputs audio sound

Kensington Lock

VIDEO IN Connect the COMPOSITE cable from a video device

AUDIO IN (L and R) Connect the AUDIO cable from a audio device

Connect the 3D IR glasses transmitter
(Note: For Vivitek brand 3D IR glasses only)

When connected to the screen through a commercially available cable,
the screen deploys automatically on start up of the projector. The screen
retracts when the projector is powered off (see notes below).

Secure to permanent object with a Kensington® Lock
system

50

16.

17.

18.

S-VIDEO IN Connect the S-Video cable from a video device

RS-232C Connect RS-232 serial port cable for remote control

AUDIO OUT Connect an AUDIO cable to audio amplifier

— 4 —

DLP Projector—User’s Manual

Note:



To use this feature, you must plug in the connector before turn on/off the projector.



Screen controllers are supplied and supported by screen manufacturers.



Do not use this jack for anything other than intended use.

Note:

If your video equipment has both S-VIDEO and RCA jacks (composite video) connect to the
S-VIDEO connector. S-VIDEO provides a better quality signal.

Warning:

As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.

– 5 –

DLP Projector—User’s Manual

Bottom view

ITEM LABEL DESCRIPTION SEE PAGE

1.

2.

3.

4.

Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw
depth of 6 mm (0.23 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling mount
load capacity must exceed the weight of the installed equipment, and as an additional precaution
be capable of withstanding three times the weight of the equipment (not less than 5.15 kg) over a
period of 60 seconds.

Tilt adjustor Rotate adjuster lever to adjust angle position.

Ceiling support holes

Height adjustor

Height adjustor button Push to release adjustor.

Contact your dealer for information on mounting the projector on a
ceiling

Adjuster drops down when adjuster button is
pushed.

15

15

— 6 —

Remote Control Parts

DLP Projector—User’s Manual

Important:

1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency

fluorescent lights can disrupt remote control operation.

2. Be sure nothing obstructs the path between the remote control and the projector. If the path
between the remote control and the projector is obstructed, you can bounce the signal off certain
reflective surfaces such as projector screens.

3. The buttons and keys on the projector have the same functions as the corresponding buttons on
the remote control. This user’s manual describes the functions based on the remote control.

Note:

Complies with FDA performance standards for laser products except for deviations pursuant to
Laser Notice No. 50, dated June 24, 2007

– 7 –

DLP Projector—User’s Manual

8

6

ITEM LABEL DESCRIPTION SEE PAGE

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

IR transmitter Transmits signals to projector

Status LED Lights when the remote control is used

Laser Press to operate the on-screen pointer

Up

Right

Down

Page Down

Up cursor

Right cursor

Down cursor

Volume +/- Adjusts volume

Mute Mutes the built-in speaker

Zoom+ Zoom in

Zoom- Zoom out

Freeze Freeze/unfreezes the on-screen picture

Blank Makes the screen blank

Source Detects the input device

Auto Auto adjustment for phase, tracking, size, position

Menu Opens the OSD

Status

Up arrow when connected through USB to a PC
(Not available in this series)

Right arrow when connected through USB to a PC
(Not available in this series)

Down arrow when connected through USB to a PC
(Not available in this series)

Page down when connected through USB to a PC
(Not available in this series)

Navigates and changes settings in the OSD

Opens the OSD Status menu (the menu only opens when
an input device is detected)

18

17

1

31

21.

22.

23.

24.

25.

26.

27.

28.

Use of controls, adjustments or performance of procedures other than those specified herein may
result in hazardous laser light exposure.

Keystone top/bottom Corrects image-trapezoid (wider top/bottom) effect

Left cursor Navigates and changes settings in the OSD

Enter

Page Up

Left

Enter

Power Turns the projector on or off

Laser Use as on-screen pointer. DO NOT POINT IN EYES.

！

Caution:

Changes settings in the OSD

Page up when connected through USB to a PC
(Not available in this series)

Left arrow when connected through USB to a PC
(Not available in this series)

Enter key when connected through USB to a PC
(Not available in this series)

— 8 —

1

18

11

DLP Projector—User’s Manual

Remote Control Operating Range

The remote control uses infrared transmission to control the projector. It is not necessary to point the
remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or
the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and
15 degrees above or below the projector level. If the projector does not respond to the remote control,
move a little closer.

Projector and Remote Control Buttons

The projector can be operated using the remote control or the buttons on the top of the projector. All
operations can be carried out with the remote control; however, the buttons on the projector are
limited in use.

– 9 –

DLP Projector—User’s Manual

Inserting the Remote Control Batteries

Remove the battery compartment

1.

cover by sliding the cover in the
direction of the arrow.

Insert the battery with the positive

2.

side facing up.

Replace the cover.

3.

Caution:

1. Only use AAA batteries (Alkaline batteries are recommended).

2. Dispose of used batteries according to local ordinance regulations.

3. Remove the batteries when not using the projector for prolonged periods.

— 10 —

Starting and Shutting down the Projector

Connect the power cord to the

1.

projector. Connect the other end to
a wall outlet.

The
projector light.

POWER LED on the

DLP Projector—User’s Manual

SETUP AND OPERATION

Turn on the connected devices.

2.

Ensure the POWER LED not a

3.

flashing. Then press the
button to turn on the projector.

The projector splash screen displays
and connected devices are
detected.

See Setting an Access Password

(Security Lo

security lock is enabled.

If more than one input device is

4.

connected, press the SOURCE
button and use ▲▼ to scroll among
devices.
(Component is supported through
the RGB to COMPONENT
ADAPTER.)

ck) on page 13 if

POWER

 HDMI 1 / HDMI 2: High-Definition Multimedia

Interface 1 / 2

 DisplayPort: Display Port

 VGA 1 / VGA 2: Analog RGB1 / RGB 2

 S-Video: Super video (Y/C separated)

 Composite Video: Traditional composite video

– 11 –

DLP Projector—User’s Manual

When the “Power Off? /Press

5.

Power again” message appears,

press the POWER button. The
projector turns off.

Caution:

1. Be sure to remove the lens cap before starting projector.

2. Do not unplug the power cord until all of fans are stop–indicating the projector has cooled down.

— 12 —

DLP Projector—User’s Manual

Setting an Access Password (Security Lock)

You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector.

When enabled, the password must be entered after you power on the projector. (See Navigating the

OSD on page 18 and Setting the OSD Language on page 19 for help on using OSD menus.)

Important:

Keep the password in a safe place. Without the password, you will not be able to use the projector.
If you lose the password, contact your reseller for information on clearing the password.

Press the MENU button to open the

1.

OSD menu.

Press the cursor ◄► button to move

2.

to the Settings 1 menu, press the
cursor ▲▼ button to select Advanced

1.

Press (Enter) / ► to enter the

3.

Advanced 1 sub menu. Press the
cursor ▲▼ button to select Security
Lock.

Press the cursor ◄► button to enter

4.

and enable or disable security lock
function.

A password dialog box automatically
appears.

– 13 –

DLP Projector—User’s Manual

You can use the cursor buttons

5.

▲▼◄►
either on keypad or IR remote control
for password entry. You can use any
combination including the same arrow
five times, but not less than five.

Press the cursor buttons in any order
to set the password. Push the MENU
button to exit the dialog box.

The password confirm menu appears

6.

when user presses the power-on key
in case the Security Lock is enabled.
Enter the password in the order you
set it at step 5. In case you forget the
password, please contact the service
center.
The service center will validate the
owner and help reset the password.

— 14 —

Adjusting the Projector Level

Take note of the following when setting up the projector:

 The projector table or stand should be level and sturdy.

 Position the projector so that it is perpendicular to the screen.

 Remove the Back Foot Holder on the rear adjuster foot before adjusting the projection

angle.

 Ensure the cables are in a safe location. You could trip over them.

DLP Projector—User’s Manual

1.

2.

3.

To raise the level of the projector, lift the projector [A] and press the height­adjuster button [B].

The height adjuster drops down [C].

To lower the level of the projector, press the height-adjuster button and push
down on the top of the projector.

To adjust the angle of the picture, turn the tilt-adjuster [D] right or left until
the desired angle has been achieved.

– 15 –

DLP Projector—User’s Manual

Adjusting the Zoom, Focus and Keystone

Use the Image-zoom

1.

control (on the projector
only) to resize the
projected image and
screen size

Use the Image-focus

2.

control (on the projector
only) to sharpen the
projected image

Use the KEYSTONE

3.

buttons (on the
projector or the remote
control) to correct
image-trapezoid (wider
top or bottom) effect.

.

.

The keystone control

4.

appears on the display.

— 16 —

Adjusting the Volume

Press the Volume +/-

1.

buttons on the remote
control.
The volume control
appears on the display.

Press the Left or Right

2.

Cursor buttons on the

keypad to adjust
Volume +/-.

DLP Projector—User’s Manual

Press the MUTE button

3.

to turn off the volume.
(This feature is available
only on the remote).

– 17

–

DLP Projector—User’s Manual

ON-SCREEN DISPLAY (OSD) MENU SETTINGS

OSD Menu Controls

The projector has an OSD that lets you make image adjustments and change various settings.

Navigating the OSD

You can use the remote control cursor buttons to navigate and make changes to the OSD.

1. To enter the OSD, press the

MENU button.

2. There are three menus.
Press the cursor ◄► button
to move through the menus.

3. Press the cursor ▲▼ button
to move up and down in a
menu.

4. Press ◄► to change values
for settings.

5. Press MENU to close the
OSD or leave a submenu.

Note:

Depending on the video source, not all items in the OSD are available. For example, the
Horizontal/Vertical Position items in the Computer menu can only be modified when connected
to a PC. Items that are not available cannot be accessed and are grayed out.

— 18 —

Setting the OSD Language

Set the OSD language to your preference before continuing.

1. Press the MENU button. Press the cursor ◄► button to navigate to Settings 1. Press the

cursor ▲▼ button to move to the Advanced 1 menu.

DLP Projector—User’s Manual

2. Press (Enter) / ► to enter the Advanced 1 sub menu. Press the cursor ▲▼ button

until Language is highlighted.

3. Press the cursor button until the language you want is highlighted.

4. Press the MENU button four times to close the OSD.

– 19 –

DLP Projector—User’s Manual

OSD Menu Overview

Use the following illustration to quickly find a setting or determine the range for a setting.


Display Mode

Brightness

Contrast

Computer

Auto Image

Advanced

Presentation, Bright, Game, Movie, TV, sRGB, Blackboard, User

Horizontal Position

Vertical Position

Frequency

Tracking

1.8, 2.0, 2.2, 2.4, B&W, Linear

Settings 1

Settings 2

Color Manager

Source

Projection

Aspect Ratio

Keystone

Digital Zoom

Audio

Advanced 1

Advanced 2

Auto Source

No Signal Power Off

Auto Power On

Lamp Mode

Reset All

Status

Advanced 1

Advanced 2

Red

Green

Blue

Cyan

Magenta

Yellow

White

Source

Normal, Real, Ceiling, Real+Ceiling

Fill, 4:3, 16:9, Letter Box, Native, 2.35:1

Volume

Mute

Language

Security Lock

Blank Screen

Splash Logo

Closed Captioning

Keypad Lock

3D Setting

Screen Capture

Test Pattern

H Image Shift

V Image Shift

Off, On

Off, On

ECO, Normal, Dynamic ECO

Menu Position

Translucent Menu

Low Power Mode

Fan Speed

Lamp Hour Reset

Projector ID

Network

Sleep Timer

Source Filter

English, Français, Deutsch, Español, Português, 簡体中文, 繁體中文, Italiano, Norsk,
Svenska, Nederlands, Русский, Polski, Suomi, Ελληνικά, 한국어, Magyar, Čeština, اﻟﻌﺮﺑﻴﺔ ,
Türkçe, Việt, 日本語, ไทย, ﻓﺎرﺳﯽ , עברית

Blank, Red, Green, Blue, White

None, Grid, White, Red, Green, Blue, Black

Center, Down, Up, Left, Right

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Hue

Saturation

Gain

Red

Green

Blue

Reference Input Source Select (IR/Keypad)

Off, On

Std., Off, User

Off, On

Off, On

3D

3D Sync Invert

3D Format

0%, 25%, 50%, 75%, 100%

Off, On

Normal, High

00-98

HDMI 1

HDMI 2

DisplayPort

VGA 1

VGA 2

S-Video

Composite Video

Frame Packing, Top/Bottom, Side-By-Side, Frame Sequential
(3D FramePacking HDMI source only)

Off, DLP-Link, IR

Off, On

Disable, Enable

Disable, Enable

Disable, Enable

Disable, Enable

Disable, Enable

Disable, Enable

Disable, Enable

— 20 —

DLP Projector—User’s Manual

Image Menu

Attention !

All of display mode parameters when changed will be saved to user mode.

Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image
Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to enter

and change values for settings.

ITEM DESCRIPTION

Display Mode Press the cursor ◄► button to enter and set the Display Mode.

Brightness Press the cursor ◄► button to enter and adjust the display brightness.

Contrast Press the cursor ◄► button to enter and adjust the display contrast.

Computer Press (Enter) / ► to enter the Computer menu. See Computer Menu on page 22.

Auto Image

Advanced

Color Manager

Press
position.

Press

23.

Press
information on Color Manager.

(Enter) / ► to automatically adjustment for phase, tracking, size and

(Enter) / ► to enter the Advanced menu. See Advanced Feature on page

(Enter) / ► to enter the color manager menu. See page 24 for more

– 21 –

DLP Projector—User’s Manual

Computer Menu

Press the MENU button to open the OSD menu. Press ◄► to move to the Image menu. Press ▲▼
to move to the Computer menu and then press Enter or ►. Press ▲▼ to move up and down in the

Computer menu.

ITEM DESCRIPTION

Horizontal Position Press the cursor ◄► button to enter and adjust the display position to left or right.

Vertical Position Press the cursor ◄► button to enter and adjust the display position to up or down.

Frequency Press the cursor ◄► button to enter and adjust the A/D sampling clock.

Tracking Press the cursor ◄► button to enter and adjust the A/D sampling dot.

— 22 —

DLP Projector—User’s Manual

Advanced Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲
to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the

Advanced menu.

ITEM DESCRIPTION

Brilliant Color Press the cursor ◄► button to enter and adjust the Brilliant Color value.

Sharpness Press the cursor ◄► button to enter and adjust the display sharpness.

Gamma Press the cursor ◄► button to enter and adjust the gamma correction of the display.

Color Temperature Press the cursor ◄► button to enter and adjust the color temperature.

Video AGC

Video Saturation Press the cursor ◄► button to enter and adjust the video saturation.

Video Tint Press the cursor ◄► button to enter and adjust the video tint/hue.

Press the cursor ◄► button to enter and enable or disable the Automatic Gain Control
for video source.

– 23 –

DLP Projector—User’s Manual

Color Manager

Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲
to move to the Color Manager menu and then press Enter or ►. Press ▼▲ to move up and down in
the Color Manager menu.

Red

Green

Blue

Cyan

Magenta

Yellow

White

ITEM DESCRIPTION

Select to enter the Red Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Green Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Blue Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Cyan Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Magenta Color Manager.
Press the ◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the Yellow Color Manager.
Press the◄► buttons to adjust the Hue, Saturation, and Gain.

Select to enter the White Color Manager.
Press the ◄► buttons to adjust the Red, Green, and Blue.

— 24 —

DLP Projector—User’s Manual

Settings 1 Menu

Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the
Settings 1 menu. Press the cursor ▲▼ button to move up and down in the Settings 1 menu. Press

◄► to

enter and change values for settings.

ITEM DESCRIPTION

Source

Projection Press the cursor ◄► button to enter and choose from four projection methods:

Aspect Ratio Press the cursor ◄► button to enter and adjust the video aspect ratio.

Keystone Press the cursor ◄► button to enter and adjust the display keystone.

Digital Zoom Press the cursor ◄► button to enter and adjust the Digital Zoom menu.

Audio Press (Enter) / ► to enter the Audio menu. See Audio on page 26.

Advanced 1

Advanced 2

Press the cursor ◄► button to enter the Source menu. Reference input Source select
(IR / Keypad).

Press
page 27.

Press
page 29.

(Enter) / ► to enter the Advanced 1 menu. See Advanced 1 Feature on

(Enter) / ► to enter the Advanced 2 menu. See Advanced 2 Feature on

– 25 –

DLP Projector—User’s Manual

Audio

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press
▼▲ to move to the Audio menu and then press Enter or ►. Press ▼▲ to move up and down in the

Audio menu.

ITEM DESCRIPTION

Volume Press the cursor ◄► button to enter and adjust the audio volume.

Mute Press the cursor ◄► button to enter and turn on or off the speaker.

— 26 —

DLP Projector—User’s Manual

Advanced 1 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press
▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down

in the Advanced 1 menu. Press ◄► to enter and change values for setting.

ITEM DESCRIPTION

Language Press the cursor ◄► button to enter and select a different localization Menu.

Security Lock Press the cursor ◄► button to enter and enable or disable security lock function.

Blank Screen Press the cursor ◄► button to enter and select different color to blank the screen.

Splash Logo Press the cursor ◄► button to enter and select splash logo.

Closed Captioning Press the cursor ◄► button to enter and enable or disable Closed Captioning

Press the cursor ◄► button to enter and enable or disable keys can be work on

Keypad Lock

3D Setting

Screen Capture

keypad.
Note : Hold the cursor ▼ button on keypad for 5 seconds to unlock keypad

Press
Setting.

Press
Picture will auto showing after next power on.

(Enter) / ►to enter the 3D menu. See page 28 for more information on 3D

(Enter) / ► to capture screen, and please wait saving picture.

Note:

To enjoy the 3D function, first enable the Play Movie in 3D setting found in your DVD device under the
3D Disc Menu.

– 27 –

DLP Projector—User’s Manual

3D Setting

ITEM DESCRIPTION

3D Press the cursor ◄► button to enter and select different 3D mode.

3D Sync Invert Press the cursor ◄► button to enter and enable or disable 3D Sync Invert.

3D Format Press the cursor ◄► button to enter and enable or disable different 3D Format.

Note:

1. The 3D OSD menu item is gray if there is no appropriate 3D source. This is the default setting.

2. When the projector is connected to an appropriate 3D source, the 3D OSD menu item is enabled for
selection.

3. Use 3D glasses to view a 3D image.

4. You need 3D content from a 3D DVD or 3D media file.

5. You need to enable the 3D source (some 3D DVD content may have a 3D on-off selection feature).

6. You need DLP link 3D or IR 3D shutter glasses. With IR 3D shutter glasses, you need to install a
driver on your PC and connect a USB emitter.

7. The 3D mode of the OSD needs to match the type of glasses (DLP link or IR 3D).

8. Power on the glasses. Glasses normally have a power on -off switch.
Each type of glasses has their own configuration instructions. Please follow the configuration
instructions that come with your glasses to finish the setup process.

Note:

Since different types of glass (DLP link or IR shutter glass) have their own setting instructions,

Please follow the guide to finish the setup process.

— 28 —

DLP Projector—User’s Manual

Advanced 2 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press
▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down

in the Advanced 2 menu. Press ◄► to enter and change values for setting.

ITEM DESCRIPTION

Test Pattern Press the cursor ◄► button to enter and select internal test pattern.

H Image Shift Press the cursor ◄► button to enter and select H Image Shift.

V Image Shift Press the cursor ◄► button to enter and select V Image Shift.

– 29 –

DLP Projector—User’s Manual

Settings 2 Menu

Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the
Settings 2 menu. Press the cursor ▲▼ button to move up and down in the Settings 2 menu.

ITEM DESCRIPTION

Auto Source

No Signal Power
Off (min.)

Auto Power On

Lamp Mode

Reset All Press (Enter) / ► to reset all settings to default values.

Status

Advanced 1

Advanced 2

Press the cursor ◄► button to enter and enable or disable automatic source
detection.

Press the cursor ◄► button to enter and enable or disable automatic shutdown of
lamp when no signal.

Press the cursor ◄► button to enter and enable or disable automatic power On when
AC power is supplied.

Press the cursor ◄► button to enter and select the lamp mode for higher brightness
or lower brightness to save lamp life.
Note:

Remarks to Dynamic ECO of ImageCare

1. Shut-down is not allowed when the projector is boot up less than one minute

2. To protect the lamp, when a shut-down command is received, the lamp mode is forced to be
reset to "Normal" and the system will automatically shut down 10 seconds later

Press
Status.

Press
page 32.

Press
page 44.

(Enter) / ► to enter the Status menu. See page 31 for more information on

(Enter) / ► to enter the Advanced 1 menu. See Advanced 1 Feature on

(Enter) / ► to enter the Advanced 2 menu. See Advanced 2 Feature on

TM

— 30 —

DLP Projector—User’s Manual

Status

Press the cursor ▲▼ button to move up and down in the Settings 2 menu. Select the Status menu
and press Enter or ► to enter.

ITEM DESCRIPTION

Active Source Display the activated source.

Video Information

Lamp Hours Lamp hour used information is displayed. ( ECO. and Normal)

Serial Number Showing serial number of product.

Displays resolution/video information for RGB source and color standard for Video
source.

– 31 –

DLP Projector—User’s Manual

Advanced 1 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press
▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down

in the Advanced 1 menu. Press ◄► to

enter and change values for setting.

ITEM DESCRIPTION

Menu Position Press the cursor ◄► button to enter and select different OSD location.

Translucent Menu Press the cursor ◄► button to enter and select OSD background translucent level.

Low Power Mode Press the cursor ◄► button to enter and turn Low Power Mode on or off.

Press the cursor ◄► button to enter and toggle between Normal and High fan

Fan Speed

Lamp Hour Reset

Projector ID

Network

speeds.
Note: We recommend selecting high speed in high temperatures, high humidity, or
high altitude (higher than 1500m/4921ft) areas.

After replacing the lamp, this item should be reset. See page 33 for more information
on Lamp Hour Reset.

Press the cursor ◄► button to enter and adjust a two digit projector ID from 00
through 98.

Press (Enter) / ► to enter the Network menu. See page 33 for more information

Network.

on

— 32 —

DLP Projector—User’s Manual

Lamp Hour Reset

Please refer to Resetting the Lamp on page 48 to reset the lamp hour counter.

Network

ITEM DESCRIPTION

Network State Displays the network connection status.

Press ◄► to turn DHCP On or Off.

DHCP

IP Address Enter a valid IP address if DHCP is turned off.

Subnet Mask Enter a valid Subnet Mask if DHCP is turned off.

Gateway Enter a valid Gateway address if DHCP is turned off.

DNS Enter a valid DNS name if DHCP is turned off.

Apply Press (Enter) / ► to confirm settings.

Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and
DNS fields.

– 33 –

DLP Projector—User’s Manual

LAN_RJ45

Wired LAN Terminal functionalites

Remote control and monitoring of a projector from a PC (or Laptop) via wired LAN is also possible.
Compatibility with Crestron / AMX (Device Discovery) / Extron control boxes enables not only collective
projector management on a network but also management from a control panel on a PC (or Laptop)
browser screen.

 Crestron is a registered trademark of Crestron Electronics, Inc. of the United States.

 Extron is a registered trademark of Extron Electronics, Inc. of the United States.

 AMX is a registered trademark of AMX LLC of the United States.

 PJLink applied for trademark and logo registration in Japan, the United States of America, and

other countries by JBMIA.

Supported External Devices

This projector is supported by the specified commands of the Crestron Electronics controller and
related software (ex, RoomView ®).

http://www.crestron.com/

This projector is supported by AMX ( Device Discovery ).

http://www.amx.com/

This projector is compliant to support Extron device(s) for reference.

http://www.extron.com/

This projector supports all commands of PJLink Class1 (Version 1.00).

http://pjlink.jbmia.or.jp/english/

For more detail of information about the diverse types of external devices which can be connected to the
LAN/RJ45 port and remote/control the projector, as well as the related control commands supporting for
each external device, kindly please get contact with the Support-Service team directly.

— 34

—

DLP Projector—User’s Manual

LAN_RJ45

1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop).

2. On the PC (Laptop), select Start → Control Panel → Network Connections.

– 35 –

DLP Projector—User’s Manual

3. Right-click on Local Area Connection, and select Properties.

4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP).

5. Click Properties.

6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK.

— 36 —

7. Press the Menu button on the projector.

8. Select Settings2→ Advanced1 → Network

9. After getting into Network, input the following:

 DHCP: Off

 IP Address: 10.10.10.10

 Subnet Mask: 255.255.255.0

 Gateway: 0.0.0.0

 DNS Server: 0.0.0.0

DLP Projector—User’s Manual

10. Press

Open a web browser
(for example, Microsoft Internet Explorer with Adobe Flash Player 9.0 or higher).

11. In the Address bar, input the IP address: 10.10.10.10.

12. Press

The projector is setup for remote management. The LAN/RJ45 function displays as follows.

(Enter) / ► to confirm settings.

(Enter) / ►.

– 37

–

DLP Projector—User’s Manual

CATEGORY ITEM INPUT-LENGTH

Crestron Control

Projector

Network Configuration

User Password

Admin Password

IP Address 15

IP ID 3

Port 5

Projector Name 10

Location 10

Assigned To 10

DHCP (Enabled) (N/A)

IP Address 15

Subnet Mask 15

Default Gateway 15

DNS Server 15

Enabled (N/A)

New Password 10

Confirm 10

Enabled (N/A)

New Password 10

Confirm 10

For more information, please visit http://www.crestron.com.

— 38 —

DLP Projector—User’s Manual

Preparing Email Alerts

1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex­ample, Microsoft Internet Explorer v6.01/v8.0).

2. From the Homepage of LAN/RJ45, click Alert Settings.

3. By default, these input boxes in Alert Settings are blank.

– 39 –

DLP Projector—User’s Manual

4. For Sending alert mail, input the following:

The 　 SMTP field is the mail server for sending out email (SMTP protocol). This is a required field.

The 　 To field is the recipient’s email address (for example, the projector administrator). This is a

required field.

The 　 Cc field sends a carbon copy of the alert to the specified email address. This is an optional

field (for example, the projector administrator’s assistant).

The 　 From field is the sender’s email address (for example, the projector administrator). This is a

required field.

Select the alert conditions　 by checking the desired boxes.

Note: Fill in all fields as specified. User can click Send Test Mail to test what setting is correct. For

successful sending an e-mail alert, you must select alert conditions and enter a correct e-mail
address.

— 40 —

DLP Projector—User’s Manual

RS232 by Telnet Function

Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated
RS232 command control, there is alternative RS232 command control way, so called “RS232 by
TELNET” for LAN/RJ45 interface.

Quick Start-Guide for “RS232 by TELNET”

Check and get the IP-Address on OSD of the projector.

Make sure that laptop/PC can access the web-page of the projector.

Make sure that “Windows Firewall” setting to be disabled in case of “TELNET” function filtering
out by laptop/PC.

Start => All Programs => Accessories => Command Prompt

– 41 –

DLP Projector—User’s Manual

Input the command format like the below:

telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed)

(ttt.xxx.yyy.zzz: IP-Address of the projector)

If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed,
the RS232 command will be workable.

How to have TELNET enabled in Windows VISTA / 7

By default installation for Windows VISTA, “TELNET” function is not included. But end-user can
have it by way of “Turn Windows features On or Off” to be enabled.

Open “Control Panel” in Windows VISTA

Open “Programs”

— 42 —

Select “Turn Windows features on or off” to open

DLP Projector—User’s Manual

Have “Telnet Client” option checked, then press “OK” button.

Specsheet for “RS232 by TELNET” :

1. Telnet: TCP

2. Telnet port: 23

(for more detail, kindly please get contact with the service agent or team)

3. Telnet utility: Windows “TELNET.exe” (console mode)

4. Disconnection for RS232-by-Telnet control normally: Close Windows Telnet utility directly
after TELNET connection ready

5. Limitation 1 for Telnet-Control: there is less than 50 bytes for successive network payload for
Telnet-Control application.

Limitation 2 for Telnet-Control: there is less than 26 bytes for one complete RS232 command
for Telnet-Control.

Limitation 3 for Telnet-Control: Minimum delay for next RS232 command must be more than
200 (ms).

(*, In Windows XP built-in “TELNET.exe” utility, “Enter” key pressed will have “Carriage­Return” and “New-Line” code.)

– 43 –

DLP Projector—User’s Manual

Advanced 2 Feature

Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press
▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down

in the Advanced 2 menu. Press ◄► to

enter and change values for setting.

ITEM DESCRIPTION

Sleep Timer

Source Filter

Press the cursor ◄► button to enter and set Sleep timer. The projector automatically
turns off after the preset period of time.

Press
information on Source Filter.

(Enter) / ► to enter the Source Filter menu. See page 45 for more

— 44 —

Source Filter

Press the ENTER button to enter the Source Filter sub menu.

ITEM DESCRIPTION

DLP Projector—User’s Manual

HDMI 1 Press the cursor ◄► button to enter and enable or disable the HDMI 1 source.

HDMI 2 Press the cursor ◄► button to enter and enable or disable the HDMI 2 source.

DP Press the cursor ◄► button to enter and enable or disable the DisplayPort source.

VGA 1 Press the cursor ◄► button to enter and enable or disable the VGA1 source.

VGA 2 Press the cursor ◄► button to enter and enable or disable the VGA2 source.

S-Video Press the cursor ◄► button to enter and enable or disable the S-Video source.

Composite Video

Press the cursor ◄► button to enter and enable or disable the Composite Video
source.

– 45 –

DLP Projector—User’s Manual

MAINTENANCE AND SECURITY

Replacing the Projection Lamp

The projection lamp should be replaced when it burns out. It should only be replaced with a certified
replacement part, which you can order from your local dealer.

Important:

a. The projection lamp used in this product contains a small amount of mercury.

b. Do not dispose this product with general household waste.

c. Disposal of this product must be carried out in accordance with the regulations of your local

authority.

Warning:

Be sure to turn off and unplug the projector at least 30 minutes before replacing the lamp. Failure to
do so could result in a severe burn.

Caution:

In rare cases the lamp bulb may burn out during normal operation and cause glass dust or shards
to be discharged outward from the rear exhaust vent.

Do not inhale or do not touch glass dust or shards. Doing so could result in injury.

Always keep your face away from the exhaust vent so that you do not suffer from the gas and
broken shards of the lamp.

When removing the lamp from a ceiling-mounted projector, make sure that no one is under the
projector. Glass fragments could fall if the lamp has been burned out.

！

IF A LAMP EXPLODES

If a lamp explodes, the gas and broken shards may scatter inside the projector and they may come
out of the exhaust vent. The gas contains toxic mercury.

Open windows and doors for ventilation.

If you inhale the gas or the shards of the broken lamp enter your eyes or mouth, consult the doctor
immediately.

Loosen the single screw

1.

on the lamp compartment
cover.

— 46 —

Remove the lamp

2.

compartment cover.

Remove the three screws

3.

from the lamp module.

Lift the module handle up.

4.

DLP Projector—User’s Manual

Pull firmly on the module

5.

handle to remove the lamp
module.

Reverse steps 1 to 5 to
install the new lamp

6.

module.
While installing, align the
lamp module with the
connector and ensure it is
level to avoid damage.

Note:
The lamp module must sit
securely in place and the
lamp connector must be
connected properly before
tightening the screws.

– 47

–

DLP Projector—User’s Manual

Resetting the Lamp

After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following:

Press the MENU button to open

1.

the OSD menu.

Press the cursor ◄► button to

2.

move to the Settings 2 menu.
Press the cursor button to move
down to Advanced 1 and press
enter.

Press the cursor ▼▲ button to

3.

move down to Lamp Hour Reset.

Press the cursor ► or Enter

4.

button.

A message screen appears.

Press ▼▲◄► buttons to reset

5.

the lamp hour.

Press the MENU button to get

6.

back to Settings 2.

— 48 —

DLP Projector—User’s Manual

Cleaning the Projector

Cleaning the projector to remove dust and grime will help ensure trouble-free operation.

Warning:

1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so

could result in a severe burn.

2. Use only a dampened cloth when cleaning. Do not allow water to enter the ventilation openings
on the projector.

3. If a little water gets into the projector interior while cleaning, leave unplugged in a well-ventilated
room for several hours before using.

4. If a lot of water gets into the projector interior when cleaning, have the projector serviced.

Cleaning the Lens

You can purchase optic lens cleaner from most camera stores. Refer to the following to clean the
projector lens.

1. Apply a little optic lens cleaner to a clean soft cloth. (Do not apply the cleaner directly to
the lens.)

2. Lightly wipe the lens in a circular motion.

Caution:

1. Do not use abrasive cleaners or solvents.

2. To prevent discoloration or fading, avoid getting cleaner on the projector case.

Cleaning the Case

Refer to the following to clean the projector case.

1. Wipe off dust with a clean dampened cloth.

2. Moisten the cloth with warm water and mild detergent (such as used to wash dishes), and
then wipe the case.

3. Rinse all detergent from the cloth and wipe the projector again.

Caution:

To prevent discoloration or fading of the case, do not use abrasive alcohol-based cleaners.

– 49 –

DLP Projector—User’s Manual

Using the Kensington® Lock & Using the Security Bar

Using the Kensington® Lock

If you are concerned about security, attach the projector to a permanent object with the Kensington
slot and a security cable.

Note:

Contact your vendor for details on purchasing a suitable Kensington security cable.
The security lock corresponds to Kensington’s MicroSaver Security System. If you have any

comment, contact: Kensington, 2853 Campus Drive, San Mateo, CA 94403, U.S.A. Tel: 800-535­4242, http://www.Kensington.com.

Using the Security Bar

In addition to the password protection function and the Kensington lock, the Security Bar helps
protect the projector from unauthorized removal. See the following picture.

— 50 —

DLP Projector—User’s Manual

TROUBLESHOOTING

Common problems and solutions

These guidelines provide tips to deal with problems you may encounter while using the projector. If
the problem remains unsolved, contact your dealer for assistance.

Often after time spent troubleshooting, the problem is traced to something as simple as a loose
connection. Check the following before proceeding to the problem-specific solutions.

 Use some other electrical device to confirm that the electrical outlet is working.

 Ensure the projector is turned on.

 Ensure all connections are securely attached.

 Ensure the attached device is turned on.

 Ensure a connected PC is not in suspending mode.

 Ensure a connected notebook computer is configured for an external display.

(This is usually done by pressing an Fn-key combination on the notebook.)

Tips for Troubleshooting

In each problem-specific section, try the steps in the order suggested. This may help you to solve the
problem more quickly.

Try to pin point the problem and thus avoid replacing non-defective parts.
For example, if you replace batteries and the problem remains, put the original batteries back and go
to the next step.

Keep a record of the steps you take when troubleshooting: The information may be useful when
calling for technical support or for passing on to service personnel.

– 51 –

DLP Projector—User’s Manual

y

g

r

r

r

r

p

r

r

r

r

r

r

LED Error Messages

ERROR CODE MESSAGES

Lamp Read
Start ON OFF OFF

Coolin

Over Temperature OFF ON OFF

T1 erro

Thermal Break Sensor erro

G794 erro

Lamp fail 5 blinks OFF OFF

Ballast temp ove
Ballast circuit short 5 blinks OFF 2 blinks

Lamp End of lamp life detected 5 blinks OFF 3 blinks

Lamp did not ignite 5 blinks OFF 4 blinks

Lamp extinguished during normal operation 5 blinks OFF 5 blinks

Lamp extinguished during run-up phase 5 blinks OFF 6 blinks

Lamp voltage too low 5 blinks OFF 7 blinks
Ballast fail 5 blinks OFF 8 blinks

ON OFF OFF

ON OFF OFF

3 blinks OFF 1 blinks

4 blinks OFF 4 blinks

5 blinks OFF 1 blinks

POWER LED

BLUE

4 blinks OFF OFF

TEMP LED

RED

LAMP LED

RED

Ballast communication fail 5 blinks OFF 10 blinks

Ballast over tem

Restrike lamp fail 1 5 blinks OFF 12 blinks

Restrike lamp fail 2 5 blinks OFF 13 blinks

Lamp fail 1 5 blinks OFF 14 blinks

Lamp fail 2 5 blinks OFF 15 blinks

Fan 1 erro

Fan 2 erro

Fan 3 erro

Fan 4 erro

Case Open 7 blinks OFF OFF

DMD erro

Color wheel erro
In the event of an error, please disconnect the AC power cord and wait for one (1) minute before restarting
the projector. If the Power or Lamp LEDs are still blinking or any other situation that isn't listed in the chart
above

8 blinks OFF OFF

, please contact your service center.

5 blinks OFF 11 blinks

6 blinks OFF 1 blinks
6 blinks OFF 2 blinks
6 blinks OFF 3 blinks
6 blinks OFF 4 blinks

9 blinks OFF OFF

Image Problems

Problem: No image appears on the screen

1. Verify the settings on your notebook or desktop PC.

2. Turn off all equipment and power up again in the correct order.

Problem: The image is blurred

1. Adjust the Focus on the projector.

— 52 —

DLP Projector—User’s Manual

2. Press the Auto button on the remote control.

3. Ensure the projector-to-screen distance is within the specified range.

4. Check that the projector lens is clean.

Problem: The image is wider at the top or bottom (trapezoid effect)

1. Position the projector so it is as perpendicular to the screen as possible.

2. Use the Keystone button on the remote control to correct the problem.

Problem: The image is reversed

Check the Projection setting on the Settings 1 menu of the OSD.

Problem: The image is streaked

1. Set the Frequency and Tracking settings on the Image->Computer menu of the OSD to

the default settings.

2. To ensure the problem is not caused by a connected PC’s video card, connect to another

computer.

Problem: The image is flat with no contrast

Adjust the Contrast setting on the Image menu of the OSD.

Problem: The color of the projected image does not match the source image.

Adjust the Color Temperature and Gamma settings on the Image->Advanced menu of the
OSD.

Lamp Problems

Problem: There is no light from the projector

1. Check that the power cable is securely connected.

2. Ensure the power source is good by testing with another electrical device.

3. Restart the projector in the correct order and check that the Power LED is on.

4. If you have replaced the lamp recently, try resetting the lamp connections.

5. Replace the lamp module.

6. Put the old lamp back in the projector and have the projector serviced.

Problem: The lamp goes off

1. Power surges can cause the lamp to turn off. Re-plug power cord. When the Power LED

is on, press the power button.

2. Replace the lamp module.

3. Put the old lamp back in the projector and have the projector serviced.

Remote Control Problems

Problem: The projector does not respond to the remote control

1. Direct the remote control towards remote sensor on the projector.

2. Ensure the path between remote and sensor is not obstructed.

3. Turn off any fluorescent lights in the room.

4. Check the battery polarity.

5. Replace the battery.

6. Turn off other Infrared-enabled devices in the vicinity.

7. Have the remote control serviced.

– 53 –

DLP Projector—User’s Manual

Audio Problems

Problem: There is no sound

1. Adjust the volume on the remote control.

2. Adjust the volume of the audio source.

3. Check the audio cable connection.

4. Test the source audio output with other speakers.

5. Have the projector serviced.

Problem: The sound is distorted

1. Check the audio cable connection.

2. Test the source audio output with other speakers.

3. Have the projector serviced.

Having the Projector Serviced

If you are unable to solve the problem, you should have the projector serviced. Pack the projector in
the original carton. Include a description of the problem and a checklist of the steps you took when
trying to fix the problem: The information may be useful to service personnel. For servicing, return the
projector to the place you purchased it.

— 54 —

HDMI Q & A

Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI
cable?

Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High­Speed cables.

˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or

up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

˙High Speed (or “category 2”) HDMI cables have been tested to perform at speeds of 340Mhz

or up to 10.2Gbps, which is the highest bandwidth currently available over an HDMI cable
and can successfully handle 1080p signals including those at increased color depths and/or
increased refresh rates from the Source. High-Speed cables are also able to accommodate
higher resolution displays, such as WQXGA cinema monitors (resolution of 2560 x 1600).

Q. How do I run HDMI cables longer than 10 meters?

There are many HDMI Adopters working on HDMI solutions that extend a cable’s effective
distance from the typical 10 meter range to much longer lengths. These companies
manufacture a variety of solutions that include active cables (active electronics built into
cables that boost and extend the cable’s signal), repeaters, amplifiers as well as CAT5/6 and
fiber solutions.

DLP Projector—User’s Manual

Q. How can I tell if a cable is an HDMI certified cable?

All HDMI products are required to be certified by the manufacturer as part of the HDMI
Compliance Test Specification. However, there may be instances where cables bearing the
HDMI logo are available but have not been properly tested. HDMI Licensing, LLC actively
investigates these instances to ensure that the HDMI trademark is properly used in the
market. We recommend that consumers buy their cables from a reputable source and a
company that is trusted.

For more detail information check http://www.hdmi.org/learningcenter/faq.aspx#49

– 55 –

DLP Projector—User’s Manual

Specifications

Model

Display type

Resolution

Projection distance

Projection screen size

Projection lens

Zoom ratio

Vertical keystone
correction

Projection methods

Data compatibility

SDTV/EDTV/ HDTV

Video compatibility

H-Sync

V-Sync

Safety certification

Operation temperature

Dimensions

AC Input

Power consumption

Lamp

Audio speaker

Input Terminals

Output Terminals

Control Terminals

Security

DMD, 0.7" XGA, Type A DMD, 0.65" 1080p, S600 DMD, 0.67" WUXGA, Type A

XGA (1024 x 768) 1080P (1920 x 1080) WUXGA(1920×1200)

23.4" - 300" 30" - 300" 24.3" - 308"

FCC-B, cUL, UL, CE, CCC, KC, PSB, PCT, CB, ICES-300, UL (Argentina), Taiwan

SPECIFICATIONS

D967 D966HD D968U

1 - 10 m 1.2 - 10 m 1 - 10 m

Manual Zoom

1.15x 1.2x 1.2x

+/- 40 Degree

Front, Rear, Desktop/Ceiling (Rear, Front)

VGA, SVGA, XGA, WXGA, SXGA, SXGA+, UXGA, WUXGA, Mac

480i, 576i, 480p, 576p, 720p, 1080i, 1080p

NTSC, PAL, SECAM

15, 31~91.4KHz

24~30Hz, 47~120Hz

Green Mark, China ECO Label

5° ~ 40°C

332.8 mm (W) x255.0 mm (D) x 114.6 mm (H)

AC Universal 100-240V

300W (ECO), <0.5W(Stand By) / 370W (Normal), <0.5W(Stand By)

310W (Std.) / 245W (Eco)

3W mono

VGA IN x 2

Display Port x 1

Composite x 1

S-Video x 1

HDMI x 2

Audio-In RCA (L/R) x 1

Audio-In (Mini-Jack) x 1

VGA-Out (15pin D-Sub) x 1

Audio-Out (Mini-Jack) x 1

RS-232C

3D sync

Screen trigger: DC Jack x 1 (DC12V 200mA output function)

USB (Type mini B) - service only

RJ45

Kensington lock / Security Bar

Note: For questions regarding product specifications, please contact your local distributor.

— 56 —

Projection Distance vs. Projection Size

Projection Distance and Size Table

DLP Projector—User’s Manual

D967

Diagonal

length (inch)

30 2.00 1.50 1097.3 1280.2 56.5

40 2.67 2.00 1463.0 1706.9 75.3

60 4.00 3.00 2194.6 2560.3 112.9

80 5.33 4.00 2926.1 3413.8 150.6

100 6.66 5.00 3657.6 4267.2 188.2

120 8.00 6.00 4389.1 5120.6 225.9

140 9.33 7.00 5120.6 5974.1 263.5

160 10.66 8.00 5852.2 6827.5 301.1

190 12.66 9.50 6949.4 8107.7 357.6

230 15.33 11.50 8412.5 9814.6 432.9

280 18.66 14.00 10241.3

300 19.99 15.00 10972.8

Screen Size (feet) Projection distance (mm)

Width Hheght Wide Tele (mm)

－

－

Offset (A)

527.0

564.6

– 57 –

DLP Projector—User’s Manual

D966HD

Diagonal

length (inch)

30 2.18 1.23

40 2.9 1.63 1400.0 1700.0 70.0

60 4.36 2.45 2100.0 2550.0 110.0

80 5.81 3.27 2800.0 3400.0 150.0

100 7.26 4.08 3500.0 4250.0 190.0

120 8.71 4.9 4200.0 5100.0 220.0

140 10.17 5.72 4900.0 5950.0 260.0

160 11.62 6.54 5600.0 6800.0 300.0

190 13.8 7.76 6650.0 8080.0 350.0

230 16.7 9.39 8040.0 9780.0 430.0

280 20.33 11.44 9790.0

300 21.78 12.25 10490.0

Screen Size (feet) Projection distance (mm)

Width Height Wide Tele (mm)

－

1280.0 60.0

－

－

Offset (A)

520.0

560.0

D968U

Diagonal

length (inch)

30 2.12 1.32

40 2.83 1.77 1308.7 1516.4 45.2

60 4.24 2.65 1963.1 2274.5 67.8

80 5.65 3.53 2617.4 3032.7 90.5

100 7.06 4.42 3271.8 3790.9 113.1

120 8.48 5.30 3926.2 4549.1 135.7

140 9.89 6.18 4580.5 5307.2 158.3

160 11.30 7.06 5234.9 6065.4 180.9

190 13.42 8.39 6216.4 7202.7 214.9

230 16.25 10.16 7525.1 8719.1 260.1

280 19.78 12.36 9161.0 10614.5 316.6

300 21.19 13.25 9815.4

Screen Size (feet) Projection distance (mm)

Width Height Wide Tele (mm)

－

1137.3 33.9

－

Offset (A)

339.2

— 58 —

Timing Mode Table

DLP Projector—User’s Manual

SIGNAL RESOLUTION

NTSC － 15.734 60 ○ － － －

PAL/SECAM － 15.625 50 ○ － － －

VESA

720 x 400 31.5 70.1 － － ○ ○

720 x 400 37.9 85.04 － － ○ ○

640 x 480 31.5 60.0 － － ○ ○

640 x 480 37.9 72.8 － － ○ ○

640 x 480 37.5 75.0 － － ○ ○

640 x 480 43.3 85.0 － － ○ ○

800 x 600 35.2 56.3 － － ○ ○

800 x 600 37.9 60.3 － － ○ ○

800 x 600 46.9 75.0 － － ○ ○

800 x 600 48.1 72.2 － － ○ ○

800 x 600 53.7 85.1 － － ○ ○

800 x 600 76.3 120.0 － － ○ ○

1024 x 768 48.4 60.0 － － ○ ○

H-SYNC

( KHZ )

V-SYNC

( HZ )

COMPOSITE

S_VIDEO

COMPONENT

RGB

(ANALOG)

DP/HDMI

(DIGITAL)

1024 x 768 56.5 70.1 － － ○ ○

1024 x 768 60.0 75.0 － － ○ ○

1024 x 768 68.7 85.0 － － ○ ○

1024 x 768 97.6 120.0 － － ○ ○

1152 x 864 67.5 75.0 － － ○ ○

1280 x 720 45.0 60.0 － － ○ ○

1280 x 720 90.0 120.0 － － ○ ○

1280 x 768 47.4 60.0 － － ○ ○

1280 x 768 47.8 59.9 － － ○ ○

1280 x 800 49.7 59.8 － － ○ ○

1280 x 800 62.8 74.9 － － ○ ○

1280 x 800 71.6 84.9 － － ○ ○

1280 x 800 101.6 119.9 － － ○ ○

1280 x 1024 64.0 60.0 － － ○ ○

1280 x 1024 80.0 75.0 － － ○ ○

1280 x 1024 91.1 85.0 － － ○ ○

1280 x 960 60.0 60.0 － － ○ ○

1280 x 960 85.9 85.0 － － ○ ○

1366 x 768 47.7 60.0 － － ○ ○

1400 x 1050 65.3 60.0 － － ○ ○

– 59 –

DLP Projector—User’s Manual

SIGNAL RESOLUTION

1440 x 900 55.9 60.0 － － ○ ○

1440 x 900 70.6 75.0 － － ○ ○

1600 x1200 75.0 60 － － ○ ○

1680 x 1050 64.7 59.9 － － ○ ○

1680 x 1050 65.3 60.0 － － ○ ○

1920 x 1200 74.0 60.0 － － ○ ○

1920 x 1080 67.5 60.0 － － ○ ○

640 x 480 35.0 66.7 － － ○ ○

Apple
Macintosh

SDTV

EDTV

832 x 624 49.7 74.5 － － ○ ○

1024 x 768 60.2 74.9 － － ○ ○

1152 x 870 68.7 75.1 － － ○ ○

480i 15.734 60.0 － ○ － ○

576i 15.625 50.0 － ○ － ○

576p 31.3 50.0 － ○ － ○

480p 31.5 60.0 － ○ － ○

H-SYNC

( KHZ )

V-SYNC

( HZ )

COMPOSITE

S_VIDEO

COMPONENT

RGB

(ANALOG)

DP/HDMI

(DIGITAL)

720p 37.5 50.0 － ○ － ○

720p 45.0 60.0 － ○ － ○

1080i 33.8 60.0 － ○ － ○

1080i 28.1 50.0 － ○ － ○

HDTV

O：Frequency supported

—：Frequency not supported



The native resolution of the panel is 1920x1080 (1080P) / 1024x768(XGA)

Resolution others than native resolution may be display with uneven size of text or line

The color of mean Displayable only. (4:3 only)

The color of mean may have a little noise is acceptable. Because video mode sync don’t auto adjustment.

HDTV timing main check tool is DVD player, VG828 is secondary

1080p 27 24.0 － ○ － ○

1080p 28 25.0 － ○ － ○

1080p 33.7 30.0 － ○ － ○

1080p 56.3 50.0 － ○ － ○

1080p 67.5 60.0 － ○ － ○

— 60 —

Projector Dimensions

DLP Projector—User’s Manual

332.8

255.0

– 61

–

107.0

109.5

114.6

DLP Projector—User’s Manual

REGULATORY COMPLIANCE

FCC Warning

This equipment has been tested and found to comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own expense.

Changes or modifications not expressly approved by the parties responsible for compliance could
void the user’s authority to operate the equipment.

Canada

This class B digital apparatus complies with Canadian ICES-003.

Safety Certifications

FCC-B, UL/cUL, UL, CE, CCC, KC, PSB, PCT, CB, ICES-300, UL (Argentina), Taiwan Green Mark,
China ECO Label

— 62 —

RS-232C Protocol

RS232 Setting

Minimum delay for next command: 1ms

Control Command Structure

Header code Command code Data code End code

HEX Command Data 0Dh
ASCII ‘V’ Command Data CR

Baud rate: 9600
Parity
check:

None

Data bit: 8
Stop bit: 1

Flow
Control

None

DLP Projector—User’s Manual

APPENDIX I

Operation Command

Note:

XX=00-98, projector's ID, XX=99 is for all projectors

Return Result P=Pass / F=Fail

n: 0:Disable/1: Enable/Value(0~9999)

Command Group 00

ASCII HEX Function Description Return Result

VXXS0001 56h Xh Xh 53h 30h 30h 30h 31h 0Dh Power On P/F

VXXS0002 56h Xh Xh 53h 30h 30h 30h 32h 0Dh Power Off P/F

VXXS0003 56h Xh Xh 53h 30h 30h 30h 33h 0Dh Resync P/F

VXXG0004 56h Xh Xh 47h 30h 30h 30h 34h 0Dh Get Lamp Hours Pn/F

VXXS0005n 56h Xh Xh 53h 30h 30h 30h 35h nh 0Dh Set Air filter timer n=0~999999 P/F

VXXG0005 56h Xh Xh 47h 30h 30h 30h 35h 0Dh Get Air filter timer n=0~999999 Pn/F

VXXS0006 56h Xh Xh 53h 30h 30h 30h 36h 0Dh System Reset P/F

0: Reset

VXXG0007 56h Xh Xh 47h 30h 30h 30h 37h 0Dh Get System Status

VXXG0008 56h Xh Xh 47h 30h 30h 30h 38h 0Dh Get F/W Version Pn/F

VXXG0009 56h Xh Xh 47h 30h 30h 30h 39h 0Dh Get Alter EMail Pn/F

VXXS0009n 56h Xh Xh 53h 30h 30h 30h 39h nh 0Dh Set Alter Email

1:Standby
2:Operation
3:Cooling

n=[e-mail].
xx

Pn/F

P/F

– 63 –

DLP Projector—User’s Manual

Command Group 01

ASCII HEX Function Description Return Value

VXXG0101 56h Xh Xh 47h 30h 31h 30h 31h 0Dh Get Brightness n=0~100 Pn/F

VXXS0101n 56h Xh Xh 53h 30h 31h 30h 31h nh 0Dh Set Brightness n=0~100 P/F

VXXG0102 56h Xh Xh 47h 30h 31h 30h 32h 0Dh Get Contrast n=0~100 Pn/F

VXXS0102n 56h Xh Xh 53h 30h 31h 30h 32h nh 0Dh Set Contrast n=0~100 P/F

VXXG0103 56h Xh Xh 47h 30h 31h 30h 33h 0Dh Get Color n=0~100 Pn/F

VXXS0103n 56h Xh Xh 53h 30h 31h 30h 33h nh 0Dh Set Color n=0~100 P/F

VXXG0104 56h Xh Xh 47h 30h 31h 30h 34h 0Dh Get Tint n=0~100 Pn/F

VXXS0104n 56h Xh Xh 53h 30h 31h 30h 34h nh 0Dh Set Tint n=0~100 P/F

VXXG0105 56h Xh Xh 47h 30h 31h 30h 35h 0Dh Get Sharpness 0~31 Pn/F

VXXS0105n 56h Xh Xh 53h 30h 31h 30h 35h nh 0Dh Set Sharpness 0~31 P/F

0:Warm

VXXG0106 56h Xh Xh 47h 30h 31h 30h 36h 0Dh Get Color Temperature

VXXS0106n 56h Xh Xh 53h 30h 31h 30h 36h nh 0Dh Set Color Temperature

VXXG0107 56h Xh Xh 47h 30h 31h 30h 37h 0Dh Get Gamma

VXXS0107n 56h Xh Xh 53h 30h 31h 30h 37h nh 0Dh Set Gamma

Command Group 02

ASCII HEX Function Description Return Value

VXXS0201 56h Xh Xh 53h 30h 32h 30h 31h 0Dh Select RGB P/F

VXXS0202 56h Xh Xh 53h 30h 32h 30h 32h 0Dh Select RGB2 P/F

VXXS0203 56h Xh Xh 53h 30h 32h 30h 33h 0Dh Select DVI P/F

VXXS0204 56h Xh Xh 53h 30h 32h 30h 34h 0Dh Select Video P/F

VXXS0205 56h Xh Xh 53h 30h 32h 30h 35h 0Dh Select S-Video P/F

VXXS0206 56h Xh Xh 53h 30h 32h 30h 36h 0Dh Select HDMI P/F

VXXS0207 56h Xh Xh 53h 30h 32h 30h 37h 0Dh Select BNC P/F

VXXS0208 56h Xh Xh 53h 30h 32h 30h 38h 0Dh

VXXS0209 56h Xh Xh 53h 30h 32h 30h 39h 0Dh Select HDMI 2 P/F

VXXS0210 56h Xh Xh 53h 30h 32h 31h 30h 0Dh Select DP P/F

Select
Component

1:Normal
2:Cold

0:Warm
1:Normal
2:Cold

0:1.8
1:2.0
2:2.2
3:2.4
4:B&W
5:Linear
0:1.8
1:2.0
2:2.2
3:2.4
4:B&W
5:Linear

P/F

Pn/F

P/F

Pn/F

P/F

— 64 —

DLP Projector—User’s Manual

Command Group 02

ASCII HEX Function Description Return Value

Return
1:RGB
2:RGB2
3:DVI
4:Video

VXXG0220 56h Xh Xh 47h 30h 32h 32h 30h 0Dh Get Current Source

5:S-Video
6:HDMI
7:BNC
8:Component
9:Display Port
10:.HDMI2

Command Group 03

ASCII HEX Function Description Return Value

0:Fill
1:4:3

VXXG0301 56h Xh Xh 47h 30h 33h 30h 31h 0Dh Get Scaling

VXXS0301n 56h Xh Xh 53h 30h 33h 30h 31h nh 0Dh Set Scaling

VXXG0302 56h Xh Xh 47h 30h 33h 30h 32h 0Dh Blank Pn/F

VXXS0302n 56h Xh Xh 53h 30h 33h 30h 32h nh 0Dh Blank P/F

VXXG0303 56h Xh Xh 47h 30h 33h 30h 33h 0Dh Auto Keystone On Pn/F

VXXS0303n 56h Xh Xh 53h 30h 33h 30h 33h nh 0Dh Auto Keystone On P/F

VXXG0304 56h Xh Xh 47h 30h 33h 30h 34h 0Dh Freeze On Pn/F

VXXS0304n 56h Xh Xh 53h 30h 33h 30h 34h nh 0Dh Freeze On P/F

VXXG0305 56h Xh Xh 47h 30h 33h 30h 35h 0Dh Volume n=0~10 Pn/F

VXXS0305n 56h Xh Xh 53h 30h 33h 30h 35h nh 0Dh Volume n=0~10 P/F

VXXG0306 56h Xh Xh 47h 30h 33h 30h 36h 0Dh Treble n=0~16 Pn/F

VXXS0306n 56h Xh Xh 53h 30h 33h 30h 36h nh 0Dh Treble n=0~16 P/F

VXXG0307 56h Xh Xh 47h 30h 33h 30h 37h 0Dh Bass n=0~16 Pn/F

VXXS0307n 56h Xh Xh 53h 30h 33h 30h 37h nh 0Dh Bass n=0~16 P/F

VXXG0308 56h Xh Xh 47h 30h 33h 30h 38h 0Dh Projection Mode

VXXS0308n 56h Xh Xh 53h 30h 33h 30h 38h nh 0Dh Projection Mode

VXXG0309 56h Xh Xh 47h 30h 33h 30h 39h 0Dh

VXXS0309n 56h Xh Xh 53h 30h 33h 30h 39h nh 0Dh

Set vertical keystone
value
Set vertical keystone
value

2:16:9
3:Letter Box
4:Native
5:2.35:1
0:Fill
1:4:3
2:16:9
3:Letter Box
4:Native
5:2.35:1

0:Front
1:Rear
2:Ceiling
3:Rear+Ceiling
0:Front
1:Rear
2:Ceiling
3:Rear+Ceiling

n=-40~+40 Pn/F

n=-40~+40 P/F

Pn/F

Pn/F

P/F

Pn/F

P/F

– 65 –

DLP Projector—User’s Manual

Command Group 03

ASCII HEX Function Description Return Value

VXXG0310 56h Xh Xh 47h 30h 33h 31h 30h 0Dh

VXXS0310n 56h Xh Xh 53h 30h 33h 31h 30h nh 0Dh

VXXG0311 56h Xh Xh 47h 30h 33h 31h 31h 0Dh Adjust the zoom n=-10~+10 Pn/F

VXXS0311n 56h Xh Xh 53h 30h 33h 31h 31h nh 0Dh Adjust the zoom n=-10~+10 P/F

VXXG0312 56h Xh Xh 47h 30h 33h 31h 32h 0Dh Adjust the focus n=-20~+20 Pn/F

VXXS0312n 56h Xh Xh 53h 30h 33h 31h 32h nh 0Dh Adjust the focus n=-20~+20 P/F

VXXG0313 56h Xh Xh 47h 30h 33h 31h 33h 0Dh

VXXS0313n 56h Xh Xh 53h 30h 33h 31h 33h nh 0Dh

VXXG0314 56h Xh Xh 47h 30h 33h 31h 34h 0Dh

VXXS0314n 56h Xh Xh 53h 30h 33h 31h 34h nh 0Dh

VXXG0315 56h Xh Xh 47h 30h 33h 31h 35h 0Dh 3D

VXXS0315n 56h Xh Xh 53h 30h 33h 31h 35h nh 0Dh 3D

VXXG0316 56h Xh Xh 47h 30h 33h 31h 36h 0Dh 3D Sync Invert

VXXS0316n 56h Xh Xh 53h 30h 33h 31h 36h nh 0Dh 3D Sync Invert

VXXG0317 56h Xh Xh 47h 30h 33h 31h 37h 0Dh 3D Format

VXXS0317n 56h Xh Xh 53h 30h 33h 31h 36h nh 0Dh 3D Format

Set horizontal keystone
value
Set horizontal keystone
value

Adjust the vertical lens
shift

Adjust the vertical lens
shift

Adjust the horizontal
lens shift

Adjust the horizontal
lens shift

Command Group 04 (Remote Control)

n=-20~+20 Pn/F

n=-20~+20 P/F

n=-20~+20 Pn/F

n=-20~+20 P/F

n=-20~+20 Pn/F

n=-20~+20 P/F

0:Off
1:DLP-Link
2:IR

0:Off
1:DLP-Link
2:IR

0:Off
1:On

0:Off
1:On

0:Frame Packing
1:Top/Bottom
2:Side-By-Side
3:Frame Sequential

0:Frame Packing
1:Top/Bottom
2:Side-By-Side
3:Frame Sequential

Pn/F

P/F

Pn/F

P/F

Pn/F

P/F

ASCII HEX Function Description Return Value

VXXS0401 56h Xh Xh 53h 30h 34h 30h 31h 0Dh UP arrow P/F

VXXS0402 56h Xh Xh 53h 30h 34h 30h 32h 0Dh DOWN arrow P/F

VXXS0403 56h Xh Xh 53h 30h 34h 30h 33h 0Dh LEFT arrow P/F

VXXS0404 56h Xh Xh 53h 30h 34h 30h 34h 0Dh RIGHT arrow P/F

VXXS0405 56h Xh Xh 53h 30h 34h 30h 35h 0Dh POWER P/F

VXXS0406 56h Xh Xh 53h 30h 34h 30h 36h 0Dh EXIT P/F

VXXS0407 56h Xh Xh 53h 30h 34h 30h 37h 0Dh INPUT P/F

VXXS0408 56h Xh Xh 53h 30h 34h 30h 38h 0Dh AUTO P/F

— 66 —

DLP Projector—User’s Manual

Command Group 04 (Remote Control)

ASCII HEX Function Description Return Value

VXXS0409 56h Xh Xh 53h 30h 34h 30h 39h 0Dh KEYSTONE+ P/F

VXXS0410 56h Xh Xh 53h 30h 34h 31h 30h 0Dh KEYSTONE- P/F

VXXS0411 56h Xh Xh 53h 30h 34h 31h 31h 0Dh MENU P/F

VXXS0412 56h Xh Xh 53h 30h 34h 31h 32h 0Dh STATUS P/F

VXXS0413 56h Xh Xh 53h 30h 34h 31h 33h 0Dh MUTE P/F

VXXS0414 56h Xh Xh 53h 30h 34h 31h 34h 0Dh ZOOM+ P/F

VXXS0415 56h Xh Xh 53h 30h 34h 31h 35h 0Dh ZOOM- P/F

VXXS0416 56h Xh Xh 53h 30h 34h 31h 36h 0Dh BLANK P/F

VXXS0417 56h Xh Xh 53h 30h 34h 31h 37h 0Dh FREEZE P/F

VXXS0418 56h Xh Xh 53h 30h 34h 31h 38h 0Dh VOLUME+ P/F

VXXS0419 56h Xh Xh 53h 30h 34h 31h 39h 0Dh VOLUME- P/F

VXXS0420 56h Xh Xh 53h 30h 34h 32h 30h 0Dh Enter P/F

– 67 –

DLP Projector—User’s Manual

D967 / D966HD / D968U family

The following model names belong to the D967 / D966HD / D968U family:

D967 D966HD D968U

D96GAA D96FHDAA D96HUAA

D96GAC D96FHDAC D96HUAB

D96GBC D96FHDBC D96HUAC

D96GCC D96FHDCC D96HUBC

D96GDC D96FHDDC D96HUCC

D96GEC D96FHDEC D96HUDC

APPENDIX II

D96GFC D96FHDFC D96HUEC

D96GGC D96FHDGC D96HUFC

D96GHC D96FHDHC D96HUGC

D96GIC D96FHDIC D96HUHC

D96GJC D96FHDJC D96HUIC

D96HUJC

Note:

The model names may vary in different regions, and may not be on the above list. For actual
family and specification, please contact your local retailer or service center for details.

— 68 —
