D935VX/D940VX

Versatile Crossover Projection Solutions

An excellent solution for home and office use, the
Vivitek D935VX and D940VX digital projectors deliver
brightness and feature-rich functionality.

The D935VX/D940VX bring connectivity options like
HDMI v1.3 and superior picture quality with
VividWheel III to make the ideal crossover video
projectors.

With DLP® and BrilliantColor™ technologies from
Texas Instruments, the Vivitek D935VX/D940VX
present images that last longer and stay brighter
over time.

Features

DLP® and BrilliantColor™ technologies for sharp

and detailed image quality

VividWheel III for improved color reproduction

through automatic gain control

New generation of high-efficiency lamps that last

up to 4000 hours (in economy mode)

Keypad lock prevents accidental system

adjustments

3000/4000 lumens (D935VX/D940VX) of brightness

with a 2400:1 contrast

Connectivity options include: HDMI v1.3, two (2)

VGA-in, Composite Video, S-Video

3:2/2:2 pull-down eliminates jagged images from

interlaced video and ensures crisp, clean images

Network-ready for integration and system

administration via RJ45

Top-loading, sliding cover for quick and easy lamp

replacement

Specifications

Brightness (Typical) 3000/4000 Lumens (D935VX/D940VX)
Native Resolution XGA (1024 x 768)
Max. Resolution SXGA+ (1400 x 1050)
Contrast Ratio 2400:1 (Full On/Off)

Lamp Life and Type ≈3000/4000 Hours (Standard/Economy Mode),

Lamp Part # 5811100686
Display Type Single 0.7” DLP® Technology by Texas Instruments
Throw Ratio 1.8 to 2.1:1(Distance/Width)

Image Size (Diagonal) 23" to 300" (0.6 to 7.6 m)
Projection Distance 3’ to 30’ (0.9 to 9.1 m)
Projection Lens F=2.55-2.72, f=21.3-24.5mm
Zoom Ratio 1.15:1 Manual Zoom/Focus
Aspect Ratio 4:3 Native, 16:9 Compatible
Offset 130%
Keystone Correction ±15° Vertical

Color Spectrum 16.7 Million
Horizontal Scan Rate 15, 30 to 90 KHz
Vertical Scan Rate 43 to 85 Hz
Speaker 3W Mono
Remote Control Fully Featured IR Remote with Laser Pointer and

Projection Method Table Top or Ceiling Mount (Front or Rear)
Uniformity 85%
Computer

Compatibility

Video Compatibility EDTV (480p), HDTV (576i, 720p, 1080i) thru RGB,

I/O Connection Ports HDMI v1.3, VGA-In (x2), Composite Video,

Security Kensington® Lock Port, Security Bar
Weight 7.7 lbs (3.5 kg)
Dimensions (W x H x D) 13.2" x 4" x 10" (355 x 102 x 256 mm)
Noise Level 34dB/29dB (Standard/Economy Mode)
Power Supply: AC 100-240V, 50/60Hz

Operating Temperature 41 to 104°F (5 to 40°C)

Warranty 1-Year Limited Warranty, 90-Day Lamp Warranty
Standard Accessories AC Power Cord, VGA Cable, Carrying Case,

Optional Accessories Replacement Lamp, Remote, Carrying Case
UPC 8 14964 33439 8/8 14964 33440 4 (D935VX/D940VX)

230W

Mouse

SXGA+, SXGA, XGA, SVGA, VGA Resized; VESA
Standards; PC and Macintosh Compatible

NTSC/NTSC 4.43, PAL B/G/H/I/M/N 60, SECAM

S-Video, RCA Audio-In, Mini-Jack Audio-In,
Mini-Jack Audio-Out, VGA-Out, USB (Service),
RS-232c, RJ45

Consumption: 240w (Economy Mode), 290W
(Standard Mode), <1W (Standby Mode)

Remote Control, Batteries for Remote, Lens Cap,
User Manual (CD), Warranty Card
