Operation Manual Operation Manual
U.S. Registered Trademark. Patents pending
Copyright 2018 All Rights Reserved.
Table of Contents
Table of Contents
Thermostat Operation
Thermostat Quick Reference
Thermostat Warranty Information
Page
2-3
4-6
7
1
Una version en español de este
manual se puede descargar en la
pagina web de la compañia.
Equipment damage hazard.
Do not operate the cooling
system if the outdoor
temperature is below 50 ˚F
(10 ˚C) to prevent possible
compressor damage.
Caution
Rev. 1821
TP-N-631W
Vive Comfort
Toll Free : 888-776-1427
Web: www.vivecomfort.com
Hours of Operation: M-F 9AM - 6PM Eastern
P.O. Box 3377
Springeld, MO 65808-3377
Thermostat OperationThermostat Operation
LCD
Fan Switch
System Switch
Temperature Setpoint Buttons
LCD Display
Fan Switch
System Switch
Temperature Setpoint Buttons
See page 6 for details about
this display read out.
AUTO will cycle the fan on
only when the heating or
cooling system is on. Select
LOW or HIGH for the fan
to run continuously at the
selected speed.
Selects the operation mode
on your HVAC system.
Selecting HEAT turns on
the heat mode. Selecting
COOL turns on the cool
mode. Selecting OFF turns
both heating and cooling
o.
Press the + or - buttons to
select the desired room
temperature.
LOW
HIGH
Thermostat Quick Reference
The low battery indicator is displayed when the AA battery
power is low. If the user fails to replace the battery within 21
days, the screen will only show the low battery indicator but
maintain all functionality. If the user fails to replace the batteries
after an additional 21 days (days 22-42 since rst “low battery”
display) the setpoints will change to 55˚F (Heating) and 85˚F
(Cooling). If the user adjusts the setpoint away from either of
these, it will hold for 4 hours then return to either 55˚F or 85˚F.
After day 63 the batteries must be replaced immediately to
avoid freezing or overheating because the thermostat will shut
the unit o until the batteries are changed.
Important:
Battery Installation
Thermostat Quick Reference
Insert 2 AA Alkaline batteries (included). High
quality Alkaline batteries are recommneded.
Battery installation is
optional if thermostat is
hardwired (R and C
terminal connected to
24V power).
Warranty Information
Warranty Registration
Your new thermostat has a 5 year limited warranty. You must register
your thermostat within 60 days of installation. Without this
registration the warranty period will begin on date of manufacture.
For warranty issues please contact the HVAC professional that
installed this product. You can register your new thermostat in 2 ways:
Go to the company website, select warranty registration and
ll out a short registration form.
Complete the form below and mail it to the address shown.
Warranty Registration
Complete form and mail to:
Thermostat Warranty Registration
Thermostat Quick Reference
Online
Mail
+1 will appear in the display
when the auxiliary heat is active.
Displays the user
selectable setpoint
temperature.
System Operation
Indicators: On will dis-
play when the COOL or
HEAT is on. The compressor delay feature is
active if ON is ashing.
Low Battery
Indicator: Replace
batteries when
indicator is shown.
Indicates the current
room temperature.
88
88
Vive Comfort
P.O. Box 3377
Springeld, MO 65808-3377
Name:
Address:
City:
State:
Zip:
Thermostat Model:
Date Installed:
Cut Out For
Warranty Registration
www.vivecomfort.com
