Vitesse VS-763 User Manual [ru]

NOU S VIVONS SAIN

We l iv e health y

VACUUM CLEANER

ПЫЛЕСОС

“Vitesse France S.A.R.L”

91 rue du Faubourg Saint Honore´ 75008 Paris-France

www.vitesse.ru

VS-763

DEAR CUSTOMER! You have made an excellent decision. Vitesse® “Nouveau” home range offers you an exclusive, high quality range of appliances for your ultimate home luxury and healthy living.

The Advantages:

1. With advanced exclusive Double-Cyclone cleaning system, Plus 2 HEPA filters, enabling a highest cleaning efficiency. Good for allergy people and asthmatics.

2. With advanced exclusive Double-Cyclone cleaning system, make this vacuum machine always with strong power, very less suction loss.

3. Super bigger power upto 2200W max., 28Kpa. (at 220-240V).

4. Super bigger dust capacity up to 4 L.

5. Super longer filter using life, almost 1 year no need any filters cleaning or replacement.

IMPORTANT SAFEGUARDS When using an electrical appliance, basic safety precautions should always be observed, including the following. READ ALL INSTRUCTIONS BEFORE USING YOUR HEAVY DUTY VACUUM. WARNING: To reduce the risk of fire, electrical shock, or injury:

1. Do not leave appliance when plugged in. Unplug from outlet when not in use.

2. Do not use outdoors or on wet surfaces.

3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.

4. Use only as described in this manual. Use only manufacturer's recommended attachments.

5. Do not use with damaged cord or plug. Do not use vacuum if it has been dropped, damaged, left outdoors, or dropped in water. Return it to an authorized service center.

6. Do not pull or carry by cord, use cord as a handle, close a door on cord,or pull cord around sharp edges or corners.

7. Do not run appliance over cord. Keep cord away from heated surfaces.

8. Do not unplug by pulling on cord. To unplug, grasp the plug, not thecord.

9. Do not handle plug or appliance with wet hands.

10. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and anything that may reduce airflow.

11. Keep hair, loose clothing, fingers, and all parts of body away fromo p e n i n g s and moving parts.

12. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or got ashes.

13. Turn off the control before unplugging.

14. Use extra care when cleaning on stairs.

15. Do not use to pick up flammable or combustible liquids such as gasoline or

use in areas where they may be present.

16. Look on your vacuum cleaner and follow all label and marking instructions.

17. Keep end of hose, wands and other openings away from your face and body.

18. Do not use the vacuum cleaner without dust cup filter in place.

19. Always unplug this appliance before connecting or disconnecting hand vacuum hose.

20. Store the hand vacuum indoors. Put the hand vacuum away after us to prevent tripping accidents.

21. Using improper voltage may result in damage to the motor and possible injury to the user. Correct voltage is listed on the rating label.

22. Use only on dry, indoor surfaces.

23. Do not use for any purpose other than described in this user's guide.

24. If the cleaner is damaged, it must be repaired by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

Product and accessories:

P/1 P/2

PRECAUTIONARY MEASURES Firstly opening the sucks in the air, to check if the suction pipe or hose somewhere inside are blocked, you should switch off the vacuum cleaner at once if such things happened. First clear the blocked substance before you attempt to start the vacuum cleaner again.

1. Do not operate the vacuum cleaner too close to heaters like radiators, cigarette bud etc.

2. Before you insert the plug into the wall contact, make sure your hand is dry.

** Removing the flexible hose from vacuum machine: Removing the plug from the power socket. Press release button on hose joint to remove the flexible hose from the vacuum machine.

2. Fixing the extension tubes and accessories a. Fixing the telescopic tube to the handle.

3. Before you start using the vacuum cleaner, please remove large or sharp objects from the floor in order to prevent the vacuum is damaged.

4. When you want to pull the plug from the wall contact, please do this at the plug itself and not by means of the electrical cable.

This vacuum cleaner is equipped with a plug and a cable which rolls up automatically. If anything gets damaged,both the plug and the cable must be repaired by a qualified repairman or electrician.

ASSEMBLING VACUUM CLEANER Always remove the plug from the power socket before fitting or removing accessories!

1. Equipping vacuum cleaner a. Fixing the flexible hose on vacuum machine:

Insert hose joint into the air intake duct on the front of appliance. Press until

it clicks into position.

b. Fixing the brush to the extension tube.

c. Fixing Floor brush Ideal for the daily cleaning on carpets and hard floors.

P/3 P/4
