VT-DVP Package
Complete Customized
Surveillance System
VT-DVP PACKAGE CONFIGURATION:
960 Digital Video Recorder:
• 960H 4 or 8 Channel 960H Digital Video Recorder
VT-SRL 904 or 908 Digital Video Recorder (DVR): 4 or 8 Channel Real Time Digital Video Recorder with 500GB, 1TB,
or 2TB Internal Storage options for recording months of continuous High Resolution video.
Cameras:
• VTC-BCR424M: Day/Night Infrared Ball Camera with 700 TV Lines
• VTC-IRB424M: Day/Night Infrared Bullet Camera with 700 TV Lines
These All New Highly Advanced 960H Ball and Bullet cameras are also ultra versatile and feature rich. These Indoor/
Outdoor Cameras offer programmable OSD (On Screen Display) enabling field adjustments of Dynamic IR, De-Fogging
Function, Backlighting and Highlight Masking among many other options.
Accessories:
• VT-12VDC-1000S: (4) / (8) 1Amp Slim Case 12VDC Camera Transformer
• VT-RG182-50: (4) / (8) 50’Mini Coaxial Video/Power Cable
• Remote Control: System Control
• USB Stick: Documentation/software for Mac OSX and Windows
• USB Mouse: System Control
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VT-DVP Package
VT-SRL Series
Spire Series 4 or 8 Channel 960H Digital Video Recorders
Complete Customized
Surveillance System
VT-SRL Series
DVR Features
• Supports High Resolution 960H Cameras
• 4 or 8 Video Inputs with 1 HDMI, 1 Spot Monitor Output, and 1
VGA output
• H.264 Compression
• Up to240fps Live Display &240fps Recording (VT-SRL908) /
120/120 (VT-SRL904)
• Supports both Dynamic and Static IP Addresses
• 4 Alarm Inputs / 1 Relay Out
• Supports two internal Hard Drives (VT-SRL908) / One internal
Hard Drive (VT-SRL904)
• Remote Viewing over the Internet, LAN, Explorer, Safari, Firefox,
Opera and Chrome
• Applications for iPhone, iPad, iTouch and Android Devices
• Mac OSX Client & PC CMS Central Management Software
Included
• Thumbnail Search
•
Automatic sending of Health & Event notifications via
email
• Control locally via USB Mouse or with the Included IR
Remote control
• PTZ Control over RS-485
Intuitive configuration menu.
Remote Viewing over the Internet,
LAN, Explorer, Safari, Firefox,
Opera and Chrome
Remote Viewing Apps Available
for iPhone, iPad & Android
Devices
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
View backups on PC
computers using included
Backup Player Software
Included CMS Software allows
remote viewing & control of
multiple DVR’s even when located
at multiple locations!
Complete Customized
VT-DVP Package
Surveillance System
Detailed Specifications VT-SRL904 VT-SRL908
Video Input
Video Compression
FPS (Display / Recording)
Playback Rate
Operating System
Video Output
Split-Screen
Audio In/Out
Alarm In/Out
Storage
Archive
USB Port
System Control
Network
RJ-45 Ethernet Port
Search
PTZ
Recording Resolution Setting
Recording Quality Control
Recording Modes
Panic Record
Pre-recording
Post-recording
Motion Detection
Player
E-mail notification
System Configuration
Bandwidth limit
Two-Way Audio
Power
Operating Temperature
Humidity
Case Form Factor
Dimensions (W x H x D)
Weight
120FPS @ 960H / 120FPS @ CIF
4 Channels
H.264
120 / 120 (CIF, 2CIF, D1, 960H)
Live: 1, 4, SEQ, Playback: 1, 4
1 Internal HDD (SATA)
10/100Mbps
By each camera for different resoultion setting(CIF/2CIF/D1/960H)
Overrides all other recording settings to provide the best quality recording
10” x 1.85” x 7.25”
3.3 lbs. (1.5kg)
Linux
VGA / HDMI / Spot BNC
4 Line In (1/8”) / 1 Line Out (1/8”)
4 Alarm Inputs / 1 Outputs with 1 Relay
USB Device & Network
2 Front USB Ports
USB Mouse, Included IR Remote Control
TCP/IP, HTTP, DHCP (DDNS)
Thumbnail, Calendar, Event
1 - RS-485
4 Levels (Low/Standard/High/Highest)
Continuous, Schedule, Alarm, and Panic
Max. 5 seconds
Max. 180 seconds
Adjustable 20x12 Grid with 30 Steps Sensitivity Level
Backup player, and HDD PC Viewer
E-mails to specific users to notify events
Full setup configuration over network
YES: Adjustable by User
YES
DC12V, Adaptor, 3.3A, 100~240V AC, 50-60Hz
32° ~ 104°F (0° ~ 40°C)
10 ~ 90% NC
1.0U
8 Channels
240 / 240 (CIF, 2CIF, D1, 960H)
240FPS @ 960H / 240FPS @ CIF
Live: 1,4,6,8,9, SEQ / Playback: 1, 4, 9
2 Internal HDD (SATA)
10/100/1000Mbps
Thumbnail, Calendar, Event
1 - RS-485
12” x 1.85” x 12.25”
6.85 lbs. (3.1kg)
H.264
VT-SRL904 VT-SRL908
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VT-DVP Package
Complete Customized
Surveillance System
VTC-BCR424M
Day/Night Infrared Ball Camera with 700 TV Lines
Camera Features
• High Density 1/4” Super DIS
• 700 TV Lines of Resolution
• 24 Infrared LEDs with up to 50’ Range
• Dual Glass Compartments to help Eliminate Glare
• 3.0mm Standard Lens Included
• 12 VDC Operation
Detailed Specifications
Image Device
Resolution
Effective Pixels
Minimum illumination
Infrared LEDs
IR Distance
Built-In Lens
Scanning System
S/N Ratio
White Balance
Signal System
Weather Resistance
Power Source
Power Consumption
Operating Conditions
Dimension
1/4” Super DIS CMOS
700 TVL
720(H) x 480(V)
0Lux (IR LED ON)
24 IR LEDs
50 ft
3.0 mm Board Lens
2:1 Interlace
≥ 46dB
ATW
NTSC/PAL
IP65
DC12V ± 10%
80mA / 250mA (IR OFF/ON)
-22°F to +104°F (-30°C to +40°C)
3.66” x 2.95” (93mm x 75mm)
Weight
11.64 oz (330g)
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VT-DVP Package
Complete Customized
Surveillance System
VTC-IRB424M
Day/Night Infrared Ball Camera with 700 TV Lines
Camera Features
• High Density 1/4” Super DIS
• 700 TV Lines of Resolution
• 24 Infrared LEDs with up to 50’ Range
• Dual Glass Compartments to help Eliminate Glare
• 3.0mm Standard Lens Included
• IP66 Weather Resistance
• 12 VDC Operation
Detailed Specifications
Image Device
Resolution
Effective Pixels
Minimum illumination
Infrared LEDs
IR Distance
Day/Night
Built-In Lens
Scanning System
S/N Ratio
White Balance
Signal System
Weather Resistance
Power Source
Power Consumption
Operating Conditions
1/4” Super DIS CMOS
700 TVL
720(H) x 480(V)
0 Lux (IR LED ON)
24 IR LEDs
50 ft
Auto
3.0mm IR Corrected
2:1 Interlace
≥ 46dB
ATW
NTSC/PAL
IP66
DC12V ± 10%
80mA / 260mA (IR OFF/ON)
-22°F to +104°F (-30°C to +40°C)
Dimension
Weight
4.37” x 2.64” x 2.60” (111mm x 67mm x 66mm)
16.2 oz (450g)
