Visonic PMASTER360 User Manual

PowerMaster 360

Version 18

User's Guide

Table of Contents

1. Introduction ...................................................... 3

Preface ........................................................... 3

Overview ......................................................... 3

System Features ............................................ 3

PowerMaster 360 Panel Indicator .................. 4

Virtual Keypad Controls .................................. 5

VISONIConfig Controls ................................... 6

Virtual Keypad / VISONIConfig Display .......... 8

Screen Saver Mode ........................................ 8

Proximity Tags ................................................ 8

Users and Codes ............................................ 8

2. Operating the PowerMaster 360 System ....... 9

Preparing to Arm ............................................ 9

Arming ‘AWAY' / ‘HOME' ................................ 9

Disarming and Stopping Alarm ....................... 9

Disarming under Duress ............................... 10

Partition Selection Process........................... 10

Switching from ‘HOME’ to ‘AWAY’ ............... 10

Switching from ‘AWAY’ to ‘HOME’ ............... 10

Arming AWAY or HOME ‘Instant’ ................. 11

Forced Arming AWAY or HOME .................. 11

Arming in the Latchkey Mode ....................... 12

Initiating Panic Alarm .................................... 12

Initiating Fire Alarm or Emergency Alarm ..... 13

Chime ON/OFF ............................................. 13

3. Reviewing Troubles and Alarm memory ..... 14

Alarm & Tamper Memory Indication ............. 14

Clearing the Memory Indication .................... 14

Troubles ........................................................ 14

General Indications ....................................... 15

Correcting Trouble Situations ....................... 15

4. Menus and Functions .................................... 16

A.1 Entering the User Settings Menu &

Selecting a Setting Option ............................ 16

A.2 Returning to the Previous Step or Exiting

the USER SETTINGS Menu ........................ 18

A.3 Buttons used for Navigation & Setting ... 18

B.1 Setting the Zone Bypass Scheme .......... 18

B.2 Reviewing the Zone Bypass Scheme .... 20

B.3 Recalling the Zone Bypass Scheme ...... 20

B.4 Programming User Codes ..................... 21

B.5 Programming the Duress Code ............. 23

B.6 Add / Delete Proximity Tags .................. 23

B.7 Add / Delete Keyfob Transmitters ......... 25

B.8 Setting the Time & Time Format ........... 27

B.9 Setting the Date & Date Format ............ 28

B.10 Enabling / Disabling Auto-Arming ....... 29

B.11 Setting the Auto-Arming Time ............. 29

B.12 Programming Email, MMS and SMS

Reporting ..................................................... 30

B.13 Enabling / Disabling the Squawk Option

..................................................................... 35

B.14 Serial Number ..................................... 35

B.15 PowerLink Parameters ........................ 36

5. Event Reporting and Control by SMS ......... 37

Event notifications by SMS .......................... 37

Remote Control by SMS .............................. 38

6. Special Applications and Functions ........... 39

Looking after People Left at Home .............. 39

Acknowledging “low battery” condition in

Keyfobs ........................................................ 39

7. Testing the System ....................................... 40

Periodic Test ................................................ 40

Periodic Test per Partition ........................... 42

8. Maintenance .................................................. 44

Replacing the Backup Battery ..................... 44

Replacing Wireless Devices Batteries ......... 44

Accessing 24-Hour Zones ........................... 44

Cleaning the Control Panel .......................... 44

Event Log ..................................................... 44

Exiting the Event Log ................................... 45

APPENDIX A. FUNCTIONS OF CONTROLLING

DEVICES ......................................................... 46

A1. KP-160 PG2 .......................................... 46

A2. KP-140/141 PG2 ................................... 47

A3. KF-234 PG2 .......................................... 48

APPENDIX B. PARTITIONING .......................... 49

B1. Selecting a Partition .............................. 49

B2. Arming / Disarming the System ............. 49

B3. The Show Function ............................... 49

B4. Siren ...................................................... 50

B5. Partition Status display .......................... 50

D-305736 PowerMaster 360 User's Guide 1

B6. Common Areas ...................................... 50

APPENDIX C. GLOSSARY................................. 52

APPENDIX D. HOME FIRE ESCAPE PLANNING

.......................................................................... 55

APPENDIX E. SPECIFICATIONS ....................... 56

E1. Functional .................................................... 56

E2. Wireless ........................................................ 56

E3. Electrical ...................................................... 57

E4. Communication .......................................... 57

E5. Physical Properties .................................... 57

E6. Peripherals and Accessory Devices ........ 57

APPENDIX F. COMPLIANCE WITH

STANDARDS .................................................. 58

2 D-305736 PowerMaster 360 User's Guide

INTRODUCTION

1. Introduction

Preface

The PowerMaster 360 is a highly advanced wireless alarm control system produced by Visonic Ltd. Note: Make sure that you have the name and telephone number of the monitoring station your system will report

to. When calling the monitoring station to ask questions, you should have access to your "ACCOUNT NUMBER" used to identify your alarm system to the monitoring station. Obtain this information from your installer and write it.

Overview

The PowerMaster 360 is a wireless alarm system for detecting and alerting in case of burglary, fire and a variety of other security and safety hazards. In addition, it can be used to monitor the activity of disabled or elderly people left at home. System status information is presented visually.

The system includes an optional partition feature (for a description of this feature, refer to Appendix B). The PowerMaster 360 is governed by a control panel (Figure 1a) and Virtual Keypad (Figure 1b) / VISONIConfig

(Figure 1c) designed to collect data from various sensors that are strategically located within and along the perimeter of the protected site.

The alarm system can be armed or disarmed by a variety of keyfobs and keypads using special codes. In the disarmed state, the system provides you with visual status information, and initiates an alarm if smoke is detected or upon disturbance in a 24-hour zone (a zone which is active 24-hours a day). In the armed state, the system initiates an alarm upon detection of disturbance in any one of the armed zones. Proximity tags enable authorized people to enter restricted areas. The system identifies a wide range of events - alarms, attempts to tamper with sensors and several types of trouble. Events are automatically reported via form) and to private telephones (SMS messages) or emails (via the server). The person receiving such a message is expected to investigate the event and act accordingly.

IMPORTANT! All you need to know to secure your premises can be found in Chapter 2 of this manual.

If you are not familiar with some of the terms used here, refer to Appendix C at the end of this guide.

Note: This system must be checked by a qualified technician at least once a year.

Broadband or GPRS

communication to monitoring stations (in IP

System Features

Your PowerMaster 360 offers a large number of unique features:

• Master / User Settings: Two user levels allow different access types (see Chapter 4. Menus and Functions,

section B.4 Programming User Codes).

• 16 detector zones: Each detector zone is identified by zone number and name (location).

• Multiple arming modes: AWAY, HOME, AWAY- INSTANT, HOME-INSTANT, LATCHKEY and BYPASS.

• Virtual Keypad / VISONIConfig: Plain-language status information and prompts are displayed on the Virtual

Keypad / VISONIConfig.

• Real-time clock: The present time is visible on the Virtual Keypad display. This feature is also used for the

log file by providing the date and time of each event.

• Various reporting destinations: Events can be reported automatically to monitoring stations, private

telephones and mobile phones of your choice, and even by SMS if GSM is installed (see Chapter 4. Menus and Functions).

• Selective reporting: Your installer can determine what type of events will be reported to which destination.

• Latchkey mode: An automatic “Latchkey” message is sent to chosen telephones if the system is disarmed by

a “latchkey” user (a junior family member, for instance). (See Chapter 2.)

• Access from remote telephones: You may access the PowerMaster 360 from a remote telephone and

Arm/Disarm it or receive system status information (see Chapter 5).

• Numerical keys serve as function keys: When the system is disarmed, the numerical keys are used also to

control various system functions. A simple icon on each key identifies the task of that key.

• Data retrieval: You can obtain status information, trouble information and review memorized alarm events

visually (see Chapter 3).

• Event log: System events are memorized in an event log that stores the most recent events, each tagged

with the time and date of the event. You can access this log and review the past events in case of need such as after a burglary (see Chapter 8. Maintenance).

D-305736 PowerMaster 360 User's Guide 3

INTRODUCTION

• Looking after elderly, physically handicapped and infirm individuals: The system can be programmed to

monitor people activity within the protected area and send out an alert message if no movement is detected in the area for a predefined period of time (See Chapter 4. Menus and Functions).

• Distress calls: Keyfobs may be used to activate this function by the simultaneous pressing of two buttons.

• Disarming under duress: If a user is forcibly compelled to disarm the system, he can do so using a special

code ("Duress Code") that disarms the system as usual, but also sends a silent alarm to the monitoring station (see Chapter 2. Operating the PowerMaster 360 System).

• System supervision: All wireless peripherals within the protected site send periodic keep alive supervision

messages. If such a message is overdue, the Virtual Keypad displays a 'missing' trouble message. Your installer can disable this feature if so desired.

• Battery supervision: The PowerMaster 360 continuously monitors the battery condition of the sensors and

devices in the system and the Virtual Keypad displays a ‘Low Battery’ message whenever a battery needs to be replaced within a maximum of 30 days. Wireless sirens can still provide 2 siren alarms before the siren becomes totally inactive.

Note: When the ‘Low Battery’ message is received, the battery should be replaced within 7 days.

PowerMaster 360 Panel Indicator

No. Function

Power (Green): Indicates that your system is properly connected to the power outlet.

Arming Status (Green / Flashing Red / Red): Indicates DISARMED / HOME / AWAY.

Trouble (Orange): Lights when the system is in a state of trouble (see Chapter 3).

Service Server (Blue): Lights when the system is connected to the security server.

Smart Home Service (Blue): Lights when the system is connected to the smart home server.

WiFi (Green): Indicates if the WiFi module is enabled / disabled.

Figure 1a. PowerMaster 360 LED Indicators

4 D-305736 PowerMaster 360 User's Guide

Virtual Keypad Controls

Virtual Keypad

Display

INTRODUCTION

Figure 1b. Virtual Keypad Controls and Display

Control Keys

Indication Function

NEXT: Advance from item to item within a given menu.

BACK: Move one step back within a given menu.

UP:

Use to move one level up in the menu or to return to previous setting step.

OK: Review status messages one by one and also select a displayed option.

Arming Keys

Indication Function

AWAY: Arming when nobody is at home

HOME:

INSTANT: Canceling the entry delay upon arming (AWAY or HOME)

DISARM / OFF: Disarming the system and stopping alarms

D-305736 PowerMaster 360 User's Guide 5

Arming when people remain at home.

INTRODUCTION

Display

Other Keys

Indication Function

Chime ON/OFF

Reviewing the event log

Emergency

Fire

Panic

Note: The above buttons are identical in function to the corresponding buttons shown throughout the document.

VISONIConfig Controls

Virtual Keypad

Figure 1b. VISONIConfig Controls and Display

6 D-305736 PowerMaster 360 User's Guide

LED Icons

Indication Function

Power

Armed

Trouble

Active service to the server

WiFi connection

Control Keys

Indication Function

OFF: Delete a device

NEXT: Advance from item to item within a given menu.

BACK: Move one step back within a given menu.

INTRODUCTION

UP: Use to move one level up in the menu or to return to previous setting step.

OK: Review status messages one by one and also select a displayed option.

Arming Keys

Indication Function

AWAY: Arming when nobody is at home

HOME: Arming when people remain at home.

INSTANT: Canceling the entry delay upon arming (AWAY or HOME)

DISARM / OFF: Disarming the system and stopping alarms

Other Keys

Indication Function

Chime ON/OFF

Reviewing the event log

Emergency

Fire

Panic

Note: The above buttons are identical in function to the corresponding buttons shown throughout the document.

D-305736 PowerMaster 360 User's Guide 7

INTRODUCTION

Virtual Keypad / VISONIConfig Display

The Virtual Keypad / VISONIConfig displays system status and events, time and date, programming instructions and also an event log file which is accompanied by the date and time of each event. The normal display alternates with the time and the system status, for example:

READY HH:MM

(alternating)

READY MEMORY

Screen Saver Mode

For security reasons, it is sometimes required to hide the status indication (Virtual Keypad and LED display) from a potential intruder. If the Screen Saver option is enabled by the installer, then if no key is pressed for more than 30 seconds, the Virtual Keypad display will read “PowerMaster 360” and the LEDs will stop indicating any status. Pressing any key will resume the normal status display. Pressing the Fire or Emergency keys will also initiate the Fire or Emergency alarm. If configured by the installer for additional security, the system will ask you to enter your user code as well before resuming the normal display. When partition is enabled, the installer can configure the system so that if no key is pressed during more than 30 seconds the date and time will appear on the Virtual Keypad display.

Proximity Tags

Your system responds to valid proximity tags enrolled to the system. The proximity tag enables you to perform a variety of functions without entering user code, for example, arming, disarming, reading the event log, etc. Whenever the user code is required, you can simply present a valid proximity tag and perform the desired operation without the need to key-in your user code.

When the system is disarmed, after presenting a valid proximity tag to the control panel, the message "<OK> for AWAY" is displayed. Now you can press the button to immediately arm the control panel, or wait for 3 second for system automatic AWAY arming (the message "Please exit now" will be displayed). Presenting the proximity tag once again will DISARM the system.

Instead of pressing the message "<OK> for HOME" / "<OK> for disarm" is displayed, accordingly) and then press the press button for HOME arming / disarming.

button (see above), you can press the

button once / twice (the

Users and Codes

As a master User (User No.1) you will need a 4-digit security code to master the system (code 0000 is not allowed).You can also authorize 7 other persons to use the system by providing them with their own security codes. Security codes are used mainly to arm and disarm the system or to access information that is restricted only to authorized users (see Chapter 4, B.4 Programming User Codes).

Moreover, you can obtain up to 8 multi-function portable keyfob transmitters that will allow you and the other users to easily arm, disarm and control the system without accessing the panel, including from outside the premises (see Chapter 2 and Chapter 4, section B.7 Add / Delete Keyfob Transmitters).

The Duress Code enables you to disarm the system using a special code that sends a silent alarm to the monitoring station (See chapter 2).

8 D-305736 PowerMaster 360 User's Guide

ELECTRICAL APPLIANCE CONTROL

2. Operating the PowerMaster 360 System

For more information regarding terms used in this chapter, refer to APPENDIX C. GLOSSARY.

Basic Arming and Disarming

Following are a set of procedures for performing basic arming and disarming of the alarm system.

Preparing to Arm

Before arming, make sure that READY is displayed.

READY HH:MM

If at least one zone is open (disturbed) the display will read:

NOT READY HH:MM

To review the open zones click . The details and location of the first open zone detector (usually an open door or window sensor) will be displayed. To fix the open zone, locate the sensor and secure it (close the door or window) – see "device locator" below. Each click of will display another open zone or trouble indication. It is highly recommended to fix the open zone(s), thus restoring the system to the state of “ready to arm”. If you do not know how to do this, consult your installer. Note: To quit at any stage and to revert to the "READY" display, click . Device Locator: The PowerMaster 360 system has a powerful device locator that helps you to identify open or troubled devices indicated on the Virtual Keypad display. While the Virtual Keypad displays an open or faulty device, the LED on the respective device flashes indicating "it's me". The "it's me" indication will appear on the device within max. 16 seconds and will last for as long as the Virtual Keypad displays the device.

Arming ‘AWAY' / ‘HOME'

If the system is READY and/or Forced Arming is enabled proceed as shown below. For more information on Forced Arming, see "Forced Arming AWAY or HOME" below. If the system is NOT READY and Forced Arming is not permitted, review any open zone detectors to locate and secure them. If you want to arm using partitions, see "Partition Selection Process" and then proceed as shown below.

If the user has changed the state of the system from a high security mode to a lower security mode i.e. from ARM to DISARM, or from ARM to HOME, he will be prompted to enter the user code thus bypassing the QUICK ARM option.

PRESS RESULTING DISPLAY

This indicates that all zones are secured and you may arm the system as desired.

This indicates that the system is not ready for arming and in most cases that one or more zones are not secured. However, it can also mean that an unresolved condition exists such as certain trouble conditions, jamming etc., depending on system configuration.

ARMING AWAY/HOME

If Quick Arm is disabled

Vacate the premises (ARM AWAY) OR Move to interior zone (ARM HOME)

ARM indicator lights steadily during the armed state.

ENTER CODE _ _ _ _

PLEASE EXIT NOW

↓ (Exit delay) ↓

AWAY/HOME

Disarming and Stopping Alarm

Enter the protected premises via a delayed zone. Upon detecting your entrance, the system will start sounding the entry delay beeps via the Virtual Keypad alerting you to disarm the system before the entry delay ends.

D-305736 PowerMaster 360 User's Guide 9

ELECTRICAL APPLIANCE CONTROL

After disarming, different displays may appear indicating that the system is in a state of alarm MEMORY. The MEMORY message will disappear only upon rearming the system. To disarm the system, proceed as shown:

PRESS RESULTING DISPLAY

[Enter Code] /

[Present tag]

ARM indicator extinguishes during the disarmed state. Disarming the system also stops the siren alarm,

irrespective of whether the alarm was initiated during the armed or the disarmed state.

Disarming under Duress

If you are forcibly compelled to disarm the system, enter the duress code (2580 by default) or another code set by the installer. Disarming will take place normally but a silent alarm will be transmitted to the monitoring station.

Partition Selection Process

Access to any desired partition is achieved through the use of an individual code or proximity tag. It is not possible to access the INSTALLER MODE menu if one or more partitions are in the AWAY or HOME modes.

Before attempting to perform any operation on any given partition(s), it is necessary to perform the operations below which enable you to select the desired/allowed partition(s) using the individual code or proximity tag:

PRESS RESULTING DISPLAY

ENTER CODE _ _ _ _

Code / Present tag

READY HH:MM

SELECT PARTITION

Enter partition # (1 - 3)

Note: The “Sad Tune” will be heard when selecting a partition to which no sensors / peripherals were enrolled.

PARTITION 1

Special Arming & Disarming Options

In addition to basic arming, PowerMaster 360 provides you with several advanced arming and disarming options:

Switching from ‘HOME’ to ‘AWAY’

You do not have to disarm the system - just press AWAY above. Vacate the premises before the exit delay expires.

Switching from ‘AWAY’ to ‘HOME’

You do not have to disarm the system - just press PowerMaster 360 will ask you to key in your master user code or user code, thus making sure that you are an authorized user.

PRESS RESULTING DISPLAY

[Enter code] /

[Present tag]

Move to interior zone

ARM indicator flashes during the armed state.

ENTER CODE _ _ _ _ Code / Present tag

ARMING HOME

↓ (Exit delay) ↓

ARM HOME HH:MM

. The response will be the same as in ARMING

Since this operation reduces the security level,

10 D-305736 PowerMaster 360 User's Guide

ELECTRICAL APPLIANCE CONTROL

Arming AWAY or HOME ‘Instant’

Pressing during the exit delay will arm the system in the "Instant' mode, i.e. without an entry delay. Therefore, any detection in any zone will trigger an immediate alarm. To arm AWAY-INSTANT, proceed as follows.

PRESS RESULTING DISPLAY

ENTER CODE _ _ _ _

Code

ARMING AWAY

Vacate the premises

ARM indicator lights during the armed state.

ARMING INSTANT

(alternating)

PLEASE EXIT NOW

↓ (Exit delay) ↓

AWAY

Forced Arming AWAY or HOME

Forced arming allows you to arm the system even if the system is "NOT READY". Any open zones will be bypassed for the duration of arming.

Note: When forced arming is carried out, the buzzer “protests” by emitting a continuous tone during the exit delay until the last 10 seconds of the delay. You can silence this signal by pressing the arming button again.

If forced arming is enabled and you wish to arm the system when NOT READY is displayed, proceed as shown:

PRESS RESULTING DISPLAY

[Enter code] /

[Present tag]

(to mute the buzzer)

Vacate the premises

ARM indicator lights during the armed state.

ENTER CODE _ _ _ _

Code / Present tag

ARMING AWAY

PLEASE EXIT NOW

↓ (Exit delay)

AWAY

Remember: Forced arming compromises security!!

↓

D-305736 PowerMaster 360 User's Guide 11

ELECTRICAL APPLIANCE CONTROL

Forced arming “HOME” is performed in a similar manner, as follows:

PRESS RESULTING DISPLAY

[Enter code] /

[Present tag]

ENTER CODE _ _ _ _

Code / Present tag

ARMING HOME

(to mute the buzzer)

Go to interior zone

ARM indicator flashes during the armed state.

PLEASE EXIT NOW

↓ (Exit delay)

HOME HH:MM

↓

Arming in the Latchkey Mode

This mode, if enabled by the installer, is useful for a parent at work who wants to be sure that his children have returned from school and have disarmed the system. A special “latchkey” message will be sent out when the system is disarmed by a “latchkey user”.

Latchkey users are holders of user codes or users of keyfob transmitters 5 through 8. The latchkey message is considered an alert and not an alarm, and is therefore sent to the private telephones programmed by the user as targets for alert messages.

Latchkey arming is possible only when you arm “AWAY”. To arm in the Latchkey mode, proceed as follows:

PRESS RESULTING DISPLAY

(Within 2 seconds)

Vacate the premises

Note: Latchkey must be enabled by your installer.

ARM indicator lights during the armed state.

ARMING AWAY

ARMING LATCHKEY

(alternating)

PLEASE EXIT NOW

↓ (Exit delay)

AWAY

↓

Initiating Alarms

Following are various methods that may be used for initiating alarms.

Initiating Panic Alarm

You can generate a panic alarm manually in the disarmed and armed states. The sequence will be as shown:

PRESS RESULTING DISPLAY

simultaneously

To stop the alarm, press the

12 D-305736 PowerMaster 360 User's Guide

PANIC ALARM

READY HH:MM

button and then key in your valid user code.

ELECTRICAL APPLIANCE CONTROL

Initiating Fire Alarm1 or Emergency Alarm

You can generate a fire alarm or a silent emergency alarm in disarmed & armed states, as follows:

PRESS RESULTING DISPLAY

for 2 seconds

To stop the alarm, press and then key in your valid user code.

Then, if or when the system is

Chime ON/OFF

Disable / enable the chime zones (see Appendix C) by alternate clicking of the key, as shown below:

PRESS RESULTING DISPLAY

FIRE ALARM

EMERGENCY

in the disarmed state:

READY HH:MM

(alternating)

READY MEMORY

CHIME ON

CHIME indicator lights steadily when “chime on” is selected.

CHIME OFF

READY HH:MM

↓

This function is disabled in ACPO compliant version

D-305736 PowerMaster 360 User's Guide 13

REVIEWING TROUBLES AND ALARM MEMORY

3. Reviewing Troubles and Alarm memory

Alarm & Tamper Memory Indication

The PowerMaster 360 retains in its memory alarm and “tamper” events that occurred during the last arming period.

Note: Alarm events are memorized only after the “abort period” (see Appendix C). This means that if you disarm the system immediately - before the abort period expires - there will be no memory indication

A. Indication of Alarm & Tamper Condition If the system is disarmed following an alarm event, a flashing MEMORY message will be displayed, as follows:

READY HH:MM

(alternating)

READY MEMORY

B. Displaying Alarm & Tamper Information

To review memory content, click button. EXAMPLE: An alarm was triggered because the garage door - zone No. 12 – was opened but then closed. In

addition, the bedroom motion detector - zone No. 7 - sent a “Tamper” message because its cover had been removed.

PRESS RESULTING DISPLAY

In response to additional clicking of the button, the display shows details of other events retained in

open tamper (if any), or reverts to its initial state (see A above).

If the system is NOT READY, the display will first read the open zones and then alarm memory events.

PowerMaster 360

Z12 ALARMED

(alternating)

Z12 CONTACT

(alternating)

GARAGE DOOR

PRESS RESULTING DISPLAY

Z07 TAMPER-OPEN

(alternating)

Z07 MOTION SENS

(alternating)

BEDROOM

READY HH:MM

↓

Clearing the Memory Indication

To clear the ‘Memory’ indication you must first review the cause of alarm as described above. Once you return to the ‘Ready’ screen simply press Away and enter the code if requested, then press Disarm followed by the code. The memory message will now clear. Otherwise the memory indication and content will be cleared upon the next arming of the system.

Troubles

A. Indication of Trouble condition

If the system detected a trouble condition in any of the enrolled devices, the TROUBLE indicator on the Virtual Keypad illuminates, 3 beeps are sounded via the Virtual Keypad once per minute and a flashing TRBL message is displayed, as follows.

READY HH:MM

(alternating)

READY TRBL NOT READY TRBL

or, if the system is not ready for arming

B. Displaying Trouble Information

All trouble messages need to be reviewed and corrected as described below:

EXAMPLE: The kitchen device - zone No. 9 - has reported a low battery – the living room device zone No. 15 has been inactive, and an attempt to communicate a message to your telephone has failed. However, these troubles do not prevent the system from being “ready to arm”.

14 D-305736 PowerMaster 360 User's Guide

(alternating)

NOT READY HH:MM

REVIEWING TROUBLES AND ALARM MEMORY

To review the source of the current troubles one by one, click the

PRESS RESULTING DISPLAY

IMPORTANT! If the trouble beeps bother you, disarm the system again (even though it is already disarmed). This will cancel the trouble beeps for 4 hours.

C. Reviewing Memory & Troubles at the Same Time

If alarms / tamper events are retained in the alarm memory and at the same time a state of trouble exists, the display will first read the alarm memory followed by trouble events, as described in sections A & B above.

PowerMaster 360

Z09 LOW BATTERY

(alternating)

Z09 CONTACT

(alternating)

KITCHEN

PRESS RESULTING DISPLAY

button repeatedly as shown below:

Z15 MISSING

(alternating)

Z15 MOTION SENS

(alternating)

LIVING ROOM

↓

COMM. FAILURE

↓

READY HH:MM

General Indications

After all trouble messages have been reviewed and if a SIM card is installed in the panel, the Virtual Keypad displays the GSM signal strength indication, as follows: "GSM RSSI STRONG" / "GSM RSSI GOOD" / "GSM RSSI POOR". If a PIR camera is enrolled in the system, the control panel will read "GPRS initialize" to indicate that the modem is undergoing initialization. This message appears at the end of all trouble messages and immediately following the GSM signal strength indication (if a SIM card is installed).

Correcting Trouble Situations

The trouble indications (illuminated TROUBLE indicator and flashing TRBL message) are cleared once you eliminate the cause of trouble. The table below describes the system faults and respective corrective actions. If

you do not know how to correct a trouble situation, report it to your installer and seek his advice.

Fault What it means 1-WAY

AC FAILURE CLEAN ME COMM. FAILURE

CPU LOW BATTERY

CPU TAMPER OPEN

GAS TROUBLE GSM NET FAIL JAMMING

LINE FAILURE LOW BATTERY MISSING NOT NETWORKED

RSSI LOW SIREN AC FAILURE TAMPER OPEN TROUBLE SOAK TEST FAIL

The device functions but cannot "hear" the panel. The control panel cannot configure or control the device. Battery consumption increases.

There is no power supplied to the device. The fire detector must be cleaned A message could not be sent to the monitoring station or to a private telephone (or

a message was sent but was not acknowledged) The backup battery within the control panel is weak and must be replaced (see

Chapter 8. Maintenance, "Replacing Backup Battery"). The control panel was physically tampered with or its cover was opened, or it was

removed from wall. Gas detector failure The GSM communicator is not able to connect to the cellular network. A radio-frequency signal which is blocking all communication frequency channels

between the sensors and control panel is detected. There is a problem with the telephone line The battery of the indicated device is near the end of its useful life. A device or detector has not reported for some time to the control panel. A device was not installed or not installed correctly, or, cannot establish

communication with the control panel after installation. The GSM communicator has detected that GSM network signal is weak There is no power to the siren The sensor has an open tamper The sensor reports trouble Detector alarms when in Soak Test mode

D-305736 PowerMaster 360 User's Guide 15

MENUS AND FUNCTIONS

4. Menus and Functions

This chapter explains the user programming features of your PowerMaster 360 system and allows you to tailor the PowerMaster 360 system according to your specific needs.

Keypad / VISONIConfig which contains the

The chapter is divided into two sections, as follows:

Part A – Guides you how to enter/exit the User Settings menu and how to select the desired setting options. Part B – Guides you to execute the selected settings.

alarm system’s control keys, numerical keypad and display.

A.1 Entering the User Settings Menu & Selecting a Setting Option

The following procedure describes how to enter and move within the User Settings menu. Detailed descriptions of the User Settings options are provided at the end of the procedure. To exit the User Settings menu – see section A.2.

1. You can enter the "USER SETTINGS" menu only when the system is disarmed.



2. Carefully read the section titled "Additional Information" according to the indicated references 1 etc – see

table at end of this section.

A. To Enter the USER SETTINGS Menu

1. READY 00:00

2. USER SETTINGS

CODE

B. To Select a Setting Option

4. SET BYPASS

5. TIME & FORMAT

Continue to the selected setting option in B.1 - B.15

Display shown in disarm state when all zones are secured (00:00 or other digits show present time).

a. If you have not already changed your personal code number, use the default setting – 1111. b. Master User has access to all User Settings options. Other users have access only to the Bypass options. c. If you enter an invalid user code 5 times, the keypad will be automatically disabled for a pre-defined

The bypass options will be displayed in the User Settings menu only if enabled by the installer. Otherwise, the first User Settings option displayed will be [

ENTER CODE:

SET BYPASS

period of time and the message WRONG PASSWORD will be displayed.



Make sure the system is disarmed and then press the button repeatedly until the display reads [USER SETTINGS]. 1

Press

The screen will now prompt you to enter your user code or present your proximity tag.

Enter your User Code. 2

The display reads the first Setting option of the User Settings menu [SET BYPASS]. 3

Click the or button until the display reads the desired setting option, for example, "TIME & FORMAT".

When the desired setting option appears on the display, press the button to enter the setting process.

The remainder of the procedures for the selected setting options is provided in sections B.1 to B.15.

Additional Information (section B.1)

USER CODES

All menu operations are performed using the Virtual

16 D-305736 PowerMaster 360 User's Guide

MENUS AND FUNCTIONS

C. User Settings Options Menu

Click until the display reads the desired setting option and then press .

SET ZONE BYPASS

REVIEW BYPASS

RECALL BYPASS

USER CODES

DURESS CODE

PROXIMITY TAGS

KEYFOBS

TIME & FORMAT

DATE & FORMAT

AUTO-ARM ENABLE

AUTO-ARM TIME

PRIVATE REPORT

SQUAWK

SERIAL NUMBER

PLNK curr.params

<OK> TO EXIT

Returns to

first option

Use to set the Zone Bypass Scheme i.e. to bypass (exclude) faulty or unsecured ("disturbed") zones, or to clear a bypassed zone (unbypass). For further details and programming procedure see section B.1. 3

Use to quickly review the Bypass Scheme i.e. which zones are bypassed. For further details and reviewing procedure see section B.2. 3

Use to Recall the last used bypassed scheme for reuse in next arming period. For further details and recalling procedure see section B.3. 3

Use to program your Master User secret access code and the seven codes of the other users. For further details and programming procedure see section B.4.

Use to program the Duress (ambush) code. For further details and programming procedure see section B.5.

Use to add new Proximity Tags to or to delete Proximity Tags when lost. For further details and programming procedure see section B.6.

Use to add new Keyfob Transmitters or to delete Keyfob Transmitters when lost. For further details and programming procedure see section B.7.

Use to set the time clock to show the correct time and time format. For further details and programming procedure see section B.8.

Use to set the calendar date to show the correct date and date format. For further details and programming procedure see section B.9.

Use to enable or disable the Automatic Daily Arming option at predefined times (see Auto-Arm Time setting). For further details and programming procedure see section B.10.

Use to set the predetermined time for the Automatic Daily Arming if enabled (see Auto-Arm Enable setting). For further details and programming procedure see section B.11.

Use to program the four private telephone numbers for reporting alarm and other event messages to private subscribers. For further details and programming procedure see section B.12.

Use to enable or disable the squawk sound i.e. arm / disarm feedback indication. For further details and programming procedure see section B.13.

Use to read the system serial number and similar data

Use to read the current IP address of the PowerLink and similar data see section B.15.

Use to exit from the “USER SETTINGS” menu back to Main Menu. For further details see section A.2.

see section B.14.

D-305736 PowerMaster 360 User's Guide 17

MENUS AND FUNCTIONS

Any screen

<OK> TO EXIT

READY 12:00

A.2 Returning to the Previous Step or Exiting the USER SETTINGS Menu

During the setting process it is frequently necessary to return to the previous setting step or option (i.e. "to go one level up") or to exit the User Settings menu.

A. To Move One Level Up

To move one level up during the setting process, click once or more. Each click will take you one level up or to the previous setting step:

B. To Exit the USER SETTINGS Menu

To exit [USER SETTINGS], move up the menu by pressing repeatedly

A.3 Buttons used for Navigation & Setting

The keypad's buttons are used for various functions when programming. The following table provides a detailed description of the function or use of each button.

Button Definition Navigation / Setting Function

BACK

HOME

AWAY

OFF

(see above) until the display reads [<OK> TO EXIT], or preferably, press once which brings you immediately to the exit screen [<OK> TO EXIT].

When the display reads [<OK> TO EXIT], press

The system exits the [USER SETTINGS] menu and returns to the normal disarm state while showing the READY display.

Use to move / scroll forward to the next menu options.

Use to move / scroll backward to the previous menu options.

Use to move one level up in the menu or to return to previous setting step.

Use to select a menu option or to confirm a setting or action.

Use to move one level up in the menu or to return to previous setting step.

Use to jump back to the [<OK> TO EXIT] screen to quit programming.

Use to cancel, delete, clear or erase setting, data, etc.

0 - 9

B.1 Setting the Zone Bypass Scheme

Bypassing permits arming only part of the system while allowing free movement of people within certain zones when the system is armed. It is also used to temporarily remove from service faulty zones that require repair work or to deactivate a sensor if, for example, you are decorating a room. ♦ Here you can set the Zone Bypass Scheme i.e. to scroll through the list of registered (enrolled) sensors to

Once you have set a Bypass Scheme you can use the following 3 options:

> To quickly review the bypassed zones – refer to section B.2. > To quickly clear a bypassed zone i.e. to reactivate the bypassed zone – refer to section B.1. > To repeat (recall) the last used zone bypassing scheme – refer to section B.3.

18 D-305736 PowerMaster 360 User's Guide

Numerical keypad used to enter numerical data.

your PowerMaster 360 system and to Bypass (deactivate) faulty or disturbed sensors (either READY or NOT-READY) or to Clear (reactivate) BYPASSED zones (sensors).

+ 42 hidden pages
