Visioneer OneTouch 7400 User Manual
Visioneer® OneTouch
7400 USB Scanner
User's Guide
for Windows
Visioneer OneTouch
7400 USB Scanner
User’s Guide
FOR WINDOWS
®
COPYRIGHT INFORMATION
Copyright © 2007 Visioneer, Inc.
Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws.
The Visioneer brand name and logo are registered trademarks of Visioneer, Inc. The PaperPort brand name and logo are registered trademarks of Nuance
Communications, Inc. ArcSoft Scrapbook Suite® is a registered brand name of ArcSoft, Inc. Adobe®, Adobe® Acrobat®, Acrobat® Reader®, and the
Adobe® Acrobat® PDF® logo are registered trademarks of Adobe Systems Incorporated in the United States and/or other countries. The Adobe PDF logo
will appear in this product’s software, and full access to Adobe software features is only available if any Adobe product is installed on your computer.
This product is covered by one or more of the following patents: 6, 480, 304; 5,818,976; 5,499,108; 5,517,332.
Microsoft is a U.S. registered trademark of Microsoft Corporation. Windows is a trademark of Microsoft Corporation. ZyINDEX is a registered trademark of
ZyLAB International, Inc. ZyINDEX toolkit portions, Copyright © 1990-1998, ZyLAB International, Inc. All Rights Reserved. All other products mentioned
herein may be trademarks of their respective companies.
Information is subject to change without notice and does not represent a commitment on the part of Visioneer. The software described is furnished under a
licensing agreement. The software may be used or copied only in accordance with the terms of such an agreement. It is against the law to copy the software on
any medium except as specifically allowed in the licensing agreement. No part of this document may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying, recording, or information storage and retrieval systems, or translated to another language, for any
purpose other than the licensee's personal use and as specifically allowed in the licensing agreement, without the express written permission of Visioneer.
Part Number: 05-0744-000
Restricted Rights Legend
Use, duplication, or disclosure is subject to restrictions as set forth in contract subdivision (c)(1)(ii) of the Rights in Technical Data and Computer Software
Clause 52.227-FAR14. Material scanned by this product may be protected by governmental laws and other regulations, such as copyright laws. The customer
is solely responsible for complying with all such laws and regulations.
Visioneer's Limited Product Warranty
IF YOU FIND PHYSICAL DEFECTS IN THE MATERIALS OR THE WORKMANSHIP USED IN MAKING THE PRODUCT DESCRIBED IN
THIS DOCUMENT, VISIONEER WILL REPAIR, OR AT ITS OPTION, REPLACE THE PRODUCT AT NO CHARGE TO YOU, PROVIDED YOU
RETURN IT (POSTAGE PREPAID, WITH PROOF OF YOUR PURCHASE FROM THE ORIGINAL RESELLER) DURING THE 90-DAY PERIOD
AFTER THE DATE OF YOUR ORIGINAL PURCHASE OF THE PRODUCT. UPON RECEIPT DURING THE INITIAL 90-PERIOD BY
VISIONEER OF A VALID REGISTRATION OF THE PRODUCT, THIS LIMITED PRODUCT WARRANTY PERIOD IS EXTENDED TO THE
12-MONTH PERIOD AFTER THE DATE OF YOUR ORIGINAL PURCHASE. IF A VALID REGISTRATION IS NOT RECEIVED DURING THE
INITIAL 90-DAY PERIOD, THE 12-MONTH WARRANTY IS NO LONGER AVAILABLE AND YOUR PRODUCT WARRANTY WILL
TERMINATE AFTER THE 90-DAY INITIAL PERIOD EXPIRES.
THIS IS VISIONEER'S ONLY WARRANTY AND YOUR EXCLUSIVE REMEDY CONCERNING THE PRODUCT, ALL OTHER
REPRESENTATIONS, WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, WRITTEN OR ORAL, INCLUDING ANY WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE EXPRESSLY EXCLUDED. AS A RESULT,
EXCEPT AS SET OUT ABOVE, THE PRODUCT IS SOLD “AS IS” AND YOU ARE ASSUMING THE ENTIRE RISK AS TO THE PRODUCT'S
SUITABILITY TO YOUR NEEDS, ITS QUALITY AND ITS PERFORMANCE.
IN NO EVENT WILL VISIONEER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY DEFECT IN THE PRODUCT OR FROM ITS USE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
All exclusions and limitations in this warranty are made only to the extent permitted by applicable law and shall be of no effect to the extent in conflict with the
express requirements of applicable law.
RoHS and WEEE Compliance
This product is compliant with RoHS Regulations of the European Parliament and Council Directive on the Restrictions of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment (2002/95/EC), and with the Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC).
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for the class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and if not installed, and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment has been certified to comply with the limits for a class B computing device, pursuant to FCC Rules. In order to maintain compliance with
FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in
interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer
could void the user's authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
TABLE OF CONTENTS i
TABLE OF CONTENTS
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
What’s in the Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
The Visioneer OneTouch 7400 USB Scanner . . . . . . . . . . . . . . . . . . 2
What You Need . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 1: Install the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 2: Connect the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Step 3: Register Your Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
View and Save the User Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Scanning from OneTouch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Scan from the OneTouch Scanner Buttons . . . . . . . . . . . . . . . . 17
Scan from the OneTouch Button Panel . . . . . . . . . . . . . . . . . . 22
Configuring the OneTouch Button Options . . . . . . . . . . . . . . . . . . 25
About the OneTouch Properties . . . . . . . . . . . . . . . . . . . . . . . . 26
The OneTouch Properties Options . . . . . . . . . . . . . . . . . . . . . . 27
Selecting Settings for a Button . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Destination Application Properties . . . . . . . . . . . . . . . . . . . . . . 30
Selecting File Format Options . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Scanning with Optical Character Recognition (OCR) . . . . . . . . 45
OneTouch Options Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Creating a New Scan Configuration . . . . . . . . . . . . . . . . . . . . . 51
Editing or Deleting Scan Configurations . . . . . . . . . . . . . . . . . . 59
Configure Before Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Scan and Burn to a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Scanning with Event Forwarding . . . . . . . . . . . . . . . . . . . . . . . . 69
ii TABLE OF CONTENTS
Creating an HTML Web Page from Your Scanned Documents 71
Transferring Scanned Documents to Storage . . . . . . . . . . . . . . . 73
Scanning to Multiple Folders . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Scanning from the TWAIN Interface . . . . . . . . . . . . . . . . . . . . . . . 81
A Note About the TWAIN Standard . . . . . . . . . . . . . . . . . . . . 81
Accessing the TWAIN Interface . . . . . . . . . . . . . . . . . . . . . . . . 82
Scanning From the Basic TWAIN Interface . . . . . . . . . . . . . . . 85
Scanning From the Advanced TWAIN Interface . . . . . . . . . . . . 87
Advanced Interface Image Adjustment Options . . . . . . . . . . . . . 89
Adjusting the Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Adjusting the Brightness and Contrast . . . . . . . . . . . . . . . . . . . . 93
Adjusting Gamma, Saturation, and Color Hue . . . . . . . . . . . . . 94
Adjusting Input Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Create a Scanning Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Scanning from the Windows Image Acquisition (WIA) Interface . . 99
Setting Up Your Scanner to Work With PaperPort . . . . . . . . . . . . 102
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Cleaning the Scanner Glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Uninstall Your Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Uninstalling the OneTouch Software . . . . . . . . . . . . . . . . . . . 110
Uninstalling the PaperPort Software . . . . . . . . . . . . . . . . . . . . 110
Visioneer 7400 USB Scanner Specifications . . . . . . . . . . . . . . . . . . 111
Visioneer 7400 USB Scanner Part List . . . . . . . . . . . . . . . . . . . . . . 111
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
WELCOME
Software CDVisioneer 7400 USB Scanner
USB Cable
Quick Install Card
Technical Support Card
Congratulations on purchasing your Visioneer OneTouch 7400 USB
scanner. With this scanner you can quickly scan paper items such as
letters, forms, photos, or magazine articles and place their electronic
images on your computer. With its innovative hinged lid, you can also
lay books flat on the scanner to scan pages.
WHAT’S IN THE BOX
Before starting the installation, check the contents of the box to make
sure that all parts are included. If any items are missing or damaged,
contact the dealer where you purchased the scanner.
VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE 1
Glass
Reference marks
Document cover
OneTouch button panel
USB port
Status light
OneTouch buttons
2 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
THE VISIONEER ONETOUCH 7400 USB SCANNER
THE VISIONEER ONETOUCH 7400 USB SCANNER 3
Document cover—Protects the document from light and
contamination.
Glass—Items are placed face down aligned at the reference marks.
Reference marks—Marks on the border of the glass show where to
align various paper sizes.
OneTouch buttons—Scans to the appropriate application indicated by
the button. For example, pressing the Email button scans the
document, then opens your Email program with the image of the
scanned document as an attachment to a new message ready for you to
address and send.
Status light—Shows the scanner’s status. Steady green light: scanner is
ready to scan. Blinking green light: scanner is busy.
USB port—Connects the scanner to the computer. Your Visioneer
7400 scanner can connect to either a USB 1.1 or a USB 2.0 port.
Note: The scanner does not have an external power supply. It draws
its power directly from the computer through the USB cable. If you
use a USB Hub with your computer, the Hub must have its own
power supply so the scanner can draw power from it. The scanner also
does not have an on/off switch. It is ready to scan as soon as Windows
loads on your computer.
4 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
WHAT YOU NEED
IBM-compatible Pentium 4 PC, or AMD equivalent with:
■ A CD-ROM drive
■ An available Universal Serial Bus (USB) port; 1.1 or 2.0
■ Microsoft Windows operating system: 2000 (Service Pack 4), XP
(Service Pack 1 and 2), or Vista
■ Windows 2000 and XP: Minimum of 512 megabytes (MB) of
internal memory (RAM)
Windows Vista: Minimum of 1 gigabyte (GB) of internal memory
(RAM)
■ 350 MB of free hard disk space
A VGA or SVGA Monitor
The recommended settings for your monitor are:
■ High Color (16-bit) or True Color (24-bit or 32-bit)
■ Resolution set to at least 800 x 600 pixels
To set your monitor’s colors and resolution:
■ Open the Windows Control Panel
■ Double-click on Display then select the Settings tab
DOCUMENTATION
Your scanner is delivered with the following documentation:
■ Quick Install Guide—Abbreviated installation instructions.
■ Visioneer OneTouch 7400 USB Scanner User’s Guide—On the
Installation CD; contains detailed installation, scanning,
configuration, and maintenance information.
■ ScanSoft PaperPort User’s Guide—On the Installation CD;
contains detailed feature and configuration information for the
PaperPort software.
■ Online Help—For the scanner configuration, TWAIN, and WIA
interfaces.
BEFORE YOU BEGIN 5
Installing
Installation is a quick, three-step process:
■ Install the software
■ Connect the scanner
■ Register your scanner
BEFORE YOU BEGIN
Please make sure of the following before you begin installation:
■ If your computer has AntiVirus or AntiSpyware software
running, you may see messages during installation asking you to
allow the installation to proceed. In each case you should allow
the installation to proceed. Alternatively, you can turn off the
AntiVirus or AntiSpyware software before installing your
scanner, but if you do, make sure to turn it back on again when
installation is finished.
■ If you already have a scanner connected to your computer it is
recommended that you remove its driver program prior to
installing your Visioneer OneTouch 7400 USB scanner. Please
refer to the user manual for your previous scanner for
instructions to remove the driver and software applicable to that
scanner.
■ The information in this User’s Guide may cover software not
provided with the scanner you purchased. Disregard any
information about software not applicable to your scanner.
Please visit our web site at www.visioneer.com for the latest
software updates for your Visioneer OneTouch 7400 USB
scanner.
■ If your computer is running Windows Vista, you may see the
Vista User Access Control screen asking you to confirm system
changes. Click the continue button to allow the installation to
proceed.
6 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
STEP 1: INSTALL THE SOFTWARE
The Installation CD contains all the driver software and scanning
software to use your scanner.
To install the software:
1. Start Microsoft Windows and make sure no other applications are
running.
2. Insert the installation CD into your computer’s CD-ROM drive.
The Main Menu automatically opens.
Note: If the CD does not start, check the following:
■ Make sure the CD drive’s door is completely shut.
■ Make sure the CD was inserted in the drive in the proper
direction (label side up).
To launch the CD manually:
■ Open the Windows option for My Computer. You can do this
by double-clicking on the My Computer icon on your
desktop.
■ Double-click the icon for your CD-ROM drive.
■ The Installation menu for the CD should now open.
If the menu does not open:
■ From the list of files on the CD, double-click the file named
START32.EXE.
STEP 1: INSTALL THE SOFTWARE 7
3. On the installation menu, select Install ScanSoft PaperPort and
Scanner Driver.
4. Make sure the boxes for Nuance PaperPort® and Scanner Driver
are checked.
If you also want to install the ArcSoft® Scrapbook Suite®
software now, select it too. You can also install it later.
5. Click Install Now.
8 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
The PaperPort installation options opens.
1. The Select Language window opens. Click the drop-down menu
arrow and select the language you want to use. Click OK.
The first PaperPort Installation window opens.
2. On the PaperPort Welcome window, click Next.
Installing PaperPort will uninstall any existing version of PaperPort
and will install the newer version while retaining all of your
previous PaperPort files.
3. Read the PaperPort license agreement and select I accept the terms
in this agreement, then click on Next. If you choose not to accept
the license agreement, the installation will terminate and the
PaperPort software will not be installed.
4. On the Customer Information window, accept the current values or
enter new information, then click Next.
5. On the Setup Type window, keep the default Setup Type and click
Next.
6. Click Install to begin the installation.
Reminder: If your computer is running an AntiVirus or
AntiSpyware application, you may see messages asking you to allow
installation. Select the option to allow installation to proceed with
the install.
7. On the Product Registration window, do one of the following:
■ Select Register online, click OK, then follow the registration
instructions.
■ Select Print registration form, click OK, then follow the
instructions to complete and print the registration form.
■ Select Remind me in 7 days and click OK.
8. At the InstallShield Wizard Completed window, click Finish.
If a message window opens instructing you to restart your
computer, click Restart.
STEP 1: INSTALL THE SOFTWARE 9
The Welcome to the OneTouch 4.0 Setup Wizard opens.
1. Click Next.
2. On the Visioneer License Agreement window, read the license
agreement. If you accept the terms, select I Agree.
If you choose not to accept the license agreement, the installation
will terminate and the scanner driver will not be installed.
3. Click Next.
10 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
4. A window opens with image quality samples asking you to select an
image for your Color Space setting.
The Color Space setting sets the gamma value for the scanner so
scanned items look good on your monitor. Gamma controls the
brightness of the midtones of colors. That setting can be changed
later on as you’re scanning.
5. Select the option that looks best to you and click Next.
6. The driver installation will now begin.
Reminder: If your computer is running AntiVirus or AntiSpyware
software, you may see messages asking you to allow installation.
Select the option to allow installation to proceed.
STEP 1: INSTALL THE SOFTWARE 11
7. STOP when you see the “Complete the installation by connecting
your hardware” window. Do NOT click on OK yet. Leave the
window open and proceed to “Step 2: Connect the Scanner” on
page 12.
Note: If you want to see more information about your scanner and a
quick explanation of how to use the OneTouch features, click the
More button on the window. When you’re finished, return to the
window to continue the installation process.
12 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
Plug into the Scanner
Plug into the Computer
STEP 2: CONNECT THE SCANNER
1. Remove any tape from the USB cable.
2. Using the steps on the screen as your guide, plug the square end of
the cable into the side of your scanner.
3. Plug the flat, computer end of the USB cable into an available USB
port on the computer.
If the plug does not attach easily, make sure that you are plugging it
in correctly. Do not force the plug into either connection.
If you use a USB hub, it must have its own power supply already
plugged into an electrical outlet.
Note: Your scanner does not have a power switch. Plugging it in turns
on the power.
Your computer recognizes that a scanner has been plugged into the
USB port. If your computer is running Windows XP or Windows
Vista, you will see a Found New Hardware message similar to the
following.
STEP 3: REGISTER YOUR SCANNER 13
The OneTouch Icon.
Serial Number
STEP 3: REGISTER YOUR SCANNER
Registering your scanner is important as it provides you with access to
our free telephone support service. Registration also gives you free access
to software updates for your scanner.
To register your scanner:
1. Right-click on the OneTouch icon in the Windows Notification
Area (at the bottom right corner of the screen).
2. Choose Check for Online Updates from the pop-up menu.
3. Follow the instructions on the screen and register your scanner by
entering your scanner’s serial number and your email address.
Note: A valid email address is required.
4. The serial number is located on the underside of the scanner.
5. You will receive a message with your RegID when registration is
complete. Write down your RegID on a piece of paper and keep it
with your scanner so you will be able to find it easily.
Your RegID is important as you will need it when accessing free
telephone support, or checking for online updates.
14 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
VIEW AND SAVE THE USER GUIDES
The User Guides for your scanner, and for the software you received
with it are on the Installation CD.
If you have already removed the installation CD from your CD-ROM
drive, insert the CD back into the drive to access the user guides.
1. On the Main Menu, click User Guides.
2. From the Visioneer User Guides window select the User Guide you
want to view and save to your computer.
VIEW AND SAVE THE USER GUIDES 15
3. The Scanner Readme file is in HTML format and will open in any
standard browser. The Scanner Readme file has late-breaking
news about your scanner.
®
Note: The User Guides are in Adobe
CD also includes a free copy of Acrobat
Acrobat® PDF format. The
®
Reader® in case your
computer does not have it already installed.
If you need to, click Acrobat Reader to install it now. Follow the
instructions on the installation windows.
To view and save the User Guides:
1. Click the name of a User Guide you want to view and it will open
in Acrobat Reader. Use the Acrobat Reader Save command to save
that User Guide on your computer.
The PhotoImpression and Collage Creator applications are part
of the ArcSoft Scrapbook Suite.
2. Return to the Visioneer User Guides window and repeat the process
to open, view, and save all the other User Guides you want.
3. When you’re finished, click Main Menu to return to the Main
Menu window and click Exit.
4. Remove the CD and store it in a safe place.
That’s it! Installation is finished and your Visioneer scanner is ready to scan.
16 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
Scanning
This section describes how to scan paper documents, book pages and
photographs:
You can use several different methods to scan with your scanner.
■ OneTouch Scanner Buttons—Each scanner button is set up to scan
for a particular function, such as Email to attach a scanned item to a
new Email message, or Photo to scan photographs to the ArcSoft
PhotoImpression software where you can touch up the colors. See
“Scan from the OneTouch Scanner Buttons” on page 17.
■ OneTouch Button Panel—Scanning from the on-screen OneTouch
Button Panel is the same as pressing a scanner button, except you
click an icon that represents the scanner button. See “Scan from the
OneTouch Button Panel” on page 22.
■ TWAIN Interface—This option is for scanning from within a
scanning application. The TWAIN interface is available from the
PaperPort software and ArcSoft Scrapbook Suite applications, as well
as from other programs such as Microsoft Word. The TWAIN
interface has two options—the Basic Interface and the Advanced
Interface. “Scanning from the TWAIN Interface” on page 81
■ Windows Image Acquisition (WIA) Interface—This option uses
the Microsoft Windows set of choices for scanning paper items only.
Scanning with WIA is available only if your computer is running
Windows XP or Windows Vista. See “Scanning from the Windows
Image Acquisition (WIA) Interface” on page 99.
SCANNING FROM ONETOUCH 17
SCANNING FROM ONETOUCH
OneTouch is your main scanning interface for using the scanner. The
OneTouch Buttons on the scanner mirror the software OneTouch
Button Panel. Changing the button settings on the OneTouch Button
Panel makes the same changes to the buttons on the scanner.
SCAN FROM THE ONETOUCH SCANNER BUTTONS
Pressing a scanner button scans the item, and then sends the image to
the Destination Application associated with the button. Each button’s
scanning function are the selected settings shown in the OneTouch
Properties window.
Based on the recommended installation of PaperPort and the scanner
driver, your scanner is preconfigured to scan items for various basic
tasks, such as email or fax, then send the scanned image to an
appropriate, pre-selected Destination Application.
If PaperPort is not installed, then the options for sending to word
processing applications such as Microsoft Word will not be available.
The following table describes the preconfigured button settings. These
are the default settings on installation of the OneTouch software and
they can be reconfigured to reflect your own scanning needs:
18 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
Button Destination Preconfigured Settings
Scan PaperPort Scans in Color, 200dpi
Opens the image in PaperPort
Custom Storage Scans in Black & White, 150dpi
Immediately saves the image file to a
folder location on your computer.
The image is not opened in an
application for viewing.
E-Mail Email Application Scans in Color, 300dpi
Attaches the scanned image to a new
email message.
OCR Microsoft Word
or WordPad
Scans in Black & White, 200dpi
Converts the scanned text into
editable text.
Copy Printer Scans in Black & White, 200dpi
Prints a Black & White copy of your
scanned item.
Note: The default page size in each configuration is based on the
location selected in your Windows setup.
For example:
■ If the Windows location is set to “United States” the default page
size in each profile will be based on the United States standard
page sizes such as 8.5”x11”.
■ If the Windows location is “United Kingdom” the default page
size in each profile is based on the ISO 216 standard and the
majority of the profiles will default to A4.
Note: The email application will default to the email program
specified in the internet options of Internet Explorer.
SCANNING FROM ONETOUCH 19
Reference marks
SCANNING PAPER DOCUMENTS OR PHOTOGRAPHS
1. Place an item face down on the glass. Align the bottom of the item
with the scanner’s reference marks. For custom sizes, align the edge
of the item with the left side of the scanner glass.
2. Close the document cover and press one of the OneTouch buttons.
20 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
3. A scan progress window opens shows the item as it is being
scanned.
4. After scanning has completed the image is sent to the selected
application for the OneTouch button.
In the example below, the image is scanned in the TIFF format and
the Destination Application is the PaperPort Desktop. The scanned
item appears a thumbnail on the PaperPort Desktop.
5. You can now work with the image in its Destination Application.
SCANNING FROM ONETOUCH 21
SCANNING PAGES IN A BOOK
Your OneTouch 7400 USB scanner has an innovative hinged lid so you
can lay books flat on the scanner glass to scan their pages.
To scan book pages:
1. Open the document cover and place the book on the glass.
2. Align the edges of the pages with the reference marks.
3. Close the document cover.
Notice how the hinge at the back of the document cover lifts up so
cover lays flat on the book.
4. Now press one of the scanner buttons to scan the pages in the book.
22 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
OneTouch Icon.
SCAN FROM THE ONETOUCH BUTTON PANEL
Scanning from the button panel on your computer’s screen works just
like pressing a button on the scanner. The scanner scans the item, then
sends the image to the Destination Application indicated by the button’s
icon. This method of scanning is especially helpful if the scanner is not
located close to your computer.
To scan from the button panel on the screen:
1. Place an item face down on the glass. Align the bottom of the item
with the scanner’s reference marks.
2. Close the document cover, and click the OneTouch icon on the
right-hand side of the Windows System Tray (at the bottom right
corner of the screen).
The button panel opens on the screen. The five buttons on the
panel correspond to the same five buttons on the scanner.
3. Click a button on the panel.
The scanner starts scanning the item. When the scan is complete, the
scanned image opens in the Destination Application indicated by the
button’s icon just as if you had scanned using a scanner button. For
example, if you click the Scan button, the scanned image opens in the
PaperPort program.
Note: To scan from the Button Panel, the OneTouch Properties
window must be closed. Click the window’s close box, or click the
Cancel or OK button on the window. See the next section, “Scan
from the OneTouch Button Panel.”
SCANNING FROM ONETOUCH 23
Click these green
arrows to cycle
through the panel’s
views.
The Hardware View.
The Detail View.
Shows the 5 scanning
options, and mirrors
the buttons on the
scanner.
This view shows the connected scanner(s).
You can click either the green arrow or the
scanner icon to get back to the previous
view.
This view shows the scan settings for the
button currently selected on the OneTouch Properties window. Right-click the
icon to see the window.
The Button Panel
ONETOUCH BUTTON PANEL FEATURES
The OneTouch Button Panel is your on-screen set of controls for the
scanner. In addition, the panel shows information about the scanner
and its settings.
Click the green arrows at the top of the panel to cycle back and forth
through three views of the panel.
1. From the main Button Panel:
■ Click the arrow pointing to the left to see the Hardware view
which shows the scanners currently attached to your computer.
■ Click the arrow that points to the right to see the Detail view
which shows the scan setting details of the currently selected
button.
2. On the OneTouch Button Panel:
3. To close the OneTouch Button Panel, click the close button at its
■ Left-click a Destination Application icon to start the scanning. If
the OneTouch Properties window is open, you must close it first.
■ Right-click a Destination Application icon to see its scan settings.
top right corner.
24 VISIONEER ONETOUCH 7400 USB SCANNER INSTALLATION GUIDE
ABOUT THE ONETOUCH BUTTON PANEL’S NAMES AND ICONS
The button names on the panel are the same as button names on the
scanner. The icons indicate the Destination Applications so you can see,
at a glance, where the image will be sent when scanning is finished.
The Scan button—Scans a page in black and white and sends the
image to the PaperPort software that you received with your scanner.
From there you can easily convert the image to many different formats,
such as PDF or DOC.
The Custom button— Scans the item as a color photo and displays it
in an image processing application. If your computer is running
Windows XP or Windows Vista, and has a CD burner attached, the
Custom button will be pre-configured to burn a CD.
The Email button—Scans a page in color then sends it to your email
application. The email application opens and the image is automatically
attached to a new message ready for you to address and send.
The OCR button—Scans a page in black & white then sends the image
to a word processing application such as Microsoft Word. OneTouch
automatically converts the item’s text to black and white word
processing text, and displays it in a word processing application so that
the text can be edited.
The Copy button—Scans a page in color then sends the image to your
printer/copier. The printer/copier starts and prints a copy of the page.
This is a quick way to print a copy of the original page.
A question mark for a button means your computer does not have
appropriate software, or in some cases the appropriate hardware, for the
initial factory settings. In that case, you can re-set the button’s
Destination Application to a software application that you know is on
your computer.
See “Selecting Settings for a Button” on page 29 to change the settings
of a button.
CONFIGURING THE ONETOUCH BUTTON OPTIONS 25
For example, rightclick on the Scan
button and the
OneTouch
Properties opens for
that button.
CONFIGURING THE ONETOUCH BUTTON OPTIONS
When you first connect your scanner to a computer, the scanner’s
software configures each OneTouch button with appropriate settings
consisting of: a Destination Application, a Scan Configuration, and a
File Format. To change the settings, you reconfigure the buttons by
selecting new options from the OneTouch Properties window.
To open the OneTouch Properties window:
1. Left-Click on the OneTouch icon in the Windows Notification
area.
2. When the button panel opens above the OneTouch icon, right-
click the button you want to configure. The OneTouch Properties
window opens for that button.
You can also open the OneTouch Properties by pressing, holding
down, and then releasing a button on the scanner.
Loading...
