VISHAY TFDU5037 Technical data

TFDU5307

Vishay Semiconductors

Fast Low Profile (2.5 mm) Infrared Transceiver Module
(MIR, 1.152 Mbit/s) for IrDA

Description

The TFDU5307 is an infrared transceiver module
compliant to the latest IrDA physical layer standard,
supporting IrDA speeds up to 1.152 Mbit/s (MIR) and
carrier based remote control modes up to 2 MHz. Inte­grated within the transceiver module are a PIN photo­diode, an infrared emitter (IRED), and a low-power
control IC to provide a total front-end solution in a sin­gle package.

This Vishay MIR transceiver is built in a low profile
package using the experiences of the lead frame
babyface technology. The transceivers are capable of
directly interfacing with a wide variety of I/O devices,
which perform the modulation/ demodulation function.
At a minimum, a V

bypass capacitor and a serial

CC

®

Applications

resistor for current control are the only external com­ponents required implementing a complete solution.
TFDU5307 has a tri-state output and is floating in
shutdown mode with a weak pull-up.

Features

• Compliant to the latest IrDA physical
layer specification (up to 1.152 Mbit/s)
and TV Remote Control, bi-directional
operation included.

• Sensitivity covers full IrDA range.
Recommended operating range is from nose to
nose to 70 cm

• Operates from

2.7 V to 5.5 V within specification

• Low power consumption (typ. 0.55 mA
Supply current in receive mode, no signal)

• Power shutdown mode (< 5 µA Shutdown Current
in Full Temperature Range, up to 85 °C)

• Surface mount package, low profile
universal (L 8.5 mm x W 2.9 mm x H 2.5 mm)
Capable of surface mount soldering to Side and
top view orientation

• Backward pin compatible to Vishay
Semiconductors SIR and MIR infrared
transceivers

e3

Applications

• Telecommunication products (cellular phones,
pagers)

• Digital still and video cameras

• Printers, fax machines, photocopiers, screen pro­jectors

• Low power consumption (typ. 0.55 mA
Supply current in receive mode, no signal)

• High efficiency emitter

• Directly interfaces with various super I/O and con­troller devices

• Tri-state-receiver output, floating in shut down with
a weak pull-up

• Split power supply, transmitter and receiver can be
operated from two power supplies with relaxed
requirements saving costs, US Patent No.
6,157,476

• Logic voltage 1.5 V to 5.5 V is independent of
IRED driver and analog supply voltage

• Only one external component required

• TV remote control supported

• Transmitter intensity can be adjusted by an
external resistor for extended range (> 0.7 m) or
minimum low
power (> 0.2 m) IrDA compliance.

• Lead (Pb)-free device

• Device in accordance to RoHS 2002/95/EC and
WEEE 2002/96EC

• Medical and industrial data collection

• Notebook computers, desktop PCs, Palmtop
Computers (Win CE, Palm PC), PDAs

• Internet TV boxes, video conferencing systems

• External infrared adapters (dongles)

• Kiosks, POS, Point and Pay devices including
IrFM - applications

Document Number 82616

Rev. 1.5, 07-Apr-06

www.vishay.com

1

TFDU5307

Vishay Semiconductors

Parts Table

Part Description Qty / Reel

TFDU5307-TR1 Oriented in carrier tape for side view surface mounting 750 pcs

TFDU5307-TR3 Oriented in carrier tape for side view surface mounting 2500 pcs

TFDU5307-TT1 Oriented in carrier tape for top view surface mounting 750 pcs

TFDU5307-TT3 Oriented in carrier tape for top view surface mounting 2500 pcs

Functional Block Diagram

V

logic

Tri-State

Amplifier

Comparator

Driver

RXD

Vcc2

18509

SD

TXD

Logic
&

Control

IRED Driver

IRED C

GND

Pin Description

Pin Number Function Description I/O Active

1 IRED

Anode

2 IRED

Connect IRED anode to the V

limiting resistor. A separate unregulated power supply can be used at this pin.

IRED Cathode, internally connected to the driver transistor

Cathode

3 TXD This Schmitt-Trigger input is used to transmit serial data when SD is low. An on-

chip protection circuit disables the LED driver if the TXD pin is asserted for longer

than 80 μs. When used in conjunction with the SD pin, this pin is also used to

control receiver output pulse duration. The input threshold voltage adapts to and

follows the logic voltage reference applied to the V

4 RXD Received Data Output, push-pull CMOS driver output capable of driving standard

CMOS or TTL loads. No external pull-up or pull-down resistor is required. Floating

with a weak pull-up of 500 kΩ (typ.) in shutdown mode. The voltage swing is

defined by the applied V

5 SD Shutdown. Also used for setting the output pulse duration. Setting this pin active

for more than 1.5 ms places the module into shutdown mode. Before that (t < 0.7
ms) on the falling edge of this signal, the state of the TXD pin is sampled and used

to set the receiver output to long pulse duration (2 µs) or to short pulse duration

(0.4 μs) mode. The input threshold voltage adapts to and follows the logic voltage

reference applied to the V

6V

7V

CC1

logic

V

defines the logic voltage levels for input and output. The RXD output range

logic

is from 0 V to V

, for optimum noise suppression the inputs’ logic decision level

logic

8 GND Ground

power supply through an external current

CC2

pin (pin 7).

logic

voltage

logic

pin (pin 7).

logic

Supply Voltage

is 0.5 x V

logic

IHIGH

OLOW

IHIGH

I

www.vishay.com

2

Document Number 82616

Rev. 1.5, 07-Apr-06

TFDU5307

Vishay Semiconductors

Pinout

TFDU5307
weight 75 mg

Definitions:

In the Vishay transceiver data sheets the following
nomenclature is used for defining the IrDA operating
modes:

SIR: 2.4 kbit/s to 115.2 kbit/s, equivalent to the basic
serial infrared standard with the physical layer version
IrPhy 1.0

MIR: 576 kbit/s to 1152 kbit/s
FIR: 4 Mbit/s
VFIR: 16 Mbit/s

MIR and FIR were implemented with IrPhy 1.1, fol­lowed by IrPhy 1.2, adding the SIR Low Power Stan­dard. IrPhy 1.3 extended the Low Power Option to
MIR and FIR and VFIR was added with IrPhy 1.4.A

18101

1234

IRED A

IRED C

TXD

56

RXD SD Vcc

7

Vlog

8

GND

new version of the standard in any case obsoletes the
former version.

With introducing the updated versions the old ver­sions are obsolete. Therefore the only valid IrDA stan­dard is the actual version IrPhy 1.4 (in Oct. 2002).

Absolute Maximum Ratings

Reference point Ground (pin 8) unless otherwise noted.
Typical values are for DESIGN AID ONLY, not guaranteed nor subject to production testing.

Parameter Test Conditions Symbol Min Ty p. Max Unit

Supply voltage range,
transceiver

Supply voltage range,
transmitter

Supply voltage range, V

Input current for all pins, except IRED anode

Output sinking current 25 mA

Power dissipation see derating curve, figure 4 P

Junction temperature T

Ambient temperature range
(operating)

Storage temperature range T

Soldering temperature see recommended solder profile

Average output current, pin 1 I

Repetitive pulsed output
current, pin 1 to pin 2

IRED anode voltage, pin 1 V

Voltage at all inputs and outputs V

Load at mode pin when used as
mode indicator

logic

- 0.3 V < V

- 0.5 V < V

- 0.5 V < V

- 0.5 V < V

- 0.5 V < V

- 0.3 V < V

pin

(figure 3)

t < 90 µs, t

< V

in

< 6 V

CC2

< 5.5 V

logic

< 6 V

CC1

< 5.5 V

logic

< 6 V

CC1

< 6.5 V

CC2

< 20 % I

on

is allowed V

CC1

V

CC1

V

CC2

V

logic

D

J

T

amb

stg

IRED(DC)

IRED(RP)

IREDA

in

- 0.3 + 6.0 V

- 0.3 + 6.5 V

- 0.3 + 5.5 V

10 mA

500 mW

125 °C

- 25 + 85 °C

- 25 + 85 °C

260 °C

125 mA

600 mA

- 0.5 + 6.5 V

- 0.5 + 5.5 V

50 pF

Document Number 82616

Rev. 1.5, 07-Apr-06

www.vishay.com

3

TFDU5307

Vishay Semiconductors

Eye safety information

Parameter Test Conditions Symbol Min Ty p. Max Unit

Virtual source size Method: (1-1/e) encircled

energy

Maximum intensity for class 1 IEC60825-1 or EN60825-1,

edition Jan. 2001, operating
below the absolute maximum
ratings

*)

Due to the internal limitation measures the device is a "class 1" device.

**)

IrDA specifies the max. intensity with 500 mW/sr.

Electrical Characteristics

Transceiver

T

= 25 °C, V

amb

Typical values are for DESIGN AID ONLY, not guaranteed nor subject to production testing.

Supply voltage V

Idle supply current SD = Low, E

Average dynamic supply
current, transmitting

Shutdown supply current SD = High, T = 25 °C, E

Standby supply current SD = High, T = 85 °C, not

Operating temperature range T

Output voltage low, RXD C

Output voltage high, RXD I

RXD to V

CC1

Input voltage low (TXD, SD) V

Input voltage high (TXD, SD)

Input leakage current (TXD, SD) V

Controlled pull down current SD, TXD = "0" to "1",

Input capacitance (TXD, SD) C

*)

Standard illuminant A

**)

The typical threshold level is 0.5 x V
The inputs in low state are actively loaded for noise protection. See for that the "Controlled pull down current" spec. Equivalently a pull up
current stabilizes the state when the inputs are in high state.

= V

CC1

= 2.7 V to 5.5 V unless otherwise noted.

CC2

Parameter Test Conditions Symbol Min Ty p. Max Unit

= 1 klx I

e

I

= 500 mA, 25 % Duty

IRED

Cycle

= 0 klx I

e

SD = High, T = 25 °C,

= 1 klx

e

*)

E

ambient light sensitive

= 15 pF, IOL = 1 mA V

Load

= - 500 µA V

OH

I

= - 250 µA, C

OH

= 15 pF V

Load

impedance R

< 0.15 V

in

**)

logic

logic

CMOS level

= 0.9 x V

in

0 < V

SD, TXD = "0" to "1",
V

> 0.7 V

in

logic

. It is recommended to use the specified min/max values to avoid increased operating current.

logic

d1.82.0 mm

(500)

*) **)

mW/sr

1µA

2.5 µA

5µA

0.4 V

V

V

+ 0.5 V

logic

+ 150 µA

5pF

I

I

I

I

e

CC1

CC1

I

CC

SD

I

SD

I

SD

OL

OH

OH

RXD

IL

V

IH

ICH

IRTx

IRTx

IN

2.7 5.5 V

550 900 µA

1100 1500 µA

A

- 25 + 85 °C

0.8 x V

logic

0.9 x V

logic

400 500 600 kΩ

- 0.5 0.5 V

V

- 0.5 V

logic

- 2 + 2 µA

- 1 0 1 µA

www.vishay.com

4

Document Number 82616

Rev. 1.5, 07-Apr-06

TFDU5307

Vishay Semiconductors

Optoelectronic Characteristics

Receiver

T

= 25 °C, VCC = 2.7 V to 5.5 V unless otherwise noted.

amb

Typical values are for DESIGN AID ONLY, not guaranteed nor subject to production testing.

Parameter Test Conditions Symbol Min Ty p. Max Unit

Minimum detection threshold
irradiance

Maximum detection threshold
irradiance

No detection receiver input
irradiance

9.6 kbit/s to 1.152 Mbit/s

λ = 850 nm - 900 nm

λ = 850 nm - 900 nm E

Threshold! No RXD output
below this irradiance value

E

e

40
(4)

e

5

(500)

E

e

4

(0.4)

90
(9)

allowed

Rise time of output signal 10 % to 90 %, CL = 15 pF,

= V

V

logic

CC

Fall time of output signal 90 % to 10 %, C

= V

V

logic

RXD pulse width of output
signal, default mode after power
on or reset

SIR ENDEC compatibility

*)

mode

: RXD pulse width of

output signal

Stochastic jitter, leading edge

input pulse length
P

> 200 ns

Wopt

input pulse length
P

> 200 ns, see chapter

Wopt

"Programming"

input irradiance = 100 mW/m

CC

= 15 pF,

L

2

,

t

r(RXD)

t

f(RXD)

t

PW

t

PW

20 60 ns

20 60 ns

300 400 500 ns

1.7 2.0 2.9 µs

80 ns

1.152 Mbit/s, 576 kbit/s

input irradiance = 100 mW/m

2

,

350 ns

≤ 115.2 kbit/s

Standby /Shutdown delay after shutdown active or (SD low

0.6 1.5 ms

to high transition)

Shutdown active time window
for programming

During this time the pulse
duration of the output can be

600 µs

programmed to the application
mode. see chapter
"Programming"

Receiver start up time power on
delay shutdown recovery delay

after shutdown inactive (SD high
to low transition) and after

300 µs

power-on

Latency t

*)

Some ENDECs are not able to decode short pulses as valid SIR pulses. Therefore this additional mode was added in TFDU5307.

L

200 µs

TFDU5307 is set to the "short output pulse" as default after power on, also after recovering from the shutdown mode (SD must have been
longer active than 1.5 ms). For mode changing see the chapter "Programming"

2

mW/m

(µW/cm

2

kW/m

(mW/cm2)

2

mW/m

(µW/cm

2)

2)

Document Number 82616

Rev. 1.5, 07-Apr-06

www.vishay.com

5

TFDU5307

Vishay Semiconductors

Transmitter

T

= 25 °C, VCC = 2.7 V to 5.5 V unless otherwise noted.

amb

Typical values are for DESIGN AID ONLY, not guaranteed nor subject to production testing.

Parameter Test Conditions Symbol Min Ty p. Max Unit

V

IRED operating current,
recommended serial resistor for
MIR applications

Output leakage IRED current TXD = 0 V, 0 < V

Output radiant intensity
recommended application
circuit, see figure 1

Output radiant intensity V

= 3.3 V: RS = 2.0 Ω

CC2

= 5.0 V: RS = 5.6 Ω

V

CC2

< 5.5 V I

CC1

α = 0 °, I

=420 mA

f

TXD = High, SD = Low

α = 0 °, 15 °, I

=420 mA

f

TXD = High, SD = Low

= 5.0 V, α = 0 °, 15 °

CC1

**)

**)

TXD = Low or SD = High
(Receiver is inactive as long as
SD = High)

Output radiant intensity, angle of
half intensity

Peak - emission wavelength

*)

Spectral bandwidth Δλ 45 nm

Optical rise time, fall time t

Optical output pulse duration input pulse width 217 ns,

1.152 Mbit/s
Note: IrDA specification for MIR

input pulse width t

input pulse width t

< 80 µs t

TXD

≥ 80 µs t

TXD

Optical overshoot 25 %

*)

Note: Due to this wavelength restriction compared to the IrDA spec of 850 nm to 900 nm the transmitter is able to operate as source for
the standard Remote Control applications with codes as e.g. Philips RC5/RC6
ditions (>120 mW/sr) the RC range to be covered is in the range from 8 m to 12 m, provided that state of the art remote control receivers
are used.

**)

Typ. conditions for If = 420 mA, V

= 3.3 V, Rs = 2.3 Ω, V

CC2

= 5.0 V, Rs = 6.4 Ω

CC2

I

D

IRED

I

e

I

e

I

e

- 1 1 µA

110 500 mW/sr

70 120 500 mW/sr

450 500 mA

0.04 mW/sr

α ± 24 °

λ

p

, t

ropt

fopt

t

opt

opt

opt

®

or RECS 80. When operated under IrDA full range con-

880 900 nm

640ns

190

(147.6)

20 t

217 240

(260)

TXD

20 85 µs

ns
ns

µs

www.vishay.com

6

Document Number 82616

Rev. 1.5, 07-Apr-06

TFDU5307

Vishay Semiconductors

Recommended Circuit Diagram

Used with a clean low impedance power supply the
TFDU5307 only needs an external series current lim­iting resistor. However, depending on the entire sys­tem design and board layout, additional components
may be required (see figure 1).

V

IRED

V

cc

GND

V

logic

SD

TXD

RXD

18147

Figure 1. Recommended Application Circuit

The capacitor C1 is buffering the supply voltage and
eliminates the inductance of the power supply line.
This one should be a Tantalum or other fast capacitor
to guarantee the fast rise time of the IRED current.
The resistor R1 is the current limiting resistor and this
is supply voltage dependent, see derating curve in fig­ure 4, to avoid too high internal power dissipation.
Vishay’s transceivers integrate a sensitive receiver
and a built-in power driver. The combination of both
needs a careful circuit board layout. The use of thin,
long, resistive and inductive wiring should be avoided.

C1

R1

R2

C2

IRED Anode

V

cc

Ground

V

logic

SD

TXD

RXD

IRED Cathode

The inputs (TXD, SD) and the output RXD should be
directly (DC) coupled to the I/O circuit.
The capacitor C2 combined with the resistor R2 is the
low pass filter for smoothing the supply voltage.
R2, C1 and C2 are optional and dependent on the
quality of the supply voltages and injected noise. An
unstable power supply with dropping voltage during
transmission may reduce the sensitivity (and trans­mission range) of the transceiver.
The placement of these parts is critical. It is strongly
recommended to position C2 as close as possible to
the transceiver power supply pins. A Tantalum capac­itor should be used for C1 while a ceramic capacitor
is used for C2.
In addition, when connecting the described circuit to
the power supply, low impedance wiring should be
used.
When extended wiring is used the inductance of the
power supply can cause dynamically a voltage drop
at V

. Often some power supplies are not apply to

CC2

follow the fast current rise time. In that case another

4.7 µF (type, see table under C1) at V

will be help-

CC2

ful.
Under extreme EMI conditions as placing an RF­transmitter antenna on top of the transceiver, we rec­ommend to protect all inputs by a low-pass filter, as a
minimum a 12 pF capacitor, especially at the RXD
port.
Keep in mind that basic RF - design rules for circuit
design should be taken into account. Especially
longer signal lines should not be used without termi­nation. See e.g. "The Art of Electronics" Paul Horow­itz, Winfield Hill, 1989, Cambridge University Press,
ISBN: 0521370957.

Table 1.
Recommended Application Circuit Components

Component Recommended Value Vishay Part Number

C1 4.7 µF, 16 V, Tantalum 293D 475X9 016B

C2 0.1 µF, Ceramic VJ 1206 Y 104 J XXMT

R1 5 V supply voltage: 5.6 Ω s. text 0.25 W (recommended

using two 2.8 Ω, 0.125 W resistors in series).

3.3 V supply voltage: 2.0 Ω s. text 0.25 W

R2 47 Ω, 0.125 W CRCW-1206-47R0-F-RT1

Document Number 82616

Rev. 1.5, 07-Apr-06

e.g. 2 x CRCW-1206-2R0-F-RT1 for 3.3 V supply voltage

www.vishay.com

7

TFDU5307

Vishay Semiconductors

I/O and Software

In the description, already different I/Os are men­tioned. Different combinations are tested and the
function verified with the special drivers available
from the I/O suppliers. In special cases refer to the I/
O manual, the Vishay application notes, or contact
directly Vishay Sales, Marketing or Application.

Programming
Pulse duration Switching

After Power-on the TFDU5307 is in the default short
RXD pulse duration mode.
Some ENDECs are not able to decode short pulses
as valid SIR pulses. Therefore an additional mode
with extended pulse duration (same as in standard
SIR transceivers) is added in TFDU5307. TFDU5307
is set to the "short output pulse" as default after power
on, and after recovering from the shutdown mode (SD
being active longer than 1.5 ms).
To switch the transceivers from the short RXD pulse
duration mode to the long pulse duration mode and
vice versa, follow the procedure described below.

3. Set SD to logic "LOW" (this negative edge latches
state of TXD, which determines speed setting).

4. After waiting t

≥ 200 ns TXD can be set to logic

h

"LOW". The hold time of TXD is limited by the maxi­mum allowed pulse length.

After that TXD is now enabled as normal TXD input
and the RXD output is set for the short RXD - pulse
duration mode.
The timing of the pulse duration changing procedure
is quite uncritical. However, the whole change must
not take more than 600 µs. See in the spec. "Shut­down Active Time Window for Programming"

SD 50 %

t

s

TXD 50 % 50 %

t

h

High:

Low:

400 ns

2 µs

Setting to the ENDEC compatibility mode
with an RXD pulse duration of 2 µs

1. Set SD input to logic "HIGH".

2. Set TXD input to logic "LOW". Wait t

≥ 200 ns.

s

3. Set SD to logic "LOW" (this negative edge latches
state of TXD, which determines speed setting).

4. After waiting t

≥ 200 ns.

h

After that TXD is enabled as normal TXD input and
the RXD output is set for the longer RXD - pulse dura­tion mode.

Setting back to the default mode with a
400 ns pulse duration

1. Set SD input to logic "HIGH".

2. Set TXD input to logic "HIGH". Wait t

≥ 200 ns.

s

18150

Figure 2. Timing Diagram for changing the output pulse duration

Simplified Method

Setting the device to the long pulse duration is simply
applying a short active (less than 600 µs) pulse to
SD. In any case a short SD pulse will force the device
to leave the default mode and go the compatibility
mode. Vice versa applying a 1.5 ms (minimum) pulse
at SD will cause the device to go back to the default
mode by activating a power-on-reset and setting the
device to the default short pulse mode. This simplified
method takes more time but may be easier to handle.

www.vishay.com

8

Document Number 82616

Rev. 1.5, 07-Apr-06

Table 2.
Truth table

Inputs Outputs Remark

SD TXD

high

< 600 µs

high

> 1.5 ms

low high x low (active) I

x x weakly pulled

x x weakly pulled

high

> 80 ms

low < 4 high inactive 0 Ignoring low signals below the IrDA

low > Minimum irradiance E

low > Maximum irradiance E

Optical input Irradiance mW/m

x high inactive 0 Protection is active

< Maximum irradiance E

2

e

e

e

RXD Transmitte

(500 kΩ) to V

(500 kΩ) to V

low (active) 0 Response to an IrDA compliant

undefined 0 Overload conditions can cause

CC1

CC1

TFDU5307

Vishay Semiconductors

r

0 Time window for pulse duration

0 Shutdown

e

Operation

setting

Transmitting

defined threshold for noise

immunity

optical input signal

unexpected outputs

Document Number 82616

Rev. 1.5, 07-Apr-06

www.vishay.com

9

TFDU5307

Time/s

/

C

10 s max. at 230 °C

120 s...180 s

240 °C max.

20 s

2 °C...4 °C/s

2 °C...4 °C/s

90 s...120 s

T ≥ 217 °C for 50 s max

T ≥ 255 °C for 20 s max

Vishay Semiconductors

Recommended Solder Profile

Solder Profile for Sn/Pb soldering

260

240

220

200

°

180

160

140

120

100

80

Tem perat u re

60

40

20

0

2...4 °C/s

0 50 100 150 200 250 300 350

160 °C max.

Figure 3. Recommended Solder Profile for Sn/Pb soldering

2...4 °C/s

90 s max.

19431_1

Lead-Free, Recommended Solder Profile

The lead-frame based transceivers (all types with the
name TFDUxxxx) are lead (Pb)-free and qualified for
lead (Pb)-free and lead - bearing processing.
In case of using a lead-bearing process we recom­mend a solder profile as shown in figure 4.
For lead (Pb)-free solder paste like Sn-(3.0-4.0)Ag­(0.5-0.9)Cu, there are two standard reflow profiles:
Ramp-Soak-Spike (RSS) and Ramp-To-Spike (RTS).
The Ramp-Soak-Spike profile was developed prima­rily for reflow ovens heated by infrared radiation. With
widespread use of forced convection reflow ovens the
Ramp-To-Spike profile is used increasingly. Shown
below in figure 5 and figure 6 are VISHAY’s recom­mende profiles for use with the TFDUxxxx transceiv­ers for lead (Pb)-free processing.

280

T

= 260 °C max.

260

240

220

200

180

160

140

120

Temperature/°C

100

80

60

40

20

0

0 50 100 150 200 250 300 350

19261

Time/s

50 s max.

peak

Figure 4. Solder Profile, RSS Recommendation

www.vishay.com

10

Document Number 82616

Rev. 1.5, 07-Apr-06

Figure 5. Solder Profile, RTS Recommendation

0

20

40

60

80

100

120

140

160

180

200

220

240

260

280

0 50 100 150 200 250 300

Time/s

Tempe ratur e/°C

< 4 °C/s

1.3 °C/s

Time above 217 °C t ≤ 70 s
Time above 250 °C t ≤ 40 s
Peak temperature T

peak

= 260 °C

< 2 °C/s

T

peak

= 260 °C max

TFDU5307

Vishay Semiconductors

A ramp-up rate less than 0.9 °C/s is not recom­mended. Ramp-up rates faster than 1.3 °C/s damage
an optical part because the thermal conductivity is
less than compared to a standard IC.

Current Derating Diagram

Figure 6 shows the maximum operating temperature
when the device is operated without external current
limiting resistor. A power dissipating resistor of 2 Ω is
recommended from the cathode of the IRED to
Ground for supply voltages above 4 V. In that case
the device can be operated up to 85 °C, too.

90

85

80

75

70

65

60

Ambient Temperature (°C)

55

50

2.0 2.5 3.0 3.5 4.0

18097

Operating Voltage [V] at duty cycle 20 %

4.5

5.0 5.5 6.0

Document Number 82616

Rev. 1.5, 07-Apr-06

Figure 6. Temperature Derating Diagram

www.vishay.com

11

TFDU5307

Vishay Semiconductors

TFDU5307 - TinyFace (Universal) Package (Dimensions in mm)

(Mechanical Dimensions)

www.vishay.com

12

18100

Document Number 82616

Rev. 1.5, 07-Apr-06

Reel Dimensions

TFDU5307

Vishay Semiconductors

14017

Tape Width A max. N W1 min. W2 max. W3 min. W3 max.

mm mm mm mm mm mm mm

16 330 50 16.4 22.4 15.9 19.4

Document Number 82616

Rev. 1.5, 07-Apr-06

www.vishay.com

13

TFDU5307

Vishay Semiconductors

Tape Dimensions in mm

Drawing-No.: 9.700-5280.01-4
Issue: 1; 03.11.03

www.vishay.com

14

19855

Figure 7. Tape drawing, TFDU5307 for top view mounting

Document Number 82616

Rev. 1.5, 07-Apr-06

TFDU5307

Vishay Semiconductors

Drawing-No.: 9.700-5279.01-4
Issue: 1; 08.12.04

Document Number 82616

Rev. 1.5, 07-Apr-06

19856

Figure 8. Tape drawing, TFDU5307 for side view mounting

www.vishay.com

15

TFDU5307

Vishay Semiconductors

Ozone Depleting Substances Policy Statement

It is the policy of Vishay Semiconductor GmbH to

1. Meet all present and future national and international statutory requirements.

2. Regularly and continuously improve the performance of our products, processes, distribution and operating

systems with respect to their impact on the health and safety of our employees and the public, as well as
their impact on the environment.

It is particular concern to control or eliminate releases of those substances into the atmosphere which are
known as ozone depleting substances (ODSs).

The Montreal Protocol (1987) and its London Amendments (1990) intend to severely restrict the use of ODSs
and forbid their use within the next ten years. Various national and international initiatives are pressing for an
earlier ban on these substances.

Vishay Semiconductor GmbH has been able to use its policy of continuous improvements to eliminate the use
of ODSs listed in the following documents.

1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments

respectively

2. Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental

Protection Agency (EPA) in the USA

3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C (transitional substances) respectively.

Vishay Semiconductor GmbH can certify that our semiconductors are not manufactured with ozone depleting
substances and do not contain such substances.

We reserve the right to make changes to improve technical design

and may do so without further notice.

Parameters can vary in different applications. All operating parameters must be validated for each

customer application by the customer. Should the buyer use Vishay Semiconductors products for any

unintended or unauthorized application, the buyer shall indemnify Vishay Semiconductors against all

claims, costs, damages, and expenses, arising out of, directly or indirectly, any claim of personal

damage, injury or death associated with such unintended or unauthorized use.

Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany

www.vishay.com

16

Document Number 82616

Rev. 1.5, 07-Apr-06

Legal Disclaimer Notice

Vishay

Document Number: 91000 www.vishay.com
Revision: 08-Apr-05 1

Notice

Specifications of the products displayed herein are subject to change without notice. Vishay Intertechnology, Inc.,
or anyone on its behalf, assumes no responsibility or liability for any errors or inaccuracies.

Information contained herein is intended to provide a product description only. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Vishay's
terms and conditions of sale for such products, Vishay assumes no liability whatsoever, and disclaims any express
or implied warranty, relating to sale and/or use of Vishay products including liability or warranties relating to fitness
for a particular purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right.

The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify Vishay for any damages resulting from such improper use or sale.
