793DX-793DE-CTC3-CTC4
*
Vishay Sprague
Solid Tantalum Surface Mount Capacitors
ANTAMOUNT
T
PERFORMANCE/ELECTRICAL CHARACTERISTICS
Operating Temperature: - 55 °C to + 125 °C
Capacitance Range: 0.10 µF to 100 µF
®
Molded Case, CECC Approved
FEATURES
• Terminations: 100 % Matte Tin, standard,
Tin/Lead available
• Compliant terminations
• Molded case available in four case codes
• Compatible with “High Volume” automatic pick
and place equipment
• Optical character recognition qualified
• CECC
30801/005 - 793DX
30801/009 - CTC3
30801/011 - CTC4
30801/801 - 793DE
Capacitance Tolerance: ± 10 %, ± 20 %
Voltage Rating: 4 VDC to 50 VDC
Pb-free
Available
RoHS
COMPLIANT
ORDERING INFORMATION
793DX
TYPE
793DE
CTC3
CTC4
Notes:
We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size.
Voltage substitutions will be marked with the higher voltage rating.
Effective July 15, 2008, part numbers with solderable termination codes “2T” and “2W” may have either matte tin or tin/lead terminations. Codes
2TE3 and 2WE3 specify only matte tin terminations. Codes 8T and 8W specify only tin/lead terminations.
106 X0 010 B 2WE3
CAPACITANCE CAPACITANCE
This is expressed in
picofarads. The first
two digits are the
significant figures. The
third is the number of
zeros to follow.
TOLERANCE
X9 = ± 10 %
X0 = ± 20 %
DC VOLTAGE RATING
at + 85 °C
This is expressed in V. To
complete the three-digit
block, zeros precede the
voltage rating. A decimal
point is indicated by an “R”
(6R3 = 6.3 V).
CASE CODE TERMINATION AND
See Ratings and
Case Codes Table.
2TE3: Matte Tin , 7" (178 mm) reel
2WE3: Matte Tin, 13" (330 mm) reel
8T: Tin/Lead, 7" (178 mm) reel
8W: Tin/Lead, 13" (330 mm) reel
PACKAGING
DIMENSIONS in inches [millimeters]
L
T MIN.
H
CASE CODE EIA SIZE L W H P T
A 3216-18
B 3528-21
C 6032-28
D 7343-31
0.126 ± 0.008
[3.2 ± 0.20]
0.138 ± 0.008
[3.5 ± 0.20]
0.236 ± 0.012
[6.0 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
0.063 ± 0.008
[1.6 ± 0.20]
0.110 ± 0.008
[2.8 ± 0.20]
0.126 ± 0.012
[3.2 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30]
H
0.063 ± 0.008
[1.6 ± 0.20]
0.075 ± 0.008
[1.9 ± 0.20]
0.098 ± 0.012
[2.5 ± 0.30]
0.110 ± 0.012
[2.8 ± 0.30]
W
0.031 ± 0.012
[0.80 ± 0.30]
0.031 ± 0.012
[0.80 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.047 ± 0.004
[1.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
T
W
P
W
TH (MIN.)
0.028
[0.70]
0.028
[0.70]
0.039
[1.0]
0.039
[1.0]
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.vishay.com For technical questions, contact: tantalum@vishay.com Document Number: 40112
48 Revision: 14-May-08
793DX-793DE-CTC3-CTC4
i
Solid Tantalum Surface Mount Capacitors
TANTAMOUNT® Molded Case, CECC Approved
RATINGS AND CASE CODES
C
R
(µF)
0.10 AA
0.15 AB
0.22 AB
0.33 AB
0.47 ABB
0.68 AA*B C
1.0 A A* B C
1.5 A A* B C D
2.2 A A* B B* C D
3.3 A A* B B* C D
4.7 A* B B* C D D
6.8 B B* C D
10 B B* C D D
15 B* C D D
22 C D D
33 C D D
47 D D
68 D D
100 D
Note:
* Available as 793DE part numbers only
4 V 6.3 V 10 V 16 V 20 V 25 V 35 V 50 V
2.7 V 4 V 7 V 10 V 13 V 17 V 23 V 33 V
RATED VOLTAGE U
CATEGORY VOLTAGE UC (V) (+ 125 °C)
(V) (+ 85 °C)
R
Vishay Sprague
MARKING
“A” CASE VOLTAGE CODE
Voltage
µF
22 10L
XX
B, C, D Case
V
Indicates
Lead
(Pb)-free
104L
Voltage
Code
VOLTS
4.0 G
6.3 J
10 A
16 C
20 D
25 E
35 V
50 T
CODE
Capacitance
Polarity
Band (+)
Data Code
Capacitance Code,
pF
Polarity Band (+)
A Case
Marking:
Capacitor marking includes an anode (+) polarity band, capacitance in microfarads and the voltage rating. “A” Case size capacitors use a
letter code for the voltage and EIA capacitance code.
The Vishay Sprague
A manufacturing date code is marked on all capacitors.
Call the factory for further explanation.
Document Number: 40112 For technical questions, contact: tantalum@vishay.com
Revision: 14-May-08 49
®
trademark is shown if space permits. Capacitors rated at 6.3 V shall be marked 6 V.
Ind
cates
Lead
(Pb)-free
2
Vishay
Sprague
Logo
www.vishay.com
793DX-793DE-CTC3-CTC4
Vishay Sprague
Solid Tantalum Surface Mount Capacitors
TANTAMOUNT® Molded Case, CECC Approved
RATINGS AND PART NUMBER REFERENCE
MAX. DC
CAPACITANCE
(µF)
3.3 A 793DX335(1)004A(2) 0.5 6 7.6 9.0 0.10
3.3 A 793DE335(1)004A(2) 0.5 6 7.6 9.0 0.10
3.3 A CTC3335(1)004A(2) 0.5 6 7.6 9.0 0.10
3.3 A CTC4335(1)004A(2) 0.5 6 7.6 9.0 0.10
4.7 A 793DE475(1)004A(2) 0.5 6 6.3 8.0 0.11
10 B 793DX106(1)004B(2) 0.5 6 3.5 4.5 0.12
10 B 793DE106(1)004B(2) 0.5 6 3.5 4.5 0.12
10 B CTC3106(1)004B(2) 0.5 6 3.5 4.5 0.12
10 B CTC4106(1)004B(2) 0.5 6 3.5 4.5 0.12
15 B 793DE156(1)004B(2) 0.6 6 2.9 3.8 0.17
33 C 793DX336(1)004C(2) 1.3 6 1.8 2.4 0.25
33 C 793DE336(1)004C(2) 1.3 6 1.8 2.4 0.25
33 C CTC3336(1)004C(2) 1.3 6 1.8 2.4 0.25
33 C CTC4336(1)004C(2) 1.3 6 1.8 2.4 0.25
68 D 793DX686(1)004D(2) 2.7 6 0.8 1.3 0.43
68 D 793DE686(1)004D(2) 2.7 6 0.8 1.3 0.43
68 D CTC3686(1)004D(2) 2.7 6 0.8 1.3 0.43
68 D CTC4686(1)004D(2) 2.7 6 0.8 1.3 0.43
100 D 793DX107(1)004D(2) 4.0 6 0.7 1.0 0.46
100 D 793DE107(1)004D(2) 4.0 6 0.7 1.0 0.46
100 D CTC3107(1)004D(2) 4.0 6 0.7 1.0 0.46
100 D CTC4107(1)004D(2) 4.0 6 0.7 1.0 0.46
2.2 A 793DX225(1)6R3A(2) 0.5 6 7.6 10.0 0.10
2.2 A 793DE225(1)6R3A(2) 0.5 6 7.6 10.0 0.10
2.2 A CTC3225(1)6R3A(2) 0.5 6 7.6 10.0 0.10
2.2 A CTC4225(1)6R3A(2) 0.5 6 7.6 10.0 0.10
3.3 A 793DE335(1)6R3A(2) 0.5 6 6.3 8.0 0.11
6.8 B 793DX685(1)6R3B(2) 0.5 6 3.4 4.5 0.16
6.8 B 793DE685(1)6R3B(2) 0.5 6 3.4 4.5 0.16
6.8 B CTC3685(1)6R3B(2) 0.5 6 3.4 4.5 0.16
6.8 B CTC4685(1)6R3B(2) 0.5 6 3.4 4.5 0.16
10 B 793DE106(1)6R3B(2) 0.6 6 2.9 3.8 0.17
22 C 793DX226(1)6R3C(2) 1.3 6 1.8 2.4 0.25
22 C 793DE226(1)6R3C(2) 1.3 6 1.8 2.4 0.25
22 C CTC3226(1)6R3C(2) 1.3 6 1.8 2.4 0.25
22 C CTC4226(1)6R3C(2) 1.3 6 1.8 2.4 0.25
47 D 793DX476(1)6R3D(2) 2.8 6 0.8 1.3 0.43
47 D 793DE476(1)6R3D(2) 2.8 6 0.8 1.3 0.43
47 D CTC3476(1)6R3D(2) 2.8 6 0.8 1.3 0.43
47 D CTC4476(1)6R3D(2) 2.8 6 0.8 1.3 0.43
68 D 793DX686(1)6R3D(2) 4.1 6 0.7 1.0 0.46
68 D 793DE686(1)6R3D(2) 4.1 6 0.7 1.0 0.46
68 D CTC3686(1)6R3D(2) 4.1 6 0.7 1.0 0.46
68 D CTC4686(1)6R3D(2) 4.1 6 0.7 1.0 0.46
Notes:
• (1) Tolerance: X0, X9
• (2) Terminations and Packaging: 2TE3, 2WE3, 8T, 8W
CASE
CODE
PART NU MB ER
LEAKAGE
at + 25 °C
(µA)
4 VDC at + 85 °C, 2.7 VDC at + 125 °C
6.3 VDC at + 85 °C, 4 VDC at + 125 °C
MAX. DF
at + 25 °C
(%)
MAX. ESR
at + 25 °C
100 kHz (Ω)
IMPEDANCE
(Z)
at + 25 °C
100 kHz
(Ω)
MAX. RIPPLE
100 kHz
I
rms
(A)
www.vishay.com For technical questions, contact: tantalum@vishay.com Document Number: 40112
50 Revision: 14-May-08
793DX-793DE-CTC3-CTC4
Solid Tantalum Surface Mount Capacitors
Vishay Sprague
TANTAMOUNT® Molded Case, CECC Approved
RATINGS AND PART NUMBER REFERENCE
MAX. DC
CAPACITANCE
(µF)
1.5 A 793DX155(1)010A(2) 0.5 6 8.0 10.5 0.10
1.5 A 793DE155(1)010A(2) 0.5 6 8.0 10.5 0.10
1.5 A CTC3155(1)010A(2) 0.5 6 8.0 10.5 0.10
1.5 A CTC4155(1)010A(2) 0.5 6 8.0 10.5 0.10
2.2 A 793DE225(1)010A(2) 0.5 6 6.3 8.0 0.11
4.7 B 793DX475(1)010B(2) 0.5 6 3.4 4.5 0.16
4.7 B 793DE475(1)010B(2) 0.5 6 3.4 4.5 0.16
4.7 B CTC3475(1)010B(2) 0.5 6 3.4 4.5 0.16
4.7 B CTC4475(1)010B(2) 0.5 6 3.4 4.5 0.16
6.8 B 793DE685(1)010B(2) 0.7 6 2.9 3.8 0.17
15 C 793DX156(1)010C(2) 1.5 6 1.8 2.5 0.25
15 C 793DE156(1)010C(2) 1.5 6 1.8 2.5 0.25
15 C CTC3156(1)010C(2) 1.5 6 1.8 2.5 0.25
15 C CTC4156(1)010C(2) 1.5 6 1.8 2.5 0.25
33 D 793DX336(1)010D(2) 3.3 6 0.8 1.3 0.43
33 D 793DE336(1)010D(2) 3.3 6 0.8 1.3 0.43
33 D CTC3336(1)010D(2) 3.3 6 0.8 1.3 0.43
33 D CTC4336(1)010D(2) 3.3 6 0.8 1.3 0.43
47 D 793DX476(1)010D(2) 4.7 6 0.7 1.0 0.46
47 D 793DE476(1)010D(2) 4.7 6 0.7 1.0 0.46
47 D CTC3476(1)010D(2) 4.7 6 0.7 1.0 0.46
47 D CTC4476(1)010D(2) 4.7 6 0.7 1.0 0.46
1.0 A 793DX105(1)016A(2) 0.5 4 9.3 11.0 0.09
1.0 A 793DE105(1)016A(2) 0.5 4 9.3 11.0 0.09
1.0 A CTC3105(1)016A(2) 0.5 4 9.3 11.0 0.09
1.0 A CTC4105(1)016A(2) 0.5 4 9.3 11.0 0.09
1.5 A 793DE155(1)016A(2) 0.5 6 6.7 9.0 0.11
3.3 B 793DX335(1)016B(2) 0.5 6 3.5 5.0 0.16
3.3 B 793DE335(1)016B(2) 0.5 6 3.5 5.0 0.16
3.3 B CTC3335(1)016B(2) 0.5 6 3.5 5.0 0.16
3.3 B CTC4335(1)016B(2) 0.5 6 3.5 5.0 0.16
4.7 B 793DE475(1)016B(2) 0.8 6 2.9 4.0 0.17
10 C 793DX106(1)016C(2) 1.6 6 1.8 2.5 0.25
10 C 793DE106(1)016C(2) 1.6 6 1.8 2.5 0.25
10 C CTC3106(1)016C(2) 1.6 6 1.8 2.5 0.25
10 C CTC4106(1)016C(2) 1.6 6 1.8 2.5 0.25
22 D 793DX226(1)016D(2) 3.5 6 0.8 1.5 0.43
22 D 793DE226(1)016D(2) 3.5 6 0.8 1.5 0.43
22 D CTC3226(1)016D(2) 3.5 6 0.8 1.5 0.43
22 D CTC4226(1)016D(2) 3.5 6 0.8 1.5 0.43
33 D 793DX336(1)016D(2) 5.3 6 0.7 1.2 0.46
33 D 793DE336(1)016D(2) 5.3 6 0.7 1.2 0.46
33 D CTC3336(1)016D(2) 5.3 6 0.7 1.2 0.46
33 D CTC4336(1)016D(2) 5.3 6 0.7 1.2 0.46
Notes:
• (1) Tolerance: X0, X9
• (2) Terminations and Packaging: 2TE3, 2WE3, 8T, 8W
CASE
CODE
PART NU MB ER
LEAKAGE
at + 25 °C
(µA)
10 VDC at + 85 °C, 7 VDC at + 125 °C
16 VDC at + 85 °C, 10 VDC at + 125 °C
MAX. DF
at + 25 °C
(%)
MAX. ESR
at + 25 °C
100 kHz (Ω)
IMPEDANCE
(Z)
at + 25 °C
100 kHz
(Ω)
MAX. RIPPLE
100 kHz
I
rms
(A)
Document Number: 40112 For technical questions, contact: tantalum@vishay.com
Revision: 14-May-08 51
www.vishay.com
793DX-793DE-CTC3-CTC4
Vishay Sprague
Solid Tantalum Surface Mount Capacitors
TANTAMOUNT® Molded Case, CECC Approved
RATINGS AND PART NUMBER REFERENCE
CAPACITANCE
(µF)
0.68 A 793DX684(1)020A(2) 0.5 4 10 13.0 0.09
0.68 A 793DE684(1)020A(2) 0.5 4 10 13.0 0.09
0.68 A CTC3684(1)020A(2) 0.5 4 10 13.0 0.09
0.68 A CTC4684(1)020A(2) 0.5 4 10 13.0 0.09
1.0 A 793DE105(1)020A(2) 0.5 4 8.4 11.0 0.09
2.2 B 793DX225(1)020B(2) 0.5 6 3.5 6.0 0.16
2.2 B 793DE225(1)020B(2) 0.5 6 3.5 6.0 0.16
2.2 B CTC3225(1)020B(2) 0.5 6 3.5 6.0 0.16
2.2 B CTC4225(1)020B(2) 0.5 6 3.5 6.0 0.16
3.3 B 793DE335(1)020B(2) 0.7 6 3.0 4.5 0.17
6.8 C 793DX685(1)020C(2) 1.4 6 1.9 2.5 0.24
6.8 C 793DE685(1)020C(2) 1.4 6 1.9 2.5 0.24
6.8 C CTC3685(1)020C(2) 1.4 6 1.9 2.5 0.24
6.8 C CTC4685(1)020C(2) 1.4 6 1.9 2.5 0.24
15 D 793DX156(1)020D(2) 3.0 6 0.9 1.5 0.41
15 D 793DE156(1)020D(2) 3.0 6 0.9 1.5 0.41
15 D CTC3156(1)020D(2) 3.0 6 0.9 1.5 0.41
15 D CTC4156(1)020D(2) 3.0 6 0.9 1.5 0.41
22 D 793DX226(1)020D(2) 4.4 6 0.7 1.2 0.46
22 D 793DE226(1)020D(2) 4.4 6 0.7 1.2 0.46
22 D CTC3226(1)020D(2) 4.4 6 0.7 1.2 0.46
22 D CTC4226(1)020D(2) 4.4 6 0.7 1.2 0.46
0.47 A 793DX474(1)025A(2) 0.5 4 12 14.0 0.08
0.47 A 793DE474(1)025A(2) 0.5 4 12 14.0 0.08
0.47 A CTC3474(1)025A(2) 0.5 4 12 14.0 0.08
0.47 A CTC4474(1)025A(2) 0.5 4 12 14.0 0.08
0.68 A 793DE474(1)025A(2) 0.5 4 8.4 11.0 0.09
1.5 B 793DX155(1)025A(2) 0.5 6 4.6 7.0 0.14
1.5 B 793DX155(1)025A(2) 0.5 6 4.6 7.0 0.14
1.5 B CTC3155(1)025A(2) 0.5 6 4.6 7.0 0.14
1.5 B CTC4155(1)025A(2) 0.5 6 4.6 7.0 0.14
2.2 B 793DE225(1)025B(2) 0.6 6 3.8 5.0 0.15
4.7 C 793DX475(1)025C(2) 1.2 6 2.0 2.8 0.24
4.7 C 793DE475(1)025C(2) 1.2 6 2.0 2.8 0.24
4.7 C CTC3475(1)025C(2) 1.2 6 2.0 2.8 0.24
4.7 C CTC4475(1)025C(2) 1.2 6 2.0 2.8 0.24
10 D 793DX106(1)025D(2) 2.5 6 1.0 1.5 0.39
10 D 793DE106(1)025D(2) 2.5 6 1.0 1.5 0.39
10 D CTC3106(1)025D(2) 2.5 6 1.0 1.5 0.39
10 D CTC4106(1)025D(2) 2.5 6 1.0 1.5 0.39
15 D 793DX156(1)025D(2) 3.8 6 0.8 1.2 0.43
15 D 793DE156(1)025D(2) 3.8 6 0.8 1.2 0.43
15 D CTC3156(1)025D(2) 3.8 6 0.8 1.2 0.43
15 D CTC4156(1)025D(2) 3.8 6 0.8 1.2 0.43
Notes:
• (1) Tolerance: X0, X9
• (2) Terminations and Packaging: 2TE3, 2WE3, 8T, 8W
CASE
CODE
PART NUMBER
MAX. DC
LEAKAGE
at + 25 °C
(µA)
20 VDC at + 85 °C, 13 VDC at + 125 °C
25 VDC at + 85 °C, 16 VDC at + 125 °C
MAX. DF
at + 25 °C
(%)
MAX. ESR
at + 25 °C
100 kHz (Ω)
IMPEDANCE
(Z)
at + 25 °C
100 kHz
(Ω)
MAX. RIPPLE
100 kHz
I
rms
(A)
www.vishay.com For technical questions, contact: tantalum@vishay.com Document Number: 40112
52 Revision: 14-May-08
793DX-793DE-CTC3-CTC4
Solid Tantalum Surface Mount Capacitors
Vishay Sprague
TANTAMOUNT® Molded Case, CECC Approved
RATINGS AND PART NUMBER REFERENCE
MAX. DC
CAPACITANCE
(µF)
0.10 A 793DX104(1)035A(2) 0.5 4 20 28.0 0.06
0.10 A 793DE104(1)035A(2) 0.5 4 20 28.0 0.06
0.10 A CTC3104(1)035A(2) 0.5 4 20 28.0 0.06
0.10 A CTC4104(1)035A(2) 0.5 4 20 28.0 0.06
0.15 A 793DX154(1)035A(2) 0.5 4 18 23.0 0.07
0.15 A 793DE154(1)035A(2) 0.5 4 18 23.0 0.07
0.15 A CTC3154(1)035A(2) 0.5 4 18 23.0 0.07
0.15 A CTC4154(1)035A(2) 0.5 4 18 23.0 0.07
0.22 A 793DX224(1)035A(2) 0.5 4 15 19.0 0.07
0.22 A 793DE224(1)035A(2) 0.5 4 15 19.0 0.07
0.22 A CTC3224(1)035A(2) 0.5 4 15 19.0 0.07
0.22 A CTC4224(1)035A(2) 0.5 4 15 19.0 0.07
0.33 A 793DX334(1)035A(2) 0.5 4 13 15.0 0.08
0.33 A 793DE334(1)035A(2) 0.5 4 13 15.0 0.08
0.33 A CTC3334(1)035A(2) 0.5 4 13 15.0 0.08
0.33 A CTC4334(1)035A(2) 0.5 4 13 15.0 0.08
0.47 B 793DX474(1)035B(2) 0.5 4 10 11.0 0.09
0.47 B 793DE474(1)035B(2) 0.5 4 10 11.0 0.09
0.47 B CTC3474(1)035B(2) 0.5 4 10 11.0 0.09
0.47 B CTC4474(1)035B(2) 0.5 4 10 11.0 0.09
0.68 B 793DX684(1)035B(2) 0.5 4 6.5 8.0 0.11
0.68 B 793DE684(1)035B(2) 0.5 4 6.5 8.0 0.11
0.68 B CTC3684(1)035B(2) 0.5 4 6.5 8.0 0.11
0.68 B CTC4684(1)035B(2) 0.5 4 6.5 8.0 0.11
1.0 B 793DX105(1)035B(2) 0.5 4 5.0 7.0 0.13
1.0 B 793DE105(1)035B(2) 0.5 4 5.0 7.0 0.13
1.0 B CTC3105(1)035B(2) 0.5 4 5.0 7.0 0.13
1.0 B CTC4105(1)035B(2) 0.5 4 5.0 7.0 0.13
1.5 C 793DX155(1)035C(2) 0.5 6 3.8 6.0 0.17
1.5 C 793DE155(1)035C(2) 0.5 6 3.8 6.0 0.17
1.5 C CTC3155(1)035C(2) 0.5 6 3.8 6.0 0.17
1.5 C CTC4155(1)035C(2) 0.5 6 3.8 6.0 0.17
2.2 C 793DX225(1)035C(2) 0.8 6 2.9 4.0 0.20
2.2 C 793DE225(1)035C(2) 0.8 6 2.9 4.0 0.20
2.2 C CTC3225(1)035C(2) 0.8 6 2.9 4.0 0.20
2.2 C CTC4225(1)035C(2) 0.8 6 2.9 4.0 0.20
3.3 C 793DX335(1)035C(2) 1.2 6 2.1 3.0 0.23
3.3 C 793DE335(1)035C(2) 1.2 6 2.1 3.0 0.23
3.3 C CTC3335(1)035C(2) 1.2 6 2.1 3.0 0.23
3.3 C CTC4335(1)035C(2) 1.2 6 2.1 3.0 0.23
4.7 D 793DX475(1)035D(2) 1.6 6 1.3 1.8 0.34
4.7 D 793DE475(1)035D(2) 1.6 6 1.3 1.8 0.34
4.7 D CTC3475(1)035D(2) 1.6 6 1.3 1.8 0.34
4.7 D CTC4475(1)035D(2) 1.6 6 1.3 1.8 0.34
6.8 D 793DX685(1)0035D(2) 2.4 6 1.1 1.5 0.37
6.8 D 793DE685(1)0035D(2) 2.4 6 1.1 1.5 0.37
6.8 D CTC3685(1)0035D(2) 2.4 6 1.1 1.5 0.37
6.8 D CTC4685(1)0035D(2) 2.4 6 1.1 1.5 0.37
10 D 793DX106(1)035D(2) 3.5 6 0.8 1.2 0.43
10 D 793DE106(1)035D(2) 3.5 6 0.8 1.2 0.43
10 D CTC3106(1)035D(2) 3.5 6 0.8 1.2 0.43
10 D CTC4106(1)035D(2) 3.5 6 0.8 1.2 0.43
Notes:
• (1) Tolerance: X0, X9
• (2) Terminations and Packaging: 2TE3, 2WE3, 8T, 8W
Document Number: 40112 For technical questions, contact: tantalum@vishay.com
Revision: 14-May-08 53
CASE
CODE
PART NU MB ER
LEAKAGE
at + 25 °C
(µA)
35 VDC at + 85 °C, 23 VDC at + 125 °C
MAX. DF
at + 25 °C
(%)
MAX. ESR
at + 25 °C
100 kHz (Ω)
IMPEDANCE
(Z)
at + 25 °C
100 kHz
(Ω)
MAX. RIPPLE
100 kHz
I
rms
(A)
www.vishay.com
793DX-793DE-CTC3-CTC4
Vishay Sprague
Solid Tantalum Surface Mount Capacitors
TANTAMOUNT® Molded Case, CECC Approved
RATINGS AND PART NUMBER REFERENCE
CAPACITANCE
(µF)
0.10 A 793DX104(1)050A(2) 0.5 4 19 27.0 0.06
0.10 A 793DE104(1)050A(2) 0.5 4 19 27.0 0.06
0.10 A CTC3104(1)050A(2) 0.5 4 19 27.0 0.06
0.10 A CTC4104(1)050A(2) 0.5 4 19 27.0 0.06
0.15 B 793DX154(1)050B(2) 0.5 4 14 22.0 0.08
0.15 B 793DE154(1)050B(2) 0.5 4 14 22.0 0.08
0.15 B CTC3154(1)050B(2) 0.5 4 14 22.0 0.08
0.15 B CTC4154(1)050B(2) 0.5 4 14 22.0 0.08
0.22 B 793DX224(1)0050B(2) 0.5 4 12 18.0 0.08
0.22 B 793DE224(1)0050B(2) 0.5 4 12 18.0 0.08
0.22 B CTC3224(1)0050B(2) 0.5 4 12 18.0 0.08
0.22 B CTC4224(1)0050B(2) 0.5 4 12 18.0 0.08
0.33 B 793DX334(1)050B(2) 0.5 4 10 14.0 0.09
0.33 B 793DE334(1)050B(2) 0.5 4 10 14.0 0.09
0.33 B CTC3334(1)050B(2) 0.5 4 10 14.0 0.09
0.33 B CTC4334(1)050B(2) 0.5 4 10 14.0 0.09
0.47 C 793DX474(1)050C(2) 0.5 4 6.7 9.0 0.13
0.47 C 793DE474(1)050C(2) 0.5 4 6.7 9.0 0.13
0.47 C CTC3474(1)050C(2) 0.5 4 6.7 9.0 0.13
0.47 C CTC4474(1)050C(2) 0.5 4 6.7 9.0 0.13
0.68 C 793DX684(1)050C(2) 0.5 4 5.9 7.0 0.14
0.68 C 793DE684(1)050C(2) 0.5 4 5.9 7.0 0.14
0.68 C CTC3684(1)050C(2) 0.5 4 5.9 7.0 0.14
0.68 C CTC4684(1)050C(2) 0.5 4 5.9 7.0 0.14
1.0 C 793DX105(1)050C(2) 0.5 4 4.6 6.0 0.16
1.0 C 793DE105(1)050C(2) 0.5 4 4.6 6.0 0.16
1.0 C CTC3105(1)050C(2) 0.5 4 4.6 6.0 0.16
1.0 C CTC4105(1)050C(2) 0.5 4 4.6 6.0 0.16
1.5 D 793DX155(1)050D(2) 0.8 6 2.9 5.0 0.25
1.5 D 793DE155(1)050D(2) 0.8 6 2.9 5.0 0.25
1.5 D CTC3155(1)050D(2) 0.8 6 2.9 5.0 0.25
1.5 D CTC4155(1)050D(2) 0.8 6 2.9 5.0 0.25
2.2 D 793DX225(1)050D(2) 1.1 6 2.1 3.5 0.27
2.2 D 793DE225(1)050D(2) 1.1 6 2.1 3.5 0.27
2.2 D CTC3225(1)050D(2) 1.1 6 2.1 3.5 0.27
2.2 D CTC4225(1)050D(2) 1.1 6 2.1 3.5 0.27
3.3 D 793DX335(1)0050D(2) 1.7 6 1.7 2.0 0.30
3.3 D 793DE335(1)0050D(2) 1.7 6 1.7 2.0 0.30
3.3 D CTC3335(1)0050D(2) 1.7 6 1.7 2.0 0.30
3.3 D CTC4335(1)0050D(2) 1.7 6 1.7 2.0 0.30
4.7 D 793DX475(1)050D(2) 2.4 6 1.2 1.5 0.37
4.7 D 793DE475(1)050D(2) 2.4 6 1.2 1.5 0.37
4.7 D CTC3475(1)050D(2) 2.4 6 1.2 1.5 0.37
4.7 D CTC4475(1)050D(2) 2.4 6 1.2 1.5 0.37
CASE
CODE
PART NU MBE R
MAX. DC
LEAKAGE
at + 25 °C
(µA)
50 VDC at + 85 °C, 33 VDC at + 125 °C
MAX. DF
at + 25 °C
(%)
MAX. ESR
at + 25 °C
100 kHz (Ω)
IMPEDANCE
(Z)
at + 25 °C
100 kHz
(Ω)
MAX. RIPPLE
100 kHz
I
rms
(A)
Notes:
• (1) Tolerance: X0, X9
• (2) Terminations and Packaging: 2TE3, 2WE3, 8T, 8W
www.vishay.com For technical questions, contact: tantalum@vishay.com Document Number: 40112
54 Revision: 14-May-08
793DX-793DE-CTC3-CTC4
Ω
Ω
Solid Tantalum Surface Mount Capacitors
TANTAMOUNT® Molded Case, CECC Approved
TYPICAL CURVES AT + 25 °C, IMPEDANCE AND ESR VS. FREQUENCY
100
10
0.1
IMPEDANCE
ESR
4.7 µF, 10 VDC-B CASE
1
4.7 µF, 10 VDC-D CASE
1K
10K
100K
1M
10M
100M
FREQUENCY IN (Hz)
100
10
Ω
10 µF, 16 VDC-C CASE
100K
0.1
1
1K
10K
FREQUENCY IN (Hz)
Vishay Sprague
IMPEDANCE
ESR
1M
10M
100M
100
10
0.1
100
IMPEDANCE
ESR
10
Ω
1
1K
10K
6.8 µF, 20 VDC-C CASE
22 µF, 20 VDC-D CASE
100K
1M
FREQUENCY IN (Hz)
10M
100M
0.1
1
1K
10K
100K
FREQUENCY IN (Hz)
1 µF, 35 VDC-B CASE
6.8 µF, 35 VDC-D CASE
1M
IMPEDANCE
ESR
10M
100M
Document Number: 40112 For technical questions, contact: tantalum@vishay.com
www.vishay.com
Revision: 14-May-08 55
Legal Disclaimer Notice
Vishay
Disclaimer
All product specifications and data are subject to change without notice.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf
(collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein
or in any other disclosure relating to any product.
Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any
information provided herein to the maximum extent permitted by law. The product specifications do not expand or
otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed
therein, which apply to these products.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any conduct of Vishay.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless
otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such
applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting
from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding
products designed for such applications.
Product names and markings noted herein may be trademarks of their respective owners.
Document Number: 91000 www.vishay.com
Revision: 18-Jul-08 1
Loading...
