VISHAY 738D User Manual

738D, CT9 (CECC 30202-004)

Vishay Tansitor

Wet Tantalum Capacitors

with Glass to Tantalum Hermetic Seal,

Sintered Anode TANTALEX® Capacitors

PERFORMANCE CHARACTERISTICS

Operating Temperature: - 55°C to + 85°C and with
voltage derating to two-thirds the + 85°C rating at + 125°C.
Capable of + 175°C operation at reduced voltage. Use of
Type 135D capacitors for high temperature applications is
recommended.

FEATURES

• Hermetic glass to tantalum seal

• High CV per unit volume

• Extremely low leakage current

• Wide temperature range: - 55 to + 175°C

• Improved reliability through the use of a glass-to- tantalum
true hermetic anode seal is the prime feature of the 738D
and CT9 sintered anode TANTALEX
construction eliminates all internal lead welds while
retaining the strength of internal lead-welded parts.

• The construction offers outstanding resistance to thermal
shock.

®

capacitor. This

Capacitance Tolerance: At 120 Hz, + 25°C. ± 20%
standard. ± 10%, ± 5% available as special.

DC Leakage Current (DCL Max.):

At + 25°C, + 85°C and + 125°C: Leakage current shall not
exceed the values listed in the Standard Ratings Tables.

Life Test: Capacitors are capable of withstanding a 2000
hour life test at a temperature of + 85°C or + 125°C at the
applicable rated DC working voltage.

ORDERING INFORMATION

CT9

738D

MODEL

226

CAPACITANCE

This is expressed in

picofarads. The first two

digits are the significant
figures. The third is the

number of zeros to

follow.

X0

CAPACITANCE

TOLERANCE

X0 = ± 20%
X9 = ± 10%
X5 = ± 5%

Special Order.

DC VOLTAGE RATING

This is expressed in volts.

To complete the three-digit

block, zeros precede the

voltage rating. A decimal

point is indicated by an "R"

APPROVALS

• CECC 30202-004 CT9 style

100

CASE CODE

AT + 85°C

See Ratings

Codes Table.

(6R3 = 6.3 volts).

B

and Case

2

STYLE NUMBER

0 = Bare case.
2 = Outer plastic

film insulation.

6 = High temperature

film insulation
(above + 125°C).

Packaging: The use of formed plastic trays for packaging these axial lead components is standard. Tape and reel is not recommended
due to the unit weight.

www.vishay.com
62

For technical questions, contact [e-mail]

Document Number: 40054

Revision 20-Oct-03

738D, CT9 (CECC 30202-004)

with Glass to Tantalum Hermetic Seal,

Sintered Anode TANTALEX® Capacitors

DIMENSIONS in inches [millimeters]

± 0.002

0.0253

[0.64 ± 0.05] Dia.

(No. 22 AWG)

Tinned Solderable Leads

BARE CASE

CASE
CODE

A

B

C

D

D

0.187 ± 0.015
[4.75 ± 0.38]

0.281 ± 0.015
[7.14 ± 0.38]

0.375 ± 0.015
[9.53 ± 0.38]

0.375 ± 0.015
[9.53 ± 0.38]

0.453 + 0.031 - 0.015
[11.51 + 0.79 - 0.38]

0.641 + 0.031 - 0.015

[16.28 + 0.79 - 0.38]

0.765 + 0.031 - 0.015

[19.43 + 0.79 - 0.38]

1.063 + 0.031 - 0.015

[27.00 + 0.79 - 0.38]

Wet Tantalum Capacitors

L

WITH OUTER

PLASTIC - FILM INSULATION

L

D (Max.)

0.219
[5.56]

0.312
[7.92]

0.406

[10.31]

0.406

[10.31]

0.180 [4.57]
Max.

Weld

Tantalum

L (Max.)

0.515

[13.08]

0.704

[17.88]

0.828

[21.03]

1.126

[28.60]

D

LEAD

LENGTH

1.500 ± 0.250
[38.10 ± 6.35]

2.250 ± 0.250
[57.15 ± 6.35]

2.250 ± 0.250
[57.15 ± 6.35]

2.250 ± 0.250
[57.15 ± 6.35]

Vishay Tansitor

Max. WEIGHT

(Ounces/Grams)

0.07
[2.0]

0.18
[5.1]

0.36

[10.2]

0.49

[13.9]

738D STANDARD RATINGS

Max. IMP.

Max. DF

CAPACITANCE

(µF)

68 A 738D686X06R3A2 17.1 10 1.0 1 2 -40 +10.5 +17.5
270 B 738D277X06R3B2 67.8 10 1.0 1 7 -44 +17.5 +20
560 C 738D567X06R3C2 151.9 10 1.0 2 13 -64 +17.5 +20

1000 D 738D108X06R3D2 100.5 10 1.0 3 14 -80 +25 +25
1200 D 738D128X06R3D2 120.6 10 1.0 3 14 -80 +25 +25

56 A 738D566X0008A2 14.1 10 1.0 1 2 -40 +10.5 +16
220 B 738D227X0008B2 55.2 10 1.0 1 7 -44 +17.5 +20
470 C 738D477X0008C2 82.6 10 1.0 2 14 -64 +17.5 +20
820 D 738D827X0008D2 51.5 10 1.0 4 16 -80 +25 +25

39 A 738D396X0010A2 15.1 10 1.0 1 2 -36 +12 +16

47 A 738D476X0010A2 15.1 10 1.0 1 2 -36 +14 +16
150 B 738D157X0010B2 28.2 10 1.0 1 6 -36 +14 +16
180 B 738D187X0010B2 45.2 10 1.0 1 7 -36 +14 +16
330 C 738D337X0010C2 51.9 10 1.0 2 16 -60 +17.5 +20
390 C 738D397X0010C2 73.5 10 1.0 2 16 -64 +17.5 +20
680 D 738D687X0010D2 42.7 10 1.0 4 16 -80 +25 +25

27 A 738D276X0016A2 10.3 10 1.0 1 2 -28 +10.5 +16

33 A 738D336X0016A2 10.3 10 1.0 1 2 -28 +14 +16
120 B 738D127X0016B2 30.2 10 1.0 1 7 -28 +17.5 +20
220 C 738D227X0016C2 34.5 10 1.0 2 16 -50 +17.5 +18
270 C 738D277X0016C2 50.8 10 1.0 2 16 -56 +17.5 +20
470 D 738D477X0016D2 35.4 10 1.0 6 24 -80 +25 +25
560 D 738D567X0016D2 42.2 10 1.0 6 24 -80 +25 +25

CASE

CODE

6.3 VDC at + 85°C, 4 VDC at + 125°C, 3 VDC at + 175°C

8 VDC at + 85°C, 5 VDC at + 125°C, 4 VDC at + 175°C

10 VDC at + 85°C, 6.3 VDC at + 125°C, 5 VDC at + 175°C

16 VDC at + 85°C, 10 VDC at + 125°C, 8 VDC at + 175°C

at + 20°C

(%)PART NUMBER*

at - 55°C

100 KHz

(Ohms)

Max. IMP.

at + 20°C

100 KHz

(Ohms)

Max. DCL (µA) at

+ 85°C

+ 20°C

+ 125°C

Max. CAPACITANCE

CHANGE (%) at

- 55°C

+ 125°C+ 85°C

Document Number: 40054
Revision 20-Oct-03

For technical questions, contact [e-mail]

www.vishay.com

63

738D, CT9 (CECC 30202-004)

Vishay Tansitor

with Glass to Tantalum Hermetic Seal,

Sintered Anode TANTALEX® Capacitors

738D STANDARD RATINGS

CAPACITANCE

(µF)

18 A 738D186X0025A2 6.9 10 1.0 1 2 -20 +10.5 +12
22 A 738D226X0025A2 6.9 10 1.0 1 2 -20 +10.5 +12

82 B 738D826X0025B2 20.6 10 1.0 1 10 -28 +13 +15
100 B 738D107X0025B2 25.1 10 1.0 1 10 -28 +13 +15
180 C 738D187X0025C2 42.2 10 1.0 2 18 -48 +13 +15
330 D 738D337X0025D2 27.2 10 1.0 7 28 -70 +25 +25
390 D 738D397X0025D2 31.8 10 1.0 7 28 -70 +25 +25

15 A 738D156X0030A2 7.5 10 1.0 1 2 -20 +10.5 +12

68 B 738D686X0030B2 25.6 10 1.0 1 8 -24 +13 +15
120 C 738D127X0030C2 24.4 10 1.0 2 17 -44 +13 +15
150 C 738D157X0030C2 37.7 10 1.0 2 18 -48 +13 +15
270 D 738D277X0030D2 27.2 10 1.0 8 32 -60 +25 +25

12 A 738D126X0040A2 6.7 10 1.0 1 2 -24 +8 +10

56 B 738D566X0040B2 21.1 10 1.0 1 9 -28 +13 +15
100 C 738D107X0040C2 15.7 10 1.0 2 17 -40 +13 +15
220 D 738D227X0040D2 25.0 10 1.0 8 32 -55 +25 +25

10 A 738D106X0050A2 5.7 10 1.0 1 2 -24 +8 +9

47 B 738D476X0050B2 17.7 10 1.0 1 9 -28 +12 +15

82 C 738D826X0050C2 20.6 10 1.0 2 16 -32 +12 +15
180 D 738D187X0050D2 23.7 10 1.0 8 32 -50 +25 +25

8.2 A 738D825X0063A2 4.1 10 1.0 1 2 -24 +8 +9
39 B 738D396X0063B2 17.2 10 1.0 1 9 -28 +10.5 +12
68 C 738D686X0063C2 25.6 10 1.0 2 16 -32 +10.5 +12

150 D 738D157X0063D2 23.6 10 1.0 8 32 -40 +20 +20

5.6 A 738D565X0075A2 3.4 10 1.0 1 2 -20 +8 +9

6.8 A 738D685X0075A2 3.4 10 1.0 1 2 -20 +8 +9
27 B 738D276X0075B2 11.8 10 1.0 1 9 -22 +11 +13
33 B 738D336X0075B2 14.5 10 1.0 1 10 -24 +15 +15
56 C 738D566X0075C2 21.8 10 1.0 2 17 -28 +15 +15

100 D 738D107X0075D2 19.5 10 1.0 9 36 -35 +20 +20
120 D 738D127X0075D2 23.3 10 1.0 9 36 -35 +20 +20

4.7 A 738D475X0100A2 2.9 30 3.0 1 2 -16 +7 +8
18 B 738D186X0100B2 7.8 15 1.5 1 8 -16 +7 +8
22 B 738D226X0100B2 9.7 15 1.5 1 9 -16 +7 +8
33 C 738D336X0100C2 9.3 15 1.0 2 15 -16 +7 +8
39 C 738D396X0100C2 14.7 15 1.0 2 17 -20 +7 +8
47 C 738D476X0100C2 17.7 15 1.0 2 17 -20 +7 +8
68 D 738D686X0100D2 13.7 15 1.5 9 36 -25 +15 +15
82 D 738D826X0100D2 16.4 15 1.5 9 36 -25 +15 +15

3.3 A 738D335X0125AR 3.4 30 3.0 1 2 -10 +7 +8

3.9 A 738D395X0125A2 3.4 30 3.0 1 2 -16 +7 +8
10 B 738D106X0125B2 9.4 15 1.5 1 5 -16 +7 +8
12 B 738D126X0125B2 8.3 15 1.5 1 6 -16 +7 +8
15 B 738D156X0125B2 11.2 15 1.5 1 7 -16 +7 +8
18 C 738D186X0125C2 10 15 1.0 2 9 -16 +7 +8
22 C 738D226X0125C2 12.1 15 1.0 2 11 -16 +7 +8
27 C 738D276X0125C2 16.7 15 1.0 2 13 -16 +7 +8
39 D 738D396X0125D2 7.5 15 1.5 10 40 -25 +15 +15
47 D 738D476X0125D2 9.2 15 1.5 10 40 -25 +15 +15
56 D 738D566X0125D2 14.2 15 1.5 10 40 -25 +15 +15

CASE
CODE

25 VDC at + 85°C, 16 VDC at + 125°C, 13 VDC at + 175°C

30 VDC at + 85°C, 19 VDC at + 125°C, 15 VDC at + 175°C

40 VDC at + 85°C, 25 VDC at + 125°C, 20 VDC at + 175°C

50 VDC at + 85°C, 32 VDC at + 125°C, 25 VDC at + 175°C

63 VDC at + 85°C, 40 VDC at + 125°C, 32 VDC at + 175°C

75 VODC at + 85°C, 50 VDC at + 125°C, 38 VDC at + 175°C

100 VDC at + 85°C, 63 VDC at + 125°C, 50 VDC at + 175°C

125 VDC at + 85°C, 80 VDC at + 125°C, 63 VDC at + 175°C

Wet Tantalum Capacitors

Max. DF

at + 20°C

(%)PART NUMBER*

Max. IMP.

at - 55°C
100 KHz

(Ohms)

Max. IMP.

at + 20°C

100 KHz

(Ohms)

Max. DCL (

+ 20

°C

µA) at

°C

+ 85

+ 125°C

Max. CAPACITANCE

CHANGE (%) at

- 55°C

+ 125°C+ 85°C

www.vishay.com
64

For technical questions, contact [e-mail]

Document Number: 40054

Revision 20-Oct-03

738D, CT9 (CECC 30202-004)

Wet Tantalum Capacitors

Vishay Tansitor

with Glass to Tantalum Hermetic Seal,

Sintered Anode TANTALEX® Capacitors

CT9 STANDARD RATINGS

Max. IMP.

Max. DF

CAPACITANCE

µF)

(

68 A CT9686X06R3A2 15 72 1 2 -40 +14 +16
270 B CT9277X06R3B2 41 30 1 7 -44 +17.5 +20
560 C CT9567X06R3C2 55 30 2 16 -64 +17.5 +20

1200 D CT9128X06R3D2 94 24 4 16 -80 +25 +25

47 A CT9476X0010A2 14 120 1 2 -36 +14 +16
180 B CT9187X0010B2 29 48 1 7 -36 +14 +16
390 C CT9397X0010C2 44 30 2 16 -64 +17.5 +20
820 D CT9827X0010D2 65 28 4 16 -80 +25 +25

33 A CT9 336X0016A2 10 108 1 2 -28 +14 +16
120 B CT9127X0016B2 24 60 1 7 -28 +17.5 +20
270 C CT9277X0016C2 45 36 2 16 -56 +17.5 +20
560 D CT9567X0016D2 44 28 6 24 -80 +25 +25

22 A CT9226X0025A2 7 168 1 2 -20 +10.5 +12
100 B CT9107X0025B2 21 60 1 10 -28 +13 +15
180 C CT9187X0025C2 29 39 2 18 -48 +13 +15
390 D CT9397X0025D2 40 29 7 28 -70 +25 +25

12 A CT9126X0040A2 6 234 1 2 -24 + 8 +10

56 B CT9566X0040B2 14 78 1 9 -28 +13 +15
100 C CT9107X0040C2 18 48 2 17 -40 +13 +15
220 D CT9227X0040D2 27 31 8 32 -55 +25 +25

8.2 A CT9825X0063A2 4.5 330 1 2 -24 + 8 + 9
39 B CT9396X0063B2 12 108 1 9 -28 +10.5 +12
68 C CT9686X0063C2 13 60 2 16 -32 +10.5 +12

150 D CT9157X0063D2 18 34 8 32 -40 +20 +20

6.8 A CT9685X0080A2 5 360 1 2 -20 + 8 + 9
33 B CT9336X0080B2 10 108 1 10 -24 +10.5 +15
56 C CT9566X0080C2 11 72 2 17 -28 +10.5 +15

100 D CT9107X0080D2 12 36 9 36 -35 +20 +20

4.7 A CT9475X0100A2 3 600 1 2 -16 + 7 + 8
22 B CT9226X0100B2 8 132 1 9 -16 + 7 + 8
47 C CT9476X0100C2 8 84 2 17 -20 + 7 + 8
82 D CT9826X0100D2 10 40 9 36 -25 +15 +15

3.9 A CT9395X0125A2 3.5 720 1 2 -16 + 7 + 8
15 B CT9156X0125B2 6 200 1 7 -16 + 7 +8
27 C CT9276X0125C2 6 106 2 13 -16 + 7 +8
56 D CT9566X0125D2 7 58 10 40 -25 +15 +15

CASE

CODE

6.3 VDC at + 85°C, 4 VDC at + 125°C, 3 VDC at + 175°C

10 VDC at + 85°C, 6.3 VDC at + 125°C, 5 VDC at + 175°C

16 VDC at + 85°C, 10 VDC at + 125°C, 8 VDC at + 175°C

25 VDC at + 85°C, 16 VDC at + 125°C, 13 VDC at + 175°C

40 VDC at + 85°C, 25 VDC at + 125°C, 20 VDC at + 175°C

63 VDC at + 85°C, 40 VDC at + 125°C, 32 VDC at + 175°C

80 VDC at + 85°C, 50 VDC at + 125°C, 40 VDC at + 175°C

100 VDC at + 85°C, 63 VDC at + 125°C, 50 VDC at + 175°C

125 VDC at + 85°C, 80 VDC at + 125°C, 63 VDC at + 175°C

at + 20°C

(%)PART NUMBER*

at - 55°C
100 KHz

(Ohms)

Max. DCL (

+ 20°C

µA) at

+ 85°C

+ 125°C

Max. CAPACITANCE

CHANGE (%) at

- 55

°C

+ 125

°C+ 85°C

Document Number: 40054
Revision 20-Oct-03

For technical questions, contact [e-mail]

www.vishay.com

65

738D, CT9 (CECC 30202-004)

Vishay Tansitor

with Glass to Tantalum Hermetic Seal,

Sintered Anode TANTALEX® Capacitors

CT9 EXTENDED RATINGS

CAPACITANCE

µF)

(

180 A CT9187X06R3A2 30 55 1.0 10 -60 +13 +16

820 B CT9827X06R3B2 115 22 2.0 17 -88 +16 +20
1500 C CT9158X06R3C2 115 22 6.0 25 -90 +20 +25
2200 D CT9228X06R3D2 125 16 6.0 25 -90 +25 +70

150 A CT9157X0010A2 25 65 1.0 10 -55 +13 +16

560 B CT9567X0010B2 80 34 2.0 17 -77 +16 +20
1200 C CT9128X0010C2 95 22 3.0 25 -88 +20 +25
1500 D CT9158X0010D2 85 18 6.0 25 -88 +25 +30

100 A CT9107X0016A2 25 88 1.0 10 -44 +13 +16

390 B CT9397X0016B2 55 38 2.0 17 -66 +16 +20

820 C CT9827X0016C2 85 27 4.0 25 -77 +20 +25
1000 D CT9108X0016D2 60 21 6.0 35 -80 +30 +30

68 A CT9686X0025A2 17 110 1.0 10 -40 +12 +15
270 B CT9277X0025B2 38 40 2.0 17 -62 +13 +16
560 C CT9567X0025C2 58 25 5.0 35 -72 +20 +25
680 D CT9687X0025D2 38 24 6.0 35 -80 +25 +30

39 A CT9396X0040A2 12 140 2.0 10 -35 +10 +12
150 B CT9157X0040B2 22 50 4.0 35 -52 +13 +16
330 C CT9337X0040C2 22 30 6.0 40 -60 +20 +25
470 D CT9477X0040D2 35 28 6.0 40 -70 +25 +30

27 A CT9276X0063A2 8.0 180 2.0 15 -24 +10 +12
100 B CT9107X0063B2 15 70 4.0 25 -36 +12 +15
220 C CT9227X0063C2 23 36 5.0 35 -40 +16 +20
270 D CT9277X0063D2 26 35 6.0 40 -65 +25 +30

22 A CT9226X0080A2 6.0 190 2.0 15 -19 +10 +12

82 B CT9826X0080B2 12 80 4.0 25 -30 +12 +15
180 C CT9187X0080C2 19 36 5.0 40 -35 +16 +20
220 D CT9227X0080D2 21 30 6.0 40 -60 +20 +25

10 A CT9106X0100A2 4.0 250 2.0 15 -17 +10 +12

39 B CT9396X0100B2 7.0 96 4.0 30 -20 +12 +15

68 C CT9686X0100C2 8.0 50 5.0 50 -30 +14 +16
120 D CT9127X0100D2 15 36 6.0 50 -40 +15 +20

6.8 A CT9685X0125A2 4.0 360 2.0 15 -14 +10 +12
27 B CT9276X0125B2 5.0 110 4.0 30 -18 +12 +15
47 C CT9476X0125C2 6.0 65 5.0 50 -26 +16 +16
82 D CT9826X0125D2 8.0 40 6.0 50 -30 +16 +17

CASE
CODE

6.3 VDC at + 85°C, 4 VDC at + 125°C, 3 VDC at + 175°C

10 VDC at + 85°C, 6.3 VDC at + 125°C, 5 VDC at + 175°C

16 VDC at + 85°C, 10 VDC at + 125°C, 8 VDC at + 175°C

25 VDC at + 85°C, 16 VDC at + 125°C, 13 VDC at + 175°C

40 VDC at + 85°C, 25 VDC at + 125°C, 20 VDC at + 175°C

63 VDC at + 85°C, 40 VDC at + 125°C, 32 VDC at + 175°C

80 VDC at + 85°C, 50 VDC at + 125°C, 40 VDC at + 175°C

100 VDC at + 85°C, 63 VDC at + 125°C, 50 VDC at + 175°C

125 VDC at + 85°C, 80 VDC at + 125°C, 63 VDC atπ + 175°C

Wet Tantalum Capacitors

Max. IMP.

Max. DF

at + 20°C

(%)PART NUMBER*

at - 55°C
100 KHz

(Ohms)

Max. DCL (

+ 20°C

µA) at

+ 85°C

+ 125°C

Max. CAPACITANCE

CHANGE (%) at

- 55

°C

+ 125

°C+ 85°C

www.vishay.com
66

For technical questions, contact [e-mail]

Document Number: 40054

Revision 20-Oct-03
