Viking Access Systems T21 User Manual

VIKING

installation instructions

and safety information

VIKING BLUE ENABLED

SOLAR EFFICIENT OPERATION

class I, class II, class III, and class IV

residential and commercial vehicular swing gate operator

1HP with battery backup are simple but powerful words describing the Viking T-21™

gate operator. The T-21™ is our heavy duty swing gate operator capable of handling

gates up to 1200 lbs. and 20’ long. Smooth efcient gate movement is achieved with

soft-start and soft-stop using the newest technology in electronics.

the viking T-21™swing gate operation

T-21 Vehicular Gate Operator • Revision B4 • November 2009

PARTS DIAGRAMPARTS DIAGRAM

20

22

29

2124

6

4

3

2

1

32 Multi-Part Arm

See Page 11 for
Additional Details

25

11

30(2)

18

19

30

8

9

13

12

14

7

28

23

2627

17

15

16

10

31

5

28-1/4"

1

7-3/4"

2

6-1/2"

EQEQ

7-1/2"

20"

ItemDescription

Output Shaft Knob

1

Part No.

WOUK10

D
2 Output Shaft Cover T21OC10
3 Clutch Key VAWRCK20

Clutch and Handle DWCL20

4
5 Output Arm DWAR20
6 Output Shaft DWOP10
7 Worm Gear #80 30:1 T21GB80
8 Sprocket 15 pitches, #50, 7/8 bore

T21SP507/8

9 Endless #50x36 Pitches T21CH50

10 Sprocket 15 pitches, #50, 3/4 bore

T21SP503/4
11 24V 1 HP DC Motor/Gear Assembly VAT21MO
12 Spacer DWSPA10
13 Limit Cam & Holder DWLC10
14 Limit switch (2) DULS10
15 Limit switch Holder DWLH10
16 Limit Switch Bracket T21LH
17 Alarm DUAL10
18 Electric Box DUEB10
19 Control Board DUPCB10
20 Chassis T21CHK
21 120V Receptacle DUOL120
22 EMI Board DUEMI10
23 Battery Fuse Holder VABFH
24 Battery DUBA12
25 Toroid Transformer DUTT15
26 Limit Switch Harness VALSWHA
27 Power Harness VAF1PHA
28 Operator Cover T21CO10
29 Operator Cover Bolt VASWCB
30 Power Switch DUMRS10
31 Warning Placard DUWPA
32 Multi-Part Arm

VA-F1ARM20

Overall Dimensions

eight 100 lb.

W

WARNING - For Installation By Qualified Personnel Only.

i

TECHNICAL SUPPORT 1 800 908 0884

TABLE OF CONTENTSTABLE OF CONTENTS

Parts Diagram/Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

Important Safety Information

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Important Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Maintenance/General Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

To Reduce Risk of Fire or Personal Injury & Terminology . . . . . . . . . . . . . . . . . .5

Photo Beam (non-contact sensor) Installation . . . . . . . . . . . . . . . . . . . . . . . . . .6

Edge Sensor (contact sensor) Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Manual Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Audible Alarm Reset Switch Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Warning Placard Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Important Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Plans of Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Plan of Installation – Concrete Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Gate Operator Installation

Step 1 through 6 – Operator Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-13

Electrical Installation

Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Single Unit Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Gate Operator Installation

Step 6 – Limit Switch Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-17

Limit Switch Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Electrical Installation

VikingBlue Wireless Master/Slave Installation . . . . . . . . . . . . . . . . . . . . . . . . . .18

Master/Slave Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Vehicular Loop Detector Installation

Loop Layout Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Loop Rack Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Accessory Connections

Open Commands; Safety Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Radio Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Optional Viking Electromagnetic Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Magnetic Lock; Solenoid Connection; Guard Station . . . . . . . . . . . . . . . . . . . . .26

Special Features

Auto-Open Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Intelligent Obstruction Sensor (Primary Entrapment Protection) . . . . . . . . . . . . .28

Fail Safe/Fail Secure Operation; Hold Open Timer . . . . . . . . . . . . . . . . . . . . . . .29

Gate Overlap Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Battery & EMI Board Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Optional Solar Panel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32-33

Optional VikingBlue Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35-37

TECHNICAL SUPPORT 1 800 908 0884

1

IMPORTANT SAFETY INFORMATIONIMPORTANT SAFETY INFORMATION

WARNING - Not following these instructions may cause severe injury or death to persons.

IMPORTANT SAFETY INSTRUCTIONS

WARNING – To reduce the risk of severe injury or death:

1. READ AND FOLLOW ALL INSTRUCTIONS.

2. Never let children operate or play with gate controls. Keep the remote control away from children.

3. Always keep people and objects away from the gate.

THE MOVING GATE

4. Test the gate operator monthly. The gate
an object activates the non-contact sensors. After adjusting the force or the limit of travel,
retest the gate operator. Failure to adjust and retest the gate operator properly can increase the
risk of injury or death.

5. Use the manual release only when the gate is not moving.

6.

KEEP GATES PROPERLY MAINTAINED. Read the owner’s manual. Have a qualified service per­son make repairs to gate hardware.

The entrance is for vehicles only. Pedestrians must use separate entrance.

7.

8.

Every gate operator installation
against entrapment, such as edge sensors and photo beams mor
in places where the risk of entrapment is more likely to occur.

9. SAVE THESE INSTRUCTIONS.

.

MUST reverse on contact with a rigid object or when

T

MMUUSST

have secondary protection devices

NO ONE SHOULD CROSS THE PATH OF

e in particularly

IMPORTANT INSTALLATION INSTRUCTIONS

Install the gate operator only when:

1.
a) The operator is appropriate for the construction of the gate and the usage Class of the gate

(refer to page 5),

b) All openings of a horizontal slide gate are guarded or screened from the bottom of the gate

to a minimum of 4 feet (1.22 m) above the ground to prevent a 2-1/4 inch (57.2 mm)
diameter sphere from passing through the openings anywhere in the gate, and in that
portion of the adjacent fence that the gate covers in the open position,

c)

ALL EXPOSED PINCH POINTS ARE ELIMINATED OR GUARDED, AND

d) GUARDING IS SUPPLIED FOR EXPOSED ROLLERS.
The operator is intended for installation only on gates used for vehicles. P

2.
supplied with a separate access opening. The pedestrian access opening shall be designed to
promote pedestrian usage. Locate the gate such that persons will not come in contact with the
vehicular gate during the entire path of travel of the vehicular gate.

3. The gate must be installed in a location so that enough clearance is supplied between the gate
and adjacent structures when opening and closing to reduce the risk of entrapment. Swinging
gates shall not open into public access areas.

The gate must be properly installed and work freely in both directions prior to the installation

4.
of the gate operator. Do not over-tighten the operator clutch or pressure
relief valve to compensate for a damaged gate.

5. The gate operator controls must be placed so that the user has full view
of the gate area when the gate is moving AND AWAY FROM THE GATE
PATH PERIMETER,

edestrians must be

2

TECHNICAL SUPPORT 1 800 908 0884

IMPORTANT SAFETY INFORMATIONIMPORTANT SAFETY INFORMATION

WARNING - Not following these instructions may cause severe injury or death to persons.

IMPORTANT INSTALLATION INSTRUCTIONS Continued

6. Controls intended for user activation must be located at least six feet (6’) away from any mov­ing part of the gate and where the user is prevented from reaching over, under, around or
through the gate to operate the controls. Outdoor or easily accessible controls shall have a secu­rity feature to prevent unauthorized use.

7. The Stop and/or Reset button must be located in the line-of-sight of the gate. Activation of the
reset control shall not cause the operator to start.

8. All warning signs and placards must be installed where visible in the area of the gate. A minimum
of two placards shall be installed. A placard is to be installed in the area of each side of the
gate and be visible to persons located on the side of the gate on which the placard is installed.

9.

For gate operators utilizing a non-contact sensor (Photo beam or like) in
accordance with section 31.1.1 of the UL325 standard:

a) See instructions on the placement of non-contact sensors for each Type of

application (refer to page 6),

b) Care shall be exercised to reduce the risk of nuisance tripping, such as when

a vehicle, trips the sensor while the gate is still moving, and

c) One or mor

or obstruction exists, such as the perimeter reachable by a moving gate or
barrier (refer to page 6).

d) Use only Omron E3K-R10K4 photoelectric eye to comply with UL325

e non-contact sensors shall be located where the risk of entrapment

10.

For a gate operator utilizing a contact sensor (Edge sensor or like) in
accordance with section 31.1.1 of the UL325 standard:

a) One or more contact sensors shall be located where the risk of entrapment or

obstruction exists, such as at the leading edge, trailing edge, and post mounted
both inside and outside of a vehicular horizontal slide gate (r

b) One or more contact sensors shall be located at the bottom edge of a vehicular

vertical lift gate.

c) One or more contact sensors shall be located at the pinch point of a vehicular

vertical pivot gate.

d) A hardwired contact sensor shall be located and its wiring arranged so that the

communication
mechanical damage.

e) A wireless contact sensor such as one that transmits radio frequency (RF)

signals to the gate operator for entrapment pr
located where the transmission of the signals are not obstructed or impeded
by building structures, natural landscaping or similar obstruction. A wireless
contact sensor shall function under the intended end-use conditions.

f) One or more contact sensors shall be located on the inside and outside leading

edge of a swing gate. Additionally, if the bottom edge of a swing gate is greater
than 6 inches (152 mm) above the gr
or more contact sensors shall be located on the bottom edge (refer to page 7).

between the sensor and the gate operator is not subjected to

otection functions shall be

ound at any point in its ar

g) One or more contact sensors shall be located at the bottom

edge of a vertical barrier (arm).

h) Use only Miller Edge Model MGR20 or MGS20 edge sensor

to comply with UL325

TECHNICAL SUPPORT 1 800 908 0884

efer to page 7).

c of travel, one

3

IMPORTANT SAFETY INFORMATIONIMPORTANT SAFETY INFORMATION

WARNING - Not following these instructions may cause severe injury or death to persons.

MAINTENANCE

Remove the Power Harness from the Control Board (refer to page 15)

• Clean and lubricate the turning pins and gate hinges using the recommended lubricant.

• Check that all mounting hardware of the gate operator is properly tighten.

• Ensure that the gate moves freely.

• Check for corroded parts and replace if necessary.

• Check the battery for the following:
Battery connections must be free of corrosion.
Battery voltage must be 26 VDC (fully charged battery).

Reconnect the Power Harness for the Control Board (refer to page 15)

• Check and confirm the proper operation of all safety devices (photoelectric eye, edge sensors or like).

• Check and confirm the operation of all installed accessories.

• Check and confirm the operation of all special features such as the Intelligent Obstruction Sensor, Hold

Open Timer (refer to page 23 to 29)

• Check and confirm the operation of the manual release (refer to page 7)

• Verify battery backup functionally by turning off the power source (120 VAC and 220 VAC). DO NOT

FORGET TO TURN ON THE POWER SOURCE AFTER VERIFICATION.

GENERAL SAFETY PRECAUTIONS

The following precautions are an integral and essential part of the product and must be supplied to the user.
Read them carefully as they contain important indications for the safe installation, use and maintenance.

• These instruction must be kept and forwarded to all possible future users of the system.

• This product must be used only for that which it has been expressly designed.

• Any other use is to be considered improper and therefore dangerous.

• The manufacturer cannot be held responsible for possible damage caused by improper, erroneous or

unreasonable use.

• Avoid operating in the proximity of the hinges or moving mechanical parts.

• Do not enter the path of the moving gate while in motion.

• Do not obstruct the motion of the gate as this may cause a situation of danger.

• Do not allow children to play or stay within the the path of the moving gate.

• Keep remote control or any other control devices out of the reach of children, in order to avoid possible

involuntary activation of the gate operator.
In case of break down or malfunctioning of the product, disconnect from the main power source. Do not

•

attempt to repair or intervene directly

• Failure to comply with the above may create a situation of danger.

All cleaning, maintenance or repair work must be carried out by qualified personnel.

•

• In order to guarantee that the system works efficiently and correctly it is important to have the manufacturer’s

instructions on maintenance of the gate and operator carried out by qualified personnel.

• In particular, regular checks are recommended in order to verify that the safety devices are operating correctly.

All installation, maintenance and repair work must be documented and made available to the user.

, contact only qualified personnel for repair.

Installer:

_____________________________________________________ ____________

Signature Date

Contact: _________________________________________________________

_________________________________________________________

4

TECHNICAL SUPPORT 1 800 908 0884

IMPORTANT SAFETY INFORMATIONIMPORTANT SAFETY INFORMATION

CAUTION: To Reduce the Risk of Fire or Injury to Persons

a) Use only the following type and size of battery(ies): Yuasa NP7-12

b) Do not dispose of the battery(ies) in fire. The cells may explode. Check with local codes for possible dis-

posal instructions.

c) Do not open or mutalate the battery(ies). Released electrolyte is corrosive and may cause damage to the

eyes or skin. It may be toxic fi swallowed.

d) Exercise care in handling batteries in order not to short the battery with conductying materials such as

rings, bracelets and keys.

e) Change the battery(ies) provided with or identified for use with this product only in accordance with the

instructions and limitations specified in this manual.

f) Observe proper polarity orientation between the battery(ies) and charging circuit.

g) Do not mix batteries of different sizes or from different manufacturers in this product (applies to products

employing more than one user replaceable secondary battery).

h) A battery-operated product employing a secondary battery supply intended to be charged within the

product shall contain specific instructions concerning the proper method of charging.

UL325 Gate Operator Classification

GLOSSARY

RESIDENTIAL VEHICULAR GA
CLASS I

in a home of one-to four single family dwelling, or a garage or
parking area associated therewith.

COMMERCIAL/GENERAL ACCESS VEHICULAR GATE OPERATOR
CLASS II

in a commercial location or building such as a multi-family hous­ing unit (five or more single family units), hotel, garages, retail
store, or other building servicing the general public.

INDUSTRIAL/LIMITED A
CLASS III

use in an industrial location or building such as a factory or
loading dock area or other locations not intended to service the
general public.

RESTRICTED ACCESS VEHICULAR GATE OPERATOR
CLASS IV

use in a guarded industrial location or building such as an air
port security area or other restricted access locations not servic­ing the general public, in which unauthorized access is prevented
via supervision by security personnel.

– A vehicular gate operator (or system) intended for use

– A vehicular gate operator (or system) intended for use

– A vehicular gate operator (or system) intended for

– A vehicular gate operator (or system) intended for

TE OPERATOR

CCESS VEHICULAR GA

TE OPERA

TOR

-

Install the gate operator only when:

The operator is appropriate for the construction of the gate
and the Usage Class of the gate.

TECHNICAL SUPPORT 1 800 908 0884

55

IMPORTANT SAFETY INFORMATIONIMPORTANT SAFETY INFORMATION

Gate in Open Position

Photo Beam Unit Reflector

Potential Entrapment

Area (Shaded)

Radio Station

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Loop Connector Open Commands Guard Station

Master/Slave

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

11

(C1)(C1)

33

(NC1)(NC1)

24VDC24VDC

1

(C1)3(NC1)

24VDC

Turn Switch to
'Light On' Position

24 VDC Power Connections

24 VDC Power Connections

Omron Model
E3K-R10
Shown

Connection '3' (NC1)

Connection '1' (C1)

W

ARNING - Not following these instructions may cause severe injury or death to persons.

NOTE - This type of installation DOES NOT reverse the gate all the way back to its limits when the photo-beam

is obstructed. This installation is only to protect against entrapment and to comply with UL325.

Photo Beam (non-contact sensor) Installation

Secondary Entrapment Protection

Photo beams or like must be installed to reduce the risk of entrapment.

Use only Omron E3K-R10K4 photoelectric eye to comply with UL325

Make the electrical connections of the photoelectric sensor as described here in this page.

Care shall be exercised to reduce the risk of nuisance tripping, such as when a
vehicle, trips the sensor while the gate is still moving, and

One or more non-contact sensors shall be located where the risk of entrapmentor
obstruction exists, such as the perimeter reachable by a moving gate or barrier.

One or more non-contact sensors shall be located where the risk of entrapment or
obstruction exists, such as the perimeter reachable by a moving gate or barrier.

Consult the installation manual for the UL325 device (photo
beam or like) for detail information about the usage,
installation and maintenance.

6

TECHNICAL SUPPORT 1 800 908 0884

IMPORTANT SAFETY INFORMATIONIMPORTANT SAFETY INFORMATION

Remove Hat

Locking Handle
(in Unlocked
Position)

R

adio Station

S

afety Connector

O

pen Commands

G

uard Station

M

aster/Slave

U

L

S

iren

L

oop Connector

O

pen Commands

G

uard Station

M

aster/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

6

0secoff

U

L

S

iren

60

Off

Siren

3

-Sided Edge Sensor

3

-Sided Edge Sensor

WARNING - Not following these instructions may cause severe injury or death to persons.

Edge Sensor (contact sensor) Installation

Secondary Entrapment Protection

Edge sensor or like must be installed to reduce the risk of entrapment.

Use only Miller Edge 3-sided activation type MGR20 or MDS20 to comply with UL325

One or more contact sensors shall be located on the inside and outside leading edge
of a swing gate. Additionally, if the bottom edge of a swing gate is greater than 6
inches (152 mm) above the ground at any point in its arc of travel, one or more
contact sensors shall be located on the bottom edge.

1. A hardwired contact sensor shall be located and its wiring arranged so that the
communication between the sensor and the gate operator is not subjected to
mechanical damage.

2. A wireless contact sensor such as one that transmits radio frequency (RF) signals
to the gate operator for entrapment protection functions shall be located where
the transmission of the signals are not obstructed or impeded by building
structures, natural landscaping or similar obstruction. A wireless contact sensor
shall function under the intended end-use conditions.

Manual Release

TECHNICAL SUPPORT 1 800 908 0884

When manual operation is required:

1. Remove the Hat

2. Lift the Locking Handle.

3. Remove the Clutch Key
To reengage the gate operator:

1. Align the Clutch and the notches on the
Output Shaft.

2. Insert the Clutch Key.

3. Push down the Locking Handle.

4. Reattach the Hat.

Attention: Lock and release operations MUST
be performed with motor NOT RUNNING.

7

IMPORTANT SAFETY INFORMATIONIMPORTANT SAFETY INFORMATION

Manual Stop

Button

5'

Minimum

S

TOP

6'

UL

Siren

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

UL

Siren

Siren

COM

N.O.

STOP

WARNING - Not following these instructions may cause severe injury or death to persons.

Audible Alarm Reset Switch Installation

Manual Reset for the Audible Alarm

UL325 standard requires an audible alarm to go off after two consecutive events
detected by the primary entrapment protection of the gate operator (obstruction sensor).

The audible alarm will continue to sound for 5 minutes or until a stop command
gets actuated.

The Stop command can be actuated in two different forms

1. Using the Built in Stop switch on the Control Box or

2. Using an External Stop button within the sight of the gate, away from moving
parts of the gate and out of reach of children.

3. Controls intended for user activation must be located at least six feet (6’) away
from any moving part of the gate and where the user is prevented from reaching
over, under, around or through the gate to operate the controls. Outdoor or easily
accessible controls shall have a security feature to prevent unauthorized use.

4. The Stop and/or Reset button must be located in the line-of-sight of the gate.
Activation of the reset control shall not cause the operator to start.

Warning Placard Installation

All Warning Signs and Placards must be installed where visible in the area
of the gate. A minimum of two placards shall be installed. A placard is
to be installed in the area of each side of the gate and be visible.

8

TECHNICAL SUPPORT 1 800 908 0884

IMPORTANT INSTALLATION INFORMATIONIMPORTANT INSTALLATION INFORMATION

2000 lb.

MAX.

12'-0"

1200 lb.

MAX.

20'-0"

C

LOSE

STOP

OPEN

ControlControl

ButtonsButtons

Control

Buttons

CAUTION -

FOR USE WITH GATES OF A MAXIMUM OF 12 FT IN LENGTH AND 2000 LBS.

IN WEIGHT OR 20 FT IN LENGTH AND 1200 LBS. IN WEIGHT.

WARNING - TO REDUCE THE RISK OF SEVERE INJURY OR DEATH TO PERSONS:

This is NOT a pedestrian gate operator

Do NOT Install the gate operator to lift gates

2000 pounds maximum gate weight at
12’ maximum gate length.

1200 pounds maximum gate weight at
20’ maximum gate length

Specifications

Maximum Gate Length: 20 feet at 1200 lbs., 12 feet at 2000 lbs.
Maximum Gate Weight: 2000 lbs. at 12 feet, 1200 lbs. at 20 feet
Maximum Aperture Angle: 120 deg.
Power Requirements: 120 VAC Single Phase at 3 Amps

Operating Temperature: -20°C (-4°F) to

TECHNICAL SUPPORT 1 800 908 0884

Locate Control Buttons:

1. Within sight of the gate,

2. At a minimum height of 5 feet so
small children are not able to
reach it, and

3. Away from all moving parts of
the gate.

Or
220 VAC Single Phase at 1.5 Amps

70°C (158°F)

9

PLANS OF INSTALLATION PLANS OF INSTALLATION

BC

C = A + 12"

Inside

Outside

Gate in Closed

Position

D

D = (L x 0.4

)

E = (L x 0.6)

L = 87" Maximum
with Viking Arm

A

F

Gate in Open Position

E

L

The gate must be installed in a location so that enough clearance is supplied between the
gate and adjacent structures when opening and closing to reduce the risk of entrapment.

Swinging gates shall not open into public access areas.

The installation shown using the
Straight Arm Secondary Extension can
NOT be back-driven. If a back-driven
installation is required, an Elbow Arm
Secondary Extension can be used.
Contact Viking Access for availability.

*Note: The dimensions provided are
just a guideline. Each site may have
different geometries or possibilities of
installation. The key for installation is
to have "E" longer than "D" and to
adjust the arms such that the arm is
straight at the closed position.

Place the operator at the desired
location and check the measurements
of A and B.

Figure A

Plan of Installation

10

TECHNICAL SUPPORT 1 800 908 0884

PLAN OF INSTALLATION – DETAILSPLAN OF INSTALLATION – DETAILS

Drill for a 1/2" x 3-1/2"
Red Head Anchor
(4) Places

23-1/4"

11"

2.5"

2.5"

30"

7-5/8"

2-7/16"

10"

3-1/4"

6" Minimum

20"

12"

Conduit Location

Center of Output Shaft

Recommended Area

for Conduit(s)

Gate Operator
Concrete Pad

Gate Operator Concrete Pad

Operator Cover

Grade Level
See Note 2

Operator Chassis

Secondary Extension

Dimension E

on Page 10

Dimension D

on Page 10

Primary Extension

Pivot Bracket

Concrete Pad

1. Follow the local building code to determine the required depth of the concrete pad.

2. Pad measurements recommended by Viking Access Systems are at least 20” long,
20” wide and 30” deep to ensure the stable operation of the operator, and a
minimum of 6” above level grade to avoid any flooding of the machinery.

4. Provide a sufficient number of conduit pathways for all low power accessories
such as loop detector leads, maglock, non-contact sensors, contact sensors, safety
and other commands.Also provide conduit for the power supply (either 110 or
220 VAC). Extend the conduit the recommended height of 1” above the level of
the concrete pad. Install all conduit in the shaded area shown above.

Arm Assembly Viking Part # VA-F1ARM

Viking Access Systems can supply an Elbow Arm
Secondary Extension to make the T-21 unit back­drivable. Contact Viking Access for availability.

TECHNICAL SUPPORT 1 800 908 0884

11

Remove Excess
Extension Tube

GATE OPERATOR INSTALLATIONGATE OPERATOR INSTALLATION

CAUTION - If mounting bar is not welded to

a frame member that runs the full length
of the gate, the gate operator may
damage the gate. Do not weld the bar or
backing plate to a few pickets.

STEP 1

Release the clutch (see page 7). Cut the
extension arms according to the desired plan
of installation (Figure A on page 10).

Note: Leave some additional material when
cutting the extension arms to allow for
additional adjustment.

STEP 2

Position the pieces of the articulated arm
with the gate in the closed position. Ensure
that the dimensions correspond to the chosen
plan of installation. Use C-clamps or tack-weld
pieces to aid in the pre-installation process.

STEP 3

With the clutch released, move the gate
manually from the completely open to the
completely closed position. Verify that:

A. The gate and arm combination can

provide the desired operation.

B. The arm does not bind in its movement,

especially in the open position.

Note: The total travel angle of the primary arm
on the output shaft determines the speed of the
gate operation. The smaller the travel angle,
the quicker the gate will open and close.

12 16

TECHNICAL SUPPORT 1 800 908 0884

Tighten the Clutch

GATE OPERATOR INSTALLATIONGATE OPERATOR INSTALLATION

Adjust the
Opposite Bolt

Insert
Clutch Key

Step 4

Upon observation of the satisfactory
arrangement of the articulated arm and
bracket, weld all pieces securely. Paint the
arm to protect it from rusting.

STEP 5

Upon test of the installation, loosen the
clutch and rotate it until it lines up with the
notches in the Output Shaft. Insert the
Clutch Key.

STEP 6

Check the Clutch adjustment. The Clutch is
shipped factory adjusted. The clutch must be
tight enough to prevent slippage in normal
operation.

Check the tightness of the Clutch:
A. Remove the Clutch Key from the clutch.
B. Attempt to move the gate by hand.
C. If slippage occurs:

1. Loosen the Locking Handle 180°
Tighten the opposite bolt.

2.

3. Tighten the Locking Handle 180°

4. Check the tightness of the clutch again.

NOTE – For proper operation of the Clutch,

keep the gap between the Clutch halves
even when adjusting (the Clutch will have
to be removed from the Output Shaft in
order to adjust the Release Handle bolt).

TECHNICAL SUPPORT 1 800 908 0884

1317

ELECTRICAL INSTALLATIONELECTRICAL INSTALLATION

To
Transformer

Neutral

Power Ground

115V/220V

Power Switch

Earth Ground

Hot

3A FUSE

Part # VAEMI

Ground Rod

Earth Ground

Radio Station

Mag.

Lock

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Radio

Rec.

UL

Sensor

OPEN RIG HT

24V BAT 24VAC

OPEN LEF T

Safety

Loop

Center

Loop

Obstruction

Sensor

Charger

Power

Low Battery

Motor Sensor

Hold Open

Timer

Stop

Overlap Delay

Close Open

Obstruction

Sensor

min. MAX

Overlap

Delay

1.5

0

3

Radio StationLoop ConnectorOpen CommandsGuard StationMaster/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag.

Lock

F

ail

Safe/Secure

MAG. LOCK

N.C.

COM

N.O.

Charger

Power

Low Battery

Check Motor

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Radio

Rec.

UL

Sens

Reopen

Loop

Center

Loop

White

Green

Red

Black

Caution – Do not connect the power harness to the board
until the installation is ready for verification.

The Gate Operator requires a single phase AC
line to operate and charge the batteries.

1. Turn off the main switch or breaker for
the power line being used.

Auxiliary Power Connection.
See page 27 for further details.

Power Harness

2. Move the selector switch on the Incoming
Voltage Selector to the proper position
(115 for 110 to 120VAC, 230 for 200 to 240VAC).

3. Connect the incoming power wires to the
terminals as shown in the illustration.

4. Turn on the main switch or breaker once
the installation is ready for final
adjustments.

To verify that there is AC power to the

5.

system, check that the ‘Charger’ LED on the
Control Board is on.

Tips for proper ground installation

A good ground in a gate operator
installation will minimize or prevent damage
to the operator cause by natural events such
as lightning strikes.

The following will provide a guideline for
proper grounding:

1. Use a ground rod to provide a ground
reference.

2. Consult your city code and be aware of
under-ground services in the site of the
gate operator to prevent inconveniences.

3. Use always a single bonding point for
grounding.

4. All ground wires must be as short and as
thick as possible.

5. Prevent unnecessary turns or loops in all
ground wires.

14 18

TECHNICAL SUPPORT 1 800 908 0884

ELECTRICAL INSTALLATION – SINGLE UNITELECTRICAL INSTALLATION – SINGLE UNIT

Radio

Rec.

UL

Sensor

OPEN RIG HT

OPEN LEF T

Safety

Loop

Center

Loop

Obstruction

Sensor

Charger

Power

Low Battery

Motor Sensor

Obstruction

Sensor

min. MAX

Charger

Power

Low Battery

Motor Sensor

Radio

Rec.

UL

Sensor

Safety

Loop

Center

Loop

Radio

Rec.

UL

Sensor

OPEN RIG HT

OPEN LEF T

Safety

Loop

Center

Loop

Obstruction

Sensor

Charger

Power

Low Battery

Motor Sensor

Obstruction

Sensor

min. MAX

Charger

Power

Low Battery

Motor Sensor

Radio

Rec.

UL

Sensor

Safety

Loop

Center

Loop

Power Connections

Connect the wire harness to the “OPEN RIGHT”
connector if the gate opens to the right.
Connect the wire harness to the “OPEN LEFT”
connector if the gate opens to the left.

RIGHT

OPEN

Gate opens towards right

OPEN LEFT

Gate opens towards left

TECHNICAL SUPPORT 1 800 908 0884

15

Left Limit Switch

Right
L

imit Switch

Clutch

Limit Switch Cam

Clutch Guide Pin

Cam Wheel

Left Limit Switch

Right Limit Switch

Set Left Cam
In This Direction

Set Right Cam
In This Direction

Cam Wheel

Limit Switch Cam

Adjust the 
Opposite Bolt

LIMIT SWITCH SET-UPLIMIT SWITCH SET-UP

Limit Switch Setup

STEP 7

A.

Loosen the screws on the Limit Switch Cams.

B. With the operator cover still off, remount

the articulated arm, making sure the cam
wheel pin is engaged with the clutch.

C.

Move the gate manually to the closed position.

D. Move the Limit Switch Cams on the Cam

Wheel to actuate each limit switch.

Gate Opens to Right

Left Limit Switch Open limit

Right Limit Switch Close limit

Gate Opens to Left

Left Limit Switch Close limit

Right Limit Switch Open limit

(see diagram on right to determine which
direction to move the cams)

E. Slightly tighten the screw on the Limit

Switch Cam.

F. Move the gate manually to the open

position. Repeat steps a, b and c for the
other cam.

G. Run the unit 2 full cycles without

interruption (from limit to limit) to
execute a “Learn Cycle.”

H. Fine-tune the adjustment of the Limit

Switch Cams.

Note:

Ensure that the cams move without restriction
through the course of the arm’s movement.

Step 8

Install the Clamshell Cover by carefully
slipping the front half over the Limit
Switches and Cam Wheel., then fitting the
back cover in place. Latch the hasps on both
sides of the Cover.

TECHNICAL SUPPORT 1 800 908 0884

1516

NC

NO

COM

NC

NO

COM

Cam Wheel

Red

Black

Green

White

Left Limit 
Switch

Right Limit Switch

Fast

Slow

Slow

LIMIT SWITCH SET-UPLIMIT SWITCH SET-UP

Opening/Closing Setup

1. Setup the limit switches manually at the desired open and close position.

2. Allow the gate operator to run a full open and close cycle (from limit to limit)
without interruption.

Note: During the first full open and close cycle: The gate operator doesn’t slow
down prior to reaching its limits. During subsequent cycles: The gate operator will
slow down prior to reaching its limits.

3. Verify that the gate opens and closes to the desired position.

To change the open or close limit position(s) the following
steps MUST BE taken:

A. Reset the gate operator by actuating both limit

switches at the same time

B. Repeat steps 1,2 and 3.

Limit Switch Connections

The Limit Switches
are wired as shown.

Additional Guide Pin
holes are provided to
allow orientation of
the Limit Cams away
from the Swing Arm.

TECHNICAL SUPPORT 1 800 908 0884

17

OPTIONAL VIKING BLUE INSTALLATIONOPTIONAL VIKING BLUE INSTALLATION

VIKINGBLUE

disconnected (red)

connected (green)

FCC ID:

T9JRN41-1

Serial #

Radio Station

O

p

en Commands

G

ua

rd

Sta

ti

on

Ma

ster/Sl

a

ve

Obst

ruct

ion

Sensor

.

m

in

.

.

MA

X

Overlap

Delay

1.5

0

3

3

Radio Station

Loop Connec

tor

O

p

en Commands

G

ua

rd

Sta

ti

on

Ma

ster/Sl

a

ve

GND

Clo

se

Sto

p

O

p

en

GND

Clo

se

Sto

p

O

p

en

Gn

d

F

ire

Gn

d

Strike

Gn

d

E

xit

Gn

d

Cen

ter

Gn

d

R

eo

p

en

Gn

d

U

L

Gn

d

+2

8

v

Gn

d

R

a

d

io

Gn

d

+2

8

v

+2

8

v

MAG. LOCK

CO

N.O

.

Hold Open

T

imer

St
op

St

Close

Open

Open

30

60

O

ff

1

Reopen

Cent

er

Loop

B

ra

k

e

Si

ren

JP3

C3

5

C36

JP2

Match upMatch up

White DotsWhite Dots

Match up

White Dots

InstallInstall

JumperJumper

Install

Jumper

JP3JP3JP3

JP2JP2JP2

OPEN RIGHT

24V BAT 24VAC

OPEN LEFT

Charger

Charger

Power

Low Battery

Check Motor

Rec.

WARNING – Connecting the plug backwards can result in damage to the Control Board

wwiillll rreennddeerr tthhee VViikkiinngg--BBlluuee MMoodduullee uusseelleessss..

and

VikingBlue Wireless Master/Slave

1. Decide which Operator will be the Master
and which will be the Slave.

2a. Install the “Master” Viking Blue Module on

the Master Control Board.

2b. Install the “Slave” Viking Blue Module on

the Slave Control Board.

Use care in connecting the plug to the Control
Board. The pins are small and easily bent.
Match the white dot on the plug to the white
dot on the control board (near the JP2 legend
as depicted).

3. Install the Jumper (near the JP3 legend
depicted). Viking-Blue requires this jumper
to operate as a Master/Slave device. The
“Low Battery” LED will turn ON, indicating
the Control Board is ready for use with the
Viking-Blue Module.

4. Attach the Viking-Blue Module to the
Operator. For better communication and
performance follow these guidelines:

• The Module must be under the Operator

Cover.

• The Modules must be facing each other as

18

much as possible.

The Light on the Viking-Blue module will turn
green upon connection between the other Module.

Be sure to test your Master/Slave communication.

TECHNICAL SUPPORT 1 800 908 0884

ELECTRICAL INSTALLATION – MASTER/SLAVEELECTRICAL INSTALLATION – MASTER/SLAVE

Inside

Outside

Slave UnitMaster Unit

Interconnecting
Conduit

Guard StationMaster/Slave

UL

Siren

Guard StationMaster/Slave

UL

Siren

GND

Close

Stop

Open

GND

Close

UL

Siren

Guard Station Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

UL

Siren

Shielded Cable

NOTE: 
Use 16 Gauge
Wire for runs 
up to 100'

Conduit

Shield Wire

Master/Slave Connections

Caution – Do not run Master/Slave communication cable in
the same conduit as the power supply (120-220V) cable.

The control board provides a connector for master/slave connectivity. This
connector will allow synchronized operation with a second gate operator.

Wire the operators as shown above and interconnect the two operators as follows:

Shield (to Earth) Shield (to Earth)

For Overlap Delay see page 29.

Master Board Slave Board Purpose

GND . . . . . . . . . . . . . . . . . . . .GND Reference

Close . . . . . . . . . . . . . . . . . . .Close Close Command

Stop . . . . . . . . . . . . . . . . . . . .Stop Stop Command

Open . . . . . . . . . . . . . . . . . . .Open Open Command

Note: It is recommended to connect all external

devices and set timer and overlap delay control
on the master unit. Ensure Slave Control Board

TECHNICAL SUPPORT 1 800 908 0884

has timer set to ‘OFF’ to allow the Master to
control the timer.

19

Inside

Outside

Exit Loop

Inside Reopen Loop

Center Loop

Outside

Reopen Loop

Inside

Outside

5'

5' 5'

AA

5'

Gate in Open Position

Inside

Reopen

Loop

Center

Loop

Outside

Reopen

Loop

Exit

Loop

Make Even

with Open Gate

VEHICULAR LOOP DETECTOR INSTALLATIONVEHICULAR LOOP DETECTOR INSTALLATION

Note: Not all loops may be necessary
for every installation. Check local
regulations and accepted best­practice design requirements

Dimension A – 5’ for Single Gate Operator

6’ for Master/Slave Gate Operator

20

TECHNICAL SUPPORT 1 800 908 0884

VEHICULAR LOOP DETECTOR INSTALLATIONVEHICULAR LOOP DETECTOR INSTALLATION

Twist Wire Outside the
Loop 6 Twists/Foot
Until Its Connection
to the Loop Detector

1/8" to 1/4" Saw Slot

Provide Additional Saw Cuts
to Eliminate Sharp Corners

Continuously Wind Wire
in Loop Slot for the
Required Number of Loops
(2 Loops Shown)

1" Min.

Backer-Rod

Vehicular Loop 

Detector Wire 

(3 Turns Shown)

Sealant

Saw Cut

WWAARRNNIINNGG––CCoonnssuulltt tthhee iinnssttaallllaattiioonn iinnssttrruuccttiioonnss ffrroomm tthhee lloooopp ddeetteeccttoorr mmaannuuffaaccttuurreerr.. TThhee ffoolllloowwiinng

g

ssttaatteemmeennttss aarree pprroovviiddeedd aass aa gguuiiddee bbuutt ddiiffffeerreenntt rreeqquuiirreemmeennttss mmaayy bbee rreeqquuiirreedd bbyy tthhe
vveehhiiccuullaarr lloooopp ddeetteeccttoorr mmaannuuffaaccttuurreerr.

.

Guidelines for Vehicular Loop Detector Installation

1. Prevent sharp corners in the geometry of the loop sensor.

2. Install the appropriate number of turns for your loop geometry based on the loop perimeter. Use
Table C (below) as a guide.

3. Use XLP (cross-linked-polyethylene) type of wire. This wire reduces the effects of moisture and
other environmental events in altering the functionality of the vehicular loop detector.

4. Twist the lead wire at least 6 turns per foot.

5. Use BACKER-ROD to minimize damage to the loop detector wire prior to using the sealant.

6. Place the loop detector wire and adjust the sensitivity of the vehicular loop detector unit in a
way to minimize the effects of the gate over the loop detector wire.

IMPORT

ANT – Some of the following parameters may affect the proper functionality of the

vehicular loop detector (consult the installation manual and the manufacturer of the
vehicular loop detector).

• Gate size,

• Number of turns in the loop sensor wire;

• Distance from the loop sensor wire to the gate either at the open or close position.

e

TECHNICAL SUPPORT 1 800 908 0884

Table C – Recommended Number of Turns

Perimeter in Feet Number of Turns

10 5
20 4

30-40 3

50-100 2

21

Radio Station

Mag.

Lock

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Brake

UL

Siren

Hold Open

Timer

Stop

Close Open

Radio Station

Loop Connector Open Commands Guard Station

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag.

Lock

Mag. Lock

N.C.

COM

N.O.

Hold Open

Timer

Stop

CloseOpen

LimitLimit

30sec

60secoff

1sec

Brake

UL

Siren

Mag.

Lock

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Brake

Siren

Inside

Outside

R

eopen

Center

E

xit

Reopen

C

enter

E

xit

G

nd

2

8V

Twist Wire Outside the

Loop 6 Twists/Foot

Until Its Connection

to the Loop Rack

Inside Safety

Loop

Center

Loop

Outside Safety

L

oop

E

xit

Loop

Loop Connector

Control Board
Connector

Viking Loop Rack

Reopen

CenterExit

OP CN RO

LOOP RACK INSTALLATIONLOOP RACK INSTALLATION

Looprack – Viking Part # VA LR
Looprack Wiring Harness – Viking Part # VA LRH

22

TECHNICAL SUPPORT 1 800 908 0884

OPTIONAL ACCESSORY CONNECTIONS

Safety ConnectorOpen CommandsGuard StationMaster/Slave

UL

Siren

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

UL

Siren

Siren

Exit

Loop

Detector

Fire

Override

Keypad

FIRE

Safety ConnectorOpen CommandsGuard StationMaster/Slave

UL

Siren

Loop Connector Open Commands Guard Station

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

UL

Siren

Siren

Center
Loop
Detector

Safety

Loop
Detector

Photo

Beam

Edge Sensor

2

1

Radio Station

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

UL

Siren

Radio Station

Loop Connector Open Commands Guard Station

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

Mag. Lock

N.O.

UL

Siren

Off

Siren

Photo

Beam

Inside

Outside

OPTIONAL ACCESSORY CONNECTIONS

Safety Connections

Connection Locations

Vehicle loop detectors must be installed to
decrease the possibility of vehicle
entrapment on the gate (see page 20).

The SECONDARY ENTRAPMENT PROTECTION
like the edge sensor and the photoelectric
beam MUST BE PART OF EVERY SINGLE
INSTALLATION to prevent pedestrian or
animal entrapment (see pages 6 and 7).

The edge sensor and/or the photoelectric
beam must be UL325 compliant devices.

Reopen Photo Beam

Note: Installing the photo beam in this way,
allows the gate to re-open all the way upon
obstruction of the photo-beam.

1

Open Commands

2

As an alternative to the Outside Reopen Loop,
a photo beam unit can be used as shown.

TECHNICAL SUPPORT 1 800 908 0884

23

Radio Station

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

UL

Siren

Radio Station

Loop Connector Open Commands Guard Station

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag. Lock

COM

N.O.

60secoff

UL

Siren

60

Off

1

Siren

External

Accessories

COM

NO

Gnd

+24VDC

OPTIONAL ACCESSORY CONNECTIONS

OPTIONAL ACCESSORY CONNECTIONS

Radio Receiver

When connecting the Radio Receiver carefully verify the proper connections.

The maximum voltage that the control board provides for external accessories is the
maximum voltage of the battery, which is about 28 volts.

In the event of an electrical short in the power to the accessories, the board will
protect itself by shutting down and will remain shut down until the short is corrected.

The control board provides two modes of
operation that a radio receiver can control
the gate:

Open-Stop-Close

1. By having the radio receiver connected as
illustrated and with the Hold Open Timer
OFF (see page 29):

Every command of the radio transmitter
will control the gate as follow:
a) First command opens the gate,
b) Second command stops the gate and
c) Third command closes the gate
d) Any subsequent commands will continue

in the same order to control the gate.

This type of configuration is not
recommended for a commercial
installations.

Open Only

2. By having the radio receiver connected as
illustrated and with the Hold Open Timer
ON (see page 29):

Each command of the radio transmitter is
ALWAYS AN OPEN COMMAND to the gate.

Note: All controls are normally open.

24

TECHNICAL SUPPORT 1 800 908 0884

M

ounting Plate/Juction Box

(Weld to Post)

M

ounting Plate

(Weld to Gate)

Set Screw

(Locks Floating Plate

M

ounting Screw)

Floating Plate

Mounting Screw

24 Volt DC Transformer

(Supplied with Lock Kit)

Cover
P

late

Cover Plate
Mounting
Screw (4)

Magnetic Lock

Mounting Screw (4)

M

ounting Screw

Weather Cover (4)

F

lexible Washer

Spacer (0 to 3)

U

se to adjust

gap between

Floating Plate and

Magnetic Lock

Guide Pin (2)

U

se long or short pin

depending on number

o

f spacers used

Floating Plate

3.000" to

3.125"

(example)

10.625"

7.5"

2.100"

Mounting Plate/
Juction Box

M

ounting Plate

Magnetic Lock

Floating Plate

M--

Radio Station

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Radio Station

Loop Connector Open Commands Guard Station

Master/Slave

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag. Lock

N.C.

COM

N.O.

60secoff

1sec

Hold Open

60

Off

1

Green

Black

White

Red

24VDC Transformer
(Supplied with Lock Kit)

24VDC

Magnetic

Lock

4-wire Cable

(Supplied with

Lock Kit)

M

™

2

2

OPTIONAL ELECTROMAGNETIC LOCKOPTIONAL ELECTROMAGNETIC LOCK

Standard Features

• Mounting base with electrical box

• 24VDC Plug-in transformer

• 12VDC or 24VDC operation
500mA at 12VDC operation

•

• 250mA at 24VDC operation

• 1300 pounds of holding force

External supply for the magnetic
lock must be provided. This will
prevent rapid drainage of the bat­tery in the event of power failure.

Relay Contact 10A-250VAC

TECHNICAL SUPPORT 1 800 908 0884

This Magnetic Lock is an OPTIONAL ACCESORY available from
Viking Access Systems. Please order part number VA-MAG13.

Connection Location

2524

UL

Siren

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

UL

Siren

Siren

N.O.

N.O.

N.O.

COM

CLOSE

STOP

OPEN

Radio Station

Mag.

Lock

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Brake

UL

Siren

Hold Open

Timer

Stop

Close Open

Radio Station

Loop Connector Open Commands Guard Station

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag.

Lock

Mag. Lock

N.C.

COM

N.O.

Hold Open

Timer

Stop CloseOpen

LimitLimit

30sec

60secoff

1sec

Brake

UL

Siren

Mag.

Lock

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Brake

Siren

Radio Station

Mag.

Lock

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Brake

UL

Siren

Hold Open

Timer

Stop

Close Open

Radio Station

Loop Connector Open Commands Guard Station

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag.

Lock

Mag. Lock

N.C.

COM

N.O.

Hold Open

Timer

Stop CloseOpen

LimitLimit

30sec

60secoff

1sec

Brake

UL

Siren

Mag.

Lock

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Brake

Siren

21

OPTIONAL ACCESSORY CONNECTIONS

OPTIONAL ACCESSORY CONNECTIONS

Magnetic Lock

External supply for the magnetic lock must
be provided. This will prevent rapid drainage
of the battery in the event of power failure.

Relay Contact 10A-250VAC

1

Connection Locations

Viking Access Systems can supply an
excellent Magnetic Lock unit (part number
VA-MAG13). See page 24 for more details.

Solenoid Connection

External supply for the solenoid connection
must be provided. This will prevent rapid
drainage of the battery in the event of
power failure.

Relay Contact 10A-250VAC

1

Guard Station

The guard station provides control of the
gate operator to open, stop and close the
gate.

All three switches must be Normally Open
type of switch, and can share the same

2

26

common (ground).

Place the control switch box within sight of
the gate, away from moving parts of the
gate and out of reach of children.

TECHNICAL SUPPORT 1 800 908 0884

SPECIAL FEATURESSPECIAL FEATURES

Mag.

Lock

Radio

Rec.

UL

OPEN RIG HT

24V BAT 24VAC

OPEN LEF T

Charger

Power

Low Battery

Motor Sensor

Charger

Power

Low Battery

Check Motor

Radio

Rec.

UL

Sens

Radio

Rec.

UL

Sensor

24V BAT 24VAC

OPEN LEF T

Safety

Loop

Center

Loop

Obstruction

Sensor

Charger

Power

Overlap Delay

Sensor

Delay

1.5

Fail

S

afe/Secure

Charger

Power

Radio

Rec.

UL

Sens

Reopen

Loop

Center

Loop

JP3

C35 C36

Auto-Open Feature

The Auto-Open feature in Viking Gate Operators enables the following functionality in
the event of power failure:

a) Open the gate in case of power failure (120 or 220 VAC).

b) Keep the gate at the open position as long as the there is no power.

c) Resume to normal operation when the power has been restored.

The Auto-Open feature allows proper operation while opening in case of power failure
for the following devices:

• All accessories,

• All safety devices,

• All entrapment protections.

The only operation that can not be executed while opening in case of power failure is to
CLOSE the gate.

To enable the Auto-Open feature : Use the
“jumper” provided and place it on the pin­header of JP3, on the terminals close to C35 as
the illustration indicates.

Once you put the “jumper” on the control
board the “Check Motor” light will come on
indicating that the Auto-Open feature has been
enabled.

TECHNICAL SUPPORT 1 800 908 0884

27

SPECIAL FEATURESSPECIAL FEATURES

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Brake

UL

Siren

Center

Loop

Obstruction

Sensor

Hold Open

Timer

Stop

Overlap Delay

Close Open

Obstruction

Sensor

min.MAX

Overlap Delay

1.5

0

3

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Hold Open

Timer

Stop

CloseOpen

LimitLimit

30sec

60secoff

1

sec

Center

Loop

Brake

UL

Siren

Obstruction

Sensor

min. MAX

Overlap

Delay

1.5

0

3

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Center

Loop

Brake

Siren

Intelligent Obstruction Sensor

Trim Pot Location

The Obstruction Sensor detects obstructions

Pot for the Obstruction Sensor adjusts the
sensitivity level that triggers the Sensor.

When the Obstruction Sensor detects an
obstruction it will:

in the path of the traveling gate. The Trim

(Primary Entrapment Protection)

Turning the Trim Pot clockwise
increases the sensitivity.

Turning the Trim Pot counter­clockwise decreases the sensitivity

.

1. Stop the gate’s movement and reverse it
momentarily.

2. Bring the gate to a resting position.

Disable the Hold Open Timer feature until the

3.
Gate Operator receives a new command.

If another obstruction is detected before the
gate reaches either limit it will:

1. Stop the gate’s movement.

2. Bring the gate to a resting position.

3. Disable the Gate Operator.

UL325 standard requires an audio alarm to
go off after two consecutive entrapment
events
Protection of the Gate Operator.

The audio alarm will sound for a period of 5
minutes or until the “Stop” Button is
pressed (see page 8 for remote installation
of a “Stop” Button).

sensed by the Inherent Entrapment

28 28

TECHNICAL SUPPORT 1 800 908 0884

SPECIAL FEATURESSPECIAL FEATURES

1

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Brake

UL

Siren

Hold Open

Timer

Stop

Close Open

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Hold Open

Timer

Stop

CloseOpen

LimitLimit

30sec

60secoff

1sec

Brake

UL

Siren

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Brake

Siren

Remove
Clutch Key

Fail Safe/Fail Secure Operation

The gate operator contains a unique design that allows the user to move the gate
manually in case of power failure.

Fail Safe:

If the operator has been installed with an
Elbow Arm, the Clutch Key can be removed
and the gate can me moved manually with a
relative low amount of force.

Fail Secure:

This unit is shipped with the default fail
secure feature.

Connection Locations

Hold Open Timer

The Hold Open Timer function holds the gate at
the open position for a predetermined amount
of time, prior to closing automatically.
Set the Timer to the desired time, from 1 to
60 seconds.

If this feature is not needed, turn the Trim
Pot clockwise to the “off” position.

Note: The Hold Open Timer affects the “radio
receiver command” and the sequence of

TECHNICAL SUPPORT 1 800 908 0884

operation for the gate (see page 24).

1

29

SPECIAL FEATURESSPECIAL FEATURES

Inside

Outside

Opens First

Slave UnitMaster Unit

Interconnecting 
Conduit

Brake

UL

Siren

Obstruction

Sensor

Hold Open

Stop

Overlap Delay

Close Open

min.MAX

Overlap Delay

1.5

0

3

Master/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Stop

CloseOpen

LimitLimit

Brake

UL

Siren

Obstruction

Sensor

min. MAX

Overlap

Delay

1.5

0

3

Hold Open

Timer

Stop

Close

Open

Brake

Siren

Gate Overlap Setting

Setting the Overlap Delay Pot to “0” will cause the master and the slave units to
open and close at the same time

Trim P

ot Location

Setting the Overlap Delay Pot to any value
other than zero will cause the master unit to
delay in opening.

The time delay can be set for up to 3 seconds.

The Master Board sets the overlap delay for
the system.

The Slave Board must have its overlap delay set
to zero. This setting prevents conflict of commands
between master and slave control boards.

30

TECHNICAL SUPPORT 1 800 908 0884

BATTERY & EMI BOARD LOCATIONBATTERY & EMI BOARD LOCATION

The Batteries are Located

Behind the Panel Door

The EMI Board is Located

Behind the Panel Door

TECHNICAL SUPPORT 1 800 908 0884

31

OPTIONALSOLAR PANEL INSTALLATIONOPTIONAL SOLAR PANEL INSTALLATION

Radio Station

Mag.

Lock

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Brake

UL

Siren

Radio

Rec.

UL

Sensor

OP EN RIGHT

24V BAT 24 VAC

OP EN LEFT

Safety

Loop

Center

Loop

Obstruction

S

ensor

C

harger

P

ower

L

ow Battery

M

otor Sensor

Hold Open

Timer

Stop

Overlap Delay

Close Open

Obstruction

Sensor

min. MAX

Overlap

Delay

1.5

0

3

Radio StationLoop ConnectorOpen CommandsGuard StationMaster/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag.

Lock

F

ail

Safe/Secure

MAG. LOCK

N.C.

COM

N.O.

C

harger

P

ower

L

ow Battery

C

heck Motor

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Radio

Rec.

UL

Sens

Reopen

Loop

Center

Loop

Brake

Siren

J

P3

C

35 C36

+

–+ –+ –

+

–

+

–

S

olar Input Battery Input Load Input

For Viking Vehicular Gate Operators

Connect the Solar Panel
Controller as shown.

Use one 24V 80W
solar panel or two
12V 40W solar panels.

Remove the existing
Power Harness and
use the power
harness provided.

Remove existing batteries. Use new
external batteries of 35 AHr or
greater and connect them in series to
provide a 24V system.

32

TECHNICAL SUPPORT 1 800 908 0884

OPTIONALSOLAR PANEL INSTALLATIONOPTIONAL SOLAR PANEL INSTALLATION

Radio Station

Mag.

Lock

Mag. Lock

Safety ConnectorOpen CommandsGuard StationMaster/Slave

Brake

UL

Siren

R

adio

Rec.

U

L

Sensor

OP EN RIGHT

24V BAT 24 VAC

OP EN LEFT

S

afety

Loop

C

enter

Loop

O

bstruction

S

ensor

Charger

Power

Low Battery

Motor Sensor

Hold Open

Timer

Stop

O

verlap Delay

Close Open

Obstruction

Sensor

min. MAX

Overlap

Delay

1.5

0

3

Radio StationLoop ConnectorOpen CommandsGuard StationMaster/Slave

GND

Close

Stop

Open

GND

Close

Stop

Open

Gnd

Fire

Gnd

Strike

Gnd

Exit

Gnd

Center

Gnd

Reopen

Gnd

UL

Gnd

+28v

Gnd

Radio

Gnd

+28v

+28v

Mag.

Lock

Fail

Safe/Secure

MAG. LOCK

N.C.

COM

N.O.

Charger

Power

Low Battery

Check Motor

Hold Open

Timer

Stop

Close

Open

30

60

Off

1

Radio

Rec.

UL

Sens

Reopen

Loop

Center

Loop

Brake

Siren

JP3

C35 C36

Connect Leads from
Solar Panel(s), Polarity 
is not important

Cut the Leads

to the Toroidal

Transformer

+

–

+

+
–

–

Reuse Existing
Battery Fuse Holder

Connect New
Batteries to
Existing Leads
Observing Polarity

Red Wire

Black Wire

+
–

+
–

Connect To Gate

Operator Input Block

24 VDC

Panel

12 VDC

P

anels

2

*With a 80 Watt (24VDC) Panel System.

5

8

10

12

14

Number of

Cycles per Day*

January July

For Viking Vehicular Gate Operators

WWAARRNNIINNGG––SSoollaarr PPaanneell mmuusstt bbee UULLLLiisstteedd,, CCllaassss 2

STEP 1

Use a 24V solar panel or two solar panels of 12V
in series with a total capacity of 80 Watts..

STEP 2

Connect the solar panel cables to the power
harness as shown. Mak

e sure you cut the wires

coming from the toroidal transformer.

STEP 3

Replace the existing batteries with a battery pack
of 35AHr or greater.

STEP 4

Refer to the maps provided to get an idea about the
number of cycles the gate will be operated per day.
This figure is for a single gate operator with just:

a) One Radio reiver,
b) One low voltage low current loop detector and
c) One low voltage, low current photo cell

2

1.

The greater capacity of the batteries, the longer the system will operate on cloudy days.

2. If more specific information is needed, please consult with Viking Access Systems.
For more information regarding solar energy refer to http:/www.nrel.gov.

TECHNICAL SUPPORT 1 800 908 0884

33

OPTIONAL VIKING BLUE INSTALLATIONOPTIONAL VIKING BLUE INSTALLATION

OPEN RIGHT

24V BAT 24VAC

OPEN LEFT

Charger

Charger

Power

Low Battery

Check Motor

Rec.

Radio Station

Op

en Comma

nds

Guard Stat

ion

Master/Slave

Obst

ruct

ion

Sensor

.

m

in

.

.

MA

X

Overlap

Delay

1.5

0

3

3

Radio Station

Loop Connec

t

or

Op

en Comma

nds

Guard Stat

ion

Master/Slave

GN

D

Clo

se

Sto

p

Op

en

GN

D

Clo

se

Sto

p

Op

en

Gn

d

Fire

Gn

d

Strike

Gn

d

E

xit

Gn

d

Cen

ter

Gn

d

R

eo

p

en

Gn

d

UL

Gn

d

+2

8

v

Gn

d

R

a

d

io

Gn

d

+2

8

v

+2

8

v

MAG. LOCK

COM

N.O

.

Hold Open

T

imer

Stop

Stop

Close

Open

Open

30

60

O

ff

1

Reopen

Cent

er

Loop

B

ra

k

e

Si

ren

JP3

C35

C36

JP2

Match upMatch up

White DotsWhite Dots

Match up

White Dots

InstallInstall

JumperJumper

Install

Jumper

JP3JP3JP3

JP2JP2JP2

1. Insert CD into host computer

2. Install MS ActiveSync (check your

computer, it may already be installed to

communicate with a PDA or smart phone.

3. Install Viking Blue software
Select Install Viking-Blue for PC (to have the
computer to communicate with the Operator)

Select Install Viking-Blue for PDA (to have

the PDA to communicate with the Operator)

WARNING: If this PDA is a new device, turn off

all options when syncing with the computer.
For either installation, follow the steps in the

user manual.

4. Plug the Viking Blue Module into the Viking
Gate Operator Control Board.

WARNING: Connecting the plug backwards can

result in damage to the Control Board and
will render the Viking Blue Module useless.

Use care in connecting the plug to the Control
Board. The pins are small and easily bent.
Match the white dot on the plug to the white
dot on the control board (near the JP2 legend
as depicted).

5. Install the Jumper (near the JP3 legend

If you are using the computer:

• Hold the computer near the Gate

• Run the application by clicking the

• Select “Setting” in the top right of the

If you are using a PDA:

• Hold the PDA near the Gate Operator.

• Select “Start” and “Programs”

• Click the Viking-Blue Application.

• Select “Connection” on the toolbar.

34 31

Operator.

icon on the desktop.

screen.

.

depicted). Viking-Blue requires this jumper
to operate. The “Low Battery” LED will turn
ON, indicating the Control Board is ready for
use with the Viking-Blue Module.

6. Open Viking Blue software on the chosen
device.

• Click “Search” (looking for available
Viking devices).

• Select the Operator you want to
communicate with.

• Click “Connect” to start communication.
The Light on the Viking-Blue module

will turn green upon connection to the
Computer or PDA.

Follow the steps in the user manual.

TECHNICAL SUPPORT 1 800 908 0884

TROUBLESHOOTINGTROUBLESHOOTING

Gate does not run – Motor Sensor indicator comes ON

Check all motor connections to
be fully engaged. Refer to page

15.

Check the 15 Amp fuse in the
control board.

Check that the reset switch is
set in the “Reset’ position.

Gate does not run – Motor Sensor indicator is OFF

Check all motor connections to
be fully engaged. Refer to 15.

Check that the UL command
(photo beam and/or edge
sensor) is not active. Refer to
page 6, 7 and 23.

Ensure that you external acces­sories are working properly.

Check that limit switches are
connected to the common and
the normally close position
refer to page 17.

Check that the vehicular loop
detectors are working properly.
Refer to page 20, 21 and 3.

Check the 4 Amps fuse in the
control board.

Check that the stop command
is not active. Refer to page 8
and 26.

Check that the radio command
is not active. Refer to page 24.

Ensure that you power cables are
adequate in voltage and properly
connected. Refer to page 15.

Gate does not run – Power failure

Check the 15 Amp battery fuse.
Refer to page 18.

Check the battery connections and
cables. Refer to page 14 and 18.

Check the voltage of the
battery.

Gate does not run – Obstruction sensor ON and audio alarm is SOUNDING

tEnsure that the gate path is
clear of obstructions.

Note: To stop the audio alarm,
use the stop command. Refer
to page 8 and 26.

Adjust the trim pot of the
obstruction sensor. Refer to
page 28.

Gate runs, stops and reverse momentarily – Obstruction sensor ON and audio alarm OFF

Ensure that the gate path is
clear of obstructions.

Check for proper functionality
and lubrication of the gate and
hardware (hinges and the lik

Adjust the trim pot of the
obstruction sensor

e).

page 28.

. Refer to

Gate ignores the limit switches

Check that the open limit
switch and close limit switch
are in the corresponding place.
Refer to page 16.

Check that the limit switch is
not faulty.

TECHNICAL SUPPORT 1 800 908 0884TECHNICAL SUPPORT 1 800 908 0884 Se habla Español

Check that all motor cable
connections, junctions and
extensions are properly
connected and color-coded.

Refer to 15.

Check that wires to the limit
switch are not shorted.

Ensure that the motor cable is
away from sources of electrical
interference, such as

a) Electric motors
b) Electric fences
c) Power lines.

Note: To minimize effects
cause by electrical interference
use twisted pairs of cables with
the shield grounded.

3528

TROUBLESHOOTINGTROUBLESHOOTING

Gate does not open or close

Check all motor connections to be
fully engaged. Refer to page 15.

Check that the UL command
(photo beam and/or edge
sensor) is not active. Refer to
page 6, 7 and 23.

Ensure that you external
accessories are working
properly.

Check that limit switches are
connected to the common and
the normally close position.
Refer to page 17.

Check that the vehicular loop
detectors are working properly.
Refer to page 20, 21 and 23.

Automatic close does not function

Check that the trim pot of the
hold open timer is set to the
proper time delay. Refer to
page 29.

Note: Hold open timer closes
the gate automatically once the
gate reaches the limit open.

The time delay to close is set
by the trim pot.

To turn this system off turn the
trim pot all the way clockwise.

Gate opens in the opposite desired direction

Check that the stop command
is not active. Refer to page 8
and 26.

Check that the radio command
is not active. Refer to page 24.

Verify your motor cable is
connected to the proper
connector. Refer to page 15.

“Open” and “Close” LEDs blinking

Check all the limit switch
connections. Check that both
limit switches are not being
actuated at the same time.
Refer to page 17.

Check that both limit switches
are not disconnected. Refer to
page 17.

On a Master/Slave installation, one gate runs in the opposite direction

erify that one unit is

Check the motor and limit
switch wiring. Refer to pages
15 and16.

V
connected as open-left and one
unit is connected as open­right. Refer to page 15.

2636 29

TECHNICAL SUPPORT 1 800 908 0884

TROUBLESHOOTINGTROUBLESHOOTING

Gate opens after few second delay

Set the overlap delay trim pot
to 0. Refer to page 30.

Note: Overlap trim pot is
normally recommended to use
in overlapping gates. Refer to
page 30.

Gate opens. Closes or stops on its own

Ensure that the key for manual
release is in the lock position.
Refer to page 7.

Make sure that the ‘Charger’
LED is on, indicating that there
is AC power.

Check that your wires from
your accessories are:

a) Not shorting together
b) Not shorting a power line
c) Not shorting to metal or

earth ground.

F-1 unit runs slower than normal

Set the overlap delay trim pot
to 0. Refer to page 30.

Note: Overlap trim pot is
normally recommended to use
in overlapping gates. Refer to
page 30.

‘Charger’ LED off. Gate does not run - alarm sounds upon any input command

Check the 4 Amp fuse on the
control board.

Check the 3 Amp fuse on the
EMI board. Refer to page 14.

Make sure the incoming AC
line is properly connected.
Refer to page 14.

Check the incoming high
voltage power supply.

Check the proper selection of
power supply (120/220 VAC).
Refer to page 14.

Verify the EMI board by
reading high voltage across the
(4) blue and red wires at the
terminal block connections.

Battery voltage reads zero or very low

Ensure the batteries are connected as follows:
a) Left battery - Black terminal connected to the black wire from the harness (jacketed wire)
b) Left battery - Red terminal connected to the red wire from fuse holder
c) Right battery - Black terminal connected to the red wire from fuse holder
d) Right battery - Red terminal connected to the red wire from the harness (jack

eted wire)

TECHNICAL SUPPORT 1 800 908 0884

37

Notes

our continuous commitment to excellence

Viking Access Systems is continuously working hard to identify and design products

that will appeal to the industry and it’s needs. As technology continues to advance, we

have developed a completely efcient and intelligent line of gate operators to meet the

changing demands. These machines offer; full UL325 and UL991 compliance, soft-start

and soft-stop, intelligent obstruction sensors, continuous operation (100% duty cycle)

and extreme power efciency. Innovative features include; adaptive and self-learning

algorithms, redundancy design in both hardware and software to ensure operation and

functionality, protection from lightning, short circuit and power surges, and our exclusive

helical gearing offering the highest efciency rating in the industry. Our entire product

line is continually modied and improved based on the latest technology and our

customer’s valuable feedback. The results are products that offer accuracy, efciency,

reliability and performance, all in sleek, high-tech designs.

We pledge to continue establishing ourself as the leader in high quality, innovative gate

operators by developing “Next Level” technology. We are committed to providing safety

and convenience with innovative solutions for every security gate need.

VIKING

standard features

and operator specications

Accessible manual releases • Fail-Safe option sets the gate to automatically transfer

to a fail-safe mode in the event of a power failure, allowing the gate to be pushed

open without the use of special knowledge of the equipment • Fail-Secure option

sets the gate to mechanically lock in the event of a power failure, allowing no manual

movement without the use of the manual release • Standard Auto Open feature •

Elegant design, appealing to any architectural project • Plated and powder coated

1/4" steel chassis • Opening up to 120° • Operation speed of 13 to 16 seconds per 90°

• 100% duty cycle under very wide temperature range • Very low power consumption

• 300 cycles of operation on backup battery (600 lb. gate and 12' length) • Intelligent

speed control with smooth start and stop, self-adjust system • Modulated speed

regulator prevents exceeding operating speed that may reduce the service life of the

gate operator and/or installation • Intelligent obstruction detection with adjustable

sensitivity • Overlap delay that holds one gate momentarily by an adjustable time

while the other gate is operating (Master/Slave installation with overlap gates) • Built-

in protection against lightning strikes or similar electrical surges • Inherent overload

protection in the regulated power supply for external accessories with multiple

devices of protection • Modular connectors for easy installation •

Solar panel and low voltage wiring compatibility • LED

indicators for verication of operation

Viking Access Systems
Phone [phone] Fax [phone]
631 Wald Irvine, CA 92618

www.vikingaccess.com
