The originator of professional performance for your home
brings you a taste of Italy you can enjoy every day.
Florence, Italy is known for outstanding food, delicious wine, impeccable design, and attention to detail. Combining Italian
design with Viking Professional performance, the Tuscany range was born in the heart of Italy. ese sophisticated new
Italian Provincial ranges are sized and featured to meet the needs of American architecture and lifestyles. Incorporating the
highest quality materials and unsurpassed reliability Viking is known for, Viking Tuscany is oered in multiple configurations
and options to meet the most discriminating tastes.
TUSCANY RANGE - 66” WIDE
ree dierent top configurations
– TVDR6608B – 8 gas burners
– TVDR6606G – 6 gas burners; electric griddle
– TVDR6606I – 6 gas burners; 2 induction elements
COOKING FEATURES
High performance burners provide fast boil times and a gentle simmer
– 20,000 BTU – 8,500 BTU high burner ratings
Stainless steel burner pan
Electronic single point, spark ignition/re-ignition on all burners
Porcelain coated cast iron burner grates
Optional surface configurations
– Machined steel griddle/simmer plate (with grease collection drawer)
– Induction elements
3.8 cu ft. electric oven (both ovens)
– 25 3/4”W. x 13”H. x 19 5/8” D.
– Stainless steel oven cavity
– Six rack positions with two oven racks including one TruGlide™ Rack
– Eight cooking functions – Bake, Convection Bake, Tru Convection,
Low Broil, High Broil, Convection Broil, Defrost, Proof
– Two oven lights
Storage drawer for baking pans with soft-close glides
Polished chrome die cast knobs
TUSCANY RANGE
13,650
BTU
20,500
BTU
13,650
BTU
20,500
BTU
TVDR6608B
8500
BTU
20,500
BTU
13,650
BTU
20,500
BTU
13,650
BTU
20,500
BTU
10,250
BTU
8500
BTU
20,500
BTU
13,650
BTU
20,500
BTU
TVDR6606G
13,650
BTU
20,500
BTU
13,650
BTU
20,500
BTU
8500
BTU
20,500
BTU
TVDR6606I
TUSCANY RANGES - 48” WIDE
ree dierent top configurations
– TVDR4806B – 6 gas burners
– TVDR4804G – 4 gas burners; electric griddle
– TVDR4804I – 4 gas burners; 2 induction elements
COOKING FE AT U R E S
High performance burners provide fast boil times and a gentle simmer
– 20,000 BTU – 8,500 BTU high burner ratings
Stainless steel burner pan
Electronic single point, spark ignition/re-ignition on all burners
Porcelain coated cast iron burner grates
Optional surface configurations
– Machined steel griddle/simmer plate (with grease collection drawer)
– Induction elements
3.8 cu ft. electric oven (left oven)
– 25 3/4”W. x 13”H. x 19 5/8” D.
– Stainless steel oven cavity
– Six rack positions with two oven racks including one TruGlide™ Rack
– Eight cooking functions – Bake, Convection Bake, Tru Convection,
Low Broil, High Broil, Convection Broil, Defrost, Proof
– Two oven lights
2.4 cu ft. oven (right oven)
– 11 5/8”W. x 18 1/4”H. x 19 5/8”D.
– Convection bake
– Side swing oven door
– One oven rack
Storage drawer for baking pans with soft-close glides
Polished chrome die cast knobs
8500
BTU
20,500
BTU
TVDR4806B
TOP CONFIGURATIONS
13,650
BTU
20,500
BTU
13,650
BTU
20,500
BTU
8500
BTU
20,500
BTU
10,250
BTU
TVDR4804G
13,650
BTU
20,500
BTU
8500
BTU
20,500
BTU
13,650
BTU
20,500
BTU
TVDR4804I
8500
BTU
20,500
BTU
TVDR3604B
13,650
BTU
20,500
BTU
TUSCANY RANGE - 36” WIDE
Top configuration
– TVDR3604B – 4 gas burners
COOKING FEATURES
High performance burners provide fast boil times and a gentle simmer
– 20,000 BTU – 8,500 BTU high burner ratings
Stainless steel burner pan
Electronic single point, spark ignition/re-ignition on all burners
Porcelain coated cast iron burner grates
3.8 cu ft. electric oven
– 25 3/4”W. x 13”H. x 19 5/8” D.
– Stainless steel oven cavity
– Six rack positions with two oven racks including one TruGlide™ Rack
– Eight cooking functions – Bake, Convection Bake, Tru Convection,
Low Broil, High Broil, Convection Broil, Defrost, Proof
– Two oven lights
Full width storage drawer for baking pans with soft-close glides
Polished chrome die cast knobs
TUSCANY WALL HOODS - 18”H. / 24”D.
– TVWH360 - 36”W.
– TVWH480 - 48”W.
– TVWH660 - 66”W.
Canopy only; must also purchase interior or exterior ventilator kit, sold separately
Backlit LED knobs extend and illuminate to control lighting level and ventilation
speed
Dimmable LED lighting is energy ecient and easily replaceable
Heat lamps standard (250 watt heat lamp bulb not included)
Dishwasher-safe commercial-type SS bae filters with handles
Separate removable grease trough for easy cleaning
Heat sensor automatically turns ventilator on full power when temperatures
reach uncomfortable levels
Virtually seamless stainless steel canopy interior for easy cleaning
TUSCANY DUCT COVERS FOR WALL HOODS
– TDCW36 - 36”W.
– TDCW48 - 48”W.
– TDCW66 - 66”W.
For use with all TVWH models
Extends height of hood 12”H. to conceal duct; 12”D.
TUSCANY DISHWASHER DOOR PANEL KIT
– TVDD P524 - 24”W.
For use with all FDWU model dishwashers (sold separately)
WARRANTY HIGHLIGHTS
Viking Signature Warranty
– Two-year full – complete product
– Ninety-day full – cosmetic parts
such as glass, painted items,
decorative items
and
COLOR FINISHES FOR RANGES,
HOODS, AND DISHWASHER PANEL
Dark Blue (DB), Antique White (AW),
Graphite Black (GB)
TRIM FINISH
Polished Chrome
TUSCANY DUAL FUEL RANGES
Description 36” W. 48” W. 66” W.
Overall width
Overall height from bottom
To top of side trim
Leg adjustment
Overall depth from rear
To end of side panel
To front of door
To end of towel bar
To end of door handle
Additions to Base Height
To top of island trim
Gas requirements
Electrical requirements
Maximum amp usage
Surface ratings
Oven interior width
Oven interior height
Oven interior depth
Oven volume
Overall AHAM
Approximate shipping weight
240V - 18.5 amps / 208V - 15.8 amps 240V - 28.5 amps / 208V - 24.4 amps 240V - 31.1 amps / 208V - 26.6 amps
35-7/8” (91.1 cm) 47-7/8” (121.6 cm) 66-1/8” (168.0 cm)
35-7/8” (91.1 cm) min to 36-5/8 (93.0 cm) max
3/4” (1.9 cm)
26-3/4” (67.9 cm)
26-3/4” (67.9 cm)
30-3/8” (77.2 cm)
28-7/8” (35.2 cm)
add 4” (10.2 cm)
Shipped Natural Gas, accepts standard residential 1/2” (1.3 cm) ID gas service line.
Natural 5.0” W.C.P./ Liquid Propane L/P 10.0” W.C.P. Unit is field convertible with conversion kit.
40 amp 50 amp 50 amp
See install guide for more information
See illustrations
25-3/4” (65.4 cm) LH 25-3/4” (65.4 cm) RH 11-5/8”
Both ovens: 25-3/4” (65.4 cm)
(29.5 cm)
13” (33.0 cm) LH 13” (33.0 cm) RH 18-1/4’
Both ovens: 13” (33.0 cm)
(46.4 cm)
19-5/8” (49.8 cm) LH 19-5/8” (49.8 cm) RH 19-5/8”
Both ovens: 19-5/8” (49.8 cm)
(49.8 cm)
3.8 cu. ft. LH 3.8 cu. ft. RH 2.4 cu. ft. Both ovens: 3.8 cu. ft.
300 - 340 lbs (135 - 153 kg) 470 - 510 lbs (212 - 230 kg) 640 - 695 lbs (289 - 314 kg)
66” W.
35 1/16” (89.1 cm)
to
37 1/16” (134.6 cm)
depending on leg
adjustment
2 1/4”
(5.7 cm)
47 5/8”
(121.0 cm)
43 3/8”
(110.2 cm)
2 1/4”
(5.7 cm)
35 1/16” (89.1 cm)
to
37 1/16” (134.6 cm)
depending on leg
adjustment
2 1/8”
(5.4 cm)
13 1/4”
(33.7 cm)
30 3/8”
(77.2 cm)
35 7/8”
(91.1 cm)
31 9/16”
(80.2 cm)
27 1/2”
(69.9 cm)
18 1/4”
(46.4 cm)
26 3/4”
(67.9 cm)
2 1/8”
(5.4 cm)
38 5/8” (98.1 cm)
39 3/4” (100.9 cm)
depending on leg
adjustment
35 15/16”
(91.3 cm)
SIDE VIEW
36” W.48”W.
to
CLEARANCE DIMENSIONS
Range Width Cutout Width
35-7/8” (91.1 cm) 36”W. (92 cm)
47-7/8” (121.6 cm) 48”W. (122 cm)
66” (167.6 cm) 66-1/8”W. (168 cm)
36”
(91.4 cm)
6” min
(15.2 cm)
36” min
(91.4 cm)
13” max
(33.0 cm)
18” min
(91.4 cm)
3/8” (0.95 cm)
WALL INSTALLATION
66” min (167.6 cm) to
72” max (182.9cm)
36”
(91.4 cm)
12” (30.5 cm)
*optional duct cover
18” (45.7 cm)
30” min (76.2 cm)
to 36” max (91.4 cm)
6”
(15. 2 c m)
24”
(61.0 cm)
18”
(45.7 cm)
A
A
36”W. 35-7/8” (91.1 cm)
48”W. 47-7/8” (121.6 cm)
12”
(30.5 cm)
TUSCANY 18”H. HOODS
Description 36” W. 48” W. 66” W.
Duct cover width
35-7/8” (91.1cm) 47-7/8”
(121.6 cm)
Duct cover depth
Duct cover height
Number of lights
Number of filters
Heat lamps
Interior ventilator kits
Exterior ventilator kits
In-line ventilator kits
Interior duct size
2 3
2 3
1 2
VINV300/600/1200 VINV1200
DEV900/1200* DEV1200*/1500**
7”/10”
12” (30.5 cm)
12” (30.5 cm)
DIL1200
10” (25.4 cm)
(17.8/25.4 cm)
Exterior duct size
Interior—Max amps
Exterior—Max amps
In-Line—Max amps
4.2/5.2/8.2 10.8
8.0/5.3 7.8/8.5
5.3/7.2 9.6
10” (24.5 cm)
It is recommended that the 1,500 CFM ventilator be used with longer duct runs. Ma x duct run is 75 ft.
NOTE: Maximum amp rating for hoods includes recommended ventilator kit rating; All products must be hard wired with 2-wire
with ground. An interior- or exterior-power ventilator kit must be purchased for installation with all 18” H. hoods.
65-7/8”
(167.3 cm)
36”W.
48”W.
66”W.
A
35 7/8” (91.1 cm)
47 7/8” (121.6 cm)
65 7/8” (167.3 cm)
DISHWASHER
Description FDWU Dishwashers
Overall Width
Overall Height
from Floor
Overall Depth
Cutout Width
Cutout Height
Cutout Depth
Electrical
Requirements
Water-Heating
Element Rating
Inlet Water
Temperature
Drain Hose
Drain Hose High
Loop Required
Approximate
Shipping Weight
23-9/16” (59.8 cm)
33-7/8” (86.0 cm) minimum to
35 7/8” (91.1 cm) maximum
To front of door panel: 22 3/16”
(56.4 cm)
24” (61.0 cm)
34” (86.4 cm) minimum to 36”
(91.4 cm) maximum
24” (61.0 cm
12.0 amps, 115V/60Hz; 4”
(120cm) electrical cord with
3-prong plug supplied with unit
1240 watts
120ºF (49ºC) required
6.4’ (1.9m) drain hose provided
Height from floor – 28” (71.0 cm)
97 lb. (44 kg)
33 -7/8”– 3 5-7/8 ” max
(86.0 cm–91.1 cm)
23-9/16” max
(59.8 cm max)
34”– 36-1/4” max
(86.4 cm–92.1 cm)
24” max
(61.0 cm max)
24” max
(61.0 cm max)
24” max
(61.0 cm max)
Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA For product information, call 1∙888∙ 845∙ 4641 or visit vikingrange.com.
F80150G 0619
© 2019 VIKING RANGE, LLC. ALL RIGHTS RESERVED.
