Viking P24CSTSS Installation manual

Viking Installation Guide

Viking Range Corporation

111 Front Street

Greenwood, Mississippi 38930 USA

[phone]

For product information,

call 1-888-VIKING1 (845-4641)

or visit the Viking Web site at

vikingrange.com

F1226D EN (031209J)

Countertop Side Trim

Installation

Grate support side trim
(standard with product)

Heat shield
(not on all products)

Countertop side trim
(optional accessory)

Heat shield
(not on all products)

Installation

For Models:

R24CSTSS - 24” D. VGIC Ranges
R27CSTSS - 27” D. VGRC Ranges
S24CSTSS - 24” D. VGSC Open Burner Self-Clean Ranges
T24CSTSS - 24” D. VGRT Open Burner Rangetops/VGWT Wok

1. Remove the outside grates and grate
supports next to the counter.

2. Locate and remove the screws holding
the grate support side trim in place.
Keep the screws for reuse.

3. Lift the grate support side trim out. It
will not be reinstalled.

4. Locate and remove the screws holding
the heat shield in place. Keep the
screws for reuse.

5. Lift the heat shield out and set aside for
reuse.

For Models:

RE24CSTSS - 24” D. VGIC/VDSC Sealed Burner Ranges/VESC Ranges
SE24CSTSS - 24” D. VGSC Sealed Burner Self-Clean Ranges
TE24CSTSS - 24” D. VGRT Sealed Burner Rangetops/VERT Rangetop/

24” W. VGGT Griddle/24” W. VGQT Grill
DGRT, DERT Designer Rangetops

P24CSTSS - 24” D. VGCC/VGSC/VDSC/VESC/VISC and Custom Ranges

and Rangetops

Place the countertop side trim template against the side of the range or rangetop.
The flange of the template should be wrapped around the back of the unit. The top of
the template should be even with the top edge of the outer trim. Mark the holes and
remove template. Using a 9/64” drill bit, drill the three designated holes into the side
of the range or rangetop. Place the countertop side trim into place and secure with
the provided screws.

6. Place the countertop side trim into
place. Align with the countertop and
the landing ledge. Replace and secure
with the original screws.

7. Replace the heat shield and align the
slotted screw holes with the screw holes
in the side trim. Replace and secure
with the original screws.

C A U T I O N

The heat shield must be replaced only if it
is part of the original product.

8. This countertop side trim was designed
to accommodate most installations. If

the trim needs to be shorter, cut at
the rear to fit.
