Standard Features & Accessories
Both ovens include
• Capacity—1.1 cu. ft. (31.2 lit.)
o 29-15/16”W. x 15-1/2”H. x
15-5/16”D.
o 13” (33.0 cm) diameter turntable
• Commercial-type styling and design
• Instant sensor settings for cooking,
reheating, and popcorn
• Four convection settings use highspeed fan that circulates air past the
heat source and around the food;
allows multiple-rack baking
o ConvecBroil
o ConvecRoast
o ConvecBake
o Manual convection
• Low Mix Bake and High Mix Roast settings offer use of convection heat to
seal and brown outside of foods while
using microwave energy to ensure the
interior is cooked
• Add-A-Minute allows you to add a
minute of extra cooking time with the
touch of one button
• Child Lock safety feature locks the
control panel to prevent unwanted
operation
• Interior light
• Cookbook included
• Built-in exhaust system
o 300 CFM blower
Model Options
COOKING
Professional & Designer Convection
Microwave Hood
o Shipped assembled to recirculate;
may also be converted to vent out
the rear or vertically
• Suitable for use over 24”W. and 30”W.
Viking surface cooking products (nongrill)
FINISH DETAILS FOR BOTH MODELS
• Stainless Steel (SS)
VMOR205
Professional
Microwave Hood
DMOR205
Designer
Microwave Hood
ORDERING INSTRUCTIONS
First specify model number, and then color code (VMOR205SS).
P L A N N I N G A N D DE S I G N GU I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 4 / 2 8 / 1 1
© 2 0 1 1 V R C — I N F O R M A T I O N S U B J E C T T O C H A N G E
COOKING
15
-
5
/1
6
”
(3
8
.
9
cm)
2
9-
1
5
/
1
6”
(65
.9
cm)
1
5-
1
/2”
(39
.4
cm)
1
5
-
5
/
1
6”
(3
8
.9
c
m
)
29-1
5
/
16”
(65
.9
cm)
15
-1
/2”
(3
9
.
4
cm)
Professional & Designer Convection
Microwave Hood
Please see
✪
Installation Notes
and Accessories for
important information,
including filters.
Dimensions & Specifications
PRODUCT DIMENSIONS
VMOR205
Professional
Microwave Hood
DMOR205
Designer
Microwave Hood
PROFESSIONAL DESIGNER
Overall width 29-15/16” (65.9 cm)
Overall height (from bottom) 15-1/2” (39.4 cm)
Overall depth (from rear) 15-5/16” (38.9 cm)
Approx. ship weight 85 lbs. (38.6 kg)
P L A N N I N G A N D DE S I G N GU I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
All Models
R E V I S E D 4 / 2 8 / 1 1
© 2 0 1 1 V R C — I N F O R M A T I O N S U B J E C T T O C H A N G E
30”
(76.2 cm)
2”
(5.1 cm) min.
36” min.
(91.4 cm) or more
from cooking
surface
15.5”
(39.4 cm)
12”
(30.5 cm)
12”
(30.5 cm)
72”
(182.9 cm) min.
72”
(182.9 cm) min.
Dimensions & Specifications
CLEARANCE DIMENSIONS
COOKING
Professional & Designer Convection
Microwave Hood
VMOR205
Professional
Microwave Hood
DMOR205
Designer
Microwave Hood
P L A N N I N G A N D DE S I G N GU I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 4 / 2 8 / 1 1
© 2 0 1 1 V R C — I N F O R M A T I O N S U B J E C T T O C H A N G E
30”
(76.2 cm)
Ground
receptacle
Opening for
power cord
15-1/2”
(39.4 cm)
12”
(30.5 cm)
12”
(30.5 cm)
UTILIT Y
REQUI RE MENTS
GAS
Not applicable
•
ELECTRICAL
3.5-foot power cord
•
included
• 120 VAC/60 Hz
Maximum amp
•
sage—
u
13.2 (1.6 kW)
Professional & Designer Convection
Installation Requirements
ACCESS REQUIREMENTS
VMOR205
Professional
Microwave Hood
COOKING
Microwave Hood
DMOR205
Designer
Microwave Hood
PLUMBING
Not applicable
All models
Cutout width 30” (76.2 cm) min.
Cutout height 15-1/2” (39.4 cm) min.
Cutout depth 12” (30.5 cm) min.
P L A N N I N G A N D DE S I G N GU I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 4 / 2 8 / 1 1
© 2 0 1 1 V R C — I N F O R M A T I O N S U B J E C T T O C H A N G E
COOKING
Professional & Designer Convection
Microwave Hood
Installation Notes & Accessories
✪
Replacement Air Filter
• Recommended replacement every 6 – 12 months
Model Description Approx. ship wt. lbs. (kg)
CFOR1 Air filter for 30”W. microwave hood 2 lbs (.91)
Compliance Information
WARRANTY INFORMATION*
• Three-year full warranty—complete product (Professional Series)
• One-year full warranty—complete product (Designer Series)
• Five-year limited warranty—magnetron tube (Professional and Designer)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items (Professional and Designer)
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
P L A N N I N G A N D DE S I G N GU I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
© 2 0 1 1 V R C — I N F O R M A T I O N S U B J E C T T O C H A N G E
R E V I S E D 4 / 2 8 / 1 1
