ViewSonic VT2215LED, VS14829-1M User Manual
VT2215LED
LCD TV
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://www.
viewsonic.com in English, or in specific languages using the Regional selection box in
the upper right corner of our website. “Antes de operar su equipo lea cu idadosamente
las instrucciones en este manual”
Model No. VS14829-1M
ENGLISH
Contents
Compliance Information .............................................................................................. i
Declaration of RoHS Compliance .............................................................................. ii
Copyright Information .................................................................................................iii
Product Registration ...................................................................................................iii
Important Safety Instructions ..................................................................................... iv
Getting Started
Package Contents ........................................................................................................ 1
Installing the LCD TV ................................................................................................... 2
Installing the Stand ....................................................................................................2
Disconnecting the Stand ............................................................................................ 2
Mounting ViewSonic LCD TV to the wall ...................................................................3
Wall Mount Kit Specications (VESA) ........................................................................ 4
Front View of the Product ...........................................................................................5
Rear View of the Product ............................................................................................6
Connecting the LCD TV ............................................................................................... 7
Cable System or VHF/UHF Antenna System ............................................................7
Cable System and VHF/UHF Antenna System .........................................................7
HD Cable Box/HD Satellite Box ................................................................................. 7
Personal Computer .................................................................................................... 9
Using the TV Features
Remote Control and TV Controls ...............................................................................10
Inserting Remote Control Batteries ............................................................................ 10
Remote Control and TV Controls ............................................................................... 10
Operation
............................................................................................................13
Other Information
Troubleshooting ........................................................................................................... 26
Specications ..............................................................................................................28
Customer Support .......................................................................................................29
Limited Warranty .......................................................................................................... 30
Mexico Limited Warranty ............................................................................................31
ENGLISH
i
Compliance Information
FCC Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modications not expressly approved by the party responsible
for compliance could void your authority to operate the equipment.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment
Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste,
but use the return and collection systems according to local law.
If the batteries, accumulators and button cells included with this equipment, display the chemical
symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than
0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead.
ENERGY STAR Information:
To ensure your television is operating at optimal energy efciency, select [Home] mode during initial
activation.
To return to [Home] mode settings, select [Standard] picture mode. [Standard] mode is recommended for
normal home use.
Keeping the TV at its factory default settings that meet ENERGY STAR criteria.
Enabling certain features and functionality of LED TV will increase its energy consumption, possibly beyond
the limits required for ENERGY STAR qualication.
SRS Trademark Information:
• is a trademark of SRS Labs, Inc. TruSurround HD technology is incorporated under license
from SRS Labs, Inc.
SRS TruSurround HD™ creates an immersive, feature-rich surround sound experience from two speakers,
complete with rich bass, high frequency detail and clear dialog.
ENGLISH
ii
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European
Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic
equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the
European Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex of the RoHS Directives as
noted below:
Examples of exempted components are:
1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps not specically
mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and electronic ceramic parts
(e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up to
0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.
ENGLISH
iii
Copyright Information
Copyright © ViewSonic® Corporation, 2012. All rights reserved.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of
ViewSonic Corporation.
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA).
As an ENERGY STAR® partner, ViewSonic Corporation has determined that this product meets the ENERGY
S
TAR
®
guidelines for energy efciency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained
herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance
or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to change
product specications without notice. Information in this document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without
prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes available, please
register your product on the Internet at: www.viewsonic.com.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
VT2215LED
ViewSonic LED TV
VS14829-1M
VT2215LED-1M_UG_ENG Rev. 1A 06-01-12
_________________________________
_________________________________
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green. Thank you for being part
of Smarter, Greener Computing. Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx
ENGLISH
iv
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15. WARNING: To Reduce The Risk Of Fire Or Electric Shock,
Do Not Expose This Apparatus To Rain Or Moisture
16. Apparatus shall not be exposed to dripping or splashing
and no objests filled with liquids, such as vases, shall be
palced on the apparatus
17. The mains plug or appliance coupler shall remain readily opeable.
USE
AC power Cord
Keep the following guidelines to protect the AC power cord from
being damaged. If the AC power cord is damaged, it may result
in a fire or an electric shock. Stop using it and ask your dealer or
ViewSonic service center to exchange it.
• Do not place the TV where the power cord is subject to wear
or abuse.
• Do not pinch, bend, or twist the cord excessively.
• The core lines may be bared and cut, causing a short-circuit,
and resulting in a fire or an electric shock.
• Do not convert or damage the power cord.
• Avoid power cord being rolled over or rested
upon.
• When the power cord is plugged in, do not
move the TV.
• Keep the power cord away from heat sources.
• When you disconnect the AC power cord, disconnect it from
the wall outlet first.
• When disconnecting the power cord, grasp the plug instead of
pulling the power cord.
• Use only an original ViewSonic AC power cord, not other
brands.
• Do not use the supplied AC power cord on any other
equipment.
Wall outlet
Insert the plug fully into the outlet. If it is loose,
do not use it. Doing so may cause arcing and
result in a fire. Contact your electrician to change
the outlet.
Wiring
For your safety, be sure to unplug the AC power
cord when connecting cables.
Take care not to trip on the cables. It may cause damage to the
TV set.
Electric shock
Do not touch the AC power cord or the TV with a
wet hand. If you plug/unplug the AC power cord
from the TV with a wet hand, it may cause electric shock.
Lightning storms
During a lightning storm, unplug the TV from the wall outlet and
disconnect the antenna to prevent damage to the TV.
When not in use
If you will not be using the TV set for long periods of time, the
TV set should be disconnected from the AC power outlet to
prevent power line surges. The TV set is not disconnected from
the AC power source when the TV set is switched off.
To disconnect the TV set completely, unplug from the AC power
outlet.
Overloading
This TV set is designed to operate on a 120V AC supply only.
Dangerous Voltage:
The lightning flash with
arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of
dangerous voltage within the inside of the product
that may be sufficient level to constitute a risk of
electric shock to persons.
Instruction: The exclamation point within an
equilateral triangle is intended to alert the user to
the presence of important operating and servicing
instructions in the literature accompanying the
appliance.
ENGLISH
v
If there are too many appliances connected to the
same AC power outlet, it could result in a fire or
an electric shock.
Optional equipment
If optional equipment is to be installed, leave
some space between optional equipment and
the TV set. Picture distortion and/or noisy sound may occur if
the TV set is positioned in close proximity to any equipment
emitting electromagnetic radiation.
Small accessories
Keep small accessories in a safe place where children are unable
to reach.
Magnetic inuence
This TV contains a strong magnet in the speaker unit that
generates a magnetic field. Keep any items susceptible to
magnetic fields away from the speaker.
Sound
If you hear snapping or popping sound comes
from the TV continuously or frequently while the
TV is operating,
unplug the TV and consult your dealer or service
technician. It is normal for some TVs to make occasional
snapping or popping sounds, particularly when being turned on
or off.
Use in outdoor
This TV is not designed for outdoors
installation. Do not expose the TV to rain,
as it may result in a fire or an electric shock.
Also, do not expose the TV to direct sunlight,
as it may heat up and become damaged.
Vehicle, ships and other vessels
Do not install this TV in a vehicle.
Car accidents may cause the TV to fall down and
cause injury.
Do not install this TV in a ship or vessel.
If the TV is exposed to seawater, it may cause a
fire or damage the TV.
Medical institutions
Do not place this TV in a place where medical equipment is in
use. It may cause the medical equipment to malfunction.
Volume adjustment
• Adjust the volume to avoid disturbing your neighbors.
Sound carries easily at night. Therefore, we suggest you close
the windows or use headphones.
• When using headphones, adjust the volume to appropriate
levels, or hearing damage may result.
ANTENNAS
Outdoor antenna grounding
If an outdoor antenna is installed, follow the precautions below.
Do not install the outdoor antenna system near of overhead
power lines or other electric light or power circuits, or where it
can come in contact with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL.
Be sure the antenna system is grounded so that it can provide
some protection against voltage surges and built-up static
charges.
Section 810 of the National Electrical Code (NEC) in the U.S.A.
and Section 54 of the Canadian Electrical Code in Canada
provides information with in regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANS/NFPA 70
Antenna
Antenna discharge
unit
Grounding conductors
Power service grounding
electrode system
Ground clamps
Electric service
equipment
Ground clamp
CLEANING
Cleaning the AC power plug
Unplug the AC power plug and clean it
regularly. If the plug is covered with dust and
gathers moisture, its insulation may deteriorate
and result in a fire.
Cleaning the screen surface/ cabinet of
the TV set
When cleaning this TV, unplug the AC power
cord. If not, it may result in electric shock. Use
a dry soft cloth to clean the cabinet of the TV. To remove dust
near the screen, wipe it gently with a soft cloth. Stubborn stains
may be removed with a cloth slightly dampened with a solution
of mild soap and warm water. Never use strong solvents such as
thinner or benzine for cleaning. If using a chemically pretreated
cloth, please follow the instruction provided on the package. The
ventilation holes can accumulate dust over time.
To ensure proper ventilation, we recommend you to remove the
dust periodically (once a month) using a vacuum cleaner, while
the LED TV is powered off.
Disclaimer
Some chemical cleaners have been reported to damage the
screen and/or case of the LCD TV. ViewSonic will not be liable
for damage resulting from use of these cleaners.
CARRYING THE TV
Carry the TV as instructed
To prevent dropping the TV and causing serious injury, you must
follow these guidelines:
• Disconnect all cables before carrying the TV.
• Carrying the large size TV requires at least two or three
people.
• When you carry the TV, place your hands as illustrated and
hold it securely. Do not put stress on the LCD panel and the
frame around the screen.
• When carrying the TV, do not subject it to shocks, vibration,
ENGLISH
vi
or excessive force.
• When lifting or moving the TV, hold it securely from the
bottom. Place your palm directly under the panel.
VENTILATION
Slots and openings in TV are provided for ventilation. To ensure
reliable operation of the TV and to protect it
from overheating, be sure these openings are
not blocked or covered.
The TV may accumulate dust and get dirty if
proper ventilation is not provided. For proper
ventilation, follow the following guidelines:
• Never install the TV face up, down or
sideways.
• Never install the TV turned over or upside
down.
• Never cover the slots and openings with a
cloth or other materials.
• Never block the slots and openings by
placing the TV on a bed, sofa, rug or other
similar surface.
• Never place the TV in a confined space, such as a bookcase
or built-in cabinet, unless proper ventilation is provided.
Leave some space around the TV set as shown below. Otherwise,
air-circulation may be inadequate and cause overheating, which
may cause a fire or damage to the TV set.
Installed
on the wall
Installed with stand
4 inches
(10 cm)
4 inches
(10 cm)
2.375 inche
s
(6.03 cm)
11.875 inches
(30.16 cm)
4 inches
(10 cm)
4 inches
(10 cm)
4 inches
(10 cm)
11.875 inches
(30.16 cm)
Leave at least this space around the set.
Do not install the TV set as follows:
Air circulation is blocked. Air circulation is blocked.
Objects and ventilation holes
Never push any objects into the slots on the TV cabinet as they
may touch dangerous voltage points or short out parts that could
result in a fire or an electric shock. Do not place any objects on
the TV.
MOISTURE
Moisture and ammable objects
• Keep the product away from moisture. Do not
expose this appliance to rain or moisture. Do
not place objects filled with liquids, such as
vases, on the TV.
• Do not use power-line operated V sets near
water, such as in places like a bathtub,
washbowl, kitchen sink, laundry tub, a wet
basement, or near a swimming pool, etc. It may
cause fire or electric shock.
• Do not let this TV get wet. Never spill liquid of any kind on the
TV. If water penetrates into the product, unplug the power cord
and contact ViewSonic.
• Do not operate the TV when wet. It may result in electric shock
or damage to the TV.
• To prevent fire, keep flammable objects or open flame (e.g.
candles) away from the TV.
INSTALLATION
Optional wall mount
To do Wall mount installation, you need a Wall-Mount Bracket.
When installing or removing the TV using the Wall-Mount
Bracket, be sure to use qualified contractors. If not properly
secured during installation or removal from the Wall-Mount
Bracket, the TV may fall and cause serious injury.
• When installing the TV using a Wall-Mount Bracket, make
sure you follow the operating instructions supplied with the
Wall-Mount Bracket.
• Attach the brackets supplied with the Wall-Mount Bracket.
• The TV is not designed for hanging from the ceiling. It may
fall and cause serious injury.
Placement
The TV should be installed near an easily accessible AC power
outlet.
Observe the following to prevent the TV from
falling from the stand or wall mount.
• Place the TV on a stable, level surface.
• Do not hang anything on the TV. Do not allow
ENGLISH
vii
children to climb on the TV.
• Do not install the TV in places subject to extreme
temperature, such as in direct sunlight, near a radiator, or
heating vent. If the TV is exposed to extreme temperature,
the TV may overheat and cause deformation of the enclosure
or cause malfunction.
• Do not install the TV in a place exposed to direct air
conditioning.
• If the TV is installed in such a location, moisture may
condense inside and may cause a malfunction.
• Do not place the TV in hot, oily, humid or
excessively dusty places.
• Do not install the TV where insects may
enter.
• Do not install the TV where it may be exposed to mechanical
vibration.
• Do not install the TV in a location where it may spear up,
such as on or behind a pillar, or where you might bump your
head on it. It may cause injury.
Preventing the TV from toppling over
To prevent the TV from toppling over, secure the TV to a wall
or stand.
Placement for watching
We suggest you to watch the TV at a distance of 3-7 times that
of the screen height, and not in excessive brightness. It is easy
to cause eye fatigue if you watch TV for too long or in a dark
room. To obtain clear picture, do not expose the screen to direct
illumination or sunlight. Use spot lighting directed down from
the ceiling if you can.
LCD SCREEN
• Although the LCD screen is made with high precision
technology and has effective pixels of 99.99% or more, black
dots or bright points or light (red, blue, or green) may appear
constantly on the LCD screen. This is a structural property of
the LCD panel and is not a malfunction.
• The LCD screen is made with high-precision technology. To
achieve a high level of performance and picture quality, this
TV’s backlight setting is set to maximize the brightness of
the TV. However, uneven brightness may be observed when
the LED TV is viewed in a dark environment without an input
source or a blank screen. This is a normal condition, not a
malfunction of the TV. To improve this condition, change the
Picture mode, Backlight setting, enable the Light Sensor, or
turn on the Power management.
• Avoid exposing the LCD screen surface to direct sunlight. It
is likely to damage the LCD panel.
• Do not push or scratch the LCD screen, or place objects on
top of the TV. The image may be uneven or the LCD panel
may be damaged.
• If the TV is used in a cold place, a smear may occur in the
picture or the picture may become dark. It is not caused by a
failure. This condition will improve as the temperature rises.
• When still pictures are displayed continuously, ghosting may
occur. It should disappear after a short period of time.
• The screen and cabinet get warm when the TV is in use. This
is a normal condition.
• Spraying insect repellent with volatile material on the screen
will cause damage.
• Do not make prolonged contact with rubber or plastic
material.
Broken pieces
Do not throw anything at the TV.
Doing so may break the screen glass and cause
serious injury.
If the surface of the TV cracks, unplug the AC
power cord before touching the TV. Otherwise electric shock
may result.
Handling of broken glass and liquid
crystal leakage
If the LCD panel gets damaged, crystalline liquid leakage may
occur, or scattered broken glass may result. Do not touch broken
glass or crystalline liquid which is toxic, with bare hands as
cuts, poisoning or skin irritation may occur. Also do not glass
fragments or leaked crystalline liquid get into your eyes or
mouth. Should either contacted your eyes or mouth, rinse the
contacted area thoroughly with water and consult your doctor.
SERVICING
Do not attempt to repair the TV yourself,
since opening the cabinet may expose you
to dangerous voltage or other hazards. Ask
qualified service personnel to do the servicing
for your TV.
Replacement parts
When replacement parts are required, be sure the service
technician certifies in writing that he/she has used replacement
parts specified by the manufacturer that have the same
characteristics as the original parts. Unauthorized substitutions
may cause a fire, an electric shock or other hazards.
Safety check
Upon completion of repairs to the TV, ask the service
technician to perform routine safety checks (as specified by the
manufacturer) to determine that the TV is safe for operating, and
to so certify.
Ask a qualified service technician to dispose of the TV.
1
ENGLISH
Getting Started
Package Contents
Please make sure the following items are included with your LCD TV.
If any items are missing, please contact your dealer.
ViewSonic Quick Start Guide
ViewSonic User Guide
Remote Control
with batteries
LCD TV
VT2215LED
LCD TV
User Guide
IMPORTANT: Please read this User Guide to obtain important informat ion on ins talling and
using your product in a safe manner, as well as registering your produ ct for future serv ice.
Warranty information contained in this User Gui de will desc ribe your lim ited coverage from
ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in
English, or in specific languages us ing the R egional selection box in the upper right corne r
of our website. “Antes de ope rar su equipo l ea cu idadosamente las ins trucciones en este
manual”
Model No. VS14829-1M
Input Video Connector Audio Connector Supported Resolutions
HDMI
No need for this input 1080p, 1080i, 720p, 480p, 480i, PC timing (Both HD and SD content)
Component
1080p, 1080i, 720p, 480p, 480i (Both HD and SD content)
480i (SD content only)
AV
Step 1: Register online at: http://www.ViewSonic.com/support
Step 2: Check your accessory contents in packaging.
Step 3: Install 2 AAA batteries (included in package) in your remote control.
Step 4: Install your TV. If you want to hang the TV on the wall, please refer
the User Guide for detailed instructions.
Welcome to high definition entertainment. ViewSonic LCD TVs bring you a
whole new “High Definition Experience”.
Before you start using your new ViewSonic LCD TV, please read this Quick
Setup Guide. This guide will explain how to get great performance from your
new high definition TV.
Enjoy High Definition :
Set up your ViewSonic LCD TV by using proper connections to an HD content
source such as your HD cable or satellite box.
This TV is optimized for HDTV.
Please enjoy HDTV with HD programming.
Video Quality
D-SUB
D-SUB
• Please contact ViewSonic Service team directly if you have any question on the PC Connection.
Required Cable Types for Connection
Mini-Pin AudioVGA
D-SUB
D-SUB
Video Quality
HDMI
HDMI
Digital Video Input
• For the HDMI connection, you must use HDMI cable for the video and also connect the audio cable for sound.
HDMIHDMI
Step 1: Identify the connector on your PC.
Step 1: Identify the connector on your PC.
Step 2:
Connect video signal with
appropriate connector cable.
Step 2: Connect video and audio signal with appropriate connector cable.
Step 3: Connect audio signal with
appropriate connector cable.
D-SUB
VGA
PC AUDIO OUT
PC
AUDIO IN
or
DVI
HDMIHDMI
HDMI
HDMI-to-HDMIDVI-to-HDMI
PC AUDIO OUT
PC
AUDIO IN
VGA
D-SUB
VT2215LED TV
Quick Start Guide
Write down your product serial number. _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
If you need any assistance, it will help you. Please contact ViewSonic service team directly if you have
questions on the use of your television.
Contact ViewSonic Service Team at: http://www.ViewSonic.com
Or call our service team: United States 1-800-688-6688 Canada 1-866-463-4775
Please Do Not Return this Product to the Store.
For further information, please refer to the User Manual supplied with the TV. Please keep this Quick
Start Guide for your future reference.
For Your Convenience
Sources Comments & Quality
High Definition Content
HD Over-The-Air Antenna (ATSC)
HD Cable Subscription/Programming
HD Satellite Subscription
HD/Blue-ray DVD Player
Aspect ratio 16:9
Best picture quality
Over-The-AirAntenna (ATSC)
Cable Subscription/Programming
Satellite Subscription
DVD Player
Digital Content
Aspect Ratio base on program
Good picture quality
Over-The Air Antenna (NTSC)
Cable Programming
Analog Content
Original TV aspect ratio 4:3
Normal picture quality
2Connect your TV with other external devices2
Before you start to connect your ViewSonic LCD TV
• Turn off and unplug all components before making connections. • Power off your TV until you complete all the connections.
Connect your PC to your ViewSonic LCD TV
• For the D-Sub connection, you need to apply D-Sub cable and mini 3.5mm audio cable.
• For the HDMI connection, you must apply HDMI cable.
• Change the PC setting to display on TV.
• For detailed information, please refer to your User Manual.
• Please contact ViewSonic Service Team if you had any problem on connection.
• For the D-Sub connection, you need to apply D-Sub cable and mini 3.5mm audio cable.
• For the HDMI connection, you must apply HDMI cable.
• Change the PC setting to display on TV.
• For detailed information, please refer to your User Manual.
• Please contact ViewSonic Service Team if you had any problem on connection.
About the HDMI
HDMI (High-Definition Multimedia Interface) is the standard for HDTV.It is built
to properly handle high bandwidth, uncompressed video and multi-channel
audio – All in One Connection.
Please find video output port on your PC. You can choose
either HDMI or D-SUB. HDMI is better video quality.
Notes on Connection
• To enjoy an HD experience, please connect an HD source to this TV.
• When receiving high-definition content signal by over-the-air antenna, it is best to use the HD antenna.
• When using a HDMI cable, please make sure to connect the HDMI side first.
• Please contact ViewSonic Service team directly,if you have any questions on the Connection.
• Or call our service team: United States 1-800-688-6688 Canada 1-866-463-4775
Connect to your Antenna
ATSC
NTSC
VHF/UHF
Antenna
• If you are using cable without CATV converter box, you can connect cable to your ViewSonic LCD TV directly.
• If you are using 300 ohm twin-lead (flat) cable, you will need 300/75 ohm adapter to connect the antenna with your ViewSonic LCD TV.
• If you are using VHF/UHF antenna, you will need a multiplexer.
Required Cable Types for Connection
Coaxial cable
(commercially available)
Step 1: Find your antenna connector. Step 2: Connect the antenna to your ViewSonic LCD TV with 75 ohm coaxial cable.
Home Antenna
terminal
TV INTV IN
2
LCD TV - The Door to High Definition 1
Copyright © 2012 ViewSonic Corporation. All right reserved.LTV_QSG_VT2215LED Rev. 1A 06-01-12
Connect to your Computer
BETTER
GOOD
BEST
2002400114P
2
ENGLISH
Getting Started
Installing the LCD TV
Installing the Stand
1. Lay the TV at on a table with the LCD screen face down. To prevent the TV from being
scratched, put a piece of soft cloth on the table on which the screen will be set. (see Figure 1)
2. Unpack the stand, one hand hold the TV and one hand pull stand with arm together. (see
Figure 2)
3. Stand the TV up. (see Figure 3)
Disconnecting the Stand
1. Lay the TV at on a table with the LCD screen face down. To prevent the TV from being
scratched, put a piece of soft cloth on the table on which the screen will be set. (see Figure 1)
2. Remove the 4 screws on the hinge, then pull up the stand slowly. (see Figure 2)
3. Then, you shall successfully uninstall the stand. (see Figure 3)
Figure 1
Figure 2
Figure 3
Figure 1
Figure 2
Figure 3
2
3
ENGLISH
Getting Started
Mounting ViewSonic LCD TV to the wall
The LCD TV can be used in a free standing position or wall-mounted. Before installing the product to the
wall, please consider the following guidelines:
• Read the Important Safety Instructions, at the start of this manual.
• Do not install in a moist or wet environment. This equipment is intended for indoor use.
• Do not install near heat source, or strong magnetic elds.
• Use only ViewSonic approved wall-mounting brackets to support the LCD TV weight.
• Before attaching the wall mount plate to the back cover, ensure the product is working.
• If your LCD TV is already set up for free-standing operation, you need to rst remove the
stand before mounting the device to the wall.
To attach the wall-mount bracket to LCD TV safely, please use the following guidelines:
• Disconnect the power and any other cables that might hinder moving the LCD TV.
• Set the LCD TV on a table or work surface, placing the screen face down on a towel or
woolen blanket to protect the screen surface from damage while installing plate.
• Before installing the LCD TV on the wall, ensure you have recorded the product serial
number on page (i) of the User Guide, as you will need the serial number to request
service should there be a service need.
• Install the wall mount plate to the LCD TV using screws NO LONGER than 10mm, as
longer screws found in universal (non-ViewSonic) wall mount kits may damage the
power supply causing the unit to fail. The wall-mount screw type is M4 x L10.
• Mount the wall mount bracket to the wall ensuring use of proper screws to support the
installation. Ensure there is at least 3cm of space surrounding any air-vents of your
LCD TV to allow adequate cooling during operation.
• Hang the LCD TV wall mount plate to the wall mount bracket, completing installation.
Enjoy your ViewSonic LCD TV!
4
ENGLISH
Getting Started
Wall Mount Kit Specications (VESA)
When attaching to other building materials, please contact your nearesr dealer.
Product Family inch VESA Spec. (A x B) Standard Screw (C x D) Quantity
LCD TV
16 75 x 75 mm M4 x L10 4
19 ~ 24 100 x 100 mm M4 x L10 4
26 ~ 27 200 x 100 mm M4 x L10 4
32 ~ 37 400 x 100 mm M6 x L10 4
42 ~ 47 600 x 200 mm M6 x L10 4
52 400 x 200 mm M6 x L10 4
• ViewSonic provides the standard dimensions for wall mount kits as shown in the table
above.
C
D
• To nd the perfect mount, please browse www.viewsonic.com or call our service team:
United States 1-800-688-6688, Canada 1-866-463-4775.
• When purchasing our wall mount kit, a detailed install manual and all parts necessary for
assembly are provided.
• Do not use the screws that longer than the standard dimension, as they may cause damage
to the inside of the TV set.
A
B
Loading...
