ViewSonic VOT530, VOT530_BJEB60 Specifications

V O T 5 3 0

PC MINI COMPUTER

Digital Media Manager and a PC

ViewSonic’s VOT530 PC mini is an outstanding solution for

downloading and managing digital content. Its powerful

Intel® Core 2 Duo processor is just right for creating your own

media and entertainment hub. This streamlined, space saving

device is also eco-friendly – made with less plastic and saves up

to 45% in energy usage.

Monitor sold separately.

Featuring Intel® Core™ 2 Duo

>

processor with 2GB memory for

 efcientcomputing

High speed USB 2.0 (x6) and eSATA

>

front and back locations for easy
connecting for peripherals

Windows® 7

>

Green – centric compact design

>

uses less plastic, less cables and
less power

DVD drive for playback

>

Kensington® lock provides optimum

>

physical security

V O T 5 3 0 P C MINI C O M P U T E R

1 2

3

1 – DVD/CD Eject Button
2 – Power Button
3 – USB 2.0 Ports
4 – Remote Control
5 – Kensington® Lock
6 – DC Power

5

4

07 – DVI-I Port 1
08 – RJ45 Ethernet Port
09 – eSata Port

10 – Microphone Port
11 – SPDIF Out
12 – Audio Out

31211

CORE CPU Processor Type Intel® Core™ 2 Duo T6600

CPU Processor Speed 2.2GHz Dual Core, FSB 800MHz, BGA

Chipset Intel

MEMORY 2GB DDR2 SDRAM

SOFTWARE Operating System Windows® 7

HARD DRIVE Capacity 320GB SATA

OPTICAL DISK DRIVE DVD +/– RW Super Multi Drive

COMMUNICATION Ethernet LAN 10/100/1000 Gigabit Ethernet

Wireless LAN 802.11 b/g/n

INPUT/OUTPUT USB 2.0 (x6)

DVI-I

RJ45 Gigabit Ethernet LAN

eSata

SPDIF out

Microphone jack

Earphone jack

POWER Power Adapter 20V DC; 90W adapter

Power Cord 3-pin AC plug

OPERATING Temperature 32–104ºF (0–40ºC)

CONDITIONS Humidity 10–90% (non-condensing)

Altitude 0–10,000 ft. (3048 m)

DIMENSIONS Physical (W x H x D) 6.5" x 1.97" x 6.5" (165mm x 50mm x 165mm)

Carton (W x H x D) 8.9" x 8.7" x 6.1" (226mm x 222mm x 156mm)

WEIGHT Net 3.1 lb. (1.4 kg)

Gross 5.5 lb. (2.5 kg)

SECURITY Kensington® lock

REGULATIONS CUL/FCC

RECYCLE/DISPOSAL Please dispose of in accordance with local, state or federal laws.

PACKAGE CONTENTS VOT530, power cord, power adapter, remote control, antenna,

System Recovery CD, Quick Start Guide

WARRANTY 1 year limited warranty

®

GM45

6

7 8 3 9

ViewSonic Corporation’s QMS & EMS have been registered

to ISO 9001 & ISO 14001, respectively, by TUV NORD.

10

Sales: [phone] • [e-mail] • ViewSonic.com

Microsoft, Windows, and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or

othercountries.Specications subjecttochangewithout notice.Selection,offers andprogramsmayvary bycountry;seeyour ViewSonic

representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright
© 2009 ViewSonic Corporation. All rights reserved. [14527-00B-09/09] VOT530-1

Sm art er G ree ner Com puti ng

For more product information, visit us on the web at ViewSonic.com
