Viewsonic VG712sb Service Manual 1b

Service Manual

ViewSonic VG712s/b-1

Model No. VLCDS23719-6W/7W

17” Color TFT LCD Display

ViewSonic

(VG712s/b_SM_835_1b Rev. 1b Oct. 2004)



381 Brea Canyon Road, Walnut, California 91789 USA - [phone]

Copyright

Copyright

2004 by ViewSonic Corporation. All rights reserved. No part of this publication may be

¤

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of ViewSonic Corporation.

Disclaimer

ViewSonic makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranty of merchantability or fitness for any particular
purpose. Further, ViewSonic reserves the right to revise this publication and to make changes from time
to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or
changes.

Trademarks

Optiquest is a registered trademark of ViewSonic Corporation.
ViewSonic is a registered trademark of ViewSonic Corporation.
All other trademarks used within this document are the property of their respective owners.

1a

1b

DCN Number ECR Number

06/18/04

10/18/04

Revision History

Documents Number

4475

4774

4626

Description of Changes EditorRevision SM Editing Date

Initial Release

Change Panel From AUO M170EN05 V.8 48.62701.003 12ms/20ms

To AUO M170EG01 V.0 48.62701.004 12ms

A. Lu

A. Lu

ViewSonic Corporation Confidential

i

-

Do Not Copy VG712s/b

TABLE OF CONTENTS

1. Precautions and Safety Notices

2. Specification

3. Front Panel Function Control Description

4. Circuit Description

5. Adjusting Procedure

6. Trouble Shooting Flow Chart

7. Recommended Spare Parts List

8. Exploded Diagram And Spare Parts List

9. Block Diagram

10. Schematic Diagrams

11. PCB Layout Diagrams

1

5

14

21

24

49

53

61
65
66

72

ViewSonic Corporation Confidential

ii

-

Do Not Copy VG712s/b

1. Precautions and Safety Notices

1. Appropriate Operation

(1) Turn off the product before cleaning.
(2) Use only a dry soft cloth when cleaning the LCD panel surface.
(3) Use a soft cloth soaked with mild detergent to clean the display housing.
(4) Use only high quality and safety approved AC/DC power adapter.
(5) Disconnect the power plug from AC outlet if the product is not used for a long period of time.
(6) If smoke, abnormal noise, or strange odor is present, immediately switch the LCD display off.
(7) Do not touch the LCD panel surface with sharp or hard objects.
(8) Do not place heavy objects on the LCD display, video cable, or power cord.
(9) Do not use abrasive cleaners, waxes or solvents for your cleaning.
(10) Do not operate the product under the following conditions:

- Extremely hot, cold or humid environment.

- Areas susceptible to excessive dusts and dirt.

- Near any appliance generating a strong magnetic field.

- Place in direct sunlight.

2. Caution

No modification of any circuit should be attempted. Service work should only be performed after you are thoroughly
familiar with all of the following safety checks and servicing guidelines.

3. Safety Check

Care should be taken while servicing this LCD display. Because of the high voltage used in the inverter circuit, the voltage
is exposed in such areas as the associated transformer circuits.

4. Power Supply Requirements

The external power converter for this display utilizes AC and DC cords, AC cord is detachable, but DC cord is permanently
attached. Any attempt to replace another adapter could result in serious problems on the display.

ViewSonic Corporation Confidential

1

-

Do Not Copy VG712s/b

5. LCD Module Handling Precautions

5.1 Handling Precautions

(1) Since front polarizer is easily damaged, pay attention not to scratch it.
(2) Be sure to turn off power supply when inserting or disconnecting from input connector.
(3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
(4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
(5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
(6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when

handling.

(7) Do not open nor modify the Module Assembly.
(8) Do not press the reflector sheet at the back of the module to any directions.
(9) In case if a Module has to be put back into the packing container slot after once it was taken out from the

container, do not press the center of the CCFL Reflector edge. Instead, press at the far ends of the CFL
Reflector edge softly. Otherwise the TFT Module may be damaged.

(10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface

Connector of the TFT Module.

(11) After installation of the TFT Module into an enclosure (LCD monitor housing, for example), do not twist

nor bend the TFT Module even momentary. At designing the enclosure, it should be taken into
consideration that no bending/twisting forces are applied to the TFT Module from outside. Otherwise the
TFT Module may be damaged.

(12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local ordinances

or regulations for disposal.

(13) Small amount of materials having no flammability grade is used in the LCD module. The LCD module

should be supplied by power complied with requirements of Limited Power Source (IEC60950 or UL1950),
or be applied exemption.

(14) The LCD module is designed so that the CFL in it is supplied by Limited Current Circuit (IEC60950 or

UL1950). Do not connect the CFL in Hazardous Voltage Circuit.

ViewSonic Corporation Confidential

2

-

Do Not Copy VG712s/b

5.2 Handling and Placing Methods

Correct Methods:

Only touch the metal frame of the LCD panel or the front
cover of the monitor. Do not touch the surface of the
polarizer.

Incorrect Methods:

Surface of the LCD panel is pressed by fingers and that
will probably cause “Mura.”

Take out the monitor with cushions

Take out the monitor by grasping the LCD panel. That
will probably cause “Mura.”

ViewSonic Corporation Confidential

3

-

Do Not Copy VG712s/b

Place the monitor on a clean and soft foam pad. Place the monitor on foreign objects. That will probably

scratch the surface of the panel or cause “Mura.”

The panel is placed facedown on the lap. That will
probably cause “Mura.”

ViewSonic Corporation Confidential

4

-

Do Not Copy VG712s/b

2. Specification

1. General Requirements

Test Resolution & Frequency 1280x1024 @ 60Hz
Test Image Size Full Size

Contrast and Brightness Controls

2. Signal Interface

Vide o Int e r fac e
Analog Input Connector DB-15 (Analog)

Digital Input Connector DVI-I (Digital)
Default Input Connector Defaults to the first detected input
Video Cable Connector DB-15 Pin out Compliant DDC 2B
Video Signals 1. Video RGB (Analog)

Video Impedance 75 Ohms (Analog), 100 Ohms (Digital)
Exclusions Not compatible with interlaced video

3. Power

Factory Default:
Contrast = 70%, Brightness = 100%

Separate

2. TMDS (Digital)

Power Supply
Power Supply (Adapter) Part Number: LSE 0107A1240

Input Voltage Range 90 to 264 VAC
Over Current Protection 12.7V ~ 18V full load
Power Dissipation 40 Watts (typ.)

4. Electrical Requirements

Horizontal / Vertical Frequency

Horizontal Frequency 30 – 82 KHz
Vertical Refresh Rate 50 – 85* Hz.

1. Since 75Hz in panel spec, the image quality
might be worse than <= 75Hz

2. For resolution 1280 x 1024, the vertical refresh
rate up to 75 Hz; for the rest resolutions, the vertical

refresh rate up to 85Hz
Maximum Pixel Clock 135 MHz
Primary Preset 1280x1024@60Hz
Look up table timing

ViewSonic Corporation Confidential

5

-

Do Not Copy VG712s/b

<<Analog>>
640 x 350 @ 70Hz, 31.5KHz
640 x 400 @ 60Hz, 31.5KHz
640 x 400 @ 70Hz, 31.5KHz
640 x 480 @ 50Hz, 24.7KHz
640 x 480 @ 60Hz, 31.5KHz
640 x 480 @ 67Hz, 35.0KHz
640 x 480 @ 72Hz, 37.9KHz
640 x 480 @ 75Hz, 37.5KHz
640 x 480 @ 85Hz, 43.27KHz
720 x 400 @ 70Hz, 31.5KHz
800 x 600 @ 56Hz, 35.1KHz
800 x 600 @ 60Hz, 37.9KHz
800 x 600 @ 75Hz, 46.9KHz
800 x 600 @ 72Hz, 48.1KHz
800 x 600 @ 85Hz, 53.7KHz
832 x 624 @ 75Hz, 49.7KHz
1024 x 768 @ 60Hz, 48.4KHz
1024 x 768 @ 70Hz, 56.5KHz
1024 x 768 @ 72Hz, 58.1KHz
1024 x 768 @ 75Hz, 60.0KHz
1024 x 768 @ 85Hz, 68.67KHz
1152 x 864 @ 75Hz, 67.5KHz
1152 x 870 @ 75Hz, 68.7KHz
1280 x 1024 @ 60Hz, 63.4KHz
1280 x 1024 @ 75Hz, 79.97KHz
1280x 720 @ 60Hz, 45KHz (HDTV)

<<Digital>>
640 x 350 @ 70Hz, 31.5KHz
640 x 400 @ 60Hz, 31.5KHz
640 x 400 @ 70Hz, 31.5KHz
640 x 480 @ 50Hz, 24.7KHz
640 x 480 @ 60Hz, 31.5KHz
640 x 480 @ 67Hz, 35.0KHz
640 x 480 @ 72Hz, 37.9KHz
640 x 480 @ 75Hz, 37.5KHz
640 x 480 @ 85Hz, 43.27KHz
720 x 400 @ 70Hz, 31.5KHz
800 x 600 @ 56Hz, 35.1KHz
800 x 600 @ 60Hz, 37.9KHz
800 x 600 @ 75Hz, 46.9KHz
800 x 600 @ 72Hz, 48.1KHz
800 x 600 @ 85Hz, 53.7KHz
832 x 624 @ 75Hz, 49.7KHz
1024 x 768 @ 60Hz, 48.4KHz
1024 x 768 @ 70Hz, 56.5KHz
1024 x 768 @ 72Hz, 58.1KHz
1024 x 768 @ 75Hz, 60.0KHz
1024 x 768 @ 85Hz, 68.67KHz
1152 x 864 @ 75Hz, 67.5KHz
1152 x 870 @ 75Hz, 68.7KHz
1280 x 1024 @ 60Hz, 63.4KHz
1280 x 1024 @ 75Hz, 79.97KHz
1280x 720 @ 60Hz, 45KHz (HDTV)

Changing Modes

Maximum Mode Change Blank Time for image
stability. Note:

1. 3 seconds (Max), excluding “Auto Adjust”

2. Under DOS mode (640 x 350, 720 x 400 &

3. The monitor needs to do “Auto Adjust” the

5. Audio Interface

Speaker Specification

Line input connection 3.5 mm stereo jack
Line input signal 1.0 Vrms
Line input impedance 10 k Ohm
Maximum power output (Electri c) 3 W @ < 8% DISTORTION
Signal to Noise Ratio 72 dB
Frequency response 400 Hz – 20 KHz
Distortion < 8 % THD (@1KHz)

4. While running Change Mode, Auto Adjust or

Memory Recall, the image shall blank.

time

640 x 400), it should recall factory setting
when execute “Auto Adjust”

first time a new mode is detected

ViewSonic Corporation Confidential

6

-

Do Not Copy VG712s/b

6. LCD Panel

Panel Characteristics
Source panel AU panel (M170EG01 V0)

Size 17”diagonal screen size
Typ e MVA type with LVDS interface
Pixel 1280*1024 addressable pixels
Pixel Pitch 0.264mm*0.264mm pixel pitch
Brightness 300 cd/m2 (Typ after 30 minute warm up)
Contrast Ratio 500:1 (Typ), 300:1 (Min)
Viewi n g Angle(Horizontal) 140 deg @ CR>10
Viewi n g Angle (Vertical) 130 deg @ CR>10
Response Time 12 ms (Tr=9ms, TF =3 ms) (Typ.)
Backlight lamps 4 CCFL backlight lamps
Backlight Life 50,000 Hours (Typ.) / 45,000 hours (Min.)

7. Mechanical

Dimensions
Width 378 mm (14.9 inch)

Height 405 mm (16.0 inch)
Depth 177 mm ( 7.0 inch)
Monitor Weight 5.3 kg / 11.66 lbs

Ergonomics
Tilt Up

Tilt Down -5 º +/- 20%

20 º +/- 20%

8. Environmental

Environmental Conditions
Operating Temperature 0°C to +40°C

Storage Temperature -20°C to +60°C
Operating Relative Humidity 20% to 90% RH Non-Condensing
Storage Relative Humidity 5% to 90% RH Non-Condensing
Operating Altitude 0 to +3,000 meters
Storage Altitude 0 to +12,000 meters

ViewSonic Corporation Confidential

7

-

Do Not Copy VG712s/b

9. EDID

Appendix E: Analog EDID

VG712s/b Analog EDID

Time: 13:10:50

Date: Wed Jan 14, 2004

______________________________________________________________________
______________________________________________________________________

VIEWSONIC CORPORATION

EDID Version # 1, Revision # 3
DDCTest For: ViewSonic VG712s/b
______________________________________________________________________
______________________________________________________________________
128 BYTES OF EDID CODE:

0 1 2 3 4 5 6 7 8 9

________________________________________

0 | 00 FF FF FF FF FF FF 00 5A 63
10 | 19 7B 01 01 01 01 01 0E 01 03
20 | 08 22 1B 78 2E C5 C6 A3 57 4A
30 | 9C 23 12 4F 54 BF EF 80 81 80
40 | 61 59 45 59 31 59 01 01 01 01
50 | 01 01 01 01 30 2A 00 98 51 00
60 | 2A 40 30 70 13 00 52 0F 11 00
70 | 30 00 1E 00 00 00 FF 00 50 33 55
80 | 30 34 30 31 30 30 30 30 31 0A
90 | 00 00 00 FD 00 32 55 1E 52 0E

100 | 00 0A 20 20 20 20 20 20 00 00
110 | 00 FC 00 56 47 37 31 32 73 0A
120 | 20 20 20 20 20 20 00 94

______________________________________________________________________
(08-09) ID Manufacturer Name = VSC
(11-10) Product ID Code = 7B19
(12-15) Last 5 Digits of Serial Number = Not Used
(16) Week of Manufacture = 01
(17) Year of Manufacture = 2004
(10-17) Complete Serial Number = See Descriptor Block
(18) EDID Version Number = 1
(19) EDID Revision Number = 3
(20) VIDEO INPUT DEFINITION:
Analog Signal

0.700, 0.300 (1.000 Vp-p)

Separate Syncs

ViewSonic Corporation Confidential

8

-

Do Not Copy VG712s/b

(21) Maximum Horizontal Image Size = 340 mm
(22) Maximum Vertical Image Size = 270 mm
(23) Display Gamma = 2.20
(24) Power Management and Supported Feature(s):
Active Off/Very Low Power, Standard Default Color Space,
Preferred Timing Mode
Display Type = R/G/B Color
(25-34) CHROMA INFO:
Red X - 0.640 Green X - 0.290 Blue X - 0.140 White X - 0.310
Red Y - 0.340 Green Y - 0.610 Blue Y - 0.070 White Y - 0.330
(35) ESTABLISHED TIMING I:
720 X 400 @ 70Hz (IBM,VGA)
640 X 480 @ 60Hz (IBM,VGA)
640 X 480 @ 67Hz (Apple,Mac II)
640 X 480 @ 72Hz (VESA)
640 X 480 @ 75Hz (VESA)
800 X 600 @ 56Hz (VESA)
800 X 600 @ 60Hz (VESA)
(36) ESTABLISHED TIMING II:
800 X 600 @ 72Hz (VESA)
800 X 600 @ 75Hz (VESA)
832 X 624 @ 75Hz (Apple,Mac II)
1024 X 768 @ 60Hz (VESA)
1024 X 768 @ 70Hz (VESA)
1024 X 768 @ 75Hz (VESA)
1280 X 1024 @ 75Hz (VESA)
(37) Manufacturer's Reserved Timing:
1152 X 870 @ 75Hz (Apple,Mac II)
(38-53) Standard Timing Identification:
1280 X 1024 @60Hz
1024 X 768 @85Hz
800 X 600 @85Hz
640 X 480 @85Hz
Not Used
Not Used
Not Used
Not Used

ViewSonic Corporation Confidential

9

-

Do Not Copy VG712s/b

______________________________________________________________________
(54-71) Detailed Timing / Descriptor Block 1:
1280x1024 Pixel Clock: 108.00 MHz
______________________________________________________________________
Horizontal Image Size: 338 mm Vertical Image Size: 271 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo

Horizontal:
Active Time: 1280 pixels Blanking Time: 408 pixels
Sync Offset: 48 pixels Sync Pulse Width: 112 pixels
Border: 0 pixels Frequency: 63.98 KHz

Vertical:
Active Time: 1024 lines Blanking Time: 42 lines
Sync Offset: 1 lines Sync Pulse Width: 3 lines
Border: 0 lines Frequency: 60.02 Hz

Digital Separate, Horizontal Polarity (+) Vertical Polarity (+)
______________________________________________________________________
(72-89) Detailed Timing / Descriptor Block 2:

Monitor Serial Number:
P3U040100001
______________________________________________________________________
(90-107) Detailed Timing / Descriptor Block 3:

Monitor Range Limits:
Min Vertical Freq - 50 Hz
Max Vertical Freq - 85 Hz
Min Horiz. Freq - 30 KHz
Max Horiz. Freq - 82 KHz
Pixel Clock - 140 MHz
Secondary GTF - Not Supported

______________________________________________________________________
(108-125) Detailed Timing / Descriptor Block 4:

Monitor Name:

VG712s/b

(126) No Extension EDID Block(s)
(127) CheckSum OK

ViewSonic Corporation Confidential

10

-

Do Not Copy VG712s/b

Appendix F: Digital EDID

VG712s/b Digital EDID

Time: 08:14:47
Date: Fri Jan 30, 2004
______________________________________________________________________
______________________________________________________________________
VIEWSONIC CORPORATION
EDID Version # 1, Revision # 3
DDCTest For: ViewSonic VG712s/b
______________________________________________________________________
______________________________________________________________________
128 BYTES OF EDID CODE:
0 1 2 3 4 5 6 7 8 9
________________________________________

0 |

00 FF FF FF FF FF FF 00 5A 63

10 |

19 7B 01 01 01 01 01 0E 01 03
20 | 80 22 1B 78 2E C5 C6 A3 57 4A
30 |

9C 23 12 4F 54 BF EF 80 81 80

61 59 45 59 31 59 31 0A 01 01

40 |
50 |

01 01 01 01 30 2A 00 98 51 00
60 |

2A 40 30 70 13 00 52 0F 11 00
70 | 0

0 1E 00 00 00 FF 00 50 33 55

30 34 30 31 30 30 30 30 31 0A

80 |
90 |

00 00 00 FD 00 32 55 1E 52 0E

00 0A 20 20 20 20 20 20 00 00

100 |

00 FC 00 56 47 37 31 32 73 0A

110 |
120 |

20 20 20 20 20 20 00 E3
______________________________________________________________________
(08-09) ID Manufacturer Name = VSC

(11-10) Product ID Code = 7B19
(12-15) Last 5 Digits of Serial Number = Not Used
(16) Week of Manufacture = 01
(17) Year of Manufacture = 2004
(10-17) Complete Serial Number = See Descriptor Block
(18) EDID Version Number = 1
(19) EDID Revision Number = 3
(20) VIDEO INPUT DEFINITION:
Digital Signal
Non - VESA DFP 1.x Compatible

ViewSonic Corporation Confidential

11

-

Do Not Copy VG712s/b

(21) Maximum Horizontal Image Size = 340 mm
(22) Maximum Vertical Image Size = 270 mm
(23) Display Gamma = 2.20
(24) Power Management and Supported Feature(s):
Active Off/Very Low Power, Standard Default Color Space,
Preferred Timing Mode
Display Type = R/G/B Color
(25-34) CHROMA INFO:
Red X - 0.640 Green X - 0.290 Blue X - 0.140 White X - 0.310
Red Y - 0.340 Green Y - 0.610 Blue Y - 0.070 White Y - 0.330
(35) ESTABLISHED TIMING I:
720 X 400 @ 70Hz (IBM,VGA)
640 X 480 @ 60Hz (IBM,VGA)
640 X 480 @ 67Hz (Apple,Mac II)
640 X 480 @ 72Hz (VESA)
640 X 480 @ 75Hz (VESA)
800 X 600 @ 56Hz (VESA)
800 X 600 @ 60Hz (VESA)
(36) ESTABLISHED TIMING II:
800 X 600 @ 72Hz (VESA)
800 X 600 @ 75Hz (VESA)
832 X 624 @ 75Hz (Apple,Mac II)
1024 X 768 @ 60Hz (VESA)
1024 X 768 @ 70Hz (VESA)
1024 X 768 @ 75Hz (VESA)
1280 X 1024 @ 75Hz (VESA)
(37) Manufacturer's Reserved Timing:

1152 X 870 @ 75Hz (Apple,Mac II)
(38-53) Standard Timing Identification:
1280 X 1024 @60Hz
1024 X 768 @85Hz
800 X 600 @85Hz
640 X 480 @85Hz
640 X 400 @70Hz
Not Used
Not Used
Not Used

ViewSonic Corporation Confidential

12

-

Do Not Copy VG712s/b

______________________________________________________________________
(54-71) Detailed Timing / Descriptor Block 1:
1280x1024 Pixel Clock: 108.00 MHz
______________________________________________________________________
Horizontal Image Size: 338 mm Vertical Image Size: 271 mm
Refreshed Mode: Non-Interlaced Normal Display - No Stereo

Horizontal:
Active Time: 1280 pixels Blanking Time: 408 pixels
Sync Offset: 48 pixels Sync Pulse Width: 112 pixels
Border: 0 pixels Frequency: 63.98 KHz

Vertical:
Active Time: 1024 lines Blanking Time: 42 lines
Sync Offset: 1 lines Sync Pulse Width: 3 lines
Border: 0 lines Frequency: 60.02 Hz

Digital Separate, Horizontal Polarity (+) Vertical Polarity (+)
______________________________________________________________________

(72-89) Detailed Timing / Descriptor Block 2:

Monitor Serial Number:

P3U040100001

(90-107) Detailed Timing / Descriptor Block 3:

Monitor Range Limits:
Min Vertical Freq - 50 Hz
Max Vertical Freq - 85 Hz
Min Horiz. Freq - 30 KHz
Max Horiz. Freq - 82 KHz
Pixel Clock - 140 MHz
Secondary GTF - Not Supported

______________________________________________________________________
(108-125) Detailed Timing / Descriptor Block 4:

Monitor Name:
VG712/b

(126) No Extension EDID Block(s)
(127) CheckSum OK

ViewSonic Corporation Confidential

13

-

Do Not Copy VG712s/b

3. Front Panel Function Control Description

Adjusting the Screen Image

Use the buttons on the front control panel to display and adjust the OnView

®

controls which display on the screen. The OnView controls are explained at the
top of the next page.

MAIN

MENU

AUTO IMAGE ADJUST
CONTRAST/BRIGHTNESS
INPUT SELECT
AUDIO MENU
COLOR ADJUST
INFORMATION
MANUAL IMAGE ADJUST
SETUP MENU
MEMORY RECALL

ř EXIT ř SELECT

1

2

Speaker Speaker

Main Menu with OnView controls

Front Control Panel shown
below

Scrolls through menu options and
adjusts the displayed control.

Also a shortcut to display the
Contrast adjustment control
screen.

Displays the Main Menu
or exits the control screen
and saves adjustments

Decreases or
increases volume

Audio Mute button
turns the sound off.

Displays the control
screen for the highlighted
control.

Also toggles between two
controls on some
screens.

Also a shortcut to toggle
between analog and
digital connections.

Power light
Green = ON
Orange = Power

Saving

Power
On/Off

ViewSonic Corporation Confidential

14

-

Do Not Copy VG712s/b

Do the following to adjust the screen image:

To display the Main Menu, press button [1].

1

NOTE:

All OnView menus and adjustment screens disappear automatically
after about 15 seconds. This is adjustable through the OSD timeout setting in the
setup menu.

2

To select a control you want to adjust, press ▲ or ▼ to scroll up or down the
Main Menu.

3

After the control is selected, press button [2]. A control screen like the one
shown below appears.

The command line at the
bottom of the control screen
tells what to do next from this
screen. You can toggle
between control screens,
adjust the selected option, or
exit the screen.

4

To adjust the control, press the up ▲ or down ▼ buttons.

5

To save the adjustments and exit the menu, press button [1]

twice

.

The following tips may help you optimize your display:

• Adjust your computer's graphic card so that it outputs a video signal 1280 x

1024 @ 60Hz to the LCD display. (Look for instructions on "changing the
refresh rate" in your graphic card's user guide.)

• If necessary, make small adjustments using H POSITION and V POSITION

until the screen image is completely visible

. (The black border around the
edge of the screen should barely touch the illuminated "active area" of the
LCD display.)

ViewSonic Corporation Confidential

15

-

Do Not Copy VG712s/b

Main Menu Controls

Adjust the menu items shown below by using the up ▲ and down ▼ buttons.

Control Explanation

Auto Image Adjust

sizes and centers the screen image

automatically.

Contrast

adjusts the difference between the image background

(black level) and the foreground (white level).

Brightness

Input Select

adjusts background black level of the screen image.

toggles between inputs if you have more than one

computer.

Audio Adjust

Volume

increases the volume, decreases the volume, and

mutes the audio.

Mute

Color Adjust

color temperatures and
green (G), and blue (B) separately. The factory setting for this
product is 6500K (6500 Kelvin).

temporarily silences audio output.

provides several color adjustment modes: preset

RGB

which allows you to adjust red (R),

Color Adjust

sRGB

9300K

Ԧ6500K

5400K
5000K

User Color

1:EXIT 2:SELECT

sRGB

— sRGB is quickly becoming the industry standard for color
management, with support being included in many of the latest
applications. Enabling this setting allows the LCD display to
more accurately display colors the way they were originally
intended. Enabling the sRGB setting will cause the Contrast and
Brightness adjustments to be disabled.

9300K

in most office settings with fluorescent lighting).

6500K

richer red.

5400K
5000K

— Adds blue to the screen image for cooler white (used

— Adds red to the screen image for warmer white and

— Adds green to the screen image for a darker color.
— Adds blue and green to the screen image for a darker

ViewSonic Corporation Confidential

16

-

Do Not Copy VG712s/b

Control Explanation

User Color

and blue (B)

1

To select color (R, G or B) press button [2].

2

To adjust selected color, press ▲ or ▼.

Important

— Individual adjustments for red (R), green (G),

.

: If you select RECALL from the Main Menu when
the product is set to a Preset Timing Mode, colors return to the
6500K factory preset.

Information

displays the timing mode (video signal input)
coming from the graphics card in your computer, the LCD
model number, the serial number, and the ViewSonic website
URL. See your graphic card’s user guide for instructions on
changing the resolution and refresh rate (vertical frequency).

NOTE:

VESA 1280 x 1024 @ 60Hz (recommended) means
that the resolution is 1280 x 1024 and the refresh rate is 60
Hertz.

Information:
H. Frequency: XX kHz
V. Frequency: XX Hz
Resolution XXXXXXXXX
Pixel Clock: XXX MHz

Serial Number: XXXXXXXXXXX
Model Number: XXXXXXXXXXX
www.ViewSonic.com 1: Exit

Manual Image Adjust Sub-menu

H. Size (Horizontal Size)

H./V. Position (Horizontal/Vertical Position)

adjusts the width of the screen image.

image left or right and up or down.

moves the screen

ViewSonic Corporation Confidential

17

-

Do Not Copy VG712s/b

Control Explanation

Fine Tune

sharpens the focus by aligning the text and/or graphic

characters.

NOTE:

Sharpness

Try Auto Image Adjust first.

adjusts the clarity and focus of the screen image.

Setup menu displays the menu shown below:

Setup Menu

Language Select

Resolution Notice

OSD Position

OSD Time Out

OSD Background On/Off

1: Exit 2: Select

Language

allows you to choose the language used in the menus

and control screens.

Resolution Notice

Resolution Notice

ԦOn ԦOff

1: Exit

allows you to enable or disable this notice.

If you enable the Resolution Notice shown above and your
computer is set at a resolution other than 1280 x 1024, the
following screen appears.

Resolution Notice

For best picture quality, change the resolution to 1280 x 1024

Press "1" to Clear Message.
Press "2" to Disable Message.

ViewSonic Corporation Confidential

18

-

Do Not Copy VG712s/b

Control Explanation

OSD Position

allows you to move the on-screen display menus

and control screens.

OSD Timeout

sets the length of time the on-screen display
screen is displayed. For example, with a “30 second” setting, if a
control is not pushed within 30 seconds, the display screen
disappears.

OSD Background

On/Off

allows you to turn the On-Screen Display

background On or Off.

Memory Recall

returns the adjustments back to factory settings
if the display is operating in a factory Preset Timing Mode listed
in the Specifications of this manual.

ViewSonic Corporation Confidential

19

-

Do Not Copy VG712s/b

Hot Keys for Function Controls

Buttons: Functions:

[Up] + [Down] arrows Recall Contrast or Brightness while in the Contrast

[Volume-] + [Volume+] Recall volume to 50% while in volume adjustment,

[1] + [2] Toggle 720x400 and 640x400 mode when input

[1] + [Up] + [Down] White Balance. White Balance should set the screen

[1] + [Down] (hold for 10 seconds) Power Lock (Unlock). User won’t be able to turn off

[1] + [Up] (hold for 10 seconds) OSD Lock (Unlock). It will lock all functions,

[Up] + [Down] + [Power On] with signal

(Hold for 3 seconds. Release “Power” button first

and then “Up” & ”Down” buttons.)

[Up] + [Down] + [Power On]

Without signal

(Hold for 3 seconds. Release “Power” button first

and then “Up” & ”Down” buttons.)

or Brightness adjustment, or recall both of Contrast
and Brightness when the OSD is not on.

or when OSD is not on.

720x400 or 640x400 mode.

on the pure black and white pattern with
640*480@60Hz resolution.

the monitor.

including “Volume” and “Mute”.
All Mode Reset. It will erase all end users’ settings
and restore the factory defaults.

Burn in Mode. After entering Burn in Mode, press
[1] button, you can find the information about this
monitor.

Remark: All the shortcut functions are only available while OSD is off.

ViewSonic Corporation Confidential

20

-

Do Not Copy VG712s/b

4. Circuit Description

1. Power supply (DC/DC Converter)

The AP1501 is monolithic IC designed for M/B DC/DC converter, and owns the ability of driving a 3A load without
any additional transistor component.

The AP1501 operates at a switching frequency of 150KHz and thus allows smaller-sized filter components than what
would be needed with lower frequency switch regulator.

ViewSonic Corporation Confidential

21

-

Do Not Copy VG712s/b

2. Flash Memory

The Pm39LV010R is a 1 Megabit, 3.3 Volt-only Flash Memory organized as 131,072 bytes of 8 bits each. This device
is designed to use a 3.0 Volt to 3.6 Volt power supply to perform in-system programming.

The 1 Megabit memory array is divided into thirty-two uniform blocks of 4 Kbytes each for data and/or code storage.

The block architecture allows users to flexibly make chip erase or block erase operation. The block erase feature
allows a particular block to be erased and reprogrammed without affecting the data in other blocks. After the device
performs chip erase or block erase operation, it can be reprogrammed on a byte-by-byte basis.

3. GM5120

The gm5110/20 is a graphic processing IC for Liquid Crystal Display (LCD) monitors at XGA/SXGA resolution. It
provides all key IC functions required for the highest quality LCD monitors. On-chip functions include a high-speed
triple-ADC and PLL, Ultra-Reliable DVI

TM

receiver, a high quality zoom and shrink scaling engine, an on-screen

display (OSD) controller, digital color controls and an on-chip microcontroller (OCM). With this level of integration,
the gm5110/20 devices simplify and reduce the cost of LCD monitors while maintaining a high-degree of flexibility and
quality.

ViewSonic Corporation Confidential

22

-

Do Not Copy VG712s/b

gm5110/5120 System Design Example

4. LVDS (THC63LVDM83A)

The THC63LVDM83A transmitter converts 28 bits of CMOS/TTL data into LVDS (Low Voltage Differential Signaling)
data stream. A phase-locked transmit clock is transmitted in parallel with the data streams over a fifth LVDS link. The
HC63LVDM83A can be programmed for rising edge or falling edge clocks through a dedicated pin. The
THC63LVDF84A receiver converts the LVDS data streams back into 28 bits of CMOS/TTL data with falling edge
clock. At a transmit clock frequency of 85MHz, 24 bits of RGB data and 4 bits of LCD timing and control data
(HSYNC, VSYNC, CNTL1, CNTL2) are transmitted at a rate of 595 Mbps per LVDS data channel.

ViewSonic Corporation Confidential

23

-

Do Not Copy VG712s/b

5. Adjusting Procedure

1. Function Test

1.1 Product

- 17” LCD Monitor

1.2 Test Equipment

- Color Video Signal & Pattern (or PC with SXGA resolution and a sound card)

1.3 Test Condition

Before function test and alignment, each LCD Monitor should be run-in and warmed up for at least 30 minutes
with the following conditions:

(a) In room temperature,
(b) With full-white screen, RGB, and Black
(c) With cycled display modes,

640*480 (H=43.27KHz, V=85Hz)
800*600 (H=53.7KHz, V=85Hz)
1024*768 (H=68.67KHz, V=85Hz)
1280*1024 (H=79.97KHz, V=75Hz)

1.4 Test Display Modes & Pattern

1.4.1 Compatible Modes

Analog Digital

1. 640 x 350 @ 70Hz, 31.5KHz

2. 640 x 400 @ 60Hz, 31.5KHz

3. 640 x 400 @ 70Hz, 31.5KHz

4. 640 x 480 @ 50Hz, 24.7KHz

5. 640 x 480 @ 60Hz, 31.5KHz

6. 640 x 480 @ 67Hz, 35.0KHz

7. 640 x 480 @ 72Hz, 37.9KHz

8. 640 x 480 @ 75Hz, 37.5KHz

9. 640 x 480 @ 85Hz, 43.27KHz

10. 720 x 400 @ 70Hz, 31.5KHz

11. 800 x 600 @ 56Hz, 35.1KHz

12. 800 x 600 @ 60Hz, 37.9KHz

13. 800 x 600 @ 75Hz, 46.9KHz

14. 800 x 600 @ 72Hz, 48.1KHz

15. 800 x 600 @ 85Hz, 53.7KHz

640 x 350 @ 70Hz, 31.5KHz
640 x 400 @ 60Hz, 31.5KHz
640 x 400 @ 70Hz, 31.5KHz
640 x 480 @ 50Hz, 24.7KHz
640 x 480 @ 60Hz, 31.5KHz
640 x 480 @ 67Hz, 35.0KHz
640 x 480 @ 72Hz, 37.9KHz
640 x 480 @ 75Hz, 37.5KHz
640 x 480 @ 85Hz, 43.27KHz
720 x 400 @ 70Hz, 31.5KHz
800 x 600 @ 56Hz, 35.1KHz
800 x 600 @ 60Hz, 37.9KHz
800 x 600 @ 75Hz, 46.9KHz
800 x 600 @ 72Hz, 48.1KHz
800 x 600 @ 85Hz, 53.7KHz

ViewSonic Corporation Confidential

24

-

Do Not Copy VG712s/b

16. 832 x 624 @ 75Hz, 49.7KHz

17. 1024 x 768 @ 60Hz, 48.4KHz

18. 1024 x 768 @ 70Hz, 56.5KHz

19. 1024 x 768 @ 72Hz, 58.1KHz

20. 1024 x 768 @ 75Hz, 60.0KHz

21. 1024 x 768 @ 85Hz, 68.67KHz

22. 1152 x 864 @ 75Hz, 67.5KHz

23. 1152 x 870 @ 75Hz, 68.7KHz

24. 1280 x 1024 @ 60Hz, 63.4KHz

25. 1280 x 1024 @ 75Hz, 79.97KHz

26. 1280x 720 @ 60Hz, 45KHz (HDTV)

832 x 624 @ 75Hz, 49.7KHz
1024 x 768 @ 60Hz, 48.4KHz
1024 x 768 @ 70Hz, 56.5KHz
1024 x 768 @ 72Hz, 58.1KHz
1024 x 768 @ 75Hz, 60.0KHz
1024 x 768 @ 85Hz, 68.67KHz
1152 x 864 @ 75Hz, 67.5KHz
1152 x 870 @ 75Hz, 68.7KHz
1280 x 1024 @ 60Hz, 63.4KHz
1280 x 1024 @ 75Hz, 79.97KHz
1280x 720 @ 60Hz, 45KHz (HDTV)

1.4.2 Function Test Display Pattern

Item

Test Content Pattern Specification Remark
1 Frequency & Tracking Fine Line Moire Eliminate visual wavy noise. Figure 1
2 Contrast/Brightness 16 Gray Scale 16 gray levels should be

Figure 2

distinguishable.

3 Boundary Horizontal & Vertical

Thickness

Horizontal and Vertical position of
video should be adjustable to be

Figure 3

within the screen frame.

4 RGB Color Performance RGB Color Intensities Contrast of each R, G, B, color

Figure 4, 5, 6

should be normal.
5 Screen Uniformity & Flicker Full White Should be compliant with the spec. Figure 7
6 Dead Pixel/Line White Screen & Dark

Screen

7 White Balance White & Black Pattern The screen must have the pure

The numbers of dead pixels should

be compliant with the spec.

Figure 7, 8

Figure 9
white and black pattern, no other
color.

Fine Line Morie Pattern (Figure1) Gray Scale Pattern (Figure2)

ViewSonic Corporation Confidential

25

-

Do Not Copy VG712s/b

Horizontal & Vertical Thickness Pattern (Figure 3) R. Color Pattern (Figure 4)

G. Color Pattern (Figure5) B. Color Pattern (Figure 6)

Full White Patter (Figure 7) Dark Screen Pattern (Figure 8)

ViewSonic Corporation Confidential

26

-

Do Not Copy VG712s/b

Black-White Pattern (Figure 9)

1.5 Function Test and Alignment Procedure

1.5.1 All Modes Reset
You should do “All Mode Reset” (Refer to Chapter III-3. Hot Keys for Function Controls) first.

This action will allow you to erase all end-user’s settings and restore the factory defaults.

1.5.2 Auto Image Adjust

Please select and enter “Auto Image Adjust” function on Main Menu to see if it is workable. The “Auto Image
Adjust” function is aimed to offer a better screen quality by built-in ASIC. For optimum screen quality,
the user has to adjust each function manually.

1.5.3 Firmware
Test Pattern: Burn In Mode (Refer to Chapter III-3. Hot Keys for Function Controls)

- Make sure the F/W is the latest version.

1.5.4 DDC

Test Pattern: EDID program

- Make sure it can pass test program.

ViewSonic Corporation Confidential

27

-

Do Not Copy VG712s/b

1.5.5 Fine Tune and Sharpness

Test Signal: 1280*1024@60Hz
Test Pattern: Line Moire Pattern

- Check and see if the image has noise and focus performs well. Eliminate visual line bar.

- If not, readjust by the following steps:

(a) Select and enter “Fine Tune” function on “Manual Image Adjust” to adjust the image to eliminate

visual wavy noise.

(b) Then, select and enter “Sharpness” function to adjust the clarity and focus of the screen image.

1.5.6 Boundary
Test Signal: 1280*1024@60Hz

Test Pattern: Horizontal & Vertical Line Thickness Pattern

- Check and see if the image boundary is within the screen frame.

- If not, readjust by the following steps:

(a) Select and enter “Manual Image Adjust” function on OSD Main Menu.

(b) Then, select and enter “Horizontal Size” or “Horizontal/Vertical Position” function to adjust the video

boundary to be full scanned and within screen frame.

1.5.7 White Balance

Test Signal: 640*480@60Hz
Test Pattern: White and Black Pattern

1.5.8 R, G, B, Colors Contrast
Test Signal: 1280*1024@60Hz

Test Pattern: R, G, B, Color Intensities Pattern and 16 Gray Scale Pattern

- Check and see if each color is normal and distinguishable.

- If not, please return the unit to repair area.

1.5.9 Screen Uniformity and Flicker

Test Signal: 1280*1024@60Hz
Test Pattern: Full White Pattern

- Check and see if it is in normal condition.

ViewSonic Corporation Confidential

28

-

Do Not Copy VG712s/b

1.5.10 Dead Pixel and Line
Test Signal: 1280*1024@60Hz
Test Pattern: Dark and White Screen Pattern

- Check and see if there are dead pixels on LCD panel with shadow gauge and filter film.

- The total numbers and distance of dead pixels should be compliant with the spec.

1.5.11 Mura

Test Pattern: White, RGB, Black, & Grey
Test Tool: 8% ND Filter

- Check if the Mura can pass 8% ND Filter.

1.5.12 Audio

Test Signal: Voice signal (optional, depend on model)
Test Pattern: liberty

- Make sure there is audio output.

- Make sure that audio function (volume≦80%) is working without noise and resonance.

- Make sure that the sound of right and left speakers are in balance.

1.5.13 Check for Secondary Display Modes

Test Signal:
Analog: 640 x 350 @ 70Hz; 640 x 400 @ 60Hz; 640 x 400 @ 70Hz;
640 x 480 @ 50/60/67/72/75/85Hz; 720 x 400 @ 70Hz; 800 x 600 @ 56/60/72/75/85Hz; 832 x 624 @ 75Hz; 1024 x
768 @ 60Hz; 1024 x 768 @ 70/72/75/85Hz; 1152 x 864 @ 75Hz; 1152 x 870 @ 75Hz; 1280 x 1024 @ 75Hz; 1280x
720 @ 60Hz (HDTV).
Digital: 640 x 350 @ 70Hz; 640 x 400 @ 60/70/Hz; 640 x 480 @ 50/60/67/72/75/85Hz; 720 x 400 @ 70Hz; 800 x
600 @ 56/60/75/72/85Hz; 832 x 624 @ 75Hz; 1024 x 768 @ 60/70/72/75/85Hz; 1152 x 864 @ 75Hz; 1152 x 870 @
75Hz; 1280 x 1024 @ 75Hz; 1280x 720 @ 60Hz (HDTV).

- Normally when the primary mode 1280*1024@60Hz is well adjusted and compliant with the specification, the
secondary display modes will be great possible to be compliant with the spec. But we still have to check with the
general test pattern to make sure every secondary is compliant with the specification.

ViewSonic Corporation Confidential

29

-

Do Not Copy VG712s/b

1.5.14 All Modes Reset

After final QC step, we have to erase all saved changes again and restore the factory defaults. You should
do "All Mode Reset” again.

1.5.15 Power Off Monitor

Turn off the monitor by pressing “Power” button.

2. Firmware Upgrade Procedure

When you receive the returned monitor, please check whether the firmware version is the latest.
If not, please do the following procedures to upgrade it to the latest version.

2.1 Equipment Needed

- VG712s/b Monitor

- Fixture for Firmware Upgrade

- Power Adapter (P/N: 47.58201.001) *1 for Fixture

- VGA Cable (P/N: 42.59901.003) *1(Pin 4, 11 should be connected to GND)

- PC (Personal Computer)

- LPT Cable (P/N: 42.59906.001) *1

- Firmware Upgrade Program

- One additional monitor for checking the program execution

ViewSonic Corporation Confidential

30

-

Do Not Copy VG712s/b

Printer Port

Power Adapter for Fixture

(P/N: 47.58201.001)

2.2 Setup Procedure

2.2.1 Connect P2 of Fixture with printer port of PC by LPT Cable.

2.2.2 Connect P1 of Fixture with VG712 Monitor by VGA Cable.

PC

LPT Cable

(P/N: 42.59906.001)

VG712S

Fixture

VGA Cable

(P/N: 42.59901.003)

2.2.3 Plug Power Adapter to Fixture.

2.2.4 Connect Power Cord to VG712 Monitor.

2.2.5 Connect PC to the additional monitor.

JP1: to Power Adapter

P2: to LPT Cable

ViewSonic Corporation Confidential

31

P1: to VGA Cable

-

Do Not Copy VG712s/b

2.2.6 Install GProbe Program by selecting and clicking Gprobe icon. Press “Yes” or “Next” buttons until the installation is
complete.

ViewSonic Corporation Confidential

32

-

Do Not Copy VG712s/b

ViewSonic Corporation Confidential

33

-

Do Not Copy VG712s/b

ViewSonic Corporation Confidential

34

-

Do Not Copy VG712s/b

ViewSonic Corporation Confidential

35

-

Do Not Copy VG712s/b

2.3 Firmware Upgrade Procedure

Step 1. Let VG712 enter Burn In Mode. (Refer to Chapter III-3. Hot Keys for Function Controls).
Step 2.

Save these three files<bdisp.txt>, <p204_205.bin> and <712AV_V2_65.bin> in a hard disk

(better in a root directory, e.g. C:\ or D:\ ).

Step 3. Open <bdisp.txt> file. Key in the path where you save the driver <p204_205.bin> and firmware <712AV_V2_65.bin >.

ViewSonic Corporation Confidential

36

-

Do Not Copy VG712s/b

Step 4. Execute Gprobe program.

Step 5. Click Connection Setup icon. Select Protocol: DDC 2Bi3, Port: LPT1 (0x378), Speed: 70000.

ViewSonic Corporation Confidential

37

-

Do Not Copy VG712s/b

Step 6. Before executing the firmware program, please test the connection between the monitor and fixtures. Key in “test” after

“Gprobe,” and then press “Enter.”

If the test result shows “passed,” it means the connection is well. If not (failed), it means the connection
has problems. Then you need to check the setup procedure or reboot the PC, or simply use another PC to do
the firmware upgrade.

ViewSonic Corporation Confidential

38

-

Do Not Copy VG712s/b

Step 7. Key in “batch C:\VG712\bdisp.txt” after “Gprobe:”, and then press “Enter” key to begin programming.

Step 8. The successful picture is as follows:

ViewSonic Corporation Confidential

39

-

Do Not Copy VG712s/b

Step 9. Unplug and replug power cord of VG712s/b and then enter “Burn In Mode” (Refer to Chapter III-3. Hot Keys for Function

Controls). Check if the version of BIOS is correct.

Step 10. At last, do “All Mode Reset.”

ViewSonic Corporation Confidential

40

-

Do Not Copy VG712s/b

Troubleshooting:

1. If the firmware upgrade fails at the last step, don’t unplug the power cord of the monitor. Just try the upgrade

procedure again.

(a) If there is error to execute the command at or before line10 in the “bdisp.txt” batch file (for instance, the

message “Error executing batch file at line 4” shows up in the Gprobe program (see the following picture)),
please try to upgrade the firmware again.

Test failed.
Test failed.
Test failed.
Test failed.
Test failed.
Test failed.
Error executing batch file at line 4.
Execution time: 5.72s
GProbe:>

(b) If there is error to execute the command at or after line11 in the “bdisp.txt” batch file, please copy the error

line of the “bdisp.txt” batch file to “Gprobe:>” in the Gprobe program, and then press “Enter.” For example,
there is “Error executing batch file at line 16” (see the following picture). Then you have to copy line 16
“FLASHWRITE C:\VG712\712AV_V2_65.bin” in the “bdisp.txt” file to “Gprobe:>” in the Gprobe program,
and then press “Enter” (see the picture next page).

ViewSonic Corporation Confidential

41

-

Do Not Copy VG712s/b

Test passed.
Test passed.
Test passed.
Erasing FLASH... Done.
Writing FLASH...
Writing FLASH... FAILED.
Error executing batch file at line 16.
Execution time: 9.61s
GProbe:>

Line 16

Line 16

ViewSonic Corporation Confidential

42

-

Do Not Copy VG712s/b

Copy the error line of the
“bdisp.txt” batch file to
“Gprobe:>”

2. If the firmware upgrade still fails, reboot the PC, or simply use another PC to upgrade.

3. If the above procedures don’t work, unplug and re-plug the power cord of VG712s/b. Then try to upgrade the

firmware again if VG712 can be powered on. If VG712s/b cannot be turned on, that means the flash memory of

the main board is out of work. You then have to replace the main board.

3. DDC Key In Procedure

Note:

1. Every time after replacing the main board, you have to do the DDC key in.

2. If you find the DDC does not conform to the monitor, you have to do the DDC key in.

3.1 Equipment Needed

- VG712s/b Series Monitor

- Fixture (V3) for DDC Key in (JP3 must be closed)

- RS232 Cable (P/N: 42.55907.001) *1

- VGA Cable (P/N: 42.59901.003) *2

- DVI-DVI Cable *1 (P/N: 42.56108.012)

ViewSonic Corporation Confidential

43

-

Do Not Copy VG712s/b

- PC (Personal Computer) with Win 98

- Power Adapter (P/N: 47.56001.501) *1 for Fixture

- DDC Key In Program

- One additional monitor for checking the program execution

COM1:

to

RS232

Cable

(P/N: 42.55907.001)

PC V3 Fixture

RS-232 Cable

JP3 must be closed

DVI-DVI Cable

(P/N: 42.56108.012)

VG712S

Power Adapter for Fixture

(P/N: 47.57702.001)

ViewSonic Corporation Confidential

Barcode Reader

VGA Cable (P/N: 42.59901.003)

44

-

Do Not Copy VG712s/b

3.2 Setup Procedure

3.2.1 Connect P2 of Fixture with VGA port of VG712s/b by VGA Cable.

3.2.2 Connect P3 of Fixture with DVI port of VG712s/b by DVI-DVI Cable.

3.2.3 Connect P1 of Fixture with COM1 of PC by RS-232 Cable.

3.2.4 Plug Power Adapter to Fixture(JP1).

3.2.5 Connect Power Cord to VG712s/b Monitor.

3.2.6 Connect PC to the additional monitor.

P3: to DVI-DVI Cable

P2: to VGA Cable

JP3 must be closed

JP1: to Power
Adapter

P1: to RS232 Cable

ViewSonic Corporation Confidential

45

-

Do Not Copy VG712s/b

3.3 DDC Key In Procedure

Step 1. Select and execute DDC Key In program.

Step 2. Select “W/w - writing mode.”

ViewSonic Corporation Confidential

46

-

Do Not Copy VG712s/b

Step 3. Key in the serial number or use the barcode reader to scan the barcode of the monitor, and then press “Enter” key.

Notice: The English of the serial number should be capital letters.

Step 4. The successful picture is as follows. “The checksum values will appear after DDC is upgraded successfully in both VGA

and DFP (DVI) modes.”

ViewSonic Corporation Confidential

47

-

Do Not Copy VG712s/b

Step 5. Let VG712 enter “Burn In Mode” (Refer to Chapter III-3. Hot Keys for Function Contro ls). Unplug and re-plug the

power cord of the monitor. The corrective serial number will show on the screen.

Step 6. Checking Method:

- Execute the DDC Key In program and select “R/r - Reading mode” in Step 2.

- Use the barcode reader to scan the barcode of the monitor, or manually key in the serial number. If the DDC is

correct, the “Send VGA” and “Send DFP” will show “Check Pass!” message.

ViewSonic Corporation Confidential

48

-

Do Not Copy VG712s/b

6. Trouble Shooting Flow Chart

This chapter provides technicians and people who have an electronic background a primary description about
maintaining the product. Moreover, you can get the appropriate operation to solve some complicated problems of
component repairing and professional problems.

1. Equipment Needed

- VG712s/b Monitor

- Philips Screw Driver #101 and #107

- Electronic Hex Nut M5 mm

- PC (Personal Computer) with SXGA resolution and sound card / Pattern Generator

2. Main Procedure

Note: Before troubleshooting, do “All Mode Reset” first to restore the monitor’s settings to the factory defaults.

ViewSonic Corporation Confidential

49

-

Do Not Copy VG712s/b

2.1 A. Power Circuit Troubleshooting

2.2 B. Performance Troubleshooting

ViewSonic Corporation Confidential

50

-

Do Not Copy VG712s/b

ViewSonic Corporation Confidential

51

-

Do Not Copy VG712s/b

Notice:

1. Make sure VGA cable connected to PC directly, not via anything like “Data transfer” or “Distribution” ……After this

action if Ghost image disappears, go to “Yes”; else, go to “No.”

2. Check the compatibility on the computer. If it is compatibility problem, feedback the information to ViewSonic; else,

go to “No.”

2.3 C. Control Function Troubleshooting

2.4 D. Speakers Troubleshooting

ViewSonic Corporation Confidential

52

-

Do Not Copy VG712s/b

PE BAG LDPE 750*760*0.05t VG700-1

M-MS-0808-9647

51.58317.001

PE BAG

1

7. Recommended Spare Parts List

RECOMMENDED SPARE PARTS LIST (VG712b-1)

ViewSonic Model Number: VLCDS23719
Rev: 1a

Item ViewSonic P/N Ref. P/N Location Universal number# Q'ty

Accessories:

1

PC Board Assembly:

2 PCBA INVERTER;EMAX FOR 17" AUO M170EG01 V0 B-SB-0221-0700 44.58402.002 INVERTER 1
3 PCBA MAIN BD VG710 "GM5120 AU-EG01V0" B-MB-0201-2734 80.62701.005 MAIN BOARD GM5120 1
4 PCBA CTRL BD VG710 B-CB-0206-0165 80.62702.001 CONTROL BOARD 1

Cabinets:

5 ASSY STAND CS-VS08 VG710b C-BS-0303-0571 70.62702.002 STAND 1
6 ASSY FRONT COVER CS-VS07A VG712b C-00000212 75.62701.004 FRONT COVER 1
7 ASSY REAR COVER CS-VS08 VG710b C-BC-0302-0539 75.62702.002 REAR COVER 1
8 BASE COVER ABS HB-VS08 VG710b M-CV-0830-2479 51.62706.002 BASE COVER 1

Cables:

9 W.A. 10/6P UL1007 #24 100mm VG700(INV) M-WR-0828-0636 42.58301.001 INVERTER WIRE 1
10 W.A. 30P UL1007 #24 225mm VG710(COST)-CMO CB-00000213 42.62701.A01 PANEL WIRE 1
11 W.A. 12P UL1571 #28 260mm W/O CORE SHARE(MB/CTRL) M-WR-0828-6010 42.58303.001 1
12 CABLE VGA 15P 1800mm 2*25mm CORE A-VC-0101-0261 42.59901.003 VGA CABLE 1
13 CABLE AUDIO 1.8M LM/BK/LM VX2000 A-AU-0120-0032 42.59903.001 AUDIO CABLE 1

Documentation:

14 USER GUIDE+CD VG712b TCO'99 A-CD-VG712B 36.62701.008 USER GUIDE 1
15 LABEL CAUTION HIGH VOLTAGE 25.4*19mm M-LB-0813-1016 35.00010.002 CAUTION LABEL 1
16 LABEL CARTON 76*76mm M-LB-0813-0706 35.58203.001 UPC LABEL 1
17 LABEL BARCODE 40*14 ViewSonic M-LB-0813-0736 35.58304.001 BARCODE LABEL 1
18 LABEL 210*65mm BLANK FOR PALLET M-LB-0813-1017 35.59906.001 0.0625
19 LABEL BAR CODE 50*25mm VP191 M-LB-0813-0781 35.61203.001 BARCODE LABEL 1
20 LABEL SPEC 120*50mm VG712b TCO99 M-LB-0830-0733 35.62701.005 SPEC LABEL 1

Electronic

21 TFT LCD 17" AUO M170EG01 V.0 M-LCD-0826-0256 48.62701.004 PANEL AUO M17EG01 V0 1

Components:

22 SPEAKER 3W FOR VG710 E-SK-0412-0080 49.62701.001 SPEAKER 1

Hardware:

23 SHIELDING BRKT-INV TINEPLATE 0.3t VG710s M-BK-0805-0020 61.61102.002 INVERTER BRACKET 1
24 LCD BRKT SECC 1.0t VG710s M-BK-0805-0021 61.62701.001 PANEL BRACKET 1
25 SHIELDING BRKT-MB SECC 1.0t VG710s M-BK-0805-0022 61.62702.001 MB BRACKET 1
26 BASE PLATE SPCC-Zn 2.5t VG710s M-MS-0808-8960 61.62703.001 BASE PLATE 1
27 HINGE SPCC-Zn 2.0t VG710s M-MS-0808-8961 61.62704.001 HINGE 1
28 HINGE CAP ABS HB-VS08 VG710b M-MS-0808-8954 51.62703.002 HINGE CAP 1

Miscellaneous:

29 BIRD LOGO AL E015-006 VG710s M-MS-0808-8946 35.62702.001 BIRD LOGO 1
30 COSMETIC STRIP ADHESIVE CS-VS06 140*21*0.3t M-MS-0808-8947 35.62703.001 COMESTIC STRIP ADHESIVE 1
31 ViewSonic AL-LOGO E015-016-1 ViewSonic M-MS-0808-8948 35.62704.001 1
32 EMI Tape (80773) 20*40mm M-MS-0808-8882 41.55601.001 2
33 EMI TAPE 80773 25*75mm M-MS-0808-8949 41.58301.001 1
34 EMI GASKET 773GT W6*H6.5*L30 M-MS-0808-8950 41.61603.001 1
35 FILAMENT TAPE 3M NO.8915 25mm*55M M-MS-0808-8797 51.00014.002 TAPE FOR WIRE 0.0032
36 LCD PROTECT FILM 355*290*0.1t mm MYLAR VG700/VG750 M-MS-0808-8952 51.58314.001 PROTECTION FILM FOR PANEL 1
37 NAMEPLATE ELLIPSE CS-VS08 ViewSonic M-MS-0808-8299 51.58711.002 NAMEPLATE 1
38 WIRE MOUNT MC-03A "G&A" VX930 M-MS-0808-8953 51.59907.001 5
39 MYLAR ADHESIVEt=0.3mm VP171 M-MS-0808-8750 51.61103.001 INVERTER MYLAR 1
40 PC 30*12*0.6t mm VG710 M-MS-0808-9643 51.62711.003 2
41 FRONT ARM ABS HB-VS08 VG710b M-MS-0808-8955 51.62707.002 FRONT ARM 1
42 REAR ARM ABS HB-VS08 VG710b M-MS-0808-8956 51.62708.002 REAR ARM 1

Packing Material:

43 CARTON AB-18 455*205*480(h) VG712b TCO99 P-BX-0601-1087 55.62701.005 CARTON 1
44 CUSHION R EPS VG710s P-FM-0602-0818 56.62701.001 CUSHION 1
45 CUSHION L EPS VG710s P-FM-0602-0819 56.62702.001 CUSHION 1
46 PE BAG LDPE 450*700*0.07t W/HOLE VG710 M-MS-0808-9642 51.62710.001 PE BAG 1

Plastics:

47 VESA RUBBER PAD D7.0*H4.5 VG710b M-MS-0808-8959 52.62701.002 4
48 RUBBER SPACER 20*10*5.5mm M-MS-0808-9644 52.62702.001 2
49 RUBBER FOOT 35*10*1.2t VG710 M-MS-0808-9645 52.62703.001 RUBBER FOOT 5
50 RUBBER 30*15*4 BLACK VG710 M-MS-0808-9646 52.62703.002 1

ADAPTER IN100-240V 12V/3.33A;"LSE" A-AD-0114-0204 47.62701.001 ADAPTER 1

Description

Item ViewSonic P/N Ref. P/N Location Q'ty

Accessories:

1

Item ViewSonic P/N Ref. P/N Location Q'ty

1 Accessories: CABLE POWER CORD 1.8M±0.1M UNSHIELD (NA) A-PC-0106-0270 42.57207.001 POWER CORD 1

Item ViewSonic P/N Ref. P/N Location Q'ty

1 Accessories: 1.8M+0.1M COLOR CS-VS08 China A-PC-0106-0187 42.50126.001 POWER CORD 1

Documentation:

1 WARRANTY CARD S. CHINESE SECOND VERSION VIEWSONIC M-MS-0808-8773 36.58307.002 WARRANTY
2 WARRANTY STICKER S. CHINESE M-LB-0813-0737 36.58308.001 WARRANTY
3 SHIPPING WARRANTY STICKER S. CHINESE VIEWSONIC M-LB-0813-0739 36.58309.001 WARRANTY
4 Packing Material:

Item ViewSonic P/N Ref. P/N Location Q'ty

1 Accessories: CABLE POWER CORD 1830mm SP-023+IS14 EUR. A-PC-0106-0271

Item ViewSonic P/N Ref. P/N Location Q'ty

1 Accessories: CABLE POWER CORD 1830mm SP-023+IS14 EUR. A-PC-0106-0271

ViewSonic Corporation Confidential

RECOMMENDED SPARE PARTS LIST (VG712b-M)

CABLE POWER CORD 1.8M±0.1M UNSHIELD (NA) A-PC-0106-0270 42.57207.001 POWER CORD 1

Description

RECOMMENDED SPARE PARTS LIST (VG712b-P)

Description

RECOMMENDED SPARE PARTS LIST (VG712b-G)

Description

RECOMMENDED SPARE PARTS LIST (VG712b-E)

Description

42.50112.001

POWER CORD 1

RECOMMENDED SPARE PARTS LIST (VG712b-A)

Description

42.50112.001

-

Do Not Copy VG712s/b

POWER CORD 1

53

RECOMMENDED SPARE PARTS LIST (VG712s-1)

PE BAG LDPE 750*760*0.05t VG700-1

M-MS-0808-9647

51.58317.001

PE BAG

1

ViewSonic Model Number: VLCDS23719
Rev: 1b

Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number# Q'ty

Accessories:

1

PC Board Assembly:

2 PCBA INVERTER;EMAX FOR 17" AUO M170EG01 V0 ECR 4990 B-SB-0221-0700 44.58402.002 INVERTER 1
3 PCBA MAIN BD VG710 "GM5120 AU-EG01V0" ECR 4626 B-MB-0201-2734 80.62701.005 MAIN BOARD GM5120 1

4 PCBA CTRL BD VG710 B-CB-0206-0165 80.62702.001 CONTROL BOARD 1

Cabinets:

5 ASSY STAND CS-VS06 VG710s PL-PS-0715-0994 70.62702.001 STAND 1
6 ASSY FRONT COVER CS-VS07A VG712s M-CV-0830-2564 75.62701.003 FRONT COVER 1
7 ASSY REAR COVER CS-VS06 VG710s C-BC-0302-0540 75.62702.001 REAR COVER 1
8 BASE COVER ABS HB-VS06 VG710s M-CV-0830-2480 51.62706.001 BASE COVER 1
9 FRONT ARM ABS HB-VS06 VG710s M-MS-0808-8970 51.62707.001 FRONT ARM 1

10 REAR ARM ABS HB-VS06 VG710s M-MS-0808-8971 51.62708.001 REAR ARM 1

Cables:

11 W.A. 10/6P UL1007 #24 100mm VG700(INV) M-WR-0828-0636 42.58301.001 INVERTER WIRE 1

12 W.A. 30P UL1007 #24 225mm VG710(COST)-CMO Added 10/01/04 CB-00000213 42.62701.A01 PANEL WIRE 1

13 W.A. 12P UL1571 #28 260mm W/O CORE SHARE(MB/CTRL) M-WR-0828-6010 42.58303.001 1
14 CABLE VGA 15P 1800mm 2*25mm CORE A-VC-0101-0261 42.59901.003 VGA CABLE 1
15 CABLE AUDIO 1.8M LM/BK/LM VX2000 A-AU-0120-0032 42.59903.001 AUDIO CABLE 1

Documentation:

16 USER GUIDE+CD VG712s TCO'03 ECR 4626 A-CD-VG712S 36.62701.007 USER GUIDE 1

17 LABEL CAUTION HIGH VOLTAGE 25.4*19mm M-LB-0813-1016 35.00010.002 CAUTION LABEL 1
18 LABEL CARTON 76*76mm M-LB-0813-0706 35.58203.001 UPC LABEL 1
19 LABEL BARCODE 40*14 ViewSonic M-LB-0813-0736 35.58304.001 BARCODE LABEL 1
20 LABEL 210*65mm BLANK FOR PALLET M-LB-0813-1017 35.59906.001 0.0625
21 LABEL BAR CODE 50*25mm VP191 M-LB-0813-0781 35.61203.001 BARCODE LABEL 1

22 LABEL SPEC 120*50mm VG712s Added 10/01/04 M-LB-0813-1044 35.62701.003 SPEC LABEL 1

Electronic

23 TFT LCD 17" AUO M170EG01 V.0 ECR 4690 M-LCD-0826-0256 48.62701.004 PANEL AUO M17EG01 V0 1

Components:

24 SPEAKER 3W FOR VG710 E-SK-0412-0080 49.62701.001 SPEAKER 1

Hardware:

25 SHIELDING BRKT-INV TINEPLATE 0.3t VG710s M-BK-0805-0020 61.61102.002 INVERTER BRACKET 1
26 LCD BRKT SECC 1.0t VG710s M-BK-0805-0021 61.62701.001 PANEL BRACKET 1
27 SHIELDING BRKT-MB SECC 1.0t VG710s M-BK-0805-0022 61.62702.001 MB BRACKET 1
28 BASE PLATE SPCC-Zn 2.5t VG710s M-MS-0808-8960 61.62703.001 BASE PLATE 1
29 HINGE SPCC-Zn 2.0t VG710s M-MS-0808-8961 61.62704.001 HINGE 1
30 HINGE CAP ABS HB-VS06 VG710s M-MS-0808-8969 51.62703.001 HINGE CAP 1

Miscellaneous:

31 BIRD LOGO AL E015-006 VG710s M-MS-0808-8946 35.62702.001 BIRD LOGO 1
32 COSMETIC STRIP ADHESIVE CS-VS06 140*21*0.3t M-MS-0808-8947 35.62703.001 COMESTIC STRIP ADHESIVE 1
33 ViewSonic AL-LOGO E015-016-1 ViewSonic M-MS-0808-8948 35.62704.001 1
34 EMI Tape (80773) 20*40mm M-MS-0808-8882 41.55601.001 2
35 EMI TAPE 80773 25*75mm M-MS-0808-8949 41.58301.001 1
36 EMI GASKET 773GT W6*H6.5*L30 M-MS-0808-8950 41.61603.001 1
37 FILAMENT TAPE 3M NO.8915 25mm*55M M-MS-0808-8797 51.00014.002 TAPE FOR WIRE 0.0032
38 LCD PROTECT FILM 355*290*0.1t mm MYLAR VG700/VG750 M-MS-0808-8952 51.58314.001 PROTECTION FILM FOR PANEL 1
39 NAMEPLATE ELLIPSE ViewSonic M-MS-0808-8116 51.58711.001 NAMEPLATE 1
40 WIRE MOUNT MC-03A "G&A" VX930 M-MS-0808-8953 51.59907.001 5
41 MYLAR ADHESIVEt=0.3mm VP171 M-MS-0808-8750 51.61103.001 INVERTER MYLAR 1

42 PC 30*12*0.6t mm VG710 Added 10/01/04 M-MS-0808-9643 51.62711.003 2

Packing Material:

43 CARTON AB-18 455*205*480(h) VG712s TCO99 ECR 4626 P-BX-0601-0991 55.62701.003 CARTON 1

44 CUSHION R EPS VG710s P-FM-0602-0818 56.62701.001 CUSHION 1
45 CUSHION L EPS VG710s P-FM-0602-0819 56.62702.001 CUSHION 1
46 PE BAG LDPE 450*700*0.07t W/HOLE VG710 M-MS-0808-9642 51.62710.001 PE BAG 1

Plastics:

47 RUBBER SPACER 20*10*5.5mm M-MS-0808-9644 52.62702.001 2
48 RUBBER FOOT 35*10*1.2t VG710 M-MS-0808-9645 52.62703.001 RUBBER FOOT 5
49 RUBBER 30*15*4 BLACK VG710 M-MS-0808-9646 52.62703.002 1
50 VESA RUBBER PAD D7.0*H4.5 VG710s M-MS-0808-8972 52.62701.001 4

ADAPTER IN100-240V 12V/3.33A;"LSE" A-AD-0114-0204 47.62701.001 ADAPTER 1

Description

RECOMMENDED SPARE PARTS LIST (VG712s-M)

Item ViewSonic P/N Ref. P/N Location Q'ty

Accessories:

1

CABLE POWER CORD 1.8M±0.1M UNSHIELD (NA) A-PC-0106-0270 42.57207.001 POWER CORD 1

Description

RECOMMENDED SPARE PARTS LIST (VG712s-P)

Item ViewSonic P/N Ref. P/N Location Q'ty

1 Accessories: CABLE POWER CORD 1.8M±0.1M UNSHIELD (NA) A-PC-0106-0270 42.57207.001 POWER CORD 1

Description

RECOMMENDED SPARE PARTS LIST (VG712s-E)

Item ViewSonic P/N Ref. P/N Location Q'ty

1 Accessories: CABLE POWER CORD 1830mm SP-023+IS14 EUR. A-PC-0106-0271

Description

42.50112.001

POWER CORD 1

RECOMMENDED SPARE PARTS LIST (VG712s-G)

Item ViewSonic P/N Ref. P/N Location Q'ty

1 Accessories: 1.8M+0.1M COLOR CS-VS08 China A-PC-0106-0187 42.50126.001 POWER CORD 1

Documentation:

2 WARRANTY CARD S. CHINESE SECOND VERSION VIEWSONIC M-MS-0808-8773 36.58307.002 WARRANTY 1
3 WARRANTY STICKER S. CHINESE M-LB-0813-0737 36.58308.001 WARRANTY 1
4 SHIPPING WARRANTY STICKER S. CHINESE VIEWSONIC M-LB-0813-0739 36.58309.001 WARRANTY 1
5 Packing Material:

Description

ViewSonic Corporation Confidential

54

-

Do Not Copy VG712s/b

BOM LIST (VG712b-1)

ViewSonic Model Number: VLCDS23719

Rev: 1a

Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty

1 M-LB-0813-1016 35.00010.002 LABEL CAUTION HIGH VOLTAGE 25.4*19mm CAUTION LABEL 1
2 M-LB-0813-0736 35.58304.001 LABEL BARCODE 40*14 ViewSonic BARCODE LABEL 1
3 M-LB-0813-0781 35.61203.001 LABEL BAR CODE 50*25mm VP191 BARCODE LABEL 1
4 M-LB-0830-0733 35.62701.005 LABEL SPEC 120*50mm VG712b TCO99 SPEC LABEL 1
5 M-MS-0808-8948 35.62704.001 ViewSonic AL-LOGO E015-016-1 ViewSonic 1
6 #N/A 39.62702.005 DDC RECODER VG712b AUO EG01 V0 1
7 A-AD-0114-0204 47.62701.001 ADAPTER IN100-240V 12V/3.33A;"LSE" 1

8 M-MS-0808-8952 51.58314.001 LCD PROTECT FILM 355*290*0.1t mm MYLAR VG70

9 M-MS-0808-8299 51.58711.002 NAMEPLATE ELLIPSE CS-VS08 ViewSonic NAMEPLATE 1
10 M-MS-0808-8954 51.62703.002 HINGE CAP ABS HB-VS08 VG710b HINGE CAP 1
11 M-MS-0808-8946 35.62702.001 BIRD LOGO AL E015-006 VG710s BIRD LOGO 1

12 M-MS-0808-8947 35.62703.001 COSMETIC STRIP ADHESIVE CS-VS06 140*21*0.3t
13 M-MS-0808-8882 41.55601.001 EMI Tape (80773) 20*40mm 3
14 M-MS-0808-8949 41.58301.001 EMI TAPE 80773 25*75mm 1
15 M-MS-0808-8950 41.61603.001 EMI GASKET 773GT W6*H6.5*L30 1
16 M-WR-0828-0636 42.58301.001 W.A. 10/6P UL1007 #24 100mm VG700(INV) INVERTER WIRE 1
17 CB-00000213 42.62701.A01 W.A. 30P UL1007 #24 225mm VG710(COST)-CMO PANEL WIRE 1
18 M-WR-0828-6010 42.58303.001 W.A. 12P UL1571 #28 260mm W/O CORE SHARE(MB 1
19 B-SB-0221-0700 44.58402.002 PCBA INVERTER;EMAX FOR 17" AUO M170EG01 V0 INVERTER 1
20 M-LCD-0826-0256 48.62701.004 TFT LCD 17" AUO M170EG01 V.0 PANEL AUO M17EG01 V0 1
21 E-SK-0412-0080 49.62701.001 SPEAKER 3W FOR VG710 SPEAKER 1
22 M-MS-0808-8797 51.00014.002 FILAMENT TAPE 3M NO.8915 25mm*55M TAPE FOR WIRE 0.001
23 M-MS-0808-8239 51.59901.001 ACETATE TAPE W=20mm 3
24 M-MS-0808-8953 51.59907.001 WIRE MOUNT MC-03A "G&A" VX930 5
25 M-MS-0808-8750 51.61103.001 MYLAR ADHESIVEt=0.3mm VP171 INVERTER MYLAR 1
26 #N/A 51.62709.002 MYLAR ADHESIVE 150*45*0.25t VG710 1
27 M-MS-0808-9643 51.62711.003 PC 30*15*1.15tmm VG712 2
28 M-MS-0808-8959 52.62701.002 VESA RUBBER PAD D7.0*H4.5 VG710b 4
29 M-MS-0808-9644 52.62702.001 RUBBER SPACER 20*10*5.5mm 4
30 M-MS-0808-9646 52.62703.002 RUBBER 30*15*4 BLACK VG710 1
31 M-MS-0808-7882 52.62707.001 SPONGE 8.0L*6.0W*8.0H VG712s 6
32 M-BK-0805-0020 61.61102.002 SHIELDING BRKT-INV TINEPLATE 0.3t VG710s INVERTER BRACKET 1
33 M-BK-0805-0021 61.62701.001 LCD BRKT SECC 1.0t VG710s PANEL BRACKET 1
34 M-BK-0805-0022 61.62702.001 SHIELDING BRKT-MB SECC 1.0t VG710s MB BRACKET 1
35 #N/A 51.62701.004 FRONT COVER ABS HB-CR VG712b 1
36 PL-BT-0706-0149 51.62704.001 SELECT BUTTON ABS HB-Cr VG710s 1
37 M-MS-0808-8973 51.62705.001 LED LENS PMMA VG710s 1
38 M-CV-0830-2630 51.62702.002 REAR COVER ABS HB-VS08 VG710b 1
39 M-BK-0805-0023 61.00042.001 LOCK BRKT+CAP SECC 0.8t 1
40 B-MB-0201-2734 80.62701.005 PCBA MAIN BD VG710 "GM5120 AU-EG01V0" MAIN BOARD 1
41 #N/A 00.58401.E01 BARE PCB L:4 MAIN BD GM5120/GM2120 1
42 #N/A 01.00034.501 RES RP 0 5% 1/4W CHIP #1206 R101 1

43 #N/A 01.00036.502 RES RP 0 5% 1/16W CHIP #0603;"TA-I TECHNOLO
44 #N/A 01.00039.501 RES RP 0 5% 1/10W CHIP #0805 R100,R105,R116,R117 4

PROTECTION FILM FOR
PANEL

COMESTIC STRIP
ADHESIVE

FRONT COVER

REAR COVER

C188,C30,R111,R33,R51,R54,
R6,R66,R67,R68,R85,R88,R95
,R98,

1

1

14

45 #N/A 01.10136.501 RES RP 100 5% 1/16W #0603 R110,R15,R16,R37,R38,R42 6

46 #N/A 01.10136.502 RES RP 100 5% 1/16W X4 V8V 8P SMD
47 #N/A 01.10216.501 RES RP 1K 1% 1/16W CHIP #0603 R55 1
48 #N/A 01.10236.501 RES RP 1K 5% 1/16W x4 V8V 8P SMD "PANAS RP3,RP4 2
49 #N/A 01.10236.502 RES RP 1K 5% 1/16W #0603;"TA-I TECHNOLOGY" R5,R75,R77 3
50 #N/A 01.10336.501 RES RP 10K 5% 1/16W x4 V8V 8P SMD "PANASO RP1,RP2 2

51 #N/A 01.10336.502 RES RP 10K 5% 1/16W CHIP #0603;"TA-I TECHNO
52 #N/A 01.10339.501 RES RP 10K 5% 1/10W CHIP #0805 R1,R2 2
53 #N/A 01.10436.501 RES RP 100K 5% 1/16W CHIP #0603 R10,R9 2
54 #N/A 01.20116.501 RES RP 200 1% 1/16W CHIP #0603 R7 1
55 #N/A 01.22036.501 RES RP 22 5% 1/16W CHIP #0603 R18,R20,R22 3

56 #N/A 01.22236.501 RES RP 2.2K 5% 1/16W CHIP #0603
57 #N/A 01.33036.501 RES RP 33 5% 1/16W x4 V8V 8P SMD "PANASON RP17 1

58 #N/A 01.33036.502 RES RP 33 5% 1/16W CHIP #0603;"TA-I TECHNOL

RP10,RP11,RP12,RP13,RP14,
RP15,RP16,RP5,RP6,RP7,RP8
,RP9

C17,R119,R12,R121,R17,R32,
R49,R50,R56,R57,R58,R59,R6
0,R61,R65,R69,R73

R34,R35,R43,R44,R47,R81,R8
2

R124,R125,R126,R40,R41,R52
,R53

ViewSonic Corporation Confidential

55

-

Do Not Copy VG712s/b

12

17

7

7

Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty

59 #N/A 01.33116.501 RES RP 330 1% 1/16W CHIP #0603 R28,R29,R3,R4,R8 5
60 #N/A 01.33336.501 RES RP 33K 5% 1/16W CHIP #0603 R80 1
61 #N/A 01.47236.501 RES RP 4.7K 5% 1/16W CHIP #0603 R13,R14 2
62 #N/A 01.56236.501 RES RP 5.6K 5% 1/16W CHIP #0603 R72 1
63 #N/A 01.68036.501 RES RP 68 5% 1/16W CHIP #0603 R45 1
64 #N/A 01.68336.501 RES RP 68K 5% 1/16W CHIP 0603 R76 1
65 #N/A 01.75016.501 RES RP 75 1% 1/16W CHIP #0603;"TA-I TECHNOL R24,R25,R26 3
66 #N/A 01.75116.501 RES RP 750 1% 1/16W CHIP #0603 R11 1
67 #N/A 01.78216.501 RES RP 7.87K 1% 1/16W CHIP #0603 R78,R79 2
68 #N/A 02.10075.402 CAP CE 10u 25V 20% 5*11mm 105 DEGREE C (PZ) C114,C121,C124 3

69 #N/A 02.10174.404 CAP CE 100u 20% 16V 6.3*11 RADIAL 105 degre
70 #N/A 02.10273.404 CAP CE 1000u 10V 20% 10*16mm 105℃ (HF) LOW C27 1
71 #N/A 02.10274.403 CAP CE 1000u 16V 20% 10*20mm 105℃ (HD) LOW C123,C5 2

72 #N/A 02.10547.102 CAP CC 100pF 5% 50V NPO #0603

73 #N/A 02.10747.101 CAP CC 0.01uF 10% 50V X7R #0603;"YCTC""TEAM

74 #N/A 02.10887.101 CAP CC 0.1uF +80%-20% 50V Y5V #0603; "YCTC"
75 #N/A 02.10987.101 CAP CC 1uF +80%-20% 16V Y5V #0603 C115,C116,C117 3
76 #N/A 02.12174.401 CAP CE 120µF 20% 16V LOW-ESR TYPE RC=405mA C1,C20 2

C100,C118,C12,C14,C174,C19
,C22,C25,C29,C32,C62,C77,C
9,C90

C102,C165,C166,C167,C168,C
186,C187,C89
C122,C163,C164,C41,C42,C43
,C44,C45,C46

C10,C101,C105,C108,C109,C1
1,C110,C111,C125,C126,C127
,C128,C129,C130,C131,C132,
C133,C134,C136,C137,C138,C
139,C140,C141,C143,C144,C1
45,C146,C147,C148,C149,C15
0,C151,C152,C153,C154,C155
,C156,C157,C158,C159,C16,C
161,C162,C169,C171,C172,C1
75,C176,C18,C180,C181,C182
,C183,C184,C2,C202,C203,C2
1,C23,C24,C26,
C28,C3,C33,C35,C37,C39,C40
,C48,C49,C57,C63,C64,C65,C
66,C67,C68,C69,C7,C70,C71,
C72,C73,C74,C78,C79,C8,C80
,C81,C82,C83,C84,C85,C86,C
87,C88,C91,C92,C93,C94,C95,
C96,C97,C98,C99

14

8

9

106

77 #N/A 02.22447.101 CAP CC 22pF 5% 50V NPO #0603; "YCTC","TEAM C192,C59,C60,C61,C75,C76 6
78 #N/A 02.33575.101 CAP CC 330pF 8P4C 20% 25V #1206 "INPAQ" CP13,CP14 2
79 #N/A 02.50347.101 CAP CC 5pF 5% 50V NPO X7R #0603 C103,C104 2
80 #N/A 03.00052.401 INDCTOR BEAD MLB-160808-0600A-N1 SMD ; "MAG L20,L21 2
81 #N/A 03.00072.401 EMI Bead MLB-201209-0300A-N1 L15,L17,L18,L19,L3 5
82 #N/A 03.00127.401 INDCTR BEAD #0805 100MHz 30R MLB201209-0030 R127,R128,R129 3
83 #N/A 03.15100.301 INDCTR CHOKE 150uH 20% 3A DIP A0060D1 "ARON L4 1
84 #N/A 03.22040.301 INDCTR CHOKE COIL 22u 10% 3A DIP A00601C2 " L1,L16,L5,L9 4
85 #N/A 07.14318.001 XTAL 14.318MHz HC-49S HALF SIZE "鴻星" X1 1
86 #N/A 08.2N390.402 TRNSTR NPN GENERAL MMBT3904LT1 SOT-23 "MO Q2,Q3 2
87 #N/A 08.2N390.603 TRANSTR PNP GENERAL PURPOSE 2N3906 SST3 "RO Q4 1
88 #N/A 09.1N414.802 DIODE RLS4148 / PMLL4148L SMD "PHILIPS" D13 1
89 #N/A 09.1N582.201 DIODE IN5822 SCHOTTKY RECTIFIER DO201AD D1 1
90 #N/A 09.DAN20.2K1 DIODE ARRAY DAN202K SMD; "ROHM" D2,D3 2
91 #N/A 11.035F1.301 CNNT F3P PWR JACK 2.54mm DIP 2DC-S005D100 JP2 1
92 #N/A 11.042M2.306 CNNT M 4P 2mm RT/LEAD TU2001WNR-04 "TYU" JP10 1
93 #N/A 11.059F2.014 CNNT PHONE JACK 5P ST/LEAD A71-5AYLT1 LIM JP9 1
94 #N/A 11.102M2.303 CNNT 10P 2.0mm TU2001WNR-10 RT/DIP;"TYU" JP3 1
95 #N/A 11.122M2.303 CNNT 12P 2.0mm TU2001WNR-12 RT/DIP;"TYU" JP7 1
96 #N/A 11.155F2.203 CNNT D-SUB 15P RT/LEAD BLUE PC99 VGA JP6 1

97 M-MS-0808-9904 11.299F2.211
98 #N/A 11.302M2.301 CNNT M 30P 2mm RT/LEAD P220-2*15-R ;"LCU" JP11 1
99 E-IC-0401-2771 20.24LC2.1A1 IC CMOS 24LC21A EEPROM 128*8 BIT 8SOIC U7,U8 2

100 #N/A 20.74LVC.141 IC CMOS 74LVC14 INNERT SCHMITT-TR 14SOIC ; U6 1
101 #N/A 20.AIC10.842 IC AIC1084:(TO252) 5A ADJUSTABLE REGULATOR U1,U3 2
102 #N/A 20.AN752.201 IC AUDIO AN7522 DUAL 3-W AMPLIFIER U12 1
103 #N/A 20.AP150.101 IC AP1501 5V SWITCHING REGULATOR SMD 150KHz U4 1
104 #N/A 20.GM512.001 IC GM5120 Dual-Interface SXGA 208P PQFP "GE U9 GM5120 1

CNNT DVI-I F 29P 1.91mm RT/LEAD HELM QH11121­CPQ "HELM"

JP5 1

ViewSonic Corporation Confidential

56

-

Do Not Copy VG712s/b

Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty

105 #N/A 20.SI230.4D1 IC NMOS SI2304DS VISHAY SOT-23 Q1 1
106 #N/A 20.THC63.LV1 IC THC63LVDM83A 85MHZ LVDS TSSOP U13,U14 2
107 #N/A 21.24LC1.601 IC EEPROM 24LC16B/SN M 2K*8 BIT IIC BUS 8SO U10 1
108 #N/A 22.62701.005 PROGRAMMED IC VG710 "GM5120 AU-EG01V0" 1
109 #N/A 21.Pm39L.V01 IC Pm39LV010 CMOS Flash memory 1Megabit(128 1
110 #N/A 39.62701.005 FW BIOS SOURCE CODE "GM5120 AU-EG01V0" 1
111 #N/A 35.00017.001 LABEL BIOS 13*11mm BLANK 1
112 #N/A 35.00018.001 LABEL BARCODE 13*26.5mm BLANK 2
113 #N/A 35.59907.001 LABEL SPEC ASIC 13*11mm BLANK For VIEWSONIC 1
114 #N/A 61.00039.001 EYELET BR f3*4.0 2
115 #N/A 61.59901.001 SHIELDING PLATE DVI T-PLATE 0.3t 1
116 B-CB-0206-0165 80.62702.001 PCBA CTRL BD VG710 CONTROL BOARD 1
117 #N/A 00.62701.A01 BARE PCB L:2 CTRL BD VG710 1
118 #N/A 09.LTL1B.ED1 DIODE LED 3mm Yellow/Green LTL-1BEDJ 1
119 #N/A 11.122M2.302 CNNT M 12P 2mm RT/LEAD P-220-2*6-R 1
120 #N/A 35.00016.001 LABEL BARCODE 6*38mm BLANK 1

121 #N/A 43.52102.002 SWITCH PUSH PT-002-B2 DC12V 50mA
122 M-MS-0808-6287 85.005AG.075 SCREW HEX I/O #4-40*H5*L7.5 Ni NYLOK 4
123 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 19
124 M-SCW-0824-6753 85.4A323.040 SCREW FLATE MECH M3*4 BLACK 2
125 M-SCW-0824-6756 85.TA123.080 SCREW CAP TAP M3*8 Ni 4
126 M-SCW-0824-6755 85.UA123.080 DOUBLE THREADS SCREW PAN TAP M3*8 Ni 3
127 M-CV-0830-2479 51.62706.002 BASE COVER ABS HB-VS08 VG710b BASE COVER 1
128 M-MS-0808-8955 51.62707.002 FRONT ARM ABS HB-VS08 VG710b FRONT ARM 1
129 M-MS-0808-8956 51.62708.002 REAR ARM ABS HB-VS08 VG710b REAR ARM 1
130 M-MS-0808-9645 52.62703.001 RUBBER FOOT 35*10*1.2t VG710 RUBBER FOOT 5
131 M-MS-0808-8960 61.62703.001 BASE PLATE SPCC-Zn 2.5t VG710s BASE PLATE 1
132 M-MS-0808-8961 61.62704.001 HINGE SPCC-Zn 2.0t VG710s HINGE 1
133 M-SCW-0824-6757 85.1F124.120 SCREW PAN MECH W/SF M4*12 Ni 4
134 M-SCW-0824-6754 85.4A524.080 SCREW FLAT MECH W/O M4*8 NYLOK 4
135 M-SCW-0824-6755 85.UA123.080 DOUBLE THREADS SCREW PAN TAP M3*8 Ni 1
136 M-SCW-0824-6872 85.YA123.070 SCREW FLAT TAP M3*7 Ni 4
137 M-LB-0813-1017 35.59906.001 LABEL 210*65mm BLANK FOR PALLET 0.063
138 #N/A 51.00069.001 PACKING STRAP 12MM*2000M*0.6MM 0.023
139 #N/A 51.00070.001 PE STRETCH FILM 500MM*1500M*0.02MM 3E-04
140 #N/A 51.00080.001 3 INCH TRANSPARENT ADHESIVE TAPE (600M) 0.002
141 #N/A 55.55103.001 CORNER BOARD 40*40*5*1050mm 0.063
142 #N/A 55.57202.001 CORNER BOARD 40*40*5*960mm 0.063
143 #N/A 55.58303.002 CORNER BOARD 40*40*5*2120mm VG700-1 0.125
144 #N/A 55.62702.001 COVER PALLET AB FLUTE 112.5*95*0.7cm FOR VG 0.031
145 #N/A 58.62701.001 WOOD PALLET 1125*950*130 VG710s 0.031
146 M-LB-0813-0706 35.58203.001 LABEL CARTON 76*76mm 1
147 A-CD-VG712B 36.62701.008 USER GUIDE+CD VG712b TCO'99 USER GUIDE 1
148 A-VC-0101-0261 42.59901.003 CABLE VGA 15P 1800mm 2*25mm CORE VGA CABLE 1
149 A-AU-0120-0032 42.59903.001 CABLE AUDIO 1.8M LM/BK/LM VX2000 AUDIO CABLE 1
150 M-MS-0808-9642 51.62710.001 PE BAG LDPE 450*700*0.07t W/HOLE VG710 PE BAG 1
151 P-BX-0601-1087 55.62701.005 CARTON AB-18 455*205*480(h) VG712b TCO99 CARTON 1
152 P-FM-0602-0818 56.62701.001 CUSHION R EPS VG710s CUSHION 1
153 P-FM-0602-0819 56.62702.001 CUSHION L EPS VG710s CUSHION 1

SW1,SW2,SW3,SW4,SW5,SW
5,SW7,SW8

8

ViewSonic Corporation Confidential

57

-

Do Not Copy VG712s/b

BOM LIST (VG712s-1)

ViewSonic Model Number: VLCDS23719
Rev: 1b

Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty

1 M-LB-0813-1016 35.00010.002 LABEL CAUTION HIGH VOLTAGE 25.4*19mm CAUTION LABEL 1
2 M-LB-0813-0736 35.58304.001 LABEL BARCODE 40*14 ViewSonic BARCODE LABEL 1
3 M-LB-0813-0781 35.61203.001 LABEL BAR CODE 50*25mm VP191 BARCODE LABEL 1
4 M-LB-0813-1044 35.62701.003 LABEL SPEC 120*50mm VG712s SPEC LABEL 1
5 M-MS-0808-8948 35.62704.001 ViewSonic AL-LOGO E015-016-1 ViewSonic 1
6 #N/A 39.62702.005 DDC RECODER VG712b AUO EG01 V0 1
7 A-AD-0114-0204 47.62701.001 ADAPTER IN100-240V 12V/3.33A;"LSE" 1

8 M-MS-0808-8952 51.58314.001

9 M-MS-0808-8116 51.58711.001 NAMEPLATE ELLIPSE ViewSonic NAMEPLATE 1
10 M-MS-0808-8969 51.62703.001 HINGE CAP ABS HB-VS06 VG710s HINGE CAP 1
11 M-MS-0808-8946 35.62702.001 BIRD LOGO AL E015-006 VG710s BIRD LOGO 1

12 M-MS-0808-8947 35.62703.001
13 M-MS-0808-8882 41.55601.001 EMI Tape (80773) 20*40mm 3
14 M-MS-0808-8949 41.58301.001 EMI TAPE 80773 25*75mm 1
15 M-MS-0808-8950 41.61603.001 EMI GASKET 773GT W6*H6.5*L30 1
16 M-WR-0828-0636 42.58301.001 W.A. 10/6P UL1007 #24 100mm VG700(INV) INVERTER WIRE 1

LCD PROTECT FILM 355*290*0.1t mm MYLAR
VG70

COSMETIC STRIP ADHESIVE CS-VS06
140*21*0.3t

PROTECTION FILM FOR
PANEL 1

COMESTIC STRIP
ADHESIVE 1

17 CB-00000213 42.62701.A01 W.A. 30P UL1007 #24 225mm VG710(COST)-CMO PANEL WIRE 1

18 M-WR-0828-6010 42.58303.001

19 B-SB-0221-0700 44.58402.002
20 M-LCD-0826-0256 48.62701.004 TFT LCD 17" AUO M170EG01 V.0 PANEL AUO M17EG01 V0 1
21 E-SK-0412-0080 49.62701.001 SPEAKER 3W FOR VG710 SPEAKER 1
22 M-MS-0808-8797 51.00014.002 FILAMENT TAPE 3M NO.8915 25mm*55M TAPE FOR WIRE 0.001
23 M-MS-0808-8239 51.59901.001 ACETATE TAPE W=20mm 3
24 M-MS-0808-8953 51.59907.001 WIRE MOUNT MC-03A "G&A" VX930 5
25 M-MS-0808-8750 51.61103.001 MYLAR ADHESIVEt=0.3mm VP171 INVERTER MYLAR 1
26 #N/A 51.62709.002 MYLAR ADHESIVE 150*45*0.25t VG710 1
27 M-MS-0808-9643 51.62711.003 PC 30*15*1.15tmm VG712 2
28 M-MS-0808-8972 52.62701.001 VESA RUBBER PAD D7.0*H4.5 VG710s 4
29 M-MS-0808-9644 52.62702.001 RUBBER SPACER 20*10*5.5mm 4
30 M-MS-0808-9646 52.62703.002 RUBBER 30*15*4 BLACK VG710 1
31 M-MS-0808-7882 52.62707.001 SPONGE 8.0L*6.0W*8.0H VG712s 6
32 M-BK-0805-0020 61.61102.002 SHIELDING BRKT-INV TINEPLATE 0.3t VG710s INVERTER BRACKET 1
33 M-BK-0805-0021 61.62701.001 LCD BRKT SECC 1.0t VG710s PANEL BRACKET 1
34 M-BK-0805-0022 61.62702.001 SHIELDING BRKT-MB SECC 1.0t VG710s MB BRACKET 1
35 C-FP-0301-1037 51.62701.003 FRONT COVER ABS HB-CR VG712s 1
36 PL-BT-0706-0149 51.62704.001 SELECT BUTTON ABS HB-Cr VG710s 1
37 M-MS-0808-8973 51.62705.001 LED LENS PMMA VG710s 1
38 C-BC-0302-0541 51.62702.001 REAR COVER ABS HB-VS06 VG710s 1
39 M-BK-0805-0023 61.00042.001 LOCK BRKT+CAP SECC 0.8t 1
40 B-MB-0201-2734 80.62701.005 PCBA MAIN BD VG710 "GM5120 AU-EG01V0" MAIN BOARD 1
41 #N/A 00.58401.E01 BARE PCB L:4 MAIN BD GM5120/GM2120 1
42 #N/A 01.00034.501 RES RP 0 5% 1/4W CHIP #1206 R101 1

43 #N/A 01.00036.502 RES RP 0 5% 1/16W CHIP #0603;"TA-I TECHNOLO
44 #N/A 01.00039.501 RES RP 0 5% 1/10W CHIP #0805 R100,R105,R116,R117 4

W.A. 12P UL1571 #28 260mm W/O CORE
SHARE(MB 1
PCBA INVERTER;EMAX FOR 17" AUO M170EG01
V0 INVERTER 1

FRONT COVER

REAR COVER

C188,C30,R111,R33,R51,R54,
R6,R66,R67,R68,R85,R88,R9
5,R98, 14

45 #N/A 01.10136.501 RES RP 100 5% 1/16W #0603 R110,R15,R16,R37,R38,R42 6

46 #N/A 01.10136.502 RES RP 100 5% 1/16W X4 V8V 8P SMD
47 #N/A 01.10216.501 RES RP 1K 1% 1/16W CHIP #0603 R55 1
48 #N/A 01.10236.501 RES RP 1K 5% 1/16W x4 V8V 8P SMD "PANAS RP3,RP4 2

49 #N/A 01.10236.502 RES RP 1K 5% 1/16W #0603;"TA-I TECHNOLOGY" R5,R75,R77 3

50 #N/A 01.10336.501 RES RP 10K 5% 1/16W x4 V8V 8P SMD "PANASO RP1,RP2 2

51 #N/A 01.10336.502 RES RP 10K 5% 1/16W CHIP #0603;"TA-I TECHNO
52 #N/A 01.10339.501 RES RP 10K 5% 1/10W CHIP #0805 R1,R2 2
53 #N/A 01.10436.501 RES RP 100K 5% 1/16W CHIP #0603 R10,R9 2
54 #N/A 01.20116.501 RES RP 200 1% 1/16W CHIP #0603 R7 1
55 #N/A 01.22036.501 RES RP 22 5% 1/16W CHIP #0603 R18,R20,R22 3

56 #N/A 01.22236.501 RES RP 2.2K 5% 1/16W CHIP #0603

57 #N/A 01.33036.501 RES RP 33 5% 1/16W x4 V8V 8P SMD "PANASON RP17 1

RP10,RP11,RP12,RP13,RP14,
RP15,RP16,RP5,RP6,RP7,RP
8,RP9 12

C17,R119,R12,R121,R17,R32,
R49,R50,R56,R57,R58,R59,R
60,R61,R65,R69,R73 17

R34,R35,R43,R44,R47,R81,R
82 7

ViewSonic Corporation Confidential

58

-

Do Not Copy VG712s/b

Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty

58 #N/A 01.33036.502 RES RP 33 5% 1/16W CHIP #0603;"TA-I TECHNOL
59 #N/A 01.33116.501 RES RP 330 1% 1/16W CHIP #0603 R28,R29,R3,R4,R8 5
60 #N/A 01.33336.501 RES RP 33K 5% 1/16W CHIP #0603 R80 1
61 #N/A 01.47236.501 RES RP 4.7K 5% 1/16W CHIP #0603 R13,R14 2
62 #N/A 01.56236.501 RES RP 5.6K 5% 1/16W CHIP #0603 R72 1
63 #N/A 01.68036.501 RES RP 68 5% 1/16W CHIP #0603 R45 1
64 #N/A 01.68336.501 RES RP 68K 5% 1/16W CHIP 0603 R76 1

65 #N/A 01.75016.501 RES RP 75 1% 1/16W CHIP #0603;"TA-I TECHNOL R24,R25,R26 3
66 #N/A 01.75116.501 RES RP 750 1% 1/16W CHIP #0603 R11 1
67 #N/A 01.78216.501 RES RP 7.87K 1% 1/16W CHIP #0603 R78,R79 2

R124,R125,R126,R40,R41,R5
2,R53 7

68 #N/A 02.10075.402 CAP CE 10u 25V 20% 5*11mm 105 DEGREE C (PZ) C114,C121,C124 3

69 #N/A 02.10174.404 CAP CE 100u 20% 16V 6.3*11 RADIAL 105 degre

70 #N/A 02.10273.404 CAP CE 1000u 10V 20% 10*16mm 105℃ (HF) LOW C27 1

71 #N/A 02.10274.403

72 #N/A 02.10547.102 CAP CC 100pF 5% 50V NPO #0603

73 #N/A 02.10747.101

74 #N/A 02.10887.101 CAP CC 0.1uF +80%-20% 50V Y5V #0603; "YCTC"
75 #N/A 02.10987.101 CAP CC 1uF +80%-20% 16V Y5V #0603 C115,C116,C117 3

76 #N/A 02.12174.401

CAP CE 1000u 16V 20% 10*20mm 105℃ (HD)
LOW C123,C5 2

CAP CC 0.01uF 10% 50V X7R
#0603;"YCTC""TEAM

CAP CE 120µF 20% 16V LOW-ESR TYPE
RC=405mA C1,C20 2

C100,C118,C12,C14,C174,C1
9,C22,C25,C29,C32,C62,C77,
C9,C90 14

C102,C165,C166,C167,C168,
C186,C187,C89 8
C122,C163,C164,C41,C42,C4
3,C44,C45,C46 9

C10,C101,C105,C108,C109,C
11,C110,C111,C125,C126,C1
27,C128,C129,C130,C131,C1
32,C133,C134,C136,C137,C1
38,C139,C140,C141,C143,C1
44,C145,C146,C147,C148,C1
49,C150,C151,C152,C153,C1
54,C155,C156,C157,C158,C1
59,C16,C161,C162,C169,C17
1,C172,C175,C176,C18,C180,
C181,C182,C183,C184,C2,C2
02,C203,C21,C23,C24,C26,
C28,C3,C33,C35,C37,C39,C4
0,C48,C49,C57,C63,C64,C65,
C66,C67,C68,C69,C7,C70,C7
1,C72,C73,C74,C78,C79,C8,C
80,C81,C82,C83,C84,C85,C86
,C87,C88,C91,C92,C93,C94,C
95,C96,C97,C98,C99

106

77 #N/A 02.22447.101 CAP CC 22pF 5% 50V NPO #0603; "YCTC","TEAM C192,C59,C60,C61,C75,C76 6
78 #N/A 02.33575.101 CAP CC 330pF 8P4C 20% 25V #1206 "INPAQ" CP13,CP14 2
79 #N/A 02.50347.101 CAP CC 5pF 5% 50V NPO X7R #0603 C103,C104 2

80 #N/A 03.00052.401
81 #N/A 03.00072.401 EMI Bead MLB-201209-0300A-N1 L15,L17,L18,L19,L3 5

82 #N/A 03.00127.401

83 #N/A 03.15100.301

84 #N/A 03.22040.301
85 #N/A 07.14318.001 XTAL 14.318MHz HC-49S HALF SIZE "鴻星" X1 1

86 #N/A 08.2N390.402

87 #N/A 08.2N390.603
88 #N/A 09.1N414.802 DIODE RLS4148 / PMLL4148L SMD "PHILIPS" D13 1

89 #N/A 09.1N582.201 DIODE IN5822 SCHOTTKY RECTIFIER DO201AD D1 1
90 #N/A 09.DAN20.2K1 DIODE ARRAY DAN202K SMD; "ROHM" D2,D3 2

91 #N/A 11.035F1.301 CNNT F3P PWR JACK 2.54mm DIP 2DC-S005D100 JP2 1

92 #N/A 11.042M2.306 CNNT M 4P 2mm RT/LEAD TU2001WNR-04 "TYU" JP10 1

93 #N/A 11.059F2.014

INDCTOR BEAD MLB-160808-0600A-N1 SMD ;
"MAG L20,L21 2

INDCTR BEAD #0805 100MHz 30R MLB201209­0030 R127,R128,R129 3
INDCTR CHOKE 150uH 20% 3A DIP A0060D1
"ARON L4 1
INDCTR CHOKE COIL 22u 10% 3A DIP A00601C2
" L1,L16,L5,L9 4

TRNSTR NPN GENERAL MMBT3904LT1 SOT-23
"MO Q2,Q3 2
TRANSTR PNP GENERAL PURPOSE 2N3906 SST3
"RO Q4 1

CNNT PHONE JACK 5P ST/LEAD A71-5AYLT1
LIME( JP9 1

ViewSonic Corporation Confidential

59

-

Do Not Copy VG712s/b

Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty

94 #N/A 11.102M2.303 CNNT 10P 2.0mm TU2001WNR-10 RT/DIP;"TYU" JP3 1
95 #N/A 11.122M2.303 CNNT 12P 2.0mm TU2001WNR-12 RT/DIP;"TYU" JP7 1
96 #N/A 11.155F2.203 CNNT D-SUB 15P RT/LEAD BLUE PC99 VGA JP6 1

97 M-MS-0808-9904 11.299F2.211
98 #N/A 11.302M2.301 CNNT M 30P 2mm RT/LEAD P220-2*15-R ;"LCU" JP11 1
99 E-IC-0401-2771 20.24LC2.1A1 IC CMOS 24LC21A EEPROM 128*8 BIT 8SOIC U7,U8 2

100 #N/A 20.74LVC.141

101 #N/A 20.AIC10.842
102 #N/A 20.AN752.201 IC AUDIO AN7522 DUAL 3-W AMPLIFIER U12 1

103 #N/A 20.AP150.101
104 #N/A 20.GM512.001 IC GM5120 Dual-Interface SXGA 208P PQFP "GE U9 GM5120 1
105 #N/A 20.SI230.4D1 IC NMOS SI2304DS VISHAY SOT-23 Q1 1
106 #N/A 20.THC63.LV1 IC THC63LVDM83A 85MHZ LVDS TSSOP U13,U14 2

107 #N/A 21.24LC1.601 IC EEPROM 24LC16B/SN M 2K*8 BIT IIC BUS 8SO U10 1

108 #N/A 22.62701.005 PROGRAMMED IC VG710 "GM5120 AU-EG01V0" 1

109 #N/A 21.Pm39L.V01 IC Pm39LV010 CMOS Flash memory 1Megabit(128 1
110 #N/A 39.62701.005 FW BIOS SOURCE CODE "GM5120 AU-EG01V0" 1
111 #N/A 35.00017.001 LABEL BIOS 13*11mm BLANK 1
112 #N/A 35.00018.001 LABEL BARCODE 13*26.5mm BLANK 2

113 #N/A 35.59907.001
114 #N/A 61.00039.001 EYELET BR f3*4.0 2
115 #N/A 61.59901.001 SHIELDING PLATE DVI T-PLATE 0.3t 1
116 B-CB-0206-0165 80.62702.001 PCBA CTRL BD VG710 CONTROL BOARD 1
117 #N/A 00.62701.A01 BARE PCB L:2 CTRL BD VG710 1
118 #N/A 09.LTL1B.ED1 DIODE LED 3mm Yellow/Green LTL-1BEDJ 1
119 #N/A 11.122M2.302 CNNT M 12P 2mm RT/LEAD P-220-2*6-R 1
120 #N/A 35.00016.001 LABEL BARCODE 6*38mm BLANK 1

121 #N/A 43.52102.002 SWITCH PUSH PT-002-B2 DC12V 50mA
122 M-MS-0808-6287 85.005AG.075 SCREW HEX I/O #4-40*H5*L7.5 Ni NYLOK 4
123 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 19
124 M-SCW-0824-6753 85.4A323.040 SCREW FLATE MECH M3*4 BLACK 2
125 M-SCW-0824-6756 85.TA123.080 SCREW CAP TAP M3*8 Ni 4
126 M-SCW-0824-6755 85.UA123.080 DOUBLE THREADS SCREW PAN TAP M3*8 Ni 3
127 M-CV-0830-2480 51.62706.001 BASE COVER ABS HB-VS06 VG710s BASE COVER 1
128 M-MS-0808-8970 51.62707.001 FRONT ARM ABS HB-VS06 VG710s FRONT ARM 1
129 M-MS-0808-8971 51.62708.001 REAR ARM ABS HB-VS06 VG710s REAR ARM 1
130 M-MS-0808-9645 52.62703.001 RUBBER FOOT 35*10*1.2t VG710 RUBBER FOOT 5
131 M-MS-0808-8960 61.62703.001 BASE PLATE SPCC-Zn 2.5t VG710s BASE PLATE 1
132 M-MS-0808-8961 61.62704.001 HINGE SPCC-Zn 2.0t VG710s HINGE 1
133 M-SCW-0824-6757 85.1F124.120 SCREW PAN MECH W/SF M4*12 Ni 4
134 M-SCW-0824-6754 85.4A524.080 SCREW FLAT MECH W/O M4*8 NYLOK 4
135 M-SCW-0824-6755 85.UA123.080 DOUBLE THREADS SCREW PAN TAP M3*8 Ni 1
136 M-SCW-0824-6872 85.YA123.070 SCREW FLAT TAP M3*7 Ni 4
137 M-LB-0813-1017 35.59906.001 LABEL 210*65mm BLANK FOR PALLET 0.063
138 #N/A 51.00069.001 PACKING STRAP 12MM*2000M*0.6MM 0.023
139 #N/A 51.00070.001 PE STRETCH FILM 500MM*1500M*0.02MM 3E-04

CNNT DVI-I F 29P 1.91mm RT/LEAD HELM
QH11121-CPQ "HELM" JP5 1

IC CMOS 74LVC14 INNERT SCHMITT-TR 14SOIC
; U6 1
IC AIC1084:(TO252) 5A ADJUSTABLE
REGULATOR U1,U3 2

IC AP1501 5V SWITCHING REGULATOR SMD
150KHz U4 1

LABEL SPEC ASIC 13*11mm BLANK For
VIEWSONIC 1

SW1,SW2,SW3,SW4,SW5,S
W5,SW7,SW8 8

140 #N/A 51.00080.001 3 INCH TRANSPARENT ADHESIVE TAPE (600M) 0.002
141 #N/A 55.55103.001 CORNER BOARD 40*40*5*1050mm 0.063
142 #N/A 55.57202.001 CORNER BOARD 40*40*5*960mm 0.063
143 #N/A 55.58303.002 CORNER BOARD 40*40*5*2120mm VG700-1 0.125

144 #N/A 55.62702.001
145 #N/A 58.62701.001 WOOD PALLET 1125*950*130 VG710s 0.031
146 M-LB-0813-0706 35.58203.001 LABEL CARTON 76*76mm 1
147 A-CD-VG712S 36.62701.007 USER GUIDE+CD VG712s TCO'03 USER GUIDE 1
148 A-VC-0101-0261 42.59901.003 CABLE VGA 15P 1800mm 2*25mm CORE VGA CABLE 1
149 A-AU-0120-0032 42.59903.001 CABLE AUDIO 1.8M LM/BK/LM VX2000 AUDIO CABLE 1
150 M-MS-0808-9642 51.62710.001 PE BAG LDPE 450*700*0.07t W/HOLE VG710 PE BAG 1
151 P-BX-0601-0991 55.62701.003 CARTON AB-18 455*205*480(h) VG712s CARTON 1
152 P-FM-0602-0818 56.62701.001 CUSHION R EPS VG710s CUSHION 1
153 P-FM-0602-0819 56.62702.001 CUSHION L EPS VG710s CUSHION 1

COVER PALLET AB FLUTE 112.5*95*0.7cm FOR
VG 0.031

ViewSonic Corporation Confidential

60

-

Do Not Copy VG712s/b

8. Exploded Diagram And Spare Parts List

ViewSonic Corporation Confidential

61

-

Do Not Copy VG712s/b

EXPLODED PARTS LIST (VG712b-1)

ViewSonic Model Number: VLCDS23719
Rev: 1a

Item ViewSonic P/N Ref. P/N Description Q'ty

1 M-MS-0808-8973 51.62705.001 LED LENS PMMA VG710s 1
2 M-MS-0808-8948 35.62704.001 ViewSonic AL-LOGO E015-016-1 ViewSonic 1
3 PL-BT-0706-0149 51.62704.001 SELECT BUTTON ABS HB-Cr VG710s 1
4 B-CB-0206-0165 80.62702.001 PCBA CTRL BD VG710 1
5 E-SK-0412-0080 49.62701.001 SPEAKER 3W FOR VG710 1
6 M-SCW-0824-6756 85.TA123.080 SCREW CAP TAP M3*8 Ni 4
7 M-MS-0808-8946 35.62702.001 BIRD LOGO AL E015-006 VG710s 1
8 C-00000212 51.62701.004 FRONT COVER ABS HB-CR VG712b 1

9 M-LCD-0826-0256 48.62701.004 TFT LCD 17" AUO M170EG01 V.0 1
10 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 4
11 M-BK-0805-0021 61.62701.001 LCD BRKT SECC 1.0t VG710s 1
12 M-MS-0808-6287 85.005AG.075 SCREW HEX I/O #4-40*H5*L7.5 Ni NYLOK 4
13 M-MS-0808-8953 51.59907.001 WIRE MOUNT MC-03A "G&A" VX930 5
14 B-SB-0221-0700 44.58402.002 PCBA INVERTER;EMAX FOR 17" AUO M170EG01 V0 1
15 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 2
16 B-MB-0201-2734 80.62701.005 PCBA MAIN BD VG710 "GM5120 AU-EG01V0" 1
17 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 3
18 M-MS-0808-8750 51.61103.001 MYLAR ADHESIVEt=0.3mm VP171 1
19 M-BK-0805-0022 61.62702.001 SHIELDING BRKT-MB SECC 1.0t VG710s 1
20 M-BK-0805-0020 61.61102.002 SHIELDING BRKT-INV TINEPLATE 0.3t VG710s 1
21 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 5
22 M-SCW-0824-6753 85.4A323.040 SCREW FLATE MECH M3*4 BLACK 2
23 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 3
24 M-MS-0808-8949 41.58301.001 EMI TAPE 80773 25*75mm 1
25 M-BK-0805-0023 61.00042.001 LOCK BRKT+CAP SECC 0.8t 1
26 M-CV-0830-2630 51.62702.002 REAR COVER ABS HB-VS08 VG710b 1
27 M-MS-0808-8959 52.62701.002 VESA RUBBER PAD D7.0*H4.5 VG710b 4
28 M-MS-0808-8955 51.62707.002 FRONT ARM ABS HB-VS08 VG710b 1
29 M-MS-0808-8961 61.62704.001 HINGE SPCC-Zn 2.0t VG710s 1
30 M-MS-0808-8956 51.62708.002 REAR ARM ABS HB-VS08 VG710b 1
31 M-SCW-0824-6757 85.1F124.120 SCREW PAN MECH W/SF M4*12 Ni 4
32 M-MS-0808-8954 51.62703.002 HINGE CAP ABS HB-VS08 VG710b 1
33 M-MS-0808-8299 51.58711.002 NAMEPLATE ELLIPSE CS-VS08 ViewSonic 1
34 M-SCW-0824-6755 85.UA123.080 DOUBLE THREADS SCREW PAN TAP M3*8 Ni 1
35 M-CV-0830-2479 51.62706.002 BASE COVER ABS HB-VS08 VG710b 1
36 M-MS-0808-8960 61.62703.001 BASE PLATE SPCC-Zn 2.5t VG710s 1
37 M-MS-0808-9645 52.62703.001 RUBBER FOOT 35*10*1.2t VG710 5
38 M-SCW-0824-6754 85.4A524.080 SCREW FLAT MECH W/O M4*8 NYLOK 4
39 M-SCW-0824-6872 85.YA123.070 SCREW FLAT TAP M3*7 Ni 4
40 M-MS-0808-9646 52.62703.002 RUBBER 30*15*4 BLACK VG710 1
41 M-MS-0808-9644 52.62702.001 RUBBER SPACER 20*10*5.5mm 4
42 M-MS-0808-7882 52.62707.001 SPONGE 8.0L*6.0W*8.0H VG712s 6
43 CB-00000213 42.62701.A01 W.A. 30P UL1007 #24 225mm VG710(COST)-CMO 1
44 M-WR-0828-6010 42.58303.001 W.A. 12P UL1571 #28 260mm W/O CORE SHARE(MB 1
45 M-WR-0828-0636 42.58301.001 W.A. 10/6P UL1007 #24 100mm VG700(INV) 1

ViewSonic Corporation Confidential

62

-

Do Not Copy VG712s/b

ViewSonic Model Number: VLCDS23719

Rev 1b

Item ViewSonic P/N Ref. P/N Description Q'ty

1 M-MS-0808-8973 51.62705.001 LED LENS PMMA VG710s 1

2 M-MS-0808-8948 35.62704.001 ViewSonic AL-LOGO E015-016-1 ViewSonic 1

3 PL-BT-0706-0149 51.62704.001 SELECT BUTTON ABS HB-Cr VG710s 1

4 B-CB-0206-0165 80.62702.001 PCBA CTRL BD VG710 1

5 E-SK-0412-0080 49.62701.001 SPEAKER 3W FOR VG710 1

6 M-SCW-0824-6756 85.TA123.080 SCREW CAP TAP M3*8 Ni 4

7 M-MS-0808-8946 35.62702.001 BIRD LOGO AL E015-006 VG710s 1

8 C-FP-0301-1037 51.62701.003 FRONT COVER ABS HB-CR VG712s 1

9 M-LCD-0826-0256 48.62701.004 TFT LCD 17" AUO M170EG01 V.0 1
10 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 4
11 M-BK-0805-0021 61.62701.001 LCD BRKT SECC 1.0t VG710s 1
12 M-MS-0808-6287 85.005AG.075 SCREW HEX I/O #4-40*H5*L7.5 Ni NYLOK 4
13 M-MS-0808-8953 51.59907.001 WIRE MOUNT MC-03A "G&A" VX930 5
14 B-SB-0221-0700 44.58402.002 PCBA INVERTER;EMAX FOR 17" AUO M170EG01 V0 1
15 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 2
16 B-MB-0201-2734 80.62701.005 PCBA MAIN BD VG710 "GM5120 AU-EG01V0" 1
17 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 3
18 M-MS-0808-8750 51.61103.001 MYLAR ADHESIVEt=0.3mm VP171 1
19 M-BK-0805-0022 61.62702.001 SHIELDING BRKT-MB SECC 1.0t VG710s 1
20 M-BK-0805-0020 61.61102.002 SHIELDING BRKT-INV TINEPLATE 0.3t VG710s 1
21 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 5
22 M-SCW-0824-6753 85.4A323.040 SCREW FLATE MECH M3*4 BLACK 2
23 M-SCW-0824-0651 85.1F123.060 SCREW PAN MECH W/SF M3*6 Ni 3
24 M-MS-0808-8949 41.58301.001 EMI TAPE 80773 25*75mm 1
25 M-BK-0805-0023 61.00042.001 LOCK BRKT+CAP SECC 0.8t 1
26 C-BC-0302-0541 51.62702.001 REAR COVER ABS HB-VS06 VG710s 1
27 M-MS-0808-8972 52.62701.001 VESA RUBBER PAD D7.0*H4.5 VG710s 4
28 M-MS-0808-8970 51.62707.001 FRONT ARM ABS HB-VS06 VG710s 1
29 M-MS-0808-8961 61.62704.001 HINGE SPCC-Zn 2.0t VG710s 1
30 M-MS-0808-8971 51.62708.001 REAR ARM ABS HB-VS06 VG710s 1
31 M-SCW-0824-6757 85.1F124.120 SCREW PAN MECH W/SF M4*12 Ni 4
32 M-MS-0808-8969 51.62703.001 HINGE CAP ABS HB-VS06 VG710s 1
33 M-MS-0808-8116 51.58711.001 NAMEPLATE ELLIPSE ViewSonic 1
34 M-SCW-0824-6755 85.UA123.080 DOUBLE THREADS SCREW PAN TAP M3*8 Ni 1
35 M-CV-0830-2480 51.62706.001 BASE COVER ABS HB-VS06 VG710s 1
36 M-MS-0808-8960 61.62703.001 BASE PLATE SPCC-Zn 2.5t VG710s 1
37 M-MS-0808-9645 52.62703.001 RUBBER FOOT 35*10*1.2t VG710 5
38 M-SCW-0824-6754 85.4A524.080 SCREW FLAT MECH W/O M4*8 NYLOK 4
39 M-SCW-0824-6872 85.YA123.070 SCREW FLAT TAP M3*7 Ni 4
40 M-MS-0808-9646 52.62703.002 RUBBER 30*15*4 BLACK VG710 1
41 M-MS-0808-9644 52.62702.001 RUBBER SPACER 20*10*5.5mm 4
42 M-MS-0808-7882 52.62707.001 SPONGE 8.0L*6.0W*8.0H VG712s 6
43 CB-00000213 42.62701.A01 W.A. 30P UL1007 #24 225mm VG710(COST)-CMO 1
44 M-WR-0828-6010 42.58303.001 W.A. 12P UL1571 #28 260mm W/O CORE SHARE(MB 1
45 M-WR-0828-0636 42.58301.001 W.A. 10/6P UL1007 #24 100mm VG700(INV) 1

EXPLODED PARTS LIST (VG712s-1)

ViewSonic Corporation Confidential

63

-

Do Not Copy VG712s/b

Packing for shipping

ViewSonic Corporation Confidential

64

-

Do Not Copy VG712s/b

VG712s-1 PPL

Item ViewSonic P/N Ref. P/N Description Q'ty

1 P-FM-0602-0819 56.62702.001 CUSHION L EPS VG710s 1
2 A-VC-0101-0261 42.59901.003 CABLE VGA 15P 1800mm 2*25mm CORE 1
3 A-AU-0120-0032 42.59903.001 CABLE AUDIO 1.8M LM/BK/LM VX2000 1
4 A-AD-0114-0204 47.62701.001 ADAPTER IN100-240V 12V/3.33A;"LSE" 1
5 M-MS-0808-9642 51.62710.001 PE BAG LDPE 450*700*0.07t W/HOLE VG710 1
6 E-00000214 DC.62701.013 D.C. VG712b;AUO TWO-TONE TCO99 1
7 M-LB-0830-0733 35.62701.005 LABEL SPEC 120*50mm VG712b TCO99 1
8 M-LB-0813-0736 35.58304.001 LABEL BARCODE 40*14 ViewSonic 1

9 A-CD-VG712B 36.62701.008 USER GUIDE+CD VG712b TCO'99 1
10 A-PC-0106-0270 42.57207.001 CABLE POWER CORD 1.8M±0.1M UNSHIELD (NA) 1
11 P-FM-0602-0818 56.62701.001 CUSHION R EPS VG710s 1
12 P-BX-0601-1087 55.62701.005 CARTON AB-18 455*205*480(h) VG712b TCO99 1

A/D BUS

FLASH MEMO RY

Pm39LV010R

VG712s/b

DVI

INPUT

D_SUB

INPUT

DDC_IIC

TMDS

R/G/B

HS/VS

DDC_IIC

Audio

Jack

DDC

EEPROM

DDC

EEPROM

XTAL

14.318MH z

ASIC

GM512 0

RA/GA/BA[0~7]

DVS/DHS/DEN/DCLK

RB/GB/BB[0~7]

SCL
SDA

VOLUME

MUTE

EEPROM

24LC16B

LVDS

LVDS Singal

BLON

AUDIO

OUTPUT

PANEL

LG 17"

AUO 17"

VLVH

INVERTER

R
16 ohm

L
16 ohm

Do Not Copy

-

65

AC (110-240V)

9. Block Diagram

(50-60Hz)

ADAPTER

+12V

DPMS

+12V
+12VIN
+5V
+3.3VD
+3.3VA
+2.5V

Title

Size Document Number Rev

Date: Sheet

BLOCK DIAGRAM

GM5120

7 7Thursday, July 10, 2003

of

E

ViewSonic Corporation Confidential

10. Schematic Diagrams

C1

120uF/16V

R100 0
R101 0
R102 0/NC
R116 0

C146

0.1uF

+3.3VD

L3

NC

C24

0.1uF

(GM5120)

(GM5120)

(GM5120)

6

+2.5VD

C12

100uF/16V

+3.3VA

+3.3VD

C25

100uF/16V

E

U1

C16

0.1u

C23

0.1uF

+3.3VD

+3.3VA

C10

0.1uF

AIC1084

3 1

VIN VOUT

GND

2

U2
XC6201

3 1

VI VO

GND

2

U3
AIC1084

3 1

VIN VOUT

3.3V_MAIN MAX 5A

L8 BEAD 0805

C149

0.1uF

L10 BEAD /0805

C151

0.1uF

L12 BEAD /1206

C153

0.1uF
L14 BEAD /0805

C155

0.1uF

POWER

GM5120

R3

R4

C19

100uF/16V

R7

200/1%

R8

330/1%

3.3V_DVDD

C148

0.1uF

3.3V_AVDD

C150

0.1uF

2.5V_VDD

C152

0.1uF

2.5V_AVDD

C154

0.1uF

1

C11

0.1uF

of

330/1%

330/1%

C18

0.1u

GND

2

+12V

C5

1000uF/16V

+5VIN

C27

1000uF/10V

Power MOSN
NMos

R10
100K

+12VIN

R5

C178
NC/100pF

L6 22uH

R11
750R

1K

C34

1000uF/10V

R1

10K

10K

C14

C13

100uF/16V

NC/0.1uF

BLON3

+5V

C29

C28

100uF/16V

0.1uF

VPL

C35

C147

0.1uF

0.1uF

0.1uF

Volume-

C8

0.1uF

R6 0

C177
NC/100pF

R131 1k

+5V

R132
100K

C7

R2

JP1CIRDIN_4-R

0.1uF

1
2

+12V

C20

120uF/16V

LESR

L7 NC

L9 22uH

L11 NC

1 2

3 4

+12V

C172

0.1uF

+3.3VD

14

1 2
7

56789

+12V

C179

0.1uF

C171

0.1uF

1 2

C21

0.1uF

C30

C32

100uF/16V

U6A
74LVC14

R112
10K /NC

C140

0.1uF

+12V

C180

0.1uF

JP15

1
2
3
4

4 HEADER

U4 AP1501

+VIN VOUT

S.S

GND

5V_MAIN=2.5A

5

3

0

C33

0.1uF

R12
10K

C181

0.1uF

VOS

C31
NC/0.1uF

C36
NC/0.1uF

C38
NC/0.1uF

C182

0.1uF

4

D1

IN5822

1

Q2
2N3904

C2

0.1uF

+12V

PNL_EN3

C39

0.1uF

JP2

BNC-2

L5 22uH

+5V

+12V+3.3VD

C145

0.1uF

C141

0.1uF

3

C144

C3

0.1uF

C183

0.1uF

L4 150uH

+12V

3
2

R9
100K

C4
120uF/16V

C184

0.1uF

1
2
3
4

L1 22uH

BRIGHT3

D

23

SOT

G

132

U5

NC
S
S
G

IRF7204

C37

0.1uF

C26

0.1uF

Q1
SI2302DS

N

MOSN

S

8

D

7

D

6

D

5

D

BRI

ON

C17
NC/0.1uF

1

Q6
2N3904

C17

NC/0.1uF

+12V

+5VIN

R133
100K

3
2

R114
NC

R113
NC

+5V

D

SOT

G

132

Power MOSN
NMos

+5V

JP3

1
2
3
4
5
6
7
8
9
10
11
12
13
14

HEADER 10-2.0

+5V

+5V

Q5
SI2302DS

N

23

MOSN

S

C205

100uF/10V

5V

C204

0.1uF

JP13

1

2

2 HEADER

C9

100uF/16V

C15

100uF/16V

C22

100uF/16V

+2.5VD

Title

Size Document Number Rev

Date: Sheet

Thursday, July 10, 2003

ViewSonic Corporation Confidential - Do Not Copy

66

VG712s/b

JP5

DVI Connector

DVI-I

1

RX2-

2

RX2+

3

GND

4

RX4-

5

RX4+

6

SCL

7

SDA

8

VS

DVI_5V

9

RX1-

10

RX1+

11

GND

12

RX3-

13

RX3+

14

5V

15

GND

16

HP

17

RX0-

18

RX0+

19

GND

20

RX5-

21

RX5+

22

GND

23

RXC+

24

RXC-

25

RIN

26

GIN

27

BIN

28

HS

29

GND

+5V

C194

0.1u

ISP_SD SDA_IN2

RIN
GIN
BIN

NC
GND
GND
GND
GND

5V
GND

NC

SDA

HS

VS

SCL

R123 0

R122 0

C195

0.1u

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

C196

0.1u

DSUB_5V

D_SUBJP6

ISP_SC

R108 0 /NC
R109 0 /NC

HOT_PLUG

DVI_5V

RIN

GIN

BIN

ISP_SD

SCL_IN2ISP_SC

SCL_IN1
SDA_IN1

R17 10K

C190

0.1u /NC

SDA_IN2
HS_DSUB

R33 0

VS_DSUB

R36 100/NC

SCL_IN2

RX2- 3
RX2+ 3

ISP_SDA 3
ISP_SCL 3

RX1- 3
RX1+ 3

RX0- 3
RX0+ 3

RXC+ 3
RXC- 3

C189

0.1u /NC

R127

R128

R129 Bead 30R

ISP_SDA 3

ISP_SCL 3

R15 100

R16 100

Bead 30R

Bead 30R

3.3V_DVDD

DSUB

R32
10K

8

RP2
10K

1

RP3 1K

4
3
2
1

RP4 1K

4
3
2
1

R31

NC

+5V

MUTE
MENU
SELECT
VOLUME+
DOWN
UP
VOLUME­PWR_SW
LEDG
LEDR
DVI_5V
DSUB

MUTE 3
MENU 3
SELECT 3
VOLUME+ 3
DOWN 3
UP 3
VOLUME- 3
PWR_SW 3
LEDG 3
LEDR 3
DVI_5V 3
DSUB 3

+5V

C202

0.1u

5
6
7
8
5
6
7
8

8

1

2 7

3 6

8

CP13

0.1uF

4 5

CP14

0.1uF

1

2 7

3 6

4 5

R28 100R
R29 100R

MENU
SELECT
VOLUME+
DOWN
UP
VOLUME­PWR_SW

LEDG
LEDR

D2

C156

0.1u

VCCNC

WP
SCL
SDA

NCNCWP
GND

BAV70

SOT23

3

81
7
6
5

C40

0.1u

C41 0.01uF

C42 0.01uF
C43 0.01uF

C44 0.01uF
C45 0.01uF

C46 0.01uF

D3

SOT23

C158

0.1u

81

VCCNC

7
6

SCL

5

SDA

3

12

DDCSCL1
DDCSDA1

BAV70

C57

0.1uF

C157

0.1u

12

DDCSCL1 3
DDCSDA1 3

R27
NC

+5VDSUB_5V

C159

0.1u

R37 100

R38 100

RED+ 3

RED- 3
GREEN+ 3

GREEN- 3
BLUE+ 3

BLUE- 3

DDCSCL2
DDCSDA2

DDCSCL2

DDCSDA2

R68 0

R67 0

DDCSCL2 3
DDCSDA2 3

+5V +5V

567

KMUTE MUTE
KMENU
KSELECT
KVOLUME+
KDOWN

JP7

KUP
KVOLUME-

12

KLEDG

11

KLEDR

10

9

KPWR

8
7
6
5
4
3
2
1

(KEYPAD)

HEADER 12-2.0

UART_D1

UART_D0

8

432

1

C48

0.1uF

UART_D1 3

UART_D0

567

RP1
10K

432

C49

R30

0.1uF

NC

3

DVI_5V +5V

R14

R13

4.7K

4.7K

U7

2

NC

3

NC

4

GND

24LC21A

R26
75

R25
75

R24
75

R34

R35

4.7K

4.7K

R18 22

R124 56
R20 22

R125 56

R22 22

R126 56

U8

2
3
4

PCB2421A

R40 33

R41 33

R43

R44

2.2K

2.2K

ViewSonic Corporation Confidential - Do Not Copy

67

C59

C60
47pF

47pF

3 4

U6B
74LVC14

5 6

U6C
74LVC14

11 10

U6E
74LVC14

9 8

U6D
74LVC14

VG712s/b

R110

100

R42

100

C192
47pF

C61
47pF

VS 3

HS 3

Title

Size Document Number Rev

Date: Sheet

INPUT CONNECTOR

Thursday, July 10, 2003

GM5120

of

2

6

E

C62

100uF/16V

3.3V_AVDD

C77

100uF/16V

C90

100uF/16V

2.5V_AVDD 2.5V_AVDD

C100

100uF/16V

C105

0.1uF

2
3
4

3.3V_DVDD

10uF/16V /NC

U10

A1A2WP
GND

24LC16B

C109

0.1UF

C114

R118

NC

VCCA0

SCL

SDA

81
7
6
5

3.3V_DVDD

R69
100K

1UF/0805

C63

0.1uF

+5V

C112

C78

0.1uF

C91

0.1uF

C101

0.1uF

C64

0.1uF

C79

0.1uF

C92

0.1uF

C102
100pF

R119
10K

R59 10K
R60 10K
R103 10K /NC

R121 10K

R74

D13
1N4148

1 2

R52 33

R53 33

Q4
SST3906

R73
10K

0 /NC

C65

0.1uF

C80

0.1uF

C93

0.1uF

RMADDR14
RMADDR9
RMADDR8
RMADDR12

3.3V_DVDD2.5V_VDD

3.3V_DVDD3.3V_DVDD

C71

0.1uF

C86

0.1uF

2.5V_VDD2.5V_VDD

C99

0.1uF

C162

0.1uF

C72

0.1uF

C87

0.1uF

C161

0.1uF

R48 100 /NC
R111 0

3.3V_DVDD

R56
10K

C66

0.1uF

C81

0.1uF

C94

0.1uF

R49

R50

10K

10K

TP6

R72

5.6K

SCL
SDA

WP

C110

0.1UF

1

Q3
2N3904

0.1uF

C82

0.1uF

C95

0.1uF

3.3V_DVDD

0.1uF

C83

0.1uF

C96

0.1uF

SCL
SDA

R65
10K

3
2

C111

0.1UF

0.1uF

C84

0.1uF

C97

0.1uF

DVI_5V2
MUTE2

RESETn

0.1uF

C85

0.1uF

C98

0.1uF

C70

C69

C68

C67

C74

C73

0.1uF

0.1uF

3.3V_AVDD

C89

C88

0.1uF

3.3V_AVDD 3.3V_AVDD

R61

10K

100pF on pin-196

100pF

DQ7
DQ6
DQ5
DQ4
DQ3
DQ2
DQ1
DQ0

VCC
GND

ROM_CE

LVDSON6

RMDATA7

21

RMDATA6

20

RMDATA5

19

RMDATA4

18

RMDATA3

17

RMDATA2

15

RMDATA1

14

RMDATA0

13

3.3V_DVDD3.3V_DVDD

1

NC

32
16

3.3V_DVDD

C103
5pF

14.318MHz

3.3V_DVDD

RMADDR15
RMADDR14
RMADDR13
RMADDR12
RMADDR11
RMADDR10 RMADDR4
RMADDR9
RMADDR8
RMADDR7
RMADDR6
RMADDR5
RMADDR4
RMADDR3
RMADDR2
RMADDR1
RMADDR0

FLASH_OEn

X1

R57 10K

C104
5pF

R47

2.2K

R51
0

/WR

31
30

29
28

25
23
26
27

10
11
12

24
22

R62 0/NC

R66
0

R95 0

RMADDR[0..15]

U11

WE
NC/A17

2

A16

3

A15
A14
A13

4

A12
A11
A10
A9
A8

5

A7

6

A6

7

A5

8

A4

9

A3
A2
A1
A0

OE
CE

AT49HF/F010-45JC

PNL_EN1
BLON1

VOLUME+2
VOLUME-2

ISP_SDA2
ISP_SCL.2

DDCSCL12
DDCSDA12

RED+2
RED-2
GREEN+2
GREEN-2
BLUE+2
BLUE-2
HS2

VS2

RXC+2
RXC-2
RX2+2
RX2-2
RX1+2
RX1-2
RX0+2
RX0-2

C108

0.1uF

R46 0 /NC

RMDATA[0..7]

2.5V_AVDD

3.3V_AVDD

3.3V_AVDD

TCLK
XTAL

Bank0

RESETn

R55 1K

RMADDR15
RMADDR14
RMADDR13
RMADDR12
RMADDR11
RMADDR10
RMADDR9
RMADDR8

RMADDR7
RMADDR6
RMADDR5

RMADDR3
RMADDR2
RMADDR1
RMADDR0

RMDATA7
RMDATA6
RMDATA5
RMDATA4
RMDATA3
RMDATA2
RMDATA1
RMDATA0

ROM_OEn

1%

gm5120

PQFP208

U9

141

AVDD_DDDS

146

AVDD_SDDS

150

AVDD_RPLL

173

AVDD_IMB

181

AVDD_RX2

187

AVDD_RX1

193

AVDD_RX0

196

AVDD_RXC

164

AVDD_BLUE

168

AVDD_GREEN

172

AVDD_RED

160

AVDD_ADC

199

VDD_RXPLL_2.5

175

AGND_IMB

178

AGND_RX2

184

AGND_RX1

190

AGND_RX0

197

AGND_RXC

198

AGND_RXPLL

157

SGND_ADC

158

AGND_ADC

161

AGND_BLUE

165

AGND_GREEN

169

AGND_RED

149

AVSS_RPLL

145

AVSS_SDDS

140

AVSS_DDDS

113

PPWR

114

PBIAS

152

TCLK

151

XTAL

206

GPIO20

207

GPIO19

208

GPIO18

1

GPIO17

205

GPIO16/HFSn

204

GPIO22/HCLK

6

DDC_SCL

7

DDC_SDA

5

RESETn

50

GPIO11/ROM_WEn

171

RED+

170

RED-

167

GREEN+

166

GREEN-

163

BLUE+

162

BLUE-

137

HSYNC

136

VSYNC

159

ADC_TEST

194

RXC+

195

RXC-

179

RX2+

180

RX2-

185

RX1+

186

RX1-

191

RX0+

192

RX0-

174

REXT

8

ROM_ADDR15

9

ROM_ADDR14

10

ROM_ADDR13

11

ROM_ADDR12

12

ROM_ADDR11

13

ROM_ADDR10

14

ROM_ADDR9

15

ROM_ADDR8

16

ROM_ADDR7

17

ROM_ADDR6

18

ROM_ADDR5

19

ROM_ADDR4

22

ROM_ADDR3

23

ROM_ADDR2

24

ROM_ADDR1

25

ROM_ADDR0

28

ROM_DATA7

29

ROM_DATA6

30

ROM_DATA5

31

ROM_DATA4

32

ROM_DATA3

33

ROM_DATA2

34

ROM_DATA1

35

ROM_DATA0

36

ROM_OEn

155

153

176

VDD_RX2_2.5

VDD1_ADC_2.5

VDD2_ADC_2.5

3.3V_A

AGND

RVSS

RVSS

RVSS

RVSS

RVSS

3213854688298

203

182

188

VDD_RX1_2.5

VDD_RX0_2.5

RVSS

RVSS

RVSS

112

13089133

2688134

CVDD_2.5

CVDD_2.5

CVDD_2.5

RVSS

CVSS

27

CVDD_2.5

CVSS

CVSS

CVSS

135

148

144

139

VDD_DPLL_3.3

VDD_SDDS_3.3

VDD_DDDS_3.3

CVSS

GND1_ADC

202

156

154

22053678197111

37

RVDD

RVDD

RVDD

RVDD

RVDD

RVDD

GPIO10/TCON_ROE3

GPIO9/TCON_ROE2

GPIO4/UART_D1
GPIO5/UART_D0

GPIO13/NVRAM_SCL
GPIO12/NVRAM_SDA

GPIO8/IRQINn

GPIO7/TCON_TDIV

GPIO6/TCON_SHC

GPIO3/TIMER1

Int_Test

GND2_ADC

GND_RX2

GND_RX1

GND_RX0

VSS_DPLL

VSS_SDDS

177

183

189

147

143

138

129

RVDD

RVDD

RVDD

DCLK

PD47/OB7
PD46/OB6
PD45/OB5
PD44/OB4
PD43/OB3
PD42/OB2
PD41/OB1
PD40/OB0

PD39/OG7
PD38/OG6
PD37/OG5
PD36/OG4
PD35/OG3
PD34/OG2
PD33/OG1
PD32/OG0

PD31/OR7
PD30/OR6
PD29/OR5
PD28/OR4
PD27/OR3
PD26/OR2
PD25/OR1
PD24/OR0

PD23/EB7
PD22/EB6
PD21/EB5
PD20/EB4
PD19/EB3
PD18/EB2
PD17/EB1
PD16/EB0

PD15/EG7
PD14/EG6
PD13/EG5
PD12/EG4
PD11/EG3
PD10/EG2

PD9/EG1
PD8/EG0

PD7/ER7
PD6/ER6
PD5/ER5
PD4/ER4
PD3/ER3
PD2/ER2
PD1/ER1
PD0/ER0

GPO0
GPO1
GPO2
GPO3
GPO4
GPO5
GPO6
GPO7

TCON_RCLK

TCON_ROE

GPIO21/IRQn

GPIO2/PWM2
GPIO1/PWM1
GPIO0/PWM0

CLKOUT

Reserved
Reserved

VSS_DDDS

JP8

DEN
DHS
DVS

N/C
N/C

+5V 1
RXD 2
TXD 3
GND 4

118
115
116
117

110
109
108
107
106
105
104
103

102
101
100
99
96
95
94
93

92
91
90
87
86
85
84
83

80
79
78
77
76
75
74
73

72
71
70
69
66
65
64
63

62
61
60
59
58
57
56
55

119
120
121
122
123
124
125
126
127
49
48
128

44
45

52
51
39
4
47
46
43
42
41
40

201

200
142
132
131

R45 33

C75
22pF

DEN\
DHS\
DVS\

OB7
OB6
OB5
OB4
OB3
OB2
OB1
OB0

OG7
OG6
OG5
OG4
OG3
OG2
OG1
OG0

OR7
OR6
OR5
OR4
OR3
OR2
OR1
OR0

EB7
EB6
EB5
EB4
EB3
EB2
EB1
EB0

EG7
EG6
EG5
EG4
EG3
EG2
EG1
EG0

ER7
ER6
ER5
ER4
ER3
ER2
ER1
ER0

ROM_CE

R54 0
R120 NC

MENU 2
SELECT 2

UART_D1
UART_D0Bank0

SCL
SDA

DSUB 2
DOWN 2
UP 2
DDCSDA2 2
DDCSCL2 2
VOLUME 4
BRIGHT 1

+5V

UART_D0
UART_D1

Title

Size Document Number Rev

Date: Sheet

DCLK 6

C76
22pF

OB[0..7] 5

OG[0..7] 5

OR[0..7] 5

EB[0..7] 5

EG[0..7] 5

ER[0..7] 5

LEDR 2
LEDG 2

LVDSON 6
ADO_CTRL

4

Fujitsu_PD 6

WP

SCL
SDA

UART_D0 2

2

UART_D1

Gensis Chip (Scaler) ASIC

Thursday, July 10, 2003

TP2
TP4

GM5120

3.3V_DVDD

C106
NC

RP17 33

4
3
2
1

R58
10K

C107
NC

5
6
7
8

12736

45

8

PWR_SW 2

3

of

6

CP15

22p /NC

DEN 6
DHS 6

6

DVS

E

ViewSonic Corporation Confidential - Do Not Copy

68

VG712s

/b

+5V

U12
AN7522

C197

JP9

PHONEJACK

1
2
3
4
5

AAINR1

AAINL1

AUGND AUGN D AUGN D

R96 0
R97 0
R105 0

0.1u

C119

100pF /NC

L20 BEAD-600

L21 BEAD-600

C120

100pF /NC

+12V

R78 7.87K 1%

R79 7.87K 1%

C164

0.01uF

C185 0.1uF
C186 0.1uF
C187 0.1uF
C188 0.1uF

L16 22uH

C170

1000uF/16V

ADO_CTRL3

C163

0.01uF

ADORI N

ADOLIN

R81

2.2K

VDO_PWR

C122

0.01uF

R75 1K

C115 1uF

C116 1uF

R82

2.2K

C123

1000uF/16V

C121

10uF/16V

1234567891011

VOL

12

L15 BEAD

OUT_R+

L17 BEAD

OUT_R-

L18 BEAD

OUT_L+

L19 BEAD

OUT_L-

C117
1uF

R76 68K

R80
33K

C118
100uF/16V

R77 1K

JP10

1
2
3
4

4 HE ADER

VOLUME 3

AUGND

ViewSonic Corporation Confidential - Do Not Copy

AUGND

NC

69

AAINL1
AAINR1
OUT_R­OUT_L+

OUT_L­OUT_R+

VG712s/b

JP16

1
2
3
4
5
6
7
8

2*4 (BD/BD)F emale

Title

Size Document Number Rev

AUDIO

GM5120

Date: Sheet

Thursday, July 10, 2003

of

4

6

E

OB[0..7]3
OG[0..7]3
OR[0..7]3
EB[0..7]3
EG[0..7]3
ER[0..7]3

OB[0..7]
OG[0..7]
OR[0..7]
EB[0..7]
EG[0..7]
ER[0..7]

OB1
OB0
OB7
OB6

RP18

1 8
2 7
3 6
4 5

R-PACK4

OB7
OB6
OB5
OB4

RP5

1 8
2 7
3 6
4 5

100X4

DBO7
DBO6
DBO5
DBO4

DBO7
DBO6
DBO5
DBO4

12736

45

CP1

OR1
OR0

NC

8

OR7
OR6

OR7
OR6
OR5
OR4

RP22

1 8
2 7
3 6
4 5

R-PACK4

RP6

1 8
2 7
3 6
4 5

100X4

DRO7
DRO6
DRO5
DRO4

DRO7
DRO6
DRO5
DRO4

12736

45

CP2

EG1
EG0

NC

8

EG7
EG6

RP26

1 8
2 7
3 6
4 5

R-PACK4

EG7
EG6
EG5
EG4

RP7

1 8
2 7
3 6
4 5

100X4

DGE7
DGE6
DGE5
DGE4

DGE7
DGE6
DGE5
DGE4

12736

45

CP3

NC

8

DRO[0..7]
DGO[0..7]
DBO[0..7]
DRE[0..7]
DGE[0..7]
DBE[0..7]

DRO[0..7] 6
DGO[0..7] 6
DBO[0..7] 6
DRE[0..7] 6
DGE[0..7] 6
DBE[0..7] 6

OB5
OB4
OB3
OB2

Select LVDS MAPPIN G

EX:RP5~RP16 for 0,1,2,3,4,5,6,7
AUO 17",19" Samsung 17",19" CHI MEI 19"
Fujitsu 19"-10
EX:RP18~RP29 for 2,3,4,5,6,7,0,1
Fujitsu 19" FLC48SXC8V-05/-10

OG1
OG0
OG7
OG6

OG5
OG4
OG3
OG2

RP8

OB3

1 8

OB2

2 7

OB1

3 6

OB0

4 5

100X4

RP19

1 8
2 7
3 6
4 5

R-PACK4

RP20

1 8
2 7
3 6
4 5

R-PACK4

RP21

1 8
2 7
3 6
4 5

R-PACK4

DBO3
DBO2
DBO1
DBO0

RP11

OG7

1 8

OG6

2 7

OG5

3 6

OG4

4 5

100X4

DGO7
DGO6
DGO5
DGO4

OG3
OG2 DGO2
OG1
OG0

RP14

1 8
2 7
3 6
4 5

100X4

DGO3
DGO2
DGO1
DGO0

RP25

R-PACK4

RP9

1 8
2 7
3 6
4 5

100X4

DRO3
DRO2
DRO1
DRO0

RP12

1 8
2 7
3 6
4 5

100X4

DBE7
DBE6
DBE5
DBE4

RP15

1 8
2 7
3 6
4 5

100X4

DBE3
DBE2
DBE1
DBE0

DBO3
DBO2
DBO1
DBO0

12736

45

CP4

OR5

NC

8

12736

45

8

12736

45

8

OR4
OR3
OR2

DGO7
DGO6
DGO5 DRE5
DGO4

CP7

EB1
EB0

NC

EB7
EB6

DGO3
DGO1

DGO0

CP10

NC

EB5
EB4
EB3
EB2

OR3
OR2
OR1
OR0

RP23

1 8
2 7
3 6
4 5

R-PACK4

EB7
EB6
EB5
EB4

RP24

1 8
2 7
3 6
4 5

R-PACK4

EB3
EB2
EB1
EB0

1 8
2 7
3 6
4 5

DRO3
DRO2
DRO1
DRO0

12736

45

CP5

NC

DBE7
DBE6
DBE5
DBE4

CP8

NC

DBE3
DBE2
DBE1
DBE0

CP11

NC

ER1
ER0
ER7
ER6

EG5
EG4
EG3
EG2

ER5
ER4
ER3
ER2

8

12736

45

8

12736

45

8

RP27

1 8
2 7
3 6
4 5

R-PACK4

RP28

1 8
2 7
3 6
4 5

R-PACK4

RP29

1 8
2 7
3 6
4 5

R-PACK4

RP10

EG3

1 8

EG2

2 7

EG1

3 6

EG0

4 5

100X4

DGE3
DGE2
DGE1
DGE0

RP13

ER7

1 8

ER6

2 7

ER5

3 6

ER4

4 5

100X4

DRE7
DRE6
DRE5
DRE4

RP16

ER3

1 8

ER2 DRE2

2 7

ER1

3 6

ER0

4 5

100X4

DRE3
DRE2
DRE1
DRE0

DGE3
DGE2
DGE1
DGE0

12736

45

CP6

NC

8

DRE7
DRE6

DRE4

12736

45

CP9

NC

8

DRE3
DRE1

DRE0

12736

45

CP12

NC

8

ViewSonic Corporation Confidential - Do Not Copy

70

VG712s/b

Title

Size Document Number Rev

Date: Sheet

Thursday, July 10, 2003

OUTPUT INTERFACE

GM5120

of

5

6

E

10
11

12
13

14
15

16
17

18
19

20
21

22
23

24
25

26
27

28

10
11

12
13

14
15
16

17
18

19
20

21
22

23
24

25
26

27
28

C168
100pF

1
2

3
4

5
6

7
8

9

1
2

3
4

5
6

7
8

9

U13

VCC
TxIN5

TxIN6
TxIN7

GND
TxIN8

TxIN9
TxIN10

VCC
TxIN11

TxIN12
TxIN13

GND
TxIN14

TxIN15
TxIN16

VCC
TxIN17

TxIN18
TxIN19

GND
TxIN20

TxIN21
TxIN22

TxIN23
VCC

TxIN24
TxIN25

DS90CF383

U14

VCC
TxIN5

TxIN6
TxIN7

GND
TxIN8

TxIN9
TxIN10

VCC
TxIN11

TxIN12
TxIN13

GND
TxIN14

TxIN15
TxIN16

VCC
TxIN17

TxIN18
TxIN19

GND
TxIN20

TxIN21
TxIN22

TxIN23
VCC

TxIN24
TxIN25

DS90CF383

+3.3VL

C165
100pF

C166
100pF

TxIN4
TxIN3

TxIN2

GND

TxIN1
TxIN0

TxIN27

LVDSGND

TxOUT0-

TxOUT0+

TxOUT1-

TxOUT1+

LVDSVCC
LVDSGND

TxOUT2-

TxOUT2+

TxCLKOUT-

TxCLKOUT+

TxOUT3-

TxOUT3+

LVDSGND

PLLGND
PLLVCC

PLLGND

/PWRDWN

TxCLKIN

TxIN26

GND

LVDSON3

TxIN4
TxIN3

TxIN2

GND

TxIN1
TxIN0

TxIN27

LVDSGND

TxOUT0-

TxOUT0+

TxOUT1-

TxOUT1+

LVDSVCC
LVDSGND

TxOUT2-

TxOUT2+

TxCLKOUT-

TxCLKOUT+

TxOUT3-

TxOUT3+

LVDSGND

PLLGND
PLLVCC

PLLGND

/PWRDWN

TxCLKIN

TxIN26

GND

LVDSON3

For Fujitst Panel select Lvds mappin g

HEADER 30

Fujitsu_PD

+3.3VL

R84
10K

Vcont

R86
NC

JP12

4140

4140

42

39

42

39

43

38

43

38

44

37

44

JP11

30
29

28
27

26
25

24
23

22
21

20
19
18

17
16

15
14

13
12

11
10

9
8

7
6

5
4

3
2

1

DRE1
DRE3

DRE4
DRE6

DGE1
DGE3

DGE4
DGE6

DBE1
DBE3

DBE4
DBE6

DRO1
DRO3

DRO4
DRO6

DGO1
DGO3

DGO4
DGO6

DBO1
DBO3

DBO4
DBO6

DEN

37

45

36

45

36

35

46

35

46

34

47

34

47

33

48

33

48

32

49

32

49

31

50

31

50

30

51

30

51

29

52

29

52

28

53

28

53

27

54

27

54

26

55

26

55

25

56

25

56

24

57

24

57

23

58

23

58

22

59

22

59

21

60

21

60

20

61

20

61

19

62

19

62

18

63

18

63

17

64

17

64

16

65

16

65

15

66

15

66

14

67

14

67

13

68

13

68

12

69

12

69

11

70

11

70

10

71

10

71

9

72

9

72

8

73

8

73

7

74

7

74

6

75

6

75

5

76

5

76

4

77

4

77

3

78

3

78

2

79

2

79

1

80

1

80

Title

Size Document Number Rev

Date: Sheet

LVDS & OUTPUT CONNECTOR

Thursday, July 10, 2003

PLV1

GM5120

DRE0
DRE2

DRE5
DRE7

DGE0
DGE2

DGE5
DGE7

DBE0
DBE2

DBE5
DBE7

DRO0
DRO2

DRO5
DRO7

DGO0
DGO2

DGO5
DGO7

DBO0
DBO2

DBO5
DBO7

DHS
DVS

R89

4.7K

R90

4.7K

C135

0.1uF

6

C171

0.1uF

C172

0.1uF

of

6

C173

0.1uF

VPL

C170

100uF/16V

E

+3.3VD

Fujitsu_PD

C174

100uF/16V

L22

Bead /1206

C125

0.1uF

VPL

DEN

C169

0.1uF

RxEIN0­RxEIN0+
RxEIN1-

RxEIN1+
RxEIN2-

RxEIN2+
RxECLKIN-

RxECLKIN+
RxEIN3-

RxEIN3+
RxOIN0-

RxOIN0+

RxOIN1+
RxOIN2-

RxOIN2+
RxOCLKIN-

RxOCLKIN+
RxOIN3-

RxOIN3+
Vcont

Fujitsu_PD DCLKB

C136

C175

C176

0.1uF

0.1uF

0.1uF

R91

NC

R92

0R

+3.3VL

56
55

54
53

52
51

50
49

48
47

46
45
44

43
42

41
40

39
38

37
36

35
34

33
32

31
30

29

56
55

54
53

52
51

50
49

48
47

46
45

44
43

42
41

40
39

38
37

36
35

34
33

32
31

30
29

DRE4
DRE3

DRE2
DRE1

DRE0
DRE6

+3.3VL

C130 0.1uF

DCLKA
DEN

DRO4
DRO3

DRO2
DRO1

DRO0
DRO6

C134 0.1uF

C138 0.1uF

DCLKA
DEN

C128 0.1uF

+3.3VL

+3.3VL

+3.3VL

C203

0.1uF

RxEIN0­RxEIN0+

RxEIN1­RxEIN1+

RxEIN2­RxEIN2+

RxECLKIN­RxECLKIN+

RxEIN3­RxEIN3+

RxOIN0­RxOIN0+

RxOIN1­RxOIN1+

RxOIN2- RxOIN1­RxOIN2+

RxOCLKIN­RxOCLKIN+

RxOIN3­RxOIN3+

+C124

10uF/16V

DHS3
DVS3
DEN3

R98 0

DCLK3

DRO[0..7]5
DGO[0..7]5

DBO[0..7]5
DRE[0..7]5

DGE[0..7]5

DBE[0..7]5

DCLKA
DCLKB

R99

NC

+3.3VL

+3.3VL

+3.3VL

+3.3VL

+3.3VL

+3.3VL

+3.3VL

+3.3VL

C126

0.1uF

C127

0.1uF

C129

0.1uF
C131

0.1uF

C132

0.1uF

C133

0.1uF

C137

0.1uF
C139

0.1uF

R85 0R

DRE7
DRE5
DGE0

DGE1
DGE2
DGE6

DGE7
DGE3
DGE4

DGE5
DBE0

DBE6
DBE7

DBE1
DBE2

DBE3
DBE4

DBE5

DHS
DVS

R88 0R

DRO7
DRO5

DGO0
DGO1

DGO2
DGO6

DGO7
DGO3

DGO4
DGO5

DBO0
DBO6

DBO7
DBO1

DBO2
DBO3

DBO4
DBO5

DHS
DVS

+3.3VL

R83
NC

R87

NC

C167
100pF

ViewSonic Corporation Confidential - Do Not Copy

71

VG712s/b

11. PCB Layout Diagrams

ViewSonic Corporation Confidential

72

-

Do Not Copy VG712s/b

*Readers Response*

Dear Readers:

Thank you in advance for your feedback on our Service Manual,which allows continuous improvement

of our products. We would appreciate your completion of the Assessment Matrix below, for return to

ViewSonic Corporation.

Assessment

A.What do you think about the content after reading VG712s/b Service Manual?

1.

Precautions And Safety Notices

2. Specification

Front Panel Function Control Description

3.

4. Circuit Description

5.

Adjusting Procedure

6. Trouble Shooting Flow Chart

7. Recommended Spare Parts List

8. Exploded Diagram and Spare Parts List

9. Block Diagram

10. Schematic Diagrams

11. PCB Layout Diagrams

tinU riaF daB

B.Are you satisfied with the VG712s/b service manual?

metI tnellecxE dooG riaF daB

dooGtnellecxE

.1

Service Manual Content

.2

Service Manual Layout

.3

The form and listing

C.Do you have any other opinion or suggestion about this service manual?

Readers basic data:

Name: Title:
Company:

Add.:
Tel:
E-mail:

After completing this form, please return it to ViewSonic Quality Assurance

1-909-839-7943.
([e-mail])

You may also e-mail any suggestions to the Director, Quality Systems & Processes

Fax:

in the USA at facsimile

ViewSonic Corporation Confidential

73

-

Do Not Copy VG712s/b
