ViewSonic VG2227WM - 22"" LCD Monitor Specifications
VG2227wm
22" (21.5" VIEWABLE)
WIDESCREEN LCD
WITH HEIGHT ADJUST AND USB HUB
Multimedia performance for your business
The 22" (21.5" viewable) VG2227wm LCD is the widescreen,
multimedia solution for demanding business professionals.
Featuring Full HD 1920x1080 resolution and 20,000:1 dynamic
contrast ratio, this high performance display is ideal for graphics
professionals, high-def multimedia visuals and other digital content.
The fully adjustable ergonomic base lets you work comfortably
for hours. The DVI-D connector ensures your high-def content
stays high-def, while the USB ports expand your connectivity for
multitasking. The slim bezel design saves space, while the eco-
mode function conserves power and extends backlight life. Choose
the feature-packed, high-performance, widescreen VG2227wm for
business and home users who demand the best.
FULL HD 1080P PERFORMANCE
> Multi-functional base design (360° Swivel, Height adjustment)
VESA
®
wall-mount interface and detachable base for ergonomic
flexibility with height, tilt and 360° swivel adjustments.
> USB Hub
2-port USB hub provides easy connectivity for USB devices.
> Multimedia Enhanced
Stereo speakers provide clear and rich sound.
> Widescreen aspect ratio with 1920×1080 resolution
The widescreen aspect ratio allows you to view Full HD content in
its native format with no stretching or distortion.
> OptiSync
®
digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI) and
analog (VGA) signals for ultimate compatibility and configuration
flexibility.
> Stylish, slim-bezel with high-gloss piano black finish
> Eco mode
Environmentally-friendly Eco-mode reduces power consumption
and extends backlight life.
> Stylish slim-bezel design
An ultra-thin bezel lets you see more
without taking up valuable desktop
real estate.
DISPLAY Size 22" (21.6" viewable) wide Color TFT Active Matrix LCD
Display Area 18.8" (H) x 10.6 ( V)
Optimum Resolution 1920x1080
Brightness 300cd/m² (t yp.)
Contrast Ratio 1000:1 static (t yp.); 20,00 0:1 dynamic
Viewing Angle 170° (H), 160° (V) @ 10:1 contrast ratio
Response Time 5ms (typ.)
Pixel Pitch 0.248mm (H) x 0.248mm ( V)
Panel Surface Anti-Glare
Light Source 50,0 00 hrs. (typ.)
Color Suppor t 16.7 M (6-bits + HiFRC)
INPUT
Analog RGB Analog (75 ohms, 0.7 / 1.0 Vp-p)
Digital DVI-D ( TMDS, 100 ohms)
Sync H/V Separated
Frequency Fh: 24-82kHz, Fv: 50-75Hz
COMPATIB IL ITY PC VGA up to 1920x1080 non-Interlaced
Mac Power Mac, up to 1920x108 0
CONNECTOR Analog 15 pin mini D-sub
Digital DVI-D
Audio 3.5 mm audio in
Power Built-in power adapter, 3-pin plug
USB down stream x2 / up stream x1
AUDIO
Speaker 2x2-watt
POWER
Volt age AC 100-240V (Universal); 50/60Hz (Switch)
Consumption 43 (typ.)
ECO mode optimize 31W (typ.) / conser ve 25W (typ.)
Save mode
≦
1W
ERGONOMICS Tilt Down -15º, Up 20º
Swivel 360º
Height adjust 3 .1"
CONTROLS Basic Power, Mute, [1], Up[▲], Down[▼], [2]
OSD Auto Image Adjust, Contrast/Brightnes s, Audio adjus t:
Volume mute, Color Adjust: sRGB, 9300K, 7500K, 6500 K,
500 0K, User Color [R, G, B], Information, Manual Image
Adjust: Horizontal size, H/ V position, fine tune, sharpness,
dynamic contrast, aspect ratio, Eco mode, Setup Menu:
Language select, resolution notice, OSD position, OSD time
out, OSD background, Memory recall
OPERATING
CONDITIONS
Temperature 32
- 104˚F (0 - 40˚C)
Humidity 10 - 90% (non-condensing)
DIMENSIONS (WxHxD) Physical with stand 20.11"x13.5"x7.5" (510.9mmx412.02mmx230mm)
Physical without stand 20.11"x11.8"x2.48" (510.9mmx305.9mmx61.7mm)
Packaging 22.9"x19.6"x6.2" (582mmx500mmx160mm)
WEIGHT Net 12.9 lb. (4.83 kg)
Net (w/o stand) 10.2 lb. (3.83 kg)
Gross (w/o stand) 18.03 lb. (6.73 kg)
REGULATIONS
CB, TCO03,WEEE,ROHS UL /cUL, FCC-B, IRAM, NOM,
ERGO, CE, Ukraine, GOST-R+Hygienic ,SASO, BSMI, PSB,
C-TICK, KCC, CCC
VESA
®
WALL MOUNT 100mmx10 0mm
POWER MANAGEMENT TCO'03
RECYCLE/DISPOSAL
The lamp in this produc t contains meury. Please dispose of
in accordance with local, state or federal laws.
PACKAGE CONTENTS
LCD monitor, power cable, audio cable, USB cable, DVI
cable, VGA cable, Quick Start Guide, ViewSonic Wizard CDROM
WARRANTY Three-year limited warranty on parts, labor and backlight.
VG2227wm
22" (21.5" vIEWABlE) WIDEScrEEN lcD WITH HEIGHT ADJUST AND USB HUB
For more product information, visit us on the web at www.viewsonic.com
For more product information, visit us on the web at ViewSonic.com
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate
names, trademarks stated herein are the property of their respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved. [14924-01B-06/10] VG2227wm-1
