ViewSonic VA926 - 19"" LCD Monitor, VA926 Specification

VA926

19" VALUE SERIES LCD

WITH 5MS VIDEO RESPONSE

Budget savvy desktop
space saver.

ViewSonic’s 19" VA926 LCD is a brilliant choice for upgrading

your home or small office. This ultra-slim, Vista-certified LCD

DELIVERS AN IMPRESSIVE ARRAY OF FEATURES that will

enhance your productivity while helping you stay within your

®

budget. With OptiSync

DYNAMIC CONTRAST RATIO (typ) and fast ClearMotiv

video response, you’ll enjoy crystal-clear graphics, video and

text. The latest OSD/power lock and AutoTune

MAXIMIZE AND MAINTAIN YOUR DISPLAY SETTINGS. The

VA926 displays excellent taste while enhancing your home or

small office desktop.

ATTRACTIVE STYLING. ATTRACTIVE PRICE.

> Fast 5ms video response delivers superior picture clarity

> Full 19" viewable screen

Displays a full, flat 19" viewable area with crisp detail and fully
saturated color.

> 1280x1024 native resolution

Incredible image detail for sharp text and graphics.

> 2000:1 dynamic contrast ratio (typ)

Provides for darker black levels and better overall
front-of-screen performance.

> Stylish slim-bezel design

An ultra-thin bezel lets you see more without taking up
valuable desktop real estate.

> OptiSync®digital/analog inputs expand your connectivity

Multi-mode input technology supports both digital (DVI) and analog
(VGA) signals for ultimate compatibility and configuration flexibility

> OSD/power lock secures your settings

Prevents changes to monitor settings and maintains an
optimized image

®

> OnView

Screen adjustments are precisely made via an easy-to-use
on-screen menu

> VESA

controls for superior screen adjustability

®

wall mount compliant

digital and analog inputs, 2000:1

®

functions

.

.

®

5ms

.

VA926

19" VALUE SERIES LCD WITH 5MS VIDEO RESPONSE

LCD Type 19" color TFT active matrix SXGA LCD

Display Area 14.8" horizontal x 11.9" vertical; 19.0" diagonal

Optimum Resolution 1280x1024

Contrast Ratio 1000:1 static (typ), 2000:1 dynamic (typ)

Viewing Angles 170° horizontal, 160° vertical

Response Time 5ms (typ)

Light Source Long life, 40,000 hrs. (typ)

Brightness 300 cd/m2 (typ)

Panel Surface Anti-glare

VIDEO INPUT Analog/Digital RGB analog (75 ohms, 0.7 Vp-p)/DVI-D

Frequency Fh: 30~82kHz, Fv: 50~75Hz

Sync H/V separated (TTL)

COMPATIBILITY PC VGA up to 1280x1024 non-interlaced

Mac®* Power Mac™ G3/G4/G5 up to 1280x1024

CONNECTOR Analog/Digital 15-pin mini D-sub/Digital

Power 3-pin AC plug (CEE22)

POWER Voltage AC 100–240V (universal), 50/60Hz (auto switch)

Consumption 32W (typ)

CONTROLS Basic Power, 1, down, up, 2

ERGONOMICS Tilt -5°/+20°

OPERATING Temperature 32–104°F (0–40°C)

CONDITIONS Humidity 10–90% (non-condensing)

DIMENSIONS Physical with stand 16.2" x 17.1" x 7.7" (412mm x 434mm x 194mm)

(W x H x D) Physical without stand 16.2" x 14.0" x 2.5" (412mm x 355mm x 64mm)

WEIGHT Net with stand 8.4 lb. (3.8 kg)

REGULATIONS UL, cUL, FCC-B, CB, CE, NOM, TUV-S, GS, ERGO (covers

RECYCLE/DISPOSAL The lamp in this product contains mercury. Please dispose of

POWER MANAGEMENT TCO’03

PACKAGE CONTENTS LCD display, video cable, power cable, Quick Start Guide,

WARRANTY Three-year limited warranty on parts, labor and backlight

®

OnView

Net without stand 7.3 lb. (3.3 kg)

Gross with stand 11.1 lb. (5.0 kg)

Auto image adjust, contrast, brightness, input select,

ViewMatch®color adjust (sRGB, 9300K, 6500K – default,

5400K, RGB), information, manual image adjust (H. size,

H. position, V. position, fine tune, sharpness), setup menu

(language, resolution notice, OSD position, OSD timeout,

OSD background), memory recall

ISO13406-2), MPR II, BSMI, CCC, PSB, C-TICK, RoHS, WEEE,

VCCI, GOST-R, SASO, TCO’03

in accordance with local, state or federal laws.

ViewSonic Wizard (DVI cable not included)

ViewSonic Corporation’s QMS & EMS have been registered

to ISO 9001 & ISO 14001, respectively, by TUV NORD.

Sales: [phone] • [e-mail] • ViewSonic.com

*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and
programs may vary by country; see your ViewSonic representative for complete details. Windows Vista and the Windows logo are trademarks
or registered trademarks of Microsoft Corporation in the United States and/or other countries. Corporate names, trademarks stated herein are
the property of their respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved. [15098-00B-06/10] VA926-1

For more product information, visit us on the web at ViewSonic.com
