ViewSonic VA2026W - 20"" LCD Monitor Specification
VA2026w
20" VALUE SERIES
WIDESCREEN LCD
WITH 5MS VIDEO RESPONSE
Big, wide, budget-friendly.
ViewSonic’s 20" VA2026w LCD brings value to big, widescreen
displays. This display doesn’t compromise on features with versatile
®
OptiSync
resolution for brilliant HD images. This stylish 20-inch LCD delivers
EXTREME CLARITY, AMAZING COLOR with 2000:1 DYNAMIC
CONTRAST RATIO (typ) and fast ClearMotiv
Enjoy beautiful graphics and view spreadsheets in unbelievable clarity.
Enjoy greater productivity with the ability to VIEW TWO FULL-SIZE
DOCUMENTS SIDE-BY-SIDE or work in multiple applications
simultaneously on the widescreen display. The stylish, slim-bezel
design and VESA
seamlessly into any office décor. It’s great for desktop applications at
home, school or in the office.
digital and analog inputs and super-high 1680x1050
®
5ms video response.
®
wall-mount compliance allow the VA2026w to fit
A WIDESCREEN DISPLAY FOR ANYONE
> Fast 5ms video response delivers superior picture clarity
> Full 20" viewable widescreen
Displays a full, flat 20" viewable area with crisp detail and fully
saturated color.
> 1680x1050 native resolution
Incredible image detail for sharp text and graphics.
> 2000:1 dynamic contrast ratio (typ)
Provides for darker black levels and better overall
front-of-screen performance.
> Stylish slim-bezel design
An ultra-thin bezel lets you see more without taking up
valuable desktop real estate.
> OptiSync®digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI) and analog
(VGA) signals for ultimate compatibility and configuration flexibility
> OSD/power lock secures your settings
Prevents changes to monitor settings and maintains an
optimized image
> OnView
Screen adjustments are precisely made via an easy-to-use
on-screen menu
> Windows Vista approved certified
> PC and Mac
> TCO’03 and ENERGY STAR
.
®
controls for superior screen adjustability
.
®
compatible
®
qualified
.
VA2026w
20" VALUE SERIES WIDESCREEN LCD WITH 5MS VIDEO RESPONSE
LCD Type 20" color TFT active matrix WSXGA LCD
Display Area 17.1" horizontal x 10.7" vertical; 20.1" diagonal
Optimum Resolution 1680x1050
Contrast Ratio 1000:1 static (typ), 2000:1 dynamic (typ)
Viewing Angles 170° horizontal, 160° vertical
Response Time 5ms (typ)
Light Source Long life, 40,000 hrs. (typ)
Brightness 300 cd/m2 (typ)
Panel Surface Anti-glare
VIDEO INPUT Analog/Digital RGB analog (75 ohms, 0.7 Vp-p)/DVI-D (HDCP)
Frequency Fh: 30~82kHz, Fv: 50~75Hz
Sync H/V separated (TTL)
COMPATIBILITY PC VGA up to 1680x1050 non-interlaced
Mac®* Power Mac™ G3/G4/G5 up to 1680x1050
CONNECTOR Analog/Digital 15-pin mini D-sub/DVI-D
Power 3-pin AC plug (CEE22)
POWER Voltage AC 100–240V (universal), 50/60Hz (auto switch)
Consumption 38W (typ)
CONTROLS Basic Power, 1, down, up, 2
ERGONOMICS Tilt -5°/+20°
OPERATING Temperature 32–104°F (0–40°C)
CONDITIONS Humidity 20–90% (non-condensing)
DIMENSIONS Physical with stand 18.6" x 16.1" x 8.9" (472mm x 408mm x 225mm)
(W x H x D) Physical without stand 18.6" x 12.9" x 2.5" (472mm x 327mm x 65mm)
WEIGHT Net with stand 10.8 lb. (4.9 kg)
REGULATIONS UL, cUL, FCC-B, CB, CE, NOM, TUV-S, GS, ERGO (covers
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please dispose of
POWER MANAGEMENT Meets TCO’03 and ENERGY STAR®standards
PACKAGE CONTENTS LCD display, video cable, power cable, Quick Start Guide,
WARRANTY Three-year limited warranty on parts, labor and backlight
®
OnView
Net without stand 9.5 lb. (4.3 kg)
Gross with stand 14.1 lb. (6.4 kg)
Auto image adjust, contrast, brightness, input select,
ViewMatch®color adjust (sRGB, 9300K, 6500K – default,
5400K, RGB), information, manual image adjust (H. size, H.
position, V. position, fine tune, sharpness), setup menu
(language, resolution notice, OSD position, OSD timeout,
OSD background), memory recall
ISO13406-2), MPR II, BSMI, CCC, ENERGY STAR,®PSB,
C-TICK, RoHS, WEEE, VCCI, GOST-R, SASO, TCO’03,
EPEAT-Silver
in accordance with local, state and federal laws.
ViewSonic Wizard (DVI cable not included)
ViewSonic Corporation’s QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details.
Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2008 ViewSonic Corporation. All rights reserved. [14193-00B-10/08] VA2026w-1
For more product information, visit us on the web at ViewSonic.com
