ViewSonic PJD6220, PJD6220-3D, PJD6230, PJD6240 User Manual

®
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
ViewSonic
DLP Projector
PJD6220
PJD6220-3D
PJD6230 PJD6240
IMPORTANT: Please read this User Guide to obtain important information on
installing and using your product in a safe manner, as well as registering your
product for future service. Warranty information contained in this User Guide will
describe your limited coverage from ViewSonic Corporation, which is also found
RQRXU ZHEVLWH DWKWWSZZZYLHZVRQLFFRP LQ(QJOLVK RULQ VSHFL¿FODQJXDJHV
using the Regional selection box in the upper right corner of our website.
- User Guide
- Guide de l’utilisateur
- Bedienungsanleitung
- Guía del usuario
- Guida dell’utente
- Guia do usuário
- Användarhandbok
- Käyttöopas
Ɋɭɤɨɜɨɞɫɬɜɨɩɨɥɶɡɨɜɚɬɟɥɹ
- ٺҢЙыġĩᖅᡝĪ
- ሢ၊࿁࿳ġĩ⇷␅Ī
Model No. : VS11949
VS11986
azulmarina azulmarina azulmarina azulmarina azulmarina
azulmarina azulmarina azulmarina azulmarina azulmarina
VS11990
Notes on the AC Power Cord
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
AC Power Cord must meet the requirement of countries where you use this projector. Please confirm your AC plug type with the graphics below and ensure that the proper AC Power Cord is used. If the supplied AC Power Cord does not match your AC outlet, please contact your sales dealer. This projector is equipped with a grounding type AC line plug. Please ensure that your outlet fits the plug. Do not defeat the safety purpose of this grounding type plug. We highly recommend using a video source device also equipped with a grounding type AC line plug to prevent signal interference due to voltage fluctuations.
Ground
azulmarina azulmarina azulmarina azulmarina azulmarina
azulmarina azulmarina azulmarina azulmarina azulmarina
CONTENTS
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
Introduction...................................................................................1
Projector Features........................................................................................................1
Package Contents........................................................ .... ............................................2
Projector Overview.......................................................................................................3
Using the Product..........................................................................5
Control Panel ...............................................................................................................5
Connection Ports..........................................................................................................6
Remote Control............................................................................................................7
Installing the Batteries..................................................................................................8
Remote Control Operation...........................................................................................9
Installation...................................................................................10
Connecting the Projector............................................................................................10
Powering On/Off the Projector...................................................................................11
Adjusting the Projector...............................................................................................12
Menu Operation..........................................................................14
Network Control..........................................................................20
Maintenance.................................................................................31
Cleaning the Lens.......................................................................... ... .... .....................31
Cleaning the Projector Housing.................................................................................31
Replacing the Lamp...................................................................................................32
Specifications...............................................................................34
Appendix......................................................................................35
LED Indicator Messages............................................................................................35
RS-232 Command and Configuration........................................................................36
Compatibility Modes...................................................................................................41
Troubleshooting .........................................................................................................42
azulmarina azulmarina azulmarina azulmarina azulmarina
azulmarina azulmarina azulmarina azulmarina azulmarina
Compliance Information
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
FCC Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: <RXDUHFDXWLRQHGWKDWFKDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\
responsible for compliance could void your authority to operate the equipment.
For Canada
• This Class B digital apparatus complies with Canadian ICES-003.
• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC.
Following information is only for EU-member states:
The mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries or accumulators as unsorted municipal waste, but use the return and collection systems available.
If the batteries, accumulators and button cells included with this equipment, display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic i
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240
Important Safety Instructions
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this unit near water.
6. Clean with a soft, dry cloth. If still not clean, see “Cleaning the Display” in this guide for further instructions.
Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s
7. instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
GHYLFHVLQFOXGLQJDPSOL¿HUVWKDWSURGXFHKHDW
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade and the third prong are provided for your safety. If
WKHSURYLGHGSOXJGRHVQRW¿WLQWR\RXURXWOHWFRQVXOWDQHOHFWULFLDQIRUUHSODFHPHQWRIWKH
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs. Convenience receptacles and the point where they exit from the unit. Be sure that the power outlet is located near the unit so that it is easily accessible.
 2QO\XVHDWWDFKPHQWVDFFHVVRULHVVSHFL¿HGE\WKHPDQXIDFWXUHU
12. 8VHRQO\ZLWKWKHFDUWVWDQGWULSRGEUDFNHWRUWDEOHVSHFL¿HGE\WKH
13. Unplug this unit when unused for long periods of time.
 5HIHUDOOVHUYLFLQJWRTXDOL¿HGVHUYLFHSHUVRQQHO6HUYLFLQJLVUHTXLUHGZKHQWKHXQLWKDV
been damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid is spilled onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if the unit does not operate normally or has been dropped.
manufacturer, or sold with the unit. When a cart is used, use caution when moving the cart/unit combination to avoid injury from tipping over.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic ii
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240
Declaration of RoHS Compliance
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below:
Substance
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex of the RoHS Directives as noted below:
Examples of exempted components are:
0HUFXU\LQFRPSDFWÀXRUHVFHQWODPSVQRWH[FHHGLQJPJSHUODPSDQGLQRWKHUODPSVQRW
VSHFL¿FDOO\PHQWLRQHGLQWKH$QQH[RI5R+6'LUHFWLYH
/HDGLQJODVVRIFDWKRGHUD\WXEHVHOHFWURQLFFRPSRQHQWVÀXRUHVFHQWWXEHVDQGHOHFWURQLF
ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or
more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium
containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.
Proposed Maximum
Concentration
Actual Concentration
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic iii
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240
Copyright Information
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
Copyright© ViewSonic© Corporation, 2009. All rights reserved. Macintosh and Power Macintosh are registered trademarks of Apple Inc. Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are trademarks of VESA. PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
FKDQJHSURGXFWVSHFL¿FDWLRQVZLWKRXWQRWLFH,QIRUPDWLRQLQWKLVGRFXPHQWPD\FKDQJHZLWKRXW
notice. No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic® Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
PJD6220/PJD6220-3D/PJD6230/PJD6240
ViewSonic DLP Projector
VS11949/VS11986/VS11990 PJD6220_PJD6220-3D_PJD6230_PJD6240_UG_ENG Rev. 1B 03-05-09
___________________________________________________________
___________________________________________________________
The lamp in this product contains mercury. Please dispose of in accordance with local, state or federal laws.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic iv
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240

Introduction

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)

Projector Features

The projector integrates high-performance optical engine projection and a user - friendly design to deliver high reliabili ty and ease of use. The projector offers the following features:
Single chip 0.55" Texas Instruments DLP XGA (1024 x 768 pixels) Auto image re-sizing (Auto-Sync.) to 1024 x 768 full screen with scaling
compression compatibility for VGA, SVGA, XGA and SXGA*
Compatibility with Macintosh Compatibility with NTSC, PAL, SECAM and HDTV D-Sub 15-pin terminal for analog video connectivity User-friendly, multi-language on-screen display Advanced electronic keystone correction Network function for remote management Closed Cap tio ning included
* means compressed.
®
computers
®
technology
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 1
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240

Package Contents

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
When you unpack the projector, make sure you have all these compon ents:

Projector with Lens Cap AC Power Cord VGA Cable (D-SUB to D-SUB)

Composite Video Cable S-Video Cable

User’s Manual Quick Start Guide Projector

Save the original shipping ca rt on and packin g material; they will comein han dy if you ever to ship your unit. For ma ximu m prot ection , rep ack yo ur uni t as it was originally packed at the factory.
Accessories and components may vary by retailer and region.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 2
azulmarina azulmarina azulmarina azulmarina azulmarina
Remote
Control (IR)
Carrying Case
PJD6220/PJD6220-3D
AAA size
batteries for
remote control
VGA -
Component
Adapter
PJD6230/PJD6240

Projector Overview

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
Front View
1112
10 8
1
2 4 5 63
Lens cap AC power socket
1
Elevator button Speaker
2 8
Lens cap strap Control panel
3 9
Projection lens Zoom ring
4
Front IR remote control sensor Focus ring
5
Ventilation holes Lamp cover
6
7
10 11 12
7 9
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 3
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240
Rear View
AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
Connection ports
1
Kensington lock
2
Rear IR remote control sensor
3
Ventilation holes
4
Bottom View
Elevator foot
1
Ceiling mount (M4 x L7.5mm)
2
Tilt-adjustment foot
3
2
3
1
4
1
2
3
This projector can be used with a ceiling mount for support. The ceiling mount is not included in the package.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 4
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240

Using the Product

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)

Control Panel

LED
1 2
3 4
568 7
Lamp (Lamp LED indicator)
1
Refer to “LED Indicator Messages”. Temp (Temperature LED indicator)
2
Refer to “LED Indicator Messages”.
Button Function
Four directional buttons
3
Use four directional buttons to select items or make adjustments to your selection.
Enter
4
Enter to sub-menu and confirm the menu selection. Activate in Color Setting, Lamp Counter Reset and Factory Default menu operations.
Resync
5
Resynchronize the projector to t he input signal from a computer.
Power
6
Turn the projector on or off.
Menu
7
Display or exit the on-screen display menus.
Source
8
Manually select an input source.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 5
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240

Connection Ports

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
2 3 4 5 6 7 8 91
LAN
1
For network control.
Audio Out
212
Connect to a speaker or other audio input equipment.
Computer Out
23
Connect to a computer display, etc.
Audio In
434
Connect an audio output from video equipment to this jack.
Computer In
45
Connect image input signal (analog RGB or component) to this jack.
Computer In
56
Connect image input signal (analog RGB or component) to this jack.
RS-232
67
When operating the projector via a computer, connect this to the controlling computer 's RS-232C port.
S-Video
78
Connect S-Video output from video equipme nt to this jack.
Video
89
Connect composite video output from video equipment to this jack.
SERVICE
10
9
This connector is for firmware update.
10
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 6
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240

Remote Control

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
Power
1
Turn the projector on or off.
Four directional buttons
2
-Use four directional buttons to select items or make adjustments to your selection.
- The right button acts as Blank Screen function. Cut off the screen temporarily. Press again to cancel the Blank Screen function.
MENU
3
Display or exit the on-screen display menus.
Laser
4
Aim the remote at the viewing screen, press and hold t his button to activate the laser pointer.
Four directional buttons
5
(Computer mode only) Act as computer keyboard (four directional buttons). This function is only available when the projector is connected to a computer via a USB cable.
Left (Computer mode only)
6
Act as mouse left button. This function is only available when the projector is connected to a computer via a USB cable.
ViewMatch
7
Switch in between high brightness performance or Accuracy color performance.
Source
8
Manually select an input source. Right (Computer mode only)
9
Act as mouse right button. This function is only available when the projector is connected to a compute via a USB cable.
Enter
10
Confirm the selection.
Freeze
11
Press "Freeze" to pause the screen image. Press again to cancel the Fre eze function.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 7
azulmarina azulmarina azulmarina azulmarina azulmarina
1
11
2
3
4
10
5
6 7
r
PJD6220/PJD6220-3D
PJD6230/PJD6240
9 8

Installing the Batteries

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)

1. Open the battery cover in the direction shown.

2. Install batteries as indicated by the diagram Inside the compartment.

3. Close the battery cover into position.

Keep the batteries out of the reach of children. There is a danger of death by
accidentally swallowing the batteries.
Do not recharge the used batteries or expose the batteries to fire or water.Do not dispose of the used batteries along with household waste. Dispose of
used batteries according to local regulations.
Danger of explosion may happen if batteries are incorrectly replaced.
Replace only with the same type recommended by the manufacturer.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 8
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240

Remote Control Operation

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
Point the remote control at the infrared remote sensor and press a button.
Operating the projector from
the front
15
10
5m
7m
5m
Operating the projector from
the rear
15
10
5m
7m
5m
Do not point the laser pointer directly to the people's eyes (especiallyn small children). There is a danger of injuiry to the eyes.
The remote control may not operate when there is sunlight or other strong light
such as a fluorescent lamp shining on the remote sensor.
Operate the remote control from a position where the remote sensor is visible.Do not drop the remote control or jolt it.Keep the remote control out of locations with excessively high temperature or
humidity.
Do not get water on the remote control or place wet objects on it.Do not disassemble the remote control.
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 9
azulmarina azulmarina azulmarina azulmarina azulmarina
PJD6220/PJD6220-3D
PJD6230/PJD6240

Installation

AzulMarinaWeb (AzulMarina)
AzulMarinaWeb (AzulMarina)
Connecting the Projector
VGA Cable (D-Sub to D-Sub) VGA (D-Sub) to HDTV (RCA) Cable
1 5
Audio Cable S-Video Cable
2 6
RS-232 Cable Composite Video Cable
3 7
USB Cable Internet Cable
4 8
Laptop type
8
When connecting cable, power cords of both a projector and external equipment
azulmarina azulmarina azulmarina azulmarina azulmarina
ViewSonic 10
azulmarina azulmarina azulmarina azulmarina azulmarina
should be disconnected from AC outlet. The figure above is a sample connection. This does not mean that all of these devices can or must be connected simultaneously. The cables that come with the projector may differ from the above illustration. The included cables are based on actual shipment delivery.
Desktop type
41112
73652 5
PJD6220/PJD6220-3D
PJD6230/PJD6240
Loading...
+ 38 hidden pages
