ViewSonic IFP2410 User Guide
IFP2410
Quick Start Guide
Guide rapide de début
Guía de inicio rápido
Compliance Information
Please read before proceeding
• Use only the batteries and power adapter provided by the manufacturer. The use of unauthorized accessories may void
your warranty.
• Do not store your device in temperatures higher than 50°C (122°F).
• The operating temperature for this device is from 0°C (32°F) to 35°C (95°F).
Connect the power cord from the unit to a grounded AC outlet. Ensure that the power source is within the operating
voltage of the display. The operating voltage can be found on the device label. The device uses either 110 to 127 volts
alternating voltage or 220 to 240 volts alternating voltage and 50/60 Hz.
CAUTION: To avoid damage to the unit, be sure to use only the power cord that came with the unit.
CE Conformity for European Countries
The device complies with the relevant section of the Low Voltage Directive 2014/35/EC, Eco-Design Directive
2009/125/EC, RoHS Directive 2011/65/EU, WEEE Directive 2012/19/EU, and Radio Equipment Directive 2014/53/
EU
European Union Regulatory Conformance
The equipment complies with the RF Exposure Requirement 2014/53/EU, Council Recommendation of 12 June 2014 on
the limitation of exposure of the general public to electromagnetic elds (0-300 GHz). This equipment meets the following
conformance standards: EN301489-1, EN301489-17, EN55022/24, EN60950-1, EN300328.
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament
and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation
Committee (TAC) as shown below:
Substance Proposed Maximum Concentration Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Bis(2-ethylhexyl) phthalate (DEHP) 0.1% < 0.1%
Butyl benzyl phthalate (BBP) 0.1% < 0.1%
Dibutyl phthalate (DBP) 0.1% < 0.1%
Diisobutyl phthalate (DIBP) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex III of the RoHS2 Directives as noted below:
Examples of exempted components are:
1. Lead in glass of uorescent tubes not exceeding 0.2% by weight.
2. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.
3. Copper alloy containing up to 4% lead by weight.
4. Lead in high melting temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead).
5. Electrical and electronic components containing lead in a glass or ceramic other than dielectric ceramic in capacitors,
e.g. piezoelectronic devices, or in a glass or ceramic matrix compound.
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter,
Greener Computing. Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwan: http://recycle.epa.gov.tw/
Copyright Information
Android, Google, Google Play, the Google Play logo and other marks are trademarks of Google Inc.
6+
) 0.1% < 0.1%
i
Caution
IC Caution:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference,
including interference that may cause undesired operation of the device.
CAN ICES-3 (B)/NMB-3(B)
FCC Caution:
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not
cause harmful interference (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void the
user's right to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit dierentfrom that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
FCC ID: GSS-VS16340
ii
Informations de conformité
Veuillez lire la section suivante avant de continuer
• Utilisez seulement les batteries et l’adaptateur secteur fournis par le fabricant. L’utilisation d’accessoires non autorisés
peut annuler la garantie.
• Ne rangez pas votre téléphone dans des endroits où la température est plus de 50ºC ou 122ºF.
• La température recommandée pour cet appareil est entre 0°C (32°F) et 35ºC (95°F).
Branchez le cordon d'alimentation de l'appareil sur une prise secteur avec terre. Veillez à ce que la tension de la source
d'alimentation soit dans les limites de fonctionnement de l'écran. La tension de fonctionnement est indiquée sur l'étiquette de
l'appareil. Le dispositif utilise soit 110-127 VAC ou 220 à 240 V CA, 50/60 Hz.
ATTENTION: Pour éviter d'endommager l'appareil, utilisez uniquement le cordon d'alimentation qui est fourni avec l'appareil.
Conformité CE pour les pays européens
L'appareil est conforme à la section correspondante de la directive basse tension 2014/35/CE, de la directive sur
l'éco-conception 2009/125/CE, de la directive RoHS 2011/65/EU, de la directive DEEE 2012/19/UE et de la
directive relative aux équipements radioélectriques 2014/53/UE
Certicat de conformité dans l'Union Européenne
Cet appareil répond aux directives d'exposition RF 2014/53/UE, Recommandation du Conseil du 12 Juin 2014, sur la
limitation d'exposition du public général aux champs électromagnétiques (0-300 GHz). Cet appareil est conforme aux
normes de conformité suivantes : EN301489-1, EN301489-17, EN55022/24, EN60950-1, EN300328.
Déclaration de conformité RoHS2 (LSDEEE2)
Ce produit a été conçu et fabriqué dans le respect de la directive 2011/65/EU du Parlement Européen et du Conseil relative
à la limitation de l’utilisation de certaines substances dangereuses dans les équipements électriques et électroniques
(Directive RoHS2 - LSDEEE2) et il est déclaré respecter les valeurs de concentration maximum dénies par le Comité
technique d’adaptation (TAC) européen, qui sont les suivantes:
Substance Concentration maximale proposée Concentration réelle
Plomb (Pb) 0.1% < 0.1%
Mercure (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Chrome hexavalent (Cr6+) 0.1% < 0.1%
Polybromobiphényle (PBB) 0.1% < 0.1%
Polybromodiphénylséthers (PBDE) 0.1% < 0.1%
Phtalate de bis (2-éthylhexyle) (DEHP) 0.1% < 0.1%
Phtalate de butyle et de benzyle (BBP) 0.1% < 0.1%
Phtalate de dibutyle (DBP) 0.1% < 0.1%
Diisobutyl phthalate (DIBP) 0.1% < 0.1%
Certains composants de produits mentionnés ci-dessus ne sont pas soumis à ces limitations, conformément aux dispositions
de l’Annexe III de la Directive RoHS2 (LSDEEE2). Il s’agit des composants suivants:
Exemples de composants exemptés:
1. Le plomb dans le verre des tubes uorescents ne dépasse pas 0,2 % du poids.
2. Plomb en tant qu’élément d’alliage de l’aluminium jusqu’à 0,4 % du poids.
3. L’alliage de cuivre contient jusqu’à 4 % de plomb.
4. Soudures à haute température (les alliages basés sur le plomb contiennent du plomb à 85 % ou plus).
5. Composants électriques et électroniques contenant du plomb dans le verre ou des porcelaines. (appareils piézoélectriques ou dans un composant de matrice de verre ou de céramique).
Elimination du produit en n de vie
ViewSonic respecte l’environnement et fait des eorts allant dans le sens d’un environnement de travail et de vie
écologiques. Merci d’oeuvrer aussi pour une informatique plus intelligente et plus écologique. Pour en savoir plus, veuillez
visiter le site web de ViewSonic.
Etats-Unis et Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwan: http://recycle.epa.gov.tw/
Informations de copyright
Android, Google, Google Play, la Google Play logo et les autres marques sont des marques commerciales de Google Inc.
iii
Información de conformidad
Lea estas instrucciones antes de continuar
• Use exclusivamente las baterías y el adaptador de alimentación suministrados por el fabricante. El uso de accesorios no
autorizados puede invalidar la garantía.
• No almacene el teléfono en lugares con temperaturas superiores a 50 ºC o 122 ºF.
• La temperatura de funcionamiento para este dispositivo está comprendida entre 0 ºC (32°F) y 35 ºC (95°F).
Conecte el cable de alimentación desde la unidad a una toma de CA conectada a tierra. Asegúrese de que la fuente de
alimentación tenga el mismo intervalo del voltaje de funcionamiento que la pantalla. La tensión de alimentación está indicada en la
etiqueta del dispositivo. El dispositivo utiliza DE 110 a 127 VCA o 220 a 240 VCA, 50/60 Hz.
PRECAUCIÓN: Para evitar daños a la unidad, utilice únicamente el cable de alimentación que se incluye con el dispositivo
Certicación CE para países europeos
El dispositivo cumple con la sección correspondiente de la Directiva de baja tensión 2014/35/CE, la Directiva de
diseño ecológico 2009/125/CE, la Directiva RoHS 2011/65/UE, la Directiva WEEE 2012/19/UE y la Directiva de
equipos de radio 2014/53/UE
Cumplimiento de normativas de la Unión Europea
El equipo cumple el requisito de exposición a la radiofrecuencia 2014/53/UE, Recomendación del consejo de 12 de junio de 2014
sobre la limitación de exposición del público en general a los campos electromagnéticos (0-300 GHz). Este equipo cumple los
siguientes estándares de conformidad: EN301489-1, EN301489-17, EN55022/24, EN60950-1, EN300328.
Declaración de Cumplimiento de RoHS2
Este producto ha sido diseñado y fabricado cumpliendo la Directiva 2011/65/EU del Parlamento Europeo y el Consejo para
la restricción del uso de ciertas sustancias peligrosas en equipos eléctricos y electrónicos (Directiva RoHS2) y se considera
que cumple con los valores de concentración máximos publicados por el European Technical Adaptation Committee (Comité
Europeo de Adaptaciones Técnicas) (TAC) tal y como se muestra a continuación:
Sustancia Concentración Máxima Propuesta Concentración Real
Plomo (Pb) 0.1% < 0.1%
Mercurio (Hg) 0.1% < 0.1%
Cadmio (Cd) 0.01% < 0.01%
Cromo Hexavalente (Cr6+) 0.1% < 0.1%
Bifenilo Polibromado (PBB) 0.1% < 0.1%
Éteres de Difenilo Polibromado (PBDE) 0.1% < 0.1%
bis(2-ethylhexyl)ftalato (DEHP) 0.1% < 0.1%
Ftalato de butilbencilo (BBP) 0.1% < 0.1%
Escribe bien estúpido (DBP) 0.1% < 0.1%
Ftalato de diisobutilo (DIBP) 0.1% < 0.1%
Ciertos componentes de los productos indicados más arriba están exentos bajo el Apéndice III de las Directivas RoHS2 tal y
como se indica a continuación:
Ejemplos de los componentes exentos:
1. Plomo en el vidrio de los tubos uorescentes sin sobrepasar el 0,2 % en peso.
2. Plomo como elemento de aleación en aluminio que contenga hasta un 0,4 % de su peso en plomo.
3. Aleación de cobre que contenga hasta un 4 % de su peso en plomo.
4. Plomo en pastas de soldadura de alta temperatura de fusión (es decir, aleaciones de plomo que contengan en peso un
85 % de plomo o más).
5. Componentes eléctricos y electrónicos que contengan plomo en un vidrio o cerámica de un tipo distinto de la cerámica
dieléctrica de condensadores, por ejemplo, dispositivos piezoelectrónicos, o en un compuesto de matrices de vidrio o
cerámica.
Desecho del producto al nal de su vida útil
ViewSonic es respetuoso con el medioambiente y está comprometido a trabajar y vivir de una manera que sea respetuosa
con el medioambiente. Gracias por ser parte de una forma de Computación más Inteligente y más Verde. Visite el sitio web
de ViewSonic para saber más.
EE.UU. y Canadá: http://www.viewsonic.com/company/green/recycle-program/
Europa: http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwán: http://recycle.epa.gov.tw/
Información del Copyright
Android, Google, Google Play, el Google Play logo y otras marcas son marcas comerciales de Google Inc.
iv
Introduction
Thank you for purchasing this IFP2410. This Start-up Guide describes how to operate and use
this product safely. Before operating, please read this guide carefully for important safety
information. Please also keep this guide handy as a quick reference should you encounter any
diculties when using this product.
You can nd the full user guide on the home screen of your device once powered on.
A. Getting Started
■ Before using this product, please ensure that the following items are included:
Main unit x 1 AC Adapter x 1
Quick Start Guide x 1
Items supplied with this product
■ Please ensure that the serial number on this product is identical to that on the product warranty.
■ If any parts are missing or broken, please contact your store of purchase.
To use this product safely
Even though this product is designed with safety in mind, improper use of this product may cause re
or electric shock that can lead to injuries or death. To prevent such accidents, please comply with the
following recommendations:
Power cable
* Plug types by country
■ Observe safety precautions
Please read and follow all safety precautions as indicated.
■ Stop using the product if it malfunctions
In the event of a malfunction, please contact ViewSonic Customer Care for support.
■ If the following events occur, then follow the recommendations
• Smoke is detected
• Strange sound or odor is observed
• If water gets inside this product
• This product is dropped or damaged
• Turn o the power
• Unplug the AC adapter cable and USB cable
• Please contact ViewSonic Customer Care
for service support.
Safety warning indications
Attention Sign Prohibition Signs Instruction Signs
Attention
Prohibited Disassembly is
prohibited
Keep dry Handle with dry
hands
5
Disconnect the
plug
B. Product Overview
Basic Operations and Front View
Built-in Webcam (5.0MP)
Built-in Microphone
Display with touch panel function
About LCD display:
This product uses a TFT LCD display. Note that some
pixels may always appear o (black) while some are
always on (orange, green, or blue). Depending on the
viewing angle, uneven color or uneven brightness may be
observed. Please note that these are natural characteristics
of TFT LCD and should not be regarded as defects.
Power button
LED indicator
OSD Menu / Exit
Arrow Button (Up/Right)
Arrow Button (Down/Left)
Input Signal Switch / OSD Menu Select
Back View
LEFT SIDE
LAN port (RJ-45)
HDMI-OUT jack
HDMI-IN jack
Headset jack
Microphone IN
SD Card Slot
MiniUSB port (OTG)
DC-in jack
RIGHT SIDE
USB Type-A x 4
USB Type-B
Please do not use AC adapters other than the one
supplied in this product package to prevent re and
electric shock.
Please do not place objects on the AC adapter, or cover it
with anything. Overheating of the AC adapter may lead to a
re.
LEFT SIDE RIGHT SIDE
1
2
3
4
5
6
7
8
1
2
6
C. Installation precautions
Installation Environment
Health precautions
Viewing computer monitor displays for extended periods of time may result in tiredness, numbness in the
hands and feet, blurry vision,etc. Please see the picture below as a guide for extended use conditions.
Safety precautions
• Install this product in a well-ventilated location to eliminate exposure to high humidity conditions
that may lead to condensation on or in the product.
• For proper heat dissipation, allow a gap of at least 6" (15cm) between this product and the wall
during installation.
Regarding lightning hazards
Where lightning strikes are expected, it is advised to turn o the computer, and unplug any cable or
cord connected to this product
Ideal installation and proper posture
Adjust the screen so
that your viewing angle
is perpendicular and
Straighten your back
while seated
slightly higher than the
middle of the screen.
Make sure that the unit
is placed on a stable, at
surface.
7
D. Installation and Connection
.
1) Open the stand in the direction of the arrow.
Place face down on a clean, at surface and avoid
any objects that could damage the display.
3) Place the unit upright on a stable, at surface.
2) Connect the power
Connect one end of the supplied AC adapter to
the DC-in jack at the back of the unit.
Connect the power cord to the other end of the
AC adapter.
Connect the power plug to the outlet.
8
E. Start-up and initial setting
Turn on the Power
1) Make sure the power cable and AC adapter are connected.
2) Press and hold the power switch until the status LED turns blue.
9
Loading...
