Viessmann Vitola 200 Flyer

Oil-/Gas-fired hot water heating boiler
for modulating boiler water temperatures
Rated input: 83 to 300 MBH

Low temperature hot water heating boiler
with biferral sandwiched heat exchanger
surface

High quality and performance. The
double-wall, sandwiched heat
exchanger surface of the Vitola 200
represents a milestone in the history of
modern heating technology. The Vitola
200 combines user comfort and
convenience with economy – it even
switches off completely when no heat
is required.

The benefits at a glance:

■ Biferral heat exchanger surface

of cast iron and steel for high
operational reliability and a long
service life.

■ Clean combustion and clean
burnout of the flame through
optimized combustion chamber
geometry. Combustion chamber
made of stainless steel. Flue gas
temperature adjustable for oversized
chimneys.

■ Meets the specifications of the
German “Blue Angel” environmental
certificate and Swiss clean air
regulations.

■ Extremely economical and
environmentally friendly due to
modulating boiler water
temperatures; the boiler switches off
completely when no heat is required.
AFUE up to 87%.

■ Reliable heat transfer due to wide
water walls and large water
content.

■ All Viessmann burners are factory
tested at operating temperature and
matched to the rated boiler input,
facilitating adjustments and faster
start-up on site.

Oil-/Gas-fired hot water heating boiler
for modulating boiler water
temperatures without low limit
with biferral sandwiched heat exchanger
surface of cast iron and steel
Rated input: 83 to 300 MBH

5167 401 05/05 Printed in Canada

Biferral
sandwiched heat
exchanger surface

Vitotronic – the new generation of
controls: intelligent, easy to install,
operate and service

Vitola 200 boiler
with Viessmann
burner

Model VB2- 18 22 33 40 50 63

Rated input oil MBH 83 107 135 170 219 300
Rated input gas MBH 90 116 146 185 238 300
Total dimensions* Length inches 43

3

⁄4 461⁄4 523⁄4 531⁄4 581⁄2 63
Width inches 251⁄4 261⁄4 271⁄2 301⁄2 301⁄2 301⁄2
Height inches 323⁄4 331⁄2 34 37 381⁄2 381⁄2

Weight (incl. insulation) lbs 381 434 542 697 866 941
Boiler water content USG 18.5 23.2 31.2 37.0 52.6 59.0

Technical information subject to change without notice.

Low-emission
burner

Vitotronic 200
digital control

Biferral
sandwiched heat
exchanger surface

3” insulation

Oil-Fired

*Total dimensions with Viessmann Vitoflame 100 Burner installed. Dimensions may vary
depending on burner type. Refer to Technical Data Manual of burner for applicable dimensions.

Viessmann Manufacturing Company Inc.
750 McMurray Road
Waterloo, ON • N2V 2G5 • Canada
Tel.: [phone] Fax: [phone]
www.viessmann.ca

Viessmann Manufacturing Company (U.S.) Inc.
45 Access Road
Warwick, RI • 02886 • U.S.A.
Tel.: [phone] Fax: [phone]
www.viessmann-us.com

Burner may not be exactly as illustrated.
