Vicks V3700 User Manual

StarryNight

Cool Moisture Humidifier

USE AND CARE MANUAL

Self-regulating evaporative system

Filters impurities from the water

Multiple output settings

If you have any questions about the operation of your Vicks Starry Night Cool Moisture Humidifier, call our toll-free Consumer Relations line at 1-800-VAPOR-1-2 or e-mail us at [e-mail].

IMPORTANT!	V3700
READ AND SAVE THESE INSTRUCTIONS	Series

Important Safety Instructions

READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS

BEFORE USING THIS APPLIANCE

When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock and injury to persons, including the following:

1.The appliance should always be placed on a firm, flat, waterproof surface at least four feet away from bedside, six inches from the wall and out of reach of patient, children and pets. Be sure the appliance is in a stable position and the power cord is away from heated surfaces and out of the way to prevent the Humidifier from being tipped over.

2.The appliance should not be left unattended in a closed room since air could become saturated and leave condensation on walls and furniture. Leave room door partly open. Do not aim mist nozzle directly at children, walls or furniture.

3.Before using the appliance, extend the cord and inspect for any signs of damage. Do not use the unit if the cord has been damaged.

4.The appliance has a polarized plug (one blade is wider than the other) as a safety feature. This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature.

5.To avoid fire or shock hazard, plug the appliance directly into a 120V AC electrical outlet.

6.The appliance should always be unplugged and emptied when not in operation or while being cleaned. Shut off and unplug humidifier before moving. Do not move or tilt humidifier while it is in operation. Plug and unplug unit with dry hands.

Never pull by cord.

7.Do not operate the appliance without water. Turn off and unplug unit when tank is empty.

8.Caution: To avoid the risk of fire, shock or personal injury, do not use an extension cord.

9.Appliance requires regular cleaning. Refer to and follow cleaning instructions.

10.Do not operate outdoors; this appliance is intended for indoor use.

11.Do not cover or insert objects into any openings on the unit.

12.Do not attempt to repair or adjust any electrical or mechanical functions on this appliance. Doing so will void your warranty.

13.For residential use only.

2

Vicks® Starry Night Cool MOISTURE Humidifier (V3700 Series)

Projector Cover

Projector Lens

Water Tank

Tank Cap Gasket

Tank Cap

Scent Pad

Scent Pad Slot

Projector

Power Switch

Humidifier

Power Switch

Handle

Filter

Filter

Tray

Main

Housing

3

Setting up your humidifier

Placement	Step 1

Select a firm, level location at least 6” (15cm) from any walls for proper airflow. Place the humidifier on a water-resistant surface, as water can damage furniture and some flooring.

Kaz will not accept responsibility for property damage caused by water spillage.

Soak Filter	Step 1			Step 2			Step 3

	Remove tank and set			Remove filter tray from			Fold filter flat. Insert
	aside. Remove filter from			unit before installing the			wet filter into filter tray.
	humidifier and soak the			wet filter.			Place filter tray back
	filter in cool water.						in humidifier.
	DO NOT wring filter.
Scent Pad	Step 1			Step 2			Step 3

Remove tank and locate	If there is a used scent pad	Insert scent pad with angled
Scent Pad slot.	in the slot carefully remove	side facing downward into
	it. Replace with a new scent	the scent pad slot. You can
	pad. Carefully open scent	use the bag as a holder
	pad bag taking care to hold	during insertion.
	pad using bag. Use care not
	to come in direct contact
	with new scent pad.

Vicks Scent Pads work with heat to gradually release soothing aromatic vapors.

One complimentary menthol vapor scent pad is included with your unit.

Recommended Usage for the Vicks Menthol Scent Pad (VSP-19/VSP-19-CAN):

·Not recommended for infants under 10 pounds.

·For children between 10-22 pounds do not use more than 2 pads in a 24 hour period.

4

Setting up your humidifier (cont’d.)

Scent Pad	WARNING: Do not rub face or eyes after touching scent pad. Do not put fingers in mouth
	after touching scent pad. Oils in the pad could act as an irritant to eyes.

WARNING: As long as your humidifier is on, the scent pad heater will also be activated. This area can be warm to the touch.

INGREDIENTS: Eucalyptus Oil, Menthol, Glycol, Cedar Leaf Oil & Others

NOTE: Replace with Vicks Scent Pads, models VSP-19/VSP-19-CAN or Vicks Sleepy Time Vapopad VBR-5, available at most retailers or through Kaz Consumer Relations or www.kaz.com.

Fill Tank

Step 1

Step 2

Step 3

		Turn tank upside-down.					Fill tank with cool tap water.			Once the filled water tank
		Remove tank cap by turning					Replace tank cap. Tighten			has been placed on the unit
										do not move humidifier.
		counter-clockwise			.		by turning clockwise		.
										Doing so could cause
							Place tank back on humidifier.
										leakage and spills.
		Do Not Use Hot Water when				Filling Humidifier
Operating your humidifier
Power		Step 1					With the power switch in the OFF position, plug the filled
							humidifier into a polarized 120V outlet. DO NOT FORCE THE
							POLARIZED PLUG INTO THE OUTLET; it will only fit one way.
							DO NOT plug in humidifier with wet hands to avoid
							electric shock.
Output		Step 1					Set fan speed to desired output:
							High	) Max Moisture
							Low (	) Night time sound sleep mode

Starry Night
		Step 1			Turn the power switch to the on position to activate the starry
Projector
					night projector
					Note: Projector can be operated independently of the humidifier.

5

Changing YOUR FILTER

NOTE: It is recommended that all maintenance be done in the kitchen or bathroom on a water resistant surface. Remove water tank from unit before moving.

The filter should be changed every 1-3 months depending on your water quality. Keep in mind, depending on your water quality, mineral deposits can still clog or discolor the filter, affecting its life and that of the humidifier.

To change the filter:

Step 1			Step 2			Step 3			Step 4

Uses replacement	Turn off and unplug	Remove the water tank	Remove filter tray from
filter WF2.	your humidifier.	and filter tray.	unit. Discard old filter
			and set filter tray aside.

Step 5

Step 6

Soak new filter in	DO NOT wring filter.
cool water.

wicking FILTER maintenance

Step 7			Step 8

Insert new filter into filter	Replace the water tank.
tray. Place filter tray back
in humidifier.
NOTE: For best fit and
performance remove filter
tray from the humidifier
and insert presoaked
new filter.

Wicking Filter performance will diminish depending on the mineral content of the water and the amount of airborne dust in the environment.

IMPORTANT: CHECK WICKING FILTER REGULARLY. Any of the following conditions indicate that it is time to replace the Wicking Filter.

•A buildup of impurities and minerals on the Wicking Filter (evidenced by discoloration of the Wicking Filter)

•An appreciable decrease in Humidifier output

•The top of the Wicking Filter is not moist to the touch

•The Wicking Filter has large holes or tears

The Wicking Filter should be replaced at least one or two times during the season, depending on usage, mineral content of the water and the environment. We encourage you to only use a Kaz Model WF2 Replacement Wicking Filter. The use of other Wicking Filters may lead to substandard performance.

6

Cleaning

Cleaning involves two steps, SCALE REMOVAL and DISINFECTING. Be sure to perform these in the proper order to avoid harmful chemical interactions.

NOTE: REMOVE FILTER BEFORE CLEANING.

Failure to remove filter during cleaning will destroy the filter

SCALE REMOVAL (Recommend this process be performed on a weekly basis)

Step 1			Step 2			Step 3			Step 4

Turn off and unplug			Remove and empty		Remove filter and	Remove Filter Tray and fill
your humidifier.			water tank.		set aside.	filter tray and water tank
						with undiluted vinegar and
						soak for 10-15 minutes.
Step 5			Step 6

Using undilluted vinegar	Rinse water tank,
wipe base thoroughly.	filter tray and base
	thoroughly with water
	to remove scale.

DISINFECTING (Recommend this process be performed on a weekly basis)

Step 1		Step 2		Step 3		Step 4

1

g

al

Turn off and unplug	Remove and empty	Remove filter and
your humidifier.	water tank.	set aside
		Dilute 1 tablespoon (TBS)
		of bleach in 1 gallon of
		cool water

Fill water tank with water and bleach solution.

Remove water tray from unit and fill with the remaining water and bleach solution.

Wipe base with the same solution.

7

Cleaning (cont’d.)

						NOTES: The use of other water treatment products
Step 5				Step 6
						and chemicals may cause deterioration of the filter
						or damage the humidifier, thereby hindering the
						humidifier’s effectiveness.

Let stand for 20 minutes.

Rinse water tray and water tank thoroughly with water until the smell of bleach

is gone.

End-of-Season Care and Storage

•Follow the CLEANING instructions when the humidifier will not be used for at least one week or more, or at the end of the season.

•At the end of the season, remove and throw away the filter; do not store with a used filter.

•Dry the humidifier completely before storing. DO NOT store with water inside the Base or Water Tank.

•Pack the unit in its original carton and store in a cool, dry location.

•Before next use, remember to clean your humidifier and install a new filter.

Consumer Relations

Mail questions or comments to: Kaz USA, Inc.

Consumer Relations Dept.

250 Turnpike Road, Southborough, MA 01772

Please be sure to specify model number.

Call us toll-free at: 1-800-477-0457; E-mail: [e-mail]

Or visit our website at: www.kaz.com

To Order Replacement Parts
V3700-Star Projector Cover	V3700-Tank
V3700-Star Projector Lens	V3700G-Tank (green)
V3700G-Star Projector Lens (green)	V3700P-Tank (purple)
V3700P-Star Projector Lens (purple)	V3700-Tank Cap
V3700-Filter Tray
Replacement Menthol Scent Pads-VSP-19/VSP-19-CAN
Replacement Soothing Sleepy Time Scent Pads VBR-5
Replacement filter part number WF2

STOP: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT KAZ CONSUMER RELATIONS OR SEE YOUR WARRANTY.

Electrical Ratings

The Vicks® models are rated at 120V, 60 Hz.

NOTE: DO NOT ATTEMPT TO OPEN THE MOTOR HOUSING YOURSELF. DOING SO MAY VOID YOUR WARRANTY AND CAUSE DAMAGE TO THE HUMIDIFIER OR PERSONAL INJURY.

8

Troubleshooting

Q:I hear the fan turning, but I don’t see any mist. Is my humidifier operating properly?

A:Dry air is pulled through the system and a fan disperses invisible, moisture balanced air. There is no “mist” emitted. When operating normally you will feel only cool air coming from the unit. Monitor the water level in your Tank/ Base. If you notice a decrease in the Water Tank over 24 hours then the unit is operating normally.

Q:My unit has been running for several hours. I hear the fan spinning, but I do not notice the water level in the tank decreasing.

A:First, check the filter to ensure it is wet. If the pad appears dry, remove it from the Base and gently rinse under cool water. Reposition wet filter in the Base. You may also want to note the current moisture level in your home. If the humidity level is over 60% the unit will not put out much moisture as your air is already saturated.

Q:My filter has turned light brown and rust colored. Do I need a new filter?

A:Probably not. Since your filter has been made with Protec™ antimicrobial the change in color indicates only a mineral deposit. Soak filter in a sink full of cool water to help break up deposits. The discoloration may remain but will not affect the humidifier’s performance.

Q:My humidifier doesn’t appear to be as clean as when I first purchased and/or I’m smelling an unpleasant odor. What should I do?

A:If you have been using your humidifier regularly for over 30 days, follow the cleaning instructions.

Q:How do I know if it’s time to replace my filter?

A:A buildup of impurities and minerals on the Wicking Filter (evidenced by discoloration of the Wicking Filter), an appreciable decrease in Humidifier output, the top of the Wicking Filter is not moist to the touch, the Wicking Filter has large holes or tears.

Q:I recently bought my humidifier and it is operating properly. The fan is running and the water level in the tank is decreasing but the room still feels very dry.

A:If you have just started using your humidifier it will take a few days to return the normal moisture balance to your room. Wood furniture, flooring, carpeting and other objects in the room will absorb moisture before it can re-saturate the air. If you run this humidifier with the door open you may be humidifying a larger area than this humidifier was intended for. Try running with the doors closed.

If your house does not have adequate insulation this could effect the amount of moisture your room is maintaining

Q:I’d like to know what my relative humidity level is in my house, how can I obtain this information?

A:You can purchase a device such as the Vicks V70/V70-CAN, called a hygrometer that will display the relative humidity level in your room.

9

3 Year Limited Warranty

You should first read all instructions before attempting to use this product.

A.This 3 year limited warranty applies to repair or replacement of product found to be defective in material or workmanship. This warranty does not apply to damage resulting from commercial, abusive, unreasonable use or supplemental damage. It also does not apply to the filter or Protec™ Cleaning Cartridge. Defects that are the result of normal wear and tear will not be considered manufacturing defects under this warranty.

KAZ IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you also may have other rights which vary from jurisdiction to jurisdiction. This warranty applies only to the original purchaser of this product from the original date of purchase.

B.At its option, Kaz will repair or replace this product if it is found to be defective in material or workmanship. Defective product should be returned to the place of purchase in accordance with store policy. Thereafter, while within the warranty period defective product may be returned to Kaz.

C.This warranty does not cover damage resulting from any unauthorized attempts to repair or from any use not in accordance with the instruction manual.

D.Return defective product to Kaz, Incorporated with a brief description of the problem. Include proof of purchase and a $10 US/$15.50 CAN check or money order

for handling, return packing and shipping charges. Please include your name, address and a daytime phone number. You must prepay shipping charges. Send to:

In U.S.A.:

Kaz USA, Inc.

Attn: Returns Department 4755 Southpoint Drive Memphis, TN 38118 USA

In Canada:

Kaz Canada, Inc.

Attn: Returns Department 510 Bronte Street South Milton, ON L9T 2X6 Canada

10
