VES FALA100/12V/TR Original Instructions Manual

FALA100/12V/TR

12V Bathroom Extract Fan

VES Andover Ltd Eagle Close Chandlers Ford Ind. Est Eastleigh Hampshire SO53 4NF
Tel: [phone] Fax: [phone] e-mail: [e-mail] web: www.ves.co.uk

Original Instructions : Installation, Operation & Maintenance Manual

ID Ref 915b • August 2014

Original Instructions : Installation, Operation & Maintenance Manual Original Instructions : Installation, Operation & Maintenance Manual

This manual must be read in full before Installation, Operation and
Maintenance of the units supplied. Please ensure that this document is
passed to the end user. This manual forms an integral part of the product
and should be kept for the working life of the product. Additional copies of
this and supporting documents are available by contacting VES or by
visiting www.ves.co.uk and following the 'Download O & M's' link.

IMPORTANT

The following symbols used within this document refer to potential dangers
or advice for safe operation

Indicates hazards associated with electric current and high
voltages

Indicates hazards that require safety advice for personnel
and/or potential unit/property damage

Indicates important information

fans are suitable for installation in Zone 1 and beyond the

zoning area (see below) The transformer be located beyond ZONE 2.

IMPORTANT

MUST

All FALA fans must be sited and installed in accordance with current IEE
Regulations BS7671 and the appropriate Building Regulations.
FALA100/12V/TR

FALA100/12V/TR is suitable for wall mounting only.
The fan should be installed in conjunction with an appropriate mounting kit
and consideration must be given to ensure that access to all moving parts of
the fan are restricted when the fan is in use.

Unit Description

The axial fan is suitable for bathroom extract applications;
for full unit details please see the unit specification later in the document.

Immediately upon receipt of your fan, check there is no
damage to the fan, and that the four fixing screws and matching wall plugs
are included within the ancillary bag. Also included is a 12V transformer
part number DMEL1010.
In the event of any damage having occurred or if any item is found to be
missing, it is essential to inform VES Andover Ltd. within 7 days of delivery
quoting sales order number and the unit type. After this period, VES would
be unable to accept any claim for damaged or missing goods.

FALA100/12V/TR

FALA100/12V/TR

FALA100/12V/TR ...............................12V extract fan c/w transformer

Part Number Description

Dimensions

ABCDØE FG(mm)

FALA100/12V/TR
DMEL1010

157 157 20 56 98 - - -

(Transformer) - - - - 147 86 66

A

B

C

D

Ø

1

zone

0

zone

2

zone

2

zone

2

zone

600mm

600mm

600mm

2250mm

IMPORTANT

Before attempting to carry out any work on our units, all accompanying
documentation including warning labels on the unit must be referenced.
Should it be necessary to remove any component ensure that these are
secured into position once reinstalled. It is critical that after any
maintenance work has been conducted that all components removed
/replaced be refitted correctly by a competent engineer.

F

E

G

IMPORTANT

All electrical work should be carried out by a qualified engineer and in
accordance with the current IEE Regulaons.
Before aempng to carry out any maintenance or repair work on our

units, the unit MUST BE COMPLETELY ISOLATED from its electrical supply.
Ensure a minimum of two minutes aer electrical disconnecon before
aempng access. This will allow any moving parts to come to a rest.

IMPORTANT

All wiring must be fixed securely and the cable to the fan should be a
minimum of 1.5mm² in secon. A double pole fused spur fied with a

3 amp fuse must be used and must be sited outside any room containing a
shower or fixed bath.

IMPORTANT

Before aempng to carry out any maintenance or repair work on our
units, the unit MUST BE COMPLETELY ISOLATED from its electrical supply.
Ensur

e a minimum of two minutes aer electrical disconnecon before

a

empng access. This will allow any moving parts to come to a rest.

VES Andover Ltd Eagle Close Chandlers Ford Ind. Est Eastleigh Hampshire SO53 4NF
Tel: [phone] Fax: [phone] e-mail: [e-mail] web: www.ves.co.uk

Original Instrucons : Installaon, Operaon & Maintenance ManualOriginal Instrucons : Installaon, Operaon & Maintenance Manual

WEEE Direcve

Ahe endoheir useful lifethe packaging andproduct should
be disposedof viaasuitable recyclingcentre. Donot dispose of
with normalhousehold waste. Do not burn.

Standards

FALA fans conform to all relevant Brish and European
standards and direcves. Further informaon is available
from VES Andover Ltd on request

Please ensurethahis documens passedon to the enduser

We reserve the right to alter the specificaon without noce
©VES Andover Ltd. 2010. No part of this publicaon may be
photocopied or otherwise reproduced without the prior
permission in wring of VES Andover Ltd.

Wiring Diagrams

Maintenance

1. Before cleaning, isolate the fan completely from the mains supply.

2. Carefully remove the front cover

3. T

o clean the front cover, either wipe it with a damp, lint free cloth or

wash it in warm soapy water. Thoroughly dry the front cover and refit.

4. Do not immerse the fan in water or other liquids to clean any other parts
of the fan.

5. Never use strong solvents to clean the fan.

6. Apart from cleaning, no other maintenance is required.

For replacement fans or install kits please visit www.vesdirect.co.uk

Specificaon

Power Supply (fan) 12V 50Hz. SELV

Operang Temperature 0~40°C

Insulaon Class Double insulated
Protecon (fan) IPX4

deveelSepyT rotoM

Power Supply (transformer) 230VAC 50Hz

0562)mpr( deepS

51)W( rewoP

21.0)A( tnerruC

Warranty

The fan is guaranteed against defects for 1 year from the date of purchase.
If you have any problems, contact VES at the address shown below.

Mark centre holes on
mounng surface then
drill out

Remove cover from
FALA fan

Original Instrucons : Installaon, Operaon & Maintenance Manual

Wire the fan as per

wiring diagram &
instrucons

Cable entry:
Use the cord grip as

provided

boom

Cable entry opons

Prepare hole in mounng
surface & plug mounng
holes as required

Replace front cover

Installaon connued

Secure fan backing
plate to mounng
surface

Standard
(Typical Installaon)

Transformer

DMEL1010

(Not Used)

1

230VAC 50Hz

12V

2

3

4

5

Fuse (3A)

Double Pole

Isolang Switch

L

L

N

N

Fan Terminals

FALA100/12V/TR

Cable entry:

Use the knock-out as

provided. Remove by hand
taking care not to damage
the surround fan casework

back




